OWNER’S MANUAL

LED LCD MONITOR

22EN43V

23EN43V

24EN43V

24EN43VS

27EN43V

Please read this manual carefully before operating

your set and retain it for future reference.

LED LCD MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 SettinguptheMonitorset

5 - AttachingtheStandBase

6 - DetachingtheStandBase

7 - Mountingonatable

7 - Usingthecableholder

9 - Mountingonawall

10 USINGTHEMONITORSET

10 ConnectingtoaPC

10 - D-SUBconnection

10 - DVI-Dconnection

10 - HDMIconnection

12 CUSTOMIZINGSETTINGS

13 CustomizingSettings

13 - MenuSettings

14 -Picture

15 -Color

16 -Display

16 -Volume

17 -Others

18 MYKEYSetting

19 FUNC.Setting

19 -PictureMode

20 -SUPERENERGYSAVING

21 -DUALDISPLAY

21 -DUALWEB

22 -MYKEYSetting

23 TROUBLESHOOTING

25 SPECIFICATIONS 

25 22EN43V

26 23EN43V

27 24EN43V

28 24EN43VS

29 27EN43V

30 PresetModes(Resolution)

30 HDMITIMING

30 Indicator

31 PROPERPOSTURE

31 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.



Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.



Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.



Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.



Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBody

(22EN43V/

23EN43V/24EN43V/24EN43VS)

StandBody

(27EN43V)

TwoScrews

(27EN43V)

StandBase

CD(Owner'sManual)/

Card

D-SUBCable

DVI-DCable

(Thiscableisnotincluded

inallcountries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator



LightingOn:Turnedon



LightingOff:Turnedoff

Connectionpanel(Seep.10)

Button(Seep.12)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION



StandBase

StandBody

Attachthe

StandBody

tothemonitorset.

Attachthe

StandBase

Tightenthescrewtotherightwithacoin.

22EN43V/23EN43V/24EN43V/24EN43VS

Attachthe

StandBody

tothemonitorset.

Usetwoscrewstofixthe

StandBody

and

monitorset.

Attachthe

StandBase

Tightenthescrewtotherightwithacoin.

StandBase

StandBody

27EN43V

ENG

ENGLISH

ASSEMBLING AND PREPARING

DetachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBase

StandBody

Pulloutthe

StandBody

and

StandBase



fromthemonitorset.

Turnthescrewtotheleftwithacoin.

Pulloutthe

StandBase



27EN43V

Turnthescrewtotheleftwithacoin.

Pulloutthe

StandBase

fromthe

StandBody

Removetwoscrewsandpulloutthe

Stand

Body

fromthemonitorset.

StandBase

StandBody



Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.



Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

22EN43V/ 23EN43V/24EN43V/24EN43VS

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

or

Usingthecableholder

Cableholder

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonawall

Forproperventilation,allowaclearanceof10cm

oneachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,

attachWallmountinginterface(optionalparts)to

thebackoftheset.

WhenyouinstalltheMonitorsetusingawall

mountinginterface(optionalparts),attachit

carefullysoitwillnotdrop.

Please,Usethescrewandwallmountinterface

inaccordancewithVESAStandards.

Ifyouusescrewlongerthanstandard,the

monitormightbedamagedinternally.

Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.In

thiscase,LGElectronicsisnotresponsiblefor

it.

VESAcompatible.

PleaseuseVESAstandardasbelow.



784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:Φ4.0mmxPitch0.7mmx

Length10mm



787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpad

andscrews.

10 cm



Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.



IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.



UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.



Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.



Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.



UsethescrewsthatarelistedontheVESA

standardscrewspecifications.



Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.



Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.



Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.



Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

CAUTION

NOTE

Model

22EN43V

23EN43V

24EN43V

24EN43VS

27EN43V

VESA(AxB)

75x75 100x100

Standardscrew

Numberofscrews

ENG

ENGLISH

USING THE MONITOR SET

USINGTHEMONITORSET

ConnectingtoaPC



YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnected

devicethatusersconnecttoaPCandturn

on,withoutdeviceconfigurationoruser

intervention.

