Portable
DVD
Player
Before
connecting,
operating
or
adjusting
this
product,
please
read
this
instruction
booklet
carefully
and
completely.
Owner's
Manual
Model:
LGDVP7772
â“’Copyright
2005,
LG
Electronics
U.S.A.,
Inc.
For
service/
support
Call:
Toll
Free
Number
1-800-243-0000
This
lightning
flash
with
arrowhead
symbol
within
an
equilateral
tri-
angle
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
dan-
gerous
voltage
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of
electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important
operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
product.
WARNING:
Do
not
install
this
equipment
in
a
confined
space
such
as
a
bookcase
or
similar
unit.
CAUTION:
This
product
employs
a
Laser
System.
To
ensure
proper
use
of
this
product,
please
read
this
owner
's
manual
carefully
and
retain
it
for
future reference.
Should
the unit
require
maintenance,
contact
an
authorized
service
center.
Performing
controls,
adjustments,
or
carrying
out
procedures
other
than
those
specified
herein
may
result
in
hazardous
radiation
exposure.
To
prevent
direct
exposure
to
laser
beam,
do
not
try
to
open
the
enclosure.
Visible
laser
radiation
when
open.
DO
NOT
STARE
INTO
BEAM.
CAUTION:
The
apparatus
should
not
be
exposed
to
water
(dripping
or
splashing)
and
no
objects
filled
with
liquids,
such
as
vases,
should
be
placed
on
the
appara-
tus.
CAUTION:
VISIBLE
AND
INVISIBLE
LASER
RADIATION
WHEN
OPEN
AND
INTERLOCKS
DEFEATED.
NOTES
ON
COPYRIGHTS:
It
is
forbidden
by
law
to
copy,
broadcast,
show,
broadcast
via
cable,
play
in
public,
or
rent
copyrighted
material
without
permission.
This
product
features
the
copy
protection
function
developed
by
Macrovision.
Copy
protection
signals
are
recorded
on
some
discs.
When
recording
and
playing
the
pictures
of
these
discs
on
a
VCR,
noise
will
appear.
This
product
incorporates
copyright
protection
technology
that
is
protected
by
method
claims
of
certain
U.S.
patents
and
other
intellectual
property
rights
owned
by
Macrovision
Corporation
and
other
rights
owners.
Use
of
this
copyright
protec-
tion
technology
must
be
authorized
by
Macrovision
Corporation,
and
is
intended
for
home
and
other
limited
viewing
uses
only
unless
otherwise
authorized
by
Macrovision
Corporation.
Reverse
engineering
or
disassembly
is
prohibited.
CAUTION
concerning
the
Power
Cord
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
That
is,
a
single
outlet
circuit
which
powers
only
that
appliance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
dangerous.
Any
of
these
conditions
could
result
in electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
discontinue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
Safety
Precautions
2
CAUTION:
TO REDUCE
THE
RISK
OF
ELECTRIC
SHOCK
DO
NOT
REMOVE
COVER
(OR
BACK)
NO
USER-SERVICEABLE
PARTS
INSIDE
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
CAUTION
RISK
OF
ELECTRIC
SHOCK
DO
NOT
OPEN
WARNING:
TO
PREVENT
FIRE
OR
ELECTRIC
SHOCK
HAZARD,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
Introduction
3
CAUTION:
The
apparatus
should
not
be
exposed
to
water
(dripping
or
splashing)
and
no
objects
filled
with
liquids,
such
as
vases,
should
be
placed
on
the
apparatus.
FCC
WARNING:
This
equipment
may
generate
or
use
radio
frequency
energy.
Changes
or
modifications
to
this
equipment
may
cause
harmful
interference
unless
the
modifications
are
expressly
approved
in
the
instruction
manual.
The
user
could
lose the
authority
to
operate
this
equipment
if
an
unauthorized
change
or
modification
is
made.
REGULATORY
INFORMATION:
FCC
Part
15
This
product
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
when
the
product
is
operated
in
a
residential
installation.
This
product
generates,
uses,
and
can
radiate
radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instruction
manual,
may
cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
product
does
cause
harmful
interference
to
radio
or
television
reception,
which
can
be
determined
by
turning
the
product
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
?
Reorient
or
relocate
the
receiving
antenna.
?
Increase
the
separation
between
the
product
and
receiver.
?
Connect
the
product
into
an
outlet
on
a
circuit
different
from
that
to
which
the
receiver
is
connected.
?
Consult
the
dealer
or
an
experienced
radio/TV
technician
for
help.
FCC
COMPLIANCE:
The
responsible
party
for
this
product's
compliance
is:
LG
Electronics
U.S.A.,
Inc.,
1000
Sylvan
Avenue,
Englewood
Cliffs,
NJ
07632
Phone:
1-201-816-2000
SERIAL
NUMBER:
The
serial
number
is
found
on
the
back
of
this
unit.
This
number
is
for
this
unit
only.
You
should
record
the
serial
number
in
the
space
pro-
vided
and
retain
this
guide
as
a
permanent
record
of
your
purchase.
Model
No.
LGDVP7772
Serial
No.
