Installation and Operating Guide | Warranty
Model Number | DVP615 | Portable DVD Player
© Copyright 2007, LG Electronics U.S.A., Inc.
For service/
support Call:
Toll Free Number
1-800-243-0000
This lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsu-
lated dangerous voltage within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompa-
nying the product.
WARNING: Do not install this equipment in a confined space such as a
bookcase or similar unit.
CAUTION:
Do not block any ventilation openings. Install in accordance with the manu-
facturer's instructions.
Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from overheating.
The openings should never be blocked by placing the product on a bed,
sofa, rug or other similar surface.This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer's instruction have been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read this owner’s manual
carefully and retain it for future reference. Should the unit require mainte-
nance, contact an authorized service center.
Performing controls, adjustments, or carrying out procedures other than
those specified herein may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible laser radiation when open. DO NOT STARE INTO BEAM.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids, such as vases,
should be placed on the apparatus.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
NOTES ON COPYRIGHTS:
It is forbidden by law to copy, broadcast, show, broadcast via cable, play in
public, or rent copyrighted material without permission.
This product features the copy protection function developed by
Macrovision. Copy protection signals are recorded on some discs. When
recording and playing the pictures of these discs on a VCR, picture noise
will appear.
This product incorporates copyright protection technology that is protected
by method claims of certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
Safety Precautions
2
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a dedicated
circuit;
That is, a single outlet circuit which powers only that appliance and
has no additional outlets or branch circuits. Check the specification
page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or dam-
aged wall outlets, extension cords, frayed power cords, or damaged
or cracked wire insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically examine the cord of
your appliance, and if its appearance indicates damage or deteriora-
tion, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and the point where the
cord exits the appliance.
To disconnect power from the mains, pull out the mains cord plug.
When installing the product, ensure that the plug is easily accessible.
FCC WARNING: This equipment may generate or use radio frequency
energy. Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the instruc-
tion manual. The user could lose the authority to operate this equipment if
an unauthorized change or modification is made.
REGULATORY INFORMATION: FCC Part 15
This epuipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the product is operated in a residential installation. This product gen-
erates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this product does
cause harmful interference to radio or television reception, which can be
determined by turning the product off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and receiver.
• Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC COMPLIANCE: The responsible party for this product’s compliance is:
LG Electronics U.S.A., Inc.,
1000 Sylvan Avenue, Englewood Cliffs, NJ.
Phone: 1-201-816-2000.
Safety Precautions (Continued)
3
Introduction
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND
INSTRUCTIONS IN THIS OWNER’S MANUAL. AND THOSE
MARKED ON THE PRODUCT. RETAIN THIS BOOKLET
FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal
safety. Improper use can result in electric shock or fire hazard. The safe-
guards incorporated in this product will protect you if you observe the fol-
lowing procedures for installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED
TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SER-
VICE PERSONNEL ONLY.
1. Read these instructions. - All these safety and operating instructions
should be read before the product is operated.
2. Keep these instructions. - The safety, operating and use instructions
should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in the operating
instructions should be adhered to.
4. Follow all instructions. - All operating and use instructions should be
followed.
5. Do not use this apparatus near water. – For example: near a bath tub,
wash bowl, kitchen sink, laundry tub, in a wet basement; or near a swim-
ming pool; and other areas located near water.
6. Clean only with dry cloth. – Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners.
7.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions. -
Slots and openings in the cabinet are pro-
vided for ventilation and to ensure reliable operation of the product and
to protect it from over- heating. The openings should never be blocked by
placing the product on a bed, sofa, rug or other similar surface. This prod-
uct should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s instruc-
tions have been adhered to.
8. Do not install near any heat sources such as radiators, heat regis-
ters, stoves, or other apparatus (including amplifiers) that produce
heat.
9. D
o not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the other.
A grounding
type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
IMPORTANT SAFETY INSTRUCTIONS
4
10. Protect the power cord from being walked on or pinched particu-
larly at plugs, convenience receptacles, and the point where they
exit from the product.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with apparatus. When a cart is used, use
caution when moving the cart/product combination to avoid injury
from tip-over.
13. Unplug this product during lightning storms or when unused for
long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is
required when the product has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the product, the product has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
IMPORTANT SAFETY INSTRUCTIONS
5
Introduction
Introduction
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
About the Symbol Display . . . . . . . . . . . . . . . . . . . . . . . .7
Symbol used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . .7
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Types of Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Identification of Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-12
Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
Preparation
Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-16
AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Automotive Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-16
Audio/video Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17-18
Rotate the LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-25
On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
LOCK (Parental Control) . . . . . . . . . . . . . . . . . . . . . . . . .23-24
OTHERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Operation
General Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-28
Resume Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Moving to another TITLE . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Moving to another CHAPTER/TRACK . . . . . . . . . . . . . . . . . .26
Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Changing the Audio Language . . . . . . . . . . . . . . . . . . . . . . . .26
Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Still Picture and Frame-by-Frame Playback . . . . . . . . . . . . . .27
Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Marker Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Last Scene Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Playing an Audio CD and MP3/WMA Disc . . . . . . . . . . . . . . . . . .29
Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Erasing a Track from program list . . . . . . . . . . . . . . . . . . . . .30
Viewing a JPEG disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Using this DVD Player you can view discs
with JPEG files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Moving to another File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
To rotate picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Still Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
JPEG disc compatibility with this player is
limited as follows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Reference
Maintenance and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Language Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Area Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Table of Contents
6
To ensure proper use of this product, please read this owner’s
manual carefully and retain for future reference.
This manual provides information on the operation and mainte-
nance of your DVD player. Should the unit require service, contact
an authorized service location.
About the Symbol Display
“ ” may appear on your LCD display during operation and indi-
cates that the function explained in this owner’s manual is not
available on that specific Disc.
Symbol Used in this Manual
Note
Indicates special notes and operating features.
Tip
Indicates tips and hints for making the task easier.
A section whose title has one of the following symbols is applica-
ble only to the disc represented by the symbol.