D-SUBconnection

TransmitsanalogvideofromyourPCtothe

Monitorset.ConnectthePCandtheMonitorset

withthesuppliedD-sub15pinsignalcableas

showninthefollowingillustrations.



Macadapter

ForAppleMacintoshuse,aseparateplug

adapterisneededtochangethe15pin

highdensity(3row)D-SUBVGAconnector

onthesuppliedcabletoa15pin2row

connector.



WhenusingaD-Subsignalinputcable

connectorforMacintosh



IfyouuseHDMIPC,itcancausecompatibility

problem.

NOTE

DVI-Dconnection

TransmitsadigitalvideosignalfromyourPCto

theMonitorset.ConnectthePCandtheMonitor

setwithaDVIcableasshowninthefollowing

illustrations.

HDMIconnection

Transmitsthedigitalvideoandaudiosignalsfrom

yourPCorA/VtotheMonitorset.ConnectthePC

orA/VandtheMonitorsetwiththeHDMIcableas

showninthefollowingillustrations.

ENG

ENGLISH

USING THE MONITOR SET



WhenyouwanttousetwoPCinourMonitor,

pleaseconnectthesignalcable(D-SUB/

DVI-D/HDMI)respectivelyinMonitorset.



IfyouturntheMonitorsetonwhileitiscold,

thescreenmayflicker.Thisisnormal.



Somered,green,orbluespotsmayappear

onthescreen.Thisisnormal.



"SelfImageSetting"Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)



‘AUTO’Function.

Whenyouencounterproblemssuchas

blurryscreen,blurredletters,screenflicker

ortiltedscreenwhileusingthedeviceor

afterchangingscreenresolution,pressthe

AUTOfunctionbuttontoimproveresolution.

(OnlysupportedinAnalogMode)

NOTE NOTE



Connectthesignal

inputcableandtighten

itbyturningthescrews

clockwise.



Donotpressthescreenwithyourfingerfor

alongtimeasthismayresultintemporary

distortiononthescreen.



Avoiddisplayingafixedimageonthe

screenforalongperiodoftimetoprevent

imageburn.Useascreensaverifpossible.

CAUTION

SelfImageSettingFunction

Pressthepowerbuttononthebottompanelto

turnthepoweron.Whenmonitorpoweristurned

on,the"

SelfImageSetting

"Functionisexecuted

automatically.(OnlysupportedinAnalogMode)

ENG

ENGLISH

CUSTOMIZING SETTINGS

CUSTOMIZINGSETTINGS

 PressthedesiredbuttononthebottomoftheMonitorset.

 ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.

Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.

 Select

EXIT

toleavetheOSDmenu.

MonitorsetButtons

Button Description

Accessesthemainmenus.(Seep.13)

OSDLocked/OSD

Unlocked

Thisfunctionallowsyoutolockthecurrentcontrolsettings,so

thattheycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.

Themessage"OSDLOCKED"shouldappear.

YoucanunlocktheOSDcontrolsatanytimebypushing

theMENUbuttonforseveralseconds.Themessage"OSD

UNLOCKED"shouldappear.

UsethisbuttontoenterMYKEYmenu.Formoreinformation.(Seep.18)

UsethisbuttontoenterPictureMode,SUPERENERGYSAVING,DUALDISPLAY,

DUALWEB,MYKEYSettingmenus.(Seep.19)

Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR

SETUPOSD.(OnlysupportedinAnalogMode)

Thebestdisplaymode

1920x1080

Youcanchoosetheinputsignal.

• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI/

HDMI)youwant.

• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis

D-SUB.

EXIT

ExittheOSD(OnScreenDisplay).

(PowerButton)

Turnsthepoweronoroff.

