Table of contents
Safety ...............................................4
General information ...........................4
Intended use......................................4
Restriction on user group...................4
Safe installation..................................5
Safe use ............................................6
Damaged appliance...........................8
Risk to children..................................9
Safety systems.................................10
Preventing material damage...........11
Safe installation................................11
Safe use ..........................................11
Childproof lock
1
..............................12
Door lock.........................................12
Environmental protection and
saving energy .................................13
Disposing of packaging ...................13
Saving energy..................................13
AquaSensor
1
....................................13
Installation and connection ............13
Scope of supply...............................13
Installing and connecting the ap-
pliance.............................................14
Drainage connection........................14
Drinking water connection................14
Electrical connection........................15
Familiarising yourself with your
appliance ........................................16
Appliance ........................................16
Controls...........................................17
Programmes ...................................19
Information for test institutes ............21
TurboSpeed 20 min ........................21
Additional functions .......................22
Features..........................................23
Top basket ......................................23
Bottom basket .................................24
Cutlery basket .................................25
Cutlery drawer .................................25
Etagere............................................26
Folding prongs ................................26
Small items holder ...........................27
Knife shelf .......................................27
Basket heights.................................27
Before using for the first time.........28
Performing initial start-up .................28
Water softening system..................28
Overview of water hardness set-
tings ................................................28
Setting water softening system.........29
Special salt ......................................29
Switching off water softening sys-
tem..................................................30
Regeneration of the water soften-
ing system .......................................30
Rinse aid system ............................31
Rinse aid .........................................31
Setting the amount of rinse aid ........31
Switching rinse aid system off ..........31
Detergent........................................32
Suitable detergents ..........................32
Unsuitable detergents ......................33
Information on detergents ................33
Adding detergent .............................33
Tableware .......................................34
Damage to glass and tableware ......34
Arranging tableware.........................35
Removing tableware ........................36
Basic operation ..............................36
Opening appliance door ..................36
1
Depending on the appliance specifications
en
3
Switching on appliance ....................36
Setting a programme .......................36
Setting additional functions ..............37
Setting timer programming...............37
Starting the programme ...................37
Interrupting programme ...................37
Terminate programme .....................37
Switching off appliance ....................37
Basic settings.................................39
Overview of basic settings ...............39
Changing basic settings...................40
Cleaning and servicing...................41
Cleaning the tub ..............................41
Self-cleaning interior
1
.......................41
Cleaning products ...........................41
Tips on appliance care ....................41
Machine Care
1
.............................41
Filter system ....................................42
Cleaning spray arms........................43
Troubleshooting .............................44
Appliance safety ..............................44
Error code / Fault display / Signal ...44
Washing results ...............................46
Information on display panel ............52
Malfunctions ....................................53
Mechanical damage ........................54
Noise...............................................54
Clean wastewater pump...................55
Transportation, storage and dis-
posal...............................................55
Removing the appliance ..................55
Protect appliance from frost .............55
Transporting the appliance...............56
Disposing of old appliance ..............56
Customer Service ...........................56
Product number (E-Nr.) and pro-
duction number (FD)........................57
AQUA-STOP guarantee
1
...................57
Technical data ................................57
1
Depending on the appliance specifications
en Safety
4
Safety
Please read the safety information to ensure that you use the ap-
pliance safely.
General information
You can find general information about this instruction manual
here.
¡ Read this instruction manual carefully. Only this ensures you will
use the appliance safely and efficiently.
¡ This manual is intended for the user of the appliance.
¡ Follow the safety instructions and warnings.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Check the appliance after unpacking it. Do not connect the ap-
pliance if it has been damaged in transit.
Intended use
Please read the information on intended use to ensure you use
the appliance correctly and safely.
Only use this appliance:
¡ As specified in this instruction manual.
¡ For cleaning household tableware.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of max. 4000m above sea level.
Restriction on user group
Avoid risks to children and vulnerable persons.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Safety en
5
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe installation
Follow these safety instructions when installing the appliance.
WARNING‒Risk of injury!
Improper installation may cause injury.
▶
When installing and connecting the appliance, follow the in-
structions in the manual and installation instructions.
WARNING‒Risk of electric shock!
Improper installation is dangerous.
▶
Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶
Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical
installation must be properly installed.
▶
Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶
When installing the appliance, check that the power cable is
not trapped or damaged.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-ap-
proved adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
en Safety
6
WARNING‒Risk of electric shock!
Cutting through the supply hose or immersing the Aqua-Stop
valve in water is dangerous.
▶
Never immerse the plastic housing in water. The plastic
housing on the supply hose contains an electric valve.
▶
Never cut through the supply hose. The supply hose con-
tains electric power cables.
WARNING‒Risk of injury!
Hinges move when opening and closing the appliance door
and can cause injury.
▶
If built-under or integrable appliances are not in a cavity so
that one side is accessible, the hinge area must be covered
at the side. Covers are available from Customer Service or
specialist outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance to tip up.
▶
Only install built-under or integrable appliances under a
continuous worktop that is securely connected to adjacent
cabinets.
WARNING‒Risk of burns!
If the appliance is not installed properly, this may result in
burns.
▶
With free-standing appliances, ensure that they are installed
with the back panel against a wall.
Safe use
Follow these safety instructions when using the appliance.
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.
▶
Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
Safety en
7
WARNING‒Risk of explosion!
¡ Adding solvents to the interior of the appliance may cause ex-
plosions.
▶
Never add solvents to the interior of the appliance.
¡ Highly caustic alkaline or highly acidic cleaning agents in con-
junction with aluminium parts in the interior of the appliance
may cause explosions.
▶
Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, e.g.
for the Machine Care programme, in conjunction with alu-
minium parts.
▶
Do not put any aluminium parts in the interior of the appli-
ance.
WARNING‒Risk of injury!
¡ Leaving the appliance door open may result in injury.
▶
Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.
▶
Do not sit or stand on the appliance door when open.
¡ Knives and utensils with sharp points can cause injuries.
▶
Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the programme is run-
ning, hot water may splash out of the appliance.
▶
Open the appliance door carefully if the programme is still
running.
WARNING‒Risk of tipping!
Overfilling the Baskets may cause the appliance to tip up.
▶
Never overfill the Baskets with free-standing appliances.
WARNING‒Risk of electric shock!
¡ An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
en Safety
8
▶
Do not use steam- or high-pressure cleaners to clean the
appliance.
¡ If the insulation of the power cord is damaged, this is danger-
ous.
▶
Never let the power cord come into contact with hot appli-
ance parts or heat sources.
▶
Never let the power cord come into contact with sharp
points or edges.
▶
Never kink, crush or modify the power cord.
Damaged appliance
Follow the safety instructions if the appliance is damaged.
WARNING‒Risk of electric shock!
¡ If the appliance or the power cord is damaged, this is danger-
ous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked or fractured sur-
face.
▶
Never pull on the power cord to unplug the appliance. Al-
ways unplug the appliance at the mains.
▶
If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.
▶
Call Customer Service. →Page56
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
¡ Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.
Safety en
9
Risk to children
Follow the safety instructions if there are children in your home.
WARNING‒Risk of suffocation!
¡ Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
¡ Children may breathe in or swallow small parts, causing them
to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
▶
With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
▶
Keep an eye on children when opening and closing the ap-
pliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.
▶
Keep children away from detergent and rinse aid products.
▶
Keep children away from the appliance when open. The wa-
ter in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.
en Safety
10
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet
collecting tray and injure themselves.
▶
Keep children away from the appliance when open.
WARNING‒Risk of suffocation!
Children may become trapped in the appliance and suffocate.
▶
Use the childproof lock if fitted.
▶
Never let children play with or operate the appliance.
Safety systems
Protect children from possible hazards resulting from the appli-
ance.
Depending on the features of the model, the appliance comes
with a
→"Childproof lock", Page12.
Preventing material damage en
11
Preventing material dam-
age
Follow these instructions to prevent
material damage to your appliance, ac-
cessories or other objects in your kit-
chen.
Safe installation
Follow the instructions when installing
the appliance.
ATTENTION!
¡ Improper installation of the appliance
may cause damage.
▶
If the dishwasher is installed
above or below other domestic
appliances, follow the information
on installation in combination with
a dishwasher in the installation in-
structions for the individual appli-
ances.
▶
If there is no information or if the
installation instructions do not in-
clude the relevant information,
contact the manufacturer of these
appliances to check that the dish-
washer can be installed above or
below these appliances.
▶
If no information is available from
the manufacturer, the dishwasher
should not be installed above or
below such appliances.
▶
To ensure the safe operation of all
domestic appliances, continue fol-
lowing the installation instructions
for the dishwasher.
▶
Do not install the dishwasher un-
der a hob.
▶
Do not install the dishwasher near
heat sources, e.g. radiators, heat
storage tanks, ovens or other ap-
pliances that generate heat.
¡ Modified or damaged water hoses
may result in material damage and
damage to the appliance.
▶
Never kink, crush, modify or cut
through water hoses.
▶
Only use the water hoses sup-
plied with the appliance or genu-
ine spare hoses.
▶
Never re-use water hoses that
have been used before.
¡ If the water pressure is too high or
too low, this may impair functioning
of the appliance.
▶
Make sure that the water pressure
in the water supply system is min.
50kPa (0,5bar) and max.
