LCRT1510SV
MFL65001002
www.lg.com
OWNER’S MANUAL
MICROWAVE OVEN
PLEASE READ THIS OWNER’S MANUAL THOROUGHLY
BEFORE OPERATING.
TABLE OF CONTENTS
Cooking Tips
..............................................................................................................................................................
TROUBLESHOOTING
..........................................................................................................................................
Questions and Answers
............................................................................................................................................
Before Calling for S
ervice
.................................................................................................................................................
WARRANTY
............................................................................................................................................
Inside back cover
MEAT
..............................................................................................................................................................................
POULTRY
........................................................................................................................................................................
Meat Cooking Table
.........................................................................................................................................................
Poultry Cooking Table
......................................................................................................................................................
Fresh Fish Cooking Table
................................................................................................................................................
FISH
................................................................................................................................................................................
SAFETY
.......................................................................................................................................................................
Precautions to Avoid Possible Exposure To Excessive Microwave Energy
..............................................................................
Grounding Instructions
.......................................................................................................................................................
Important Safety Instructions
..............................................................................................................................................
Specifications
.....................................................................................................................................................................
Parts and Accessories
........................................................................................................................................................
Control Panel
.....................................................................................................................................................................
Cookware Guide
.................................................................................................................................................................
Tips for Microwave Cooking
................................................................................................................................................
Cleaning
............................................................................................................................................................................
Installation
..........................................................................................................................................................................
UNDERSTANDING YOUR MICROWAVE OVEN
....................................................................................................
USING YOUR MICROWAVE OVEN
.....................................................................................................................
Clock
................................................................................................................................................................................
Child Lock
........................................................................................................................................................................
Timer
...............................................................................................................................................................................
Sensor Touch Operation Instruction
..................................................................................................................................
Sensor Touch Reheat
........................................................................................................................................................
opcorn
.....................................................................................................................................................
Sensor Touch
P
Melt
..................................................................................................................................................................................
Custom Set
......................................................................................................................................................................
1LB Defrost
.......................................................................................................................................................................
Cook Time
.......................................................................................................................................................................
Multi-stage Cooking
........................................................................................................................................................
Microwave Power Levels
...................................................................................................................................................
Thank you for purchasing a LG microwave oven.
HOW TO USE TrueCookPlus
...............................................................................................................................
10-11
12-22
12
12
12
13
13
13
14
14
15
16
17
17
Custom Defrost Table
..................................................................................................................................................
18-19
20
Defrosting Tips
................................................................................................................................................................
20
21
21
22
22
23-24
23
23
23
23
24
24
25-27
25-26
27
3-4
3
3
4
5
5
6
7
8
9
9
5-9
Potato (Example)
..............................................................................................................................................................
Custom Cook
...................................................................................................................................................................
Custom Defrost
................................................................................................................................................................
Soften
.............................................................................................................................................................................
Quick Table
................................................................................................................................................
TouchSensor
Please record the model number and serial
number of this unit for future reference. We also
suggest you record the details of your contact
with LG (LG Electronics U.S.A., Inc.)
concerning this unit.
Staple your receipt here for proof of purchase.
Model No:
EZ-ON
.............................................................................................................................................................................
12
Serial No:
Dealer:
Dealer Phone No:
Customer Relations
LG Electronics U.S.A., Inc.
Service Division Bldg. #3
201 James Record Rd.
Huntsville, AL 35824-0126
SAFETY
• Do not attempt to operate this oven with
the door open, since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or tamper
with the safety interlocks.
•Do not place any object between the oven
front face and the door,or allow soil or
cleaner residue to accumulate on sealing
surfaces.
•Do not operate the oven if it is damaged.
It is particularly important that the oven door
close properly and that there is no damage to
the:
- door (bent),
- hinges and latches (broken or loosened),
- door seals and sealing surfaces.
•The oven should not be adjusted or
repaired by anyone except properly qualified
service personnel.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event
of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape
wire for the electric current. This appliance is
equipped with a cord having a grounding wire
and a grounding plug. The plug must be
plugged into an outlet that is properly installed
and grounded.
WARNING
Improper grounding can result in a risk of elec-
tric shock. Consult a qualified electrician if the
grounding instructions are not completely under-
stood, or if doubt exists as to whether the appli-
ance is properly grounded, and either:
1. If it is necessary to use an extension cord,
use only a 3-wire extension cord that has a
3-blade grounding plug, and a 3-slot recepta-
cle that will accept the plug on the appliance.
The marked rating of the extension cord shall
be equal to or greater than the electrical
rating of the appliance, or. . . .
2. Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or serviceman install an outlet near
the appliance.
NOTES:
1. A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are
available and may be used if care isexer-
cised in their use.
3. If a long cord or extension cord is used, (1)
the marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance, (2) the
extension cord must be a grounding-type
3-wire cord, and (3) the longer cord should be
arranged so that it will not drape over the
countertop or tabletop where it can be pulled
on by children or tripped over accidentally.
Ensure proper ground
exists before use
3
SAVE THESE INSTRUCTIONS
SAFETY
IMPORT ANT SAFETY INSTRUCTIONS
The safety instructions below will tell you how to use your oven to avoid harm to yourself or damage to your
oven.
WARNING
-
To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
found on page 3 of this manual.
3. This appliance must be grounded. Connect only to properly grounded outlet.
See
GROUNDING INSTRUCTIONS
found on page 3 of this manual .
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Some products, such as whole eggs and sealed containers – for example, closed glass jars are able to
explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use corrosive chemicals
or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not
designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified service personnel. Contact the nearest authorized service
facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11 . Do not store this appliance outdoors. Do not use this product near water – for example, near a kitchen sink,
in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over the edge of a table or counter.
15. When cleaning surfaces of door and oven that come together on closing the door, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c. If materials inside the oven ignite, KEEP OVEN DOOR CLOSED, turn oven off, and disconnect the power
cord or shut off power at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to
be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CON-
TAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce
the risk of injury to persons; 1) Do not overheat the liquid. 2) Stir the liquid both before and halfway through
heating it. 3) Do not use straight-sided containers with narrow necks. 4) After heating, allow the container to
stand in the microwave oven for a short time before removing the container. 5) Use extreme care when
inserting a spoon or other utensil into the container.
18. Avoid heating small-necked containers such as syrup bottles.
19. Avoid using corrosive and vapors, such as sulfide and chloride.
20. Liquids heated in certain shaped containers (especially cylindrical-shaped containers) may become overheat-
ed. The liquid may splash out with a loud noise during or after heating or when adding ingredients (instant
coffee, etc.), resulting in harm to the oven and possible injury. In all containers, for best results, stir the liquid
several times before heating. Always stir liquid several times between reheatings.
4
UNDERSTANDING YOUR MICROWAVE OVEN
SPECIFICATIONS
*IEC 60705 RATING STANDARD
Specifications subject to change without prior notice.
