INSTALLATION INSTRUCTIONS
27 " (68.6 CM)AND 30" (76.2 CM) ELECTRIC
SINGLE AND DOUBLE BUILT-IN OVEN
INSTRUCTIONS D’INSTALLATION
FOUR ÉLECTRIQUE ENCASTRÉ
27" (68,6 CM) ET 30" (76,2 CM) –
SIMPLE ET DOUBLE
W10351242C
BUILT-IN OVEN SAFETY .......................................................... 1
INSTALLATION REQUIREMENTS .......................................... 2
Tools and Parts .................................................................... 2
Location Requirements ....................................................... 2
Electrical Requirements ....................................................... 5
INSTALLATION INSTRUCTIONS ........................................... 6
Prepare Built-In Oven .......................................................... 6
Remove Oven Door(s) ......................................................... 6
Positioning Oven Feet
for Multiple Cabinet Cutout Heights .................................... 7
Make Electrical Connection ................................................ 10
Install Oven ........................................................................ 12
Complete Installation ......................................................... 14
SÉCURITÉ DU FOUR ENCASTRÉ ...................................... 15
EXIGENCES D’INSTALLATION ........................................... 16
Outillage et pièces ............................................................. 16
Exigences d’emplacement ................................................ 16
Spécications électriques .................................................. 19
INSTRUCTIONS D’INSTALLATION. .................................... 20
Préparation du four encastré ............................................. 20
Dépose de la porte du four ............................................... 20
Positionnement des pieds du four pour des ouvertures
d’encastrement de hauteur différente ................................ 21
Raccordement électrique .................................................. 24
Installation du four .............................................................. 26
Achever l’installation ......................................................... 28
Table of Contents/Table des matières
IMPORTANT:
Save for local electrical inspector’s use.
IMPORTANT :
À conserver pour consultation par l’inspecteur local des installations électriques.
BUILT-IN OVEN SAFETY
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't
follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
