Refrigeration
02
Designed
specifically for
those that care
about preserving
the quality and
freshness of all
kinds of food.
Freshness
that brings
food to life
Mitsubishi Electric has been
an integral part of Australian
kitchens for more than 30 years,
providing high-quality, innovative
appliances that serve as fixtures
in this important space.
We pride ourselves on
understanding the Australian
household and delivering
products tailored to meet
their needs.
MITSUBISHI ELECTRIC
#worksforme
02
03
03
French Door
WX Series 743 Litres 6
627 Litres
500 Litres
EX Series 655 Litres 8
574 Litres
LX Series 630 Litres 10
L4 Series 710 Litres 12
650 Litres
Bottom Mount
CX Series 402 Litres 18
370 Litres
BF-EK Series 390 Litres 19
325 Litres
Top Mount
TF-EK Series 560 Litres 20
508 Litres
420 Litres
385 Litres
Refrigeration
Range
WX and EX
Series
Multi Drawer
PREMIUM DESIGN THAT
SAVES ON SPACE & ENERGY.
Smart Cube/VIP
Thanks to Vacuum Insulation
Panel Technology the WX and EX
series allow for maximum food
storage while maintaining a slim,
sleek profile.
(WX Series and EX Series)
04
Premium Quality
and Design
Unique LED Touch Screen
panels and luxury glass door
finish to compliment any
modern kitchen.
10 Year Compressor
Warranty
Mitsubishi Electric Inverter
refrigerators are backed by
a comprehensive 10 year
compressor and 5 year parts
and labour warranty.
3.5 Star Energy Rating
The higher the energy
rating, the lower the power
consumption costs will be
over time. (MR-WX743/MR-
WX627 and EX Series)
05
06
Bigger on the
inside without
compromising
space.
REFRIGERATOR
377/321/230 LITRES
ICE DRAWER
25/25/23 LITRES
VEGETABLE DRAWER
134/112/98 LITRES
FREEZER DRAWER
151/125/116 LITRES
VERSA DRAWER
56/44/33 LITRES
TOTAL CAPACITY
743/627/500 LITRES
MR-WX743 / MR-WX627 / MR-WX500 FEATURES
» Surround Multi Airflow System
(MR-WX743)
» Multi Airflow System
(MR-WX627/MR-WX500)
» LED Light
» Power Save Mode
» Temperature Sensors
» Auto Closer
» Smooth Case Roller
» Anti-Bacteria & Deodoriser
» 2 Adjustable Feet
» Frost Free
» Separable Shelf & Two-way
Flexi Glass Shelf
» Inverter Technology
» Wide Chilling Case
» Quick Ice Making
» Sliding Top Tray
» Supercool Chilling Case
» Neuro Fuzzy Logic
» Egg Tray
» Completely Washable
Ice Tray Parts
» VitaLED
» Multi Temperature Setting
» ECO Mode
» Constant Humidity Case
» Supercool Freezing
The MR-WX743 has an increased internal capacity with slim external dimensions, thanks to its
unique VIP (Vacuum Insulation Panel) and Smart Cube Technology. The luxury glass door finish
completes the modern design.
Available in 743, 627 and 500 litres catering for various kitchen sizes. The new
MR-WX500 is designed with a reduced height and width, to easily fit into a compact fridge
cavity of 660mm width.
WX Series
MULTI DRAWER
06
MR-WX743
H 1821 x W 800 x D 748mm
MR-WX627
H 1821 x W 685 x D 748mm
MR-WX500
H 1696 x W 650 x D 709mm
Dimensions
(MR-WX743 / MR-WX627)
07
» Soft Freezing
» Hot Freezing
» ECO Guide
» Bottle Pockets
» Aluminium Tray
» Door Alarm
» Adjustable Door Pockets
» External LED Touch Control Panel
MR-WX743
743 Litres
MR-WX500
500 Litres
MR-WX627
627 Litres
Dark
Mahogany*
Diamond
White
Argent
Silver*
07
Hot Freezing
The LED Sensor is
designed to detect hot
food and adjust the cold
air flow directly onto the
hot food. This saves time
while also preserving the
quality and freshness of
the food.
