Split System
AIR CONDITIONING RANGE
Australians love
a Kelvinator
Designed for simplicity, longevity and superior performance, you can simply sit back and
enjoy the benefits.
Brand
All Kelvintor products go through
rigorous testing to ensure they meet
stringent Australian performance and
quality standards.
Quality
Kelvinator air conditioners are built for
the harsh and varied Australian climate.
With corrosion resistance on both the
indoor and outdoor units, you can relax
knowing that your air conditioner will
last no matter where you live.
Heritage
With 90 years’ experience in
refrigeration systems, you know your
Kelvinator is a product backed by years
of innovation and the highest standards
of quality.
Warranty
For added peace of mind, all Kelvinator air
conditioners feature a five year parts and
labour warranty. This applies to all systems
purchased at an approved stockist or retailers,
properly sized for the selected room and
correctly installed by a licenced installer.
Expertise
Kelvinator air conditioners are backed by
our national Top Service after sales program
which includes delivery, home service and
spare parts.
Australians
love a Kelvinator
For over 90 years, Kelvinator has been
delivering reliability and performance to
Australian families. It’s a brand you can
trust to get the job done well and it’s
easy to see why. There’s peace of mind
in knowing that with Kelvinator, you will
be comfortable for years to come.
Discover the perfect blend of functional
design and practical innovation. An air
conditoner that looks great and performs
well is an asset to your home and makes life
that much more enjoyable.
Whether you live in the country or on the
coast, in a house or an apartment, there is a
Kelvinator air condioner to suit your needs.
What’s more, our air condioners are easy to
keep clean, simple to use and sensitive to the
environment, your family and your energy bill.
Easy, breezy cooling and heating
With user-friendly features like the wireless remote
control, multiple fan speeds and a 24-hour timer,
operating your Kelvinator air conditioner will be simple
and easy. When it’s time to shut down, simply activate
the self clean function to purge your air conditioner of
moisture to help prevent mould growth.
A breath of fresh air with advanced air filtration
Enjoy improved air quality with a combination of 3 filters.
A high density dust filter which filters and collects dust
from the airstream is combined with 2 additional special
filters. The BIO/HEPA filter purifies the air by eliminating
95% of bacteria and captures 99% of particles down
to 0.3µm while the Ion filter freshens the air to ensure
cleaner, fresher air in your home.
Create the perfect indoor environment
All Kelvinator split system air conditioners feature inverter
technology which ensures a quiet operation, they use less
energy and maintain the desired room temperature at all
times. Set the Follow Me mode and your air conditioner
will set the temperature to wherever the remote control is
located ensuring personalised comfort. Plus Turbo Mode
provides fast cooling and heating when you need it most.
Energy efficiency
With built-in features such as high efficiency DC
componentry and inverter technology these air
conditioners use less power than ever before. With
some models reaching a 5 star energy rating, year round
comfort can be more affordable for you and your family.
PeakSmart technology*
Energy-saving PeakSmart technology caps energy
consumption when the electricity network reaches
peak demand.
*only available in QLD
Not all features in all models.
Intelligent Inverter Technology
Kelvinator’s intelligent inverter technology
accurately controls the speed of the compressor
to meet the exact settings you have selected.
Low Noise Fan
A DC motor drives the indoor fan with a total
of 12 speed settings, providing the optimum
combination of temperature control and
low noise.
Multi-Level Filtration
Enjoy improved air quality with a combination
of 3 filters. A high density dust filter combined
with 2 additional special filters work together
to ensure cleaner, fresher air in your home.
Stylish
All models feature smooth fronts with gently
curved edges and an elegant clear trim. This
is offset by a concealed digital display which
can be turned off when watching a movie
or sleeping.
User-friendly Remote Control
A handy remote control with an easy-to-read
back-lit LCD and luminescent keypad lets
you conveniently control all functions, even
in low light
Follow Me
Select Follow Me and your air conditioner will
set the temperature based on a sensor in the
remote control. This ensures the temperature
is perfect, exactly where you want it to be.
Sleep Mode
Gently increases or decreases (reverse cycle
models in heating mode) the temperature to
adjust to your needs for a peaceful night’s sleep.
Energy consumption is also reduced, whilst
keeping the temperature at a comfortable level.
Powered Air Swing
At the touch of a button on the remote control,
the motorised louvres will oscillate the airflow up
and down providing even distribution of air in
your home.
Choosing the right air conditioner
Go to kelvinator.com.au/AirConSelectionWizard or refer to the table below.