PowerIndicator

Thepowerindicatorstaysredifthedisplayisrunningproperly

(OnMode).IfthedisplayisinSleepMode,thepowerindicator

blinksred.

ENG

ENGLISH

CUSTOMIZING SETTINGS

CustomizingSettings

MenuSettings

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu Analog Digital HDMI Description

Picture Sharpness ● ● ●

Toadjusttheclearnessofthescreen.

BlackLevel ●

Tosetoffsetlevel

Overscan

●

Toimprovetheclarityandstabilityofthescreen

Color Gamma

● ● ●

Tocustomizethecolorofthescreen

ColorTemp

Display Horizontal

●

Toadjustthepositionofthescreen

Vertical

Clock

●

Toimprovetheclarityandstabilityofthescreen

Phase

Volume

●

ToadjusttheVolume

Others Language

● ● ●

Tocustomizethescreenstatusforauser's

operatingenvironment

PowerIndicator



Analog:

D-SUB(Analogsignal)input.



Digital:

DVI-D(Digitalsignal)input.



HDMI:

HDMI(Digitalsignal)input.

Menu Analog Digital HDMI Description

Brightness

● ● ●

Toadjustthebrightness,contrastofthescreen

Contrast ● ● ●

Wide/Original

● ● ●

Wide

Switchtofullscreenmodeaccordingtoinputimagesignal.

Original

Changetheinputimagesignalratiotooriginal.

*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio

(16:9).

Reset

● ● ●

Restoreallfactorydefaultsettings.Pressthe

◄



,

►

buttonstoreset

immediately.

ENG

ENGLISH

CUSTOMIZING SETTINGS


 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Enterto


bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Picture Description

Sharpness

Toadjusttheclearnessofthescreen.

BlackLevel

Youcansettheoffsetlevel.Ifyouselect'High',thescreenwillbebrightandif

youselect‘Low’,thescreenwillbedark.(onlyforHDMIinput)

*Offset?Asthecriteriaforvideosignal,itisthedarkestscreenthemonitorcan

show.

Overscan ToselecttherangeofoutputimageforDTVtiminginHDMIinput.(onlyforHDMI

input)RecommendOverscanfunctiontoturnonwhenconnectAVequipment.

ENG

ENGLISH

CUSTOMIZING SETTINGS

Color

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Color

bypressingthe►button.

 Enterto

Color

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Color Description

Gamma

Setyourowngammavalue.:Gamma0,Gamma1,Gamma2onthemonitor,

highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay

blackishimages.

ColorTemp Custom

•Red:

Setyourownredcolorlevels.

•Green:

Setyourowngreencolorlevels.

•Blue:

Setyourownbluecolorlevels.

Selectthescreencolor.

Warm:

Setthescreentowarmcolortemperature(morered).

Medium:

Setthescreentomediumcolortemperature.

Cool:

Setthescreentocoolcolortemperature(moreblue).

ENG

ENGLISH

CUSTOMIZING SETTINGS

Display

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Display

bypressingthe►button.

 Enterto

Display

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Volume

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Volume

bypressingthe►button.

 Enterto

Volume

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Display Description

Horizontal

Tomoveimageleftandright.

Vertical

Tomoveimageupanddown.

Clock

Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The

horizontalscreensizewillalsochange.

Phase

Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontal

noiseandclearorsharpentheimageofcharacters.

Menu>NextMenu>Volume Description

Volume

ToadjusttheVolumeofheadphone/earphone.(OnlyforHDMIinput)

ENG

ENGLISH

CUSTOMIZING SETTINGS

Others

 Press

buttononthebottomoftheMonitorset

todisplaythe

OSD.

 Selectthe"

NextMenu

"buttontoenterthemore

optionsettings.

 Select

Others

bypressingthe►button.

 Enterto

Others

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

Menu>NextMenu>Others Description

Language

Tochoosethelanguageinwhichthecontrolnamesaredisplayed.