Soft Freezing
Soft Freezing allows food
to be frozen for up to three
weeks in a ‘soft’ state. This
means meat can be easily
cut without thawing.
Versa Drawer
The Versa Drawer offers
the ultimate functionality
in preserving food quality
without losing moisture and
taste. The Versa Drawer
has two main modes,
Supercool Freezing and
Hot Freezing.
Supercool Freezing
Ensures food is frozen evenly,
minimising cell destruction,
preserving its freshness,
texture and locking in
maximum flavour.
Please note these modes
must be manually set in order
to function.
Vegetable Drawer
VitaLED lighting system slows down
the wilting process, keeping fruit
and vegetables crisper and fresher
for longer. The vegetable drawer
features a tray at the top which is
ideal for storage and organisation of
smaller items such as fruit.
Automatic Ice Maker
As there is no separate plumbing
connection required, the fridge can
be placed anywhere. Simply fill the
removable water tank and the Ice
Maker is ready to go!
Two Way Flexi & Glass Shelf
This glass shelf slides back easily to
halve its size, allowing taller items to
be stored at the front of the refrigerator
compartment.
Supercool Chilling Case
The Supercool chilling function is
ideal for storing meat, fish, or other
perishable food without freezing it.
This provides the convenience of
food ready to cook without the need
to defrost it.
(MR-WX500)
*Please refer to specification table
Our Multi-Drawer refrigerators feature extremely efficient Inverter technology, a unique LED
Touch Control Panel and a large capacity with slim dimensions.
Super quiet at only 15 dBA and designed to keep food fresher for longer, these are the ultimate
entertainer’s fridge.
MR-EX655 / MR-EX574 FEATURES
» Advanced Surround Multi Airflow
» LED Compartment Light
» Power Save Mode
» 8 Temperature Sensors
» Auto Closer
» Versa Drawer
» Supercool Freezing
» Soft Freezing
» Hot Freezing
» Smooth Case Roller
» Anti-Bacteria & Deodoriser
» Elevating Shelf
» 2 Adjustable Feet
» Two-Way Flexi Shelves
» Frost Free
» Inverter Technology
» Sliding Chilled Case
» Quick Ice Making
» Sliding Top Tray
» Quiet Operation
» R600a Refrigerant
» Egg Tray
» Completely Washable
Ice Tray Parts
» VitaLED
» Multi Temperature Setting
» ECO Mode
» Constant Humidity Care
REFRIGERATOR
327/252 LITRES
TOTAL CAPACITY
655/574 LITRES
ICE DRAWER
26/27 LITRES
VEGETABLE DRAWER
116/129 LITRES
FREEZER DRAWER
131/118 LITRES
VERSA DRAWER
55/48 LITRES
EX Series
MULTI DRAWER
MR-EX655
H 1821 x W 745 x D 735
MR-EX574
H 1696 x W 685 x D 735
08
Dimensions
» ECO Guide
» Bottle Pockets
» Aluminium Tray
» Sliding Top Tray
» Door Alarm
» Adjustable Door Pockets
» External LED Touch Control Panel
MR-EX655
655 Litres
09
Platinum
Light
MR-EX574
574 Litres
Vegetable Drawer
VitaLED lighting system slows down
the wilting process, keeping fruit
& vegetables crisper and fresher
for longer. The vegetable drawer
features a tray at the top which is
ideal for storage and organisation of
smaller items such as fruit.
Automatic Ice Maker
As there is no separate plumbing
connection required, the fridge can
be placed anywhere. Simply fill the
removable water tank and the Ice
Maker is ready to go!
Elevating Shelf
Simply slide the lever and you can
raise or lower the bottom shelf by up
to 40mm. There is no need to remove
any items from the shelf... What could
be easier than that?
Freezer Drawer
The Freezer Drawer is roomy
enough to fit bulky items such
as ice cream tubs, loaves of
bread and frozen vegetables.
The top tray is ideal for storage
and organisation of flat pack items
such as meat packs.