LCRT1510SV
MODEL
Power Supply
Rated Power Consumption
Microwave Output
Frequency
Rated Current
Overall Dimensions (W
x
H
x
D)
Oven Cavity Dimensions (W
x
H
x
D)
Capacity of Oven Cavity
120 V AC, 60 Hz
1750 W
*1200 W
2450 MHz
14.5 A
21
7
/
8
'' x 12
1
/
2
'' x 17
7
/
32
''
51
21
/
32
'' x 10
7
/
16
'' x 15
27
/
32
''
1.5 Cu.ft.
INSTALLATION
A. Circuits
For safety purposes this oven must be plugged into a
15 or 20 Amp circuit. No other electrical appliances or
lighting circuits should be on this line. If in doubt, con-
sult a licensed electrician.
B. Voltage Warning
The voltage used at the wall receptacle must be the
same as specified on the oven name plate located on
the back or on the side of the control panel of the oven.
Use of a higher voltage is dangerous and may result in
a fire or other type of accident causing oven damage.
Low voltage will cause slow cooking. In case your
microwave oven does not perform normally in spite of
proper voltage, remove and reinsert the plug.
C. Placement of the Oven
Your microwave oven can be placed easily in your
kitchen, family room, or anywhere else in your home.
Place the oven on a flat surface such as a kitchen
countertop or a specially designed microwave oven
cart. Do not place oven above a gas or electric range.
Free air flow around the oven is important. Allow at
least 4 inches of space at the top, sides, and back of
the oven for proper ventilation.
D. Do not block the air vents
All air vents should be kept clear during cooking. If air
vents are covered during oven operation the oven may
overheat. In this case, a sensitive thermal safety device
automatically turns the oven off. The oven will be
inoperable until it has cooled sufficiently.
E. Radio interference
1. Microwave oven operation may interfere with TV or
radio reception.
2. When there is interference, it may be reduced or
eliminated by taking the following measures:
a. Clean the door and the sealing surfaces of the
oven.
b. Reorient the receiving antenna of radio or
television.
c. Relocate the microwave oven in relation to the TV
or radio.
d. Move the microwave oven away from the
receiver.
e. Plug the microwave oven into a different outlet
so that microwave oven and receiver are on
different branch circuits..
5
UNDERSTANDING YOUR MICROWAVE OVEN
PARTS AND ACCESSORIES
Your oven comes with the following accessories:
1 Use and Care Manual
1 Glass
Turntable
1 Rotating Ring
Oven Front Plate
Window
Door Seal
Control Panel
Door Open Button
Safety Door Lock System
Display Window
6
A. Glass Turntable
B. Turntable Shaft
C. Rotating Ring
D. Motor Shaft
A
B
C
D
WARNING:
Do not operate the oven when empty or without the glass tray. It is best to leave a glass water
in the oven when not in use. The water will safely absorb all microwave energy, if the oven is
accidentally started.
w
UNDERSTANDING YOUR MICROWAVE OVEN
7
CONTROL PANEL
1. DISPLAY. The display includes a clock and
indicators that tell you time of day, cooking time
settings, and cooking functions selected.
2.
1 6. STOP/CLEAR. Touch this pad to stop the oven or
clear entries
.
COOK TIME. Touch this pad to set a cooking time.
1
3.
COOK POWER. Touch this pad to set a cooking power1 4.
CLOCK. Touch this pad to enter the time of day.
1 1.
9 .
TIMER. T
ouch this pad to use your microwave oven
as a kitchen timer.
1 0.
NUMBER PADS Touch number pads to enter
cooking time, power level, quantities, or weights.
1 2 .
8.
MELT. Touch this pads to melt butter/margarine,
chocolate,cheese,or mashmallows.
6.
SOFTEN. Touch this pad to soften butter,ice cream,
cream cheese, or frozen juice.
SENSOR TOUCH
1 5. START/EZ-ON:
START allows oven to begin functioning.
.
This pad allows you to cook most of
your favorite foods without having to select cooking
times and p
ower levels.
3. CUSTOM SET. Touch this pad to select
sound(on/off), clock(on/off), scroll speed(slow,
normal, fast) and unit(lbs./kg.).
4.
CUSTOM COOK. Touch this pad to select programming
food items..
5.
7.
1LB DEFROST.
This pad contains Exact and Auto
CUSTOM DEFROST.
This pad is an accurate defrosting
method for meat, poultry and fish up to 6.0 lbs or 4.0 kg.
TrueCookPlus :
gnidrocca doof kooc ot dap siht hcuoT
to TrueCookPlus code.
Touch EZ-ON to cook at 100% cook power for 30
seconds up to 3 minutes 30 seconds; after 3 minutes
30 seconds,every touch will add 1 minute up to 99 min
59 seconds.
1
13
15
2
3
4
5
6
8
10
12
11
7
9
14
16
defrosting methods. The Exact Defrost is an accurate
defrosting method for frozen meat, poultry, and fish
up to 6.0 lbs or 4.0kg.
UNDERSTANDING YOUR MICROWAVE OVEN
USE
Ovenproof Glass
• Glass treated for use in high-intensity heat
includes utility dishes, bread dishes, pie plates, cake
plates, liquid measuring cups, casseroles, and bowls
without metallic trim.
China
• Bowls, cups, serving plates, and platters without
metallic trim can be used in your oven.
Plastic
• When using plastic wrap as a cover, make sure that
the dish is deep enough so the plastic wrap does not
touch the food. As the food heats, it may melt the
plastic wrap wherever the wrap touches the food.
• Place plastic wrap loosely over the top of the dish
and secure it by pressing the wrap to the sides of
the dish.
• Vent by turning back one corner of the plasticwrap.
This will allow excess steam to escape.
• Use plastic dishes, cups, semi-rigid freezer
containers, and plastic bags only for short time
cooking. Use these with care because the
plastic may soften from the heat of the food.
Paper
• Microwave-safe paper towels, waxed paper, paper
napkins, and paper plates with no metallic trim or
design can be used in your oven.
• Refer to the manufacturer’s label for use of any
paper product in the microwave oven.
DO NOT USE
Metal Utensil
• Metal shields food from microwave energy and
produces uneven cooking. Avoid metal skewers,
thermometers, or foil trays.
• Metal utensils can cause arcing, which is a
discharge of electric current. Arcing can damage
your microwave oven.
Metal Decoration
• Do not use metal-trimmed or metal-banded
dinnerware, casserole dishes, etc.
Centura™ Tableware
• The Corning Company recommends that you
do not use Centura tableware and some Corelle™
closed-handle cups for microwave
cooking.
Aluminum Foil
• Avoid large sheets of aluminum foil because
they hinder cooking and may cause arcing.
• Use small pieces of foil to shield poultry legs
and wings.
• Keep all aluminum foil at least 1 inch from the walls
and door of the oven.
Wood
• Wooden bowls, boards, and baskets will dry out and
may split or crack when you use them in the
microwave oven.
Tightly Closed Containers
• Tightly closed cookware can explode. Be sure
to leave an opening for steam to escape from
covered cookware.
Brown Paper
• Avoid using brown paper bags. They absorb
heat and could burn.
Metal Twist Ties
• Always remove metal twist ties as they can become
hot and cause a fire.