PowerIndicator

Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitorto

OnorOff.IfyousetOff,itwillgooff.

IfyousetOnatanytime,thepowerindicatorwillautomaticallybeturnedon.

ENG

ENGLISH

CUSTOMIZING SETTINGS

MYKEYSetting

 Press

MYKEY

buttononthebottomoftheMonitor

settodisplaythe

MYKEY

OSD.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Select

EXIT

toleavetheOSDmenu.

MYKEY Description

MYKEYSetting

MYKEYisshortkey.YoucanselectoneofFUNC.(PictureMode,SUPER

ENERGYSAVING,DUALDISPLAY,DUALWEB)asyourfavoritefeature.

Back

SelectBacktoreturnMYKEYmenu.

Eachoptionisexplainedbelow.

ENG

ENGLISH

CUSTOMIZING SETTINGS

FUNC.Setting

PictureMode

 Press

FUNC.

buttonon thebottomoftheMonitorset

todisplaythe

FUNC.

OSD. 

 Enterto

PictureMode

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

PictureMode Description

Custom

Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.

Text

Itisamodethatthescreenisadjustedtothebestforthetextworks.


Itisamodethatthescreenisadjustedtothebesttoviewpictures.

Cinema

Itisamodethatthescreenisadjustedtothebesttoviewthevideos.

Game

Itisamodethatthescreenisadjustedtothebesttoplayagame.

Eachoptionisexplainedbelow.

PCMode

AVMode

PictureMode Description

Custom

Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.

Vivid1

Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,brightness,Colour,

andsharpness.

Vivid2

Standard

Adjuststheimageforthenormalenvironment.

Cinema

Itisamodethatthescreenisadjustedtothebesttoviewthevideos.

ENG

ENGLISH

CUSTOMIZING SETTINGS





TOTALPOWERREDUCTION

:Howmuchpowerissavedwhileusingthemonitor.



TOTALCO2REDUCTION

:ChangetheTOTALPOWERREDUCTIONtoCO2.



SAVINGDATA(W/h)

546mm

(21.5inch)

584mm

(23inch)

609mm

(24inch)

600mm

(23.6inch)

685mm

(27inch)

SUPERSAVING 5W/h 6W/h 6W/h 6W/h 8W/h



SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel

vendor.



LGcalculatedthesevaluesbyusing

“broadcastvideosignal”

(includingbroadcastvideo:IEC62087)



SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING

function.

NOTE

SUPERENERGYSAVING

Press

FUNC.

buttononthebottomoftheMonitorsetto

displaythe

FUNC.

OSD.

 Select

SUPERENERGYSAVING

bypressingthe►

button.

 Enterto

SUPERENERGYSAVING

bypressingthe▼

button.

 Settheoptionsbypressingthe◄or►or▼buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheuparrow

( )button.

Eachoptionisexplainedbelow.

SUPERENERGYSAVING Description

EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-efficientfunction

Off

DisablesSUPERENERGYSAVING.

Reset

ResetsthevaluesoftotalenergyconsumptionreductionandCO2emissionreduction

estimates.

ENG

ENGLISH

CUSTOMIZING SETTINGS



NOTE



Whenmonitorgoestopowersavingmodewithpcsavingoption->Pressinganybutton->OSD

appearandusershouldpressdualbutton->Usercanbringbacktonormalmode.

DUALDISPLAY

Press

FUNC.

buttononthebottomoftheMonitorset

todisplaythe

FUNC.

OSD.

 Select

DUALDISPLAY

bypressingthe►button.

 Enterto

DUALDISPLAY

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.

Eachoptionisexplainedbelow.

DUALDISPLAY Description

Clone

ByselectingClone,usercanusesecondarymonitorasdonemodeofprimarymonitor.

Extended

ByselectingExtended,usercanusesecondarymonitorasextendedmodeofprimary

monitor.

Off

IfselectOff,DUALDISPLAYisoff.