1000kPa (10bar).
▶
If the water pressure exceeds the
maximum value specified, a pres-
sure-reducing valve must be in-
stalled between the drinking water
connection and the hose set of
the appliance.
Safe use
Follow the instructions when using the
appliance.
ATTENTION!
¡ Escaping water vapour can damage
fitted units.
▶
When the programme ends, leave
the appliance to cool down for a
while before opening the door.
¡ Special salt can damage the tub due
to corrosion.
▶
To make sure that any special salt
that escapes is washed out of the
tub, add the special salt to the
dispenser for special salt immedi-
ately before the programme
starts.
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the water
softening system with special
dishwasher salt.
en Childproof lock
12
¡ Unsuitable cleaning agents may
damage the appliance.
▶
Do not use a steam cleaner.
▶
So as not to scratch the finish on
the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.
▶
To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or rinse
such cloths thoroughly several
times before using them for the
first time.
Childproof lock
1
The childproof lock lets you protect
children from possible hazards result-
ing from the appliance.
Depending on the features of the
model, the appliance comes with a
door lock.
Door lock
The door lock is a mechanical safety
system and makes it more difficult to
open the appliance door.
You can activate or deactivate the door
lock.
WARNING
Risk of suffocation!
Children may become trapped in the
appliance and thus suffocate.
▶
Activate the door lock and close the
appliance door.
→"Opening appliance door", Page36
Activating the door lock
Note:The door lock remains activated
until it is deactivated manually.
1. Open the appliance door.
2. Pull the catch of the childproof lock
forwards and close the appliance
door .
1
2
Deactivating the door lock
1. Open the appliance door.
2. Push the catch of the childproof lock
to the right and slide it backwards
.
1
2
3. Close the appliance door.
1
Depending on the appliance specifications
Environmental protection and saving energy en
13
Environmental protection
and saving energy
Help protect the environment by using
your appliance in a way that conserves
resources and by disposing of re-
usable materials properly.
Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶
Sort the individual components by
type and dispose of them separately.
Information about current disposal
methods are available from your
specialist dealer or local authority.
Saving energy
If you follow these instructions, your ap-
pliance will use less electricity and less
water.
Use the Eco 50° programme.
The Eco 50° programme is energy
efficient and environmentally
friendly.
→"Programmes", Page19
If you do not have much tableware to
wash, use the additional Half Load
function.
1
The programme will adjust to a
lower load and consumption will be
reduced.
→"Additional functions", Page22
AquaSensor
1
The AquaSensor is an optical measur-
ing device (light barrier) which meas-
ures the turbidity of the washing water.
You can save water with the Aqua-
Sensor.
Use of the AquaSensor depends on the
programme. If the soiling level is low,
the washing water is used in the next
wash cycle, so reducing water con-
sumption by 3-6 litres. If the soiling
level is is greater, the washing water is
drained off and replaced with fresh wa-
ter. In the automatic programmes the
temperature and running time are addi-
tionally adjusted to the level of soiling.
Installation and connec-
tion
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the specified
criteria and the installation instructions.
Scope of supply
After unpacking all parts, check for any
damage in transit and completeness of
the delivery.
If you have any complaints, contact the
dealer who sold you the appliance or
our Customer Service.
Note:The appliance was tested at the
factory to check it is in working order. It
is possible that water has left marks on
the appliance. These marks will disap-
pear after the first wash cycle.
The delivery consists of the following:
¡ Dishwasher
¡ Instruction manual
¡ Installation instructions
¡ Warranty
1
1
Depending on the appliance specifications
en Installation and connection
14
¡ Installation material
¡ Steam guard plate
1
¡ Rubber apron
1
¡ Mains cable
¡ Quick reference guide
1
Installing and connecting the
appliance
You can position your built-under or in-
tegrable appliance in a fitted kitchen
between wooden and plastic walls. If
you subsequently install your dish-
washer as a free-standing appliance,
you must stop it from tipping over, e.g.
by screwing it to the wall or installing it
under a continuous worktop that is se-
curely connected to adjacent cabinets.
1. Follow the safety instructions.
→Page4
2. Follow the instructions for electrical
connection. →Page15
3. Check the Scope of supply
→Page13 and the condition of the
appliance.
4. Consult the installation instructions
for the installation dimensions re-
quired.
5. Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6. Install the drainage connection.
→Page14
7. Install the drinking water connection.
→Page14
8. Connect the appliance to the electri-
city supply.
Drainage connection
Connect your appliance to drainage
connection so dirty water is discharged
via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions
supplied for the steps required here.
2. Connect the wastewater hose to the
outlet connection of the siphon using
the enclosed parts.
3. When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4. Also check that there is no cover in
the drainage system preventing the
wastewater from being discharged.
Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water
connection
Note:If you are replacing the appli-
ance, you must use a new water supply
hose.
1. Consult the installation instructions
supplied for the steps required here.
2. Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the Technical data
→Page57.
3. When doing so, check that the drink-
ing water connection is not kinked,
crushed or twisted.
1
Depending on the appliance specifications
Installation and connection en
15
Electrical connection
Connect your appliance to the power
supply.
Connecting the appliance to the
electricity supply
Notes
¡ Follow the Safety instructions
→Page5.
¡ Connect the appliance to alternating
current only, in the range of 220 -
240V and 50Hz or 60Hz.
¡ Please note that the water safety
system is only functional if there is a
power supply.
1. Insert the non-heating appliance plug
of the power cable into the appli-
ance.
2. Insert the mains plug of the appli-
ance into a nearby socket.
The connection data for the appli-
ance can be found on the rating
plate.
3. Check that the mains plug is inser-
ted properly.
en Familiarising yourself with your appliance
16
Familiarising yourself with your appliance
Familiarise yourself with the parts of your appliance.
Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
Rating plate Rating plate with E number and FD number →Page57.
The data you need for Customer Service →Page56.
1
Depending on the appliance specifications
Familiarising yourself with your appliance en
17
2
Detergent dispenser Detergent →Page32 is added to the detergent dis-
penser.
3
Bottom basket Bottom basket →Page24
4
Dispenser for special salt Add special salt for the Water softening system
→Page28 to the dispenser for special salt.
5
Lower spray arm The lower spray arm washes the tableware in the bottom
basket.
If the tableware has not been washed properly, clean the
spray arms.
→"Cleaning spray arms", Page43
6
Tablet collecting tray During the wash cycle tablets automatically fall out of the
detergent dispenser into the tablet collecting tray where
they can fully dissolve.
7
Top basket Top basket →Page23
8
Cutlery drawer
1
Cutlery drawer →Page25
9
EmotionLight
1
Interior lighting of the appliance.
→"Overview of basic settings", Page39
10
Etagere Etagere →Page26
11
Upper spray arm The upper spray arm washes the tableware in the top
basket.
If the tableware has not been washed properly, clean the
spray arms.
→"Cleaning spray arms", Page43
12
Filter system Filter system →Page42
13
Cutlery basket
1
Cutlery basket →Page25
14
Dispenser for rinse aid Add rinse aid for the Rinse aid system →Page31 to
the dispenser for rinse aid.
1
Depending on the appliance specifications
Controls
The controls are used to configure all functions of your appliance and to obtain in-
formation about the operating status.
With some buttons you can perform different functions.
en Familiarising yourself with your appliance
18
10
A B C
1 2 3 54 6 7
89
1
ON/OFF button
Switching on the appliance →Page36
Switching off the appliance →Page37
2
Programme buttons Programmes →Page19
3
Water supply display Display for water supply lights up →Page45
4
Special salt refill indicator Water softening system →Page28
5
Rinse aid refill indicator Rinse aid system →Page31
6
Programme buttons and additional func-
tions
Programmes →Page19
Additional functions →Page22
7
Start button and reset button
Starting the programme →Page37
Terminating the programme →Page37
8
Timer programming Setting timer programming →Page37
9
Door opener
1
Opening the appliance door →Page36
10
Display The display shows information about the remaining
running time or the basic settings. You can change
the basic settings via the display and the setting
buttons.
→"Changing basic settings", Page40
1
Depending on the appliance specifications
Programmes en
19
Programmes
You can find an overview of the pro-
grammes that can be selected here.
Different programmes, which can be
found on the control panel of your ap-
pliance, are available depending on the
appliance configuration.
The running time may vary depending
on the programme selected. The run-
ning time depends on the water tem-
perature, the quantity of tableware, the
level of soiling and the Additional func-
tion →Page22 selected. The running
time will change if the rinse aid system
is switched off or rinse aid needs to be
added.
The consumption values can be found
in the quick reference guide. The con-
sumption values relate to normal condi-
tions and a water hardness of 16-20°
°E. Different influencing factors such as
water temperature or pipe pressure
may result in deviations.
Programme Use Programme sequence Additional functions
Intensive 70°
Tableware:
¡ Washing pots and
pans, non-fragile
tableware and cut-
lery.
Level of soiling:
¡ Removing stubborn
burned or dried-on
food remnants con-
taining starch and
protein.
When using powder de-
tergent, you can also ap-
ply a little to the inside of
the appliance door.
Intensive:
¡ PreRinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Rinsing 69°C
¡ Drying
All
→"Additional functions",
Page22
Auto 45-65°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Sensor-controlled:
¡ Optimised by sensors
depending on the
soiling of the washing
water.
