USER MANUAL
ƫ
ĆĂąČƫĉĂą
2
www.electrolux.com
CONTENTS
1. SAFETY INFORMATION
............................................................................
3
2. USE
................................................................................................................
5
3. CARE AND CLEANING
..............................................................................
5
4. CONTROLS
..................................................................................................
6
5. LIGHTING
.....................................................................................................6
6.WARRANTY
.....................................................................................................
7
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
ƫƫƫƫƫ
ƫĚƫ
$!.!*!ƫ0+ƫ0$!ƫ %.!0%+*/ƫ"+.ƫ1/!ƫ%*ƫ0$%/ƫ)*1(ƫ
%/ƫ!40.!)!(5ƫ%),+.0*0ƫ"+.ƫ$!(0$ƫ* ƫ/"!05ċƫ%(1.!ƫ
0+ƫ/0.%0(5ƫ $!.!ƫ0+ƫ0$!ƫ.!-1%.!)!*0/ƫ%*ƫ0$%/ƫ)*1(ƫ
)5ƫ.!/1(0ƫ%*ƫ,!./+*(ƫ%*&1.5Čƫ,.+,!.05ƫ )#!ƫ
* ƫ""!0ƫ5+1.ƫ%(%05ƫ0+ƫ)'!ƫƫ(%)ƫ1* !.ƫ0$!ƫ
!/0%*#$+1/!ƫ)*1"01.!.Ě/ƫ3..*05ƫ,.+2% ! ƫ
3%0$ƫ5+1.ƫ,.+ 10ċƫ.+ 10/ƫ)1/0ƫ!ƫ1/! Čƫ%*/0((! ƫ
* ƫ+,!.0! ƫ%*ƫ+. *!ƫ3%0$ƫ0$%/ƫ)*1(ċƫ
ƫ
+1ƫ)5ƫ*+0ƫ!ƫ(!ƫ0+ƫ(%)ƫ+*ƫ0$!ƫ!/0%*#$+1/!ƫ
)*1"01.!.Ě/ƫ3..*05ƫ%*ƫ0$!ƫ!2!*0ƫ0$0ƫ5+1.ƫ
,.+ 10ƫ"1(0ƫ%/ƫ 1!ƫ0+ƫ"%(1.!ƫ0+ƫ $!.!ƫ0$%/ƫ)*1(.
3
ENGLISH
1. SAFETY INFORMATION
For your safety and correct operation of the appliance,
read this manual carefully before installation and use.
Always keep these instructions with the appliance even if
you move or sell it. Users must fully know the operation
and safety features of the appliance.
The wire connection has to be done by specialized
technician.
• The manufacturer will not be held liable for any damages
resulting from incorrect or improper installation.
• The minimum safety distance between the cooker top
and the extractor hood is 650 mm (some models can be
installed at a lower height, please refer to the paragraphs
on working dimensions and installation).
• If the instructions for installation for the gas hob specify a
greater distance, this must be respected.
• Check that the mains voltage corresponds to that indicated
•
wiring in accordance with the wiring rules.
• For Class I appliances, check that the domestic power
supply guarantees adequate earthing.
•
be as short and as straight as possible.
• Regulations concerning the discharge of air have to be
• Do not connect the extractor hood to exhaust ducts carrying
• If the extractor is used in conjunction with non-electrical
-
gree of aeration must be guaranteed in the room in order
hood is used in conjunction with appliances supplied with
energy other than electric, the negative pressure in the
room must not exceed 0,04 mbar to prevent fumes being
drawn back into the room by the cooker hood.
•
The route of the flue must
4
www.electrolux.com
exhausting fumes from appliances burning gas or other fuels.
• If the supply cord is damaged, it must be replaced from the
manufacturer or its service agent.
• Connect the plug to a socket complying with current regula-
tions, located in an accessible place.
• With regards to the technical and safety measures to be
adopted for fume discharging it is important to closely follow
the regulations provided by the local authorities.
WARNING: Before installing the Hood, remove the
SURWHFWLYH¿OPV
• Use only screws and small parts in support of the hood.
WARNING:)DLOXUHWRLQVWDOOWKHVFUHZVRU¿[LQJGHYLFH
in accordance with these instructions may result in
electrical hazards.
• Do not look directly at the light through optical devices
(binoculars, magnifying glasses…).
• 'RQRWÀDPEqXQGHUWKHUDQJHKRRGULVNRI¿UH
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appli-
ance. Cleaning and user maintenance shall not be made
by children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• The appliance is not to be used by persons (including chil-
dren) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction.
Accessible parts may become hot when used with cook-
ing appliances.
• &OHDQDQGRUUHSODFHWKH)LOWHUVDIWHUWKHVSHFL¿HGWLPH
period (Fire hazard). See paragraph Care and Cleaning.
• There shall be adequate ventilation of the room when the
range hood is used at the same time as appliances burning
gas or other fuels (not applicable to appliances that only
5
ENGLISH
discharge the air back into the room).
• The symbol
on the product or on its packaging indi-
cates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and elec-
tronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative
• This range hood is not recommended for barbecues.
• Exhaust air must not be discharged into a wall cavity
unless the cavity has been designed for the purpose.
consequences for the environment and human health,
which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information
about recycling of this product, please contact your local
shop where you purchased the product.