Safety
Precautions
(Continued)
Table
of
Contents
Introduction
SafetyPrecautions.....................................................2-3
TableofContents.......................................................4
BeforeUse..........................................................5-8
SymbolusedinthisManual...........................................5
AbouttheSymbolDisplay........................................5
NotesonDiscs....................................................5-6
Disc-relatedterms...................................................6
MaintenanceandService..............................................7
TypesofPlayableDiscs..............................................8
IdentificationofControls...............................................9-12
MainUnit.......................................................9-10
RemoteControl..................................................11-12
PowerConnections..................................................13-16
ACAdapter.......................................................13
AutomotiveAdapter.................................................14
BatteryPack....................................................15-16
PlayingaDisc.........................................................17
Advanced
Operations
On-ScreenDisplay...................................................18-19
GeneralFeatures....................................................20-24
?MovingtoanotherTITLE........................................20
?MovingtoanotherCHAPTER/TRACK..............................20
?Search.......................................................20
?StillPictureandFrame-by-FramePlayback...........................21
?SlowMotion..................................................21
?TimeSearch...................................................21
?RepeatA-B...................................................21
?Repeat.......................................................21
?MarkerSearch.................................................22
?Zoom........................................................23
?ResumePlay..................................................23
SpecialDVDFeatures................................................23-24
?TitleMenu....................................................23
?DiscMenu....................................................23
?ChangingtheAudioLanguage.....................................23
?CameraAngle.................................................24
?Subtitles......................................................24
?LastSceneMemory.............................................24
?ScreenSaver..................................................24
?ChangingtheAudioChannel......................................24
PlayinganAudioCDandMP3/WMADisc...............................25-27
AudioCDandMP3/WMADiscFeatures.............................26-27
?Pause........................................................26
?MovingtoanotherTrack.........................................26
?Search.......................................................26
?RepeatTrack/All/Off...........................................26
?RepeatA-B...................................................26
?
MP3
/
WMA
disc
compatibility
with
this
player
is
limited
as
follows
. . . . . . .
27
ProgrammedPlayback................................................28-29
?RepeatProgrammedTracks.......................................29
?ErasingaTrackfromProgramList.................................29
?ErasingtheCompleteProgramList.................................29
ViewingaJPEGdisc................................................30-31
?SlideShow...................................................30
?StillPicture...................................................30
?MovingtoanotherFile..........................................31
?Zoom........................................................31
?Torotatepicture................................................31
?TolistentoMP3/WMAmusicwhilewatchingpicture.
. . . . . . . . . . . . . . . . .
.31
?JPEGdisccompatibilitywiththisplayerislimitedasfollows.
. . . . . . . . . . .
.31
PlayingaDVDVRformatDisc...........................................32
PlayingaDivXMovieDisc..............................................33
?DivXdisccompatibilitywiththisplayerislimitedasfollows
. . . . . . . . . . . .
.33
Initial
Settings
InitialSettings......................................................34-39
GeneralOperation..................................................34
LANGUAGE.....................................................34
DISPLAY........................................................35
AUDIO.......................................................35-36
OTHERS......................................................36-37
LOCK(ParentalControl)..........................................38-39
Connections
SettingupthePlayer.................................................40-41
DVDPlayerConnections............................................40
AudioConnectiontoOptionalEquipment................................41
Reference
Troubleshooting.......................................................42
LanguageCodeList....................................................43
AreaCodes...........................................................44
Specifications.........................................................45
4
5
Introduction
Before
Use
To
ensure
proper
use
of
this
product,
please
read
this
owner
's
manual
carefully
and
retain
for
future
reference.
This
manual
provides
information
on
the
operation
and
maintenance
of
your
DVD
player.
Should
the
unit
require
service,
contact
an
authorized
service
location.
Symbol
Used
in
this
Manual
The
lightning
flash
symbol
alerts
you
to
the
presence
of
danger-
ous
voltage
within
the
product
enclosure
that
may
constitute
a
risk
of
electric
shock.
The
exclamation
point
alerts
you
to
the
presence
of
important
operating
and
maintenance
/
servicing
instructions.
Indicates
hazards
likely
to
cause
harm
to
the
unit
itself
or
other
material
damage.
NOTE
Indicates
special
notes
and
operating
features.
TIP
Indicates
tips
and
hints
for
making
the
task
easier.
A
section
whose
title
has
one
of
the
following
symbols
is
applicable
only
to
the
disc
represented
by
the
symbol.
DVD
and
finalized
DVD±R/RW
Video
CDs.
Audio
CDs.
MP3
discs.
WMA
discs.
JPEG
discs.
DivX
discs
About
the
Symbol
Display
"
"
may
appear
on
your
LCD
display
during
operation
and
indicates
that
the
function
explained
in
this
owner
's
manual
is
not
available
on
that
specific
DVD
video
disc.
Notes
on
Discs
Handling
Discs
Do
not
touch
the
playback
side
of
the
disc.
Hold
the
disc
by
the
edges
so
that
fingerprints
do
not
get
on
the
surface.
Never
stick
paper
or
tape
on
the
disc.
DivX
JPEG
WMA
MP3
CD
VCD
DVD
6
Before
Use
(Continued)
Storing
Discs
After
playing,
store
the
disc
in
its
case.
Do
not
expose
the
disc
to
direct
sunlight
or
sources
of
heat
and
never
leave
it
in
a
parked
car
exposed
to
direct
sunlight.
Cleaning
Discs
Fingerprints
and
dust
on
the
disc
can
cause
poor
picture quality
and
sound
distortion.
Before
playing,
clean
the
disc
with
a
clean
cloth.
Wipe
the
disc
from
the
center
out.
