ELECTRONIC ORGANIZER

OPERATION MANUAL

Instrucciones abreviadas en español

YO-520

CONTENTS

Using the Organizer for the First Time .................................................. 1

When Abnormal Conditions Cause a Malfunction ................................. 1

Auto Power Off Function ...................................................................... 1

Backlight .............................................................................................. 1

Adjusting the LCD Contrast .................................................................. 2

Turning the “beep” On and Off .............................................................. 2

Selecting the Guidance Language ......................................................... 2

Part Names ................................................................................................. 3

Display Symbols ......................................................................................... 4

Entering Characters .................................................................................... 4

Note on the Description of the MENU Key Operations ................................ 5

Notes for the Built-in Calendar and the Time .............................................. 5

Clock Mode ................................................................................................ 6

Telephone Mode ......................................................................................... 8

Calendar Mode ........................................................................................... 9

Schedule Mode ........................................................................................... 9

To Do Mode .............................................................................................. 12

Memo Mode ............................................................................................. 12

Expense Mode .......................................................................................... 13

Anniversary Mode .................................................................................... 14

Checking the Memory Storage ................................................................. 15

Freeing Up Memory .................................................................................. 15

Recalling the Listings ............................................................................... 15

Editing the Listings ................................................................................... 17

Deleting the Listings ................................................................................. 17

Calculator Mode ....................................................................................... 18

Conversion Mode ..................................................................................... 19

Secret Function ........................................................................................ 21

Battery Replacement ................................................................................ 23

Specifications ........................................................................................... 24

Using the included Software CD-ROM ................ 26

Instrucciones abreviadas en español ...................................................... S-1

YO-520 (E0365E)

YO-520 Hyoshi,E.E65 5/31/2000, 11:43 AM3

NOTICE

• SHARP strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any

electronic memory product under certain circumstances. Therefore, SHARP assumes no responsibility for data lost or otherwise rendered

unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other

cause.

• SHARP assumes no responsibility, directly or indirectly, for financial losses or claims from third persons resulting from the use of this product

and any of its functions, such as stolen credit card numbers, the loss of or alteration of stored data, etc.

• This Organizer is not designed to transfer/receive e-mails by using the E-mail addresses you will store.

• The information provided in this manual is subject to change without notice.

• All company and/or product names are trademarks and/or registered trademarks of their respective manufacturers.

• Microsoft

and Windows

are registered trademarks of Microsoft Corporation.

CAUTIONS

• Do not carry the Organizer in the back pocket of slacks or trousers.

• Do not drop the Organizer or apply excessive force to it.

• Do not subject the Organizer to extreme temperatures.

• Since this product is not waterproof, do not use it or store it where fluids can splash onto it. Raindrops, water spray, juice, coffee, steam,

perspiration, etc. will also cause malfunction.

• Clean only with a soft, dry cloth.

• Use only a SHARP approved service facility.

Included in this Package

• SHARP Electronic Organizer YO-520

• Alkaline batteries LR03 x 2

• Operation manual (This book)

• Software CD-ROM

• PC Link cable

Please contact your dealer if any of the above items are not included in the package or if they are broken.

YO-520 (E0365E)

YO-520 Hyoshi,E.E65 5/31/2000, 11:43 AM4

Using the Organizer for the First Time

Be sure to perform the following operations before using the Organizer for

the first time.

(1) Installing the batteries

1. Set the battery replacement switch on

the bottom of the Organizer to

REPLACE BATTERIES.

2. Slide off the operating batteries cover.

3. Insert the two batteries on the top of

the ribbon tab, as shown in the

diagram.

4. Replace the operating batteries cover.

5. Set the battery replacement switch to

NORMAL OPERATION.

(2) Initializing the Organizer

1. Press the RESET switch while holding down

. Release the RESET switch and then

release

“CLEAR ALL DATA OK(Y/N)?” is displayed.

• Press the RESET switch with a ball-point pen

or similar object. Do not use an object with a

breakable or sharp tip.

• Under certain conditions the message may

appear as “Data has been impaired! Press [Y]

to CLEAR ALL memory”. Proceed to the next

step in either case.

2. Press

to initialize the memory of the Organizer.

3. Select the desired language. Press

to move to the next language

screen, then press

to move to

the previous language screen.

For example, press

to select English.

• Then the Home Clock is displayed. Proceed to set the date and time of

the clock. (Refer to page 6.)

When Abnormal Conditions Cause a Malfunction

If the Organizer is subjected to strong, extraneous electrical noises or

shocks during use, an abnormal condition may occur in which no keys

(including

and

OFF

) will respond. If this happens, press the RESET

switch.

Noises or shocks may erase some or all of the Organizer’s memory.

Auto Power Off Function

When none of the keys has been pressed for approximately 7 minutes, the

Organizer automatically turns the power off to save the batteries. (The

actual time may vary depending upon the condition of use.) Press

resume operation.

Backlight

The Organizer is provided a built-in Backlight, which allows you to view the

display and use the Organizer even in low-light conditions.

Pressing

BackLight

once illuminates the display for as long as you

continue to use the Organizer, until you have not typed any key for 15

seconds.

• To turn the Backlight off, press

BackLight

again.

LANGUAGES

1 DEUTSCH

4 FRANÇAIS

2 ENGLISH

3 ESPAÑOL

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM1

• The Backlight may remain on for less than 15 seconds or it may not

function if the battery level is very low.

★ The backlight turns off automatically if you carry out the following

operations with the Organizer.

• Storing any listings in the Organizer

• Deleting any listings from the Organizer

• Marking any completed TO DO listings as done with

• Freeing up memory

• Exchanging data with a personal computer

★ Do not use the Backlight unnecessarily.

• Since the Backlight drains power from the operating batteries,

excessive use of the Backlight will significantly reduce the life of your

batteries.

• Do not continue using the Organizer after it has automatically turned

itself off while the backlight was being used. Even if it can be turned

on again, the clock time will be incorrect and other functions may not

work properly until the batteries are replaced.

Adjusting the LCD Contrast

1. Press

to select “2 CONTRAST”.

2. Press or to darken or lighten

the display.

• The amount of contrast changes

continuously while either or

is held down.

3. Press

C•CE

after adjusting the contrast.

CONTRAST

–DARK

–LIGHT

Turning the “beep” On and Off

While “ ” is displayed, a “beep” will sound when a key is pressed. To turn

the “beep” on and off, press

2nd

(

2nd

). The “beep” will not

sound when “ ” is turned off.

Selecting the Guidance Language

The Organizer can give messages and guidance during operation in seven

different languages.

Change the guidance language from English to Italian.

1. Press

to select “3 LANGUAGES”.

2. Press

to to select “1 ITALIANO”.

All messages and guidance will now appear in Italian.

• In this manual explanations are based on a guidance language set to

English.

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM2

Part Names

q Display

w MENU key

e Power ON/OFF key

r PC-LINK key (PC SYNC)

t RESET switch

y Clear/Clear entry key

u MODE keys

i Cursor movement keys

o SEARCH keys

!0 Option port (COMPUTER LINK)

In this manual the keys are represented by symbols, for

example:

→

: Indicates the & key.

→

: Indicates the numeric 7 key.

→

SCHEDULE

: Mode key with only one

function.

The key : These keys are used to select capital

(uppercase) or small (lowercase)

letters or to access the symbols above

the number key and “

” and “

;

”.

While holding down , press the

desired key to be entered.

Numbers, letters and space for operation are shown in

italic and bold.

;

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM3

Entering Characters

1.Moving the Cursor

The cursor ( _ , or ) can be moved by pressing (or holding down)

, , , or .

2.Entering Characters

(1) Entering letters and numbers

The cursor ( _ , or ) indicates the position to enter a character or

number. After initializing the Organizer, the default setting for entering

letters will be capital (uppercase) letters. To enter small (lowercase) letters,

turn “CAPS” off by pressing

CAPS

(2) Entering graphic symbols and special characters

Press

SMBL

to display the symbol entry mode, allowing a total of 140

symbols and characters to be selected. To select the symbol display

containing the desired symbol/special character, press

(or ) or

(or ), then press the corresponding number.

• The first display is determined by your previous choice. The 10 most

recently used symbols/special characters are stored and displayed on

this display.

Press

SMBL

to exit the symbol entry mode.

You can also enter the following symbols/special characters by pressing

and an appropriate key (q) or directly from the numeric keys (w)

located next to the LCD display:

q &, , (, $, /, ^ , !, @, #, )

w ÷, ×, –, +, =, ±, %

• You cannot enter “았앙” symbol.

Display Symbols

:A “beep” will sound when a key is pressed.

:The schedule alarm will sound.

CAPS

:Capital (uppercase) letters will be entered. To enter small

(lowercase) letters, turn “CAPS” off by pressing

CAPS

EDIT

:The listing on the display can be edited.

2nd

:Indicates that

2nd

has been pressed.

:More information exists above the current display. (Press .)

:More information exists below the current display. (Press .)

:Secret function is in effect. (Secret listings cannot be recalled

without a password.)

:Indicates that the recalled listing is secret.

BATT

:Indicates that the operating battery level is low.

• In the display examples of this manual, only the symbols necessary for

explanation will be shown.

NOTES:

• The symbol “ ” shown by setting the LCD contrast to DARK is not

used in this product.

• The “ ” mark indicates the alarm sound for the scheduled listings is

turned on.

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM4

(3) Entering non-English characters

Press

2nd

followed by the corresponding keys.

