Whynter ARC-126MD 12,000 BTU (7,700 BTU SACC) Dual Hose Cooling Portable Air Conditioner

Instruction Manual - Transcript

• Page 1 - English - : Congratulations on your new Whynter product To ensure proper operation please read this Instruction Manual carefully before using this product Keep this manual in a safe place for future reference Model ARC126MD INSTRUCTION MANUAL WHYNTER 12000 BTU DUAL HOSE PORTABLE AIR CONDITIONER WITH 3M AND SILVERSHIELD FILTER V 2019626
• Page 2 - English - : TABLE OF CONTENTS PAGE DISPOSAL INFORMATION SAFETY PRECAUTIONS INTRODUCTION TECHNICAL DATA PARTS IDENTIFICATION 6 7 CONTROL PANEL INSTALLATION 9 11 OPERATION INSTRUCTIONS 12 13 REMOTE CONTROL CARE AND MAINTENANCE TROUBLESHOOTING 16 17 WARRANTY INFORMATION
• Page 3 - English - : DISPOSAL INFORMATION This symbol on the product or its packaging indicates that the appliance cannot be treated as nor mal domestic trash but must be handed in at a collection point for recycling electric and electronic appliances Your contribution to the correct disposal of this product protects the environment Fur ther information about the recycling of this product can be obtained from your local municipal au thority Thank you for choosing the Whynter 12000 BTU Portable Air Conditioner Dual Hose with 3M and Silvershield filter Please follow the instructions provided in this user guide to obtain the very best performance from your portable air conditioner and take full advantage of the many features your portable air conditioner offers you We trust that your Whynter air conditioner will provide the perfor mance and reliability that we stand for Please keep this user manual in a safe place for future reference
• Page 4 - English - : WARNING TO REDUCE THE RISK OF FIRE ELECTRICAL SHOCK OR INJURY WHEN USING YOUR AIR CONDIITIONER FOLLOW THESE BASIC PRECAUTIONS Before the appliance is used it must be properly positioned and installed as detailed in this manual Do not under any circumstances cut or remove the third ground prong from the power cord Make sure this unit is connected to a correctly grounded power supply outlet Do not use an extension cord or power strip The power cord is UL listed It has a builtin LCDI leakage current detection interruption circuit breaker for added safety If the power supply is interrupted press the reset button to reconnect the unit to power source It is recommended to use a separate circuit that its size should be 15 Amps for the air conditioner Do not use an excessively wet cloth industrial solvents oilbased products to clean this portable air condition er To avoid the risk of shock the product should never be used in bathrooms shower rooms or in any other steamy or wet areas Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other applianc es Do not repair disassemble andor modify the unit by yourself Always turn off the portable air conditioner when cleaning the air filter and transporting Do not turn this unit on and off by plugging and unplugging Always use the ONOFF switch Transport the unit in an upright position only or leave it in an upright position for at least 4 hours before first use Ensure curtains or other objects are not obstructing the air inlet filters Do not bend or crush the exhaust hose while in use Always allow at least 20 of clearance around the unit for ventilation Do not use this unit inside closets cabi nets andor cramped spaces between furniture This unit is optimized to operate in an ambient temperature of 64F 90F This unit must be installed in an area protected from the element such as wind rain water spray or drips The unit should not be located next to ovens grills or other sources of high heat Always place the unit on even and hard and level surface Do not sit or place objects on the unit Do not allow children to climb stand or hang on the appliance The air conditioner could tip over and get dam aged andor seriously injure somebody Keep fingers out of the air intakes and air outlets The appliance is an electrical appliance To avoid injury from electrical shock do not operate it with wet hands while standing on a wet surface or while standing in water Do not use it in outdoors or in wet condi tions When positioning or moving the appliance ensure it is not turned upside down or greater than 45 or more off level This appliance is designed for household noncommercial use only Any other use will void the warranty Do not plug into the power outlet before set up is completed Do not operate this unit without the air filters Do not use harsh chemicals to clean the filters Dry thoroughly before inserting the filters into the unit Do not add extra length to the exhaust hose by more than a total length of 9 This will reduce the cooling effi ciency of the portable air conditioner At the end of each season all water must be drained from the unit and filters must be cleaned before stor age SAFETY PRECAUTIONS THE MANUFACTURER DISCLAIMS ANY RESPONSIBILITY IF THE ABOVE INSTRUCTIONS ARE NOT FOLLOWED