MR-EX655
10
LX Series
FRENCH DOOR
MR-LX630 FEATURES
»
10
Dimensions
MR-LX630
H 1798 x W 900 x D 735mm
The first thing you notice about the MR-LX630 is its striking looks with toughened glass front
panels, presenting a luxurious finish. French doors open up to reveal 760 mm wide shelves.
Convenient features include separate vegetable and freezer drawers, an automatic ice maker
that doesn’t require plumbing and a Supercool chilling case for storing items at about -3°C to
0°C without freezing it.
REFRIGERATOR
333 LITRES
TOTAL CAPACITY
630 LITRES
VEGETABLE DRAWER
117 LITRES
FREEZER DRAWER
180 LITRES
» 4.0 Energy Rating
» Inverter Technology
» R600A Refrigerant
» Multi Air-flow System
» LED Light
» Tempered Glass Shelves
» Automatic Ice Maker
» Water Tank
» Vegetable Drawer
» Egg Tray
» Bottle Pocket
» Adjustable Pocket
» Wide Chilling Case
(upper case)
» Supercool Chilling Case
(lower case)
» VitaLED
» Smooth Case Roller
» Wide Open Case
» Anti-Bacterial & Deodoriser
» Neuro Fuzzy Technology
» Rapid Cooling
» Eco Mode
1111
MR-LX630
630 Litres
Brilliant
Black
Argent
Silver
Vegetable Drawers
Two big vegetable drawers to store
fruit and vegetables. A full-width
tray at the top is ideal for storage
and organisation of smaller and
delicate items such as punnets
of fruit.
Automatic Ice Maker
A continuous supply of ice cubes
is produced by the automatic
ice maker without the need for
a plumbing connection. The
removable water tank can be
easily filled with tap water.
Glass Door Finish
Toughened glass front panels
present a luxurious, striking finish
and are easy to keep clean.
Supercool Chilling Case
The Supercool chilling function is
ideal for storing meat, fish, or other
perishable food without freezing it.
This provides the convenience of
food ready to cook without the need
to defrost it.
» Power Saving Mode
» Door Alarm
» Glass Door
» Large Capacity
1212
The L4 Series is designed for
larger living. With an internal
width of 800mm, this refrigerator
provides you with maximum
storage capacity for grocery
types of any size, ensuring
you will never be caught short
of space.
L4 Series
FRENCH DOOR
800mm wide
1313
14
L4 Series
FRENCH DOOR
MR-L710 / MR-L650 FEATURES
» Twin Fan Multi Air Flow
» Frost Free
» Anti-Bacteria Food Liner
» Utility Case
» Ice Box
» Quiet Operation
» Vegetable Compartment
» Inverter Technology
» Revolving Ice Trays
» VitaLED in Humidity Case
» 2 Adjustable Feet
» Neuro Fuzzy Logic
» Egg Tray
» 4 Castors
» Child Lock
» Capsule Door Pocket
» Eco Mode
» Auto Closer
» Large Bottle Pockets
» Anti-Mould Gasket
» Door Alarm
» Adjustable Door Pockets
» Rapid Cooling
» Tempered Glass Shelves
» External LED Control Panel
» R600a Refrigerant
Stainless
Steel
Diamond
Black
MR-L710
710 Litres
MR-L650
650 Litres
Pearl
White
REFRIGERATOR
478/418 LITRES
FREEZER
232 LITRES
TOTAL CAPACITY
710/650 LITRES
The L4 series is designed for
larger living.
Available in two sizes 710 and 650
litres catering for various kitchen
sizes. The L4 Series features an
ergonomic four-door layout designed
to reflect the most frequently used
fridge spaces.
The L4 Mini (650L) is designed with
a reduced height, to easily fit into a
French door cavity with overhead
cupboards.
Dimensions
MR-L710
H 1820 x W 950 x D 805mm
MR-L650
H 1700 x W 950 x D 805mm
15
15
Providing more usable
space for items such
as bulky groceries
and platters.
16
16
L4 Series
MR-L710
FRENCH DOOR
17
17
LED Control Panel
Featuring four smart operation
modes - including Eco Mode,
an energy saving setting which
automatically adjusts the
temperature and Rapid Cooling
which cools quickly to preserve
the freshness of food.