All
→"Additional functions",
Page22
Eco 50°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Most economical pro-
gramme:
¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 66°C
¡ Drying
All
→"Additional functions",
Page22
en Programmes
20
Programme Use Programme sequence Additional functions
Silence 50
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Reduced noise:
¡ PreRinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 65°C
¡ Drying
IntensiveZone
Half Load
HygienePlus
ExtraDry
Shine & Dry
→"Additional functions",
Page22
Glass 40°
Tableware:
¡ Cleaning delicate
tableware, cutlery,
temperature-sensitive
plastics, glasses and
stemware in the
stemware basket.
Level of soiling:
¡ Removing lightly ad-
hering fresh food
remnants.
Particularly gentle:
¡ PreRinse
¡ Cleaning 40°C
¡ Intermediate rinse
¡ Rinsing 60°C
¡ Drying
IntensiveZone
VarioSpeedPlus
Half Load
ExtraDry
Shine & Dry
→"Additional functions",
Page22
1 hr Programme
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Time-optimised:
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying
ExtraDry
Shine & Dry
→"Additional functions",
Page22
Quick 45°
Tableware:
¡ Cleaning delicate
tableware, cutlery,
temperature-sensitive
plastics and glasses.
Level of soiling:
¡ Removing lightly ad-
hering fresh food
remnants.
Time-optimised:
¡ Cleaning 45°C
¡ Intermediate rinse
¡ Rinsing 55°C
ExtraDry
Shine & Dry
→"Additional functions",
Page22
Programmes en
21
Programme Use Programme sequence Additional functions
TurboSpeed 20 min
Tableware:
¡ Washing pots and
pans, non-fragile
tableware and cut-
lery.
Level of soiling:
¡ Removing stubborn
burned or dried-on
food remnants con-
taining starch and
protein.
¡ Cleaning 50°-60°
¡ Final rinse 55°-65°
ExtraDry
Shine & Dry
→"Additional functions",
Page22
PreRinse
Tableware:
¡ Cleaning all types of
tableware.
Level of soiling:
¡ Cold rinsing, interme-
diate cleaning.
Cold rinse suitable:
¡ Pre-Rinse
None
Machine Care
- Machine Care 70°C None
Information for test institutes
Test institutes are provided with inform-
ation for comparability tests, e.g. ac-
cording to EN60436.
These are the conditions for conduct-
ing the tests, however they are not the
results or consumption values.
E-mail enquiries to: dishwasher@test-
appliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rating
plate on the appliance door.
TurboSpeed 20 min
TurboSpeed 20 min, an especially fast
washing programme with one-off pre-
heating. The appliance heats up for ap-
prox. 25minutes. You can then run
several fast wash cycles of 20minutes
each one after the other.
Setting TurboSpeed
Tips
¡ Use powder detergent for the pro-
gramme TurboSpeed 20 min. Tabs
will not dissolve properly in this short
time.
¡ Only load tableware in the appliance
after the heating phase.
Note:Make sure that the dispenser for
special salt and for rinse aid are always
filled and the Water softening system
→Page28 and the Rinse aid system
→Page31 are set correctly.
1. Open the appliance door.
2.
Press .
3.
Press .
a H (H=heating phase) flashes on the
display.
4.
Press .
en Additional functions
22
5. Close the appliance door.
If the appliance is loaded before the
heating phase, the length of this
phase is extended.
a A spot of light or H appears on the
floor. The heating phase of the
empty appliance starts.
6. ATTENTION! The interior is hot after
the heating phase and may cause
burns if touched.
▶
Load the tableware carefully.
Load the tableware when the spot of
light or L (L=Load) flashes.
7.
Press .
8.
If the spot of light flashes or ap-
pears and the signal tone sounds,
the wash cycle has finished.
9. Open the appliance door.
a "0:00" appears on the display.
10.Take out the tableware.
‒ L flashes on the display.
‒ For further wash cycles, load the
tableware.
‒ Press .
‒ Close the appliance door.
11.If no more wash cycles are required,
press .
12.Close the appliance door.
Additional functions
You can find an overview of the addi-
tional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configura-
tion.
Additional func-
tion
Use
VarioSpeedPlus
¡ The running time is
shortened by 20% to
66% depending on the
washing programme.
¡ Energy and water con-
sumption are increased.
Half Load
¡ Switch on with small
loads.
¡ It is recommended
adding less detergent to
the detergent dispenser
than for a full machine
load.
¡ The running time is
shortened.
¡ Energy and water con-
sumption are reduced.
HygienePlus
¡ To ensure a higher hy-
giene status for the appli-
ance and tableware, the
temperature is raised
and maintained for an ex-
tra-lengthy period.
¡ Especially suitable for
cleaning chopping
boards or baby bottles.
¡ Continuous use of this
function increases the
hygiene status.
¡ This will increase the run-
ning time and energy
consumption.
Features en
23
Additional func-
tion
Use
IntensiveZone
¡ Switch on with mixed
loads containing table-
ware with different soil-
ing levels, e.g. place very
soiled pots and pans in
the bottom basket and
normally soiled table-
ware in the top basket.
¡ The spray pressure in
the bottom basket is in-
creased and the max-
imum programme tem-
perature held longer.
This will increase the run-
ning time and energy
consumption.
ExtraDry
¡ For a better drying result
the final rinse temperat-
ure is increased and the
drying phase extended.
¡ Especially suitable for
drying plastic parts.
¡ There is a slight increase
in energy consumption
and the running time is
extended.
Shine & Dry
¡ To avoid marks and im-
prove drying, the quantity
of water is increased and
the drying phase exten-
ded.
¡ Energy consumption in-
creases.
¡ Use rinse aid.
Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model of
your appliance.
Top basket
Arrange cups and glasses in the top
basket.
a
Knife shelf
1
You can adjust the height of the top
basket to make room for larger items
of tableware.
Adjusting top basket with side
levers
To wash large items of tableware in the
baskets, adjust the shelf position of the
top basket.
1. Pull out the top basket.
2. To prevent the basket from suddenly
dropping down, hold the side of the
basket by the top edge.
3. Press in the levers on the right and
left on the outside of the basket.
1
Depending on the appliance specifications
en Features
24
The basket can then slip down
slightly.
4. Raise or lower the basket evenly to
the right level.
→"Basket heights", Page27
Check that the basket is level on
both sides.
5. Slide the basket back in.
Adjusting top basket with pairs of
rollers
To wash large items of tableware in the
baskets, adjust the shelf position of the
top basket.
1. Pull out the top basket.
2. Remove the basket.
3. Insert the basket at the right basket
height.
→"Basket heights", Page27
Check that the basket is level on
both sides.
4. Slide the basket back in.
Bottom basket
Arrange pans and plates in the bottom
basket.
a
Cutlery basket
1
Large plates up to a diameter of
31/34cm
1
can be arranged as shown.
1
Depending on the appliance specifications
Features en
25
Cutlery basket
Arrange cutlery in the cutlery basket, al-
ways without sorting it and with the
sharp points downwards.
Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and
sharp edges downwards.
You can reorganise the cutlery drawer
to make more space for longer/wider
items of cutlery.
1
Reorganising cutlery drawer
1
You can fold down the side shelves
and front prongs to make more space
for longer/wider items of cutlery.
1. To fold down a side shelf, push the
lever forwards and fold down the
side shelf .
2. To fold down the front prongs, push
the lever forwards and fold down the
prongs .
1
2
3
Tip
If you want to return the cutlery drawer
to the original position, fold the side
shelf back up until it clicks into posi-
tion.
1
Depending on the appliance specifications
en Features
26
Etagere
Use the etagere and space underneath
for small cups and glasses or for large
items of cutlery, e.g. wooden spoons or
serving cutlery.
You can adjust the height of the
etagere.
1
If you do not need the etagere, you can
fold it up.
Adjusting etagere
1
You can adjust the height of the
etagere.
1. Position the etagere vertically and
pull it upwards .
2
3
1
1
2
2. Position the etagere at a slight angle
and move to the right height .
3. Push the etagere down.
a The etagere clicks into position.
Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to posi-
tion pans, bowls and glasses better.
1
Folding down prongs
1
If you do not need the prongs, fold
them down.
1.
Push the lever forwards and fold
down the prongs .
1
2
2. To use the folding prongs again, fold
them back up.
a The folding prongs click in position.
1
Depending on the appliance specifications
Features en
27
Small items holder
Use the small items holder to position
small items of tableware, e.g. light
plastic parts.
Knife shelf
Use the knife shelf for long, sharp ob-
jects and long items of cutlery.
Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 22 cm 31 cm
2 max. ø 24.5 cm 27.5 cm
3 max. ø 27 cm 25 cm
Appliance height 81.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 16 cm 31 cm
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
Appliance height 86.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 24 cm 34 cm
2 max. ø 26.5 cm 30.5 cm
3 max. ø 29 cm 28 cm
en Before using for the first time
28
Appliance height 86.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 18 cm 34 cm
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm
Before using for the
first time
Configure the settings for initial start-
up.
Performing initial start-up
On initial start-up or after a reset to the
factory settings, you will need to make
settings.
Requirement:The appliance has been
installed and connected. →Page13
1.
Add special salt. →Page29
2.
