8 Bottle Drinks Cooler
User Guide
Model number:
RH8WC2
For Customer Services & Spare Parts please call 0345 208 8750
or visit us at https://mda.russellhobbs.com
IMPORTANT:
RETAIN FOR FUTURE REFERENCE
Contents
Safety
Instructions
………………………………………
. 3-5
Electrical
Safety
………………………………………
. 5
Transportation and Handling
………………………………………
. 5
In
stalling and Switching on Your Appliance
………………………………………
. 6
Before
Switching On
………………………………………
. 7
Your
Appliance and the Compartments
……………………………
.………… 8
Unit
& Spare Parts
……………………………………….
8
Where
to Put Your Appliance
………………………………………
. 9
Installation
………………………………………
. 10
Usage
Information
……………………………………….
11
–
12
Cleaning
and Maintenance
………………………………
.……… 13
Bulb
Replacement
………………………………………
. 13
Important
Notes
…………………………
.…………… 13
Connection
to the Mains Supply
……………………………
.………… 14
Reversing
the Door
………………………………………
. 15
Troubleshooting
………………………………………
.
16
–
17
Guarantee
………………………………………
. 18
Technical
specification
………………………………………
. 19
Safety Instructions
This appliance is a Semi-conductor electric refrigerating appliance, which is a
Category 10 other appliance, according to ErP 643/2009. Its design temperature is
17°C.
Important note: Please read this booklet before installing and switching on this
appliance. The manufacturer assumes no responsibility for incorrect installation
and usage as described in this booklet.
Warning: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
Warning: Do not locate multiple portable socket-outlets or portable power
suppliers at the rear of the appliance.
• Do not obstruct ventilation openings in the appliance
• The appliance must not be placed or rested on its power cord.
• Do not use mechanical devices or other artificial means to accelerate the
defrosting process, such as a heater or a hair dryer.
• Do not use electrical appliances in the appliance compartment of the
appliance.
• If this appliance is to replace an old appliance with a lock, the lock must be
removed as a safety measure before storing it or disposing of it. This is to
protect children from locking themselves inside the appliance.
• Old refrigerators and freezers contain insulation gases and refrigerant, they
must be disposed of properly. Contact your local authority or your dealer if
you have any questions. Please ensure that you do not damage the scrap unit
prior to being picked-up by the relevant waste disposal service.
• Do not use adaptors or extension leads when connecting the appliance to the
electrical power supply
• Do not plug in damaged plugs.
• Do not pull, twist or damage the power cable.
3
• Do not plug-in or un-plug the appliance with wet hands to prevent electrical
shock.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance.
• Children aged from 3 to 8 years are allowed to load and unload this appliance.
• This appliance is designed to be used by adults, do not allow children to play
with the appliance or let them hang over the door.
• Do not place explosive or flammable material in your appliance for your own
safety.
• Bottles containing a high percentage of alcohol must be sealed well and placed
vertically in the appliance.
• Do not cover the body or the top of the appliance
• Fix down the accessories in the appliance during transportation to prevent
damage to them.
• To avoid contamination of food, please respect the following instructions
• Opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance.
• Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
• Clean water tanks if they have not been used for 48h; flush the water
system connected to a water supply if water has not been drawn for 5
days.
• Store raw meat and fish in suitable containers in the appliance, so that
it is not in contact with or drip onto other food.
• Two-star frozen-food compartments(if they are presented in the
appliance) are suitable for storing pre-frozen food, storing or making
ice-cream and making ice cubes.
4
• One-, two- and three -star compartments (if they are presented in the
appliance) are not suitable for the freezing of fresh food.
• If the appliance is left empty for long periods, switch off, defrost, clean,
dry and leave the door open to prevent mount developing within the
appliance.
Electrical Safety
THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET
• Before switching on, make sure that the voltage of your electricity supply is the
same as that indicated on the rating plate. This product is designed to operate
on 220 – 240V AC; 50Hz. Connection to any other power source may damage
the unit.
• This product may be fitted with a non re-wireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
• If the plug has to be changed because it is not suitable for your socket, or
becomes damaged in any way, it should be cut off and an appropriate plug
fitted following the wiring instructions. This should be carried out by a qualified
electrician. The plug removed must be disposed of safely, as insertion into a 13
Amp socket is likely to cause an electrical hazard.
Transportation and Handling
For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the
base and rear corners of cabinet. Lift the appliance carefully. Never use the door
handles for lifting. To move the appliance on a flat level surface, tilt it slightly
backwards and push backwards.
This unit is heavy and could cause injury – ensure there are adequate people
present to move the appliance.
5
Installing and Switching on Your Appliance
• Operating voltage for your appliance is 220-240V at 50Hz.
• Before plugging in the power supply, ensure that the voltage on the rating label
corresponds to the working voltage of your electrical system in your home.