• Page 5 - English - : INTRODUCTION TECHNICAL DATA HOW IT WORKS The Whynter compact CFCfree leadfree and energy efficient 12000 BTU portable air conditioner helps you stay cool while working with better environmental standards and reducing energy consumption This high output portable air conditioner specially designed to be mobile can be easily setup in almost any indoor location and is most commonly used in data closets server rooms bedrooms classrooms and garages workshops This Whynter ARC126MD portable air conditioner features an ECOFRIENDLY CFCfree GREEN R410A refrigerant and leadfree RoHS compliant components Operationally a dual hose portable air conditioner has two main advantages over a single hose unit A dual hose portable air conditioner can help cool a room faster and will help minimize a negative air pressure situation in the room If the outside temperature is much higher or more humid than the room the intake hose can be detached and the unit will function as a single hose unit TECHNICAL DATA Model ARC126MD Operational Modes Auto Air conditioner Fan or Dehumidifier Cooling Capacity 12000 BTU Coverage Area 450 sq ft Dehumidifying Capacity 61 Pts day Fan Speed 3 Fan Speeds Filters 3M Filter and Silvershield washable prefilter Thermostat Control Range 62 88F Timer 24 hour programmable timer Noise Level lt55 dBA Extendable Hose 59 Window Kit Length Minimum 265 Maximum 48 Refrigerant R410A Air Flow at high speed 497 m h 292 CFM Maximum Power Consumption 1355W 118A Power Supply 115 V 60Hz EER 89 Unit Dimensions 185quot W x 1875quot D x 3025quot H Package Dimensions 2075 W x 2075quot D x 35quot H Net Weight 7275 lbs Gross Weight 815 lbs Intake hose prefilter
• Page 6 - English - : PARTS IDENTIFICATION FRONT VIEW BACK VIEW Control Panel Front Air Vent Louvers Casters four Handle power plug socket power cord buckle vent control bottom tray drain outlet power cord outlet drain outlet only for pump heating mode upper air filter behind the grille upper air intake air outlet lower air filter lower air intake drain outlet
• Page 7 - English - : PARTS IDENTIFICATION LeakageCurrent Detection and Interruption LCDI Opera ting Conditions Mode Room Temperature Cool Higher than 64F Dry Higher than 60F Your portable air conditioner is supplied with a LeakageCurrent Detection and Interruption LCDI plug This plug reduces the risk of fire due to arcing faults in the power supply cord Please follow the instructions below to ensure that LCDI plug works properly 1 Plug the power cord to a grounded wall outlet Do not plug to a power strip or extension cord 2 Press the TEST button on the plug This should trip the plug and cut the power to the air condi tioner If the plug does not trip and the unit comes on please contact technical support 3 Press the RESET button to start the air conditioner 4 Do NOT use the TEST and RESET buttons to turn the air conditioner on and off ACCESSORY IMAGE ACCESSORY DESCRIPTION QUANTITY Exhaust and intake hose adapters to the unit 1 set Exhaust and intake hose 1 each Exhaust and intake hose adapters to the window 1 set Window Slider Kit 1 set Clear plastic plug plug is in the upper corner of the plastic bag that holds the user manual 1 piece Foam seal A Adhesive Foam seal B Adhesive Foam seal C Nonadhesive 2 pieces 2 pieces 1 piece Security bracket with 2 screws 1 set Drain hose 1 piece 3M Filter preinstalled on unit 1 piece Silvershield prefilter preinstalled on unit 1 piece Intake hose prefilter preinstalled on unit 1 piece Storage Cover sold separately 1 piece
• Page 8 - English - : CONTROL PANEL Power Button Press to turn the air conditioner on and off Sleep Button Press to activate Sleep mode Fan Speed Button Press to change fan speed Controls the 3 fan speeds LO MED HI and AUTO The fan speed indicator lights illuminates to show the set fan speed When the AUTO speed is selected none of the fan speed indicator illuminates Mode Button Press to change mode Controls the 4 function modes COOL AUTO FAN and DRY Timer Button Press to program Timer Delayed Switch ON or OFF function Swing Button To adjust the air flow direction Up and Down Buttons Adjusts set temperature 1C 2F increments or timer hours 0 24 hours This unit is capable of displaying set temperature in Fahrenheit or in Celsius To convert from one to the other press and hold the Up and Down buttons for 3 seconds LED Display In Cool mode shows set temperature in C or F and AUTO timer setting In DRY and FAN only modes shows room temperature Error Codes E1 Room temperature sensor error Unplug unit and restart in 5 minutes E2 Evaporator sensor error Unplug unit and restart in 5 minutes E3 Condenser sensor error Unplug unit and restart in 5 minutes E4 Display panel sensor error Unplug unit and restart in 5 minutes P1 Water reservoir full Drain water from the unit