Add rinse aid. →Page31
3. Switch on the appliance.
→Page36
4. Set the water softening system.
→Page29
5. Set the amount of rinse aid to be
dispensed. →Page31
Tip:You can change these settings
and other Basic settings →Page39 at
any time.
Water softening system
Hard water leaves limescale on the tub
and tableware and parts of the appli-
ance may become blocked.
To ensure good dishwashing results,
you can treat the water with special salt
and the water softening system. To
avoid damage to the appliance, water
with a hardness above 9 °E must be
softened.
Overview of water hardness settings
You can find an overview of the water hardness values that can be selected here.
You can find out how hard your water is from your local water company or by using
a water hardness tester.
Water hardness °E Hardness range mmol/l Setting value
0 - 8 Soft 0 - 1.1 H:00
9 - 10 Soft 1.2 - 1.4 H:01
11 - 12 Medium 1.5 - 1.8 H:02
13 - 15 Medium 1.9 - 2.1 H:03
16 - 20 Medium 2.2 - 2.9 H:04
21 - 26 Hard 3.0 - 3.7 H:05
27 - 38 Hard 3.8 - 5.4 H:06
39 - 62 Hard 5.5 - 8.9 H:07
Water softening system en
29
Note:Set the water hardness determ-
ined on your appliance.
→"Setting water softening system",
Page29
With a water hardness of 0 - 8°E you
can dispense with special salt and
switch off the water softening system.
→"Switching off water softening sys-
tem", Page30
Setting water softening sys-
tem
Set the water hardness on your appli-
ance.
1. Determine the water hardness and
the appropriate setting value.
→"Overview of water hardness set-
tings", Page28
2.
Press .
3. Hold programme button A and press
repeatedly until the display
shows H:xx.
4. Release programme button A and
.
a Programme button A flashes and the
display shows H:04.
5. Press programme button C re-
peatedly until the right water hard-
ness has been set.
6.
Press to save the setting.
Special salt
You can use special salt to soften wa-
ter.
Adding special salt
If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the pro-
gramme starts. The amount of special
salt required depends on the water
hardness: the higher the water hard-
ness, the greater the amount of special
salt required.
ATTENTION!
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the water
softening system with special
dishwasher salt.
¡ Special salt can damage the tub due
to corrosion.
▶
To make sure that any special salt
that escapes is washed out of the
tub, add the special salt to the
dispenser for special salt immedi-
ately before the programme
starts.
1. Unscrew the lid of the dispenser for
special salt and remove.
2. On initial start-up: Fill the dispenser
right up with water.
3. Note:Only use special salt for dish-
washers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dis-
penser.
a
Funnel
1
Fill the dispenser right up with spe-
cial salt. The water in the dispenser
is displaced and forced out.
1
Depending on the appliance specifications
en Water softening system
30
4. Place the lid back on the dispenser
and turn to close.
Switching off water softening
system
Note
To avoid damage to the appliance, only
switch off the water softening system in
the following cases:
¡ The water hardness is max. 26°E
and you are using combined deter-
gents with salt replacement sub-
stances. According to manufactur-
ers, combined detergents with salt
replacement substances can gener-
ally only be used up to a water hard-
ness of 26°°E without adding spe-
cial salt.
¡ The water hardness is 0 - 8°°E. You
do not need to use special salt.
1.
Press .
2. Hold programme button A and press
repeatedly until the display
shows H:xx.
3. Release programme button A and
.
a Programme button A flashes and the
display shows H:04.
4. Press programme button C re-
peatedly until the display shows
H:00.
5.
Press to save the setting.
a The water softening system is
switched off and the salt refill indic-
ator is deactivated.
Regeneration of the water
softening system
In order to obtain fault-free function of
the water softening system, the appli-
ance performs reheating of the water
softening system at regular intervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all programmes.
It will increase the run time and con-
sumption values, e.g. water and electri-
city.
Overview of consumption values with regeneration the water softening
system
Here you can find an overview of the maximum additional running time and con-
sumption values during regeneration of the water softening system.
You can find the column applicable to your model in the quick reference guide ac-
cording to its water consumption in the Eco50° programme.
Water consump-
tion in litres (de-
pending on
model)
Regeneration of
the water soften-
ing system after x
rinse cycles
Additional run-
ning time in
minutes
Additional water
consumption in
litres
Additional power
consumption in
kWh
6.5 / 6.7 8 7 5 0.05
7.5 / 7.7 7 7 5 0.05
9.5 6 7 5 0.05
above 10.5 5 7 5 0.05
The consumption values specified are
laboratory measurements determined
in accordance with the currently applic-
able standard and using the Eco 50°
programme and the factory value of the
water hardness is set to 16 - 20°E.
Rinse aid system en
31
Rinse aid system
You can use the rinse aid system and
rinse aid to get tableware and glasses
rinsed perfectly without marks.
Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish-
washers.
Adding rinse aid
If the rinse aid refill indicator lights up,
top up with rinse aid. Only use rinse aid
for domestic dishwashers.
1. Press the catch on the lid of the dis-
penser for rinse aid and lift .
1
2
2. Add rinse aid up to the max mark.
max
3. If rinse aid spills out, remove it from
the tub.
Spilled rinse aid can cause excess-
ive frothing during the wash cycle.
4. Close the lid of the dispenser for
rinse aid.
a The lid clicks into position.
Setting the amount of rinse
aid
If there are streaks or water marks on
tableware, change the amount of rinse
aid.
1.
Press .
2. Hold programme button A and press
repeatedly until the display
shows H:xx.
3. Release programme button A and
.
a Programme button A flashes and the
display shows H:04.
4. Press programme button A re-
peatedly until the display shows the
value set at the factory r:05.
5. Press programme button C re-
peatedly until the right amount of
rinse aid has been set.
– A low setting adds less rinse aid
during the wash cycle and re-
duces streaking on tableware.
– A higher setting adds more rinse
aid during the wash cycle, re-
duces water marks and improves
the drying result.
6.
Press to save the setting.
Switching rinse aid system off
If you find the rinse aid refill indicator ir-
ritating, e.g. when using combined de-
tergents with a rinse aid component,
you can switch the rinse aid system off.
Tip:The function of rinse aid is limited
with combined detergents. You will
generally get better results using rinse
aid.
1.
Press .
en Detergent
32
2. Hold programme button A and press
repeatedly until the display
shows H:xx.
3. Release programme button A and
.
a Programme button A flashes and the
display shows H:04.
4. Press programme button A re-
peatedly until the display shows the
value set at the factory r:05.
5. Press programme button C re-
peatedly until the display shows r:00.
6.
Press to save the setting.
a The rinse aid system is switched off
and the rinse aid refill indicator is de-
activated.
Detergent
Find out which detergents are suitable
for your appliance.
Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res-
ults, use separate detergent, adding
Special salt →Page29 and Rinse aid
→Page31 separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with en-
zymes. Enzymes break down starch
and remove protein. Oxygen-based
bleaching agents are generally used to
remove coloured marks, e.g. tea or
ketchup.
Note:Follow the manufacturer's instruc-
tions for each detergent.
Detergent Description
Tabs Tabs are suitable for all
cleaning functions and do
not need to be measured
out.
With shorter Programmes
tabs sometimes do not dis-
solve entirely and leave
residues of detergent. This
may impair the cleaning ef-
fect.
Powder detergent Powder detergent is recom-
mended for shorter Pro-
grammes.
The dosage can be adjusted
to the level of soiling.
Liquid detergent Liquid detergent works
faster and is recommended
for shorter Programmes
without PreRinse.
Sometimes liquid detergent
may leak out despite the de-
tergent dispenser being
closed. This is not a fault
and is non-critical if you re-
member the following:
¡ Only choose a pro-
gramme without PreR-
inse.
¡ Do not select timer pro-
gramming for starting
the programme.
The dosage can be adjusted
to the level of soiling.
Tip:Suitable detergents are available
online via our website or from Cus-
tomer Services →Page56.
Separate detergents
Separate detergents are products that
do not contain components other than
detergent, e.g. powder detergent or li-
quid detergent.
With powder and liquid detergent the
dosage can be individually adjusted to
the level of soiling of the tableware.
Detergent en
33
For better washing and drying results
and to avoid damage to the appliance,
please additionally use Special salt
→Page29 and Rinse aid →Page31.
Combined detergent
Besides conventional separate deter-
gents, a number of products are avail-
able with additional functions. These
products contain not only detergent but
also rinse aid and salt replacement
substances (3in1) and, depending on
the combination (4in1, 5in1,...), addi-
tional components such as glass pro-
tection or stainless steel cleaner.
According to manufacturers, combined
detergents generally only function up to
a water hardness of 26°°E. With a wa-
ter hardness above 26°°E you will
need to add special salt and rinse aid.
For the best washing and drying results
we recommend using special salt and
rinse aid from a water hardness of 17°
°E. If you are using combined deter-
gent, the washing programme is adjus-
ted automatically to ensure the best
possible washing and drying result.
Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Detergent Description
Hand washing-up
liquid
Hand washing-up liquid can
cause increased frothing
and damage the appliance.
Detergent contain-
ing chlorine
Chlorine residue on table-
ware may present a risk to
health.
Information on detergents
Follow the instructions on detergents in
everyday use.
¡ Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or completely
dispense with certain substances.
The cleaning effect may be restricted
here.
