Instructions for installation
and use
Extractor hood
Loading ...
Loading ...
Loading ...
1
2
3
4
5
6
>
Summary of Contents for Bosch DWF97KQ60/02:
[en] Instructions for installation and use
1
Extractor hood
1
Table of contents
2
[en] Instructions for installation and use
2
Instruction manual
2
8 Intended use
2
Intended use
2
( Important safety information
3
Important safety information
3
: Warning
3
Danger of suffocation!
3
: Warning
3
Danger of death!
3
: Warning
3
Risk of fire!
3
: Warning
4
Risk of burns!
4
: Warning
4
Risk of injury!
4
: Warning
4
Risk of injury!
4
: Warning
4
Hazard due to magnetism!
4
: Warning
4
Risk of electric shock!
4
Causes of damage
4
Caution!
4
7 Environmental protection
5
Environmental protection
5
Saving energy
5
Environmentally-friendly disposal
5
Ç Operating modes
5
Operating modes
5
Exhaust air mode
5
Note:
5
Circulating-air mode
5
Note:
5
1 Operating the appliance
6
Operating the appliance
6
Note:
6
Control panel model 1
6
Symbol
6
Explanation
6
Setting the fan
6
Switching on
6
Selecting the fan setting
6
Switching off
6
Intensive setting
6
Switching on
6
Note:
6
Switching off
6
Intermediate position for the glass front
6
Fan run-on time
6
Switching on
6
Switching off
6
Lighting
6
Saturation display
7
Audible signal
7
Switching on
7
Switching off
7
Control panel model 2
8
Symbol
8
Explanation
8
Setting the fan
8
Switching on
8
Selecting the fan setting
8
Switching off
8
Intensive setting
8
Switching on
8
Note:
8
Switching off
8
Intermediate position for the glass front
8
Fan run-on time
8
Switching on
8
Switching off
8
Automatic mode
8
Switching on
8
1. Touch the # symbol.
8
2. Touch the > symbol.
8
Switching off
8
Sensor control
8
1. Touch and hold the > symbol when the fan is switched off. The setting will be displayed.
8
2. The sensor controller setting can be changed by touching symbols 1, 2, 3, C or D.
8
3. Take your finger off the > symbol.
8
Lighting
9
Saturation display
9
Audible signal
9
Switching on
9
Switching off
9
2 Cleaning and maintenance
9
Cleaning and maintenance
9
: Warning
9
Risk of burns!
9
: Warning
9
Risk of electric shock!
9
: Warning
9
Risk of electric shock!
9
: Warning
9
Risk of injury!
9
: Warning
9
Risk of injury!
9
Cleaning agents
9
Note:
9
Note:
9
Area
10
Cleaning products
10
Removing metal grease filter
10
1. Open the glass front slowly and fully. Hold the glass front in the centre when doing so, gripping it firmly.
10
2. Open the lock and swing down the metal grease filter. When you do this, take hold of the metal grease filter from underneath with your other hand.
10
3. Take the metal grease filter out of the holder.
10
Notes
10
Cleaning the metal mesh grease filters
10
: Warning
10
Risk of fire!
10
Notes
10
By hand:
10
Note:
10
In the dishwasher:
10
Note:
10
Installing the metal mesh grease filter
11
: Warning
11
Risk of injury!
11
Note:
11
1. Insert the metal grease filter and lock it in place. When you do this, take hold of the metal grease filter from underneath with your other hand.
11
Note:
11
2. If the metal grease filter has not been inserted correctly, open the lock and reinsert the metal grease filter correctly.
11
3 Trouble shooting
11
Trouble shooting
11
: Warning
11
Risk of electric shock!
11
Malfunction table
11
Problem
11
Possible cause
11
Solution
11
LED lights
11
: Warning
11
Risk of injury!
11
4 Customer service
12
Customer service
12
To book an engineer visit and product advice
12
Accessories
12
Note:
12
Note:
12
Accessories
12
Order number
12
Installation instructions
13
Note:
14
( Important safety information
14
Important safety information
14
: Warning
14
Risk of fire!
14
: Warning
15
Risk of death!
15
: Warning
15
Danger of death!
15
: Warning
15
Danger of death!
15
: Warning
15
Risk of injury!
15
: Warning
15
Hazard due to magnetism!
15
: Warning
16
Risk of electric shock!
16
: Warning
16
Risk of electric shock!
16
: Warning
16
Danger of suffocation!
16
K General information
16
General information
16
Checking the wall
16
Electrical connection
16
: Warning
16
Risk of electric shock!
16
: Warning
16
Risk of electric shock!
16
5 Installation
17
Installation
17
Preparing for installation
17
Caution!
17
1. Determine where the extractor hood should be positioned and lightly mark where the lower edge of the appliance should be on the wall. Determine where the middle should be based on the hob.
17
Note:
17
2. Place the template against the line drawn on the wall and fasten it in place. Mark where the screws should be inserted.
17
3. Drill 8 mm diameter holes to a depth of 80 mm for fastening the appliance, remove the template and press in the wall plugs flush with the wall.
17
Fitting with a flue duct
18
Fitting without a flue duct
18
Installation
18
Wall-mounting the appliance and levelling it
19
1. First remove the protective film from the back of the appliance and, following installation, remove the rest of the film.
19
2. When mounting the appliance, ensure that it engages properly with the mounting supports.
19
3. If required, the appliance can be moved to the right or to the left.
19
4. Firmly tighten the screws for the mounting supports. Hold the bracket firmly when doing so. ¨
19
5. If no duct is to be fitted, screw in the two locking screws without the bracket. ©
19
Connecting the pipes
19
Note:
19
Exhaust air pipe, dia. 120 mm
19
1. Fit the reducing connector directly to the air-pipe connector.
19
2. Attach the exhaust air pipe to the reducing connector.
19
3. Use suitable means to seal both joints.
19
Attaching the flue duct
19
: Warning
19
Risk of injury!
19
: Warning
19
Risk of electric shock!
19
1. Separate the flue duct sections by removing the adhesive tape.
19
2. Remove the pieces of protective film from both flue duct sections.
19
3. Push one flue duct section into the other.
19
Notes
19
4. Place flue ducts sections on the appliance.
19
5. Slide the inner flue duct section upwards, attach it to the left and right sides of the retaining bracket, and then slide it down to engage it. ¨
19
6. Screw the flue duct section to the sides of the retaining bracket using two screws. ©
19
7. Clip the lower flue duct section in at the retaining bracket. The connection cable must not be damaged. ª
19
Note:
19
File type: PDF
File name: 74565553_dwf97kq60-03.pdf
File size: 2.15 MB
File Language: English
Pages: 20
Author: Bosch
Published: 2020-05-11
Updated: 2023-08-16
Download File
