User Manual LG GBB62PZGFN Kühl-Gefrierkombination 384 Liter Nutzinhalt FRESHBalancer™

1) Dismantling -> "French Door" model
- Take the shelves and the vegetable drawer out of the refrigerator.
- To release the jar above the vegetable compartment, place your hand under the compartment cover and lift it up. Observe the note on the cover.
- Hold the cover with one hand and lift the glass with the other hand.
- Lift up the entire vegetable compartment.
- Pull out the vegetable drawer a little, then lift up one side and take it out.

2) Disassembly / assembly -> Side-By-Side DIOS model
- Both doors should be fully open.
- Take the handle and pull it out.
- If this is not possible, lift it up slightly and then pull it out.
- Lift the cover slightly when assembling.
- Make sure that the compartment fits into the guide rails.
- Slightly lift the front part of the compartment and push it in completely.

1. Difficulties in assembling or disassembling the shelves
Dismantle the shelf - "French Door" model
- Remove all objects on the shelf.
- Lift the shelf slightly at the front and then pull it out with both hands.
Fitting the shelf - "French Door" model
- Hold the shelf tilted backwards at the desired height in the device.
- Hook the rear part into the device at the desired height and then lower the front of the shelf.
Dismantle the shelf - side-by-side refrigerator
Type 1
- Both doors should be wide open.
- Slightly lift the rear part of the shelf and pull on the shelf.
- If this is already half pulled out of the device, lift the front part of the shelf slightly and then pull the shelf out completely.
Type 2
- Both doors should be wide open.
- Grasp the front of the shelf and pull it until you feel resistance.
- As soon as this is in place, lift the front slightly and then pull the shelf out completely.
2. Difficulties in assembling or disassembling the bottle door compartment
1) Bottle door compartment -> dismantling
- Hold both sides of the tray, lift the front slightly, and then pull the tray out
2) Bottle door compartment -> assembly
- Hold both sides of the compartment and then press only one side down slightly at a time.
- Repeat this until the compartment is level in the holder.
3) Door compartment for dairy products -> dismantling
- Hold both sides, then lift the compartment and take it out of the door.
3. Difficulties in assembling or disassembling the "Magic Space"
Type1
- First remove the door compartment for dairy products, then lift up the cover of the home bar and take it out.
Type2
- Lift the cover of the house bar upwards and remove it.
