www.beko.com.tr
BDF1630X
EN
Document Number :
15 9486 0100_AA_BEKO_C6AU_EN/ 22-06-18.(15:46)
Dishwasher
User’s Manual
www.beko.com.tr
Explanation of symbols
Throughout this User Manual the following symbols are used:
C
Important information or useful
hints about usage.
A
Warning for hazardous situations
with regard to life and property.
B
Warning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other wastes.
Take them to the packaging material collection points designated by the local authorities.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from your product which has been manufactured
with high quality and state-of-the-art technology. Therefore, please read this entire user
manual and all other accompanying documents carefully before using the product and
keep it as a reference for future use. If you handover the product to someone else, give
the user manual as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
This product was manufactured using the latest technology in environmentally friendly conditions.
CONTENTS
1 INSTRUCTIONS FOR SAFETY
AND ENVIRONMENT 4
General safety .......................................4
Intended use ..........................................4
Children’s safety .................................... 5
Disposing of packaging material ........5
Transportation of the product ............5
Compliance with WEEE Directive and
Disposing of the Waste Product .........6
Compliance with RoHS Directive ........6
Package information ............................6
2 DISHWASHER 7
Overview ................................................7
Fan drying system .................................8
Technical specications .......................8
3 INSTALLATION 9
Appropriate installation location .......9
Connecting water supply .....................9
Connection to the drain .................... 10
Adjusting the feet .............................. 10
Aquasafe+ ........................................... 11
Electrical connection ..........................11
Initial use ..............................................11
4 PREPARATION 12
Tips for energy saving ........................12
Detergent .............................................12
Tablet detergents ...............................13
Rinse aid ...............................................13
Items not suitable for washing in the
dishwasher ...........................................14
Placing the dishes into the
dishwasher ...........................................14
Cutlery basket .....................................16
Collapsible lower basket tines ..........17
Tray Wash Supports ........................... 18
SoftTouch Accessory ......................... 18
Lower Basket Glass Holder ............... 18
Lower basket multipurpose / height
adjustable service rack ..................... 19
Lower basket bottle wire .................. 20
Upper basket height adjustable
rack ....................................................... 20
Upper basket multipurpose service
rack ....................................................... 20
Adjusting the height of the upper
basket
...................................................21
Collapsible upper basket wires ........ 22
Height setting with empty basket .. 22
Ceiling cutlery basket ........................ 23
Silverware basket piece .................... 24
5 OPERATING THE PRODUCT 25
Keys ...................................................... 26
Preparing the machine...................... 26
Programme selection ........................ 26
Auxiliary functions ............................ 28
Programming the washing time ...... 29
Cancelling the programme ................31
Adjusting the amount of rinse aid ....31
InnerClean ........................................... 32
End of programme ............................. 32
Overowing warning ......................... 32
6 MAINTENANCE AND
CLEANING 33
Cleaning the outer surface of the
product ................................................ 33
Cleaning the interior of the machine 33
Cleaning the lters ............................ 33
Cleaning the hose lter ..................... 34
Cleaning the impellers ...................... 35
Lower impeller .................................... 35
Upper impeller ................................... 35
7 TROUBLESHOOTING 36
4 Dishwasher / User’s Manual/42 EN
instructions for safety and environment
1
This section contains safety
instructions that will help to get
protected from risk of personal
injury or property damage. Failure
to follow these instructions shall
void all warranties.
General safety
• Never place the product
on a carpet-covered floor;
otherwise, lack of airflow
beneath the product will
cause electrical parts to
overheat. This will cause
problems with your product.
• Do not operate the product
if the power cable / plug is
damaged! Call the Authorised
Service Agent.
• Connect the product to a
grounded outlet protected
by a fuse complying with
the values in the “Technical
specifications” table. Do
not neglect to have the
grounding installation made
by a qualified electrician. The
manufacturer shall not be
liable for any damages that
will arise when the product
is used without grounding
in accordance with the local
regulations.
• The water supply and
draining hoses must be
securely fastened and remain
undamaged.
• Unplug the product when not
in use.
• Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
• Never touch the plug with
wet hands! Never unplug by
pulling on the cable, always
pull out by grabbing the plug.
• The product must be
unplugged during installation,
maintenance, cleaning and
repairing procedures.
• Always have the installation
and repairing procedures
carried out by the Authorised
Service Agent. Manufacturer
shall not be held liable for
damages that may arise from
procedures carried out by
unauthorised persons.
• Never use chemical solvents
in the product. They bring
forth the risk of explosion.
• When you pull the upper and
lower baskets out completely,
the door of the product will
bear all the weight of the
baskets. Do not put other
loads on the door; otherwise,
the product may tilt.
• Never leave the door of
the product open apart
from loading and unloading
procedures.
• Do not to open the door of
the product when it is running
unless necessary. Be careful
for the rush of hot steam
when you open the door.
Intended use
• This product has been
designed for domestic use.
• It must be used to do the
domestic type dishes only.
Dishwasher / User’s Manual
5 / 42
EN
instructions for safety and environment
• This appliance is intended
to be used in household and
similar applications such as:
- Staff kitchen areas in shops,
offices and other working
environments;
- Farm houses;
- By clients in hotels, motels
and other residential type
environments;
- Bed and breakfast type
environments
• Only dishwasher safe
detergents, rinse aids and
additives must be used.
• The manufacturer waives
any responsibility arisen
from incorrect usage or
transportation.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical,sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
Chldren’s safety
• Electrical products are
dangerous for the children.
Keep children away from the
product when it is in use. Do
not let them to tamper with
the product.
• Do not forget to close the door
of the product when leaving
the room where it is located.
• Store all detergents and
additives in a safe place away
from the reach of the children.
Dsposng of
packagng materal
Packaging materials are
dangerous to children. Keep
packaging materials in a safe place
away from reach of the children.
Packaging materials of the
product are manufactured from
recyclable materials. Dispose
of them properly and sort in
accordance with recycled waste
instructions. Do not dispose
of them with normal domestic
waste.
Transportaton of the
product
A
If you need to move the
product, do it in upright
position and hold from
the rear side. Slanting
the product onto its
front side may cause the
electronic parts in it get
wet and damaged.
6 Dishwasher / User’s Manual/42 EN
instructions for safety and environment
1. Unplug the product before
transporting it.
2. Remove water drainage and
water supply connections.
3. Drain the remaining water in
the product completely.
Complance wth
WEEE Drectve and
Dsposng of the
Waste Product
This product complies with
EU WEEE Directive
(2012/19/EU). This product
bears a classification symbol
for waste electrical and electronic
equipment (WEEE).This product
has been manufactured with high
quality parts and materials which
can be reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the
collection center for the recycling
of electrical and electronic
equipment. Please consult your
local authorities to learn about
these collection centers.