DVD discs
Audio CDs
MP3 discs
WMA discs
Notes on Discs
Handling Discs
Do not touch the playback side of the disc. Hold the disc by the
edges so that fingerprints do not get on the surface. Never stick
paper or tape on the disc.
Storing Discs
After playing, store the disc in its case. Do not expose the disc to
direct sunlight or sources of heat and never leave it in a parked
car exposed to direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality
and sound distortion. Before playing, clean the disc with a clean
cloth. Wipe the disc from the center out.
Do not use strong solvents such as alcohol, benzine, thinner, com-
mercially available cleaners, or anti-static spray intended for older
vinyl records.
WMA
MP3
ACD
DVD
Before Use
7
Introduction
Before Use
8
Types of Playable Discs
DVD
(8 cm / 12 cm disc)
Audio CD
(8 cm / 12 cm disc)
In addition, this unit plays DVD±R/RW and CD-R/RW that contains
audio titles, MP3, WMA, and/or JPEG files.
Notes
•
Depending on the conditions of the recording equipment or the CD-
R/RW (or DVD±R/±RW) disc itself, some CD-R/RW (or
DVD±R/±RW) discs cannot be played on the unit.
• Do not attach any seal or label to either side (the labeled side or
the recorded side) of a disc.
•
Do not use irregularly shaped CDs (e.g., heart-shaped
or octagonal). It may result in malfunctions.
Regional Code
This unit has a regional code printed on the bottom of the unit.
This unit can play only DVD discs labelled same as the bottom of
the unit or “ALL”.
Notes on Regional Codes
• Most DVD discs have a globe with one or more numbers in it
clearly visible on the cover. This number must match your unit’s
regional code or the disc cannot play.
• If you try to play a DVD with a different regional code from your
player, the message “Check Regional Code” appears on the TV
screen.
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic” and the double-D
symbol are trademarks of Dolby Laboratories.
DTS and DTS Digital Out are trademarks of Digital
Theater Systems, Inc.
Identification of Controls
9
a LCD screen
b Speaker
c Power : Switches the player ON or OFF.
d DISPLAY : Accesses On-Screen display.
e Menu Control Buttons
• b B v V (left/right/up/down)
Selects an item in the menu.
• b B : Adjusts the COLOR/BRIGHT.
• ENTER : Confirms menu selection.
f Function Buttons
• MENU : Accesses menu on a DVD disc.
• TITLE : Displays title menu, if available.
• LCD MODE : NORMAL
→
4:3
→
OFF
• ANGLE : Selects a DVD camera angle, if available.
• COLOR/BRIGHT : Selects the mode of LCD adjustment
Brightness
→
Color
→
OFF
• SETUP : Accesses or removes setup menu.
g Disc Lid
h OPEN button : Push this button to open the Disc lid.
Note
Place a disc with the playback side down on the spindle, and push
gently on the center of the disc so it goes into position.
P
U
S
H
C
L
O
S
E
ENTER
a
b
c
d
e
f
g
h
Main Unit
Introduction
a Volume Control
b Earphones jacks
c COAXIAL jack
d VIDEO/AUDIO Out jack
e DC 9.5V IN
Connect the AC adapter or Automotive adapter.
f Remote sensor
Receive the signal from the Remote Control for operation.
g Battery charge indicator
Light turns red when the battery is in charging; turns green
when the battery is fully charged.
h Playback buttons
• PLAY ( B/X ): Starts playback/ Pauses playback temporarily.
• STOP ( x ) : Stops playback.
• Reverse SKIP/SEARCH ( .)
Search backward*/ go to beginning of current chapter or
track or go to previous chapter or track.
• Forward SKIP/SEARCH ( >)
Search forward*/ go to next chapter or track.
* Press and hold button for about two seconds.
Main Unit
Identification of Controls (Continued)
10
a b c d e
f g h
11
Introduction
Identification of Controls (Continued)
a
POWER
Switches DVD Player ON or OFF.
AUDIO
Selects an audio language (DVD).
SUBTITLE
Selects a subtitle language.
A-B
Repeat sequence.
Reverse SKIP/SEARCH ( . )
Search backward*/ go to beginning of
current chapter or track or go to previous
chapter or track.
Forward SKIP/SEARCH ( >)
Search forward*/ go to next chapter or track.
* Press and hold button for about two
seconds.
SLOW ( t/T)
Reverse/ Forward slow playback.
PLAY
Starts playback.
PAUSE
Pauses playback temporarily/ press repeated-
ly for frame-by-frame playback.
STOP ( x )
Stops playback.
ZOOM
Enlarges video image.
b
MENU
Accesses menu on a DVD disc.
DISPLAY
Accesses On-Screen display.
b B v V (left/right/up/down)
Selects an item in the menu.
ENTER
Confirms menu selection.
SETUP
Accesses or removes setup menu.
TITLE
Displays title menu, if available.
MARKER/SEARCH
Marks any point during playback.
Displays MARKER SEARCH menu.
REPEAT
Repeat chapter, track, title all.
RETURN
Removes the setup menu.
c
PROG.
Places a track on the program list.
CLEAR
Removes a track number on the
program list or a mark on the
MARKER SEARCH menu.
0-9 number buttons
Selects numbered items in a menu.
PLAY
POWER
STOP
SKIP/SEARCH
MARKER
SEARCH
1 2
3
4
5
6
7
8 9
0
RETURN
PROG
TITLEMENU
CLEAR
AUDIO
SUBTITLE
REPEAT
A-B
ZOOM
SLOW
PAUSE
ENTER
SETUP
DISPLAY
Remote Control
a
b
c
Insert the battery (Lithium battery)
Notes
• Do not expose the Remote Control sensor to bright light.
• Do not place obstacles between the Remote Control sensor and
the Remote Control.
V
Replacing the button-type battery
The battery normally lasts for about a year. Replace the battery if
the Remote Control fails to operate the unit when used within the
operation range.
Button-type battery (Lithium battery)
1. Pinch the battery holder clip together then pull the tab to
remove the battery holder.
