MODEL:
HR6CDFF695GB
HR6CDFF695GW
Contents
2
Brief introduction
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to
ensure that they do not play with the
appliance.
Do not store explosive substances
such as aerosol cans with a flammable
propellant in this appliance.
WARNING—Keep ventilation openings,
in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING—Do not use mechanical
devices or other means to accelerate
the defrosting process, other than those
recommended by the manufacturer.
WARNING—Do not damage the
refrigerant circuit.
WARNING—Do not use electrical
appliances inside the food storage
compartments of the appliance, unless
they are of the type recommended by
the manufacturer.
WARNING—When disposing of the
appliance do so only at an authorized
waste disposal centre. Do not expose to
flame.
WARNING—If the supply cord is
damaged, it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.
●
Thank you for your choosing our
products. We are sure you will find
your new appliance a pleasure to use.
Before you use the appliance, we
recommend that you read through
these instructions carefully, which
provides details about its usage and
functions.
Please ensure that all people using
this appliance are familiar with its
operations and safety features. It is
important that you install the appliance
correctly and pay attention to the safety
instructions carefully.
We recommend that you keep this
user's manual with the appliance for
future reference and retain it to any
future users.
This appliance is intended to be used
in household and similar applications
such as:
-Staff kitchen- areas in shops, offices
and other working environments;
-Farmhouses by clients in hotels,
motels and other residential types of
environment;
- B e d a n d b r e a k f a s t t y p e o f
environments;
-Catering and similar non-retail
applications.
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
●
●
●
●
2
8
17
5
7
10
15
12
13
Brief introduction
Import safety instroctions
3
3
Safety for children and infirm persons
Safety about electricity
●
●
●
●
●
●
●
●
Unpack the appliance and check
through the appliance. Should any
damage be evident, don't plug in the
appliance but contact the shop
immediately from which you purchased
it. Keep all packing materials in this
case.
We recommend that you wait for 4
hours before connecting the appliance
to allow the refrigerant to flow back into
the compressor.
The appliance must be applied with
single phase alternating current of
220~240V/50Hz. If the voltage
fluctuates exceeding the upper limit,
A.C. automatic voltage regulator of
more than 350W should be applied to
the refrigerator for safety use.
The mains plug must be accessible
when the appliance is installed.
recommend that you follow the
guidelines below.
Store any food in accordance with the
s t or a ge i ns t ru c ti on s f ro m t he
manufacturer.
Don't try to repair the appliance
yourself. It is dangerous to alter the
specifications or modify this product in
any way. Any damage to the cord may
cause short circuit, fire or electric
shock.
Don't place too much food directly
against the air outlet on the rear wall of
both the refrigerator and freezer
compartment, as it affects sufficient air
circulation.
Don't place hot items near the plastic
components of this appliance.
Frozen food must not be refrozen
once it has been thawed out.
Don't store bottled or canned drinks
(especially carbonated drinks) in the
freezer compartment. Bottles and cans
may explode.
Do not consume ice popsicles or ice
cubes straight from the freezer as this
can cause freezer burn to the mouth
and lips.
●
●
Keep all packaging away from
children to avoid risk of suffocation.
Protect children from being scalded
by touching the very hot compressor at
the rear bottom of appliance.
Don't place items on top of the
appliance as this could cause injury
should they fall off.
Never allow children to play with the
appliance by hanging or standing over
or on the doors, racks, shelves and
drawers etc.
●
●
●
To avoid the risks that are
always present when using an
electric appliance, we recommend that
you pay more attention to the
instructions about electricity below.
Important safety instructions
●
It is important to use your
appliance safely. We
General safety and daily use
4
●
This appliance must be earthed.
-This appliance is fitted with a plug in
accordance with local standard. The
plug should be suitable for use in all
houses fitted with sockets in
a c c o r d a n c e w i t h c u r r e n t
specifications.
-If the fitted plug is not suitable for
your socket outlets, it should be cut
off and carefully disposed of. To avoid
a possible shock hazard, do not insert
the discarded plug into a socket. If in
doubt contact a qualified, registered
electrician.
Do not use extension cords or
multiple sockets which could cause
overloading of wiring circuits and could
cause a fire.
Always plug your appliance into its
own individual electrical socket which
has a voltage rating that matched the
rating plate.
●
●
●
Make sure that the plug is not
squashed or damaged. Otherwise, it
may cause short circuit, electric shock
or overheat and even cause a fire.
Do not insert the mains plug if the
socket is loose, there is a risk of
electric shock or fire.