Enter “Ä”, “ü’, “é” and “ô” in MEMO mode, for example.

Press

MEMO

2nd

CAPS

2nd

• “ç” is entered by pressing

2nd

. Non-English characters can also

be entered as symbols.

3.Making Corrections

(1) Inserting characters

Press

INS

to change the cursor from “ ” (replace) to “ ” (insert).

Press

INS

again to change the cursor from “ ” to “ ”.

(2) Deleting characters

Press

DEL

to delete the character at the cursor position.

Press

to delete the character to the left of the cursor.

•

DEL

and

will not operate in some cases such as when you input

the time in Schedule mode or you are in Calculator mode. In these

cases, press

C•CE

and reenter.

• Press

C•CE

to clear all characters on the current display.

Note on the Description of the MENU Key Operations

This Organizer offers a variety of functions which you choose from the

menus (see the following table).

To switch or scroll the menu screens displayed by pressing

, press

(or ) to move to the next screen, or

(or ) to move to

the previous screen.

Menu See page...

Checking the Memory Storage 15

Adjusting the LCD Contrast 2

Deleting the Listings 17

Designating the File Names 8

Selecting the Date Format 8

Selecting the Weekly Format 9

Freeing Up Memory 15

Selecting the Guidance Language 2

Notes for the Built-in Calendar and the Time

• Calendar, Schedule, Expense, and Clock modes allow you to enter the

desired date and time between Jan. 1, 1901 and Dec. 31, 2099.

• If an attempt is made to store an invalid time or date, you cannot move

the cursor to date entering, or store the time and date by pressing

ENTER

. Enter the correct value and press

ENTER

again.

Äüéô

–

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM5

Clock Mode

The Organizer has both Home and World clocks. The display switches

between Home and World clock each time

CLOCK

is pressed.

Home clock World clock

“(+ 5:00)” indicates the time difference from the Home city.

1.Setting the Home Clock

(1) Setting and changing the Home city

Set your local city as the Home city by selecting its zone number.

Zone numbers are based on the distance of the zones from the international

date line (zone number zero). For example, there is a 13-hour difference

between the date line and London (London is 13 hours behind), so the zone

number for London is 13. Honolulu is 23 hours behind the date line, so its

zone number is 23.

The names and zone numbers of 27 cities are stored in the Organizer's

memory. (See the following table.)

1. Press

CLOCK

once or twice to display the Home clock.

2. Press

2nd

EDIT

• The zone number is displayed on the right side.

3. Press

to display the desired city which corresponds

to your local zone from the cities stored in the Organizer.

(2) Setting the Clock

Set the date and time to April 12, 2001, 10:05 PM (or 22:05).

1. Press

CLOCK

once or twice to display the Home clock.

2. Press

2nd

EDIT

• The cursor will flash.

3. Press

12 24

to select the 12-hour

or 24-hour clock.

• The display switches between the two clocks each time

12 24

pressed. AM or PM is displayed for the 12-hour clock (default).

(Note: 12:00PM: noon, 12:00AM: midnight)

4. Enter the hour and minutes.

1005

(For the 24-hour clock, press 2205)

(Enter 2 digits each for both hour and minutes.)

Zone

Display City

Zone

Display City

No. No.

0 10 MOW MOSCOW

1 AKL AUCKLAND 11 CAI CAIRO

2 NOU NOUMEA 12 PAR PARIS

3 SYD SYDNEY 13 LON LONDON

3.3 ADL ADELAIDE 14

4 TYO TOKYO 15

5 HKG HONG KONG 16 RIO RIO DE JANEIRO

6 BKK BANGKOK 17 CCS CARACAS

6.3 RGN YANGON 18 NYC NEW YORK

7 DAC DHAKA 19 CHI CHICAGO

7.3 DEL NEW DELHI 20 DEN DENVER

8 KHI KARACHI 21 LA LOS ANGELES

8.3 KBL KABUL 22 ANC ANCHORAGE

9 DXB DUBAI 23 HNL HONOLULU

9.3 THR TEHRAN 24 MID MIDWAY

NYC

MON JAN 1,2001

12:00

LON

(

5:00

)

MON JAN 1,2001

5:00

Day of the week/

Month/Day/Year

World

city

Time

Day of the week/

Month/Day/Year

Home

city

4. Press

ENTER

to set the Home city.

• Zone numbers 0, 14, and 15 have no city name on the display.

NYC

[

18.0

]

MON JAN 1,2001

12:00

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:56 AM6

5. Enter the month, day, and year.

04122001

Use to skip entering a number that needs no change.

6. Press

ENTER

. The clock starts from 0 second.

2.Using the World Clock

Changing the city for the World clock

1. Press

CLOCK

once or twice to display the World clock.

2. Press

2nd

EDIT

3. Press

to display the city which corresponds to the

desired zone.

4. Press

ENTER

3.Registering a City Name not Found in the List

If you want to set the city for the World clock to Rome, for example (Rome

belongs to zone number 12, but is not included in the city list):

1. Press

CLOCK

once or twice to display the World clock.

2. Press

2nd

EDIT

3. Press

(or

) to set the zone number to 12.

(Initially the city is “PAR” (PARIS).)

4. Enter the city name (up to 8 characters).

ROME

5. Press

ENTER

to store the new name.

• To register a city name for the Home clock, first display the Home clock

then press

2nd

EDIT

and press to move the cursor to the city

name line.

• Only one changed city name can be stored in each of the Home and

World clocks.

• Each changed name is stored until you next change the zone number.

4.Setting Daylight Saving Time/Summer Time

If DST (daylight saving time/summer time) is used, the local time is

advanced one hour during the summer. Both the Home clock and World

clock can be set for DST as follows:

(1) Home clock

1. Press

CLOCK

once or twice to display the Home clock.

2. Press

2nd

EDIT

3. Enter the correct daylight saving time/summer time.

4. Press

2nd

ENTER

to set the time as DST.

A “ ” appears on the display and DST is now set.

(2) World clock

1. Press

CLOCK

once or twice to display the World clock.

2. Press

2nd

EDIT

3. Press

2nd

ENTER

A “ ” appears on the display and DST is now set. Setting DST in the

World clock automatically sets the time one hour ahead.

• When DST is set for one World city, it is used for all cities displayed in

the World clock.

• DST can be set independently in either the Home or the World clock.

(3) Clearing DST

To clear DST, follow steps 1 to 4 for Home clock, or follow steps 1 through

3 for World clock.

The “ ” disappears.

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:57 AM7

5. Selecting the Date Format

The date format can be switched between MONTH/DAY/YEAR and

DAY.MONTH.YEAR.

1. Press

to select “5 DATE FORMAT”.

2. Press

to select “MONTH/

DAY/YEAR” or “DAY.MONTH.YEAR”.

• A “ ” mark moves to your selection

and you return to the mode in which

you were before pressing

Telephone Mode

In Telephone mode, a listing consists of 4 entries: name, number, E-mail

address, and postal address.

Further, Telephone listings provide 3 files (TEL1, TEL2, TEL3). The files are

cycled each time you press

TEL

. You can switch them for convenience

by keeping business, private and other listings separate.

1.Designating the File Names

You can change each file name in up to 10 characters long as follows:

1. Press

to select “4 TEL FILE NAME”.

2. Enter the new name for TEL1, then

press

ENTER

• You can skip changing a file name by

pressing

ENTER

• To cancel entering the file names, press

C•CE

twice.

3. Press

TEL

to check the new file name(s).

TEL FILE NAME

[

TEL 1

]

[

TEL 2

]

[

TEL 3

]

Johns, Pat

–

Johns, Pat

F 265–1234

–

201–265–5600

07430–2135, U.S.A.

–

201–265–5600

Box G, Sharp Plaza,

johns–[email protected]

Mahwah, New Jersey,

Johns, Pat

johns–[email protected]

201–265–5600

–

2.Storing the Telephone Listings

1. Press

TEL

to display the TEL1 entry

prompt.

2. Enter the name. For example,

Johns, Pat

3. Press

ENTER

The number entry prompt is

displayed.

4. Enter the phone and fax numbers.

For example,

201-265-5600

F 265-1234

5. Press

ENTER

, then enter the E-mail

address. For example,

[email protected]

6. Press

ENTER

, then enter the

address. For example,

Box G, Sharp Plaza,

Mahwah, New Jersey,

07430-2135, U.S.A.

7. Press

ENTER

“STORED!” will be displayed briefly, then the listing will be displayed.

The telephone listing is now stored.

• To skip entering the number, E-mail address, or address, press

ENTER

when “NUMBER?”, “E-MAIL?”, or “ADDRESS?” is displayed. However,

the name entry cannot be skipped.

TEL 1

NAME?

DATE FORMAT

1 MONTH/DAY/YEAR

2 DAY.MONTH.YEAR

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:57 AM8

• To enter the next telephone listing, continue to enter in the same manner.

• The Telephone listings are stored in alphabetical order.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

Calendar Mode

1.Controlling the Monthly Calendar Display

The Organizer has a 5-line display and 4 weeks of a month and day of the

week can be displayed. Use the following keys to control the display status.

: displays the following or previous month.

• Hold down either of these keys for rapid recall.

moves the cursor or scrolls the calendar up or down one week.

1. Press

CALENDAR

to display the

Calendar mode.

•“ ” indicates the 5th or 6th week of

the month is hidden below. To display

the 5th or 6th week, press until

the cursor scrolls into the next screen.