2. Insert the battery with the + facing in the same direction as the
+ on the battery holder.
3. Replace the battery holder with battery into the Remote Control
unit making sure that it is fully inserted.
• Replace Remote Control unit battery with 3V micro lithium cells
such as CR. 2025 or its equivalent.
• Dispose of battery safely in accordance with local laws. Do not
dispose of in fire.
Warning: The battery used in this device may present a fire or
chemical burn hazard if mistreated. Do not recharge,
disassemble, incinerate, or heat above 100 °C (212
°F).Replace the battery with Matsushita Elec. Ind. Co.,
Ltd. (Panasonic), part no. CR. 2025 only.
Use of another battery may present a risk of fire or
explosion. Dispose of used batteries. Keep batteries
away from children. Do not disassemble or dispose of
in fire.
Identification of Controls (Continued)
12
13
Preparation
Power Connection
Connect the AC adapter.
a Connect the AC Adapter to the DC IN jack on the unit.
b Connect the AC adapter to the wall outlet.
Caution
• Do not connect the power plug to a power outlet other than
that indicated on the label, as this can result in a risk of fire or
electric shock.
• Do not connect or disconnect the power plug with wet hands.
Doing so may cause electric shock.
• Do not use an AC adapter other than one specified, as it can
cause a fire or damage to the player.
AC adapter
• This AC adapter operates on 100-120V~ 27W 50-60Hz.
• Contact an electrical parts distributor for assistance in selecting
a suitable AC plug adapter or AC cord set.
• Manufactured by WANLIDA GROUP Co., Ltd.
a
b
Connect the Automotive adapter
This DVD player and its automotive adapter are designed for use
in vehicles that have 12 volt, negative ground electrical systems.
(This is standard for most vehicles.) If your vehicle has a different
type of electrical system, the DC power system cannot be used.
a Connect the automotive adapter to the DC IN jack on
the unit.
b Connect the automotive adapter to the car’s cigarette lighter
socket.
Caution
• To prevent electrical shock and possible damage to your DVD
player or vehicle, always unplug the automotive adapter from
the cigarette lighter socket before you remove the plug from
your DVD player.
• A 3 amp. 250V fuse for protection is installed in the
automotive adapter.
• While the engine is being started, disconnect the
automotive adapter from the car’s cigarette lighter socket.
•
Do not operate your DVD player when the car battery is
discharged. Peak current from the car generator may cause the
DC fuse to blow.
• If the vehicle’s supply voltage drops below approximately 10
volts, your DVD player may not work properly.
• Do not leave your DVD player in a place where the
temperature exceeds 70°C (158°F), or the pick-up device
may be damaged.
Examples include:
- Inside a car with the windows closed and in direct
sunshine.
- Near a heating appliance.
Automotive adapter
• This automotive adapter operates on DC 12V.
• Contact an electrical parts distributor for assistance in select-
ing a suitable automotive adapter.
• Manufactured by WANLIDA GROUP Co., Ltd.
Power Connection (Continued)
14
Cigarette lighter socket
a
b
15
Preparation
Power Connection (Continued)
Battery Pack
Charge the battery pack before using it for the first time.
A
Attaching the battery pack (supplied)
1. Match the hooks of the battery pack into the holes on the
bottom of the player.
2. Press and slide the battery pack until the hooks click.
Notes
• Do not detach the battery pack during playback.
• Be careful not to drop the battery pack.
A
Detaching the battery pack
1. Press the PUSH knob.
2. Pull the battery pack until the hooks click.
ATTENTION
The product that you have purchased contains a rechargeable battery. The battery is
recyclable. At the end of it’s useful life, under various state and local laws, it may be illegal to
dispose of this battery into the municipal waste stream. Check with your local solid waste/offi-
cials for details in your area for recycling options or proper disposal.
1
2
Hooks
1
2
A
Charging the battery pack
1. Attach the battery pack to the player.
2. Connect the AC adapter to the player and then plug into an AC
outlet.
When charging starts, the charge indicator lights up in red.
3. When recharging is complete, the indicator turns up in green.
4.
Disconnect the AC adapter from the player and pull out the plug
from the AC outlet after charging.
A
If there is not enough battery,
“ ”
flashes on the LCD
screen
A
Recharging and play times
* When Brightness control is set to minimum.
- using the headphones.
- at room temperature (25°C)
Notes
• Recharging times shown above depend on operating
conditions.
• When the power is ON, you cannot charge the battery.
• Charge the battery at a temperature of +5°C (+41°F) to +35°C
(+95°F).
The charging time may vary, depending on the surrounding
temperature.
• The battery will not be charged when it is naturally or pur-
posely discharged. Because the unit cannot perceive battery
voltage, even if you attached the battery.
When you are in this situation, power on the unit and then
power off again. Then battery charging will proceed.
Player
Connect the AC adapter
cord
Recharging Play time (DVD-VIDEO)
without Playback LCD On
Approx. Approx.
2.5 hours 3 hours*
Charge indicator
Battery Pack
Power Connection (Continued)
16
17
Preparation
Audio/Video Connection
The picture and sound of a nearby TV, VCR, or radio may be
distorted during playback. If this occurs, position the player away
from the TV, VCR, or radio, or turn off the unit after removing the
disc.
AV output Connections
Depending on your TV and other equipment there are various
ways you can connect the unit. Please refer to the manuals of
your TV, stereo system or other devices as necessary for
additional connection information.
AV output Connections to Your TV
1. Connect the black end of supplied AV cable to the AV OUT jack
on the unit.
2. Connect the yellow end of supplied AV cable to the VIDEO
Input jack on your TV.
3. Connect the red and white ends of supplied AV cable to the
AUDIO Input jacks on your TV.
NOTE
Make sure the DVD player is connected directly to the TV and not
to a VCR, otherwise the DVD image could be distorted by the
copy protection system.
Audio/Video cable
(Supplied)
Rear of TV
Right side of unit
Audio Connection to Optional Equipment
Connect the DVD player to your optional equipment for audio
output.