Do
not
use
strong
solvents
such
as
alcohol,
benzine,
thinner,
commercial-
ly
available
cleaners,
or
anti-static
spray
intended
for
older
vinyl
records.
Disc-related
terms
DVD±R/DVD±RW
DVD
-R
and
DVD
+R
are
two
different
standards
for
recordable
DVD
drives
and
discs.
This
format
allows
information
to
be
recorded
onto
the
DVD
disc
only
once.
DVD
+RW
and
DVD
-RW
are
two
standards
for
re-writable
media,
meaning
the
DVD
content
can
be
erased
and
re-
recorded.
VCD
(Video
CD)
AVCD
holds
up
to
74
minutes
(650
MB
disc)
or
80
minutes
(700
MB
disc)
of
MPEG-1
full-motion
video
along
with
quality
stereo
sound.
MPEG
MPEG
is
an
international
standard
for
video
and
audio
compression.
MPEG-1
is
used
in
encoding
video
for
VCD
and
provides
for
multichan-
nel
surround
sound
coding
such
as
PCM,
Dolby
Digital,
DTS
and
MPEG
audio.
MP3
MP3
is
a
popular
compression
format
used
for
digital
audio
files
that
yields
very
high
near-CD
quality.
WMA
Windows
media
audio
file.
A
type
of
coding
/
decoding
developed
by
Microsoft
Corp.
JPEG
Joint
Pictures
Expert
Group.
JPEG
is
a
compressed
file
format
that
allows
you
to
save
images
with
no
limit
on
the
number
of
colors.
DivX
DivX
is
the
name
of
a
revolutionary
new
video
codec
which
is
based
on
the
new
MPEG-4
compression
standard
for
video.You
will
be
able
to
play
DivX
movies
using
this
DVD
player.
7
Introduction
PBC:
Playback
Control
(Video
CD
only)
Playback
control
is
available for
Video
CD
(VCD)
version
2.0
disc
for-
mats.
PBC
allows
you
to
interact
with
the
system
via
menus,
search
func-
tions,
or
other
typical
computer-like
operations.
Moreover,
still
pictures
of
high
resolution
can
be
played
if
they
are
included
in
the
disc.
Video
CDs
not
equipped
with
PBC
(Version
1.1)
operate
in
the
same
way
as
audio
CDs.
Title
(DVD
video
discs
only)
A
title
is
generally
a
distinct
section
of
a
DVD
disc.
For
example
the
main
feature
could
be
title
1,
a
documentary
describing
how
the
film
was
made
could
be
title
2,
and
cast
interviews
could
be
title
3.
Each
title
is
assigned
a
reference
number
enabling
you
to
locate
it
easily.
Maintenance
and
Service
Refer
to
the
information
in
this
chapter
before
contacting
a
service
technician.
Handling
the
Unit
When
shipping
the
unit
Please
save
the
original
shipping
carton
and
packing
materials.
If
you
need
to
ship
the
unit,
for
maximum
protection,
re-pack
the
unit
as
it
was
originally
packed
at
the
factory.
Keeping
the
exterior
surfaces
clean
?
Do
not
use
volatile
liquids
such
as
insecticide
spray
near
the
unit.
?
Do
not
leave
rubber
or
plastic
products
in
contact
with
the
unit
for
a
long
period
of
time.
since
they
leave
marks
on
the
surface.
Cleaning
the
unit
To
clean
the
player,
use
a
soft,
dry
cloth.
If
the
surfaces
are
extremely
dirty,
use
a
soft
cloth
lightly
moistened
with
a
mild
detergent
solution.
Do
not
use
strong
solvents
such
as
alcohol,
benzine,
or
thinner,
as
these
might
damage
the surface
of
the
unit.
Maintaining
the
Unit
The
DVD
player
is
a
high-tech,
precision
device.
If
the
optical
pick-up
lens
and
disc
drive
parts
are
dirty
or
worn,
the
picture quality
could
be
diminished.
Depending
on
the
operating
environment,
regular
inspection
and
mainte-
nance
are
recommended
after
every
1,000
hours
of
use.
For
details,
please
contact
your
nearest
authorized
service
center.
Before
Use
(Continued)
8
Before
Use
(Continued)
Types
of
Playable
Discs
DVD
(8cm/12cmdisc)
Video
CD
(VCD)
(8cm/12cmdisc)
Audio
CD
(8cm/12cmdisc)
In
addition,
this
unit
plays
DivX
file,
DVD±R,
DVD±RW,
SVCD,
and
CD-R
or
CD-RW
that
contains
audio
titles,
MP3,
WMA
or
JPEG
files.
This
indicates
a
product
feature
that
is
capable
of
playing
DVD-RW
discs
recorded
with
Video
Recording
format.
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby",
"Pro
Logic",
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
DTS
and
DTS
Digital
Out
are
trademarks
of
Digital
Theater
Systems,
Inc.
NOTES
?
Depending
on
the
conditions
of
the
recording
equipment
or
the
CD-R/RW
(or
DVD±R/±RW)
disc
itself,
some
CD-R/RW
(or
DVD±R/±RW)
discs
cannot
be
played
on
the
unit.
?
Do
not
attach
any
seal
or
label
to
either
side
(the
labeled
side
or
the
recorded
side)
of
a
disc.
?
Do
not
use
irregularly
shaped
CDs
(e.g.,
heart-shaped
or
octagonal).
