Programmable Timer
for NTE4T Series
Set current day and time
Enter “settings” menu Press bottom left button to select “set day/time” menu
The day function should be flashing.
1. Select day by pressing up or down arrow.
2. Press bottom left button to confirm day.
Now do the same to select and confirm hour and minute of current time.
NB: Time is in 24 hour format.
QUICK START GUIDE
This instruction manual will show you how to use the timer on the heater. If you do not want to
use the timer, please simply skip to the “Set current day and time” section to learn how to input
the time. You can control the thermostat with the up and down buttons and turn the heater on
and off with the switch on the side of the heater.
Timer Overview
The timer has two heat modes: one for
“day/peak” and one for “night/off peak”.
You can set a different temperature for
both of these periods, for example,
to keep the room warm during the
day while you are using it and then to
take the chill off the room when you
are sleeping.
The desired temperature for each heat
mode can be set to between 7°C and
30°C. Alternatively, you can just have the
heater turn off in either mode.
The icon in the bottom left of the screen
(either a sun or moon symbol) will denote
the current heat mode (either day/peak
or night/off-peak).
Sometimes, you may want to switch your current heat mode (from the default mode set for the current time) to the
non-current mode e.g. from day/peak to night/off-peak or vice versa.
You may want to do this to allow you to adjust the desired temperature/thermostat of the non-current mode.
Or you may want to apply the other heat mode at this current moment (e.g. you may want to turn up the temperature
temporarily without distorting the pre-programmed settings)
To manually switch heat modes (e.g. from night/off-peak to day/peak or vice versa), simply press the top left button
next to the picture of either the sun or the moon. That icon should now get highlighted with a black background and
the desired temperature in the display screen should also change (assuming the alternative heat mode has a different
temperature).
In the diagram shown, the desired temperature/thermostat has changed from 21 (set for day/peak mode) to 16 degrees
(set for night/off peak mode).
Press the same button again to go back to the default heat mode for the current time.
Note: for safety reasons, at 3am each day, if the heat mode has been manually overridden, the heater will automatically
switch back to the default heat mode for that time. Manual overrides will also end when a new timing setting starts.
To lock the timer (e.g. so children cannot change the settings), press and hold the two left buttons for one
second. A lock icon should show up on the right side of the display screen.
To unlock the timer, again press and hold the two left buttons for one second. The lock icon should disappear
and the regular settings should reappear on the display screen.
Manually Overriding Heat Modes
Heater on light
Key Lock
This light will illuminate when the
heating element is on.
Glen Dimplex Australia Pty Ltd
Unit 1, 21 Lionel Road
Mount Waverley VIC 3149
Ph: 1300 556 816 Fax: 1800 058 900
Email: [email protected]
www.nobo.com.au
Glen Dimplex New Zealand Ltd
38 Harris Road
East Tamaki, Auckland
Ph: 09 274 8265 Fax: 09 274 8472
Email: [email protected]
www.nobo.co.nz
Selects the function shown in the top right of
the display screen. In many menus, this button
will take you back to the previous screen.
Scroll down/decrease
Scroll up/increase
Desired
temperature
for current
heat mode
Press top left button to
manually override the
current heat mode –
see “Manual Override
Heat Mode” section
Current day
and time
Current heat
mode is
“day/peak”
Selects the function shown in the bottom right
of the display screen. In many menus, this
button will confirm your settings.
page 1