• Page 9 - English - : INSTALLATION WARNING NEVER OPERATE THE AIR CONDITIONER WITHOUT THE AIR FILTER AIR FILTERS Silvershield Prefilter and Intake Hose PreFilter This portable air conditioner is equipped with a Silvershield prefilter and intake hose prefilter which removes large particles such as dust pet hair and dander These pre filters can be removed for cleaning by pulling the filter frame back and out Both prefilters are washable and do not need to be replaced 3M Antimicrobial High Air Flow Filter This portable air conditioner comes with the 3M Antimicrobial High Air Flow Filter which is designed to remove particles such as dust pet hair and dander antimicrobial agent helps inhibit the growth of mold and mildew and the microstructured elec trostatically charged filtration media traps and retains particles The 3M Filter is preinstalled Note The 3M Filter should be replaced every 23 months de pending on usage Please contact supportwhyntercom for retail sales information WATER DRAINAGE The dehumidifying capacity of this unit is 61 pints per day The patented selfevaporating function of the ARC126MDB unit fully exhausts all condensation automatically in most en vironments when humidity is less than 70 Areas with more than 70 humidity the selfevaporating function can still ex haust about 98 of the moisture and the remaining 2 of moisture will be collected in the water tank of the air condi tioner When the water reservoir reaches its maximum level the unit will beep 8 times and the digital display will show P1 When the unit displays P1 all operation modes will be disabled temporarily while the fan continuously running The P1 code will disappear when the water is completely drained Manual drainage Fig 1a Carefully move the unit to a drain location or position a flat container dish or optional drain bucket accessory sold separately under the drain area of the lower drain port Remove the bottom drain plug and let the water drain Replace the drain plug and plug in to resume operation Continuous drainage Fig 1b Remove the upper drain plug from the back of the unit and install the drain hose Place the open end of the hose to a drain area This method is recommended if uninterrupted op eration is desired 3M Filter Intake Hose prefilter Fig 1a Fig 1b Silvershield Filter SCALE 0500 drain hose adaptor Continuous drain hose Remove the lower drain plug drain hose adaptor Continuous drain hose Remove the lower drain plug
• Page 10 - English - : INSTALLATION LOCATION The air conditioner should be placed on a hard and level surface strong enough to support the unit The unit has casters and it should only be rolled on smooth flat surfaces Use caution when rolling on carpet surfaces Do not attempt to roll the unit over objects Never place any obstacles around the air inlet or outlet and allow at least 20 inch of clearance for efficient airconditioning EXHAUST AND INTAKE HOSE INSTALLATION When you use this air conditioner unit hot air must be exhausted out of the room to complete the air exchange of the condenser When the unit is operating in DRY or FAN only mode installation of the exhaust hose is optional 1 Pull out about 6 of each end of the exhaust and intake hose 2 Snap each of the hose connectors to the unit onto one end of each hose and then snap each of the hose connectors to the window onto the other ends See Fig 1 3 Lineup the hose connector hooks of each hose onto the back of the unit and slide into the hole seats See Fig 2 4 Only extend the exhaust hose to the necessary length keeping it as short and straight as possible WINDOW KIT INSTALLATION The window kit has been designed to fit most standard vertical and horizontal windows However it may be necessary to modify the installation procedures to accommodate your window Please refer to Fig 3a and Fig 3b for minimum and maximum window openings If your window opening is less than the mentioned minimum length of the window slider kit the window slider kit can be cut to fit the window opening Never cut into the exhaust intake hose cutouts on the window slider kit If your window opening is larger than the maximum length of the window slider kit additional material will be needed to cover the open space such as Plexiglas PVC plastic ply wood etc Alternately an additional window slider kit can be purchased to be used in combination with the included kit NOTE When using the window slider kit on a window or sliding door additional security measures may be needed The window slide bars can be fixed with the clear plastic bolt Fig 4 Fig 2 Hole Seat Hole Seat Fig3a Fig 4 Fig3b Fig 1 Hook Hook Clear plastic plug