1. Total size of room (m
2
)?
m
2
It’s important to select the right sized air conditioner for your room in order to ensure effective and efficient
cooling and heating.
ceiling insulated YES NO
main window facing north or west south or east north or west south or east
model room size m
2
room size m
2
room size m
2
room size m
2
split system inverter cooling only
KSV25CRG 16 18 14 16
KSV35CRG 22 24 16 19
KSV70CRG 46 48 40 44
split system inverter reverse cycle
KSV25HRG/KSD25HRG 16 18 14 16
KSV35HRG/KSD35HRG 22 24 16 19
KSV50HRG/KSD50HRG 30 33 26 29
KSV70HRG/KSD70HRG 46 48 40 44
KSV80HRG/KSD80HRG 57 59 51 56
This is a guide only. Values in chart apply if air conditioners are used under average conditions and installed in accordance with manufacturer’s instructions. Prior to
installation selection should be verified by your authorised Kelvinator retailer or a licenced installer.
Air conditioning features
3. Do you have ceiling insulation?
2. Direction the main
window faces?
4. Do you require an air conditioner
that heats and cools or cools only?
Reverse cycle
• Auto & manual operation
• 24 hour timer
• Auto restart
• Blue shield corrosion
protection
• 5 year warranty
• Climate control
• Inverter compressor
technology
• Ambient temperature
range -15°C to 50°C
• 2-way auto air swing
• Sleep mode
• HEPA filter and negative
ion filter
• Digital display
• Remote control
model
1
KSV25HRG
KSD25HRG
KSV35HRG
KSD35HRG
KSV50HRG
KSD50HRG
KSV70HRG
KSD70HRG
KSV80HRG
KSD80HRG
type heating & cooling heating & cooling heating & cooling heating & cooling heating & cooling
cooling capacity (kW) 2.5 3.5 5.0 7.0 8.0
cooling capacity (Btu/h) 8500 11900 17100 23900 27300
heating capacity (kW) 3.2 4.0 6.0 8.0 9.0
heating capacity (Btu/h) 10900 1360 0 20500 27300 30700
running current (A) 2.9 4.1 6.5 9.9 11.1
maximuim current (A) 9.5 10.5 15.5 17.5 19.5
indoor unit dimensions
w x h x d (mm)
802 x 297 x 189 802 x 297 x 189 1080 x 335 x 226 1080 x 335 x 226 1080 x 335 x 226
outdoor unit dimensions
w x h x d (mm)
885 x 554 x 365 885 x 554 x 365 924 x 702 x 382 924 x 702 x 382 1040 x 810 x 455
performance
indoor sound pressure (dBA)
high/low fan setting
42/25 42/25 49/32 50/33 50/34
outdoor sound power max.
(dBA)
60.5 59.4 64.1 65.0 66.8
ambient temperature
range
2
(°C)
-15°C to 50°C -15°C to 50°C -15°C to 50°C -15°C to 50°C -15°C to 50°C
indoor air circulation
max (m
3
/h)
600 600 1200 1170 1200
moisture removal (L/h) 1.0 1.2 1.9 2.4 3.0
energy star rating cool/heat 5.0/5.0 4.0/4.0 3.5/3.5 2.5/2.5 2.5/2.5
1
Models with model codes commencing with KSD are DRED enabled
2
May operate outside this range but at less than rated performance.
Please note: By law, only a licensed Room Air Conditioner installer is allowed to install split system models. In accordance with the Electrolux warranty,
Electrolux is not liable if the appliance is damaged by incomplete or improper installation. † Refer to product information details on page 7. For further
information on our Kelvinator air conditioning range, or to obtain dimension and installation requirements please call 1300 363 640 or visit kelvinator.com.au
Specifications
KSV50HRG, KSD50HRG, KSV70HRG, KSD70HRG, KSV80HRG, KSD80HRGKSV25HRG, KSD25HRG, KSV35HRG, KSD35HRG
model KSV25CRG KSV35CRG KSV70CRG
type cooling cooling cooling
cooling capacity (kW) 2.5 3.5 7.0
cooling capacity (Btu/h) 8500 11900 23900
running current (A) 2.3 3.6 8.7
maximuim current (A) 9.5 10.5 17. 5
indoor unit dimensions
w x h x d (mm)
802 x 297 x 189 802 x 297 x 189 1080 x 335 x 226
outdoor unit dimensions
w x h x d (mm)
885 x 554 x 365 885 x 554 x 365 924 x 702 x 382
performance
indoor sound pressure (dBA)
high/low fan setting
42/25 42/25 50/33
outdoor sound power max. (dBA) 60.5 59.4 65.0
ambient temperature
range
1
(°C)
17°C to 50°C 17°C to 50°C 17°C to 50°C
indoor air circulatiuon max (m
3
/h) 600 600 1170
moisture removal (L/h) 1.0 1.2 2.4
energy star rating
5.0 4.0 2.5
1
May operate outside this range but at less than rated performance.