2. Press

(or

) to display the calendar for the next (or

previous) month.

• When you reset the Organizer, the calendar defaults to Jan. 1, 2001.

2.Selecting the Weekly Format

The weekly format can be switched between SUN-SAT and MON-SUN.

1. Press

CALENDAR

to display the Calendar mode screen.

2. Press

to select “1 WEEKLY FORMAT”.

3. Press

to select “SUN-SAT” or “MON-SUN”.

• A “ ” mark moves to your selection and you return to the mode in

which you were before pressing

3.Returning the Calendar to the Current Date

Press

2nd

CALENDAR

in Calendar mode.

• The current monthly calendar will be displayed, and the current date will

flash.

See also ...

Recalling the Listings ................ 15

Schedule Mode

A schedule listing consists of 3 entries: date, time, and detail. In the date

entry, 4 digits can be entered for the year and 2 digits each for the month,

day, hour, and minute.

1.Storing the Schedule Listings

There are 3 ways to enter the desired date:

(1) Enter the desired date in Calendar mode

(2) Enter the desired date with

(or

)

(3) Enter the desired date directly

After the date has been entered, the entry of time and detail is the same for

all 3 ways.

S M T W T F S2001

APR

Year

Month

Day of the

week

YO-520 (E0365E)

YO-520 p01~09,E.E65 5/31/2000, 11:57 AM9

(1) Enter the desired date in Calendar mode

Enter the following data.

“Lunch with Tom” from 11:30 AM to 1:00 PM on June 24,

2001.

1. Press

2nd

CALENDAR

in Calendar mode to display the calendar for

the current date (For example, April 12, 2001).

2. Press

to move the cursor to June

24, 2001.

3. Press

SCHEDULE

to change to the

Schedule mode.

Time entry prompt for June 24, 2001 is

displayed.

4. Enter the starting and ending time.

1130

(For the 24-hour clock, press 1130 13 .)

“DESCRIPTION?” is displayed.

• “:00” will be entered automatically.

• You can enter schedule details without the ending time. Press

ENTER

(or ) after entering the starting time to display the “DESCRIPTION?”

prompt.

• You can also enter schedule details without a specified time, except

details starting with a number. Skip entering time and start to enter

letters for the details as described in step 5.

• The hour and minute should each consist of 2 digits.

• The time can be set using either the 12-hour or 24-hour format. When

you move the cursor to the next entry field, the time is displayed in the

format selected in the Clock mode.

• If an attempt is made to store an invalid time, you cannot move the

cursor to the next entry field. Enter the correct time and follow the next

procedure.

5. Enter the schedule detail.

Lunch with Tom

6. Press

ENTER

to store the listing.

7. Now, press

CALENDAR

to check if the

listing is stored in the memory.

• Notice the tag ( ) on the right of “24”. It indicates a scheduled item for

that date:

(2) Enter the desired date with

(or

)

This is a convenient way of entering a nearby date. Press

(or

) and change the display day by day until the desired date appears.

Enter a schedule listing on April 17, 2001.

1. Press

SCHEDULE

to display the Schedule mode screen.

2. Press

2nd

SCHEDULE

to display the time entry prompt for the current

date (For example, April 12, 2001).

3. Press

repeatedly until the time entry prompt for April 17, 2001

appears. Enter the time and detail following the procedure for “(1) Enter

the desired date in Calendar mode” (from step 4) on this page.

Schedule items beginning in the morning or schedule

items without a specified time

Anniversary items

Schedule items beginning in the afternoon

SUN JUN 24,2001

TIME?

SUN JUN 24,2001

Lunch with Tom

–

11:30AM~ 1:00PM

S M T W T F S2001

JUN

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 11:59 AM10

(3) Enter the desired date directly

When the date is not close to the currently displayed date, the following

method is more convenient than the previous 2 ways.

Enter a schedule listing on June 26, 2002.

1. Press

SCHEDULE

C•CE

to display

the date entry prompt.

2. Enter the date.

06262002

3. Press

ENTER

The time entry prompt for June 26, 2002 is displayed. Enter the time and

detail following the procedure for “(1) Enter the desired date in Calendar

mode” from step 4 on page 10.

• If an attempt is made to store an invalid date, you cannot move to the

time entry prompt. Enter the correct date and follow the next procedure.

2.Schedule Alarm

Schedule alarm sounds for approximately 20 seconds when the time set for

a schedule listing is reached. Once a schedule item has been selected for

the alarm and the alarm has been turned on, the alarm will sound

automatically and the relevant item will be displayed even if the Organizer

has been turned off. The alarm can also be set to sound for secret items

without displaying the item.

Set an alarm for June 22, 2001 (Meeting at 10:00AM -

11:00AM).

1. Press

SCHEDULE

and enter the date, time, and schedule detail.

2. Press

2nd

ALARM

to set the alarm

and press

ENTER

to store.

A “ ” is displayed on the left of the

starting time for the scheduled item,

and an alarm sound mark (“ ”) is displayed on the left of the display.

• You cannot set the schedule alarm to the listings with no time entry.

MM/DD/YYYY

DAY :12

MONTH :04

YEAR :2001

• You can set an alarm while you are entering or editing the schedule item.

When you press

2nd

ALARM

while “ ” is displayed, the alarm will be

canceled and “ ” will disappear from the display.

• If the alarm time you attempt to enter has already passed, the message

“ALARM TIME ELAPSED!” appears briefly. Enter the correct alarm time.

• After the alarm sounds, “ ” will disappear and the scheduled item will

remain in the memory without “ ”.

• Even if “ ” is turned off and the scheduled alarm time has passed,

“ ” will not disappear from the display.

• The schedule alarm may not sound if the time for a schedule listing

arrives while you are exchanging data with a personal computer.

• Press

C•CE

to stop the alarm sound.

Turn the alarm sound on and off

Pressing

2nd

after the alarm setting, turns off the alarm sound while

keeping the schedule alarm turned on.

• A “ ” disappears, and the alarm sound is set to off.

• Press

2nd

to set the alarm sound to on again, so that the “ ” is

displayed.

• Setting the alarm sound (“ ” mark status) does not affect the setting of

the schedule alarm (“ ” mark status) to each schedule listing.

• The schedule alarm set for the schedule listing will sound when the “ ”

is turned on and the time for each listing is reached. You cannot classify

or declassify each listing.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

FRI JUN 22,2001

Meeting

10:00AM~11:00AM

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 11:59 AM11

To Do Mode

1.Storing the Listings

1. Press

TO DO

to display the To Do

entry prompt.

2. Enter the description. For example,

Call Frank about a sales meeting

3. Press

ENTER

4. Enter the priority. For example,

5. Press

ENTER

to store it in the

memory.

• Press

C•CE

twice to cancel the entry.

• The priority can be set by any number 0-9 or letter A-Z or just left blank

by pressing

ENTER

. Lowercase letters entered without

CAPS

pressed

will be changed to the uppercase letters.

• Order of priority is from 0-9, A-Z, then space.

2.Checking off Completed Items

1. Press

TO DO

to display the To Do entry prompt.

2. Press

ENTER

to enter the index mode.

3. Press and to select the item.

4. Press to mark it as done.

•“SORTING...” is displayed briefly and items marked with “ ” are given

the lowest priority and listed at the end of the list.

• You can also check off the item by recalling each listing and pressing

TO DO

DESCRIPTION?

Call Frank about a s

PRIORITY:2

• To restore the checked off item, recall the listing to be restored, press

2nd

EDIT

to enter the edit mode, and then enter the priority.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

Memo Mode

1.Storing the Memo Listings

1. Press

MEMO

to display the Memo

entry prompt.

2. Enter the title. For example,

Xmas presents list

3. Press

ENTER

4. Enter the details. For example,

Sweater for Jill

Ring for Mother

5. Press

ENTER

to store it in the

memory.

• The Memo listings are stored in alphabetical order.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

MEMO

TITLE?

Xmas presents list

Ring for Mother

–

Sweater for Jill

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:00 PM12

Expense Mode

1.Creating the Expense Records

The date is April 5, 2001.

You bought flight tickets for a business trip for $1,200.

1. Press

EXPENSE

to enter the Expense

mode.

• The month and the day must be

entered using 2 digits and the year

using 4 digits. For single digit months or days, enter “0” before the

single digit.

• The date can be changed by pressing either or .

2. Enter the expense date and press

ENTER

04052001

ENTER

3. Enter the expense amount and press

ENTER

1200

ENTER

• Numerical values can be input in up to 10 digits including 2 decimal

places.

4. Enter the memo.

Flight tickets for inspection abroad

5. Press

ENTER

to store it in the

memory.

• Press

C•CE

once or twice to return to the date entry prompt.

• The description field can be skipped by pressing

ENTER

EXPENSE

M/D/Y= 4/12/2001

DATE?

2.Expense Summaries

Expense summaries are a collection of records stored in Expense mode.

You can recall them for a specific day or a certain period.

(1) Summarizing an expense report for a specific day

Specify the date, April 5, 2001.

1. Press

EXPENSE

to enter the Expense mode.

2. Press

2nd

EXPENSE

to enter the

Expense report mode.

3. Press

to select “1 DAILY”.

• The current date will be displayed.

4. Enter the desired date.

04052001

5. Press

ENTER

• Press

ENTER

to return to the date

entry prompt, when you wish to check

another daily report.