¡ Set the rinse aid and the water
softening system to the separate de-
tergent or combined detergent in
use.
¡ According to manufacturers, com-
bined detergents with salt replace-
ment substances can only be used
up to a certain water hardness, usu-
ally 26°E, without adding special
salt. For the best washing and drying
results we recommend using special
salt from a water hardness of 17°E.
¡ To prevent sticking, only touch deter-
gents in a water-soluble pouch with
dry hands and only ever place them
in a dry detergent dispenser.
¡ Even if the rinse aid and special salt
refill indicators light up, washing pro-
grammes will run properly with com-
bined detergents.
¡ The function of rinse aid is limited
with combined detergents. You will
generally get better results using
rinse aid.
¡ Use tablets with a special drying per-
formance.
Adding detergent
1. To open the detergent dispenser,
press the locking latch.
2. Add the detergent to the dry deter-
gent dispenser.
15 ml
25 ml
50 ml
en Tableware
34
If you are using tablets, one is
enough. Insert the tablets in a hori-
zontal position.
If you are using powder or liquid de-
tergent, follow the manufacturer's in-
structions and quantities for dosage
in the detergent dispenser.
20ml–25ml detergent is sufficient
for normal soiling. If tableware is
only lightly soiled, slightly less than
the amount of detergent specified is
usually sufficient.
3. Close the lid of the detergent dis-
penser.
a The lid clicks into position.
a The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or li-
quid detergent will spread around
the washing tank and dissolve there.
Tablets will fall into the tablet collect-
ing tray and dissolve in the right
dosage. In order to ensure that tab-
lets can dissolve evenly, do not
place any other objects in the tablet
collecting tray.
Tableware
Only clean tableware that is suitable for
dishwashers.
Note:Decorated glassware and parts
made of aluminium or silver may fade
or discolour with dishwashing. Delicate
types of glass may turn cloudy after a
few washing cycles.
Damage to glass and table-
ware
Avoid damage to glass and tableware.
Cause Recommendation
The following table-
ware is not dishwasher-
safe:
¡ Items of cutlery and
tableware made
from wood
¡ Decorated glass-
ware, antique and
hand-crafted table-
ware
¡ Plastic parts not
resistant to heat
¡ Tableware made
from copper or tin
¡ Tableware soiled
with ash, wax, lub-
ricating grease or
paint
¡ Very small items of
tableware
Only put tableware in
the dishwasher if it is
marked as dishwasher-
safe by the manufac-
turer.
Glass and tableware
was not dishwasher-
safe.
Only put glasses and
china in the dish-
washer if it is marked
as dishwasher-safe by
the manufacturer.
The chemical composi-
tion of the detergent
causes damage.
Use a detergent
marked as gentle on
tableware by the manu-
facturer.
Tableware en
35
Cause Recommendation
Highly caustic alkaline
or highly acidic clean-
ing agents, in particular
commercial or indus-
trial cleaning agents,
are not suitable for
dishwashers in con-
junction with alu-
minium.
If you are using highly
caustic alkaline or
highly acidic cleaning
agents, in particular
commercial or indus-
trial cleaning agents,
do not put aluminium
parts in the dishwasher
interior.
The water temperature
of the programme is
too high.
Select a programme
with lower temperat-
ures.
After the programme
has ended, take glass-
ware and cutlery out of
the appliance without
delay.
Arranging tableware
Arrange the tableware correctly to op-
timise the dishwashing result and pre-
vent damage to both the appliance and
tableware.
Tips
¡ Using the appliance allows you to
save energy and water compared to
washing-up by hand.
¡ See our website for examples of
how to arrange load your appliance
efficiently, free of charge.
¡ To save energy and water, do not
load more place settings than the
number specified.
→"Technical data", Page57
¡ For better washing and drying res-
ults, position items with curves or re-
cesses at an angle so the water can
run off.
1. Remove large remnants of food from
your tableware.
Prerinsing under running water is not
necessary - nor is this a good idea
in terms of saving energy.
2. Observe the following when arran-
ging tableware:
– Put heavily soiled tableware in the
bottom basket, e.g. pans. The
more powerful the spray jet, the
better the dishwashing result will
be.
– To prevent damage to tableware,
arrange it so it is stable and can-
not tip over.
– To prevent injury, arrange cutlery
with the points and sharp edges
downwards.
– Position containers with the open-
ings facing down so no water can
collect in them.
– Do not block the spray arms -
make sure that they can turn
freely.
– Do not place small parts in the
tablet collecting tray and do not
block it with tableware so as not
to obstruct the lid of the detergent
dispenser.
en Basic operation
36
Removing tableware
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.
▶
When the programme has ended, do
not empty the appliance until the
tableware has cooled down for a
while.
1. To prevent water dripping on the
tableware, unload it starting at the
bottom and working up.
2. Check the tub and accessories for
soiling and clean if necessary.
→"Cleaning and servicing",
Page41
Basic operation
You can find out everything you need
to know about operating your appli-
ance here.
Opening appliance door
1. If the childproof lock
1
is not activ-
ated, open the appliance door.
2. If the childproof lock
1
is activated,
press the catch of the lock to the
right and open the appliance door
.
2
1
Switching on appliance
▶
Press .
The Eco 50° programme is set by
default.
The Eco 50° programme is an espe-
cially environmentally friendly pro-
gramme and ideal for normally
soiled tableware. It is the most effi-
cient programme for the combina-
tion of energy/water consumption for
this type of tableware and evidences
conformity with the EU Ecodesign
Order.
If you do not perform any actions on
the appliance for 15 minutes, the ap-
pliance will automatically switch off.
Setting a programme
To adjust the wash cycle to the soiling
level of the tableware, select a suitable
programme.
▶
Press the right programme button.
→"Programmes", Page19
a The programme is set and the pro-
gramme button flashes.
1
Depending on the appliance specifications
Basic operation en
37
Setting additional functions
You can set additional functions to
complete the washing programme se-
lected.
Note:The additional functions which
can be used depend on the pro-
gramme selected.
→"Programmes", Page19
▶
Press the button for the relevant ad-
ditional function.
→"Additional functions", Page22
a The additional function is set and the
additional function button flashes.
Setting timer programming
You can delay the start of the pro-
gramme by up to 24hours.
1.
Press .
a "h:01" appears in the display.
2.
Use or to set the required start
time for the programme.
3.
Press .
a This activates timer programming.
Note:To deactivate timer program-
ming, press or repeatedly until
"h:00" appears in the display.
Starting the programme
▶
Press .
a The programme has ended when
the display shows "0:00".
Notes
¡ If you want to add more tableware
while the appliance is running, do
not use the tablet collecting tray as a
handle for the top basket. You might
touch the partially dissolved tablet.
¡ You can only change a programme
when running if you cancel it.
→"Terminate programme",
Page37
¡ The appliance switches off automat-
ically 1minute after the end of the
programme to save energy. If you
open the appliance door immedi-
ately after the programme has
ended, the appliance will switch off
after 4 seconds.
Interrupting programme
Note:When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a few
minutes and then close it. This will help
prevent excess pressure building up in
the appliance and stop the appliance
door bursting open.
1.
Press .
a The programme is saved and the ap-
pliance switches off.
2.
Press to resume the programme.
Terminate programme
To end a programme early or to switch
from a programme that has already
started, you will need to terminate it
first.
1. Open the appliance door.
2.
Press for approx.
3seconds.
3. Close the appliance door.
a The programme is terminated and
ends after approx. 1minute.
Switching off appliance
1. Please note the information on Safe
use →Page11.
2.
Press .
3. To prevent damage from dripping
water, turn the water tap off tight (not
applicable to appliances with Aqua-
Stop).
en Basic operation
38
Tip:If you press during the wash
cycle, the programme currently running
will be interrupted. When you switch
the appliance back on, the programme
continues automatically.
Basic settings en
39
Basic settings
You can configure the appliance to meet your needs.
Overview of basic settings
The basic settings depend on the features of your appliance.
Basic setting Display text Selection Description
Water hardness H:04
1
H:00 - H:07 Set the water softening system to your
water hardness.
→"Setting water softening system",
Page29
Level H:00 switches the water soften-
ing system off.
Rinse aid disp. r:05
1
r:00 - r:06 Set the amount of rinse aid to be dis-
pensed.
→"Setting the amount of rinse aid",
Page31
Switch the rinse aid system off with
level r:00.
Intensive drying d:00
1
d:00 - d:01 The temperature is increased during
the final rinse, which improves the dry-
ing result. This may increase the run-
ning time slightly.
Note:Not suitable for delicate items of
tableware.
Switch Intensive drying on "d:01" or off
"d:00".
Hot water A:00
1
A:00 - A:01 Set cold water or hot water connec-
tion. Only set the appliance to hot wa-
ter if this can be prepared with little en-
ergy and a suitable installation is avail-
able, e.g. solar heating system with cir-
culation line. The water temperature
should be at least 40°C and max.
60°C.
Switch hot water on "A:01" or off
"A:00".
1
Factory setting (may vary according to model)
en Basic settings
40
Basic setting Display text Selection Description
timeLight S:01
1
S:00 - S:02 Switch timeLight on or off.