Complance wth RoHS
Drectve
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
Package nformaton
Packaging materials of the
product are manufactured from
recyclable materials in accordance
with our National Environment
Regulations. Do not dispose
of the packaging materials
together with the domestic or
other wastes. Take them to the
packaging material collection
points designated by the local
authorities.
Dishwasher / User’s Manual
7 / 42
EN
Dishwasher
2
Overvew
1. Upper basket
2. Upper impeller
3. Lower impeller
4. Silverware basket
5. Door
6. Rating Label
7. Control panel
8. Detergent dispenser
9. Lower basket
10. Filters
11. Salt reservoir lid (depends on model)
12. Upper basket rail
13. Upper cutlery basket (depends on model)
14. Tabletop (depends on model)
15. Fan drying system (depends on model)
15
8 Dishwasher / User’s Manual/42 EN
Dishwasher
Techncal specfcatons
Compliance to standards and test data / EC declaration of conformity
This product complies with the following EU directives;
Development, production and sales stages of this product comply with the safety
rules included in all pertaining European Community regulations.
2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242
Power input 220-240 V, 50 Hz (see rating label)
Total power consumption 1800-2100 W (see rating label)
Heater power consumption 1800 W (see rating label)
Total current (depends on the model) 10 A (see rating label)
Drain pump power consumption 30 W (see rating label)
Water pressure 0.3 –10 bar (= 3 – 100 N/cm² = 0.01-1.0
Mpa)
C
Technical specifications may be changed without prior notice to improve the
quality of the product.
C
Figures in this manual are schematic and may not match the product exactly.
C
Values stated on the markings of the product or in the printed documents
accompanying the product are obtained in the laboratory on basis of the relevant
standards. Depending on operational and environmental conditions of the
product, these values may vary.
Note for test institutions:
Data required for performance tests shall be provided upon request. Requests can be
e-mailed to the following address:
dishw[email protected]om
Do not forget to provide the code, stock and serial numbers of the product to be tested in
your request e-mail along with your contact information. Code, stock and serial numbers of
the product may be found on the type label attached to the side wall of the door.
Fan dryng system
(depends on model)
Fan drying system ensures efficient drying of your dishes.
It is normal to hear a different sound than that of washing cycle during fan operation.
Dishwasher / User’s Manual
9 / 42
EN
3
Installation
Refer to the nearest Authorised Service
Agent for installation of your product. To
make the product ready for use, make sure
that the electricity, tap water supply and
water drainage systems are appropriate
before calling the Authorised Service Agent.
If they are not, call a qualified technician
and plumber to have any necessary
arrangements carried out.
C
Preparation of the location and
electrical, tap water and waste
water installations at the place
of installation is the customer's
responsibility.
B
Installation and electrical
connections must be carried
out by the Authorised Service
Agent. Manufacturer shall not
be held responsible for damages
arising from processes carried
out by unauthorised persons.
A
Prior to installation, visually
check if the product has any
defects on it. If so, do not have
it installed. Damaged products
cause risks for your safety.
C
Make sure that the water inlet
and discharge hoses are not
folded, pinched or crushed
while pushing the product into
its place after installation or
cleaning procedures.
When placing the product, pay attention not
to damage the floor, walls, piping, etc. Do
not hold the product by its door or panel to
move it.
Approprate nstallaton
locaton
• Place the product on a solid and flat
floor that has sufficient load carrying
capacity! The product must be installed
on a flat surface in order for the door to
be closed comfortably and securely.
• Do not install the product at places
where temperature may fall below 0ºC.
• Place the product at least 1 cm away
from the edges of other furniture.
• Place the product on a rigid floor. Do
not place it on a long pile rug or similar
surfaces.
B
Do not place the product on the
power cable.
• Make sure that you select a location
that will allow you to load and unload
the dishes in a fast and comfortable
manner.
• Install the product in a place close to
the tap and the drain hole. Select the
installation location by considering
that it will not be changed after the
connections are made.
Connectng water supply
C
We recommend attaching a
filter on the house/apartment
supply water inlet to protect the
machine from damages that
may arise from impurities (sand,
dirt, rust, etc.) coming from the
urban water supply system or
from your own water system as
well as to prevent complaints
such as yellowing or sludge
accumulation at the end of
washing.
10 Dishwasher / User’s Manual/42 EN
Installation
Permitted water temperature: up
to 25°C
The dishwasher should be connected to cold
water inlet.
• Do not use old or used water inlet hose
on the new product. Use the new water
inlet hose supplied with the product.
• Connect the water inlet hose directly
to the water tap. Pressure coming from
the tap should be minimum 0.3 and
maximum 10 bars. If the water pressure
exceeds 10 bars, a pressure relief valve
should be installed in between.
• Open the taps completely after making
the connections to check for water
leaks.
C
Use a screw-on hose connector
to connect the water inlet hose
to a water tap with a ¾ inch
external thread. If required, use
a filter insert to filter deposits
from the pipes.
A
For your safety, close the water
inlet tap completely after the
washing programme is over.
Connecton to the dran
Water discharge hose can directly be
connected to the drain hole or sink’s
drainage. The length of this connection must
be min. 50 cm and max. 100 cm from the
floor. A discharge hose longer than 4 meters
causes dirty washing.
Attach the water discharge hose to the
drainpipe without bending it. Tightly fix the
water discharge hose to the drainpipe in
order to prevent any dislocation of the water
discharge hose during operation of the
product.
min
300
min
120
max 1000
min 500
C
Drainpipe must be connected
to the sewage system and it
should not be connected to any
surface water.
Adjustng the feet
If the door of the product cannot be closed
properly or if the product swings when you
push it slightly, then you need to adjust
the feet of the product. Adjust the feet of
the product as illustrated in the installation
manual supplied with the product.
A
Diswashers door must be
aligned properly otherwise hot
steam can escape! Danger of
serious burns, other injury or
may damage furniture.
Dishwasher / User’s Manual
11 / 42
EN
Installation
• The voltage and allowed fuse or
breaker protection are specified in the
“Technical specifications” section. If the
current value of the fuse or breaker in
the house is less than 16 Amps, have
a qualified electrician install a 16 Amp
fuse.
• The specified voltage must be equal to
your mains voltage.
• Do not make connections via extension
cables or multi-plugs.
B
Damaged power cables must
be replaced by the Authorised
Service Agent.
B
If your dishwasher is equipped
with internal illumination, lamp
should only be replaced by the
Authorised Service Agent in case
of failures that may occur on the
lamp.
B
If the product has a failure, it
should not be operated unless
it is repaired by the Authorised
Service Agent! There is the risk
of electric shock!