• Insert the plug into an efficient Ground (Earth) connection. If the socket has no
Ground (Earth) contact or the plug does not match, we suggest you call an authorised
electrician for assistance.
• Place your appliance in an area that is not exposed to direct sunlight.
• Your appliance should be placed at least 10cm away from stoves, ovens and other
heating cores.
• This appliance should never be used outdoors or left in the rain.
• When your appliance is placed next to a chest freezer or freezer, there should be at
least 10cms between them to prevent humidity on the outer surface.
• Do not place anything on your appliance and install the unit in a suitable place so that
there is at least 30cm clearance above the appliance.
• If placing your appliance next to kitchen cabinets, leave 5cm between them.
• The rear of the appliance should be at least 6cm away from the back wall.
• The appliance must be used in the vertical position and on a flat surface.
• To level the appliance, use the adjustable feet on the appliance.
• Do not place your appliance on a carpeted surface as this will prevent adequate
ventilation.
• This appliance should only be placed on a flat, firm surface.
• Choose a dry and well-ventilated space.
• The appliance should be positioned so that the plug is easily accessible.
• If you need help or are unsure how to install the unit, please contact Customer
Services on 0345 208 8750 or visit https://mda.russellhobbs.com.
WARNING! During using, service and disposal the appliance, please
pay attention to symbol similar to one shown, which is located on rear
of appliance (rear panel) and with a yellow or orange colour. It’s risk of
fire warning symbol. There are flammable materials in appliance.
Please be far away fire source during using, service and disposal.
6
Before Switching On
• Before using your appliance, add a teaspoon of bicarbonate of soda to warm
water and with a damp cloth wipe down all parts of the new appliance, then
repeat the process with a clean damp cloth and dry. (ensure the appliance is
not connected to the power when performing this task).
• Remove all transport tapes and foam protection pieces . Clean the interior with
a cloth dampened in lukewarm soap and water. Wipe with clean water and
wipe dry.
• There may be an odour when you first switch on the appliance, it will disappear
when the appliance starts to cool.
• When the appliance has been positioned, adjust the feet to ensure the unit is
stable. This is essential to ensure quiet running and proper door
opening/closing.
• Connect to the electrical socket set the thermostat to the required setting and
switch on the power. The appliance will begin to work. Close the door
• To save energy, you should minimize the frequency and duration of door
opening.
7
1. Light
2. Fan
3. Shelves
4. Feet
5. Water box
6. Door window
7. Seal
8. Door frame
9. Temperature adjustment
buttons
10. LED display
11. Light switch
Your Appliance and the Compartments
Partsmay vary accordingto the appliance model.
8
1
2
10
9
6
3
4
11
Spare Parts
For spare parts please contact customer service on
0345 208 8750 or visit https://mda.russellhobbs.com
Item Quantity
Shelf 4
Instruction Booklet 1
5
8
7
Where to put your appliance
This appliance should only be placed on a flat, solid surface.
Do not place your appliance on a carpeted surface as this will prevent
adequate ventilation.
Choose a dry and well-ventilated space. No less than 50mm (5cms) must be left
around the sides and 100mm (10cms) around the back of the appliance to allow
sufficient cooling.
Choose a location away from a heat source, e.g. direct sunlight, a radiator or
oven, etc.
The appliance should be positioned so that the plug is easily accessible.
9
(5cms)
(10cms)
(5cms)
Installation
• The unit should be kept away from direct sunlight.
• Remove all transport tapes and foam protection pieces. Clean the
interior of the appliance with a cloth dampened in lukewarm soap and
water. Wipe with clear water and wipe dry.
• When the appliance has been positioned, adjust the adjustable foot at
the front of the appliance to ensure the unit is stable. This is essential to
ensure quiet running and proper door opening /closing. See figure
below.
• Plug in the cooler and adjust the temperature to the required level by
the temperature adjustment buttons. Close the door.
• Leave the appliance for a minimum of 3 hours for the correct
temperature to be reached before placing bottles inside.
10
Usage Information
Thermostat Setting
Note: The temperature of the freshly stored bottles and how often the door is
opened affects the temperature in the compartment. If required, change the
temperature setting.
• When you first switch on the appliance, to enable suitable cooling, the appliance
should work 24 hours continuously until it cools down to sufficient temperature.
• During this time do not open the door frequently or place a lot of bottles inside
the appliance.
• If the unit is switched off or unplugged, you must allow at least 5 minutes before
restarting or re-plugging the unit.
• Temperature selection - The temperature of the appliance is controlled manually by the
temperature adjustment arrow buttons. To alter the temperature, press the up or down
arrow on the control panel. The LED display will increase or decrease by one degree at a
time.
• The appliance has a temperature range of 8° c- 18°c.