While the programme is running,
status information is projected onto
the floor below the appliance door re-
lating to timer programming, the pro-
gramme or the time now remaining. If
the base panel is pulled forwards or if
the appliance is installed at eye level
with the cabinet front fitted flush, the
display is not visible.
The setting "S:00" switches timelight
off.
InfoLight I:01
1
I:00 - I:01 Switch InfoLight on or off.
While the programme is running, a
spot of light is projected onto the floor
below the appliance door. This light
will not be visible if the appliance is in-
stalled at eye level with the cabinet
front fitted flush. If the appliance door
is not completely closed, the spot of
light will flash. The programme has
ended when the spot of light is no
longer visible on the floor.
The setting "I:00" switches Infolightoff.
Tone volume b:02
1
b:00 - b:03 Adjustment of tone volume.
End of programme indicated by an
audible signal tone.
The setting "b:00" switches the signal
tone off.
1
Factory setting (may vary according to model)
Changing basic settings
1. Open the appliance door.
2.
Press .
3. Hold programme button A and press
repeatedly until the display
shows H:xx.
4. Release programme button A and
.
a Programme button A flashes and the
display shows H:04.
5. Press programme button A re-
peatedly until the display shows the
required setting.
6. Press programme button C re-
peatedly until the display shows the
right value.
You can change several settings.
7.
Press to save the setting.
8. Close the appliance door.
Cleaning and servicing en
41
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important to
clean and maintain it carefully.
Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
▶
Never use detergents containing
chlorine.
1. Remove any coarse soiling in the in-
terior with a damp cloth.
2. Add detergent to the detergent dis-
penser.
3. Select the programme with the
highest temperature.
→"Programmes", Page19
4. Start the programme without table-
ware. →Page37
Self-cleaning interior
1
To remove deposits, the appliance self-
cleans the interior at regular intervals.
The programme sequence is automat-
ically adjusted for self-cleaning, e.g. the
cleaning temperature is briefly in-
creased. Consumption values, e.g. wa-
ter and electricity, may also increase.
If the interior is no longer self-cleaned
adequately and deposits occur, see
this information:
→"Cleaning the tub", Page41.
Cleaning products
Only use suitable cleaning products to
clean your appliance.
→"Safe use", Page11
Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door seals,
the front of the dish-
washer and the control
panel regularly using a
damp cloth and wash-
ing-up liquid.
This ensures the parts
of the appliance will re-
main clean and hy-
gienic.
If the appliance is not
going to be used for a
while, leave the door
slightly ajar.
This will prevent un-
pleasant odours.
Machine Care
1
Deposits can cause your dishwasher to
malfunction, e.g. due to grease or
limescale. To avoid such faults and re-
duce odours, we recommend cleaning
your appliance at regular intervals.
Machine Care combined with commer-
cially available machine care products
is the right programme for the care of
your appliance.
Run Machine Care without tableware if
the indicator for Machine Care lights up
on the control panel or if advised to do
so by the display. Once you have run
the Machine Care programme, the in-
dicator goes out. If your appliance
does not have a reminder function, fol-
low the directions for use on the ma-
chine care products.
Performing Machine Care
Run the Machine Care programme if
the indicator for Machine Care lights up
on the control panel or if advised to do
so by the display.
1
Depending on the appliance specifications
en Cleaning and servicing
42
Notes
¡ Run the Machine Care programme
without any tableware in the dish-
washer.
¡ Only use suitable machine care
products specially designed for dish-
washers and not dishwasher deter-
gent. Observe the manufacturer's in-
structions.
¡ Make sure that there are no alu-
minium parts in the interior of the ap-
pliance.
¡ If you have not run Machine Care
after 3 washing cycles, the indicator
for Machine Care will go out auto-
matically.
¡ Follow the safety instructions and the
directions for use on the packagings
of the machine care products.
1. Remove any coarse soiling in the in-
terior with a damp cloth.
2. Clean filters.
3. Add the machine care product to the
appliance.
4.
Press .
5.
Press .
a The Machine Care programme is
run.
a As soon as machine care has fin-
ished, the indicator for Machine Care
goes out.
Filter system
The filter system removes coarse soil-
ing from the dishwashing cycle.
1
2
3
1
Micro filter
2
Fine filter
3
Coarse filter
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1. After each wash check the filters for
residue.
2. Turn the coarse filter anticlockwise
and remove the filter system .
‒ Check that no foreign objects fall
into the sump.
1
2
3. Pull down the micro filter to remove.
4.
Press the locking catches to-
gether and lift the coarse filter out .
Cleaning and servicing en
43
1
2
5. Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
6. Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7. Insert the filter system into the appli-
ance and turn the coarse filter clock-
wise.
Make sure that the arrow markings
match up.
Cleaning spray arms
Limescale and soiling in the dishwash-
ing water may block the nozzles and
bearings on the spray arms. Clean the
spray arms regularly.
1.
Unscrew the upper spray arm and
pull down to remove .
1
2
2. Pull up the lower spray arm to re-
move.
3. Check the outlet nozzles on the
spray arms for blockages under run-
ning water and remove any foreign
bodies.
4. Insert the lower spray arm.
a The spray arm clicks into position.
5. Insert the upper spray arm and
screw it firmly in place.
en Troubleshooting
44
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting in-
formation before contacting Customer Service. This will avoid unnecessary costs.
WARNING
Risk of electric shock!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced with a spe-
cial connection cable, which is available from the manufacturer or his Customer
Service.
Appliance safety
Errors Cause Troubleshooting
Appliance door will not open
or cannot be opened easily.
Childproof lock is activated.
▶
Open the appliance door. →Page36
Error code / Fault display / Signal
Errors Cause Troubleshooting
E:12 lights up. Heating element is furred up. 1. Descale the appliance.
2. Operate the appliance with the Water
softening system.
E:14 lights up. Water protection system is ac-
tivated.
1. Turn off the water tap.
2. Call Customer Service →Page56.
E:15 lights up. Water protection system is ac-
tivated.
1. Turn off the water tap.
2. Call Customer Service →Page56.
E:16 lights up. Water is continuously running
into the appliance.
1. Turn off the water tap.
2. Call Customer Service →Page56.
E:18 or indicator for water
supply lights up.
Supply hose is kinked.
▶
Install the supply hose without kinks.
Water tap is turned off.
▶
Turn on the water tap.
Water tap is jammed or furred
up.
▶
Turn on the water tap.
The flow rate must be at least 10 l/
min when the water supply is open.
Filter in the water supply is
blocked.
1. Switch off the appliance.
2. Pull out the mains plug.
3. Turn off the water tap.
4. Unscrew the water connection.
Troubleshooting en
45
Errors Cause Troubleshooting
E:18 or indicator for water
supply lights up.
5. Remove the filter from the supply
hose
6. Clean the filter.
7. Re-insert the filter in the supply hose.
8. Screw the water connection back on.
9. Check the water connection for leaks.
10. Restore the power supply.
11. Switch the appliance on.
E:22 lights up. Filters are soiled or blocked.
▶
Clean the filters.
→"Cleaning filters", Page42
E:24 lights up. Wastewater hose is blocked
or kinked.
1. Reposition the wastewater hose
without kinks.
2. Remove residues.
Siphon connection is still
sealed.
▶
Check the connection to the siphon
and open if necessary.
Cover of the wastewater
pump is loose.
▶
Secure the cover of the Wastewater
pump →Page55 so it clicks into
position.
E:25 lights up. Wastewater pump is blocked.
▶
Clean the wastewater pump.
→"Clean wastewater pump",
Page55
Cover of the wastewater
pump is loose
▶
Secure the cover of the Wastewater
pump →Page55 so it clicks into
position.
E:27 lights up. Mains voltage is too low. This is not a fault on the appliance.
1. Contact an electrician.
2. Have the mains voltage and electrical
installation checked by an electrician.
en Troubleshooting
46
Errors Cause Troubleshooting
Another error code appears
on the display.
E:01 to E:30
A technical fault is present. 1.
Press .
2. Unplug the appliance or switch off the
fuse.
3. Wait at least 2minutes.
4. Insert the mains plug of the appliance
in a socket or switch on the fuse.
5. Switch the appliance on.
6. If the problem occurs again:
‒ Press .
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact Customer Service
→Page56 and give the er-
ror code.
Washing results
Errors Cause Troubleshooting
Tableware is not dry. No rinse aid used or dosage
set too low.
1. Add Rinse aid →Page31.
2. Set the amount of rinse aid to be dis-
pensed.
Selected programme has no
drying phase
▶
Select a programme with drying.
Water collects in recesses of
the tableware or cutlery.
▶
Position tableware at an angle where
possible.
The combined detergent used
has a poor drying perform-
ance.
1. Use rinse aid to improve drying per-
formance.
2. Use a different combined detergent
with a better drying performance.
Extra Dry not activated to im-
prove drying performance.
▶
Activate Extra Dry.
Troubleshooting en
47
Errors Cause Troubleshooting
Tableware is not dry. Tableware removed too early
or drying process not yet
ended.
1. Wait until the programme ends.
2. Only remove tableware 30minutes
after the programme has ended.
Rinse aid used has a limited
drying performance.
▶
Use a name-brand rinse aid.
Eco products may have limited effect-
iveness.
Plastic tableware is not dry. Not a fault. As plastic does not
store heat so well, it also does
not dry as well.
▶
No remedial action possible.