Intal use
Before starting to use the product, make
sure that all preparations are made in
accordance with the instructions in sections
“Important safety instructions” and
“Installation”.
•
A
There might be a small amount
of water left in the product after
factory quality control tests. This
has no harm on the product.
Aquasafe+
(depends on model)
The Aquasafe+ system protects against
water leaks that may occur at the hose inlet.
Water contact with the valve box of the
system must be avoided to prevent damage
to the electrical system. If the Aquasafe+
system is damaged, unplug the product and
call the Authorised Service Agent.
A
As the hose set contains
electrical connections and
assemblies, never shorten
or lengthen the hose with
extension hoses.
Electrcal connecton
Connect the product to a grounded outlet
protected by a fuse complying with the
values in the “Technical specifications” table.
The manufacturer shall not be liable for any
damages that will arise when the product is
used without grounding in accordance with
the local regulations.
• Connection must comply with national
regulations.
• Power cable plug must be within easy
reach after installation.
B
Unplug the product after the
washing programme is over.
12 Dishwasher / User’s Manual/42 EN
Preparation
4
Tps for energy savng
Following information will help you use the
product in an ecological and energy-efficient
manner.
Wipe away any coarse food remnants on the
dishes before putting them in the product.
Operate the product after filling it
completely.
When selecting a programme, consider
the table of "Programme data and average
consumption values".
Do not put more detergent than suggested
on the detergent package.
Detergent
You can use powder, liquid/gel or tablet
detergents in the machine.
A
Only use in the machine the
detergents produced particularly
for use with dishwashers.
We recommend you not use
detergents that contain chlorine
and phosphate as they are
harmful for the environment.
Adding detergent
C
Pay attention to the warnings
on the detergent packaging
to get better washing and
drying results. Contact the
manufacturer of the detergent
for further questions.
A
Do not put solvents into the
detergent dispenser. There is
the risk of explosion!
Put the detergent into the detergent
dispenser just before operating the machine
as illustrated below.
1. Push the latch to right to open the
detergent dispenser lid (A).
2. Put suggested amount of powder,
liquid/gel or tablet detergent in the
reservoir.
C
Inside the detergent dispenser
there are level markings that
help you use appropriate amount
of powder detergent. When
brimful, detergent dispenser will
contain 45 cm³ of detergent.
Fill detergent up to 15 cm³ or 25
cm³ level marks in the detergent
dispenser according to fullness
of the machine and/or soiling
degree of the dishes. One
tablet is enough if you are using
detergent tablets.
3. Push the lid of the detergent dispenser
to close it. A "click" will be heard when
the lid is closed.
Dishwasher / User’s Manual
13 / 42
EN
Preparation
1
2
3
C
Use powder or liquid/gel
detergent in short programmes
without prewash since the
solubility of the tablet detergent
changes depending on the
temperature and time.
Tablet detergents
C
Observe the instructions of the
detergent manufacturer on
the package when using tablet
detergents.
C
Contact the detergent
manufacturer if your dishes
are wet and/or if you notice
limescale spots particularly on
your glasses after the washing
programme is over when using a
tablet detergent.
Rnse ad
C
The rinse aid used in
dishwashers is a special
combination that aims to
increase drying efficiency and
prevent water or lime stains
on the washed items. For this
reason, care must be paid
to have rinse aid in the rinse
aid reservoir and to use rinse
aids produced specially for
dishwashers only.
1. Open the lid of the rinse aid reservoir
with the help of the latch.
2. Fill the reservoir until “MAX” level.
3. Slightly press the point (B) of the
reservoir lid to close it.
14 Dishwasher / User’s Manual/42 EN
Preparation
C
Decorative prints of chinaware
as well as aluminium and silver
items may get discoloured or
tarnished after washing in the
dishwasher just as it happens
in handwashing as well. Some
delicate glass types and crystals
may become dull in time. We
strongly recommend you to
check if the tableware you are
going to purchase is suitable
for washing especially in the
dishwasher.
Placng the dshes nto the
dshwasher
You can use your dishwasher in the optimum
way with respect to energy consumption
and washing and drying performance only if
you place the dishes in an orderly way.
• Wipe away any coarse food remnants
(bones, seeds, etc.) on the dishes
before placing them in the dishwasher.
• Place thin, narrow pieces in the middle
sections of baskets if possible.
• Place the heavily soiled and bigger
items in the lower basket and smaller,
delicate and light items in the upper
basket.
• Place the hollowed dishes such as
bowls, glasses and pans upside down in
the dishwasher. Thus, accumulation of
water in deep hollows is prevented.
A
To prevent possible injuries,
always place the sharp and
pointed dishes such as service
fork, bread knife, etc. upside
down so as their pointed ends
will face down or they will lie
horizontally in the dish basket.
Unload dishes in the lower basket first and
then the dishes in the upper basket.
4. If there are stains on tableware items
after washing, level must be increased
and if there is a blue trace after wiping
them by hand, it must be decreased.
This is set to position 3 as factory
default.
C
The rinse aid adjustment is
described under "Adjusting
the amount of rinse aid" in
the section for operating the
machine.
C
Wipe clean any spilled rinse
aid outside the reservoir. Rinse
aid that spilled accidentally
will cause foaming and it will
eventually decrease washing
performance.
Items not sutable for
washng n the dshwasher
• Never wash dishes soiled by cigarette
ash, candle remnants, polish, dyestuff,
chemicals, etc. in your dishwasher.
• Do not wash silverware and cutlery
with wooden or bone stems, glued
pieces, or pieces that are not resistant
to heat, as well as copper and tin-plated
containers in the dishwasher.
Dishwasher / User’s Manual
15 / 42
EN
Preparation
Suggestions for loading the dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Improper Loading Of Dishware
16 Dishwasher / User’s Manual/42 EN
Preparation
Cutlery basket
(depends on model)
Cutlery basket is designed to wash your
dishes such as knife, fork, spoon, etc. in an
efficient manner.
Since the cutlery basket can be moved (A,
B), you can create more space while placing
your dishes in the lower basket and free up
space for your dishes of different sizes.
Cutlery basket
(depends on model)
Cutlery basket is designed to wash your
dishes such as knife, fork, spoon, etc. in an
efficient manner.
Since the cutlery basket can be moved (A,
B), you can create more space while placing
your dishes in the lower basket and free up
space for your dishes of different sizes..
Dishwasher / User’s Manual
17 / 42
EN
Preparation
C
Bringing the tines to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, it will
be appropriate to bring the tines
in the middle to horizontal or
vertical position by holding them
from their stems and pushing in
the direction of arrow.