(2) Summarizing a report for a certain period

Starting date: April 1, 2001

Ending date: April 30, 2001

1. Press

EXPENSE

to enter the Expense mode.

2. Press

2nd

EXPENSE

to enter the Expense report mode.

3. Press

to select “2 PERIOD”.

4. Enter the starting and ending time.

04012001

ENTER

04302001

THU APR 5,2001

Flight tickets for i

1,200.00

nspection abroad

–

1 DAILY

2 PERIOD

EXPENSE REPORT

DATE :APR 5,2001

–DAILY–

1,200.00

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:00 PM13

5. Press

ENTER

• Press

ENTER

to return to the date

entry prompt.

• If the integer section in the calculation

result exceeds 12 digits, “ , , , . ” is

displayed.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

Anniversary Mode

In Anniversary mode, you can specify the month and date (such as

wedding anniversaries and birthdays), or month, week, and day of the week

(such as Mother’s Day (second Sunday in May)).

Once a date is stored as an anniversary, the date will be an anniversary for

every year from 1901 to 2099.

Anniversaries are marked with a tag ( ) in the center right of the date (See

page 10) in the monthly calendar.

1.Storing the Anniversary Listings

Enter the following data.

“Nancy’s Birthday” on February 12th.

1. Press

ANN

to enter the Anniversary mode.

2. Press

to select “1 MONTH/DAY” to

enter the date entry prompt.

FROM :APR 1,2001

–PERIOD–

1,415.25

TO :APR 30,2001

3. Enter the date and press

ENTER

(or

0212

ENTER

• If an attempt is made to store an

invalid date, you cannot move to the description entry prompt. Enter the

correct date and follow the next procedure.

4. Enter the description of the anniver-

sary.

Nancy’s Birthday

5. Press

ENTER

to store it in the memory.

1. Press

ANN

to enter the Anniversary mode.

2. Press

to select “2 MONTH/WEEK” to display the date entry mode.

3. Enter the month, week, and day of the

week.

05 2 0

4. Press

ENTER

, and then enter the

description of the anniversary.

ENTER

Mother's Day

5. Press

ENTER

to store it in the memory.

See also ...

Recalling the Listings ................ 15 Checking the Memory Storage .. 15

Editing the Listings .................... 17 Entering Characters .................... 4

Deleting the Listings .................. 17

–ANN–

M=MONTH D=DAY

M/D=

–

–ANN–

DESCRIPTION?

FEB 12

–ANN–

Nancy's Birthday

–

FEB 12

3:W 4:T 5:F 6:S

D=DAY 0:S 1:M 2:T

–ANN–

M=MONTH W=WEEK

M/W/D=05/2/0

–ANN–

Mother's Day

–

MAY WEEK 2 SUN

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:00 PM14

TEL 3 : 6

TEL 2 : 31

TEL 1 : 76

0% 100%

Recalling the Listings

1.Notes for Recalling the Listings

• Perform searching the listings in each mode other than Clock, Calculator,

and Conversion modes.

• The direct, keyword, and index searches are not case sensitive.

• When the symbol “ ” or “ ” is displayed, more information exists.

Pressing or scrolls up or down one line.

• When there are no more (or relevant) listings to be recalled or to be

searched, “NOT FOUND!” is displayed briefly and the display returns to

the entry prompt.

2.Sequential Search

Recalls the listings in order in each mode.

To begin searching in Anniversary mode, press

ANN

to enter the

Anniversary mode and then press

(or

) to select the searching type.

Press

(or

) to recall the listings in forward (or reverse)

order. Hold down either of these keys for rapid recall.

Schedule listings

• When nothing has been entered for that day, only the time entry prompt

is displayed.

• Press

2nd

SCHEDULE

in Schedule mode to recall the scheduled

listings for the current day. Then press

repeatedly to check if any

other listings are scheduled for the current day.

• Press

2nd

(or

2nd

) in Schedule mode repeatedly to

recall the listings skipping empty dates. Press

C•CE

, then press

2nd

(or

2nd

) to display the first (or last) listing in

chronological order. After the last (or first) listing in chronological order

has been found, “NOT FOUND!” is displayed briefly.

Checking the Memory Storage

1. Press

to select “1 CHECK

MEMORY”.

The number of listings stored in TEL1,

TEL2 and TEL3 files is displayed.

2. Press

again to display the number of listings stored in

SCHEDULE, ANN1, and ANN2 files.

3. Press

again to display the number of listings stored in MEMO,

EXPENSE, and TO DO files.

4. Press

C•CE

to return to the mode in which you were before pressing

• When the amount of memory used approaches “100%”, delete

unnecessary data to make enough space to store new listings.

• Since the same memory is used for all the modes other than the

Calculator and Conversion modes, the number of listings that can be

stored in each of these modes will vary depending on the situation of

each mode.

Freeing Up Memory

Deleting or modifying data during operation can produce unnecessary

space in the memory of the Organizer. Delete unnecessary space and free

up memory, when the Organizer displays “MEMORY FULL!”.

1. Press

2. Press

to start freeing up memory.

•“WORKING...” is displayed indicating that the memory is being freed up.

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:00 PM15

3.Direct Search

Recalls the listings by the first character(s) of the name (or the contents) in

Telephone, Schedule, To Do, or Memo mode.

1. Enter the first character(s) of the desired name (or the contents) in each

mode.

2. Press

(or

• The search in Schedule mode begins from the currently displayed date in

forward (or reverse) order.

• If the desired listing in Telephone or Memo mode is not found, the

subsequent listing in sequential order will be displayed.

• Each time

(or

) is pressed, sequential search will be

performed.

4.Keyword Search

Recalls the listings by a word contained in the desired listing in Telephone,

Schedule, To Do, or Memo mode.

Recall the listings containing the word “Sharp” in the TEL1 file.

1. Press

TEL

to display the TEL1 file.

2. Enter the word.

Sharp

3. Press

2nd

• Each time

2nd

are pressed,

subsequent listings containing the

word “Sharp” will be displayed.

5.Index Search

Recall the listings in Telephone, Schedule, To Do, Memo, Expense, or

Anniversary mode. The listings recalled are listed one for each line on the

display. To enter the index mode, press

ENTER

when the entry prompt or

listing is displayed. In the Expense mode, press

C•CE

ENTER

to enter

the index mode when the entry prompt is displayed.

Johns, Pat

F 265–1234

201–265–5600

Box G, Sharp Plaza,

johns–[email protected]

Display the Index in the Telephone mode.

1. Press

TEL

to display the Telephone

mode screen.

2. Press

ENTER

to enter the index

mode.

• The index of the Telephone listing is

displayed.

• Up to five listings are displayed at a time.

• To display the first listing beginning with a particular character in the

Telephone, or Memo mode, press the desired character key. If there is no

listing for that character, the first subsequent listing will be displayed.

• Pressing

and

scrolls the page forward and backward. To

see the whole listings press and to select the desired listing, and

press

ENTER

. Next, press

ENTER

again to enter the index mode.

6.Date Search

Recalls the listings by the date in Calendar, Schedule, or Expense mode.

(1) Calendar or Schedule listings

Recall the calendar or schedule for December 25, 2001.

1. Press

CALENDAR

SCHEDULE

2. Press

C•CE

to display the date entry

prompt.

3. Press

C•CE

and enter the month,

day, and year.

12252001

To make a correction, move the cursor with or , or press

C•CE

to clear the displayed date.

• To enter a single-digit month or day, enter zero and the digit.

TEL 1

NAME?

Shingo Nakahara

Robert, Smith

Tom Robert

Stevenson Dug

Johns, Pat

YEAR :2001

MONTH :04

DAY :12

MM/DD/YYYY

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:00 PM16

4. Press

ENTER

The specified calendar or schedule will be displayed.

(2) Expense listings

Press

C•CE

in the Expense entry prompt, then enter the date and press

(or

7.Other Search in Calendar Mode

Recalling the scheduled item from the Calendar mode

The scheduled date is displayed with the tag ( ) on the right of the date

number.

1. Press

CALENDAR

to display the Calendar mode.

• Pressing

2nd

CALENDAR

displays the current date.

2. Press the cursor movement keys ( , , , ) to move to the

date with a tag.

3. Press

SCHEDULE

to display the schedule contents.

Editing the Listings

1.Editing the Listings

1. Recall a listing in the desired mode.

2. Press

2nd

EDIT

• The edit mode is entered and the cursor flashes.

3. Modify the data as desired.

4. Press

ENTER

to store it in the memory.

• In the index display, press

ENTER

to display the desired listing, and

press

2nd

EDIT

. You cannot enter the edit mode in the index display.

2.Creating a New Listing

Pressing

2nd

ENTER

instead in step 4 in the above section, “1. Editing

the Listings”, creates a new listing without deleting the previously stored

listing.

This operation is useful when you enter a new listing whose contents are

the same as or similar to the previously stored listing.

Deleting the Listings

1.Deleting One Listing

1. Recall the listing to be deleted.

2. Press

DEL

“DELETE? Y/N” will appear.

3. Press

to delete the currently displayed listing.

• To cancel the deletion operation, press

• You can also delete individual listing on the index display.

In the index mode, press or to select the listing you want to

delete, and press

DEL

and

2.Deleting All of the Listings in Each Mode

(1) Deleting all of the listings in each mode

If all of the listings for Telephone, Schedule, To Do, Memo, Expense, or

Anniversary mode are not necessary any more, you can delete them all at

once.