Amplifier equipped with 2-channel analog stereo or Dolby Pro
Logic ll / Pro Logic: Connect the AV OUT jacks on the DVD
player to the audio left and right IN jacks on your amplifier,
receiver, or stereo system, using the audio cables.
Amplifier equipped with 2-channel digital stereo (PCM) or
audio / video receiver equipped with a multi-channel decoder
(Dolby Digital™, MPEG 2, or DTS): Connect one of the unit
Coaxial jack to the corresponding in jack on youramplifier. Use an
optional digital audio cable.
Digital Multi-channel sound
A digital multi-channel connection provides the best sound quality.
For this you need a multi-channel audio / video receiver that
supports one or more of the audio formats supported by your DVD
player such as MPEG 2, Dolby Digital and DTS. Check the
receiver manual and the logos on the front of the receiver.
Notes
•
If the audio format of the digital output does not match the
capabilities of your receiver, the receiver produces a strong,
distorted sound or no sound at all.
• Six Channel Digital Surround Sound via a digital connection can
only be obtained if your receiver is equipped with a Digital
Multi-channel decoder.
• To see the audio format of the current DVD in the on-screen
display, press AUDIO.
R
L
AUDIO INPUT
DIGITAL INPUT
COAXIAL
Audio/Video Connection
18
Coaxial cable
(Not supplied)
Audio/ Video
cable (Supplied)
and/or
Amplifier(Receiver)
Right side of unit
You can rotate the LCD clockwise 180 degrees, however,
if you turn it by force, it can cause serious damage.
Rotating the LCD
19
Preparation
M
E
N
U
O
P
E
N
P
U
S
H
C
L
O
S
E
T
I
T
L
E
A
N
G
L
E
L
C
D
M
O
D
E
C
O
L
O
R
/
B
R
I
G
H
T
E
N
T
E
R
D
I
S
P
L
A
Y
P
O
W
E
R
S
E
T
U
P
MENU
OPEN
P
U
S
H
C
L
O
S
E
DISPLA
LCD MODE
COLOR/BRIGHT
ENTER
A/V IN/OUT
POWER
After rotating LCD completely, you can fold the LCD screen as
shown above.
20
Initial Settings
On-Screen Display
Some items can be changed using the menu.
1. Press DISPLAY during playback.
2. Press
b /B
to select an item.
The selected item is highlighted.
3. Press
v / V
to change the setting.
Press ENTER.
You can also use the number buttons if appropriate
(e.g. inputting the title number).
: Title(Track) Number, : Time search
: Chapter Number (DVD disc only)
Note
If no button is pressed for a few seconds, the on-screen display
disappears.
By using the Setup menu, you can make various adjustments to
items such as picture and sound. You can also set a language for
the subtitles and the Setup menu, among other things. For details
on each Setup menu item, see pages 21 to 25.
To display and exit the Menu:
Press SETUP to display the menu. A second press of SETUP will
take you back to initial screen.
To go to the next level:
Press
B
on the Remote Control.
To go back to the previous level:
Press
b
on the Remote Control.
General Operation
1. Press SETUP. The Setup menu appears.
2. Use
b / B
to select the desired option then press
V
or ENTER
to move to the second level. The screen shows the current set-
ting for the selected item, as well as alternate setting(s).
3. Use
v / V
to select the second desired option then press
B
to
move to the third level.
4.
Use
v / V
to select the desired setting then press ENTER to
confirm your selection. Some items require additional steps.
5. Press SETUP, RETURN or PLAY to exit the Setup menu.
DVD
Menu Language English
Original
Off
Original
Disc Audio
Disc Subtitle
Disc Menu
Move Select Exit
LANGUAGE
LANGUAGE
Menu Language
Select a language for the Setup menu and on-screen display.
Disc Audio / Subtitle / Menu
Select the language you prefer for the audio track (disc audio),
subtitles, and the disc menu.
Original: Refers to the original language in which the disc
was recorded.
Other: To select another language, press numeric buttons and
then ENTER to enter the corresponding 4-digit number
according to the language code list on the page 33. If you
enter the wrong language code, press CLEAR.
Off (for Disc Subtitle) – Turn off Subtitle.
DISPLAY
TV Aspect
4:3:
Select when a standard 4:3 TV is connected.
16:9: Select when a 16:9 wide TV is connected.
Note
If the TV Aspect option is set to 16:9, the Display Mode setting is
automatically set to Widescreen.
Display Mode
Display Mode setting works only when the TV Aspect mode is set
to “4:3”.
LetterBox: Displays a wide picture with bands on the upper
and lower portions of the screen.
Panscan:
Automatically displays the wide picture on the entire
screen and cuts off the portions that do not fit.
TV Aspect 16:9
Widescreen
Display Mode
DISPLAY
Move Select Exit
Initial Settings (Continued)
21
Preparation
22
Initial Settings (Continued)
AUDIO
Each DVD disc has a variety of audio output options. Set the
player’s AUDIO options according to the type of audio system you
use.
Dolby Digital / DTS / MPEG
Bitstream: Select “Bitstream” if you connect the DVD Player’s
DIGITAL OUT jack to an amplifier or other equipment with a
Dolby Digital, DTS or MPEG decoder.
PCM (for Dolby Digital / MPEG): Select when connected to a
two-channel digital stereo amplifier. DVDs encoded in Dolby
Digital or MPEG will be automatically downmixed to two-chan-
nel PCM audio.
Off (for DTS): If you select “Off”, the DTS signal is not
output through the DIGITAL OUT jack.
Sample Freq. (Frequency)
If your receiver or amplifier is NOT capable of handling 96 KHz
signals, select 48 KHz. When this choice is made, this unit
automatically converts any 96 KHz signals to 48 KHz so your
system can decode them.
If your receiver or amplifier is capable of handling 96 KHz signals,
select 96 KHz. When this choice is made, this unit
passes each type of signal through without any further
processing.
Check the documentation for your amplifier to verify its
capabilities.