Collapsble lower basket
tnes
(depends on model)
There are foldable tines (A) located at the
lower basket of the machine are designed
for an easier placement of large pieces such
as pans, bowls, etc. You can create larger
spaces by folding each tines individually or
all of them at once.
To bring the collapsible tines into horizontal
position, grab the tines from mid position
and push them in the directions of arrows
(B). To bring the tines back to vertical
position, just lift them up. Collapsible tines
will click into the latch again (C).
18 Dishwasher / User’s Manual/42 EN
Preparation
Tray Wash Supports
(depends on model)
Use the supports to wash trays in the
bottom basket.
See the Auxiliary functions section for
appropriate programme and function
selection.
SoftTouch Accessory
(depends on model)
The SoftTouch Accessory found in the lower
basket of your machine enables a safe
washing for your fragile glasses.
Lower Basket Glass Holder
(depends on model)
Lower Basket Glass Holder found in the
lower basket of your machine enables a safe
washing for your oversized and tall glasses.
Dishwasher / User’s Manual
19 / 42
EN
Preparation
Lower basket multpurpose
/ heght adjustable servce
rack
(depends on model)
This accessory located at the lower basket
of your machine allows you to easily wash
pieces such as extra glasses, long ladles and
bread knives.
C
You may use the racks as
required by moving them to
lower or upper position, or close
them to create a wider space in
your lower basket.
A
Make sure that the impeller does
not touch the dishes you placed
on the racks.
To close the racks:
1. Fold the rack (A).
2. Slide the rack up (B).
3. Put the rack in vertical position (C).
4. Slide the rack down and lock it by the
tabs (D).
C
You may open the racks in the
same process in reverse order.
To adjust the height of the racks:
1. Fold the rack (E).
2. Slide the rack up (F).
3. Open the rack at the desired level (G).
20 Dishwasher / User’s Manual/42 EN
Preparation
Upper basket multpurpose
servce rack
(depends on model)
This accessory located at the upper basket
of your machine allows you to easily wash
pieces such as extra long ladles and bread
knives.
You can lift up the upper basket
multipurpose service rack to remove it if you
do not want to use it.
If you want to use the upper basket
multipurpose service rack again, you can
easily attach it to the side section of your
upper basket.
Upper basket heght
adjustable rack
(depends on model)
Use the lower and upper parts of the height
adjustable racks in the upper basket of
the machine by sliding them down or up
according to the heights of the glasses, cups
or etc. (A, B, C).
Lower basket bottle wre
(depends on model)
The bottle wire is designed for easier
washing of long pieces with wide mouths.
You may take out the bottle wire from the
basket when not in use by pulling it out from
both sides (H).
These racks are detachable as well. It is
recommended that you should detach the
rack on the front left corner of the basket to
place the silverware basket piece if needed.
Dishwasher / User’s Manual
21 / 42
EN
Preparation
To lower the basket, while it is in the
uppermost position;
1. Hold the upper basket wires with both
hands, slightly lift up the basket and
simultaneously push and release the
latches shown in the figure (B).
2. Lower the basket from its current
position to the lower one.
3. Release the basket after it has reached
one level down.
Repeat the process if the height is not
sufficient.
1
2
3
C
The movement mechanism
may not function properly if the
upper basket is overloaded or
if the weight distribution is not
balanced. In heavier conditions,
there is the risk of falling one
level down.
C
Make sure that the adjustment
mechanism has the same
positions on the right and left
sides of the upper basket.
Adjustng the heght of the
upper basket
(depends on model)
The upper basket height adjustment
mechanism has been designed for you to
create large spaces in the lower or upper
sections of your machine depending on your
needs by adjusting the height in the upper
or lower direction while your basket is empty
or loaded.
Thanks to this mechanism, you can use your
basket in three different positions, namely
lower, middle and upper positions (1, 2, 3).
1. To raise your basket, hold the upper
basket wires with both hands while the
basket is in the lowermost position and
pull them up (A).
2. You will hear a "Click" from the right
and left mechanisms, indicating that
the basket has reached the next level.
Release the basket.
Repeat the process if the height is not
sufficient.
1
2
3
22 Dishwasher / User’s Manual/42 EN
Preparation
Pull the basket out completely.
Place the basket back into the tracks at the
desired height.
Push the latches back into the correct
position.
Collapsble upper basket
wres
(depends on model)
You can use collapsible wires when you need
a larger space for your dishes in the upper
basket of your machine.
To bring the collapsible wires into horizontal
position, grab the wire from the middle
position and push them in the direction of
arrow in the figure. Place your larger dishes
into the area created. To bring the wires back
to vertical position, just lift them up.
C
Bringing the wires to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, hold
the wires from their stems while
bringing them to the horizontal
or vertical positions.
Heght settng wth empty
basket
(depends on model)
In this model, the height setting of the upper
basket may be changed using the wheels
which are mounted at two different heights.
Release the latches on both the right and
left tracks of the upper basket by pushing
them outwards.
Dishwasher / User’s Manual
23 / 42
EN
Preparation
Celng cutlery basket
(depends on model)
Ceiling cutlery basket is designed to wash
your cutlery items such as forks, spoons and
etc. by placing them between the bars on
the basket.
1
In models with partial movement feature,
pushing the bar (1) on the handle enables
the central tray of the basket to get to
the lower position and the system gets
unlocked. Thus right and left side trays can
be used as moving parts.
The free space enabled by the side trays
allows long parts to be loaded in the upper
basket.
When the central tray is in the lower
position, you can load long/high items such
as coffee cups, ladles, etc. on the tray. When
the side trays lean on two side walls, the
handle can be pulled to allow the central tray
to rise and the system to be locked.
24 Dishwasher / User’s Manual/42 EN
Preparation
Slverware basket pece
(depends on model)
You can place your forks, spoons and etc. to
upper basket with the additional piece in the
figure..
It is recommended that you should place the
silverware basket piece on front left corner
of the upper basket by detaching the Upper
basket height adjustable rack.
Dishwasher / User’s Manual
25 / 42
EN
9.
10. Start ( ) / Pause ( ) indicator
11. Time Delay indicator
5
5
Operating the product
1. Display
2. On/Off key
3. Start/Pause/Cancel key
4. Time Delay key
7. Programme indicator
5
5. Function keys
a)
b)
c)
d)
6. Programme Selection keys
12. End of Programme indicator
13. Screen information line
14. Child Lock indicator
15. Rinse aid ( ) indicator
16.
1 2
34
5
6
a b c
d
7 8 9 10
111213141516
EverClean Filter
AquaIntense Function
Fast+ Function
SteamGloss Function
Not in use
Not in use
8.
