User manual Range for LG Electronics LRG4115ST
Table of contents
- PRODUCT FEATURES
- IMPORTANT SAFETY INSTRUCTIONS
- PRODUCT OVERVIEW
- Parts
- Accessories
- INSTALLATION
- Before Installing the Range
- Installing the Range
- Providing Adequate Gas Supply
- Connecting the Range to Gas
- Electrical Connections
- Sealing the Openings
- Assembling the Surface Burners
- Checking Ignition of the Surface Burners
- Leveling the Range
- Engaging the Anti-tip Device
- OPERATION
- Gas Surface Burners
- Burner Locations
- Minimum & Maximum Default Settings
- Timer On/Off
- Settings
- Setting the Hour Mode
- Selecting Fahrenheit or Celsius
- Lockout
- Start Time (Delayed Timed Cook)
- Cook Time (Timed Cook)
- TROUBLESHOOTING
- SMART DIAGNOSISTM
- WARRANTY (USA)
Adjusting the Surface Burner to the Low Flame (Simmer) Setting
- Light all surface burners.
- Turn the knob on the burner being adjusted to Lo.
- Remove the knob.
- Insert a small, flat-blade screwdriver into the valve shaft.
- NOTE: Hold the valve shaft with one hand while turning the screw to adjust with the other.
- Replace the knob.
- Test the flame stability. Test 1: Turn the knob from Hi to Lo quickly. If the flame goes out, increase the flame size and test again. Test 2: With the burner on a Lo setting, open and close the oven door quickly. If the flame is extinguished by the air currents created by the door movement, increase the flame height and test again.
- Repeat steps 1-6 for each surface burner.
Checking Operation of Bake / Broil Burners
To check ignition of the Bake burner, follow the steps below
- Remove all packing materials from inside the oven cavity.
- Touch Bake. 350 °F appears in the display.
- Touch Start.
It may take between 30 and 90 seconds for the burner to start heating.
To check ignition of the Broil burner, follow the steps below
- Touch Broil. Hi appears in the display.
- Make sure the door is closed.
- Touch Start.
Engaging the Anti-tip Device
- Slide the range against the wall, making sure the back leg slides into and engages the anti-tip bracket.
- Check for proper installation by grasping the front edge of the cooktop and carefully attempting to tilt the range forward.
Timer On/Off
- The Timer On/Off serves as an extra timer in the kitchen that beeps when the set time has run out. It does not start or stop cooking.
- The Timer On/Off feature can be used during any of the other oven control functions.
Setting the Hour Mode
The control is set to use a 12-hour clock. To reset the clock to 24-hour mode, follow the steps below.
- Touch Settings once.
- Touch 1 to toggle between a 12-hour and 24-hour clock.
- Touch Start to accept the change.
Setting Convection Auto Conversion
When Conv. Bake and Conv. Roast are selected, Convection Auto Conversion automatically converts the standard recipe temperature entered to a convection temperature by subtracting 25 °F / 14 °C. This auto- converted temperature shows on the display. For example, select Conv. Bake, enter 350 °F, and 325 °F shows on the display after preheat.
Convection Auto Conversion is enabled by default. To change the setting, follow these instructions.
- Touch Settings repeatedly until Auto appears in the display.
- Touch 1 to disable or enable auto conversion.
- Touch Start to accept the change.
