EN
1
PRODUCT DESCRIPTION
CONTROL PANEL
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the front
of the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8.
Identification plate
(do not remove)
9. Lower heating element
(not visible)
1. LEFTHAND DISPLAY
2. ON / OFF
For switching the oven on and off
and for stopping an active function
at any time.
3. BACK
For returning to the previous menu
when configuring settings.
4. TEMPERATURE
For setting the temperature.
5. KNOB
For selecting menu items and
changing or adjusting the settings
of a function.
6. START
For starting functions and
confirming settings.
7. T I M E
For setting or changing the time
and adjusting the cooking time.
8. CONFIRM
For confirming an item you have
selected or the settings for a
function.
9. RIGHTHAND DISPLAY
DAILY REFERENCE
GUIDE
Before using the appliance carefully read the Health and Safety guide.
THANK YOU FOR PURCHASING AN
HOTPOINT PRODUCT
To receive more comprehensive help and
support, please register your product at
www.hotpoint.eu/register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website docs.hotpoint.eu and following
the instructions on the back of this booklet.
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
8
9
7
6
1 2 5 6 93 4 7 8