Switch off the appliance and
disconnect it from the mains power
before you clean or move it.
Never unplug the appliance by pulling
on the electrical cord. Always grip the
plug firmly and pull straight out from
the socket to prevent damaging the
power cord.
●
●
●
●
●
Do not operate the appliance without
the light cover of interior lighting.
Any electrical component must be
replaced or repaired by a qualified
electrician or authorized service
engineer. Only genuine spares should
be used.
Do not use electrical appliances such
as ice cream makers inside the food
s t o ra g e co m p ar t m en t s o f t h e
appliance, unless they are approved
by the manufacturer.
Do not look direct into the LED light
located in the refrigerator compartment
with optical instruments to avoid eye
injuries. If it is not functioning correctly,
consult a qualified, registered
electrician or replace it in accordance
with the “cleaning and care” chapter.
●
Refrigerant
The refrigerant isobutene (R600a) is
contained within the refrigerant circuit
of the appliance, a natural gas with a
h i g h l e v e l o f e n v i r o n m e n t a l
compatibility, which is nevertheless
flammable. During transportation and
installation of the appliance, ensure
that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
5
●
●
●
Don't store products which contain
flammable propellants(e.g. spray cans )
or explosive substances in the
appliance.
Should the refrigerant circuit be
damaged:
Avoid opening flames(candles,
lamps etc.) and sources of ignition.
Thoroughly ventilate the room in
which the appliance is situated.
Service Note
This appliance employs
Hydrocarbon Refrigerant type
R600a.
It is hazardous for anyone other
than an Authorized Service Person
to service this applian. In
Queensland the authorized Service
Person MUST hold a Gas Work
Authorization for hydrocarbon
refrigerants to carry out servicing or
repairs which involve removal of
covers.
Caution: risk of fire
●
●
Installing your new appliance
Ventilation of appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
In order to improve efficiency
of the cooling system and save
energy, it is necessary to maintain
good ventilation around the appliance
for the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest :It is advisable for there to be
at least 100mm of space from the back
to the wall, at least 300mm from its
top,at least 200mm from its side to the
wall and a clear space in front to allow
the doors to open 135°.As shown in
following diagrams
200
300
100
Climate class
Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Leveling of appliance
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted.
●
≤10mm
To allow the doors to self-close, tilt
the top backwards by about 10mm.
Note:
the climate class showed in the table
below.
This appliance performs well within
It may not work properlyif being
left at a temperature above or below
the indicated range for a long period.
908mm
650m
m
765mm
1410mm
1
2
0
°
12
0°
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct
sunlight， rain or frost. Stand the
appliance away from heat sources
such as stoves, fires or heaters.
●
●
●
You can adjust them manually by
hand or by using a suitable spanner.
●
6
Note:
slightly different from this instruction manual, but its functions and using methods
remain the same. To get more space in the freezer, you can remove drawers
(except lower freezer drawer) and twistable ice tray.
Due to unceasing modification of our products, your refrigerator may be
Freezer glass shelves
Twistable ice tray (inside)
Freezer LED light
Rotary separator
Fridge LED light
Egg tray(located in the plastic bag)
Adjustable bottom feet
Freezer
Fridge
15
17
23
25
18
19
21
22
10
20
24
26
16
Left fridge upper rack
Refrigerator air duct cover
Movable rack
Left fridge small rack
Serving tray
15
16
Bottles block stripe
19
20
21
23
24
Middle drawer
26
Lower drawer
25
22
18
27
17
My Fresh Choice
Freezer rack
Nano negative ion preservation
technology system
Right fridge upper rack
Fridge glass shelf
Upper crisper box cover
Lower crisper box cover
Right fridge small rack
Right fridge middle rack
Upper crisper box
Lower crisper box
My Fresh Choice LED light
My Fresh Choice rack
7
(optional)
Display controls
Controlling the temperature
We recommend that when you start
your refrigerator for the first time, the
temperature for the refrigerator is set
to 5°C ,my fresh choice to -12 and
the freezer to -18°C. If you want to
change the temperature, follow the
instructions below.
Caution! When you set a temperature,
you set an average temperature for
the whole refrigerator cabinet.
Temperatures inside each
compartment may vary from the
temperature values displayed on the
panel, depending on how much food
you store and where you place them.
Ambient temperature may also affect
the actual temperature inside the
appliance.