Not in use
26 Dishwasher / User’s Manual/42 EN
Operating the product
Keys
On / Off key
It is used to turn on or off the machine.
Press On / Off Key to switch ON. A signal is
heard and the machine door is turned on.
Press the On / Off key for 1 second to turn
off. A signal will be heard and machine will
turn off at the end of 1 second. To turn off
while the programme is running, keep Off
key pressed for 3 seconds. A countdown in
the form of “3”, “2”, “1” will appear on the
display. Machine will turn off with the end
melody at the end of 3 seconds.
Machine will turn on with economy
programme in On mode and the number
of the economy programme will appear on
the programme indicator. In Off position,
indicators on the display will turn off.
Start / Pause / Cancel key
It is used to start, pause or cancel a selected
programme or function.
Programme Selection keys
They are used to select the washing
programme you determined from the
table of “Programme data and average
consumption values”.
Delayed Start key
It should be pressed to make the time delay
settings.
Preparng the machne
1. Open the door of the dishwasher.
2. Place the dishes in accordance with the
instructions in the user manual.
3. Make sure that the upper and lower
impellers rotate freely.
4. Put adequate amount of detergent into
the detergent dispenser.
6. Close the door of the dishwasher.
Programme selecton
1. Press the On/Off button to turn on your
machine.
2. Refer to the table of "Programme data
and average consumption values"
to determine a washing programme
suitable for your dishes.
3. Press Programme Selection keys until
the number of the programme you
selected appears on the Programme
indicator. Use P+ to switch to the next
programme, and P- to switch to the
previous one.
5. Check Rinse Aid indicator light and add
rinse if needed.
Dishwasher / User’s Manual
27 / 42
EN
Operating the product
0123456789
InnerClean Eco * Auto AquaFlex Baby Protect Intensive Quick&Shine GlassCare Mini Prewash
-
45 ºC 40-65 ºC - 70 ºC 70 ºC 60 ºC 40 ºC 35 ºC -
This programme
is
recommended
to be
operated on
every 1-2
months for
machine
cleaning and
necessary
hygiene.
The programme
should be
operated
while the
machine is
empty.
In order to
achieve
Most economical
washing
program
for the normally
soiled daily
dishes
that are kept
waiting.
Determines the
soiling degree
of the dishes
and sets the
temperature
and amount of
the washing
water as well as
the washing
time
automatically.
Suitable for all
types of dishes.
It is the most
suitable
washing
programme for
daily mixed
dishes including
plastic items.
While delicate
glass items are
washed in the
upper basket,
pans and trays
can be washed
in the lower
basket.
Suitable for the
dishes which
require extra
hygiene such as
articles for
babies. Also
suitable for
heavily soiled
dishes.
Suitable for
heavily soiled
dishes, pots
and pans.
Daily washing
program
at which the
medium
soiled dishes
that
are kept waiting
are
cleaned and
dried in the
fastest
way.
Special
programme for
gentle cleaning
of delicate
glassware.
Suitable for
lightly soiled
daily dishes that
are scraped or
pre-cleaned.
Suitable for
removing the
remnants on the
soiled dishes
that will be kept
waiting in the
machine for a
few days, and
thus, for
preventing the
bad odour
buildup.
- Medium
Medium to high
Medium High High Medium Low Low -
- ++++ +-+
- ++++ ++-
- ++++ +- -
75 196 110-173 197 144 158 58 113 30 15
15,2 13 9,4-12,4 19 18 16,8 10,6 13,6 10,8 4
0,66 0,70 0,85-1,40 1,53 1,80 1,51 1,18 1,20 0,80 -
Degree of Soiling
Energy (kWh)
Prewash
Wash
Dry
Duration (min)
Water (I)
Programme Table
The consumption values shown in the table were determined under standard conditions. Differences may therefore occur under practical conditions. * Reference
programme for testing institutes. The tests in accordance with EN 50242 must be carried out with a full water softener salt dispenser and a full rinse aid reservoir, and
using the test programme.
Programme number
Programme name
Cleaning temperature
#
Sensitivity: Public
28 Dishwasher / User’s Manual/42 EN
Operating the product
Auxlary functons
Washing programmes of your dishwasher
are designed to obtain the best cleaning
effect, considering the type of the soil,
soiling degree and properties of the dishes
to be washed.
Auxiliary functions are provided in order to
enable you to save time, water and energy
and to perform a more comfortable washing
with conditions specific to you.
C
Auxiliary functions may cause
changes in the programme
duration.
C
Auxiliary functions are not
suitable for all washing
programmes. Indicator of the
auxiliary function that is not
compatible with the programme
will not be active.
To add auxiliary function to the
programme:
1. Select the desired washing programme
by pressing the programme selection
key.
2. In the selected washing programme, if
auxiliary function is selected, its symbol
will be displayed on the screen. If the
function button is pressed again the
symbol will disappear and selection is
cancelled.
3. Selection will be cancelled when you
press the function key again.
EverClean Filter
With this function, your micro filter will be
cleaned by a special system at the end of
washing cycle and it is made ready for use
for the next usage of the machine. This
cleaning process increases the cleaning
period of the micro filter from 2 weeks to
3 months and thus boosts the washing
performance. Employing this function in
every washing cycle is recommended in
order to get the most out of it.
AquaIntense Function
AquaIntense impeller
located under the
lower impeller helps
washing your heavily
soiled dishes places in
the right side of the
lower basket. It will give better results to
place the most soiled dish to the right front
side.
C
Do not try to remove the
AquaIntense impeller!
SteamGloss Function
It provides superior drying performance.
Fast+ Function
It shortens the time of the washing cycle
selected and decreases water consumption
by enabling washing under higher pressure.
Floor illumination
Warning to show that machine is
in washing phase
(depends on the model)
Your machine reflects a light to the floor
during the washing process. This light turns
off after the washing process is complete.
C
Floor illumination is activated
automatically when the washing
programme starts and remains lit
until the end of the programme.
C
Floor illumination cannot be
cancelled by the user.
Dishwasher / User’s Manual
29 / 42
EN
Operating the product
Changing Warning Sound Volume
Your machine is equipped with an audio
signal to inform warnings audibly.
1. After turning on the machine, press
Time Delay and P+ keys simultaneously.
Continue to press until the countdown
3, 2, 1 is completed on the display.
2. Press P+ key to activate the S position.
3. Select one of S1, S2 and S0 with Time
Delay key.
4. Turn off the machine with On/Off
button to save the changes.
Programmng the washng
tme
Time Delay
If an economical electricity tariff is applied
in your region, you can use the Time
Delay function to wash your dishes during
appropriate hours.
You can delay the start of the selected
programme until 24 hours. Time Delay
cannot be set after the programme starts.