Delete all listings in the TEL1 files.

1. Press

to select “3 DATA DELETION”.

2. Press

to select “1 TEL”.

3. Press

to select “1 TEL1”.

“DELETE? Y/N” is displayed.

• After performing step 1, press the following keys in other modes:

SCHEDULE:

ANN1:

ANN2:

MEMO:

EXPENSE:

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:01 PM17

TO DO (ALL):

TO DO (DONE):

• When the Secret function is on, “SECRET ON MODE” is displayed and

the file cannot be deleted. In this case, turn the Secret function off (page

21) and repeat the above procedure.

4. Press

• To cancel the deletion operation, press

• All of the listings (including secret listings) in the selected mode will be

deleted all at once.

(2) Deleting all of the scheduled listings for an entire month

1. Press

CALENDAR

to recall the calendar for the desired month.

2. Press

DEL

. “DELETE? Y/N” will appear.

3. Press

to delete all of the schedule listings for the currently

displayed month.

• To cancel the deletion operation, press

• Although all of the schedule listings for the month are deleted,

anniversaries are still retained.

(3) Deleting the password and secret listings

(Refer to page 21, “Secret Function” on registering the password and

turning the Secret function on and off.)

The password and all secret listings can be deleted at the same time.

1. Press

to select “3 DATA DELETION”.

2. Press

to select “2 SECRET DATA”.

“ALL SECRET DATA DELETE? Y/N” is displayed.

3. Press

• To cancel the deletion operation, press

•“DELETED!” is displayed briefly and the password and all secret listings

are deleted.

Calculator Mode

The Organizer’s built-in calculator can perform the 4 arithmetic calculations

in up to 12 digits.

Calculator mode is selected by

pressing

CALC/CONV

once or twice.

Each time you press this key, the display

switches between Calculator and

Conversion modes.

Before performing any calculation, press

C•CE

twice to clear the display.

• An error occurs when the integer section of the calculation result

exceeds 12 digits, if the memory exceeds 12 digits, or a number is

divided by zero. (“-E-” is displayed.)

Press

C•CE

to cancel the error.

CALC

Example Operation Display

(–24+2) ÷ 4=

–

2 4

–5.5

34 + 57 =

45 + 57 =

68 × 25 =

68 × 40 =

The second figure (57)

becomes the constant.

(Subtraction and division are

performed in the same way as above.)

68 25

The first figure (68)

becomes the constant.

91.

102.

1,700.

2,720.

20.

25.

220.

400.

What is 10% of 200?

What percentage is 9

of 36?

200 + (200 × 10 %) =

500 – (500 × 20 %) =

200 10

9 36

200

500

–

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:01 PM18

Example Operation Display

4,096.

0.125

25 – 9 =

)

1/8

–

= =

았앙앙앙

25 × 5 =

–) 84 ÷ 3 =

+) 68 + 17 =

(Total) =

25 5

84 3

–

123456789098 ×

145 =

– E –

123456789098 145

17.9012344192

C•CE

17.9012344192

(17.9012344192 × 10

= 17901234419200)

-M- 125.

-M- 28.

-M- 85.

-M- 182.

–

(minus) can only be used when entering a negative number as the

first number. Use

/–

for following negative numbers during

calculation.

5 × (–10) = –50

5 10

/–

←

Conversion display number

CONVERSION 1

$ £

No.

Conversion pattern

No.

Conversion pattern

Unit A Unit B Unit A Unit B

1$→ £ 10 gal → l

2$→ DM 11 I.gal → l

→ $ 12 fl.oz → ml

13 I.fl.oz → ml

4 inch → cm 14 oz → g

5 feet → m15lb→ kg

6 yard → m16°F → °C

7 mile → km 17 cal → J

8 acre → m

18 hp → W

9 acre → ha 19 PS → W

1.Changing the Conversion Display

1. Press

CALC/CONV

once or twice to select the Conversion mode.

2. Press

and

until the desired conversion type is

displayed.

Conversion Mode

Each time you press

CALC/CONV

, the display switches between

Calculator and Conversion modes.

This mode has 2 types of conversions; currency conversions and unit

conversions.

The number on the top right of the conversion display indicates the

selected conversion type.

YO-520 (E0365E)

YO-520 p10~19,E.E65 5/31/2000, 12:01 PM19

2.Setting the Rate

Set the following rate: $1 = £0.6

1. Press

CALC/CONV

once or twice to select the Conversion mode.

2. Press

(or

) to select the conversion display number 1.

3. Press

2nd

EDIT

• The result display disappears and the rate display flashes.

4. Enter the rate (up to 10 digits).

0.6

ENTER

3.Changing the Currency or Unit

If there is no conversion pattern you want to use, you can change the

currency or unit in the conversion patterns No. 1 to No. 3.

1. Repeat steps 1 to 3 of the above section, “Setting the Rate”.

2. Press , and to move the cursor to the currency to be

changed and enter the new currency or unit.

• Up to 7 letters can be entered each for unit A and unit B.

3. Press to move the cursor to the rate field and enter the rate.

4.Converting Currency/Unit

To convert unit A to unit B, press .

To convert unit B to unit A, press .

Convert $198 to £.

1. Press

(or

) to select the unit. (In this example, select the

conversion display number 1: $1 = £0.6.)

2. Enter the value to be converted.

198

CONVERSION

$ £

0.6

198.

CONVERSION

$ £

0.6

118.8

CONVERSION 1

$ £

0.6

3. Press to convert it.

The conversion result is displayed.

• Once you have set each rate, you can

perform a consecutive conversion

such as from £ to $, and then from $ to DM.

• The previous conversion result remains on the display, when you switch

from one conversion type to another. Press

C•CE

to clean the result

and start another conversion.

Convert 25°C to °F.

1. Press

(or

) to select the unit. (In this example, select the

conversion display number 16, which does not display the rate.)

2. Enter the value to be converted.

3. Press to convert it.

• The conversion result may have a slight calculation error as a result of

rounding off the number. Use the conversion result for reference.

CONVERSION

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM20

Secret Function

The Secret function allows you to protect confidential listings with a

password, so that no unauthorized person can recall them.

1. Registering a Password

Up to 7 characters can be registered for the password.

If you forget the password, it will be necessary to clear the password

and all secret listings from the memory (see page 18). As a safeguard,

make a written record of the password.

1. Press

2nd

SECRET

• If “ALLOW ACCESS TO SECRET DATA”

is displayed instead, a password is

already registered.

To delete and change the password, refer to page 22.

2. Enter the password. For example,

1234567

3. Press

ENTER

“PASSWORD [1234567] IS NOW SET”

and an “

” are displayed.

The “

” indicates the Secret

function is in effect.

4. Press

C•CE

to display the entry prompt.

2. Turning the Secret Function On and Off

When the Secret function is on, an “

” is displayed. When the Secret

function is off, the “

” is cleared even after the password is registered.

(1) Turning the Secret function off

1. Press

2nd

SECRET

2. Enter the password and press

ENTER

(Enter “1234567” in this case.)

“SECRET DATA ACCESSIBLE!” is displayed briefly. The Secret function

is now off and secret listings can be recalled. The display changes into

the entry prompt without the “

”.

• If the incorrect password is entered, “INCORRECT PASSWORD!” will be

displayed briefly and the display changes into the entry prompt.

• Even after the Secret function is turned off, the Secret function will

automatically be turned on after manual or auto power off.

(2) Turning the Secret function on

1. Press

2nd

SECRET

2. Press

to select “1 HIDE SECRET”.

“SECRET DATA IS HIDDEN!” is

displayed briefly. The Secret function is

now on and secret listings cannot be

recalled. The display changes into the entry prompt with the “

”.

3. Designating the Listings as Secret

Only one password can be registered, but many secret listings can be

entered.

A “ ” next to a listing indicates it is secret. Secret listings cannot be

recalled unless the Secret function is off.

(1) Storing a listing as secret

1. Press

2nd

MARK

during the data entry.

A “ ” is displayed.

2. Press

ENTER

to store it in the memory.

PASSWORD

[

1234567

]

IS NOW SET

SECRET DATA

[

–

]

ALLOW ACCESS TO

SET PASSWORD

[

–

]

1 HIDE SECRET

2 DELETE PASSWORD

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM21

(2) Designating a stored listing as secret

Designate the listing for “Xmas presents list” as secret.

1. Recall the listing.

2. Press

2nd

EDIT

to enter the edit mode.

3. Press

2nd

MARK

The “ ” is displayed.

4. Press

ENTER

The listing is now designated as secret.

(3) Changing a secret listing to non-secret

1. Turn the Secret function off. (Refer to page 21.)

2. Recall the desired secret listing.

3. Press

2nd

EDIT

to enter the edit mode.

4. Press

2nd

MARK

The “ ” disappears.

5. Press

ENTER

The secret listing is now changed to non-secret.

(4) Recalling (and editing) the secret listings

Perform recalling (or editing) the secret listings in each mode.

To recall (and edit) the secret listings, the Secret function must first be

turned off.

(5) Recalling only the secret listings

1. Turn the Secret function off. (Refer to page 21.)

2. Press the desired mode key to display the mode screen in which you

want to recall the listing.

3. Press

2nd

MARK

to display the “ ”.

4. Press

2nd

(or

2nd

The secret listings only are sequentially recalled.

• If no secret listing is found, “NOT FOUND!” is displayed briefly and the

display returns to the entry prompt.