• Page 11 - English - : INSTALLATION WINDOW KIT INSTALLATION IN A DOUBLEHUNG WINDOW 1 Open window or sliding door for approxi mately 5 2 Cut the foam seal A and B adhesive type to the proper length and attach it to the bottom of the window Fig 5a 3 Adjust the length of the window bars to the same length and width of the opening of the window Cut the window piece if nec essary to fit the length of your window Fig 5b 4 Close the window on the window slide bars For long term installation you may screw the window kit into your window frame using the security bracket Fig 5c 5 Cut the foam seal C nonadhesive to the length and seal the open gap between the top window sash and outer window sash Shown in Fig 5d WINDOW KIT INSTALLATION IN A SLIDING WINDOWDOOR 1 Open window or sliding door for approx imately 5 2 Cut the foam seal adhesive type to the proper length and attach it to the bot tom of the door window Fig 6a 3 Adjust the length of the window slide bars to the same length and width of the opening of the window Cut the window piece if necessary to fit the length of your window Fig 6b 4 Close the door window on the window slide bars For long term installation you may screw the window kit into your window frame using the security bracket Fig 6c 5 Cut the foam seal C nonadhesive to the length and seal the open gap between the top window sash and outer window sash Show in Fig 6d Foam seal A adhesive type Foam seal B adhesive type Security bracket Screws Foam seal C nonadhesive type Foam seal A adhesive type Foam seal B adhesive type Security bracket Screws Foam seal C nonadhesive type EXHAUST AND INTAKE HOSE INSTALLATION TO THE WINDOW KIT 1 Make sure that window slider kit is securely installed 2 Move the unit to the window extend both hoses align the hose connectors and snap them into the window kit
• Page 12 - English - : OPERATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE Remove the exterior and interior packing Before connecting the appliance to the power source let it stand upright for approximately 4 hours This will reduce the possibility of a malfunction in the cooling system from handling during transportation SWITCHING ONOFF THE AIR CONDITIONER The appliance can be switched ON or OFF by pressing the POWER button on the control panel or the ONOFF but ton on the remote control COOLING MODE In this mode the air conditioner cools and dehumidifies the room To activate this function mode press the MODE button until the COOL indicator light comes on When the cooling mode is set the compressor will start in approxi mately 3 minutes In cooling mode hot air is exhausted from the outdoor exhaust port and the exhaust hose must be connected to exhaust out the hot air The temperature setting range of this air conditioner is from 62F 17C to 88F 30C To set the temperature press the or buttons This air conditioner has a 5F temperature cushion which if the set temperature is within 5F of the ambient temperature the unit runs on fan only mode This saves energy and prolongs the life of the compres sor of the air conditioner To set the fan speed press the FAN button In cooling mode the difference in noise level between the 3 fan speeds is not very noticeable when the compressor is on Try setting the unit to Fan only mode you should be able to hear the difference between high and low fan speed settings A dual hose portable air conditioner may cool a room faster and will help minimize a negative air pressure situation in the room If the outside temperature is much higher or more humid than the room the intake hose can be disconnected and it will function like a single hose unit DRY DEHUMIDIFYING ONLY MODE In this mode the air conditioner only dehumidifies the room the compressor will activate intermittently depending on the ambient temperature and the fan speed is set to LOW To activate this function mode press the MODE button until the DRY indicator light is displayed Please note that when switching function mode there will be an approxi mately 3 minute transition time In dehumidifying mode the exhaust hose does not need to be vented If the exhaust hose is ventedthe room will be cooled as it dehumidifies To prevent cooling remove the exhaust hose from the window kit and allow the warm air from the rear to be recirculated into the room If room temperature is higher than 77F the fan speed can be adjusted If room temperature is lower than 77F the fan speed is set at Low NOTE When using dehumidifying mode venting the exhaust hose to the outside is not required If vented the warm air is exhausted to the outside and