User Manual Bosch HMT75M451B Freestanding microwave46 x 29 cm Stainless steel

Documents for Bosch HMT75M451B

User Manual

For HMT75M451B. Also, The document are for others Bosch models: HMT75M421B, HMT75M461B

• [en] Instruction manual1
• Ú Table of contents[en] Instruction manual2
  • Installation and connection 52
  • The control panel 52
  • Before using the appliance for the first time 62
  • The microwave 62
  • Memory 72
  • Changing the signal duration 82
  • Care and cleaning 82
  • Malfunction table 92
  • After-sales service 102
  • Automatic programmes 102
  • Tested for you in our cooking studio 112
  • Test dishes in accordance with EN 60705 142
    • : Important safety information2
  • Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual for future use or for subsequent owners.2
  • Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.2
  • Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.2
  • This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.2
  • This appliance is intended for use up to a maximum height of 2000 metres above sea level.2
  • This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...2
  • Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.2
  • Keep children below the age of 8 years old at a safe distance from the appliance and power cable.2
    • Risk of fire!2
    • ■ Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...2
      • Risk of fire!2
    • ■ The appliance becomes very hot. Pay attention to the information in the section Installation and connection regarding minimum clearances for the appliance. The appliance must not be installed in a fitted unit.3
      • Risk of fire!3
    • ■ Using the appliance for anything other than its intended purpose is dangerous and may cause damage. The following is not permitted: drying out food or clothing, heating slippers, grain or cereal pillows, sponges, damp cleaning cloths or similar. ...3
      • Risk of fire!3
    • ■ Food may catch fire. Never heat food in heat-retaining packages. Do not leave food heating unattended in containers made of plastic, paper or other combustible materials. Do not select a microwave power or time setting that is higher than necessa...3
      • Risk of fire!3
    • ■ Cooking oil may catch fire. Never use the microwave to heat cooking oil on its own.3
      • Risk of explosion!3
        • Liquids and other food may explode when in containers that have been tightly sealed. Never heat liquids or other food in containers that have been tightly sealed.3
      • Risk of serious damage to health!3
    • ■ The surface of the appliance may become damaged if it is not cleaned properly. Microwave energy may escape. Clean the appliance on a regular basis, and remove any food residue immediately. Always keep the cooking compartment, door seal, door and ...3
      • Risk of serious damage to health!3
    • ■ Microwave energy may escape if the cooking compartment door or the door seal is damaged. Never use the appliance if the cooking compartment door or the door seal is damaged. Contact the after- sales service.3
      • Risk of serious damage to health!3
    • ■ Microwave energy will escape from appliances that do not have any casing. Never remove the casing. For any maintenance or repair work, contact the after-sales service.3
      • Risk of electric shock!3
    • ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...3
      • Risk of electric shock and serious injury!3
    • ■ The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.3
      • Risk of electric shock!3
    • ■ Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.3
      • Risk of electric shock!3
    • ■ Penetrating moisture may cause electric shock. Never subject the appliance to intense heat or humidity. Only use this appliance indoors.3
      • Risk of electric shock!3
    • ■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.3
      • Risk of electric shock!3
    • ■ The appliance is a high-voltage appliance. Never remove the casing.3
      • Risk of burns!3
    • ■ The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.3
      • Risk of serious burns!3
    • ■ Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.3
      • Risk of burns!3
    • ■ Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care3
      • Risk of burns!3
    • ■ Foods with peel or skin may burst or explode during, or even after, heating. Never cook eggs in their shells or reheat hard-boiled eggs. Never cook shellfish or crustaceans. Always prick the yolk when baking or poaching eggs. The skin of foods th...4
      • Risk of burns!4
    • ■ Heat is not distributed evenly through baby food. Never heat baby food in closed containers. Always remove the lid or teat. Stir or shake well after the food has been heated. Check the temperature of the food before it is given to the child.4
      • Risk of burns!4
    • ■ Heated food gives off heat. The ovenware may become hot. Always use oven gloves to remove ovenware or accessories from the cooking compartment.4
