SHX98M09UC/70 photo
2
1
3 TBS MAX
2 TBS (25 ML)
1 TBS (15 ML)
Use fresh powdered detergent
for best results
1 tablespoon will clean most loads
3 tablespoons Max, do not overfill
When using detergent tabs, lay them
flat to avoid contact with the cover
Using too much detergent can
damage your dishware
*GETTING STARTED
WITH YOUR NEW DISHWASHER
STEP 1- ADDING RINSE AGENT
To add Rinse Agent
pour on the arrow
Turn arrow to
adjust the amount
of rinse agent
dispensed
Add Rinse Agent when the
"Refill Rinse Aid" message
appears on the display
Add
Detergent
To close
If you should
need to open
the cover
STEP 2 - ADDING DETERGENT
STEP 3 - TO START THE DISHWASHER
*ALWAYS READ YOUR USE AND CARE MANUAL FOR DETAILED INSTRUCTIONS
AND IMPORTANT SAFETY NOTICES.
To Contact Customer Service
With the dishwasher door open, locate the label on the right side
of the door. There you will find the:
Model Number
Serial Number (FD#########)
Toll Free Customer Service Phone Number
Run Time
To save energy, this dishwasher has a "Smart Control" that
automatically adjusts the cycle based on soil loads and incom-
ing water temperature. The "Smart Control" makes decisions
that can cause the cycle time and water usage to adjust at
discrete times, and suddenly change in midcycle. The cycle
times listed in the Use and Care manual are based on normal soil
loads and 120°F incoming water and will vary based on your
actual conditions.
When is the Cycle Complete
Depending on model you can tell when your unit has completed
the cycle in one of the following ways. Please refer to your Use
and Care manual for complete details
Countdown Display at "0"
Clean Light illuminates
Cycle completion signal sounds (tone adjustable)
Cycle indicator light that shines on floor goes out
Canceling a Cycle
Be careful of splash-out.
*To cancel a cycle already in process, open the door only far
enough to expose the control panel, the display will show:
"Close the door"
Approximate remaining cycle time
The current cycle
The cycle phase
"Cancel Program"
Press the – button. The display will show "To cancel, close the
door". The dishwasher will then drain the remaining water and
shut off.
FREQUENTLY ASKED
QUESTIONS
For Proper Drying Always use Rinse Agent even if your detergent containes Rinse Agent
9000151951 Rev. A • 01/06
Arrow
Turn
Decrease
for
Streaks on
glasses
Increase
for
Spots on
glasses
1
2
Push the blue button in
(NOT DOWN)
Lift tab to
open
Slide cover fully left
Push rear of cover down
firmly until you hear the
CLICK
Hidden Top Controls
4) Touch start
3) Select a cycle
2) Turn on
1) Open the door
In order to activate a touch control button, place the
entire fingertip over
the button for three seconds
The first time you use your dishwasher you must select a language. These choices
will appear on the display screen:
AE (American English) / CF (Canadian French) / MS (Mexican Spanish)
Touch the – or + button until the desired language flashes, then touch the
MENU/OK button to save the setting
Start
On
Off
Menu
ok
Auto Wash
5) Close the
door to start