cooling within the room may occur Additionally if the exhaust hose is not vented the unit may require more frequent draining Also the air conditioner does not have a humidistat in which a specific humidity level can be set AUTOMATIC MODE When you set the air conditioner in AUTO mode it will automatically select cooling or fan only operation depending on the temperature of the room The fan speed is automatically selected and cannot be changed To operate the unit in Auto mode when the unit is on press the MODE button until the AUTO indicator light comes on FAN ONLY MODE In this mode only the fan of the air conditioner runs and circulates the air in the room To activate this function mode press the MODE button until the FAN indicator light comes on In this function mode the temperature cannot be set Subsequently set the desired fan speed by pressing the FAN button Fan Only mode does not require the use of both exhaust and intake hoses
• Page 13 - English - : OPERATION INSTRUCTIONS TIMER DELAYED SWITCH ON OFF FUNCTION This function mode enables a delayed switch ON or delayed switch OFF of the air conditioner The time hours de lay can be set enabled and disabled SETTING SWITCH OFF TIMER With the air conditioner operating in any function mode press the TIMER button The TIMER OFF light will come on Then set the desired time delay OFF hours by pressing the UP and DOW N buttons The time increments are at 05 hour to up to 10 hours followed by 1 hour increment up to 24 hours When the delay time set has elapsed the air conditioner switches off To cancel the delayed switch off function turn off the air conditioner or adjust the time set ting to 00 SETTING DELAYED SWITCH ON TIMER With the air conditioner is off press the TIMER button The TIMER ON light will come on Then set the desired time delay ON hours by pressing the UP and DOW N buttons The time increments are at 05 hour to up to 10 hours fol lowed by 1 hour increment up to 24 hours When the delay time set has elapsed the air conditioner switches on To cancel the delayed switch on function turn on the air conditioner or adjust the time setting to 00 SLEEP MODE In this mode the air conditioner gradually increases the set temperature in cooling mode decreases the noise level and conserves energy In Sleep and cooling mode the set temperature is increased by 1C 2F in the first 30 minutes The temperature will then increase by another 1C 2F after an additional 30 minutes This new tempera ture will remain the same for 7 hours To activate this function mode press the SLEEP button until the SLEEP indicator light comes on AUTO RESTART In the event of a power outage the air conditioner restarts at the previously set function mode and settings when power is restored CONTROLLING THE AIR FLOW DIRECTION The louvers can be controlled to AutoSwing or in a fixed direction To control the air flow direction by AutoSwing press the SWING button To set the louvers in a fixed angle or direction press SWING button while on AutoSwing mode when desired angle is chosen NOISE LEVEL Portable air conditioners may make sounds that are not familiar to you The sounds listed below are normal Noise reflecting off hard surfaces such as a floor or wall can make the sounds seem louder than they actually are The compressor may make a pulsating or highpitched sound Water running from the evaporator to the water tank may make a splashing sound Refrigerant flowing may make a gurgling sound Fan sound may come from front and back air vents COMPRESSOR LOCK OUT This portable air conditioner is optimized to operate in an ambient temperature of 64F 90F The compressor cir cuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly This prevents overheating of the compressor and possible circuit breaker tripping SHORTCUT FUNCTION Push this button when remote controller is on the system will automatically revert back to the previous settings in cluding operating mode setting temperature fan speed level and sleep feature if activated If shortcut button is pushed for more than 2 seconds the system will automatically store the current operation settings including operat ing mode setting temperature fan speed level and sleep feature if activated