• Your appliance is designed to operate in the ambient temperature intervals statedin
the associated standards, according to the climate class stated on the information
label. We do not recommendoperatingyour cooler out of the stated temperatures,
as the appliance may not operate to its optimum level.
11
Usage Information
Interior light
• The appliance has an interior light and this can be switched on and off, by pressing
the light switch that is located next to the temperature adjustment buttons.
Shelves
• Any of the shelves can be removed, to accommodate larger bottles.
• Removing a shelf - Remove all of the bottles from the shelf that you want to remove.
Lift the shelf upwards and then gently pull the shelf away from the appliance.
• Replacing a shelf - Place the shelf back into a supporting guide slot and push it back as
far as it will go.
Important: Whilst the cooler can store larger bottles, you must make sure that they do not
prevent the door from shutting properly.
• Always check that you can close the door without it touching or hitting any of the
bottles, before shutting it.
• When loading several beverages at once, it will take longer for the appliance to cool the
individual bottles or cans.
12
Cleaning and Maintenance
• Disconnect the appliance from the power supply before cleaning.
• Do not pour water directly over or on the appliance.
• The compartment should be cleaned periodically using a solution of bicarbonate of
soda and lukewarm water.
• Do not use abrasive products, detergents or soaps. After cleaning wipe down with a
damp clean cloth.
• Note: Reconnect to the power after you have dried your hands.
Do not use sharp metal tools as it may damage the appliance.
Do not use an electrical heater, this may cause an electric shock.
Bulb Replacement
Bulb is not replaceable, please contact your retailer or Product Care.
Import ant Notes:
• If you do not use your appliance for a long period of time, e.g. when on summer
holidays unplug it. Clean and leave the door open to prevent humidity and bad
odours.
13
Connection to the mains supply
For UK use only – Plug fitting details (where applicable):
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your plug,
proceed as follows:
The GREEN/YELLOW wire is the EARTH and must be connected to the
terminal which is marked with the letter E or by the earth symbol or coloured
GREEN or
GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to the
terminal marked with the letter N or coloured BLACK. The
BROWN wire is the LIVE wire and must be connected to the
terminal marked with the letter L or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If a 13A (BS1363) fused plug is used it must be fitted with a
13amp fuse conforming to BS1362 and be BSI or ASTA approved.
14
15
Reversing the Door
The doors cannot be reversed
Troubleshooting
16
Problem
Solution
The appliance doesn't work
Check that the appliance is switched on.
Check that there has not been a power cut.
Check that the plug is not
faulty.
Check that the fuse has not blown.
Check that the voltage is correct for the appliance.
The temperature inside the
appliance is not cold enough
Check that there are not too many bottles in the
appliance.
Check that the temperature is set to a suitable
temperature.
Check that the appliance is not placed in direct sunlight,
or too near to a heating source.
Check that the ambient temperature is within the
operation limits of the appliance.
Opening the doors frequently will also reduce the
temperature within the appliance.
Check that the door has not been left open
or c
heck that
the door gasket is clean and undamaged.
The temperature within the
appliance is too cold.
Increase the working temperature
The inner surfaces of the
appliance are wet
Caused by condensation
-
dry the inside of the appliance.
The outer surfaces of the
appliance are wet
Caused by condensation
-
dry the outer of the appliance
carefully.
Unusual noises
Check that the appliance is on a flat, level surface and is
stable.
Check the spacing's around the appliance and ensure it is
not touching other items.
Troubleshooting
17
Problem
Solution
Smell/odour
Check that no bottles have leaked or any stagnant liquid
is at the bottom of the appliance. Clean if required.
Guarantee
This product is guaranteed for 12 months from the date of the original
purchase. If any defect arises due to faulty materials or workmanship the faulty
product must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with the original proof of
purchase.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other instructions
for use which have been supplied.
• It must be used for domestic purposes only and for its intended use.
• This warranty does not cover wear and tear, damage, misuse or
consumable parts.
This does not affect your statutory rights.
Produced for:
G2S Limited
Wigan
WN2 4AY
18
19
Technical Specification
Model number RH8WC2
Rated Voltage 220-240V/50Hz
Capacity (litres) 8 bottles (75cl)/23 litres
Dimensions (CMs): (
H)45.6 x (W)25.2 x (D)51.5
This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this
symbol is marked on a product/batteries, it means that the product/batteries
should not be disposed of with your general household waste. Only discard
electrical/electronic/battery items in separate collection schemes, which cater
for the recovery and recycling of materials contained within. Your co-operation
is vital to make sure the success of these schemes and for the protection of the
environment. For your nearest disposal facility, visit www.recycle-more.co.uk
or ask in store for details.
We reserve the right due to possible changes to design to alter the
instruction manual without prior notice.
Revision 9
For Customer Services & Spare Parts
please call 0345 208 8750
or visit us at
https://mda.russellhobbs.com