Ergonomic and
User Friendly
Designed for frequent access,
the refrigeration compartment that
is accessed most commonly is
positioned at chest height. The
separate drawers are placed
conveniently from waist height
down, providing quick and
easy access.
Triple Twist Ice Trays
Release ice cubes from trays
with a simple twist action into
the collection box.
Vegetable Crisper
Designed to store fruit and
vegetables. Some require more
humidity than others, that is why
the humidity controls will help to
regulate the amount of moisture
in the crisper.
Twin Fan Multi
Airflow System
Twin ventilator fans blow and
circulate air at various levels
throughout the refrigerator and
freezer compartments. This allows
for even cooling distribution and
keeps food fresher for longer.
Large Bottle Pockets
The smart big bottle door pocket
is designed for convenient
storage and retrieval of large
and small bottles.
Large Capacity
With a large internal width of
800mm you have maximum
storage capacity and more usable
space for items such as bulky
groceries and large platters.
Tempered Glass Shelves
The Tempered Glass Shelves
are easy to clean, heat resistant
and built to withstand up to 101
kilograms of weight.
800mm
Designed for larger living
Bottom Mount
» LED Light
» Double Sliding Chilled Cases
» Egg Shelf (1 egg rack)
» Small Item Pocket
» 2-Way Flexi Glass Shelf
» Tempered Glass Shelf
» Fruit & Vegetable Drawer
» Door Alarm
» Auto Ice Maker
» Freezer Drawer
» Adjustable Feet
» Deodoriser Filter
» 3.5 Star Energy Rating
» R600a Refrigerant
» Inverter Technology
MR-CX402 / MR-CX370 FEATURES
Sliding Chilled Case
The Double Sliding Chilled Cases
allow for easy access and greater
storage. Ideal for separately
storing dairy products and
chilling drinks.
Automatic Ice Maker
As there is no separate plumbing
connection required, the fridge
can be placed anywhere. Simply
fill the removable water tank and
the Ice Maker is ready to go!
Vegetable Drawer
The drawer features a higher
humidity than the main
refrigerator compartment and
is ideal for storing and keeping
fruit and vegetables crisper and
fresher for longer.
FREEZER
104 LITRES
REFRIGERATOR
221/189 LITRES
VEGETABLE
DRAWER
77 LITRES
TOTAL CAPACITY
402/370 LITRES
MR-CX402
H 1820 x W 600 x D 660mm
MR-CX370
H 1698 x W 600 x D 660mm
MR-CX402
402 Litres
MR-CX370
370 Litres
Onyx
Black
Glossy
Red
*
White
Stainless
Steel
*Please refer to specification table
18
Dimensions
MR-CX402
CX SERIES
Bottom Mount
» Frost Free
» 2-Way Flexi Glass Shelf
» Door Alarm
» Anti-Bacteria Food Liner
» Tempered Glass Shelf
» Egg Shelf (1 egg rack)
» Titanium Filter
» Bottle Pocket & Bottle Dividers
» LED Light
» Revolving Ice Tray
» Freezer Drawer
» Adjustable Feet
» 3.0 Star Energy Rating
» R600a Refrigerant
» Inverter Technology
Freezer Drawer
It is roomy enough to fit bulky
items such as ice cream tubs,
loaves of bread and frozen
vegetables.
Ergonomic Design
The refrigeration compartment
that is accessed most commonly
is positioned at chest height.
The separate drawers are placed
conveniently from waist height
down, providing quick and
easy access.
2-Way Flexi Glass Shelf
Make the Tempered Glass shelf
deeper or push it in for more
space. It is ideal for storing
taller items such as a salad or
dessert bowl.