DRC (Dynamic Range Control)
With the DVD format, you can hear a program’s soundtrack in the
most accurate and realistic presentation possible, thanks to digital
audio technology. However, you may wish to compress the
dynamic range of the audio output (the difference between the
loudest sounds and the quietest ones). This allows you to listen to
a movie at a lower volume without losing clarity of sound. Set
DRC to On for this effect.
Dolby Digital Bitstream
Bitstream
PCM
Off
48KHz
DTS
MPEG
DRC
Sample Freq.
AUDIO
Move Select Exit
LOCK (Parental Control)
Rating
Blocks playback of rated DVDs based on their content. Not all
discs are rated.
1. Select Rating on the LOCK menu then press
B
.
2. Select a rating from 1 to 8 using the
v / V
buttons and press . The
password widow will appear.
Rating 1-8: Rating one (1) has the most restrictions and rating
eight (8) is the least restrictive.
Unlock: If you select unlock, parental control is not active and the
disc plays in full.
Note
If you set a rating for the player, all disc scenes with the same rating or
lower are played. Higher rated scenes are not played unless an alter-
nate scene is available on the disc. The alternative must have the
same rating or a lower one. If no suitable alternative is found, playback
stops.
You must enter the 4-digit password or change the rating level in
order to play the disc.
3. If you have not entered password yet:
When the “New Password” section is highlighted, enter a
4-digit password using the numbered buttons then press ENTER.
Enter the 4-digit password again to verify when the “Confirm
Password” section is highlighted. The “OK” will be highlighted.
If you have entered password already:
Enter a 4-digit password you have entered using the numbered
buttons. The “OK” will be highlighted.
4. Press ENTER to confirm your rating selection, then press SETUP
to exit the menu.
Tip
s
• If you make a mistake before pressing ENTER in each section,
press CLEAR to enter again or b repeatedly to delete password
numbers one by one then correct it.
• If you enter the wrong password, you can not proceed to the
next step.
Rating Unlock
U S
Password NEW
Area code
LOCK
Move Select Exit
Initial Settings (Continued)
23
Preparation
24
Initial Settings (Continued)
Password
You can create or change password.
1. Select Password on the LOCK menu then press B. The
“Change” is highlighted
2. Press ENTER then the password window will appear.
3. To make a new password:
When the “New Password” section is highlighted, enter a
4-digit password using the numbered buttons then press
ENTER. Enter the 4-digit password again to verify when the
“Confirm Password” section is highlighted, then the “OK” will be
highlighted.
To change the password:
When the “Old Password” section is highlighted, enter the
4-digit password you have created then press ENTER.
The“New Password” section will be highlighted. Enter a new
4-digit password using the numbered buttons then press
ENTER. Enter the new 4-digit password again to verify when
the “Confirm Password” section is highlighted, then the “OK”
will be highlighted.
4. Press SETUP to exit the menu.
If you forget your password
If you forget your password you can clear it using the following
steps:
1. Remove any disc from the unit and close the disc tray.
2. Press SETUP and setup menu appears on the TV screen.
Use the numbered buttons to enter the 6-digit number
“210499”.
3. Enter a new password as described above.
Area Code
Enter the code of the area whose standards were used to rate the
DVD video disc, based on the list on page 34.
1. Select “Area Code” on the LOCK menu then press B.
2. Select the first character using
v / V
buttons.
3. Shift the cursor using B button and select the second charac-
ter using
v / V
buttons then press ENTER,
the password window will appear.
4. Follow step 3 as shown previous page (Rating).
5. Press ENTER to confirm your Area Code selection, then press
SETUP to exit the menu.
OTHERS
The Auto Play, B.L.E. settings can be changed.
Auto Play
You can set up the DVD Player so a DVD disc automatically starts
playing whenever the DVD is inserted.
If Auto Play mode is set to On, this DVD player will search for title
that has the longest playback time and then play back the title
automatically.
On: Auto Play function is activated.
Off: Auto Play function is not activated.
Note
The Auto Play function may not work for some DVDs.
B.L.E. (Black Level Expansion)
To select the black level of playback pictures. Set your preference
and monitor’s ability.
On: Expanded grey scale. (0 IRE cut off)
Off: Standard grey scale. (7.5 IRE cut off)
Auto Play On
B.L.E Off
OTHERS
Move Select Exit
Initial Settings (Continued)
25
Preparation
26
General Features
If a menu screen is displayed
Use the b B v V buttons to select the title/chapter you want to view,
then press ENTER to start. Press TITLE or MENU to return to the
menu screen.
Unless stated otherwise, all operations described use the
remote control. Some features may also be available on the
Setup menu.
Resume Play
When play is stopped, the unit records the point where STOP was
pressed (RESUME function).
Press PLAY and play will resume from this point.
Moving to another TITLE
When a disc has more than one title, you can move to another title.
Press DISPLAY during playback or resume play then the appropriate
number (0-9) or use b / B to move to another title.
Title Menu
Checking the contents of DVD discs: Menus
DVDs may offer menus that allow you to access special features.
To use the disc menu, press TITLE.
Input the corresponding number or use the b B v V buttons to
highlight your selection. Then press ENTER.
Disc Menu
Press MENU and the disc menu is displayed.
Press MENU again to exit.
Moving to another CHAPTER/TRACK
During playback, press SKIP (. or >) to go to the next
chapter/track or to return to the beginning of the current
chapter/track.
Press SKIP . twice briefly to step back to the previous
chapter/track.
Slow Motion
1. Press SLOW t or T during playback.
The player will enter SLOW mode.
DVD disc; 4 steps
2. To exit slow motion mode, press PLAY.
Changing the Audio Language
Press AUDIO repeatedly during playback to hear a different audio
language or audio track.
DVD
DVD
ALL
DVD
DVD
DVD
ALL
DVD
Search
1. Press and hold SKIP/SEARCH . or > for about two sec-
onds during playback.
The player will now go into SEARCH mode.
2. Press and hold SKIP/SEARCH . or > repeatedly to select
the required speed.