It
may
result
in
malfunctions.
Notes
on
DVDs
and
Video
CDs
Some
playback
operations
of
DVDs
and
Video
CDs
may
be
intention-
ally
programmed
by
software
manufacturers.
This
unit
plays
DVDs
and
Video
CDs
according
to
disc
content
designed
by
the
software
manufacturer,
therefore
some
playback
features
may
not
be
available
or
other
functions
may
be
added.
Regional
code
This
DVD
player
is
designed
and
manufactured
for
playback
of
region
"1"
encoded
DVD
software.
This
unit
can
play
only
DVD
discs
labeled
"1"
or
"ALL".
Notes
on
Regional
Codes
?
Most
DVD
discs
have
a
globe
with
one
or
more
numbers
in
it
clearly
visible
on
the
cover.
This
number
must
match
your
DVD
player
's
regional
code
or
the
disc
cannot
play.
?
If
you
try
to
play
a
DVD
with
a
different
region
code
from
your
player,
the
message
"Check
Regional
Code"
appears
on
the
screen.
1
9
Introduction
Identification
of
Controls
1
2
3
4
5
6
10
9
7
8
1.
LCD
screen
2.
Speaker
3.
COLOR
control
buttons
:
--
;
black
and
white,
+
;
color
4.
BRIGHT
control
buttons
:
--
;
dark,
+
;
light
5.
POWER
Switches
the
player
ON
and
OFF.
6.
A/V
IN/OUT
Selects
the
TV's
source.
7.
?
bBvV(left/right/up/down)
Selects
an
item
in
the
menu.
?
ENTER
Confirms
menu
selection.
8.
?
TITLE
Displays
title
menu,
if
available.
?
LCD
MODE
NORMAL
→
FULL
→
ZOOM
→
OFF
?
MENU
Accesses
menu
on
a
DVD
disc.
?
DISPLAY
Accesses
On-Screen
display.
?
SETUP
Accesses
or
removes
setup
menu.
9.
Disc
Lid
10.
OPEN
button
Push
this
button
to
open
the
Disc
lid.
NOTE
Place
a
disc
with
the
playback
side
down
on
the
spindle,
and
push
gently
on
the
center
of
the
disc
so
it
goes
into
position.
Main
Unit
1.
Remote
sensor
2.
Charge
indicator
During
recharging,
charge
indicator
is
red.
If
recharging
is
complete,
charge
indicator
changes
to
green
color.
3.
Reverse
Skip/Search
Go
to
previous
chapter
/
track
or
to
the
beginning.
Press
and
hold
for
two
seconds
for
fast
reverse
search.
4.
Forward
Skip/Search
Go
to
the
next
chapter
/
track.
Press
and
hold
for
two
seconds
for
fast
forward
search.
5.
PLAY
Starts
playback.
6.
PAUSE
Pause
playback
temporarily/press
repeatedly
for
frame-by-frame
playback.
7.
STOP
Stops
playback.
8.
Volume
Control
9.
Earphone
jack
10.
AUDIO
In/Out
jack
(OPTICAL
OUT)
11.
VIDEO
In/Out
jack
12.
DC
IN
9.5V
Connect
the
AC
adapter.
13.
Battery
Pack
Identification
of
Controls
(continued)
10
Main
Unit
12
34567
8
9
101112
13
11
Introduction
1.
AUDIO
Selects
an
audio
language
(DVD).
2.
POWER
Switches
DVD
Player
ON
and
OFF.
3.
?
Reverse
SKIP/SEARCH
(
S
)
Search
backward*/
go
to
beginning
of
current
chapter
or
track
or
go
to
previous
chapter
or
track.
?
Forward
SKIP/SEARCH
(
T
)
Search
forward*/
go
to
next
chapter
or
track.
*
Press
and
hold
button
for
about
two
seconds.
4.
PLAY
Starts
playback.
5.
PAUSE
Pauses
playback
temporarily/
press
repeatedly
for
frame-by-frame
playback.
6.
MENU
Accesses
menu
on
a
DVD
disc.
7.
?
bBvV(left/right/up/down)
Selects
an
item
in
the
menu.
?
ENTER
Confirms
menu
selection.
8.
SETUP
Accesses
or
removes
setup
menu.
9.
0-9
number
buttons
Selects
numbered
items
in
a
menu.
10.
SUBTITLE
Selects
a
subtitle
language.
11.
A-B
Repeat
sequence.
12.SLOW(,/.)
Reverse/
Forward
slow
playback.
13.STOP(x)
Stops
playback.
14.
ZOOM
Enlarges
video
image.
15.
TITLE
Displays
title
menu,
if
available.
16.
DISPLAY
Accesses
On-Screen
display.
17.
?
MARKER
Marks
any
point
during
playback.
?
SEARCH
Displays
MARKER
SEARCH
menu.
18.
REPEAT
Repeat
chapter,
track,
title
all.
19.
RETURN
Removes
the
setup
menu,
displays
the
video
CD
with
PBC.
20.
PROG.
Places
a
track
on
the
program
list.
21.
CLEAR
Removes
a
track
number
on
the
program
list
or
a
mark
on
the
MARKER
SEARCH
menu.