MR-BF390 / MR-BF325 FEATURES
MR-BF390
H 1720 x W 600 x D 696mm
MR-BF325
H 1479 x W 600 x D 696mm
MR-BF390
390 Litres
MR-BF325
325 Litres
Onyx
Black
White
Stainless
Steel
FREEZER
105 LITRES
REFRIGERATOR
285/220 LITRES
TOTAL CAPACITY
390/325 LITRES
19
Dimensions
MR-BF325
BF-EK SERIES
» Elevating Shelf (MR-560, MR-508)
» Tempered Glass Shelves
» Deodoriser
» Egg Shelf (2 egg racks)
» 2-Way Flexi Glass Shelf
(MR-560, MR-508)
» Surround Cooling System
(MR-420, MR-385)
» Adjustable Door Shelf
» Big Bottle Pockets & Stopper
» Anti-Bacteria Food Liner
» Revolving Ice Tray
» Frost Free
» Adjustable Feet
MR-560 / MR-508 / MR-420 / MR-385 FEATURES
REFRIGERATOR
382/330 LITRES
FREEZER
178 LITRES
TOTAL CAPACITY
560/508 LITRES
REFRIGERATOR
290/255 LITRES
FREEZER
130 LITRES
TOTAL CAPACITY
420/385 LITRES
MR-560
560 Litres
MR-508
508 Litres
MR-420
420 Litres
MR-385
385 Litres
Stainless
Steel
Shiny
Black
White
MR-560
H 1777 x W 751 x D 795mm
MR-508
H 1652 x W 751 x D 795mm
MR-420
H 1691 x W 686 x D 706mm
MR-385
H 1586 x W 686 x D 706mm
Top Mount
TF-EK SERIES
20
Dimensions
Dimensions
The smart elevating shelf function is a unique time and space saving feature, helping to
maximise the usable space in the refrigerator compartment. (MR-560/MR-508)
21
Elevating Shelf
Simply slide the lever and you
can raise or lower one of the
shelves by up to 40 mm. There is
no need to remove any items from
the shelf... what could be easier
than that!
(MR-560, MR-508)
Sliding Chilled Case
Equipped with a smooth-sliding
roller, the Sliding Chilled Case
allows for easy access. Great
for storing dairy products and
chilling drinks. Food is stored
at around 0°C, ensuring longer
lasting freshness.
Tempered Glass Shelves
The Tempered Glass Shelves
are easy to clean, heat resistant
and built to withstand up to 101
kilograms of weight.
» 4 Rollers
» LED Light
» 4.0 Star Energy Rating
» Multi Airflow System (MR-560, MR-508)
» R600a Refrigerant
MR-560
22
REFRIGERATOR
FRECH DOOR
WX Series EX Series LX Series L4 Series
MODEL
MR-WX743 MR-WX627 MR-WX500 MR-EX655 MR-EX574 MR-LX630 MR-L710 MR-L650
Capacity
(Gross)
TOTAL
743 627 500 655 574 630 710 650
Refrigerator Compartment
377 321 230 327 252 333 478 418
Freezer Compartment
151 125 116 131 118 180 232 232
Ice Making Compartment
25 25 23 26 27
Versa Compartment
56 44 33 55 48
Vegetable Compartment
134 112 98 116 129 117
Dimensions
(mm)
Width
800 685 650 745 685 900 950 950
Height
1821 1821 1696 1821 1696 1798 1820 1700
Max Depth
748 748 709 735 735 735 805 805
Clearance
Dimensions
(mm)
Top
100 100 25 100 25 100 100 100
Left
20 20 5 20 5 30 30 30
Right
20 20 5 20 5 30 30 30
Back
50 60 60