(6) Deleting and changing the password

1. Turn the Secret function off. (Refer to page 21.)

2. Press

2nd

SECRET

3. Press

to select “2 DELETE

PASSWORD”.

4. Enter the old password to be deleted

and press

ENTER

“PASSWORD IS DELETED!” is displayed briefly and the display changes

into the entry prompt.

5. To register a new password, follow the procedure described in “1.

Registering a Password” on page 21.

If you forget the password

If you forget the password, you have to delete it by deleting all the secret

data.

Make sure that you really want to delete them, and see page 18, “(3)

Deleting the password and secret listings”.

Xmas presents list

Ring for Mother

Sweater for Jill

Xmas presents list

Ring for Mother

Sweater for Jill

EDIT

1 HIDE SECRET

2 DELETE PASSWORD

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM22

Battery Replacement

General guidelines

The Organizer uses the following type of battery:

Use Type Size/Model Qty.

General operation Alkaline batteries LR03 (L30) 2

1.Precautions

There are some extremely important points to remember when installing

new batteries:

• Replace the two operating batteries at the same time with new batteries

of the same type.

• Keep batteries out of the reach of children.

• Remove batteries from the unit when they become weak or when the

unit will not be used for a long period of time. Leaving weak batteries in

the unit may cause battery leakage and damage from corrosion.

• Do not dispose of batteries by fire as they may explode.

2.Replacing the operating batteries

The Organizer detects two low battery levels which are warning and fatal.

When the batteries is in warning level, the

BATT

symbol appears at the

display. In fatal level, the organizer will turn off automatically without

indication.

If the

BATT

symbol still appears or nothing is shown, replace both of the

operating batteries immediately.

1. Press

OFF

to turn off the Organizer.

2. Set the battery replacement switch on the bottom of the Organizer to

REPLACE BATTERIES.

3. Slide off the operating batteries cover.

4. Remove the old batteries by pulling the ribbon tab.

5. Insert the two new batteries on top of the ribbon tab, taking care to

position them correctly according to the plus (+) and minus (–)

terminals, as shown below.

6. Replace the cover.

7. Set the battery replacement switch to NORMAL OPERATION.

8. Press the RESET switch with a ball-point pen or similar object.

If nothing appears on the display, repeat the above battery replacement

procedure step by step.

9. Set the clock to the correct time.

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM23

Specifications

Model: YO-520

Display: 120 × 40 dot matrix liquid crystal display

Applications: Calendar, Schedule, To Do, Anniversary, Telephone,

Memo, Expense, Expense Report, Clock, Calculation,

Conversion

Memory capacity: 1MB Flash memory

User area approx. 896 KB

Application capacity: 10,000 entries

(Schedule 2,500, TEL 2,500, Memo 2,500, To Do

1,500, Expense 1,000) in total

These capacities assume the following average entry

sizes.

Schedule: 22 characters/entry

Tel: 8 characters/entry in the name field

10 characters/entry in number field

Memo: 12 characters/entry in title field

18 characters/entry in description field

To Do: 30 characters/entry in description field

Expense: 6 characters/entry in amount field

11 characters/entry in memo field

* Maximum storage in each application: 5,000 entries

Maximum data size per entry: Approx. 2,000 bytes

Calculator digits: 12

★ The following are the settings and contents that may change after

replacing the batteries.

• The alarm sound on and off

• The key touch tone on and off

• The DST

• The LCD contrast

• The CAPS on and off

• The memory of the calculator

• The first display contents when you press

SMBL

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM24

Clock mode:

Accuracy: ±30 seconds/month (at 25°C/77°F)

Display: Year, month, day, day of the week, hour, minute, AM/

PM, city name, time zone

Clock system: 12-hour/24-hour format (switchable) World clock

function, daylight saving time/summer time display

function, schedule alarm function

Peripherals and Data transfer interface:

Cable jack: 3-pin connector

Power consumption: 0.5W

Operating temperature: 0°C – 40°C (32°F – 104°F)

Power supply: Battery: 3V ... (DC)

(Alkaline batteries LR03 × 2)

Battery life:

Battery life may vary depending on usage.

• Approx. 1200 hours

When data is continuously displayed without Backlight (at 25°C/77°F).

• Approx. 300 hours

When data is continuously displayed with Backlight, for 2 minutes per

hourly use (at 25°C/77°F).

• Approx. 270 hours

When data is searched for 5 minutes, and displayed for 55 minutes

per hourly use and Backlight is on for 2 minutes per hourly use (at

25°C/77°F).

Weight: Approx. 175 g (0.39 lb.) (including batteries)

Dimensions:

Open: 139 mm (W) × 145.5 mm (D) × 11.8 mm (H)

5-15/32" (W) × 5-23/32" (D) × 15/32" (H)

Closed: 139 mm (W) × 80 mm (D) × 21 mm (H)

5-15/32" (W) × 3-5/32" (D) × 13/16" (H)

Accessories: Alkaline batteries LR03 x 2,

Operation manual,

Software CD-ROM,

PC Link cable

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM25

Using the included Software CD-ROM

The CD-ROM supplied in this package includes the following software. With

these applications, you can link your Organizer to your PC and increase the

functionality of your Organizer.

PC Software

This software enables you to synchronize data on your PC with that in your

Organizer.

Downloader for SHARP Electronic Organizer

This software lets you download a variety of contents for use with your

Organizer.

These helpful software are easy to install. Place the CD-ROM in the CD-

ROM drive on your PC, and the “SHARP Electronic Organizer Menu”

window will appear. Follow the instructions on the screen to complete

the installation. If the “SHARP Electronic Organizer Menu” does not

appear, double click the My Computer icon on your PC, click your CD-

ROM drive then proceed to install the software.

Before installing the software, read the software requirements.

1.PC Software Requirements

• Windows

2000 Professional, Windows

98 or Windows

• 133 MHz or higher Pentium-compatible CPU (Windows

2000

Professional),

75 MHz or higher Pentium-compatible CPU (Windows

98 or 95)

• 64MB RAM (Windows

2000 Professional),

24MB RAM (Windows

98 or 95)

• 16MB free hard disk space

• VGA monitor or better

• CD-ROM drive double speed or higher

• One available serial port with D-sub 9-pin connector

Your PC

PC Interface Cable

(supplied)

• Microsoft

Mouse or compatible Pointing Device

• An Internet Service Provider is required for Internet and Web access on

your PC.

2.Installing PC Software

To install PC software, make sure Windows is running on your PC and you

have the CD-ROM from your SHARP Organizer package.

1. Insert the CD-ROM in your CD-ROM drive to automatically start the

installation program.

2. Click the [Install] button.

3. Follow the installation instructions that appear on the screen.

3.To setup your Organizer for use with PC Software

1. First turn off your PC and Organizer before connecting the supplied

cable.

2. Connect the standard 9-pin connector of the supplied cable to one of the

COM ports on your PC.

• You will need to purchase an adaptor in order to use a COM port with a

25-pin connector.

3. Connect the supplied cable to the option port (COMPUTER LINK) of your

Organizer.

Connected to the option port

(COMPUTER LINK) of an

Organizer

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM26

Press

[

]

to quit.

READY!

PC SYNC/LINK

4. Turn on your PC and Organizer.

5. Press

PC SYNC

on your Organizer.

• Your Organizer is now ready to

exchange data.

• Press

at any time to exit the

PC-Link mode.

• The alarm setting is ignored. The alarm will not sound during data

transfer.

• The Auto power off function is disabled in the PC-Link mode.

• If an error message appears while transferring data, press

YO-520 (E0365E)

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM27

YO-520 (E0365E)

MEMO

YO-520 p20~28,E.E65 5/31/2000, 12:03 PM28

S-1

ÍNDICE

Empleo del Organizador por primera vez .......................................... S-1

Luz de fondo .................................................................................... S-2

Ajuste del contraste de LCD ............................................................. S-2

Activación y desactivación del “pitido” ............................................. S-2

Ajuste del reloj ........................................................................................ S-2

Selección del formato de fecha............................................................... S-2

Almacenamiento de los listines telefónicos ............................................ S-2

Visualización del calendario mensual ..................................................... S-3

Selección del formato semanal ............................................................... S-3

Almacenamiento de los listines del programa de actividades ................. S-3

Almacenamiento de los listines de cosas a hacer (“To Do”) ................... S-3

Almacenamiento de los listines de notas ................................................ S-4

Almacenamiento de los registros de gastos ........................................... S-4

Almacenando listines de aniversarios ..................................................... S-4

Llamada de los listines ........................................................................... S-4

Edición de los listines ............................................................................. S-5

Borrado de los listines ............................................................................ S-5

Modo de conversión ............................................................................... S-5

Utilización del CD-ROM de Software incluido ......................................... S-6

Empleo del Organizador por primera vez

(1) Instalación de las pilas

1. Ajuste el interruptor de recambio de las pilas en la parte inferior del

Organizador a REPLACE BATTERIES.

2. Deslice y saque la tapa del

compartimiento de las pilas.

3. Instale las dos pilas encima de la tira

de cinta, tal como se observa en la

figura.

4. Reinstale la tapa del compartimiento

de las pilas.

5. Ajuste el interruptor de recambio de

las pilas a NORMAL OPERATION.

(2) Inicialización del Organizador

1. Pulse el interruptor RESET mientras

mantiene pulsado

. Suelte el interruptor

RESET y luego suelte

Aparece “CLEAR ALL DATA OK(Y/N)?”