Identification
of
Controls
(continued)
PLAY
POWER
STOP
SKIP/SEARCH
MARKER
SEARCH
123
456
789
0
RETURN
PROG
TITLE
MENU
CLEAR
AUDIO
SUBTITLE
REPEAT
A-B
ZOOM
SLOW
PAUSE
ENTER
SETUP
DISPLAY
1
2
3
45
6
7
8
9
10
11
12
14
13
15
16
17
18
19
20
21
Remote
Control
Insert
the
battery
(Lithium
battery)
NOTES
?
Do
not
expose
the
remote
control
sensor
to
bright
light.
?
Do
not
place
obstacles
between
the
remote
control
sensor
and
the
remote
control.
V
Replacing
the
button-type
battery
The
battery
normally
lasts
for
about
a
year.
Replace
the
battery
if
the
remote
control
fails
to
operate
the
unit
when
used
within
the
operation
range.
Button-type
battery
(Lithium
battery)
1.
Pinch
the
battery
holder
clip
together
then
pull
the
tab
to
remove
the
battery
holder.
2.
Insert
the
battery
with
the
+
facing
in
the
same
direction
as
the
+
on
the
battery
holder.
3.
Replace
the
battery
holder
with
battery
into
the
remote
control
unit
making
sure
that
it
is
fully
inserted.
?
Replace
remote
control
unit
battery
with
3V
micro
lithium
cells
such
as
CR.
2025
or
its
equivalent.
?
Dispose
of
battery
safety
in
accordance
with
local
laws.
Do
not
dispose
of
in
fire.
Identification
of
Controls
(continued)
12
Warning
:
The
battery
used
in
this
device
may
present
a
fire
or
chemi-
cal
burn
hazard
if
mistreated.
Do
not
recharge,
disassemble,
incinerate,
or
heat
above
100
°C
(212
°F).
Replace
the
battery
with
Matsushita
Elec.
Ind.
Co.,
Ltd.
(Panasonic),
part
no.
CR.
2025
only.
Use
of
another
battery
may
present
a
risk
of
fire
or
explosion.
Dispose
of
used
batteries.
Keep
batteries
away
from
children.
Do
not
disassem-
ble
or
dispose
of
in
fire.
13
Introduction
Caution
?
Do
not
connect
the
power
plug
to
a
power
outlet
other
than
that
indicated
on
the
label,
as
this
can
result
in
a
risk
of
fire
or
electric
shock.
?
Do
not
connect
or
disconnect
the
power
plug
with
wet
hands.
Doing
so
may
cause
electric
shock.
?
Do
not
use
an
AC
adapter
other
than
one
specified,
as
it
can
cause
a
fire
or
damage
to
the
player.
AC
adapter
?
This
AC
adapter
operates
on
100-240V~
1.5A
50-60Hz.
?
MODEL
NO.
:
DP-AC90
?
Manufactured
by
WANLIDA
Digital
Technology
Co.,
Ltd.
?
Contact
an
electrical
parts
distributor
for
assistance
in
selecting
a
suitable
AC
plug
adapter
or
AC
cord
set.
Power
Connections
AC
Adapter
Follow
steps
1
to
3
to
connect.
When
disconnecting,
reverse
the
order.
14
Caution
?
To
prevent
electrical
shock
and
possible
damage
to
your
DVD
player
or
vehicle,
always unplug
the
automotive
adapter
from
the
cigarette
lighter
socket
before
you
remove
the
plug
from
your
DVD
player.
?A3
amp.
250Vfuse
for
protection
is
installed
in
the
automotive
adapter.
?
While
the
engine
is
being
started,
disconnect
the
automotive
adapter
from
the
car's
cigarette
lighter
socket.
?
Do
not
operate
your
DVD
player
when
the
car
battery
is
discharged.
Peak
current
from
the
car
generator
may
cause
the
DC
fuse
to
blow.
?
If
the
vehicle's
supply
voltage
drops
below
approximately
10
volts,
your
DVD
player
may
not
work
properly.
?
Do
not
leave
your
DVD
player
in
a
place
where
the
temperature
exceeds
70 C
(158 F),
or
the
pick-up
device
may
be
damaged.
Examples
include:
-
Inside
a
car
with
the
windows
closed
and
in
direct
sunshine.
-
Near
a
heating
appliance.
Automotive
adapter
?
This
automotive
adapter
operates
on
DC
12V.
?MODELNO.
:
DPB-C90
?
Manufactured
by
WANLIDA
Digital
Technology
Co.,
Ltd.
?
Contact
an
electrical
parts
distributor
for
assistance
in
selecting
a
suitable
automotive
adapter.
Power
Connections
(continued)
1
2
Automotive
Adapter
Follow
steps
1
to
2
to
connect.
When
disconnecting,
reverse
the
order.
This
DVD
player
and
its
automotive
adapter
are
designed
for
use
in
vehicles
that
have
12
volt,
negative
ground
electrical
sys-
tems.
(This
is
standard
for
most
vehicles.)
If
your
vehicle
has
a
different
type
of
electrical
system,
the
DC
power
system
can-
not
be
used.
Cigarette
lighter
socket
15
Introduction
?
Charge
the
battery
pack
before
using
it
for
the
first
time.
A
Attaching
the
battery
pack
1.
Match
the
hooks
of
the
battery
pack
into
the
holes
on
the
bottom
of
the
player.
2.
Combine
the
battery
pack
to
push
toward
up
until
you
can
hear
the
click
sound.
A
Detaching
the
battery
pack
To
separate
the
battery
pack,
pull
the
switch
which
is
locate
beside
the
battery
pack
then
slide
down
the
battery
pack
at
the
same
time.