Energy Efficiency
Energy Star Rating
3.5 3.5 4.0 3.5 3.5 4.0 3.0 3.0
Energy Consumption (kWh/year)
475 415 345 425 410 390 540 508
Inverter Compressor
• • • • • • • •
Refrigerant Type
R600a R600a R600a R600a R600a R600a R600a R600a
Door Finish
Door Finish
ARGENT
SILVER
ARGENT
SILVER
PLATINUM
LIGHT
PLATINUM
LIGHT
ARGENT
SILVER
STAINLESS
STEEL
STAINLESS
STEEL
DARK
MAHOGANY
DARK
MAHOGANY
BRILLIANT
BLACK
DIAMOND
BLACK
DIAMOND
BLACK
DIAMOND
WHITE
DIAMOND
WHITE
DIAMOND
WHITE
PEARL
WHITE
PEARL
WHITE
Glass Door Finish • • • •
Refrigerator
Air Flow System
SURROUND MULTI MULTI SURROUND SURROUND MULTI TWIN TWIN
LED Light
• • • • • • • •
Moisturising Cooling
• • • • •
Elevating Shelf (Auto Shelf)
• •
Tempered Glass Shelves
• • • • • •
Separate Shelf (Middle Shelf)
• •
Two-Way Flexi Shelf (Middle Shelf)
• • • • •
Two-Way Flexi Shelf (Top Shelf)
• •
Side Take-Out Pocket
• • • • •
Utility Case
2 2 2 2
Wide Chilled Case (Upper Case)
• • • •
Supercool Chilling Case / Chilled Case
(Lower Case)
• • • •
Auto Closer
• • • • • • •
Water Tank
• • • • • •
Egg Tray
• • • SLIDING SLIDING • • •
Bottle Pocket
• • • • • • • •
Adjustable Pocket
• • • • • • • •
Vegetable Crisper
• •
Small Item Holder
• •
SPECIFICATIONS
22
23
WARRANTY:
Inverter Mitsubishi Electric refrigerators are backed by a comprehensive 10 year
compressor and 5 years parts and labour warranty.
Refrigerator are for illustration purposes only.
REFRIGERATOR
FRENCH DOOR
WX Series EX Series LX Series L4 Series
MODEL
MR-WX743 MR-WX627 MR-WX500 MR-EX655 MR-EX574 MR-LX630 MR-L710 MR-L650
Vegetable Drawer
Humidity Control
• • • • • • •
Smooth Case Roller
• • • • • •
Wide Open Case
• • • • •
Freezer Compartment
Freezing Case (Small)
• •
Freezing Case (Medium)
• •
Freezing Case (Large)
• •
Freezing Case (Upper and Lower)
• • • • • •
Ice-Making Compartment
Direct Water Supply Auto Ice Maker
• • • • •
Anti Bacteria Washable Ice Tray
• • • • •
All Washable Water Supply Parts
• • • • •
Quick Ice Making Mode
• • • • •
Required Time for Quick Ice Making (min)
80 80 80 65 70 80
Water Tank Capacity (L)
1.1 1.2 1.2 1.2 1.2 1.2
Versa Compartment
Supercool Freezing
• • • • •
Soft Freezing
• • • • •
Hot Freezing
• • • • •
Alminium Tray
• • • • •
Others
Fresh Air Filter (Anti-bacteria & Deodoriser)
• • • • • • • •
Smart Cube VIP
• • • • •
Rapid Cooling
• • • • • • • •
Eco Mode
• • • • • • • •
Power Save Mode
• • • • • • • •
Door Alarm
• • • • • • • •
Total Number of Sensors
16 15 16 16 16 8 8 8
SPECIFICATIONS
23
24
SPECIFICATIONS
WARRANTY:
Inverter Mitsubishi Electric refrigerators are backed by a comprehensive 10 year compressor and 5 years parts and labour warranty.