Please note: By law, only a licensed Room Air Conditioner installer is allowed to install split system models. In accordance with the Electrolux warranty, Electrolux
is not liable if the appliance is damaged by incomplete or improper installation. † Refer to product information details on page 7. For further information on our
Kelvinator air conditioning range, or to obtain dimension and installation requirements please call 1300 363 640 or visit kelvinator.com.au
Specifications
Cooling only
KSV70CRGKSV25CRG, KSV35CRG
• Auto & manual operation
• 24 hour timer
• Auto restart
• Blue shield corrosion
protection
• 5 year warranty
• Climate control
• Inverter compressor
technology
• Ambient temperature
range 17°C to 50°C
• 2-way auto air swing
• Sleep mode
• HEPA filter and negative
ion filter
• Digital display
• Remote control
Piping length elevation & additional quantity of gas
Model
Suction pipe
diameter
Discharge pipe
diameter
Maximum
pipe
length (A)
Maximum height
difference between
indoor & outdoor
units (B)
Standard
pre-charged
pipe length
Additional
refrigerant for
pipe length above
precharge length
KSV25CRG, KSV25HRG,
KSD25HRG
Ø9.52mm (3/8") Ø6.35 (1/4") 25m 10m 5m 15g/m
KSV35CRG, KSD35HRG,
KSD35HRG,
Ø12.7mm (1/2") Ø
6.35 (1/4") 25m
10m 5m 15g/m
KSV50HRG, KSD50HRG Ø12.7mm (1/2") Ø6.35 (1/4")
30m
20m 5m 15g/m
KSV70CRG, KSV70HRG,
KSD70HRG
Ø15.9 (5/8") Ø
9.52 (3/8") 50m
25m 5m 30g/m
KSV80HRG, KSD80HRG Ø
15.9 (5/8")
Ø
9.52 (3/8") 50m
25m 5m 30g/m
Installation of air conditioners must be performed in accordance with all applicable
Standard(s), Code(s), Regulation(s), Act(s) and local Service Rule(s). By law, only a
licensed Room Air Conditioner installer is allowed to install split system models.
In accordance with the Kelvinator warranty, Kelvinator is not liable if the appliance
is damaged by incomplete or improper installation.
Outdoor unit must be accessible for service. If the outdoor unit is located greater
than 2m above ground, additional service charges may apply.
Outdoor
Unit
Indoor
Unit
B
A
Installation requirements
†product information
The descriptors and illustrations in this publication apply to the specific products and models described as at the date of issue. Under our policy of continuous
product development, product specifications may change without notice. Prospective purchasers should therefore check with their retailer to ensure this
publication correctly describes the products that are being offered for sale. All information supplied is to be used for general reference purposes only and is on
the understanding that Electrolux Home Products Pty Ltd will not be liable for any loss, liability or damage of whatever kind arising as a result of reliance on such
information. Colours of products illustrated are as close as printing limitations allow. Electrolux will at all times comply with its obligations pursuant to law including
Trade Practices (Australian Consumer Law) Act and Regulations.
Delivery
The purchase of a new appliance is an exciting experience. Kelvinator customers can, for an additional charge, choose to have their new
appliance delivered by our experienced staff. Delivery is available in Adelaide, Brisbane, Melbourne, Perth and Sydney. Delivery may not
be available in some rural locations.
Home service
Home Service is provided for repairs to appliances by trained technicians. For repairs to appliances that are outside the manufacturer’s
warranty period and not required as a result of a manufacturing defect, a service fee is payable. Home Service is available Australia-wide
on all models.
Spare parts
Home Service and Spare Parts can be contacted by phoning 13 13 49 for Service and 13 13 50 for Spare Parts (for the cost of a local call)
or visit our website at electrolux.com.au
Warranty
Electrolux Home Products warrants that for domestic or equivalent applications the Kelvinator products featured in this brochure are
free from defects in materials and workmanship for 2 years. This is extended by an additional 3 years if evidence is provided that the unit
was installed by a licensed Air Conditioner installer.
All warranties are subject to the conditions set out in the warranty card accompanying the product when purchased.
Electrolux Top Service
Electrolux Top Service encompasses our after sales service including delivery, home service and spare
parts for Kelvinator air conditioners.
Electrolux Home Products Australia
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: kelvinator.com.au
Kelvinator. We are part of the Electrolux Family.
To add a touch of professional inspiration to your home,
visit electrolux.com.au
© 2016 Electrolux Home Products Pty Ltd
KBRO_AirCare_Aug16