1. Press the Time Delay function key after
selecting the washing programme and
other auxiliary functions.
2. Once you press the Time Delay key,
Display Information Line will show
"0:30" and Time Delay indicator will start
flashing.
3. Set the desired time by pressing the
Time Delay key. Time will increase with
increments of 30 minutes up to 6 hours
Auto Tablet Feature
Auto Tablet is a feature which detects
the use of combined tablet detergents
automatically.
C
Drying performance of these
type of detergents is improved
by adjusting temperature and
duration accordingly.
Owing to this feature, there is no need
to press any button in case of a tablet
detergent use.
Feature can be activated if automatic
detection is desired.
To activate / to deactivate:
1. After turning on the machine, press
Time Delay and P+ keys simultaneously.
Keep them pressed until the countdown
3, 2, 1 is completed on the display.
2. Press P+ key to activate the a: option.
Automatic detergent detection feature
is disabled at “a:0” option and enabled
at "a:1" option. Set the desired option by
pressing the Time Delay key.
3. Turn off the machine with On/Off key to
save the changes.
2. Press P+ key to activate the L: option.
The interior lighting is turned off at "L:0"
option and turned on at "L:1" option. Set
the desired option with the Time Delay
key.
3. Turn off the machine with On/Off key to
save the changes.
Interior Lighting
(Depends on the model)
Some models have interior lighting to
illuminate the interior when the door is
opened.
Changing the interior lighting
setting
1. After turning on the machine, press
Time Delay and P+ keys simultaneously.
Continue to press until the countdown
3, 2, 1 is completed on the display.
30 Dishwasher / User’s Manual/42 EN
Operating the product
and after that in 1 hour increments up to
24 hours every time you press the key.
4. Press Start / Pause / Cancel key to
start countdown for the Time Delay.
Time Delay indicator and Start / Pause
indicator will light continuously until
the end of the period. Time Delay is
displayed on the Display Information
Line. Selected programme will start as
soon as the countdown is over.
Changing the settings while Time
Delay function is enabled
While the Time Delay function is activated,
you cannot make changes in the washing
programme, auxiliary functions or the
duration of delay time.
C
Programme and auxiliary
functions cannot be set/
changed after the programme
has started.
To cancel the Time Delay function
1. Press and hold Start / Pause / Cancel key
for 3 seconds.
2. When the Start / Pause / Cancel key
is pressed and hold, "3", "2", "1" appear
on the Display Information Line. Time
Delay indicator will turn off at the end
of the cancellation process and delaying
process is cancelled.
C
You can select and start a
new programme following
the cancellation of Time Delay
function.
C
Time Delay function can not be
set after the programme starts.
Starting the programme
To start your machine after selecting the
programme and auxiliary functions, press
Start / Pause / Cancel key.
Once the programme starts a tune is played
and the estimated time remained to the end
of the programme will appear on the Display
Information Line. Start / Pause / Cancel
indicator starts lighting continuously.
C
The total time can change
while the programme is
running depending on the
ambient temperature where
your machine is installed,
temperature of the supply water
and amount of the dishes.
C
Pay attention not to open the
door of the machine when it is
running. Stop the machine by
pressing Start / Pause / Cancel
key if you have to open the door.
There may be a rush of steam
when you open the door of your
machine; be careful. Close the
door of your machine and press
Start/Pause/Cancel key again.
Programme will resume running.
Dishwasher / User’s Manual
31 / 42
EN
Operating the product
C
The machine will remain silent
in pause mode for some time
in order to remove the water in
the machine and on the dishes
completely and to have the
water softener cleaned, and
then it will resume running in
drying mode.
Child (Key) Lock
You may prevent other people from
interrupting and changing the programme
cycle and time delay while the machine is
running.
To activate the Child Lock:
1. Pres Child (Key) Lock keys simultaneously
and hold for 3 seconds.
2. "3", "2", "1" is displayed on Display
Information Line and key lock is activated.
C
Child Lock prevents the selected
programme or functions from
being changed and disables the
Start / Pause / Cancel key.
C
Child Lock does not lock the door
of the machine.
C
If you turn your machine off by
using On/Off key at the end of
the programme, the Child Lock
will be deactivated automatically.
C
For energy saving, the product
is automatically turned off
following the completion of the
programme or if the programme
is not started.
To deactivate the Child Lock:
1. Pres Child (Key) Lock keys simultaneously
and hold for 3 seconds.
2. "3", "2", "1" is displayed on Display
Information Line and key lock is cancelled.
Cancellng the programme
1. Press Start/Pause/Cancel key for 3
seconds to cancel the programme.
2. Release the key when the Start / Pause
indicator starts flashing. For a couple
of minutes the machine will fulfill the
necessary operations required to cancel
the programme.
C
There might be residues of
detergent or rinse aid left in the
machine and / or on the pieces
being washed depending on the
step the programme you have
cancelled was in.
Adjustng the amount of
rnse ad
1. After turning on the machine, press
Time Delay and P+ keys simultaneously.
Keep them pressed until the countdown
3, 2, 1 is completed on the display.
2. Press P+ to move to position P on the
display.
3. Set to the appropriate level with the
Time Delay key.
4. Turn off the machine with On/Off key to
save the changes.
No rinse aid dispensed in P:0 wash position.
1 dose of rinse aid is dispensed in P:1
position.
Rinse Aid indicator ( )
Please check the rinse aid indicator on the
display to see whether there is adequate
amount of rinse aid in the dishwasher or
not. You need to refill the rinse aid reservoir
with rinse aid whenever rinse aid warning
indicator appears on the display of your
machine.
32 Dishwasher / User’s Manual/42 EN
Operating the product
Overowng warnng
If the machine intakes too much water or
there is leakage at any of the components
then the machine will detect this and E:01
icon will flash on the Programme indicator.
As long as the overflowing continues safety
algorithm will be active and try to discharge
the water. If overflowing stops and safety is
assured, E:01 icon will disappear. If E:01 does
not disappear, there is a permanent fault. In
this case the authorised service should be
contacted.
2 doses of rinse aid are dispensed in P:2
position.
3 doses of rinse aid are dispensed in P:3
position.
4 doses of rinse aid are dispensed in P:4
position.
End of programme
End of Programme indicator will light up
once the washing programme is over.
1. Press the On/Off button to turn off your
machine.
2. Close the tap.
3. Unplug the machine from the socket.
C
For energy saving, the product
is automatically turned off
following the completion of the
programme or if the programme
is not started.
C
Leave your dishes in the machine
for about 15 minutes to cool
down after they are washed.
Your dishes will dry in a shorter
time if you leave the door of your
machine ajar during this period.
This process will increase the
drying effectiveness of your
machine.