DUALWEB

Press

FUNC.

buttononthebottomoftheMonitorset

todisplaythe

FUNC.

OSD.

 Select

DUALWEB

bypressingthe►button.

 Enterto

DUALWEB

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturntothe

uppermenuorsetothermenuitems,usetheup

arrow( )button.

*Beforeusingbelowfunctions,pleaseinstallDUALSMARTSOLUTIONprogramme.

Eachoptionisexplainedbelow.

DUALWEB Description

Helpusertobrowsewebefficientlybydividinginhalf.Helptoarrangeandmove

windowsonscreen.Helpusertocontroldividedwindowsratio.

Off

IfselectOff,DUALWEBisoff.

ENG

ENGLISH

CUSTOMIZING SETTINGS

Eachoptionisexplainedbelow.

MYKEYSetting

Press

FUNC.

buttononthebottomoftheMonitor

settodisplaythe

FUNC.

OSD.

 Select

MYKEYSetting

bypressingthe►button.

 Enterto

MYKEYSetting

bypressingthe▼button.

 Settheoptionsbypressingthe◄or►buttons.

 Select

EXIT

toleavetheOSDmenu.Toreturnto

theuppermenuorsetothermenuitems,use

theuparrow ( )button.

MYKEYSetting Description

PictureMode

PictureModeadjusttheMonitorsetforthebestpictureappearance.

SUPERENERGYSAVING

EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-effcient

function.

DUALDISPLAY

UsercanuseCloneorExtendedinanothermonitor.

DUALWEB

Helpusertobrowsewebefficientlybydividinginhalfandsomeotherconveniencein

browsingdualpages.

ENG

ENGLISH

TROUBLESHOOTING

Checkthefollowingbeforecallingforservice.

Noimageappears

Isthepowercordofthedisplay

connected?





Checkandseeifthepowercordisconnectedproperlytothepower

outlet.

Isthepowerindicatorlighton?





PressthePowerbutton.

Isthepoweronandthepower

indicatorRed?





Adjustthebrightnessandthecontrast.

Isthepowerindicatorflickering?





Ifthedisplayisinpowersavingmode,trymovingthemouseor

pressinganykeyonthekeyboardtobringupthescreen.





TrytoturnonthePC.

Doyouseean"OUTOFRANGE"

messageonthescreen?





ThismessageappearswhenthesignalfromthePC(videocard)is

outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe

'Specifications'sectionofthismanualandconfigureyourdisplay

again.

Doyouseea"NOSIGNAL"

messageonthescreen?





Whenthemonitorison"No-Signal"in5minutes,themonitorgoesto

DPMmode.

Doyouseea"OSDLOCKED"messageonthescreen?

Doyousee“OSDLOCKED”when

youpushMENUbutton?





Youcansecurethecurrentcontrolsettings,sothattheycannotbe

inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime

bypushingtheMENUbuttonforseveralseconds:themessage“OSD

UNLOCKED”willappear.

Displayimageisincorrect

DisplayPositionisincorrect.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Onthescreenbackground,vertical

barsorstripesarevisible.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Anyhorizontalnoiseappearingin

anyimageorcharactersarenot

clearlyportrayed.





Pressthe

AUTO

buttontoautomaticallyadjustyourdisplayimageto

theidealsetting.





Check

ControlPanel►Display►Settings

andadjustthedisplay

totherecommendedresolutionoradjustthedisplayimagetotheideal

setting.Setthecolorsettinghigherthan24bits(truecolor).

ENG

ENGLISH

TROUBLESHOOTING

Displayimageisincorrect

Thescreencolorismonoor

abnormal.





Checkifthesignalcableisproperlyconnectedanduseascrewdriver

tofastenifnecessary.





Makesurethevideocardisproperlyinsertedintheslot.





Setthecolorsettinghigherthan24bits(truecolor)at

ControlPanel



►



Settings

Thescreenblinks.