COOKWARE GUIDE
Most heat-resistant, non-metallic cookware is safe for use in your microwave oven. However, to test cookware
before using, follow these steps:
1. Place the empty cookware in the microwave oven.
2. Measure 1 cup of water in a glass measuring cup and place it in the oven beside the cookware.
3. Microwave on 100% power for 1 minute. If the dish is warm, it should not be used for microwave cooking.
8
UNDERSTANDING YOUR MICROWAVE OVEN
TIPS FOR MICROWAVE COOKING
BROWNING
Meat and poultry with high fat content that are cooked
for 10 or 15 minutes or longer will brown lightly. Foods
cooked a shorter time can be brushed with a browning
agent, such as Worcestershire sauce, soy sauce, or
barbecue sauce.
COVERING
A cover traps heat and steam and causes the food to
cook more quickly. Use a lid or microwave-safe plastic
wrap with one corner folded back to vent the excess
steam. Lids on glass casseroles can become hot
during cooking. Handle carefully. Waxed paper will
prevent the food from splattering in the oven and help
retain heat. When warming bread items, use waxed
paper, napkins, or paper towels. To absorb extra
moisture, wrap sandwiches and fatty foods in paper
towels.
SPACING
Arrange individual foods, such as baked potatoes,
cupcakes, and hors d’oeuvres in a circle and at least
1 inch apart. This will help the food cook more evenly.
STIRRING
Stirring blends flavors and redistributes the heat in
foods. Always stir from the outside toward the center
of the dish. Food at the outside of the dish heats first.
TURNING
Large foods, such as roasts and whole poultry, should
be turned so that the top and bottom cook evenly. Also
turn over chicken pieces and chops.
ARRANGEMENT
Do not stack food. Arrange in a single layer in the dish
for more even cooking. Because dense foods cook
more slowly, place thicker portions of meat, poultry, fish,
and vegetables toward the outside of the dish.
TESTING FOR DONENESS
Because foods cook quickly in a microwave oven, you
need to test frequently for doneness.
STANDING TIME
SHIELDING
To prevent some portions of rectangular or square dish-
es from overcooking, you may need to shield
them with small strips of aluminum foil to block the
microwaves. You can also cover poultry legs and
wing tips with foil to keep them from overcooking.
Always keep foil at least 1 inch from oven walls
to prevent arcing.
PIERCING
Pierce the shell, skin, or membrane of foods before
cooking to prevent them from bursting. Foods that
require piercing include yolks and whites of eggs, hot
dogs, clams, oysters, and whole vegetables, such as
potatoes and squash.
CLEANING
Wipe the oven inside and outside with a soft cloth and
a mild detergent solution. Then rinse and wipe dry.
This should be done weekly or more often, if needed.
Never use cleaning powders or rough pads.
Excessive oil splatters on the inside top will be difficult
to remove if left for many days. Wipe splatters with a
wet paper towel, especially after cooking chicken or
bacon.
REMOVABLE PARTS
The turntable and turntable roller rest are removable.
They should be hand-washed in warm (not hot) water
with a mild detergent and a soft cloth. Once they are
clean, rinse well and dry with a soft cloth. Never use
cleaning powders, steel wool, or rough pads.
• The glass turntable may be cleaned at the sink. Be
careful not to chip or scratch the edges as this may
cause the turntable to break during use.
• The turntable roller rest should be cleaned regularly.
SPECIALCARE
For best performance and safety, the inner door panel
and the oven front frame should be free of food or
grease buildup. Wipe often with a mild detergent; then
rinse and wipe dry. Never use cleaning powders or
rough pads.
After cleaning the control panel, touch STOP/CLEAR
to clear any entries that might have been entered
accidentally while cleaning the panel.
Depending on density, food often needs to stand from
2 to 15 minutes either in or outside of oven to finish
cooking after cooking power shuts off. Outside of oven,
you usually need to cover food during standing time to
Remove most foods when they are slightly
and they will finish cooking during standing
internal temperature of food will rise about 10°F
standing time.
retain heat.
undercooked
time.The
during
9
1234
WHAT IS TrueCookPlus ?
TrueCookPlus is the first ever way to microwave cook
your food to perfection. Every time, in any size or
power microwave oven anywhere in the world.
EXAMPLE: USING TrueCookPlus
1. Press the
STOP/CLEAR
Button.
2. Find the simple TrueCookPlus
code on your favorite food
package or at
www.TrueCookPlus.com.
On your food package, your
TrueCookPlus code will look
similar to this:
3. Press the
TrueCookPlus
button on your microwave
oven keypad.
4. You will hear a musical tone
and your oven will ask you
to enter your TrueCookPlus
code.
5. Key in
1 2 3 4
(for example).
The display shows :
6. Press the
START / EZ-ON
button.
7. TrueCookPlus now manages
your microwave cooking
automatically -- adjusting
power levels, cook times etc.
8. When TrueCookPlus is done,
your oven will beep.
9. Your food will be cooked to
perfection.
1 0. If you enter an invalid
TrueCookPlus code, your oven
will display ‘CODE ERROR’
11. Your oven relies on you to
enter the TrueCookPlus code
exactly as it appears on the
food package or at
http://www.TrueCookPlus.com
If you make an error entering the simple numeric
TrueCookPlus , or enter a TrueCookPlus code other
than the one specific
to your food product,
or fail to
press the TrueCookPlus button before entering your
TrueCookPlus code,your food may undercook,
overcook or even burn.
HOW TO USE TrueCookPlus
TrueCookPlus is a registered trademark of Microwave
Science JV LLC.
HOW TO USE TrueCookPlus
and used herein under license from
Science JV LLC.
Microwave Science JV LLC under US patents 5,812,393,
5,883,
801, 6,198,975, 6,249,710. Copyright 2008
Microwave
10
C TOUCH START
1 2 3 4
11
TrueCookPlus SETUP
After you unpack and plug in your TrueCookPlus oven,
take a few moments to tell TrueCookPlus your zip code.
2. Press the
TrueCookPlus
button three times
3. Enter your five digit U.S.
Post Office zip code.
Once TrueCookPlus knows your zip code, every
time you enter a TrueCookPlus code, TrueCook-
Plus will automatically adjust for your elevation
above sea level.
1. Press the
STOP / CLEAR
button
4. Press the
START / EZ-ON
button
Example : Setup your ZIP code
CUSTOMIZING TrueCookPlus
1. Press the
STOP / CLEAR
button
2. Press the
TrueCookPlus
button twice
6. Press the
START / EZ-ON
button
You may find that you would prefer TrueCookPlus to
cook your food more
quickly or more slowly.
TrueCookPlus can adjust to your tastes—to cook your
food more quickly or more slowly.
HERE’S HOW
3. If you want your food to
cook more quickly when you
enter a TrueCookPlus code,
press a number between 3
and 5
4. If you want your food to
cook more slowly when
you enter a TrueCookPlus
code,press 1 .