Water cut-o warning
If mains water is cut or water inlet tap is
turned off the machine cannot take water
in and E:02 icon will flash on the programme
indicator. As long as the problem continues,
washing programme is paused and the
water inlet is checked regularly by the
machine; when the water is restored E:02
icon will disappear after a while and the
washing programme resumes.
InnerClean
This programme is recommended to be
operated on each 1-2 months for machine
cleaning and necessary hygiene. The
programme should be operated while the
machine is empty.
In order to achieve an efficient result, it is
recommended to use together with special
machine cleaning agents.
C
Do not use this programme to
clean dishes. As it operates in
high temperatures, it is harmful
for the dishes.
Dishwasher / User’s Manual
33 / 42
EN
Maintenance and cleaning
6
Service life of the product extends and
frequently faced problems decrease if it is
cleaned at regular intervals.
A
Unplug the product and turn off
the tap before attempting any
cleaning procedures.
C
Do not use abrasive substances
for cleaning.
C
Clean the filter and impellers at
least once a week in order for the
machine operates efficiently.
Cleanng the outer surface
of the product
Wipe the outer surface and door gaskets
of the product gently with a mild cleaning
material and damp cloth. Wipe the "Control
panel" only with a slightly damp cloth.
Cleanng the nteror of the
machne
• Clean the interior of the machine and
the tank by running a programme with
or without detergent based on the
degree of soil.
• If water has remained in the machine,
drain the water by performing the
procedures under the topic "Canceling
a programme". If the water cannot
be discharged, remove the filters
as specified in the "Cleaning the
filters" section and check if there
are any leftover deposits that have
accumulated at the bottom of the
machine, blocking the water path. Clean
if necessary.
Cleanng the flters
Clean the filters at least once a week in order
for the machine operates efficiently. Check if
food residues are left on the filters. If there
are food residues on filters, take them out
and clean well under running water.
C
Filter cleanliness is increased
by 80% with the micro filter
cleaning system available on
your machine.
1. Turn the micro filter (1) and coarse filter
(2) assembly counter clockwise and pull
it out from its seating.
2. Pull out the metal/plastic filter (3) from
the seating.
3. Press the two pawls on the coarse filter
inwards and separate the coarse filter
from the assembly.
34 Dishwasher / User’s Manual/42 EN
Maintenance and cleaning
4. Clean all three filters under tap water by
means of a brush.
A
Do not remove the micro filter
cleaning mechanism (4) for
cleaning (D).
5. Install the metal/plastic filter.
6. Place the coarse filter into the micro
filter. Make sure that it is properly
seated. Turn the coarse filter clockwise
until a "click" sound is heard.
C
Do not use the dishwasher
without filter.
C
Incorrect placement of the filters
will reduce washing efficiency.
Cleanng the hose flter
Damages on the machine that may be
caused by impurities coming from the urban
supply water or your own water installation
(such as sand, dirt, rust, etc.) can be
prevented by means of the filter attached to
the water inlet hose. Check the filter and the
hose regularly and clean them if necessary.
1. Turn off the tap and remove the hose.
2. After taking out the filter, clean it under
running tap water.
3. Place the cleaned filter back to its seat
in the hose.
4. Install the hose to tap.
(depends on model)
Dishwasher / User’s Manual
35 / 42
EN
Maintenance and cleaning
Cleanng the mpellers
Clean the impellers at least once a week in
order for the machine operates efficiently.
Lower mpeller
Check if the holes on the lower impeller (1)
are clogged. If they are clogged, remove and
clean the impeller. You can pull the lower
impeller up to remove it.
Upper mpeller
Check if the holes on the upper impeller (1)
are clogged. If they are clogged, remove
and clean the impeller. Turn its nut to left to
remove the upper impeller.
Make sure that the nut is tightened well
when installing the upper impeller.
36 Dishwasher / User’s Manual/42 EN
7
Troubleshooting
Machine does not start.
• Power cable is unplugged. >>> Check if the power cable is plugged in.
• Fuse is blown. >>> Check the fuses in your house.
• Water is cut. >>> Make sure that the water inlet tap is open.
• Door of the machine is open. >>> Make sure that you have closed the door of the
machine.
• On / Off button is not pressed. >>> Make sure that you have turned on the machine by
pressing the On / Off button.
Dishes are not washed clean
• Dishes are not placed orderly in the machine. >>> Load the dishes as described in the
user manual.
• Selected programme is unsuitable. >>> Select a programme with a higher temperature
and cycle time.
• Impellers are stuck. >>> Prior to starting the programme, turn the lower and upper
impellers by hand to make sure that they rotate freely.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be clogged with
food remnants such as lemon pips. Clean the impellers regularly as illustrated in section
“Cleaning and Care”.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Filters are installed incorrectly. >>> Check the filter system and make sure that it is
installed correctly.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their capacity.
• Detergent is stored under unsuitable conditions. >>> If you are using powder detergent,
do not store the detergent package in humid places. Keep it in a closed container if
possible. For ease-of-storing, we recommend you to use tablet detergents.
• Detergent is not sufficient. >>> If you are using powder detergent, adjust the amount of
detergent according to the soiling degree of your dishes and/or programme definitions.
We recommend you to use tablet detergents for optimum results.
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
• Detergent dispenser lid is left open. >>> Make sure that the detergent dispenser lid is
closed tightly after adding detergent.
Dishes are not dry at the end of cycle
• Dishes are not placed orderly in the machine. >>> Place your dishes in a way that no
water will accumulate in them.
Dishwasher / User’s Manual
37 / 42
EN
Troubleshooting
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
• Machine is unloaded right after the programme is over. >>> Do not unload your machine
right after washing process is completed. Slightly open the door and wait for evacuation
of the steam inside for a while. Unload the dishes after the pieces cool down to a
touchable level. Start unloading process from the lower basket. Thus, dropping of water
remained on a piece at upper basket onto the pieces at lower basket is prevented.
• Selected programme is unsuitable. >>> Since rinsing temperature is low at programmes
with short duration, drying performance will also be low. Select programmes with longer
duration for a higher drying performance.
• Surface quality of the kitchen utensils is deteriorated. >>> Desired washing
performance can not be obtained on kitchen utensils with deteriorated surfaces and it
is not suitable to use such utensils in terms of hygiene as well. Also, water can not flow
easily on deteriorated surfaces. It is not recommended to wash such kitchen utensils in
dishwasher.
C
It is normal that drying complaints can be experienced with Teflon kitchen
utensils. It is associated with the structure of Teflon. Since the surface tensions
of Teflon and water are different, water droplets will remain as beads on the
Teflon surface.
Tea, cafe or lipstick stains remain on dishes.