DVD: 4 steps
MP3, WMA, Audio CD: 3 steps
3. To exit SEARCH mode, press PLAY.
Still Picture and Frame-by-Frame Playback
During playback, press X to pause playback.
Press X repeatedly to play Frame-by-Frame.
( Remote Control Only )
To exit still motion mode, press PLAY.
Repeat
During playback, press REPEAT repeatedly to select a desired
repeat mode.
DVD Discs: Chapter/Title/Off
Audio CD, MP3/WMA discs: Track/All/Normal
Notes
If you press SKIP (>) once during Repeat Chapter (Track) play-
back, the repeat playback cancels.
Marker Search
Storing a MARKER in the DVD memory is similar to marking your
page in a book. It allows you to quickly return to any point on the
disc.
Storing a marker in the memory
1. Press MARKER/SEARCH during play.
The MARKER SEARCH menu appears on the screen.
2. During playback, press ENTER when playback reaches the
spot that you want to memorize.
3. Press
F
/
G
to select the other marker.
Repeat step 2 to enter up to nine Marker points on a disc.
4. To remove the MARKER SEARCH menu, press
MARKER/SEARCH.
To Recall or Clear a Marked Scene
1. Press MARKER/SEARCH during playback.
The MARKER SEARCH menu will appear on the screen.
2. Press
F
/
G
to select the marker to be recalled/ cleared.
3. Press ENTER to recall a marker.
Press CLEAR to clear a marker.
Play resumes from the point corresponding to the
selected marker, or the selected marker is cleared.
DVD
ALL
DVD
ALL
ALL
General Features
27
Operation
28
General Feature
Repeat A-B
To repeat a sequence.
1. Press A-B at your chosen starting point. “A ” appears briefly on
the TV screen.
2. Press A-B again at your chosen end point.
“A B” appears briefly on the TV screen and the repeat
sequence begins.
3. Press A-B again to cancel.
Zoom
Use zoom to enlarge the video image.
1. Press ZOOM during playback to activate the Zoom function.
2. Each press of the ZOOM button changes the screen in the
sequence: 200%
→
300%
→
400%
→
Normal (4 steps).
3 Use the
b B v V
buttons to move through the zoomed
picture.
4. To resume normal playback, press CLEAR.
Note
Zoom may not work on some DVDs.
Camera Angle
If the disc contains scenes recorded at different camera angles, you
can change to a different camera angle during playback.
Press ANGLE repeatedly during playback to select a desired angle.
Note that the number of the current angle appears on the display.
Subtitles
Press SUBTITLE repeatedly during playback to display the
different subtitle languages.
Last Scene Memory
This player memorizes last scene from the last disc that is viewed.
The last scene remains in memory even if you remove the disc
from the player or switch off the player. If you load a disc that has
the scene memorized, the scene is automatically recalled.
Note
This player does not memorize the scene of a disc if you switch off
the player before commencing to play the disc.
Screen Saver
The screen saver appears when you leave the DVD player in Stop
mode for about five minutes. If the Screen Saver is displayed for
five minutes, the DVD Player automatically turns itself off.
ACDDVD
DVD
DVD
DVD
WMA
MP3ACDDVD
The DVD player can play MP3/WMA formatted recordings on
CD-ROM, CD-R, or CD-RW ,DVD discs.
MP3/ WMA/ Audio CD
Once you insert an MP3/WMA files recorded media or Audio CD,
a menu appears on the TV screen.
Press v / V to select a track/file then press PLAY or ENTER and
playback starts. You can use variable playback functions. Refer to
page 26-28.
Audio CD Menu MP3/WMA Menu
Tips
• If you are in a file list on the MUSIC menu and want to return to
the Folder list, use the v / V to highlight and press PLAY or
ENTER.
• Press MENU to move to the next page.
Press TITLE to move to the previous page.
• On a CD with MP3/WMA and JPEG you can switch MP3/WMA
and JPEG.
Press v / V to select a folder, and press ENTER to see the fold-
er contents.
MP3 / WMA disc compatibility with this player is limited as
follows:
• Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48kHz (WMA)
• Bit rate: within 8 - 320kbps (MP3), 32 - 192kbps (WMA)
• The player cannot read an MP3/WMA file that has a file extension
other than “.mp3” / “.wma”.
• CD-R physical format should be ISO 9660
• If you record MP3 / WMA files using software that cannot create a file
system (eg. Direct-CD) it is impossible to playback MP3 / WMA files.
We recommend that you use Easy-CD Creator, which creates an ISO
9660 file system.
• File names should have a maximum of 8 letters and must incorporate
an .mp3 or .wma extension.
• They should not contain special letters such as / ? * : “ < > l etc.
•
The total number of files on the disc should be less than 648.
This DVD player requires discs and recordings to meet certain technical
standards in order to achieve optimal playback quality. Pre-recorded
DVDs are automatically set to these standards. There are many differ-
ent types of recordable disc formats (including CD-R containing MP3 or
WMA files) and these require certain pre-existing conditions (see
above) to ensure compatible playback.
Customers should note that permission is required in order to
download MP3 / WMA files and music from the Internet. Our
company has no right to grant such permission. Permission
should always be sought from the copyright owner.
TRACK 02
TRACK 03
TRACK 01
TRACK 04
TRACK 05
TRACK 06
Normal
CD
001 / 022
0:00:00
Add
DISPLAY
PROGRAM
Program List
Music 01
Music 02
Music 03
Music 04
Music 05
Normal
003 / 036
00:00 /00:00
Program List Add
DISPLAY
PROGRAM
Playing an Audio CD or MP3/WMA Disc
29
Operation
30
Programmed playback
The program function enables you to store your favorite tracks
from any disc in the player memory.
A program can contain 30 tracks (Audio CD, MP3/WMA).
1. Insert a disc. (Audio CD, MP3 or WMA.)
2. Press v / V to select the desired file.
3. Press PROG. during playback or in the stop mode.
Repeat press PROG. to place additional tracks on the
program list.