      • Risk of burns!4
    • ■ Airtight packaging may burst when food is heated. Always observe the instructions on the packaging. Always use oven gloves to remove dishes from the cooking compartment.4
      • Risk of scalding!4
    • ■ When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance.4
      • Risk of scalding!4
    • ■ Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment.4
      • Risk of scalding!4
    • ■ There is a possibility of delayed boiling when a liquid is heated. This means that the liquid reaches boiling temperature without the usual steam bubbles rising to the surface. Even if the container only vibrates a little, the hot liquid may sudd...4
      • Risk of injury!4
    • ■ Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.4
      • Risk of injury!4
    • ■ Unsuitable ovenware may crack. Porcelain or ceramic ovenware can have small perforations in the handles or lids. These perforations conceal a cavity below. Any moisture that penetrates this cavity could cause the ovenware to crack. Only use micro...4
  • Causes of damage4
    • Caution!4
      • ■ Heavily soiled seal4
      • ■ Operating the microwave without food4
      • ■ Microwave popcorn4
      • ■ Creation of sparks4
      • ■ Foil containers4
      • ■ Cooling with the appliance door open4
      • ■ Condensation in the cooking compartment4
    • Installation and connection5
      • Notes5
    • The control panel5
      • Rotary selector6
  • Accessories6
    • How to fit the turntable:6
      • 1. Place the turntable ring a in the recess in the cooking compartment.6
      • 2. Let the turntable b slot in place in the drive c in the centre of the cooking compartment floor.6
    • Note6
    • Special accessories6
    • Before using the appliance for the first time6
      • Setting the clock6
        • 1. Press the 0 button.6
          • 2. Set the clock using the rotary selector.6
          • 3. Press the 0 button again.6
          • Hiding the clock6
          • Resetting the clock6
          • Change the clock, e.g. from summer to winter time6
    • The microwave6
      • Note6
    • 1. Press 800 W.6
      • 2. Set 1:30 minutes using the rotary knob.6
      • 3. Press the Start button.6
  • Notes regarding ovenware7
    • Suitable ovenware7
    • Unsuitable ovenware7
    • Caution!7
    • Ovenware test7
    • 1. Heat the empty ovenware at maximum power for ½ to 1 minute.7
      • 2. Check the temperature occasionally during that time.7
  • Microwave power settings7
    • Note7
  • Setting the microwave7
    • 1. Press the required microwave power setting.7
      • 2. Set a cooking time using the rotary selector.7
      • 3. Press the Start button.7
      • The cooking time has elapsed7
      • Changing the cooking time7
      • Pausing7
      • Cancelling operation7
      • Note7
  • Cooling fan7
    • Notes7
    • Memory7
      • Notes7
  • Saving memory settings7
    • Example: 360 W, 25 minutes7
    • 1. Press the i button.7
      • 2. Press the required microwave power setting.8
      • 3. Set the cooking time using the rotary selector.8
      • 4. Confirm by pressing the i button.8
  • Starting the memory8
    • 1. Press the i button.8
      • 2. Press the Start button.8
      • The cooking time has elapsed8
      • Pausing8
      • Cancelling the setting8
    • Changing the signal duration8
    • Care and cleaning8
      • : Risk of short circuit!8
      • : Risk of burns!8
      • : Risk of electric shock!8
      • Do not use8
  • Cleaning agents8
    • Caution!8
    • Malfunction table9
      • : Risk of electric shock!9
      • Troubleshooting9
    • After-sales service10
      • E number and FD number10
        • To book an engineer visit and product advice10
  • Technical data10
  • Environmentally-friendly disposal10
    • Automatic programmes10
      • Setting a programme10
        • 1. Press the g button repeatedly until the required programme number appears.10
        • 2. Press the 1 button.10
        • "P" and a default weight appear in the display.10
          • 3. Turn the rotary selector to specify the weight of the dish.10
          • 4. Press the Start button.10
        • The cooking time has elapsed10
        • Correction10
        • Pausing11
        • Cancelling operation11
        • Notes11
  • Defrosting using the automatic programmes11
    • Notes11
  • Cooking with the automatic programmes11
    • Notes11
    • Tested for you in our cooking studio11
      • Information regarding the tables11
  • Defrost11
    • Notes11
  • Defrosting, heating up or cooking frozen food12
    • Notes12
  • Heating food13
    • : Risk of scalding!13
    • Caution!13
    • Notes13
  • Cooking food13
    • Notes13
    • Microwave tips14
      • Condensation14
    • Test dishes in accordance with EN 6070514
      • Cooking and defrosting with microwave14
        • Microwave cooking14
        • Microwave defrosting14
