FEATURES
●
MTS/SAP Tuner
●
Flat Screen Picture Tube
●
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
●
PLL Frequency Synthesized Tuning- Provides free and easy channel selection and lets
you tune directly to any channel using the channel number buttons on the remote control.
●
Sleep Timer
●
Closed Caption Decoder
●
Auto Shut Off Function- If there is no signal input from the antenna terminal and no user
operation for 15 minutes, the TV will turn itself off automatically.
●
Resume Function- If the power fails or is disconnected while the TV is on, the TV will turn
on automatically when the power resumes.
●
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.
●
Full-Function Remote Control
●
On-Screen Function Display
●
S-VIDEO Input- Allows you to get better picture detail and clarity.
●
Front AV Input
●
Rear Audio Input
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be con-
nected to the grounding system of the building as close to the point of cable entry as practical.
FCC WARNING - This equipment may
generate or use radio frequency energy.
Changes or modifications to this equip-
ment may cause harmful interference
unless the modifications are expressly
approved in the instruction manual.
The user could lose the authority to
operate this equipment if an unautho-
rized change or modification is made.
IF YOU NEED ADDITIONAL ASSISTANCE WITH SET-UP OR OPERATING
AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE
1-877-467-4289 OR VISIT OUR WEB SITE AT http://www.insignia-products.com
Owner’s Manual
1EMN20321 Printed in Thailand
L3303UD * * * * *
IS-TV040920
20 INCH COLOR TELEVISION
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLI-
ANCE TO RAIN OR MOISTURE.
IMPORTANT SAFEGUARDS
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK) NO
USER SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THIS SYMBOL INDICATES THAT DAN-
GEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRE-
SENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT
THERE ARE IMPORTANT OPERATING
AND MAINTENANCE INSTRUCTIONS
IN THE LITERATURE ACCOMPANYING
THE APPLIANCE.
These warning labels appear on the rear of the cabinet.
1. READ INSTRUCTIONS - All the safety and operating
instructions should be read before the appliance is
operated.
2. RETAIN INSTRUCTIONS - The safety and operating
instructions should be retained for future reference.
3. HEED WARNINGS - All warnings on the appliance
and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS - All operating and use
instructions should be followed.
5. CLEANING - Unplug TV from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol clean-
ers. Use a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupt-
ed service and, that for some specific reason, such as
the possibility of the loss of an authorization code for a
CATV converter, is not intended to be unplugged by
the user for cleaning or any other purpose, may
exclude the reference to unplugging the appliance in
the cleaning description otherwise required in item 5.
6. ATTACHMENTS - Do not use attachments not recom-
mended by the TV manufacturer as they may cause
hazards.
7. WATER AND MOISTURE - Do not use this TV near
water, for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool, and the like.
8. ACCESSORIES - Do not place this
TV on an unstable cart, stand, tripod,
bracket, or table. The TV may fall,
causing serious injury to someone,
and serious damage to the appliance.
Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the TV.
Any mounting of the appliance should follow the man-
ufacturer’s instructions and should use a mounting
accessory recommended by the manufacturer. An appli-
ance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
9. VENTILATION - Slots and openings in the cabinet and
the back or bottom are provided for ventilation and to
ensure reliable operation of the TV and to protect it
from overheating, these openings must not be blocked
or covered. The openings should never be blocked by
placing the TV on a bed, sofa, rug, or other similar sur-
face. This TV should never be placed near or over a
radiator or heat register. This TV should not be placed
in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufactur-
er’s instructions have been adhered to.
10. POWER SOURCES - This TV should be operated only
from the type of power source indicated on the mark-
ing label. If you are not sure of the type of power sup-
ply to your home, consult your appliance dealer or
local power company. For TVs intended to operate
from battery power, or other sources, refer to the oper-
ating instructions.
11. GROUNDING OR POLARIZATION - This TV is
equipped with a polarized alternating-current line
plug(a plug having one blade wider than the other).
This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
12. POWER-CORD PROTECTION - Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, con-
venience receptacles, and the point where they exit
from the appliance.