Cutlery is not dry. Cutlery not arranged properly
in the cutlery basket or cutlery
drawer.
1. Arrange the cutlery properly.
→"Arranging tableware", Page35
2. Arrange cutlery individually where
possible.
3. Avoid points of contact.
Appliance interior still wet
after wash cycle.
Not a fault. The condensation
drying principle causes water
droplets in the tub – they are
indeed desirable here. The
moisture in the air condenses
on the inside walls, runs off
and is pumped out.
No action required.
Remnants of food on table-
ware.
Tableware was placed too
close together.
1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
Basket is overfilled. 1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
Spray arm rotation is blocked.
▶
Arrange tableware so that it does not
obstruct spray arm rotation.
Spray arm nozzles are
blocked.
▶
Clean the Spray arms →Page43.
Filters are soiled.
▶
Clean the filters.
→"Cleaning filters", Page42
Filters are inserted incorrectly
and/or not engaged.
1. Insert the filters properly.
→"Filter system", Page42
2. Engage the filters.
en Troubleshooting
48
Errors Cause Troubleshooting
Remnants of food on table-
ware.
Washing programme selected
too weak.
▶
Select a more intensive washing pro-
gramme.
▶
Adjust the sensitivity of the sensors.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
Tall narrow receptacles in
corner areas are not rinsed
adequately.
▶
Do not position tall narrow recept-
acles at too great an angle or in
corner areas.
Top baskets on right and left
are not set to same height.
▶
Set the top baskets on the left and
right to the same level.
→"Top basket", Page23
Detergent residue in the appli-
ance
Lid of the detergent dispenser
is blocked by items of table-
ware parts and will not open.
1. Arrange tableware in the top basket
tableware so the tab collecting tray is
not obstructed by tableware.
→"Arranging tableware", Page35
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fragrance
dispensers in the tablet collecting
tray.
The lid of the detergent dis-
penser is blocked by the tab
and will not open.
▶
Position the tab in the detergent dis-
penser crosswise, not vertically.
Tabs are used in the quick or
short programme. Dissolving
time of the tab is not attained.
▶
Select a more intensive Programme
or use Powder detergent →Page32.
Washing effect and dissolving
performance are reduced
after a prolonged storage time
or detergent is very lumpy.
▶
Change your detergent →Page32.
Water marks on plastic parts. Due to laws of physics droplet
formation on plastic surfaces
is unavoidable. After drying
water marks are visible.
▶
Select a more intensive programme.
▶
Position tableware at an angle.
→"Arranging tableware", Page35
▶
Use rinse aid.
→"Rinse aid", Page31
▶
Set the water softening system
higher.
Troubleshooting en
49
Errors Cause Troubleshooting
Wipeable or water-soluble
coatings are present inside
the appliance or on the door.
Detergent substances are de-
posited there. These coatings
cannot generally be removed
with chemicals.
▶
Change your detergent →Page32.
▶
Clean the appliance mechanically.
White coating is deposited in
the appliance interior.
1. Set the water softening system cor-
rectly.
In most cases you will need to in-
crease the setting.
2. Change your detergent if required.
Special salt dispenser is not
screwed tight.
▶
Screw the special salt dispenser tight.
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Detergent substances are de-
posited there. These coatings
cannot generally be removed
with chemicals.
▶
Change your detergent →Page32.
▶
Clean the appliance mechanically.
The hardness range is set in-
correctly or the water hard-
ness is greater than 62°°E
(8,9mmol/l).
▶
Set the Water softening system
→Page28 to the water hardness or
add special salt.
3in1/organic/eco detergent is
not effective enough.
▶
Set the Water softening system
→Page28 to the water hardness
and use separate detergents (propri-
etary detergent, special salt, rinse
aid).
Too little detergent is being
used.
▶
Increase the amount of detergent
used or change Detergent
→Page32.
Washing programme selected
too weak.
▶
Select a more intensive washing pro-
gramme.
▶
Adjust the sensitivity of the sensors.
Tea residue or lipstick marks
on tableware.
Washing temperature is too
low.
▶
Select a programme with a higher
washing temperature.
Too little detergent is being
used or is unsuitable.
▶
Use a suitable Detergent →Page32
and follow the manufacturer's instruc-
tions for the amount to be used.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
en Troubleshooting
50
Errors Cause Troubleshooting
Coloured coatings (blue, yel-
low, brown) that are difficult or
impossible to remove are
present inside the appliance
or on stainless steel table-
ware.
The formation of films is due
to substances contained in ve-
getables (cabbage, celery,
potatoes, noodles, etc.) or tap
water (manganese).
▶
Clean the appliance.
You can remove deposits with Mech-
anical cleaning →Page41 or a ma-
chine cleaning product. It may not al-
ways be possible to completely re-
move deposits but they are harmless
to health.
The formation of films is due
to metal components on silver
or aluminium tableware.
▶
Clean the appliance.
You can remove deposits with Mech-
anical cleaning →Page41 or a ma-
chine cleaning product. It may not al-
ways be possible to completely re-
move deposits but they are harmless
to health.
Coloured deposits (yellow, or-
ange, brown) that are easy to
remove are present inside the
appliance (mainly at the bot-
tom).
The formation of films is due
to ingredients of food rem-
nants and tap water (limes-
cale) "soaplike".
1. Check the setting of the water soften-
ing system.
→"Setting water softening system",
Page29
2. Add special salt.
→"Adding special salt", Page29
3. If you are using combined detergents
(tabs), activate the water softening
system.
Follow the information about deter-
gents.
→"Information on detergents",
Page33
Plastic parts inside the appli-
ance are discoloured.
Plastic parts inside the appli-
ance may become discol-
oured during the life of the
dishwasher.
▶
Discolouration can come about and
will not impair functioning of the ap-
pliance.
Plastic parts are discoloured. Washing temperature is too
low.
▶
Select a programme with a higher
washing temperature.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
Removable streaks are
present on glasses, glassware
with a metallic appearance
and cutlery.
Amount of rinse aid to be dis-
pensed is set too high.
▶
Set the rinse aid system to a lower
setting.
No rinse aid has been added.
▶
→"Adding rinse aid", Page31
Troubleshooting en
51
Errors Cause Troubleshooting
Removable streaks are
present on glasses, glassware
with a metallic appearance
and cutlery.
Detergent residue is present
in the final rinse. Lid of the de-
tergent dispenser is blocked
by tableware items and will
not open fully.
1. Arrange tableware in the top basket
tableware so the tab collecting tray is
not obstructed by tableware.
→"Arranging tableware", Page35
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fragrance
dispensers in the tablet collecting
tray.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
Irreversible clouding of glass-
ware.
Glasses are not dishwasher-
proof, only suitable for dish-
washers.
▶
Use dishwasher-proof glasses.
▶
Avoid a lengthy steam phase (stand-
ing time after wash cycle ends).
▶
Use a programme with a lower tem-
perature.
▶
Set the softening system to the water
hardness.
▶
Use detergent with a glass protection
component.
Rust spots on cutlery. Cutlery is not sufficiently rust-
resistant. Knife blades are of-
ten more severely affected.
▶
Use rust-resistant tableware.
Cutlery may also rust if
washed together with rusting
items.
▶
Do not wash rusting items.
Salt content in washing water
is too high.
1. Remove any spilled special salt from
the tub.
2. Screw the cap of the special salt dis-
penser on tight.
Detergent residue is present
in the detergent dispenser or
the tablet collecting tray.
Spray arms were blocked by
tableware so detergent was
not rinsed out.
▶
Check that the spray arms are not
blocked and can rotate freely.
Detergent dispenser was
damp when detergent was ad-
ded.
▶
Only add detergent to a detergent dis-
penser when dry.
en Troubleshooting
52
Errors Cause Troubleshooting
Excessive formation of foam
occurs.
Hand washing-up liquid is
present in dispenser for rinse
aid.
▶
Immediately add rinse aid to the dis-
penser.
→"Adding rinse aid", Page31
Rinse aid has been spilled.
▶
Remove the rinse aid with a cloth.
Detergent or appliance care
product used causes excess-
ive foaming.
▶
Change the brand of detergent.
Information on display panel
Errors Cause Troubleshooting
Special salt refill indicator
lights up.
Insufficient special salt.
▶
Add Special salt →Page29.
Sensor does not detect spe-
cial salt tablets.
▶
Do not use special salt tablets.
Refill indicator for special salt
does not light up.
Water softening system is
switched off.
▶
Setting water softening system
→Page29
Refill indicator for rinse aid
lights up.
Insufficient rinse aid. 1. Add Rinse aid →Page31.
2. Set the amount of rinse aid to be dis-
pensed.
Refill indicator for rinse aid
does not light up.
Rinse aid system is switched
off.
▶
→"Setting the amount of rinse aid",
Page31
L or H appears on the digital
display.
Not a fault.
▶
Consult the description for the
TurboSpeed programme.
Display flashes. Appliance door is not closed
properly.
▶
Close the appliance door.
‒ Arrange the tableware so that
no parts project beyond the
basket and prevent the appli-
ance door from closing prop-
erly.
Machine Care indicator lights
up.
Machine care is recommen-
ded.
▶
Run the Machine Care programme
without tableware.
‒ Use a special machine care
product.
The indicator will go out automatically
after 3 wash cycles whether Machine
Care is carried out or not.