°C
Use your appliance according to the following control regulations, your appliance
has the corresponding functions and modes as the control panels showed in the
pictures below. When the appliance is powered on for the first time, the
backlighting of the icons on display panel starts working. If no buttons have been
pressed and the doors are closed, the backlighting will turn off.
Lock
Artificial Intelligence
Holiday
Super Freeze
1. Fridge
Press "Fridge" button repeatedly to
set your desired fridge temperature
between 8 and 2 , the
temperature will decrease 1
degrees with each press and the
fridge temperature indicator will
display corresponding value according
to the following sequence.
°C °C
°C
5
3. Freezer
Press "Freezer" button to set the freezer
temperature between -14°C and -24°C to
suit your desired temperature, and the
freezer temperature indicator will display
corresponding value according to the
following sequence.
-20°C
-21°C
-22°C -23°C
-24°C-14°C
-19°C
-17°C
-16°C
-15°C
-18°C
2. My Fresh Choice
Press "My Fresh Choice" button to set the
my fresh choice temperature between
-5°C and -20°C to suit your desired
temperature, and the my fresh choice
temperature indicator will display
corresponding value according to the
following sequence.
8
4. Super Freeze
Super Freeze can rapidly
lower frozen temperature and
freeze you food substantially
faster than usual.
Refrigerator unlock key
Fridge temperature display area
My Fresh Choice temperature display area
Freezer temperature display area
Run mode icon
Fridge temperature setting key
My Fresh Choice temperature setting key
Freezer temperature setting key
Run mode setting key
Refrigerator unlock icon
4
3
2
87
6
-14°C
-15°C
......
-20°C
-5°C-8°C
-13°C
-11°C
-10°C
-9°C
-12°C
the fridge during this time.
When the holiday function is on, you
can switch it off by pressing any button
of "Mode", "Fridge" and " Freezer”
button.
Do not store any food in Important !
This feature also helps to keep
vitamins and nutrition of fresh food for
longer period.
Press button to "Mode”
activate the super freeze function. The
super freeze light will be illuminated
and the freezer temperature setting
will display -24
Super freeze automatically switches
off after 26 hours .
When super freeze function is on,
you can switch it off by pressing any
button of "Mode" ,and”Freezer” button.
°C.
When the holiday function is
activated, the temperature of
the refrigerator is automatically
switched to °C to minimise
the energy consumption.
15
5.Artificial intelligence
When the function is
activated, the temperature of
the refrigerator is
automatically switched to
6. Holiday
The temperature of the freezer is
automatically switched to -18°C.
8. Mode
You can select different modes by
pressing the “Mode ” button when
" " .When certain mode is
selected, wait for the
corresponding icon flashing for 10
seconds.
●
●
●
5°C ,the temperature of freezer is
automatically switched to -18°C.
●
9. Unlock
All the buttons are locked if the icon
“ ” is illuminated, press the
“Unlock” button for 3
seconds to unlock them. And it will
be locked itself after 20 seconds no
pressing any button.
9
7. Dual ion sterilization preservation
technology system
In the unlock state, press "Unlock"
and “Mode” button for 3 seconds, and
than beep twice, to enter the
sterilization mode. This mode will last
for 30 hours. E
nter the sterilization
mode, the “Fridge temperature display
area” flashing display “℃”.
Enter the sterilization mode after 60
minutes, if you open the fridge door,
then exit sterilization mode, and the
“Fridge temperature display area” is
normal, no longer flashing display “℃”.
You can also exit sterilization mode
manually. In the unlock state, press
"Unlock" and “Mode” button for 3
seconds, and than beep twice, to exit
the sterilization mode.
●
●
●
If your production has dual ion
sterilization preservation technology
system .It has the function of
sterilization preservation.
Using your appliance
You appliance has the accessories as the "Description of the showed in
general, with this part instruction you can have the right way to use them.
appliance”
Door rack
It is suitable for the storage of eggs,
canned liquid, bottled drinks and
packed food, etc. Do not place too
many heavy things in the racks
The middle door racks can be placed
at different heights according to your
appliance. Please take food out of the
racks before lifting vertically to
reposition.
●
●
Shelf
There are three glass shelves in
refrigerator chamber. They can be
adjusted to various heights as needed.
●
When you remove the shelves, gently
pull them forward until the shelf
comes clear of the shelf guides.
When you return the shelves, make
sure there is no obstacle behind and
gently push the shelf back into the
position.
●
●
All the door racks are completely
removable for cleaning.
●
Crispers
The crisper, mounted on
telescopic extension slides, is for
storing vegetables and fruits.