4. Press DISPLAY. Program List menu appear.
Press v / V to select the track you want to start playing.
Press MENU to move to the next page.
Press TITLE to move to the previous page.
Audio CD Menu MP3/WMA Menu
5. Press PLAY or ENTER to start.
6. To resume normal playback from programmed playback.
Press DISPLAY then select a track of list and then press PLAY
or ENTER.
Erasing a Track from program list
1. Use v / V to select the track that you wish to erase from
the program list.
2. Press CLEAR. Repeat to erase additional tracks on the
program list.
For details on each operations item,
refer to relevant page. (See pages 26-28)
TRACK 02
TRACK 03
TRACK 01
TRACK 04
TRACK 05
TRACK 06
Normal
CD
001 / 022
0:00:00
DISPLAY
Return Delete
CLEAR
Program List
Music 02
Music 03
Music 04
Music 05
Music 06
Normal
003 / 036
00:00 /00:00
Return
Program List
Delete
DISPLAY
CLEAR
Music 01
Using this DVD Player you can view discs with JPEG files.
1. Insert a disc and close the tray.
The PHOTO menu appears on the TV screen.
2. Press v / V to select a folder, and press ENTER or PLAY.
A list of files in the folder appears. If you are in a file list and
want to return to the previous Folder list, use the v / V buttons
on the remote to highlight and press ENTER or PLAY.
3. If you want to view a particular file, press v / V to highlight a
file and press ENTER or PLAY. Viewing the file proceeding
starts. While viewing a picture, you can press STOP to move
to the previous menu (PHOTO menu).
Tips
• Press MENU to move to the next page.
Press TITLE to move to the previous page.
• On a CD with MP3/WMA and JPEG you can switch MP3/WMA and
JPEG. Press v / V to select a folder, and press ENTER to see the folder
contents.
Moving to another File
Press SKIP (. or >) once while viewing a picture to advance
to the next or previous file.
To rotate picture
Press b / B during showing a picture to rotate the picture clock-
wise or counter clockwise.
Still Picture
1. Press PAUSE during slide show.
The player will now go into PAUSE mode.
2. To return to the slide show, press PLAY, ENTER or press
PAUSE again.
Zoom
Use zoom to enlarge the image.
1. Press ZOOM during playback to activate the Zoom function.
2. Each press of the ZOOM button changes the screen in the
sequence: 100%
→
150%
→
200%
→
100%
3 Use the b B v V buttons to move through the zoomed
picture.
4. To resume normal playback, press CLEAR or press ZOOM
repeatedly to select the 100%.
JPEG disc compatibility with this player is limited as follows:
• Depending upon the size and number of JPEG files, it could take a
long time for the DVD player to read the disc’s contents. If you don’t
see an on-screen display after several minutes, some of the files may
be too large — reduce the resolution of the JPEG files to less than 2M
pixels as 2760 x 2048 pixels and burn another disc.
• The total number of files and folders on the disc should be less than
648.
• Ensure that all the selected files have the “.jpg” extensions when copy-
ing into the CD layout.
• If the files have “.jpe” or “.jpeg” extensions, please rename them as
“.jpg” file.
• File names without “.jpg” extension can not be read by this DVD play-
er. Even though the files are shown as JPEG image files in Windows
Explorer.
File 01
File 02
File 03
File 04
File 05
Normal
001 / 052
00:00 /00:00
Program List Add
DISPLAY
PROGRAM
Viewing a JPEG Disc
31
Operation
32
Refer to the information in this chapter before contacting a
service technician.
Handling the Unit
When shipping the unit
Please save the original shipping carton and packing materials. If
you need to ship the unit, for maximum protection, re-pack the unit
as it was originally packed at the factory.
Keeping the exterior surfaces clean
• Do not use volatile liquids such as insecticide spray near the
unit.
• Do not leave rubber or plastic products in contact with the unit
for a long period of time. since they leave marks on the
surface.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the surfaces are
extremely dirty, use a soft cloth lightly moistened with a mild
detergent solution.
Do not use strong solvents such as alcohol, benzine, or thinner, as
these might damage the surface of the unit.
Maintaining the Unit
The DVD player is a high-tech, precision device. If the optical
pick-up lens and disc drive parts are dirty or worn, the picture
quality could be diminished.
Depending on the operating environment, regular inspection and
maintenance are recommended after every 1,000 hours of use.
For details, please contact your nearest authorized service
center.
Maintenance and Service
33
Reference
Language Code List
Language Code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Albanian 8381
Ameharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Cambodian 7577
Catalan 6765
Chinese 9072
Corsican 6779
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Language Code
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Javanese 7487
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laothian 7679
Latin 7665
Latvian, Lettish 7686
Language Code
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maltese 7784
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Language Code
Singhalese 8373
Slovak 8375
Slovenian 8376
Somali 8379
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085
34
Area Code
Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Area Code
Ethiopia ET
Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Greenland GL
Heard and McDonald Islands
HM
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Area Code
Malaysia MY
Maldives MV
Mexico MX
Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Netherlands Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian Federation RU
Area Code
Saudi Arabia SA
Senegal SN
Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW
Choose an area code from this list.
Area Code List
35
Reference
Troubleshooting
Symptom
No power.
No picture on the LCD or
TV (including video from
another unit).
No sound.
The DVD player does not
start playback.
No response when buttons
are pressed.
The Remote Control does
not work properly.
Correction
• Plug the power cord into the wall outlet securely.
• Recharge the battery.
• Connect the video cable into the jacks securely.
• Select a LCD mode other than OFF.
• Select the appropriate video input mode on the TV so
the picture from the DVD player appears on the screen.
• Select the correct input mode of the audio receiver so
you can listen to the sound from the DVD player.
• Connect the audio cable into the jacks securely.
• Insert a playable disc. (Check the disc type, color
system and Regional code.)
• Cancel the Rating function or change the rating level.
• “ ” may appear on the screen during operation.
• Operate the Remote Control within about 23 ft (7 m).
Cause
• The power cord is disconnected.