5. If you wish to reset TrueCo-
okPlus to its factory default,
press 2
Note :
1 : Shorter (6%)
2 : Normal (Default)
3 or 4, 5 : Longer (3%, 6%, 9%)
TrueCookPlus is a registered trademark of Microwave Science JV LLC; and used herein under license
from Microwave Science JV LLC under US patents 5,812,393, 5,883,801, 6,198,975, 6,249,710. Copyright
2008 Microwave Science JV LLC.
HOW TO USE TrueCookPlus
1.
1.
2.
Your microwave oven can be used as a kitchen
timer. You can set up to 99 minutes, 99 seconds.
Example: To set 3 minutes.
Touch: Display Shows:
TIMER
USING YOUR MICROWAVE OVEN
Example: To set the clock for 10:30(AM).
Touch: Display Shows:
CLOCK
1.
2.
3.
5.
NOTE: This is a 12 hour clock. You can switch
between AM and PM by touching 1 or 2 after step 4.
You can use this safety feature to lock the control
panel so that children cannot use the oven when
you do not want them to and when you are
cleaning the oven.
To set CHILD LOCK:
Touch: Display Shows:
CHILD LOCK
Touch and
hold until
from the
the display.
(approx
imately
3 seconds)
Time of day.
Time of day.
1.
2.
3.
6.
4.
:
AM
10
:
30
Touch and hold
until
appears in
the display.
(approximately
3 seconds)
To cancel CHILD LOCK:
Touch: Display Shows:
12
3
:
00
T
I
M
E
R
:
ENTER TIME IN MIN AND SEC
3
:
00
TOUCH START
Time counting down
ENTER TIME OF DA
10
:
30
TOUCH START
10
:
30
TOUCH
START
AM TOUCH
1
PM TOUCH
2
AM
10
:
30
TIMER
LOCKED
LOCKED
disappears
EZ-ON
A time-saving pad, this simplified control lets
you quickly set and start microwave cooking.
NOTE:
If you touch EZ-ON, it will add 30 seconds up to
3 minutes 30 seconds; after 3 minutes 30 seconds,
every touch will add 1 minute up to 99 min 59
seconds.
Example : To set EZ-ON cooking 2 minutes.
4 times
The oven begins
cooking and display
shows time counting
down.
Display Shows:
Time of day.
Touch:
Quick cooking provides exciting new
features to make microwave oven easier. Your new
microwave oven will guide you, step by step,
whether it be simply to reheat food or cook food
and sensor menu with all the popular food choices
helps you to cook perfectly because it has been
pre-programmed and can tell how long to cook or
reheat food items.
Categories :
1. Sensor Touch Reheat
2. Sensor Touch Potato
3. Sensor Touch Rice
4. Sensor Touch Popcorn
5. Sensor Touch Vegetable
(Fresh Vegetable/Frozen Vegetable)
6. Sensor Touch Frozen Entree
1. The Sensor Touch system works by detecting
a build-up of vapor.
2. Make sure the door remains closed.
3. Opening the door or touching the STOP/CLEAR
pad before the vapor is detected will abort the
process.The oven will stop.
4. Before using Sensor Touch , make sure the
exterior of the reheating container and the
interior of the oven are dry,to assure the best
results.
SENSOR COOK allows you to cook most
of your favorite foods without having to
select cooking times and power levels.
This oven automatically determines
required cooking times for each food item.
Example: To cook potato
Touch: Display Shows:
The oven will start automatically.
1.
2.
SENSOR TOUCH OPERATION
INSTRUCTION
POTATO (EXAMPLE)
QUICK
TABLE
TOUCHSENSOR
Sensor Touch
13
NOTE: If you open the door or press STOP/CLEAR
during sensing,the process will be canceled.
CATEGORY
Potato
Rice
Popcorn
Fresh
Vege-
table
Frozen
DIRECTION
Pierce each potato with
a fork and place on the
oven tray around the edge,
at least one inch apart.
Place rice and twice as
much liquid (water or
chicken or vegetable
stock) in a 2-quart
microwavable dish.
Cover with plastic wrap.
When cooking is
complete,allow 10
minutes standing time.
Stir for fluffier rice.
Place only bag of
prepackaged microwave
popcorn on the center
of turntable.
Prepare as desired, wash,
and leave residual water
on the vegetables. Place in
an appropriately-sized
microwave container,cover
with plastic wrap and vent.
Remove from package,
rinse off frost under
running water.Place in
an appropriately-sized
microwave container,
cover with plastic wrap
and vent.
AMOUNT
1~4 medium
approx.
9 oz. each
1~2 cups
Use medium
or long grain
rice. Cook
instant rice
according to
directions on
the package.
Regular size
Use one
fresh bag of
popcorn
1~4 cups
1~4 cups
Frozen
Entr
e
e
Remove from outer display
package.Slit cover. If not in
microwave-safe container,
place on plate, cover with
plastic wrap, and vent.
10~21 oz.
3.0-3.5 oz.
POTATO
USING YOUR MICROWAVE OVEN
Food item in the Sensor Touch
Reheat menu include:
The feature reheats single servings
of previously
cooked foods or a plate of leftovers.
1. DINNER PLATE
2.
SOUP/SAUCE
3. CASSEROLE
Example:
To reheat
Touch: Display Shows:
simply follow the steps below.
The oven will start automatically
Approx.
10.3 - 15.5
oz.
1-4 cups
1-4 cups
Place foods to be heated
on a dinner plate or
similar dish. Cover with
plastic wrap.
Place foods to be heated
in an appropriately
sized microwave container.
Cover with plastic wrap.
Cover dish containing the
casserole with plastic wrap.
SENSOR TOUCH REHEAT TABLE
CATEGORY DIRECTION AMOUNT
Casserole
Soup/sauce
Dinner plate
SENSOR TOUCH REHEAT
Time of day.
CASSEROLE
This feature makes preparation of microwave
popcorn simple and quick...
one bag at a time.
The automatic popcorn uses the HI power only.
The popping time counts down in the display.
When the popping time is over, two short and
one long tones sound and End shows.
Oven shuts off automatically.
Place one bag only(50-100g) of prepackaged
microwave popcorn on a microwave-safe /
oven-safe dish on the turntable,The package
.
should be at room temperature.
SENSOR TOUCH POPCORN
Touch: Display Shows:
The oven will start automatically.
Time of day.
14
P
RN
P
USING YOUR MICROWAVE OVEN
SELECT MENU 1 TO
CASSEROLE
3
If popcorn bag size is not known,
follow manufacturers' instructions
and do not use this feature.
Do not use POPCORN key pad in
combination with any other feature
key pads.
Do not attempt to reheat or cook
any unpopped kernels.
Do not reuse bag. Overcooking can
result in an oven fire.
Prepare one bag only at a time.
Do not use popcorn popping devices
in microwave oven with this feature.
Do not leave microwave unattended
while cooking popcorn.
CAUTION : Never use a brown paper
bag for popping corn.
NOTE :
When popping prepackaged popcorn;
Place carefully so the bag does not
touch the oven walls. Fold each end of
the bag in half toward the center top
of the bag.
CUSTOM SET FUNCTION CHART
1.
2.
3.
4.
CUSTOM
SET
CUSTOM SET
NO.