Power
Connections
(continued)
Battery
Pack
ATTENTION
The
product
that
you
have
purchased
contains
a
rechargeable
battery.
The
battery
is
recyclable.
At
the
end
of
it's
useful
life,
under
various
state
and
local
laws,
it
may
be
illegal
to
dispose
of
this
battery
into
the
municipal
waste
stream.
Check
with
your
local
solid
waste/officials
for
details
in
your
area
for
recycling
options
or
prop-
er
disposal.
2
1
Hooks
2
1
16
A
Charging
the
battery
pack
1.
Attach
the
battery
pack
to
the
player.
2.
Connect
the
AC
power
adapter
to
the
player
and
the
plug
into
an
AC
outlet.
3.
During
recharging,
charge
indicator
is
red.
If
recharging
is
complete,
charge
indicator
changes
to
green
color.
CAUTION
Take
the
following
precautions
to
avoid
liquid
leakage,
overheating,
etc.
?
Do
not
use
any
unauthorized
parts.
?
Use
the
authorized
AC
adapter
when
recharging
battery.
?
Do
not
expose
to
high
temperature
above
60°C
(140°F).
?
Do
not
attempt
to
dismantle
or
modify
the
unit.
?
Excessive
impact
may
cause
the unit
to
malfunction.
?
Do
not
incinerate.
?
Do
not
disassemble;
dispose
of
properly.
?
Do
not
short-circuit.
NOTE
Charging
a
battery
only
happens
when
the
power
is
off.
The
battery
will
not
be
charged
when
it
is
naturally
or
purposely
discharged.
Because
the
unit
cannot
perceive
battery
voltage,
even
if
you
attached
the
battery.
When
you
are
in
this
situation,
power
on
the
unit
and
then
power
off
again.
Then
battery
charge
will
proceed.
A
Recharging
and
play
times
*
When
Brightness
control
is
set
to
initial
mode.
A
Press
"Display"
to
display
the
battery
status
on
the
screen.
?
If
using
the
AC
adapter,
battery
display
does
not
appear.
A
If
play
time
dramatically
reduces
after
recharging
The
battery
pack
has
reached
the
end
of
its
service
life
(it
can
be
recharged
about
300
times).
AIftheunitisnottobeusedforalongtime
?
Detach
the
battery
pack.
(Even
if
the unit
is
off,
it
still
uses
some
power.
This
can
lead
to
over
discharging
of
the
battery
and
malfunction.)
?
Recharge
the
battery
pack
when
you
are
ready
to
use
it
again.
A
Battery
Pack
?
MODEL
NO.
:
DP-BS930
Power
Connections
(continued)
Battery
Pack
Player
AC
adapter
cord
insert
jack
(DC
IN
9.5V)
Charge
indicator
Recharging
Play
time
without
player
LCD
On
LCD
Off
Approx. Approx.
Approx.
3.5
hour
3
hours*
4
hours
17
Introduction
1.
Prepare
the
power
supply.
2.
Open
the
outer
cover
and
press
POWER
button.
3.
Press
OPEN
to
open
the
disc
lid
and
insert
a
disc
with
the
side
you
want
to
play
label
up.
Close
the
disc
lid
by
hand.
?
If
the disc
is
placed
in
upside
down
(and
it
is
a
single-sided
disc),
"NO
DISC"
or
"DISC
ERROR"
appears
on
the
screen.
?
After
playing
back
all
of
the
chapters
in
the
title,
the
DVD
player
automati-
cally
stops
and
returns
to
the
menu
screen.
4.
Press
PLAY
to
start
play.
5.
Adjust
the
volume.
NOTES
?
Place
a
disc
with
the
playback
side
down
on
the
spindle,
and
push
gently
on
the
center
of
the
disc
so
it
goes
into
position.
?
Confirm
LCD
MODE
position
by
pressing
LCD
MODE
button.
A
Changing
the
size
of
the
Use
the
LCD
MODE
button
to
change
the
mode.
The
mode
is
shown
on
the
unit's
display
as
follows.
NORMAL
→
FULL
→
ZOOM
→
OFF
NOTE
May
appear
to
differ
according
to
kind
of
disc.
A
The
mode
and
size
The
shown
on
the
LCD
depends
on
the
display
mode
and
the
size
recorded
on
the
disc.
NOTES
?
If
you
are
not
using
the
LCD
on
this
unit,
select
OFF
to
conserve
power.
?
The
LCD
is
turned
off
if
you
close
the
unit.
?
Horizontal
lines
may
appear
in
the
when
the
mode
is
switched
to
ZOOM,
but
this
is
not
an
indication
of
a
malfunction.
Playing
a
Disc
You
can
display
the
general
playback
status
on
the
screen.
Some
items
can
be
changed
using
the
menu.
To
use
the
on-screen
display:
1.
Press
DISPLAY
during
playback.
2.
Press
v
/
V
to
select
an
item.
The
selected
item
is
highlighted.
3.
Press
b
/
B
to
change
the
setting.
You
can
also
use
the
number
but-
tons
if
appropriate
(e.g.
inputting
the
title
number).
For
some
functions,
press
ENTER
to
execute
the
setting.
NOTES
?
Some
discs
may
not
provide
all
of
the
features
shown
below.
?
If
no
button
is
pressed
for
10
seconds,
the
on-screen
display
disappears.