●
To save energy, please avoid
keeping the door open for a long
time when using the appliance. The
door alarm can be cleared by closing
the door.
10. Door alarm
If the door of fridge or freezer is open
for over 2 minutes, the door alarm
will sound. The buzzer will
automatically stop alarming 10
minutes later.
10
Using your freezer drawer
The freezer drawers are suitable
for storage of foods required to be
frozen, such as meat, ice cream and
others.
Caution! Ensure that bottles are not
stored in the freezer as freezing
may cause the bottle to break.
●
freezer
to make and store ice cubes.you should use
it as follows
freezer compartment.
freezer compartment.
11
Helpful hints and tips
●
●
refrigerator or freezer, the internal
temperature will increase resulting in
the compressor having to work harder
and will consume more energy.
Do cover or wrap the food，
particularly if it has a strong flavor.
Place food properly so that air can
circulate freely around it.
Hints for refrigeration
Meat (All Types) Wrap in polythene
food: wrap and place on the glass shelf
above the vegetable drawer. Always
follow food storage times and use by
dates suggested by manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
●
●
Energy saving tips
We recommend that you follow the tips
below to save energy.
Try to avoid keeping the door open
for long periods in order to conserve
energy.
Ensure the appliance is away from
any sources of heat (Direct sunlight,
electric oven or cooker etc)
Don't set the temperature colder than
necessary.
Don't store warm food or evaporating
liquid in the appliance.
Place the appliance in a well
ventilated, humidity free, room. Please
refer to Installing your new appliance
chapter.
If the diagram shows the correct
combination for the drawers, crisper
and shelves, do not adjust the
combination as this is designed to be
the most energy efficient configuration.
Hints for fresh food refrigeration
Do not place hot food directly into the
●
●
●
●
●
●
●
Cleaning and care
Milk bottles:
Should have a lid and be stored in the
door racks.
Hints for freezing
When first starting-up or after a period
out of use, let the appliance run at
least 2 hours on the higher settings
before putting food in the
compartment.
Prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible to
subsequently thaw only the quantity
required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight,
Do not allow fresh unfrozen food to
touch the food which is already frozen
to avoid temperature rise of the latter.
Iced products，if consumed
immediately after removal from the
freezer compartment, will probably
，
●
●
●
●
cause frost burns to the skin.
each frozen package in order to keep
track of the storage time.
Hints for the storage of frozen food
Ensure that frozen food has been
stored correctly by the food retailer
rapidly and should not be re-frozen. Do
not exceed the storage period indicated
by the food manufacturer.
Switching off your appliance
If the appliance needs to be switched
off for an extended period, the following
steps should be taken prevent mould
on the appliance.
It is recommended to label and date
Once defrosted，food will deteriorate
●
●
●
●
●
Butter and cheese:
Should be wrapped in airtight foil or
plastic film wrap.
●
12
●
Cleaning and care
For hygienic reasons the appliance
(including exterior and interior
accessories) should be cleaned
regularly at least every two months.
Caution! The appliance must not be
connected to the mains during
cleaning. Danger of electrical shock!
Before cleaning switch the appliance
off and remove the plug from the
mains socket.
Exterior cleaning
To maintain good appearance of your
appliance, you should clean it
regularly.
-Wipe the digital panel and display
panel with a clean, soft cloth.
-Spray water onto the cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of moisture
to the surface.
-Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wiped dry with a soft cloth.
Caution!
-Don't use sharp objects as they are
likely to scratch the surface.
-Don't use Thinner, Car detergent,
Clorox, ethereal oil, abrasive cleansers
or organic solvent such as Benzene for
cleaning. They may damage the
surface of the appliance and may
cause fire.
Interior cleaning
defrosts, a layer of frost may occur on
the freezer compartment's interior
walls if the freezer door is opened
frequently or kept open too long. If the
frost is too thick, choose a time when
the supply of food stocks are low and
proceed as follows:
1.Remove existing food and
accessories baskets, unplug the
appliance from the mains power and
leave the doors open. Ventilate the
room thoroughly to accelerate the
thawing process.
2. When defrosting is completed, clean
your freezer as described above.
Caution!
remove frost from the freezer
compartment. Only after the interior is
completely dry should the appliance be
switched back on and plugged back
into the mains socket.
Don't use sharp objects to
1. Remove all food.
2. Remove the power plug from the
mains socket.
You should clean the appliance interior
regularly. It will be easier to clean
when food stocks are low. Wipe the
inside of the fridge freezer with a weak
solution of bicarbonate of soda, and
then rinse with warm water using a
wrung-out sponge or cloth. Wipe
completely dry before replacing the
shelves and baskets.