1
2
3
4
NOTE: When the power cord is first plugged
in, the default setting are Sound ON,
Clock On, Normal Speed and LBS.
SOUND ON/OFF
CLOCK ON/OFF
SCROLL SPEED
LBS/KG CHOICE
Sound On or Sound Off
Clock On or Clock Off
Slow, Normal, or Fast
Lbs or Kg
FUNCTION
CHOICE
15
CUSTOM SET provides four modes which make
using your microwave oven quite handly.
you can select SOUND ON/OFF,
CLOCK ON/OFF, SCROLL SPEED and
LBS/KG.
SOUND ON TOUCH
1
OFF TOUCH
2
SOUND OFF
USING YOUR MICROWAVE OVEN
CUSTOM COOK
CUSTOM COOK TABLE
Custom Cook made easy! Your oven’s
menu has been preprogrammed to
automatically cook food. Tell the oven
what you want and how many items
there are. Then let your microwave oven
cook your selections.
Food items in the CUSTOM COOK menu
include:
1. Bacon
2. Frozen Roll/Muffin
3. Fresh Roll/Muffin
4. Beverage
5. Chicken Pieces
6. Hot Cereal
EXAMPLE: To cook 4 slices of bacon,
simply follow the steps below.
DIRECTIONCODE
CA
TEGORY
Bacon
Frozen
Roll/Muffin
Fresh
Roll/Muffin
Frozen Roll/Muffin
Fresh Roll/Muffin
Beverage
Chicken
Pieces
Hot Cereal
AMOUNT
2 to 6
slices
1 to 6
pieces
(2~3
oz. each)
1 to 6
pieces
(2~3
oz. each)
1 to 2
cups
0.5 to 2
lbs.
1 to 6
servings
Place bacon strips on
microwave bacon rack
for best results.(Use
dinner plate lined with
paper towels if rack is
not available).
Remove from display
package and place on
plate.(If muffins are over
3 oz. each, count as two
when entering quantity.)
Remove from display
package and place on
plate.(If muffins are over
3 oz. each, count as two
when entering quantity.)
Remove from display
package and place on
plate.(Be careful! The
beverage will be very
hot! Sometimes liquids
heated in cylindrical
containers will splash
out when the cup is
moved.)
Place the chicken pieces
in an appropriately sized
microwaveabl e container
,cover with plastic wrap,
and vent.
Prepare as directed on
package and cook.
Stir and allow standing
time before eating.Use
only instant hot cereal.
1
2
3
4
5
6
16
Category Touch Amount
Bacon
1
2
3
4
5
2 slices
3 slices
4 slices
5 slices
6 slices
1 1 muffin
2 muffins
3 muffins
4 muffins
5 muffins
6 muffins
2
3
4
5
6
1
2
3
4
5
6
Beverage
1
2
1 cup
2 cups
Chicken Pieces
Enter
Weight
0.5 to 2 lbs.
Hot Cereal
1
2
3
4
5
6
1 serving
2 servings
3 servings
4 servings
5 servings
6 servings
1 muffin
2 muffins
3 muffins
4 muffins
5 muffins
6 muffins
Touch: Display Shows:
1.
3.
Time counting down and
BACON
BACON
TOUCH
1
TO
S
4
SLICES
TOUCH START
will
appear on display.
CUSTOM
COOK
SELECT MENU
1
TO
6
2.
USING YOUR MICROWAVE OVEN
4.
Example: To defrost 1.2 lbs of ground beef.
Touch: Display Shows:
CUSTOM DEFROST
1.
2.
3.
and
4.
Time counting down
and
to enter the weight
Three defrost sequences are preset in the oven.
The custom defrost feature provides you with the best
defrosting method for frozen foods. The cooking guide
will show you which defrost sequence is recommended
for the food you are defrosting.
For added convenience, the Custom Defrost
includes a built-in beep mechanism that reminds
you to check, turn over, separate, or rearrange to get
best defrost results. Three different defrosting levels
are provided.
1 MEAT
2 POULTRY
3 FISH
*Available weight is 0.1~6.0 lbs.
NOTE:
When you touch the START pad, the display changes
to defrost time count down. The oven will beep during
the DEFROST cycle. At this time, open the door and
turn, separate, or rearrange the food.
Remove any portions that have thawed.
Return frozen portions to the oven and touch
START to resume the defrost cycle.
appear on display.
will
on display in middle of
cycle and you will hear
Note:
will appear
17
MEAT TOUCH
1
POULTR TOUCH
2
FISH TOUCH
3
1 . 2
TOUCH START
Lbs
DEF
R
SO T
USING YOUR MICROWAVE OVEN
MEAT
ENTER
WEIGHT
a beep.
This feature should be used only when you defrost 1
pound of frozen ground beef.
Example: To defrost 1 lb Ground beef.
Touch: Display Shows:
1LB DEFROST
1.
2.
on display in middle of cycle
Note:
will appear
Time of day.
1LB
DEFROST
Time counting down and
will appear on display.
D
E
F
R
S
O
T
cycle and you will hear
a beep.
18
USING YOUR MICROWAVE OVEN
CUSTOM DEFROST TABLE
NOTE: Meat of irregular shape and large, fatty cuts of meat should have the narrow or fatty areas shielded with
foil at the beginning of the defrost sequence.
Meat settings
FOOD
BEEF
Ground Beef,
Bulk
Ground Beef,
Patties
Round Steak
Tenderloin
Steak
Stew Beef
Pot Roast,
Chuck Roast
Rib Roast
Rolled Rump
Roast
LAMB
Cubes for
Stew
Chops
(1 inch thick)
PORK
Chops
(1/2 inch thick)
Hot Dogs
Spareribs
Country-style
Ribs
Sausage,
Links
Sausage,
Bulk
Loin Roast,
Boneless
SETTING
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
AT BEEP
Remove thawed portions with fork.
Turn over. Return remainder to oven.
Separate and rearrange.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Remove thawed portions with fork.
Separate remainder.
Return remainder to oven.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Remove thawed portions with fork.
Return remainder to oven.
Separate and rearrange.
Separate and rear
range.
Separate and rearrange.
Turn over. Cover warm areas with
aluminum foil.
Separate and rearrange.
Remove thawed portions with fork.
Turn over. Return remainder to oven.
Turn over. Cover warm areas with
aluminum foil.
SPECIAL INSTRUCTIONS
Do not defrost less than 1/4 lb.
Freeze in ball shape.
Do not defrost less than 2 oz. patties.
Depress center when freezing.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
19
USING YOUR MICROWAVE OVEN
CUSTOM DEFROST TABLE (CONTINUED)
Poultry setting
Fish setting
FOOD
CHICKEN
Whole
(up to 6 lbs)
Cut-up
CORNISH
HENS
Whole
TURKEY
Breast
(up to 6 lbs)
FOOD
FISH
Fillets
Steaks
Whole
SHELLFISH
Crab meat
Lobster tails
Shrimp
Scallops
SETTING
POULTRY
POULTRY
POULTRY
SETTING
FISH
FISH
FISH
FISH
FISH
FISH
FISH
AT BEEP
Turn over (finish defrosting breast
side down). Cover warm areas with
aluminum foil.