Checkifthescreenissettointerlacemodeandifyes,changeittothe

recommendresolution.

Doyouseean"Unrecognizedmonitor,Plug&Play(VESADDC)monitorfound"message?

Haveyouinstalledthedisplay

driver?





BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or

diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe

driverfromourwebsite:http://www.lg.com.





MakesuretocheckifthevideocardsupportsPlug&Playfunction.





Check

ControlPanel►Display►Settings

andseeifthefrequencyortheresolutionwere

changed.Ifyes,readjustthevideocardtotherecommendresolution.



Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe

screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.



ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned

abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer

orthevideocardmanufacturer.

CAUTION

Thescreenisflickering.

Didyouselecttherecommended

resolution?





IftheselectedresolutionisHDMI

1080i

60/50Hz,thescreenmay

beflickering.Changetheresolutiontotherecommendedresolution

1080P

ENG

ENGLISH

SPECIFICATIONS

SPECIFICATIONS 

Display ScreenType

54.6cm(21.5inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:54.6cm

PixelPitch

0.248mmx0.248mm(PixelPitch)

SyncInput HorizontalFrequency

30kHzto83kHz(Automatic)

VerticalFrequency

56Hzto75Hz(D-SUB,DVI-D)

56Hzto61Hz(HDMI)

InputForm

SeparateSync.Digital

VideoInput SignalInput

15pinD-SUBConnector/DVI-DConnector(Digital)

HDMIConnector

InputForm

RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max

D-SUB(Analog):1920x1080@60Hz

DVI/HDMI(Digital):1920x1080@60Hz

Recommend

VESA1920x1080@60Hz

Plug&Play

DDC2B(Analog,Digital,HDMI)

Power

Consumption

OnMode:25W(Typ.)

SleepMode≤0.3W

OffMode≤0.3W

PowerInput

19V

1.2A

AC-DCAdapter

TypeADS-40SG-19-319025G,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPG-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPBR-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPI-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPCU-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPB-2,manufacturedbySHENZHENHONORELECTRONIC

orTypeLCAP21,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-A,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-E,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-I,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-B,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypePSAB-L203A,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202B,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202C,manufacturedbyLGInnotekCo.,Ltd

orTypePSAB-L202D,manufacturedbyLGInnotekCo.,Ltd

OUTPUT:

19V 1.3A

Dimensions

(WidthxHeightx

Depth)

WithStand

50.8cmx38.5cmx18.1cm

WithoutStand

50.8cmx31.3cmx5.7cm

Weight

2.6kg

TiltRange

-5°to20°

Environmental

conditions

OperatingTemperature

OperatingHumidity

10°Cto35°C

10%to80%

StorageTemperature

StorageHumidity

-20°Cto60°C

5%to90%non-Condensing

StandBase

Attached(),Detached(O)

Powercord

Wall-outlettype

Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct

functions.

22EN43V

ENG

ENGLISH

SPECIFICATIONS

SPECIFICATIONS 

Display ScreenType

58.4cm(23inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:58.4cm

PixelPitch

0.265mmx0.265mm(PixelPitch)

SyncInput HorizontalFrequency

30kHzto83kHz(Automatic)

VerticalFrequency

56Hzto75Hz(D-SUB,DVI-D)

56Hzto61Hz(HDMI)

InputForm

SeparateSync.Digital

VideoInput SignalInput

15pinD-SUBConnector/DVI-DConnector(Digital)

HDMIConnector

InputForm

RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max

D-SUB(Analog):1920x1080@60Hz

DVI/HDMI(Digital):1920x1080@60Hz

Recommend

VESA1920x1080@60Hz

Plug&Play

DDC2B(Analog,Digital,HDMI)

Power

Consumption

OnMode:27W(Typ.)

SleepMode≤0.3W

OffMode≤0.3W

PowerInput

19V

1.3A