2. Pulse

para inicializar la memoria del

Organizador.

3. Seleccione el idioma deseado. Pulse

para ir a la siguiente pantalla de idioma, o

pulse

para ir a la pantalla de idioma

anterior.

Por ejemplo, pulse

para seleccionar inglés.

Instrucciones abreviadas en español

ESPAÑOL

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:52 AM1

S-2

Luz de fondo

Pulsando

BackLight

una vez la pantalla permanece encendida mientras

continúa usando el Organizador, hasta que deje de accionar las teclas

durante 15 segundos.

Ajuste del contraste de LCD

1. Pulse

para seleccionar “2 CONTRAST” (2 CONTRASTE).

2. Pulse o para hacer la pantalla

más oscura o más clara.

Activación y desactivación del “pitido”

Mientras “ ” se encuentre visualizado, sonará un “pitido” cada vez que

pulsa una tecla. Para activar y desactivar el “pitido”, pulse

2nd

(

2nd

). El pitido no sonará mientras “ ” se encuentre apagado.

Ajuste del reloj

1. Pulse

CLOCK

una o dos veces para

que se visualice el reloj local.

2. Pulse

2nd

EDIT

3. Pulse

para que se

visualice la ciudad deseada correspondiente a su zona local entre las

ciudades almacenadas en el Organizador.

4. Pulse

12 24

para seleccionar el reloj de 12 horas o de 24 horas.

• Cada vez que pulsa

12 24

, la visualización cambia entre ambos

formatos de reloj. Para el reloj de 12 horas, se visualizará AM o PM.

(Nota: 12:00PM: mediodía, 12:00AM: medianoche)

5. Introduzca la hora y los minutos. Por ejemplo,

1005

(Para el reloj de 24 horas, pulse 2205).

(Introduzca 2 dígitos tanto para la hora como para los minutos).

CONTRAST

–DARK

–LIGHT

NYC

[

18.0

]

MON JAN 1,2001

12:00

6. Introduzca el mes, el día y el año. Por ejemplo,

04122001

Utilice para omitir la entrada de un número que no necesita cambiar.

7. Pulse

ENTER

. El reloj comenzará a funcionar desde 0 segundo.

8. Pulse

CLOCK

para que se visualice el reloj mundial.

9. Pulse

2nd

EDIT

.Pulse

hasta que aparezca la ciudad correspondiente al

huso horario deseado.

.Pulse

ENTER

Selección del formato de fecha

1. Pulse

para seleccionar “5 DATE FORMAT” (5 FORMATO

FECHA).

2. Pulse

para seleccionar “MONTH/DAY/YEAR” o

“DAY.MONTH.YEAR”.

Almacenamiento de los listines telefónicos

En el modo de teléfono, un listín se compone de 4 entradas: nombre,

número, dirección de correo electrónico y dirección postal.

Asimismo, los listines de teléfono proporcionan 3 archivos (TEL1, TEL2,

TEL3). Cada vez que pulsa

TEL

, los archivos se desplazan

secuencialmente. Cambie convenientemente entre los archivos para

mantener separados los listines de negocios, privados y de otros fines.

1. Pulse

TEL

para visualizar el indicador

de entrada de TEL1.

TEL 1

NAME?

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:53 AM2

S-3

2. Introduzca el nombre, los números de

teléfono y de facsímil, la dirección de

correo electrónico, la dirección. Por

ejemplo,

Johns, Pat

ENTER

201-265-5600

F 265-1234

ENTER

[email protected]

ENTER

Box G, Sharp Plaza,

Mahwah, New Jersey,

07430-2135, U.S.A.

ENTER

Visualización del calendario mensual

: para visualizar el mes siguiente o anterior.

: para mover el cursor o desplazar el calendario una semana

hacia arriba o hacia abajo.

1. Pulse

CALENDAR

para que se

visualice el modo de calendario.

“ ” indica que la semana 5ª o 6ª del

mes está oculta abajo. Para visualizar

la semana 5ª o 6ª, pulse hasta que

el cursor se desplace a la siguiente

pantalla.

2. Pulse

) para visualizar el calendario del mes siguiente

(o anterior).

Selección del formato semanal

1. Pulse

CALENDAR

para que se visualice la pantalla del modo de

calendario.

2. Pulse

para seleccionar “1 WEEKLY FORMAT” (1

FORMATO SEMANAL).

3. Pulse

para seleccionar “SUN-SAT” o “MON-SUN”.

S M T W T F S2001

APR

Año

Mes

Día de la

semana

SUN JUN 24,2001

Lunch with Tom

–

11:30AM~ 1:00PM

Almacenamiento de los listines del programa de

actividades

Ingrese un listín del programa de actividades del 24 de junio de 2001.

1. Pulse

SCHEDULE

para que se visualice la pantalla del modo de

programa de actividades.

2. Pulse

C•CE

para que se visualice el indicador de entrada de fecha.

3. Introduzca la fecha, las horas de inicio

y de fin, los detalles del programa. Por

ejemplo,

06242001

ENTER

1130

Lunch with Tom

ENTER

4. Ahora, pulse

CALENDAR

para

comprobar que el listín ha quedado

almacenado en la memoria.

• Observe la etiqueta ( ) a la derecha de “24”. Indica un ítem

programado para esa fecha.

Almacenamiento de los listines de cosas a hacer (“To Do”)

1. Pulse

TO DO

para que se visualice el indicador de entrada de cosas a

hacer.

2. Introduzca la descripción. Por ejemplo,

Call Frank about a sales meeting

ENTER

3. Introduzca la prioridad. Por ejemplo,

ENTER

• La prioridad puede ajustarse a cualquier número de 0 a 9 o letra de A a

Z, o puede dejarse en blanco pulsando

ENTER

• El orden de prioridad es de 0 a 9, A a Z, seguido de espacio.

07430–2135, U.S.A.

–

201–265–5600

Box G, Sharp Plaza,

johns–[email protected]

Mahwah, New Jersey,

S M T W T F S2001

JUN

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:53 AM3

S-4

Xmas presents list

Ring for Mother

–

Sweater for Jill

EXPENSE

M/D/Y= 4/12/2001

DATE?

Verificación de los ítems realizados

1. Pulse

ENTER

para ingresar el modo de índice.

2. Pulse para seleccionar el ítem.

3. Pulse para marcarlo como ítem realizado.

• A los ítems marcados “ ” se asigna la prioridad más baja y se

clasifican al final de la lista.

Almacenamiento de los listines de notas

1. Pulse

MEMO

para que se visualice el indicador de entrada de notas.

2. Introduzca el título. Por ejemplo,

Xmas presents list

ENTER

3. Introduzca los detalles. Por ejemplo,

Sweater for Jill

Ring for Mother

ENTER

Almacenamiento de los registros de gastos

1. Pulse

EXPENSE

para ingresar el

modo de gastos.

2. Introduzca la fecha de gastos. Por

ejemplo,

04052001

ENTER

3. Introduzca el importe de los gastos. Por ejemplo,

1200

ENTER

4. Introduzca el apunte. Por ejemplo,

Flight tickets for inspection

abroad

ENTER

Almacenando listines de aniversarios

En el modo de aniversario, podrá especificar el mes y el día (como los

aniversarios de bodas y cumpleaños), o el mes, la semana y el día de la

semana (como el Día de la Madre (segundo domingo de mayo)).

Mes/Día

1. Pulse

ANN

para ingresar el modo de aniversario.

2. Pulse

para seleccionar “1 MONTH/DAY” (1 MES/DÍA) y visualizar el

indicador de entrada de fecha.

3. Introduzca la fecha y la descripción.

0212

ENTER

Nancy’s Birthday

ENTER

Mes/Semana

1. Pulse

ANN

para ingresar el modo de aniversario.

2. Pulse

para seleccionar “2 MONTH/WEEK” (2 MES/SEMANA) para

visualizar el modo de entrada de fecha.

3. Introduzca el mes, la semana, el día de

la semana, y a continuación introduzca

la descripción del aniversario.

05 2 0

ENTER

Mother's Day

ENTER

Llamada de los listines

(1) Búsqueda secuencial

Permite llamar los listines en el orden de cada modo.

Pulse

) para llamar los listines en orden progresivo (o

regresivo). Mantenga pulsada una u otra tecla para una llamada rápida.

• Pulse

2nd

) en el modo de programa de

actividades repetidas veces para llamar los listines saltando las fechas

vacantes. Pulse

C•CE

, luego pulse

2nd

)

para visualizar el primer (o último) listín en orden cronológico.

THU APR 5,2001

Flight tickets for i

1,200.00

nspection abroad

–

–ANN–

Nancy's Birthday

–

FEB 12

–ANN–

Mother's Day

–

MAY WEEK 2 SUN

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:53 AM4

S-5

• Cuando no hayan más listines (existentes o pertinentes) que se puedan

llamar o buscar, aparecerá “NOT FOUND!” (¡NO ESTÁ!) por unos

instantes y volverá a visualizarse el indicador de entrada.

(2) Búsqueda directa

1. Introduzca el primer carácter(es) del nombre deseado en cada modo.

2. Pulse

(3) Búsqueda por palabra clave

1. Seleccione el modo deseado. (Por ejemplo, pulse

TEL

2. Introduzca la palabra.

Sharp

3. Pulse

2nd

• Cada vez que pulsa

2nd

, se

visualizarán los listines subsiguientes

que contengan la palabra “Sharp”.