Separate pieces and rearrange.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
AT BEEP
Turn over. Separate fillets when
partially thawed, if possible.
Separate and rearrange.
Turn over.
Break apart. Turn over.
Turn over and rearrange.
Separate and rearrange.
Separate and rearrange.
SPECIAL INSTRUCTIONS
Place chicken breast-side up in a
microwave safe dish. Finish defrosting by
immersing in cold water. Remove giblets
when chicken is partially defrosted.
Place in a microwave safe dish.
Finish defrosting by immersing in cold water.
Place in a microwave safe
dish.
Finish defrosting by immersing in cold water.
Place in a microwave safe dish.
Finish defr
osting by immersing in cold water.
SPECIAL INSTRUCTIONS
Place in a microwave safe dish.
Carefully separate fillets under
cold water.
Place in a microwave safe dish.
Run cold water over to finish defrosting.
Place in a microwave safe dish.
Cover head and tail with foil; do not let
foil touch sides of microwave. Finish
defrosting by immersing in cold water.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave saf
e dish.
For best results, some recipes call for different cook
powers during different stages of a cook cycle. You
can program your oven to switch from one power
level to another for up to 2 stages.
Example: To set a 2-stage cook cycle.
Touch: Display Shows:
MULTI-STAGE COOKING
1.
2.
5.
3.
4.
6.
to set a 7 minute cook
time for second stage.
to set a 3 minute cook
time for first stage.
7.
9.
8.
to set an 50% cook
power for the second
stage.
to set an 80%
cook power for
the first stage.
When the first stage is over, you will hear two
short tones as the oven begins the second
cook stage.
10.
Time counting down
and
will
appear on display.
COOK
20
TOUCH START OR
POWER LEVEL
TOUCH START OR
POWER LEVEL
POWER 100
ENTER POWER
LEVEL
0
TO
10
POWER
0
TOUCH START
POWER
80
: ENTER COOKING TIME
3:00
3:00
3:00
: ENTER COOKING TIME
7:00
7:00
POWER 10
0
ENTER POWER
LEVEL
0
TO
10
POWER 50 TOUCH START
7:00
USING YOUR MICROWAVE OVEN
TIME
COOK
POWER
COOK
TIME
COOK
POWER
DEFROSTING TIPS
• When using Auto Defrost, the weight to be
entered is the net weight in pounds and tenths
of pounds (the weight of the food minus the
container).
• Before starting, make sure to remove any and
all metal twist-ties that often come with frozen
food bags, and replace them with strings or
elastic bands.
• Open containers, such as cartons, before
placing in the oven.
• Always slit or pierce plastic pouches or
packaging.
• If food is foil wrapped, remove foil and place it
in a suitable container.
• Slit the skin of skinned food, such as sausage.
• Bend plastic pouches of food to ensure even
defrosting.
• Always underestimate defrosting time. If
defrosted food is still icy in the center, return it
to the microwave oven for more defrosting.
• The length of defrosting time varies according
to how solidly the food is frozen.
•
The shape of the package affects how quickly
food will defrost. Shallow packages will defrost
more quickly than a deep block.
• As food begins to defrost, separate the pieces.
Separated pieces defrost more easily.
•
Use small pieces of aluminum foil to shield parts
of food such as chicken wings,leg tips,fish tails,
or areas that start to get warm. Make sure the
foil does not touch the sides, top, or bottom of
the oven. The foil can damage the oven lining.
• For better results, let food stand after defrosting.
(For more information on standing time, see the
“Microwave Cooking Tips” section).
• Turn over food during defrosting or standing time.
Break apart and remove food as required.
8
SOFTEN
MELT
The oven uses low power to melt foods (butter,
margarine,chocolate, cheese and marshmallows).
See the following table.
Example: To Melt 8 oz. Chocolate.
Touch: Display Shows:
1.
2.
3.
5.
time counting down and
on display.
will appear
4.
Time of day.
4.
time counting down and
will appear
on display.
5.
The oven uses low power to soften foods (butter,
ice cream, cream cheese, and frozen juice)
See the following table.
Example: To Soften Quart Ice Cream.
Touch: Display Shows:
1.
2.
3.
Time of day.
SOFTEN TABLE
Amount
1, 2 or 3
sticks
Pint,
Quart,
Half
gallon
3 or 8
oz.
6, 12 or
16 oz.
Direction
Unwrap and place in
microwavable container.
No need to cover butter.
Butter will be at room
temperature and ready
for use in recipe.
Place container in oven.
Ice cream will be soft
enough to make
scooping easier.
Unwrap and place in
microwavable container.
Cream cheese will be at
room temperature and
ready for use in recipe.
Remove top.
Place in oven.
Frozen juice will be soft
enough to easily mix with
water.
Cate-
gory
Butter
Ice
Cream
Cream
Cheese
Frozen
Juice
1
2
3
4
Code
MELT TABLE
Amount
1, 2 or
3 sticks
4 or 8
oz.
8 or 16
oz.
5 or 10
oz.
Direction
Unwrap and place in
microwavable container
.
No need to cover butter
.
Stir at the end of cooking
to complete melting.
Choose the 4 or 8 oz.(actual
weight) selection to melt
squares of baking chocolate.
Unwrap squares and place
them in a microwavable
container.Stir at the end of
cycle to complete melting. If
Use processed cheese
food only. Cut into cubes.
Place in a single layer in
microwavable container
.
Stir at the end of cooking
to complete melting.
Large or miniature
marshmallows may be
used. Place in
microwavable container
.
Stir at the end of cycle to
complete melting.
Cate-
gory
Butter/
Marga-
rine
Choco
late
Cheese
Marsh-
mallows
1
2
3
4
Code
-
using chocolate morsels
always use the 4 oz. setting.
Stir at the end of the cycle to
complete melting.Add time as
necessary if more than 4 oz.
dry measure is being melted.
21
select menu 1 to 4
ice cream
touch 1 to
ice cream
select menu 1 to 4
chocolate touch 1 to
chocolate
USING YOUR MICROWAVE OVEN
3
QUART TOUCH START
2
8
O
Z
TOUCH START
USING YOUR MICROWAVE OVEN
COOK TIME
1.
2.
5.
3.
4.
This feature lets you program a specific cook time
and power. For best results, there are 10 power
level settings in addition to HIGH power (100%).
Refer to the “Microwave Power Level Table”
for more information.
NOTE: If you do not select a power level, the oven
will automatically cook at HIGH (100%) power.
Example: To cook for 5 minutes, 30 seconds
at 80% power.
Touch: Display Shows:
Time counting down
and
appear on display.
will
MICROWAVE POWER LEVELS
Your microwave oven has 10 cook power levels to let
you cook or heat a wide variety of foods. Refer to the
table below for suggestions:
Microwave Power Level Table
• Boiling water.
• Making candy.
• Cooking poultry pieces, fish, & vegetables.
• Cooking tender cuts of meat.
• Whole poultry
.