Troubleshooting en
53
Malfunctions
Errors Cause Troubleshooting
Water is left in the appliance
at the end of the programme.
Filter system or area under
the filters is blocked.
1. Clean the Filters →Page42.
2. Clean the Wastewater pump
→Page55.
Programme has not yet
ended.
▶
Wait until the programme ends or
cancel the programme with reset.
▶
→"Terminate programme", Page37
Appliance cannot be switched
on or operated.
Appliance functions have
failed.
1. Pull out the mains plug or switch off
the fuse.
2. Wait at least 2minutes.
3. Connect the appliance to the power
supply.
4. Switch the appliance on.
Appliance does not start. The mains fuse has tripped.
▶
Check the relevant fuse.
Mains cable is not inserted. 1. Check whether the socket works.
2. Check whether the mains cable is
properly inserted in the socket and on
the rear of the appliance.
Appliance door is not closed
properly.
▶
Close the appliance door.
Programme starts automatic-
ally.
You did not wait until pro-
gramme ended.
▶
→"Terminate programme", Page37
Appliance stops during the
programme or cuts out.
Appliance door is not closed
properly.
▶
Close the appliance door.
Power and/or water supply
has been interrupted.
1. Check the power supply.
2. Check the water supply.
Top basket is pressing against
inner door and preventing ap-
pliance door from being
closed securely.
▶
Check whether the rear panel of the
appliance is being pressed in by a
socket or hose holder that has not
been removed.
▶
Arrange the tableware so that no
parts project beyond the basket and
prevent the appliance door from clos-
ing properly.
en Troubleshooting
54
Mechanical damage
Errors Cause Troubleshooting
Appliance door cannot be
closed.
Door lock has been activated.
▶
Close the appliance door with greater
force.
Door cannot be closed due to
installation method.
▶
Check whether the appliance has
been installed properly.
When closed, the appliance door, its
decor or attached parts should not
knock against adjacent cabinets or
the worktop.
Lid on the detergent dis-
penser cannot be closed.
Detergent dispenser or lid are
blocked by sticky detergent
residue.
▶
Remove detergent residue.
Noise
Errors Cause Troubleshooting
Filling valves making knock-
ing noises.
Caused by the domestic in-
stallation. No appliance fault
present. Does not affect func-
tioning of the appliance.
▶
Can only be remedied in the domestic
installation.
Knocking or rattling noise. Spray arm is striking table-
ware.
▶
Arrange tableware so that the spray
arms do not strike tableware.
With a small load the water
jets directly strike against the
tub.
▶
Distribute the tableware evenly.
▶
Load the appliance with more table-
ware.
Light items of tableware move
about during the wash cycle.
▶
Position light items of tableware se-
curely.
Transportation, storage and disposal en
55
Clean wastewater pump
Large remnants of food or foreign bod-
ies can block the wastewater pump. As
soon as the washing water no longer
drains properly, the wastewater pump
must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or frag-
ments of glass may block the waste
water pump and cause injury.
▶
Remove any foreign bodies carefully.
1. Disconnect the appliance from the
power supply.
2. Remove the top and bottom basket.
3. Remove the filter system.
4. Scoop out any water.
Use a sponge if necessary.
5. Prise off the pump cover using a
spoon and grip it by the crosspiece.
6. Lift the pump cover inwards at an
angle and remove.
7. Remove any remnants of food and
foreign bodies in the area of the im-
peller.
8.
Insert the pump cover and press
down .
1
2
a The pump cover clicks into position.
9. Install the filter system.
10.Insert the top and bottom basket.
Transportation, storage
and disposal
You can find out here how to prepare
your appliance for transportation and
storage. You will also find out how to
dispose of old appliances.
Removing the appliance
1. Disconnect the appliance from the
power supply.
2. Turn off the water tap.
3. Detach the drainage connection.
4. Detach the drinking water connec-
tion.
5. Loosen any screws fastening the ap-
pliance to cabinet parts.
6. Remove the base panel if fitted.
7. Pull the appliance out carefully,
along with the hose behind it.
Protect appliance from frost
If there is a risk of frost where the appli-
ance will be standing, e.g. in a holiday
home, empty the appliance completely.
▶
Empty the appliance. →Page56
en Customer Service
56
Transporting the appliance
To avoid damage to the appliance,
empty it before transporting.
Note:Always transport the dishwasher
upright to prevent residual water get-
ting into the machine's controls and
damaging the appliance.
1. Remove tableware from the appli-
ance.
2. Secure loose parts.
3. Turn on the water tap.
4.
Switch on appliance. →Page36
5. Select the programme with the
highest temperature.
→"Programmes", Page19
6.
Start the programme. →Page37
7. To drain the appliance, terminate the
programme after approx. 4minutes.
→"Terminate programme", Page37
8.
Switch off the appliance. →Page37
9. Turn off the water tap.
10.To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
Disposing of old appliance
Valuable raw materials can be re-
claimed by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the ap-
pliance, thereby putting their lives at
risk.
▶
With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair so
that the appliance door will no
longer close.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an envir-
onmentally friendly manner.
This appliance is labelled in ac-
cordance with European Directive
2012/19/EU concerning used
electrical and electronic appli-
ances (waste electrical and elec-
tronic equipment - WEEE).
The guideline determines the
framework for the return and re-
cycling of used appliances as ap-
plicable throughout the EU.
Customer Service
If you have any queries, are unable to
rectify faults on the appliance yourself
or if your appliance needs to be re-
paired, contact Customer Service.
You can solve many problems yourself
by consulting the information on
troubleshooting in these instructions or
on our website. If this is not the case,
contact our Customer Service.
We will always find an appropriate solu-
tion and try to avoid unnecessary visits
being made by a Customer Service
technician.
With any warranty claims we will make
sure that your appliance is repaired by
trained Customer Service technicians
using genuine spare parts, including
after the manufacturer's warranty has
expired.
For safety reasons repairs to the appli-
ance should only be carried out by
trained specialist staff. The warranty
claim becomes void if repairs or inter-
ventions have been carried out by per-
sons not authorised by us for that pur-
pose or if our appliances have been fit-
ted with spare, supplementary or ac-
cessory parts that were not genuine
parts and then resulted in a defect.
Technical data en
57
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on which
your appliance was placed on the mar-
ket within the European Economic
Area.
Note:Under the terms of the manufac-
turer's warranty the use of Customer
Service is free of charge.
Detailed information about the warranty
period and terms of warranty in your
country are available from Customer
Service, your dealer or our website.
When contacting Customer Service,
you will need the product number (E-
Nr.) and the production number (FD) of
your appliance.
The contact details for Customer Ser-
vice can be found in the enclosed Cus-
tomer Service directory or on our web-
site.
Product number (E-Nr.) and
production number (FD)
The product number (E-Nr. ) and the
production number (FD) can be found
on the rating plate of the appliance.
The rating plate is located inside the
appliance door.
Make a note of your appliance's details
and the Customer Service telephone
number to find them again quickly.
AQUA-STOP guarantee
1
In addition to warranty claims against
the seller under the purchase agree-
ment and in addition to our manufac-
turer's warranty, we will provide a re-
placement under the following condi-
tions.
¡ If our Aqua-Stop system is defective
and causes water damage, we will
make good the damage for private
users. To ensure protection from wa-
ter damage, the appliance must be
connected to the power supply.
¡ The liability guarantee is valid for the
service life of the appliance.
¡ A claim can only be made under the
guarantee if the appliance has been
correctly installed and connected
with Aqua-Stop according to our in-
structions; this also includes cor-
rectly fitting the Aqua-Stop extension
(genuine accessory). Our guarantee
does not cover defective supply
lines or fittings up to the Aqua-Stop
connection on the tap.
¡ If your appliance is fitted with Aqua-
Stop, you can leave your appliance
unattended during operation and the
tap turned on afterwards. The tap
only needs to be turned off if you are
away from home for a long period,
e.g. on holiday for several weeks.
Technical data
Facts and figures for your appliance
can be found here.
Weight Max.: 60kg
Voltage 220 - 240V, 50Hz or
60Hz
Power rating 2000 - 2400W
Fuse 10 - 16A
1
Depending on the appliance specifications
en Technical data
58
Power consumption Off mode/standby
mode: 0.10W
Left-on mode: 0.10W
Networked standby: -
W
Time in left-on mode:
0min
Time after which appli-
ance is switched to net-
worked standby mode:
-min
Complies with the
latest regulations (EU)
for energy label and
ecological design at
the time of placing on
the market.
Additional functions
and settings may in-
crease power con-
sumption and times.
Water pressure ¡ Min. 0.05MPa
(0.5bar)
¡ Max. 1MPa
(10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
Hot water max.: 60°C
Capacity 12-15place settings
More information about your model can
be found online at https://www.bsh-
group.com/energylabel
1
. This web ad-
dress is linked to the official EU EPREL
product database. At the time of print-
ing its web address had not yet been
published. Please then follow the in-
structions on searching for models. The
model identifier is made up of the char-
acters before the slash in the product
number (E-Nr. ) on the rating plate. Al-
ternatively you can also find the model
identifier in the first line of the EU en-
ergy label.
1
Only applies to countries in the European Economic Area
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service direct-
ory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001426281*
9001426281 (990606) 642 MV
en