Playback
Status/Restrictions
Repeat
title
Repeat
sequence
Enter
a
Marker
Marker
Search
menu
Resume
play
from
this
point
Action
prohibited
or
not
available
MARKER
SEARCH
1/9
Title
On-Screen
Display
18
Items
Title
Number
Chapter
Number
Time
search
Audio
language
and
Digital
Audio
Output
mode
Subtitle
language
Angle
Selection
Method
b
/
B,
Numbers
ENTER
b
/
B,
Numbers
ENTER
Numbers,
ENTER
b/Bor
AUDIO
b/Bor
SUBTITLE
b/B
1/3
1/12
0:20:09
ABC
1
ENG
1/3
Example:
On-Screen
Display
during
playing
DVD
Video
19
Advanced Operations
On-Screen
Display
(continued)
Example:
On-Screen
Display
during
playing
VCD
Items
Track
Number
(or
PBC
mode)
Time
search
Audio
Channel
Selection
Method
b
/
B,
Numbers
ENTER
Numbers
ENTER
b/Bor
AUDIO
1/3
0:20:09
Items
Track
Number
Time
search
Audio
language
and
Digital
Audio
Output
mode
Subtitle
language
Selection
Method
b
/
B,
Numbers
ENTER
Numbers,
ENTER
b/Bor
AUDIO
b/Bor
SUBTITLE
1/3
0:20:09
MP3
1
ABC
ENG
Example:
On-Screen
Display
during
playing
divx
movie
disc
Use
the
bBvVbuttons
to
select
the
title/chapter
you
want
to
view,
then
press
ENTER
to
start.
Press
TITLE
or
MENU
to
return
to
the
menu
screen.
Use
the
number
buttons
to
select
the
track
you
want
to
view
and
press
RETURN
to
return
to
the
menu
screen.
Menu
settings
and
operating
procedures
may
differ.
Follow
the
instructions
on
the
each
menu
screen.
You
also
may
set
PBC
to
Off
(See
"PBC"
on
page
36).
NOTES
?
If
parental
control
is
set
and
the
disc
is
not
within
the
rating
settings
you
must
input
the
password.
(See
"Lock
Menu"
on
page
38-39.)
?
DVDs
may
have
a
region
code.
Your
player
does
not
play
discs
that
have
a
region
code
different
from
your
player.
The
region
code
for
this
player
is
1
(one).
Unless
stated
otherwise,
all
operations
described
use
the
remote
control.
Some
features
may
also
be
available
on
the
Setup
menu.
Moving
to
another
TITLE
When
a
disc
has
more
than
one
title,
you
can
move
to
another
title.
Press
DISPLAY
while
playback
is
stopped
then
the
appropriate
number
(0-9)
or
use
b
/
B
to
move
to
another
title.
You
can
play
any
title
by
inputting
its
number
while
playback
is
stopped.
Moving
to
another
CHAPTER/TRACK
When
a
title
on
a
disc
has
more
than
one
chapter
or
a
disc
has
more
than
one
track,
you
can
move
to
another
chapter/track
as
follows:
?
Press
SKIP/SEARCH
.
or
>
briefly
during
playback
to
select
the
next
chapter/track
or
to
return
to
the
beginning
of
the
current
chapter/track.
?
Press
SKIP/SEARCH
.
twice
briefly
to
step
back
to
the
previous
chapter/track.
?T
o
go
directly
to
any
chapter
during
DVD
playback,
press
DISPLAY
and
press
v
/
V
to
select
the
chapter/track
icon.
Then,
input
the
chapter/track
number
or
use
b
/
B.
Search
1.
Press
and
hold
SKIP/SEARCH
.
or
>
for
about
two
seconds
during
playback.
The
player
will
now
go
into
SEARCH
mode.
2.
Press
and
hold
SKIP/SEARCH
.
or
>
repeatedly
to
select
the
required
speed:
mX2,
mX4,
mX16,
mX100
(backward)
or
MX2, MX4,
MX16,
MX100
(forward).
With
a
Video
CD,
the
Search
speed
changes:
mX2, mX4,
mX8,
(backward)
or
MX2,
MX4, MX8,
(forward).
3.
To
exit
SEARCH
mode,
press
PLAY.
General
Features
20
21
Advanced Operations
Still
and
Frame-by-Frame
Playback
1.
Press
PAUSE
on
the
remote
control
during
playback.
Advance
the
frame-by-frame
by
pressing
PAUSE
repeatedly.
2.
To
exit
still
motion
mode,
press
PLAY.
Slow
Motion
1.
Press
SLOW
t
or
T
during
playback.
The
player
will
enter
SLOW
mode.
2.
Use
the
SLOW
t
or
T
to
select
the
required
speed:
t
1/16,
t1/8,t1/4ort1/2(backward),orT1/16,T1/8,T1/4or
T
1/2
(forward).
3.
To
exit
slow
motion
mode,
press
PLAY.
NOTE
Slow
motion
playback
in
reverse
is
not
applicable
for
Video
CD
and
DivX
Discs.
Time
Search
To
start
playing
at
any
chosen
time
on
the
disc:
1.
Press
DISPLAY
during
playback.
The
time
search
box
shows
the
elapsed
playing
time.
2.
Press
v
/
V
to
select
the
time
clock
icon
and
"-:--:--"
appears.
3.