2. USE
• The extractor hood has been de-
signed exclusively for domestic use
to eliminate kitchen smells.
• Never use the hood for purposes
other than for which it has been
designed.
• -
der the hood when it is in operation.
•
it onto the bottom of the pan only,
making sure that it does not engulf
Always switch off gas burners
before removing pots or pans.
the sides.
•
•
Deep fat fryers must be continu-
ously monitored during use: over-
3.
CARE AND CLEANING
-
not washable and cannot be re-
generated, and must be replaced
approximately every 4 months
of operation, or more frequently
for particularly heavy usage (W).
WW
-
every 2 months of operation, or
more frequently for particularly
heavy usage, and can be washed
in a dishwasher (Z).
Z
• Clean the hood using a damp cloth
and a neutral liquid detergent.
• There is a fire risk if cleaning is
not carried out in accordance with
the instructions.
6
www.electrolux.com
5. LIGHTING
•
F
or replacement contact Service. To purchase contact Spare parts.
4. CONTROLS
Button Function Led
L Turns the lights on/off at maximum strength. -
T1 Turns the motor on/off at speed one. -
T2 Turns the Motor on at speed two. -
Press and hold the button for approximately 5 seconds, with all the loads
turned off (Motor and Lights), to turn the Activated Charcoal Filter alarm
To turn the alarm off, press the button again and hold for at least 5 seconds.
Flashing
T3 Turns the Motor on at speed three. -
Press and hold the button for approximately 3 seconds, with all the loads
turned off (Motor and Lights), to perform a reset. The LED S1
three times.
Flashing
T4 Turns the Motor on at INTENSIVE Speed.
This speed is timed to run for 6 minutes. At the end of this time, the system
returns automatically to the speed that was set before. If it is activated with
the motor turned off, the hood will switch to OFF at the end of the time.
-
Press and hold for 5 seconds to enable the remote control, indicated by
Press and hold for 5 seconds to disable the remote control, indicated by
Flashing
S1 Signals the Metal Grease Filter saturation alarm, indicating that it is
been in operation for 100 working hours.
Fixed
When this is activated, it signals the Activated Charcoal Filter saturation
must also be washed. The Activated Charcoal Filter saturation alarm comes
into operation after the Hood has been working for 200 hours.
Flashing
Hob2
Hood
remote
control
NOTE: This Hood can be switched on remotely by certain cooktops that
have compatible Hob to Hood capability.
To switch on/off the Hob to Hood function, press and hold ܼfor 3 seconds,
the indicator LED will flash twice to confirm the function is activated.
To disable this function, press and hold ܼfor 3 seconds, the LED will flash
once to confirm the function has been disabled.
This document sets out the terms and conditions of the product
warranties for Westinghouse Appliances. It is an important
document. Please keep it with your proof of purchase documents
in a safe place for future reference should there be a manufacturing
defect in your Appliance. This warranty is in addition to other rights
you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products
Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances purchased in Australia and Electrolux
(NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
L º>HYYHU[`7LYPVK»TLHUZ[OLWLYPVKZWLJPÄLKPUJSH\ZLVM[OPZ
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
VќLYLKMVYH]HSPK^HYYHU[`JSHPTPZYLWHPYVYYLWSHJLTLU[,SLJ[YVS\_VYP[Z
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
H SPNO[NSVILZIH[[LYPLZÄS[LYZVYZPTPSHYWLYPZOHISLWHY[Z"
(b) parts and Appliances not supplied by Electrolux;
J JVZTL[PJKHTHNL^OPJOKVLZUV[HќLJ[[OLVWLYH[PVUVM[OL
Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
I [OL(WWSPHUJLPZTVKPÄLK^P[OV\[H\[OVYP[`MYVT,SLJ[YVS\_PU^YP[PUN"
(c) the Appliance’s serial number or warranty seal has been removed
or defaced
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the terms
of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
*VUÄKLU[PHSP[`! You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: WESTINGHOUSE RANGEHOODS
WRange_War_Jul19
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
AUSTRALIA
FOR SERVICE
VY[VÄUK[OLHKKYLZZVM`V\YULHYLZ[
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
VY[VÄUK[OLHKKYLZZVM`V\YULHYLZ[
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call
NEW ZEALAND
FOR SERVICE
VY[VÄUK[OLHKKYLZZVM`V\YULHYLZ[
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
VY[VÄUK[OLHKKYLZZVM`V\YULHYLZ[
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
AUSTRALIA
,$+*!čƫāăƫāăƫąĊ
!)%(čƫ1/0+)!..!Į!(!0.+(14ċ+)ċ1
3!čƫ3!/0%*#$+1/!ċ+)ċ1
NEW ZEALANDƫ
,$+*!čƫĀĉĀĀƫāĀƫććƫāĀ
!)%(čƫ1/0+)!..!Į!(!0.+(14ċ+ċ*6
3!čƫ3!/0%*#$+1/!ċ+ċ*6
For more information on all Westinghouse
appliances, or for dimension and installation
information, call into your retailer, phone or email
our customer care team or visit our website:
and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license by Electrolux Home Products Pty Ltd. All Rights Reserved.
© 20ĂĀ
Electrolux Home Products Pty Ltd.ƫ
ABN 51 004 762 341
ĤĆĂąĤĉĂąĤ0+.5Ĥ*ĂĀ
991.0599.717_03 - 200206 - D00006174_02