• Reheating rice, pasta, & vegetables.
• Reheating prepared foods quickly.
• Reheating sandwiches.
• Cooking egg, milk, & cheese dishes.
• Cooking cakes, breads.
• Melting chocolate.
• Cooking veal.
• Cooking whole fish.
• Cooking puddings & custard.
• Cooking ham, whole poultry, & lamb.
• Cooking rib roast, sirloin tip.
• Thawing meat, poultry, & seafood.
• Cooking less tender cuts of meat.
• Cooking pork chops, roast.
• Taking chill out of fruit.
• Softening butter.
• Keeping casseroles & main dishes warm.
• Softening butter & cream cheese.
• Standing time.
10
(High)
9
8
7
6
5
4
3
2
1
0
Use
Power
Level
22
COOK
TIME
COOK
POWER
3 0
S
TOUCH START OR
POWER LEVEL
3
:
0
S
POWER 10
0
ENTER POWER
LEVEL
0
T
O
1
3
:
0
S
POWER
80
TOUCH START
: ENTER COOKING TIME
POWER
80
0
Meat
1. No special techniques are required. Meat should be
prepared as with conventional cooking. Season if
desired. Always thoroughly defrost meat before cook-
ing.
2. Place the meat on a microwave roasting rack or
microwave-proof plate and place on the turntable.
3. Cook according to the Meat Cooking Table (below).
Use the longer time for large cuts of meats and the
shorter time for small cuts of meats. For thicker
chops, use the longer time.
4. Turn the meat once halfway through the cooking
time.
5. .gnikooc retfa nevo ni setunim 01-5 rof dnats teL
The standing time is very important as it
completes the cooking process.
6. Make sure meat, especially pork, is thoroughly
cooked before eating.
Poultry
1. No special techniques are required. Poultry should
be prepared as with conventional cooking. Season if
desired.
2. Poultry should be thoroughly defrosted. Remove
giblets and any metal clamps.
3. Prick the skin and brush lightly with vegetable oil
unless the poultry is self-basting.
4. All poultry should be placed on a microwave roasting
rack or a microwave-proof plate and placed on the
turntable.
5. Cook according to the instructions in the Poultry
Cooking Table below. Turn over halfway through the
cooking time. Because of its shape, poultry has a
tendency to cook unevenly, especially in very bony
parts.Turning during roasting helps to cook these
areas
evenly.
6. Let stand for 5-10 minutes in oven after cooking
before carving. The standing time is very important,
as it completes the cooking process.
7. Make sure poultry is thoroughly cooked before eating.
Whole poultry is completely cooked when the juices
run clear from the inside thigh when it is pierced with
a sharp knife. Poultry pieces should be pierced with
a sharp knife through the thickest part to ensure that
the juices are clear and the flesh is firm.
WARNING: Do not use aluminum
foil
during
cooking cycle.
Poultry Cooking Table
NOTES:
• The times listed above are only a guide. Allow for
difference in individual tastes and preferences. The
times may also vary due to the shape, cut, and
composition of the food.
• If whole poultry is stuffed, the weight of the stuffed
bird should be used when calculating the cooking
time.
NOTE: The times listed above are only a guide. Allow
for difference in individual tastes and preferences. The
times may also vary due to the shape, cut, and compo-
sition of the food.
Poultry
COOKING TIPS
USING YOUR MICROWAVE OVEN
CHICKEN
Whole
Breast (boned)
Portions
TURKEY
Whole
Microwave
Power
8
8
8
8
Cooking Time
Per Pound
11 to 15 minutes
10 to 14 minutes
11 to 17 minutes
11 to 15 minutes
BEEF
Standing/Rolled Rib
– Medium
– Well-done
Ground Beef (to
brown for casserole)
Hamburgers,
Fresh or defrosted
(4 oz. each)
– 2 patties
– 4
patties
PORK
Loin, Leg
Bacon
– 4 slices
– 6 slices
Microwave
Power
8
8
HIGH(100%)
HIGH(100%)
HIGH(100%)
8
HIGH(100%)
HIGH(100%)
Cooking Time
Per Pound
9
1
/
2
to 11
1
/
2
minutes
11
1
/
2
to 14 minutes
6
1
/
2
to 9
1
/
2
minutes
2
1
/
2
to 4
1
/
2
minutes
3
1
/
2
to 5
1
/
2
minutes
12
1
/
2
to 16
1
/
2
minutes
2
1
/
2
to 3
1
/
2
minutes
3
1
/
2
to 4
1
/
2
minutes
Meat Cooking Table
Meat
23
USING YOUR MICROWAVE OVEN
COOKING TIPS (continued)
Fish
1. Arrange fish in a large shallow non-metallic dish or casserole.
2. Cover with pierced microwave plastic wrap or casserole lid.
3. Place the dish on the turntable.
4. Cook according to the instructions in the Fresh Fish Cooking Table below. Flakes of butter can be added to the
fish if desired.
5. Let stand as directed in the Cooking Table before serving.
6. After standing time, check to see that the fish is thoroughly cooked. The fish should be opaque and flake easily.
Fresh Fish Cooking Table
Fish
Fish Fillets
Whole Mackerel,
Cleaned and Prepared
Whole Trout,
Cleaned and Prepared
Salmon Steaks
Microwave
Power
HIGH
HIGH
HIGH
HIGH
Cooking Time
Per Pound
4
1
/
2
to 8 minutes
4
1
/
2
to 8 minutes
5
1
/
2
to 9 minutes
5
1
/
2
to 8 minutes
Standing
Time
2 to 3 minutes
3 to 4 minutes
3 to 4 minutes
3 to 4 minutes
Butter
Add 15 to 30 ml (1 to 2 tbsp lemon juice)
–
–
Add 15 to 30 ml (1 to 2 tbsp lemon juice)
24
QUESTIONS AND ANSWERS
Operation
Question
Why is the oven light not on during
cooking?
Why does steam come out of the air
exhaust vent?
Will the microwave oven be damaged if it
operates empty?
Does microwave energy pass through the
viewing screen in the door?
Why does a tone sound when a pad on
the control panel is touched?
Can my microwave oven be damaged if
food is cooked for too long?
When the oven is plugged into the wall
outlet for the first time, and it does not
work properly. What is wrong?
Why do I see light reflection around the
outer case?
What are the various sounds I hear when
the microwave oven is operating?
There may be several reasons why the oven light is not on.
Have you:
• Set a cooking time?
• Touched START?
Steam is normally produced during cooking. The microwave oven
has been designed to vent this steam.
Yes. Never operate the oven empty or without the glass turntable.
No. The metal screen bounces the energy back to the oven cavity.
The holes (or ports) allow only light to pass through. They do not
let microwave energy pass through.
The tone tells you that the setting has been entered.
Like any other cooking appliance, it is possible to overcook food
to the point that the food creates smoke and even possibly fire,
and damage to the inside of the oven. It is always best to be near
the oven while you are cooking.
The microcomputer controlling your oven may temporarily
become scrambled and fail to function as programmed when you
plug in for the first time or when power resumes after a power
interruption. Unplug the oven from the 120 volt household outlet
and then plug it back in to reset the microcomputer.