• Selected programme is unsuitable. >>> Select a programme with a higher temperature
and cycle time.
• Surface quality of the kitchen utensils is deteriorated. >>> Tea and cafe stains or other
dye spots may not be cleaned in dishwasher when they have penetrated in deteriorated
surfaces. Desired washing performance can not be obtained on kitchen utensils with
deteriorated surfaces and it is not suitable to use such utensils in terms of hygiene as
well. It is not recommended to wash such kitchen utensils in dishwasher.
• Detergent is stored under unsuitable conditions. >>> If you are using powder detergent,
do not store the detergent package in humid places. Keep it in a closed container if
possible. For ease-of-storing, we recommend you to use tablet detergents.
Lime traces remain on dishes and glassware gains a misty appearance
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
38 Dishwasher / User’s Manual/42 EN
Troubleshooting
There is a different odour in the machine
C
A new machine has a peculiar odour. It will fade out after a couple of washes.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Dirty dishes are kept in dishwasher for 2-3 days. >>> If you are not going to start the
machine right after you have put the dishes into it, remove the remnants on the dishes
and run the Prewash programme without detergent every 2 days. In such cases, do not
close the door of the machine completely in order to avoid odour build up in machine. You
can also use commercially available odour removers or machine cleaners.
Rust, discoloration or surface deterioration occurs on dishes
• Salty food remnants have remained on dishes for a long time. >>> If cutlery soiled with
such foods will be kept waiting in machine, dirt must be removed by prewash or dishes
must be washed without being kept waiting.
• Electric installation is not grounded. >>>Check if your machine is connected to the actual
grounding line. Otherwise, the static electric created in the product causes arcs on the
surfaces of metal items creating pores, removing the protective cover on the surface and
causing discoloration.
• Intensive cleansers such as bleaches are used. >>> Protective cover on metal surfaces
gets damaged and looses its efficiency in time when it gets in contact with cleansers
such as bleach. Do not wash your dishes with bleach.
• Metal items particularly knives are used for purposes other then their intended uses.
>>> Protective cover on the edges of knives may get damaged when they are used for
purposes such as opening cans. Do not use metal kitchen utensils out of their intended
uses.
• Cutlery are made of low quality stainless steel. >>> Corrosion on such items is inevitable;
they should not be washed in dishwashers.
• Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a
corroded item can migrate to other stainless steel surfaces and cause corrosion on those
surfaces as well. Such items should not be washed in dishwashers.
Detergent remains in detergent dispenser.
• Detergent dispenser was damp when adding detergent. >>> Make sure that the
detergent dispenser is dried well prior to filling it with detergent.
• Detergent is added long before the washing process. >>> Pay attention to add detergent
shortly before start-up of the washing.
• Opening of the detergent dispenser lid is prevented during washing. >>> Place the
dishes in a way that will not prevent the detergent dispenser lid from opening and the
water going into the machine from impellers.
Dishwasher / User’s Manual
39 / 42
EN
Troubleshooting
• Detergent is stored under unsuitable conditions. >>> If you are using powder detergent,
do not store the detergent package in humid places. Keep it in a closed container if
possible. For ease-of-storing, we recommend you to use tablet detergents.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be clogged with
food remnants such as lemon pips. Clean the impellers regularly as illustrated in section
“Cleaning and Care”.
Decorations and ornaments on kitchen utensils are being erased.
C
Decorated glasses and decorated lustre porcelains are not suitable for washing in
the dishwasher. Manufacturers of some glassware and porcelain tableware items
do not recommend washing such kitchen utensils in the dishwashers either.
Dishes are scratched.
C
Kitchen utensils that contains or are made of aluminium should not be washed in
dishwasher.
• Dishes are not placed orderly in the machine. >>> When placing the glasses and other
glassware into the basket lean them not against other dishes but the edges or racks of
the basket or the glass support tines. Striking of the glasses to each other or to other
dishes due to the impact of water during washing can cause breaks, or scratches on their
surfaces.
A smear remains on glasses that resembles milk stain which can not be
removed when wiped by hand. A bluish / rainbow appearance occurs when
the glass is pointed to light.
• Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when
adding rinse aid.
Foam forms in the machine.
• Dishes are washed with hand-wash detergent by hand but not rinsed before placing
them into the machine. >>> Hand-wash detergents do not contain antifoam. There is
no need to hand-wash the dishes before placing them into the machine. Removing the
coarse soil on the dishes under tap water, with a tissue paper or fork will be sufficient.
• Rinse aid has spilled into the machine when adding rinse aid. >>> Take care that rinse
aid is not spilled in the machine when you are filling it. Clean any spilled rinse ait with the
help of a tissue paper/towel.
• Lid of the rinse aid reservoir is left open. >>> Make sure that the lid of the rinse aid
reservoir is closed after adding rinse aid.
Kitchen utensils are broken.
• Dishes are not placed orderly in the machine. >>> Load the dishes as described in the
user manual.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their capacity.
40 Dishwasher / User’s Manual/42 EN
Troubleshooting
Water remains in the dishwasher at the end of the programme.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Discharge hose is clogged/blocked. >>> Check the discharge hose. If necessary, remove
the discharge hose, clear the blockage and insert is as illustrated in the user manual.
C
If you cannot eliminate the problem although you follow the instructions in this
section, consult your dealer or the Authorised Service Agent. Never try to repair a
nonfunctional product yourself.
Dishwasher / User’s Manual
41 / 42
EN
Troubleshooting
Mandatory Warnings
Dishwashers
•
The appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervised or
instruction concerning use of the appliance by a responsible person for
their safely.
•
Young children should be supervised to ensure that they do not play
with the appliance.
•
If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
•
Capacity standard place settings
•
Please do not leave the door open as this will cause a tripping hazard
•
The dishwasher must always be connected to the water system using
new hose sets.
•
Water Supply Min: 0.03 MPa - Max: 1.0 MPa
•
If the appliance is installed on a carpet floor, take care that the openings
in its base are not obstructed
•
WARNING - Knives and other utensils with sharps points must be
loaded in the basket with the points down or placed in a horizontal
position.
•
WARNING: SOME DISHWASHER DETERGENTS ARE STRONGLY
ALKALINE. THEY CAN BE EXTREMELY DANGEROUS IF SWALLOWED.
AVOID CONTACT WITH SKIN AND EYES AND KEEP CHILDREN AWAY
FROM THE DISHWASHER WHEN THE DOOR IS OPEN.
•
This appliance is intended to be used in household and similar
applications such as:
-
Staff kitchen areas in shops, offices and other working environments;
-
Farm houses;
-
By clients in hotels, motels and other residential type environments;
-
Bed and Breakfast type environments
16