REFRIGERATOR
BOTTOM MOUNT
CX Series BF-EK Series
MODEL
MR-CX402 MR-CX370 MR-BF390 MR-BF325
Capacity (Gross)
TOTAL
402 370 390 325
Refrigerator Compartment
221 189 285 220
Freezer Compartment
104 104 105 105
Vegetable Compartment
77 77
Dimensions (mm)
Width
600 600 600 600
Height
1820 1698 1720 1479
Depth
656 656 686 686
Depth with Leg Cover
660 660 696 696
Clearance Dimensions (mm)
Top
100 100 100 100
Left
20 20 20 20
Right
20 20 20 20
Back
50 50 50 50
Energy Star Rating
3.5 3.5 3.0 3.0
Energy Consumption (kWh/year)
351 337 400 370
Inverter Compressor
• • • •
Cooling System
MULTI AIRFLOW
Frost Free
• • • •
Anti-Bacteria Food Liner
• •
Deodoriser
FILTER FILTER TITANIUM FILTER TITANIUM FILTER
Minus Ion
• • • •
VitaLED*
• • • •
Door Alarm
• • • •
Refrigerator Compartment
Slide Chilled Case
2 2
Two-Way Flexi Shelf
1 1 1 1
Tempered Glass Shelf (R)
3 2 4 3
Egg Case
1 1 1 1
Multi-Free Pocket
2 2 2 2
LED Light
LED Light
Fruit & Vegetable Case
1 1
Bottle Pocket
1 1 2 1
Bottle Stopper
1 1
Freezer Compartment
Auto Ice Making
• •
Revolving Ice Tray
2 2
Ice Box
1 1 1 1
Aluminium Tray
1 1
Freezer Case Lower
1 1 1 1
Freezer Case Upper & Ice Box
1 1
Ice Spoon
1 1
Vegetable Drawer
Vegetable Case (Upper & Lower)
1 1
Others
Castors
4 4 4 4
Kick Plate
• • • •
Adjustable Foot
2 2 2 2
Refrigerant Type
R600a R600a R600a R600a
Door Finish
WHITE WHITE WHITE WHITE
STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL
ONYX BLACK ONYX BLACK ONYX BLACK ONYX BLACK
GLOSSY RED
Door Opening
Right Right Right Right
25
WARRANTY:
Inverter Mitsubishi Electric refrigerators are backed by a comprehensive 10 year compressor and 5 years parts and labour warranty.
SPECIFICATIONS
REFRIGERATOR
TOP MOUNT
TF-EK Series
MODEL
MR-560 MR-508 MR-420 MR-385
Capacity (Gross)
TOTAL
560 508 420 385
Refrigerator Compartment
382 330 290 255
Freezer Compartment
178 178 130 130
Dimensions (mm)
Width
751 751 686 686
Height
1777 1652 1691 1586
Depth
795 795 706 706
Clearance Dimensions (mm)
Top
100 100 100 100
Left
20 20 20 20
Right
20 20 20 20
Back
50 50 50 50
Energy Star Rating
4.0 4.0 4.0 4.0
Energy Consumption (kWh/year)
350 340 326 310
Inverter Compressor
• • • •
Refrigerant Type
R600a R600a R600a R600a
Cooling System
MULTI AIRFLOW SURROUND COOLING
Frost Free
• • • •
Anti-Bacteria Food Liner
• • • •
Deodoriser
FILTER FILTER FILTER FILTER
Minus Ion
• •
Refrigerator Compartment
Slide Chilled Case
1 1 1 1
Tempered Glass Shelf (R)
1 - 3 3
Tempered Glass Shelf (RV)
1 1
Elevating Shelf
1 1
Flexible Shelf
1 1
Egg Case
2 2 2 2
Multi-Free Pocket
3 2 1 1
LED Light
• • • •
Fruit & Vegetable Case
1 1 1 1
Bottle Pocket
2 2 2 2
Bottle Stopper
2 2 1 1
Freezer Compartment
Revolving Ice Tray
3 3 2 2
Ice Box
1 1 1 1
Freezer Pocket
2 2 2 2
Crystal Shelf
2 2 1 1
Others
Castors
4 4 4 4
Kick Plate
• • • •
Adjustable Foot
2 2 2 2
Door Finish
WHITE WHITE WHITE WHITE
STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL
SHINY BLACK SHINY BLACK SHINY BLACK SHINY BLACK
Door Opening Right Right Right Right
26
ME Fridge Finder
Want to see how these fridges
will look in your kitchen?
27
NOTES
The illustrations, specifications, design and other contents appearing in this publication are described as at the date of printing. Product
design and specifications may change without notice. Images are representational for illustration purposes. PRINTED: SEPTEMBER 2017
For more information contact
www.mitsubishielectric.com.au
Call 1300 722 228
Distributed and guaranteed throughout Australia by
MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.
(Incorporated in New South Wales) A.B.N. 58 001 215 792
Fridge Finder App
Available to download
from the App Store
See website for full Terms
and Conditions