• Page 14 - English - : REMOTE CONTROL The portable air conditioner can be switched on by the remote control To transmit signals from the remote con trol to the air conditioner point the front part of the remote handset towards the control panel on the air condi tioner Reception of the signal is confirmed by a beep The maximum signal transmission distance is approxi mately 8 meters 26 feet NOTE Other appliances in the same room controlled by a remote control TV radio stereo etc may cause interferences Electronic and fluorescent lamps may interfere with the signal transmissions between the remote control and the air conditioner Remove the batteries if the remote control is not used for long periods INSTALLING BATTERIES To insert the batteries open the flap on the back of the remote control by sliding if off Strictly adhere to the polarity signs on the bottom of the battery housing close the flap once the batteries have been inserted Only use two dry LR03 AAA 15V Batteries included in the remote control Always change both batteries at the same time INDICATOR FUNCTION 1 Mode Indicator Displays the current selected mode Auto Cool Dry or Fan 2 Transmission Indi cator Displays when remote sends signal to unit 3 ONOFF Display Displays when the unit is turned on and disappears when it is turned off 4 Timer On Indicator Displays when TIMER ON is set 5 Timer Off Indicator Displays when TIMER OFF is set 6 Battery Indicator Displays battery life status 7 TemperatureTimer display Displays the set temperature by default or timer setting when using TIMER ON OFF functions 8 Sleep Display Displays when SLEEP function is activat ed 9 Fan Speed Display Displays selected Fan speed This display is blank when set to AUTO speed BUTTONS FUNCTION 10 OnOff Button Turns the unit On and Off 11 Mode Button Controls the 4 function modes Auto Cool Dry amp Fan 12 Fan Speed Button Controls the fan speeds High Medium Low or Auto 13 Sleep Button Enables Sleep mode 14 Swing Button Starts or stops louver movement and set louver angle 15 LED Display But ton Turns on and off the display light 16 Up Button Increases set temperaturetime 17 Down Button Decreases set temperaturetime 18 Shortcut Button Restore the current settings or resume previous settings 19 Timer On Button Enables the Timer On 20 Timer Off Button Enables the Timer Off 4 3 2 13 14 15
• Page 16 - English - : TROUBLESHOOTING Problem Possible Causes Solutions The portable air conditioner does not turn on Power failure outage The automatic switch line fuse or breaker has been tripped The power supply voltage is too low The power cord is damaged The LCDI power plug for the unit is tripped The internal water reservoir is full and P1 appears on display Restore the power supply Flip the switch change the fuse turn the breaker back on Also note that you may have too many appliances drawing power on one circuit you may need to move the other appliances to another circuit Move the unit onto another circuit with the correct voltage Call for service Only authorized per sonnel should replace damaged pow er cord or power plug Press the Reset button on the LCDI power plug Drain water from the air conditioner Possible loose internal connection Please contact Whynter for service The unit turns on but the com pressor does not turn on the fan runs but the unit is not cooling The room temperature is outside of the operational tolerances of the unit The Cooling mode is not on The compressor has not turned on yet because of its time delay The set temperature is too high The internal water reservoir is full and P1 appears on display This unit is designed to work in ambi ent temperatures of 63F to 90F Press the MODE button until the COOL light is shown on the display Give the compressor 3 minutes to turn on after the Cooling mode has been selected Set the air conditioner to a lower tem perature It is recommended to set the temperature to at least 5F of the am bient temperature Either manually drain the water by removing the drain plug or allow the unit to exhaust the water itself by run ning the fan only mode Then cooling will resume Possible loose internal connection Please contact Whynter for service The air coming out of the unit is not very cold or the airflow volume is weak The filters are dirty or obstructed The air intake or exhaust is ob structed The unit is set in DRY or FAN mode The unit is set to low fan speed Clean the air filters Make sure there is at least 20quot of clearance from the air intake Make the length of the exhaust hose is as short as possible Set the unit to the cooling mode Set the unit to a higher fan speed Many common portable air conditioner problems are easily resolved Try the troubleshooting suggestions below to see if the problems can be resolved before having to contact the service department