13. OUTDOOR ANTENNA GROUNDING - If an outside
antenna or cable system is connected to the TV, be sure
the antenna or cable system is grounded so as to pro-
vide some protection against voltage surges and built-
up static charges. Article 810 of the National Electrical
Code, ANSI/NFPA No. 70, provides information with
respect to proper grounding of the mast and supporting
PORTABLE CART WARNING
S3126A
structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding elec-
trode. (Fig. A)
14. LIGHTNING - For added protection for this TV
receiver during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug
it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the TV due
to lightning and power-line surges.
15. POWER LINES - An outside antenna system should
not be located in the vicinity of overhead power lines
or other electric light of power circuits, or where it can
fall into such power lines or circuits. When installing
an outside antenna system, extreme care should be
taken to keep from touching such power lines or cir-
cuits as contact with them might be fatal.
16. OVERLOADING - Do not overload wall outlets and
extension cords as this can result in a risk of fire or
electric shock.
17. OBJECT AND LIQUID ENTRY - Never push objects
of any kind into this TV through openings as they may
touch dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill liq-
uid of any kind on the TV.
18. SERVICING - Do not attempt to service this TV your-
self as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
19. DAMAGE REQUIRING SERVICE - Unplug this TV
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a. When the power supply cord or plug is damaged or
frayed.
b. If liquid has been spilled, or objects have fallen into
the TV.
c. If the TV has been exposed to rain or water.
d. If the TV does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions, as improper
adjustment of other controls may result in damage and
will often require extensive work by a qualified techni-
cian to restore the TV to its normal operation.
e. If the TV has been dropped or damaged in any way.
f. When the TV exhibits a distinct change in perfor-
mance, this indicates a need for service.
20. REPLACEMENT PARTS - When replacement parts
are required, be sure the service technician uses
replacement parts specified by the manufacturer that
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, injury to persons or other hazards.
21. SAFETY CHECK - Upon completion of any service or
repairs to this TV, ask the service technician to perform
routine safety checks to determine that the TV is in
proper operating condition.
22. HEAT - This TV product should be situated away from
heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
NEC - NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
S2898A
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA
LEAD IN
WIRE
PRECAUTIONS
●
Place your TV in a room with adequate ventilation.
●
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
●
Do not place your TV on soft surfaces, such as rugs or blankets.
●
Leave enough room for air to circulate around the bottom, top and back of the set.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
The serial number of this product may be found on the back of the TV. The serial number on your
television is unique. You should record the number and other vital information here and retain this
book as a permanent record of your purchase to aid identification in case of theft.
LIMITED WARRANTY
Insignia Products warrants to you, the original purchaser of this Product, that this product shall be free of defects in
material or workmanship for a period of ninety (90) days from the date of purchase as follows:
1. LABOR: During the Warranty Period if this Product is determined to be defective, Insignia will repair or
replace the Product, at its option at no charge, or pay the labor charges to any Insignia authorized service
facility. After the Warranty Period, you must pay for all labor charges.
2. PARTS: In addition, Insignia will supply, at no charge, new or rebuilt replacement parts in exchange for
defective parts for the Warranty Period. After the Warranty Period, you must pay all parts costs.
To obtain warranty service, you must take the Product with your original receipt or other proof of purchase, either in
its original packaging or packaging affording an equal degree of protection, to your nearest retail store location of the
store or online web site from which you purchased the Product.
This warranty does not cover cosmetic damage or damage due to acts of God, lightning strikes, accident, misuse,
abuse, negligence, commercial use, or modification of, or to any part of the Product, including the antenna. This war-
ranty does not cover damage due to improper operation or maintenance, connection to improper voltage supply, or
attempted repair by anyone other than a facility authorized by Insignia to service the Product. This warranty does not
cover Products sold AS IS or WITH ALL FAULTS, or consumables (such as fuses or batteries). This warranty is
valid only in the United States and Canada.
This warranty is invalid if the factory applied serial number has been altered or removed from the Product.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAM-
AGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY, REPRESENTATION OR CONDI-
TION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMIT-
ED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states or provinces do not allow the exclusion or limitation of incidental or consequential damages, or allow
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may have other rights which vary from state to state, or province to
province.
For customer service please call 1-877-467-4289
www.insignia-products.com
Insignia Products, Richfield, Minnesota, U.S.A.
Downloaded from www.ManualsFile.com manuals search engine
Loading ...
Loading ...
Loading ...