This light is from the oven light which is located between the
oven cavity and the outer wall of the oven.
The clicking sound is caused by a mechanical switch turning the
microwave oven’s magnetron ON and OFF.
The heavy hum and clunk is from the change in power the
magnetron draws as it is turned ON and OFF by a mechanical
switch.The change in blower speed is from the change in line
voltage caused by the magnetron being turned ON and OFF.
Answer
TROUBLESHOOTING
25
TROUBLESHOOTING
QUESTIONS AND ANSWERS (continued)
Food
Question
What is wrong when baked foods have a
hard, dry, brown spot?
Why do eggs sometimes pop?
Why are scrambled eggs sometimes a
little dry after cooking?
Is it possible to pop popcorn in a
microwave oven?
Why do baked apples sometimes burst
during cooking?
Why do baked potatoes sometimes
burn during cooking?
Why is a standing time recommended
after microwave cooking time is over?
Why is additional time required for
cooking food stored in the refrigerator?
A hard, dry, brown spot indicates overcooking. Shorten the cooking
or reheating time.
When baking, frying, or poaching eggs, the yolk may pop due to
steam build-up inside the yolk membrane. To prevent this,
simply pierce the yolk with a wooden toothpick before cooking.
CAUTION: Never microwave eggs in the shell.
Eggs will dry out when they are overcooked, even if the same
recipe is used each time. The cooking time may need to be varied
for one of these reasons:
• Eggs vary in size.
• Eggs are at room temperature one time and at refrigerator
temperature another time.
• Eggs continue cooking during standing time.
Yes, if using one of the two methods described below:
(1) microwave-popping devices designed specifically for microwave
cooking
(2) prepackaged commercial microwave popcorn that is made
for specific times and
power output needed
Follow exact directions given by each manufacturer for
its popcorn popping product and do not leave the oven
unattended while the corn is being popped. If corn fails
to pop after the suggested time, discontinue cooking.
Overcooking could result in an oven fire.
CAUTION:
• Never use a brown paper bag for popping corn or attempt to
pop leftover kernels.
The peel has not been removed from the top half of each apple to
allow for expansion of the interior of the apple during cooking. As in
conventional cooking methods, the interior of the apple expands
during the cooking process.
If the cooking time is too long, fire could result. At the end of the
recommended cooking time, potatoes should be slightly firm.
CAUTION: Do not overcook.
Standing time allows foods to continue cooking evenly for a few
minutes after the actual microwave oven cooking cycle. The
amount of standing time depends upon the density of the foods.
As in conventional cooking, the initial temperature of food affects
total cooking time. You need more time to cook food taken out of a
refrigerator than for food at room temperature.
Answer
26
BEFORE CALLING FOR SERVICE
Problem
Oven does not start
Arcing or Sparking
Incorrect time of day
Unevenly Cooked Foods
Overcooked Foods
Undercooked Foods
Improper Defrosting
You can often correct operating problems yourself. If your microwave oven fails to work properly, locate the
operating problem in the list below and try the solutions listed for each problem.
If the microwave oven still does not work properly, contact the nearest LG Authorized Service Center.
LG Authorized Service Centers are fully equipped to handle your service requirements.
• Is the power cord plugged in?
• Is the door closed?
• Is the cooking time set?
• Are you using approved cookware?
• Is the oven empty?
• Have you tried to reset the time of day?
• Are you using approved cookware?
• Is the glass turntable in the oven?
• Did you turn or stir the food while it was cooking?
• Were the foods completely defrosted?
• Was the time/cooking power level correct?
• Was the time/cooking power level correct?
• Are you using approved cookware?
• Were the foods completely defrosted?
• Was the time/cooking power level correct?
• Are the ventilation ports clear?
• Are you using approved cookware?
• Was the time/cooking power level correct?
• Did you turn or stir the food during the defrosting cycle?
WARNING
:
This equipment generates and uses ISM frequency
energy and if not installed and used properly, that is in
strict accordance with the manufacturer’s instructions,
may cause interference to radio and television
reception. It has been type tested and found to
comply with limits for ISM Equipment pursuant to part
18 of FCC Rules, which are designed to provide
reasonable protection against such interference in a
residential installation.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following:
• Reorient the receiving antenna of the radio or
television.
• Relocate the microwave oven with respect to the
receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so
that the microwave oven and the receiver are on
different branch circuits.
The manufacturer is not responsible for any radio or
TV interference caused by unauthorized
modification to this microwave oven. It is the
responsibility of the user to correct such interference.
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
Possible Causes
STATEMENT
TROUBLESHOOTING
27
WARNING:
This product contains chemicals known to the State of California
to cause cancer. Wash hands after
handling
.
w
LG Electronics, Inc. will repair or replace your product, at LG’s option, if it proves to be defective in
material or workmanship under normal use, during the warranty period set forth below, effective from the
date of original consumer purchase of the product. This warranty is good only to the original purchaser of
the product and effective only when used in the United States, including U.S. Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE
EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS
WARRANTY PERIOD ABOVE LG WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL,
INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST
REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR
OTHERWISE. Some states do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above exclusion or limitation may not apply to you. This
warranty gives you specific legal rights and you may also have other rights that vary from state to state.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
• Service trips to your home to deliver, pick up, and/or install the product, instruct, or replace house fuses or
correct wiring, or correction of unauthorized repairs.
• Damages or operating problems that result from misuse, abuse, operation outside environmental
specifications or contrary to the requirements of precautions in the Operating Guide, accident, vermin, fire,
flood, improper installation, acts of God, unauthorized modification or alteration, incorrect electrical current or
voltage, or commercial use, or use for other than intended purpose.
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer
.
CUSTOMER INTERACTIVE CENTER NUMBERS
WARRANTY PERIOD:
LABOR: One Year
from the Date of Purchase*
.
PARTS (except as listed below): One Year
from the
Date of Purchase*
.
MAGNETRON:
Ten Years from the Date of
Purchase*.
Replacement Units and Repair Parts are warranted
for the remaining portion of the original unit’s
warranty period.
* Retain your Sales Receipt to prove the date of
purchase. A copy of your Sales Receipt must be
submitted at the time warranty service is provided.
HOW SERVICE IS HANDLED:
Please call 1-800-243-0000 and choose the
appropriate option. (Phones are answered 24
hours a day, 365 days per year.) Please have
the product type (Microwave) and your ZIP code
ready.
Or visit our website at: http://us.lgservice.com
To obtain Customer Assistance, Product Infor-
mation, or Dealer or Authorized Service Center
location :
Call 1-800-243-0000 (24 hours a day, 365 days per
year) and select the appropriate option from the menu.
Or visit our website at: http://us.lgservice.com
LG MICROWAVE OVEN LIMITED WARRANTY — USA
Model LCRT1510SV
TO CONTACT LG ELECTRONICS BY MAIL:
LG Customer Interactive Center
P. O. Box 240007
201 James Record Road
Huntsville, Alabama 35824
ATTN: CIC
Printed in China