• Page 17 - English - : TROUBLESHOOTING Problem Possible Causes Solutions The unit has worked for a long time but the room is not cold enough Windows or doors are open There are too many people in the room There is direct sunshine into the room The room is a kitchen or with many heatproducing appliances There is a server in the room The room is too large Close all windows and doors You may need additional cooling or another air conditioner Close curtains or blinds and try to min imize the amount of direct sunlight into the room You may need additional cooling or another air conditioner The unit is very noisy The unit is not level The surface underneath the unit is uneven Low power voltage Make sure the unit is on hard level and stable surface Move the unit to a location with a level and hard floor Make sure the wall outlet and support the required power consumption of the air conditioner and do not use an ex tension cord The unit leaks water The unit is tilted or not leveled The water tank is full Make use the unit is leveled Drain water from the drain plug at the back of the air conditioner Fan speed cannot be changed Fan speed differences are not very noticeable The fan speed difference is not very noticeable when the compressor is on Try setting the unit to Fan only mode you should be able to hear the differ ence between high and low fan speed settings
• Page 18 - English - : ONE YEAR LIMITED WARRANTY amp THREE YEAR WARRANTY ON COMPRESSOR This WHYNTER product is warranted to the original owner purchased from an authorized Whynter dealer within the 48 US continental states for one year from the original purchase date against defects in material and work manship under normal residential usage Should your WHYNTER product prove defective within one year from the date of purchase contact Whynters Customer Support team with the serial number and proof of purchase to make a warranty claim A Return Authorization number must be issued before returning any parts or products Parts or products received without a Whynter issued Return Authorization number will be refused Under this warranty Whynter will repair or replace any parts found defective with new or remanufactured parts or exchange the defective product with a new refurbished or remanufactured product at our discretion All defective products and parts covered by this warranty will be repaired or replaced on a mailin basis to Whynters Service Center This warranty is not transferable After the expiration of the warranty the cost of labor and parts will be the re sponsibility of the original owner The compressor of portable air conditioners is warranted for an additional two years after the one year limited warranty expires from the date of purchase Return freight is prepaid by Whynter within two months of purchase After two months to one year the customer will be responsible for the return freight cost to Whynters Service Center Please package the product carefully in its original packaging to avoid damage in transit Whynter is not responsible for damage resulting from shipper mishandling or improper packaging Please retain the original box and packaging materials THIS WARRANTY DOES NOT COVER Acts of God such as fire flood hurricanes earthquakes and tornadoes Improper power supply such as power surge low voltage defective household wiring or inadequate fuses Use in commercial or industrial applications Damage accidental or otherwise to the product while in the possession of a consumer not caused by a defect in material or workmanship Damage caused by consumer misuse tampering lack of maintenance or failure to follow the care and special handling provisions in the instructions Damage to the finish of the case or other appearance parts caused by wear Damage caused by repairs or alterations to the product by anyone other than authorized by the manufacturer Removal Replacement Packaging Freight and Insurance cost for the warranty service Products sold AS IS or from an unauthorized reseller Products that have had their serial numbers removed or defaced DISCLAIMER OF IMPLIED WARRANTIES LIMITATION OF REMEDIES CUSTOMERS SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR RE PLACEMENT AS PROVIDED HEREIN CLAIMS BASED ON IMPLIED WARRANTIES INCLUDING WARRANTIES OF MERCHANTA BILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW BUT NOT LESS THAN ONE YEAR WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WAR RANTY OR ANY IMPLIED WARRANTY SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCI DENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES SO THESE LIMITA TIONS OR EXCLUSIONS MAY NOT APPLY TO YOU THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE The warranty product contents and specifications are subject to change at any time without notice please refer to wwwwhyntercom for the most current information To register your warranty please visit wwwwhyntercom and fill out the online Warranty Registration form Please be sure to include a copy of your purchase invoice To obtain service or information contact Whynter LLC via email at supportwhyntercom or call 866WHYNTER 8669496837 Product contents and specifications may change without notice Copyright 2019 Whynter LLC WWWWHYNTERCOM V 2019626