• The battery is discharged.
• The video cable is not connected securely.
• LCD mode is set to OFF.
• The TV is not set to receive DVD signal output.
•
The equipment connected with the audio cable is not
set to receive DVD signal output.
• The audio cables are not connected
securely.
• An unplayable disc is inserted.
• The Rating level is set.
• Some discs prohibit certain operations.
• The Remote Control is too far from the
DVD player.
36
Specifications
DVD Player
Power supply:
DC 9.5V (AC adapter terminal), DC 7.4V (Battery)
Power consumption: 12W with battery
Weight: 1.6 lbs (0.74 kg) (without battery pack)
External dimensions (W x H x D):
7.5 x 6.8 x 1.5 inches (191 x 174 x 39 mm)
Signal system: NTSC
Laser:
DVD Laser wavelength 662+25 / 662-15 nm
CD Laser wavelength 785+25 / 785-15 nm
Frequency range (audio):
DVD linear sound: 48kHz sampling 8 Hz to 20 kHz
96kHz sampling 8 Hz to 44 kHz
Signal-to-noise ratio (audio): More than 80 dB
Dynamic range (audio): More than 80 dB
Harmonic distortion (audio): 0.03 %
Operating conditions:
Temperature: 0°C to 40°C, Operation status: Horizontal
Connectors
Video output (VIDEO Out):
1.0 V (p-p), 75
Ω
, negative sync., ø3.5mm mini jack x 1
Audio output (AUDIO Out, analog audio):
1.6 Vrms(1 KHz, 0 dB), ø3.5mm mini jack x 1
Earphone terminal: ø3.5mm stereo mini jack x 2
Liquid Crystal Display
Panel size: 7 inches wide (diagonal)
Projection system: R.G.B. stripe
Driving system: TFT active matrix
Resolution: 234 x 480 x 3 (effective pixel rate: more than
99.99%)
Supplied Accessories
• RCA Audio/Video cable...........................................................1
• AC Adapter (DPAC1) ..............................................................1
• Automotive Adapter (DPDC1) .................................................1
• Battery Pack (DPB125)...........................................................1
• Remote control........................................................................1
• Battery for Remote control (Lithium Battery) ..........................1
z
Design and specifications are subject to change without
notice.
Note
Note
ZENITH ELECTRONICS USA., INC.
DVD PLAYER LIMITED WARRANTY-USA
Zenith will repair or replace your product, at Zenith’s option, if it proves to be defective in material or workmanship under normal use, during
the warranty period (“Warranty Period”) listed below, effective from the date (“Date of Purchase”) of original consumer purchase of the prod-
uct. This warranty is good only to the original purchaser of the product and effective only when used in the United States, excluding U.S.
Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS
REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. ZENITH WILL NOT BE LIABLE
FOR ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES OR PROFITS, IN
CONNECTION WITH THE PRODUCT. SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS
OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO YOU.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
1.Damages or operating problems that result from shipping, installation, adjustment of user controls, calibration, maintenance or
failure to maintain, or separate system components; and
2.Damages or operating problems that result from normal wear and tear, misuse, abuse, operation outside environmental
specifications or contrary to the requirements or precautions in the Operating Guide, accident, lightning strikes or other natural
causes, unauthorized modification or alteration, incorrect electrical current or voltage, software errors that do not disable
functionality, operating software protocols adopted after the date of manufacture or for outside the U.S., institutional or commercial
use, or other causes not arising out of defect in material or workmanship.
3. Therefore, the cost of repair or replacement of such a defective product shall be borne by the consumer.
WARRANTY PERIOD:
LABOR: 90 DAYS from the Date of Purchase.
PARTS: ONE YEAR from the Date of Purchase.
Repaired or Replacement Units are warranted for the
remaining period of the original warranty.
HOW SERVICE IS HANDLED:
Call 1-800-243-0000 for instructions on getting the defective
unit repaired or replaced.
Please retain dated sales receipt and your box to return
the unit to Zenith for repair or replacement.
Both ways shipping charges will be borne by Zenith during the
Warranty Period. After the Warranty Period, you pay in-bound
shipping charges and Zenith pays return shipping charges.
CUSTOMER INTER-ACTIVE CENTER NUMBERS:
FOR WARRANTY SERVICE:
You must call 1-800-243-0000 (24 hours a day, 365 days per year) and select appropriate option from the menu to confirm the
product is defective and to obtain Return Authorization (RA). During the Warranty Period, Zenith will send you a return-shipping
label. After you obtain RA for return, please box your unit with a copy of the sales receipt and enough packing material to ensure
undamaged delivery of your product. When you receive the label, place it on the box and call the 800 # in the instruction for pick-up.
When your unit is received, Zenith will repair or replace your unit in accordance with this Limited Warranty.
ADVANCE SHIPMENT. If replacement unit is available and you want second day delivery, our service representative will ask for your
credit card number. Zenith requires a reserved deposit by credit card as surety for such advance shipment. Your credit card will not be
charged if you return the defective unit in 10 business days. For advance shipment, the return label will come with the replacement
unit sent to you. Please follow boxing and shipping instructions above.
MARKETED AND DISTRIBUTED BY LG ELECTRONICS U.S.A., INC., GS# MFL37883941
1000 SYLVAN AVENUE, ENGLEWOOD CLIFFS, NJ. Printed in China
Issue O
For Warranty Service
For Post Warranty Repair
For Where-to buy, Product
Assistance, or Customer
Assistance
Call 1-800-243-0000 (24 hours a day, 365 days per year)
Retain your dated sales receipt to prove the Date of Purchase as well as your box for ship-
ping the unit
to Zenith, for warranty service.
Legible copy of your sales receipt must be submitted with the unit at the time the unit is
returned for warranty service.
For repair or replacement after the Warranty Period has expired,
Call 1-800-243-0000 (24 hours a day, 365 days per year)
Call 1-800-243-0000 (24 hours a day, 365 days per year) and select an
appropriate option from the menu.Or visit our website at http://www.zenithservice.com