Thoroughly dry all surfaces and
removable parts.
Although this appliance automatically
3. Clean and dry the interior
thoroughly.
4. Ensure that all the doors are
wedged open slightly to allow air to
circulate.
13
Defrosting
Water contained in the food or getting into air inside the fridge by opening doors may
form a layer of frost inside .It will weaken the refrigetation when the frost is thick.
This appliance is frost-free refrigerator, Automatic defrost itself regularly, without
manual defrost.Water from defrosting will be drained into an drip tray through a drain
pipe,Then the water within the drip tray will be evaporated.
●
●
Door seals cleaning
Take care to keep door seals clean.
Sticky food and drinks can cause seals
to stick to the cabinet and tear when
you open the door. Wash seal with a
mild detergent and warm water. Rinse
and dry it thoroughly after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on.
Replacing the LED light:
Warning: The LED light must not be
replaced by the user! If the LED light is
damaged, contact the customer
helpline for assistance. To replace the
LED light, the below steps can be
followed:
1. Unplug your appliance.
2. Remove light cover by pushing up
and out.
3. Hold the LED cover with one hand
and pull it with the other hand while
pressing the connector latch.
4. Replace LED light and snap it
correctly in place.
14
Troubleshooting
If you experience a problem with your appliance or are concerned that the
appliance is not functioning correctly, you can carry out some easy checks
according to this section before calling for service. You can carry out some easy
Warning!
have made the checks mentioned below, contact a qualified electrician, authorized
service engineer or the shop where you purchased the product.
Don't try to repair the appliance yourself. If the problem persists after you
Problem
Check h h w ether t e power cord is plugged into the power outlet
properly.
Check t e h
fuse or circuit of your power supply, replace if
necessary.
The
ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
I is nt ormal that the freezer is not operating
during the
autom cycl aatic defrost e, or for short time after the appliance
i
itched on to
ects sw prot the compressor.
The
a
interior
m y need to be cleaned
Some food,
containers or
wrapping
cause odours.
The nds sou below are quite normal:
Com ressorp running noises.
Air movement no he
fan motor
in the freezer
ise from t small
compartment or
other compartments.
Gurgling sound similar to water boiling.
Popp noing ise during automatic defrosting.
Clicking noise before the compressor starts.
Other
unusual noises are due
to the a reasons below nd may
need you to
and
take action
check
:
The
net
cabi
not level.
The b
ck
a of appliance touches the wall.
Bottles co ainers falle or nt n or rolling.
The motor runs
cont nuousli y
I is
normal
to frequt ently hear the sound of the motor, it will
need run or to m e when in following circumstances:
Te e setting is set colder than necessary mperatur
Lar antity of warm food has recently been stored within ge qu
t e ah ppliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been swicthed off
for a long time.
Possible cause & Solution
●
●
●
●
●
●
●
●
●
●
App
correctly
liance is not working
Odours from the
compartments
15
Noise from the
appliance
checks according to this section before calling for service.
A layer of frost occurs in
the comp m t art en
Check
that the air outlets
ked and ensure are not bloc
by food
food is placed within the appliance to allow sufficient
ven attil ion. Ensure that door is fully closed. To remove the
forst
please refer to clean, ing and care chapter.
Temperature inside is
too w m ar
You may have left the doors open too long or too frequently; or
t doors arhe e kept open by some obstacle; or the appliance is
l th insuf e sides back d op.ocated wi ficient clearance at th , an t
Temperature inside is
too co ld
I ease thncr e temperature by following the "Display controls”
chapter.
Doors can’t be
closed
easily
Check
whether
the
top of the refrigerator is tilted back by
10-15 t all w the doors to self close, or if something inside mm o o
i rs prevening the doors f om closing.
Water drips on the floor
The ter pan located wa ( at the rear bottom of the cabinet) may
not b e properly leveled, or the draining spout （ located
underne h t op o depoat he t f the compressor t） not be
may
properly pos itioned to direct water into this pan, or the water
spout a a is blocked. You may need to pull the refrigerator
w
y
from the
al an an w l to check the p d spout.
The lig t is n or h ot w king
The
D light may be damage
R
er to replace LED l ght
LE d. ef i s
i cleaninn g and care chapter.
The system has disa du do control bled the lights e to the or
being kep t open too long, close and reopens the door to
reacti e the vat
lights.
●
●
16
Disposal of the appliance
17