(4) Búsqueda por índice

Aparece una lista de los listines llamados, uno por cada renglón.

1. Seleccione el modo deseado. (Por ejemplo, pulse

TEL

2. Pulse

ENTER

para ingresar el modo

de índice.

• Pulsando

la página

se desplaza secuencialmente hacia

adelante y atrás. Para ver todos los listines, pulse y para

seleccionar el listín completo, y pulse

ENTER

. Seguidamente,

pulse

ENTER

otra vez para ingresar el modo de índice.

Edición de los listines

1. Llame un listín en el modo deseado.

2. Pulse

2nd

EDIT

3. Modifique los datos según se desee.

4. Pulse

ENTER

para almacenarlo en la memoria.

Borrado de los listines

(1) Borrado de un listín.

1. Liame el listin que desea borrar.

2. Pulse

DEL

Aparecerá “DELETE? Y/N” (¿BORRAR? S/N).

3. Pulse

para borrar el listín actualmente visualizado.

• Para cancelar la operación de borrado, pulse

(2) Borrado de todos los listines en cada modo

1. Pulse

para seleccionar “3 DATA DELETION” (3 BORRADO DE

DATOS).

2. Para borrar todos los listines, pulse la tecla de número del modo. (Para

seleccionar “To Do” y “SECRET DATA”, pulse

Aparecerá “DELETE? Y/N” (¿BORRAR? S/N).

3. Pulse

• Para cancelar la operación de borrado, pulse

Modo de conversión

(1) Ajuste del tipo de cambio

1. Pulse

CALC/CONV

una o dos veces para seleccionar el modo de

conversión.

2. Pulse

) para seleccionar el número de la pantalla de

conversión 1.

3. Pulse

2nd

EDIT

• La pantalla del resultado se borra y el tipo de cambio destella.

4. Introduzca el tipo de cambio. Por ejemplo,

0.6

ENTER

Johns, Pat

F 265–1234

201–265–5600

Box G, Sharp Plaza,

johns–[email protected]

Shingo Nakahara

Robert, Smith

Tom Robert

Stevenson Dug

Johns, Pat

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:53 AM5

S-6

(2) Conversión de monedas/unidades

Para convertir la unidad A en la unidad B, pulse .

Para convertir la unidad B en la unidad A, pulse .

1. Pulse

) para seleccionar la unidad. (En este ejemplo,

seleccione el número de la pantalla de conversión 1: $1 = £0.6).

2. Introduzca el valor que desea convertir.

198

3. Pulse para convertirlo.

Aparecerá el resultado de la conversión.

Utilización del CD-ROM de Software incluido

El CD-ROM suministrado con este paquete incluye el siguiente software.

Con estas aplicaciones, podrá enlazar su Organizador a su PC para que su

Organizador disponga de un número mayor de funciones.

Software de PC

Este software le permite sincronizar los datos de su PC con los de su

Organizador.

Downloader para el Organizador Electrónico SHARP

Este software le permite descargar diversos contenidos para usarlos con su

Organizador.

(1) Requisitos del Software de PC

• Windows

2000 Professional, Windows

98 o Windows

• CPU de 133 MHz o superior compatible con Pentium (Windows

2000

Professional),

CPU de 75 MHz o superior compatible con Pentium (Windows

98 ó 95)

• 64MB RAM (Windows

2000 Professional) ,

24MB RAM (Windows

98 ó 95)

• 16MB de espacio disponible en disco duro

198.

CONVERSION 1

$ £

0.6

• Monitor VGA o superior

• Unidad de CD-ROM de velocidad doble o superior

• Un puerto en serie disponible con conector D-sub de 9 patillas

• Microsoft

Mouse o dispositivo apuntador compatible

• Se requiere un proveedor de servicios de Internet para poder acceder a

Internet y sitios web desde su PC.

(2) Instalación del Software de PC

Para instalar el Software de PC, asegúrese de que su PC esté ejecutando

Windows y de que tiene a mano el CD-ROM del paquete de su Organizador

SHARP.

1. Inserte el CD-ROM en su unidad de CD-ROM para iniciar

automáticamente el programa de instalación.

2. Haga clic en el botón [Install].

3. Siga las instrucciones de instalación que aparecen en pantalla.

(3) Cómo configurar su Organizador para usarlo con el Software de PC

1. Antes de conectar el cable suministrado, primero apague su PC y el

Organizador.

2. Conecte el conector de 9 patillas estándar del cable suministrado a uno

de los puertos COM de su PC.

• Para poder usar el puerto COM con un conector de 25 patillas, deberá

comprar un adaptador.

3. Conecte el cable suministrado al puerto opcional (COMPUTER LINK) de

su Organizador.

4. Encienda su PC y su Organizador.

5. Pulse

PC SYNC

en su Organizador.

• Su organizador ha quedado preparado para intercambiar datos.

• Para salir del modo de enlace de PC, pulse

en cualquier

momento.

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:54 AM6

S-7

• EL ajuste de la alarma será ignorado. La alarma no sonará durante la

transferencia de datos.

• La función de desactivado automático se inhabilita en el modo de enlace

de PC.

• Si aparece un mensaje de error mientras transfiere los datos,

pulse

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:54 AM7

Declaration of Conformity

Electronic Organizer : YO-520

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Responsible Party:

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

TEL: 1-800-BE-SHARP

Tested To Comply With FCC Standards

FOR HOME OR OFFICE USE

WARNING – FCC Regulations state that any unauthorized changes or

modifications to this equipment not expressly approved by the

manufacturer could void the user’s authority to operate this equipment.

Note: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Note: A shielded interface cable is required to ensure compliance with

FCC regulations for Class B certification.

PRODUCT SUPPORT

If you have read the ORGANIZER operation manual, but you still require

product support, you can:

Call a Sharp Customer Assistance Center

630-378-3590

(7am to 7pm CST M–F)

Visit our Web Site

http://www.sharp-usa.com

Send an E-mail

pdasuppor[email protected]

Write to our Customer Assistance Center

Sharp Electronics Corp.

Customer Assistance Center

Att: WIZARD HELP

1300 Naperville Drive

Romeoville, IL 60446

YO-520 (E0365E)

YO-520 p01~08,Sp.E65 5/31/2000, 11:54 AM8

LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer

purchaser that this Sharp brand product (the “Product”), when shipped

in its original container, will be free from defective workmanship and

materials, and agrees that it will, at its option, either repair the defect or

replace the defective Product or part thereof with a new or remanufactured

equivalent at no charge to the purchaser for parts or labor for the period(s)

set forth below.

This warranty does not apply to any appearance items of the Product nor

to the additional excluded item(s) set forth below nor to any Product the

exterior of which has been damaged or defaced, which has been subjected

to improper voltage or other misuse, abnormal service or handling, or

which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser

should follow the steps set forth below and provide proof of purchase to

the servicer.

The limited warranty described herein is in addition to whatever implied

warranties may be granted to purchasers by law. ALL IMPLIED

WARRANTIES INCLUDING THE WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE

PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW.

Some states do not allow limitations on how long an implied warranty

lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized

to make any warranties other than those described herein, or to extend

the duration of any warranties beyond the time period described herein

on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties

granted by Sharp and shall be the sole and exclusive remedy available

to the purchaser. Correction of defects, in the manner and for the period

of time described herein, shall constitute complete fulfillment of all liabilities

and responsibilities of Sharp to the purchaser with respect to the Product,

and shall constitute full satisfaction of all claims, whether based on

contract, negligence, strict liability or otherwise. In no event shall Sharp

be liable, or in any way responsible, for any damages or defects in the

Product which were caused by repairs or attempted repairs performed

by anyone other than an authorized servicer. Nor shall Sharp be liable or

in any way responsible for any incidental or consequential economic or

property damage. Some states do not allow the exclusion of incidental

or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY

ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Your Product : Electronic Organizer

Warranty Period for this One (1) year parts and labor from date

Product : of purchase.

Additional Items Excluded Any consumable items such as paper,

from Warranty Coverage : maintenance cartridge, ink cartridges

supplied with the Product or to any

equipment or any hardware, software,

firmware, fluorescent lamp, power cords,

covers, rubber parts, or peripherals other

than the Product.

Where to Obtain Service : At a Sharp Authorized Servicer located

in the United States. To find out the

location of the nearest Sharp Authorized

Servicer, call Sharp toll free at 1-800-BE-

SHARP.

What to do to Obtain Service : Ship (prepaid) or carry in your Product to

a Sharp Authorized Servicer. Be sure to

have proof of purchase available. If you

ship or mail the Product, be sure it is

packaged carefully.

TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP.

YO-520 (E0365E)

YO-520 Hyoshi,E.E65 5/31/2000, 11:43 AM5

PRINTED IN CHINA/IMPRESO EN CHINA

00CTO (TINSE0365EHZZ)

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

YO-520 (E0365E)

YO-520 Hyoshi,E.E65 5/31/2000, 11:43 AM2

Sharp YO-520 Electronic Organizer

Product's Documents

User Manual

Specifications

Sharp YO-520 Questions and Answers

Related Products

Sharp EL-6710 Electronic Organizer

Sharp OZ-730 Electronic Organizer Pocket Computer

Sharp EL-6061H Electronic Organizer Memo Master 100

Sharp YO-530 Electronic Organizer

Sharp YO-180 Electronic Organizer

Sharp EL-6360 Electronic organizer