Input
the
required
start
time
in
hours,
minutes,
and
seconds
from
left
to
right.
If
you
enter
the
wrong
numbers,
press
CLEAR
to
remove
the
numbers
you
entered.
Then
input
the
correct
numbers.
4.
Press
ENTER
to
confirm.
Playback
starts
from
the
selected
time.
Repeat
A-B
To
repeat
a
sequence.
1.
Press
A-B
at
your
chosen
starting
point.
"
A
*
"
appears
briefly
on
the
screen.
2.
Press
A-B
again
at
your
chosen
end
point.
"A
B"
appears
briefly
on
the
screen
and
the
repeat
sequence
begins.
3.
Press
A-B
again
to
cancel.
Repeat
You
can
play
a
title/chapter/all/track
on
a
disc.
Press
REPEAT
during
playback
to
select
a
desired
repeat
mode.
DVD
Video
Discs
-
Repeat
Chapter/Title/Off
?
Chapter:
repeats
the
current
chapter.
?
Title:
repeats
the
current
title.
?
Off
:
does
not
play
repeatedly.
Video
CDs,
DivX
discs
-
Repeat
Track/All/Off
?
Track
:
repeats
the
current
track
?
All
:
repeats
all
the
tracks
on
a
disc.
?
Off
:
does
not
play
repeatedly.
NOTES
?
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
Off
on
the
setup
menu
to
use
the
repeat
function
(See
"PBC"
on
page
36).
?
If
you
press
SKIP
(>)
once
during
Repeat
Chapter
(Track)
playback,
the
repeat
playback
cancels.
General
Features
(continued)
General
Features
(continued)
22
Marker
Search
Storing
a
MARKER
in
the
DVD
memory
is
similar
to
marking
your
page
in
a
book.
It
allows
you
to
quickly
return
to
any
point
on
the
disc.
Storing
a
marker
in
the
memory
1.
Press
MARKER/SEARCH
during
play.
The
MARKER
SEARCH
menu
appears
on
the
screen.
2.
During
playback,
press
ENTER
when
playback
reaches
the
spot
that
you
want
to
memorize.
?
The
Marker
number
appears.
?
Do
this
within
10
seconds
while
the
MARKER
SEARCH
menu
appears.
?T
o
enter
additional
Marker
points,
press
F/G
until
another
empty
point
on
the
MARKER
SEARCH
menu
is
highlighted,
then
press
ENTER
when
playback
reaches
the
point
at
which
you
want
the
next
Marker.
3.
Repeat
step
2
to
enter
up
to
nine
Marker
points
on
a
disc.
4.
To
remove
the
MARKER
SEARCH
menu,
press
MARKER/SEARCH.
Recalling/Clearing
a
marker
5.
Press
MARKER/SEARCH
during
playback.
The
MARKER
SEARCH
menu
will
appear
on
the
screen.
6.
Press
F/G
to
select
the
marker
to
be
recalled/
cleared.
7.
Press
ENTER
to
recall
a
marker.
Press
CLEAR
to
clear
a
marker.
Play
resumes
from
the
point
corresponding
to
the
selected
marker,
or
the
selected
marker
is
cleared.
NOTES
?
These
operations
work
only
with
discs
for
which
the
elapsed
playing
time
appears
in
the
display
window
during
playback
or
stop.
?
Some
subtitles
recorded
around
the
marker
may
fail
to
appear
(DVD).
?
All
the
markers
are
cleared
when
the
power
is
turned
off
or
the
disc
is
removed.
?
The
marker
is
not
stored
when
the
DVD
or
title
menu
is
displayed
on
the
screen.
23
Advanced Operations
General
Features
(continued)
Zoom
Use
zoom
to
enlarge
the
video
image.
1.
Press
ZOOM
during
playback
or
still
playback
to
activate
the
Zoom
function.
The
square
frame
appears
briefly
in
the
right
bottom
of
the
picture.
2.
Each
press
of
the
ZOOM
button
changes
the
screen
in
the
sequence:
100%
size
→
400%
size
→
1600%
size
→
screen
fit
mode
→
100%
size
Screen
fit
mode:
You
can
change
the
way
the
appears
on
the
screen
when
you're
playing
a
DVD
movie.
Press
3/4
to
select
between
Normal,
Enhanced,
and
Maximum.
3.
Use
the
bBvVbuttons
to
move
through
the
zoomed
picture.
4.
To
resume
normal
playback,
press
CLEAR.
NOTES
?
Zoom
may
not
work
on
some
DVDs.
?
Screen
fit
mode
is
available
for
playing
the
DVD
disc,
VR
disc
and
movie
file.
Resume
Play
When
play
is
stopped,
the
unit
records
the
point
where
STOP
was
pressed
(RESUME
function).
Press
PLAY
and
play
will
resume
from
this
point.
Special
DVD
Features
Checking
the
contents
of
DVD
discs:
Menus
DVDs
may
offer
menus
that
allow
you
to
access
special
features.
To
use
the
disc
menu,
press
MENU.
Input
the
corresponding
number
or
use
the
bBvVbuttons
to
highlight
your
selection.
Then
press
ENTER.
Title
Menu
1.
Press
TITLE.
If
the
current
title
has
a
menu,
the
menu
appears
on
the
screen.
Otherwise,
the
disc
menu
may
appear.
2.
The
menu
offers
features
such
as
camera
angles,
spoken
language
and
subtitle
options,
and
chapters
for
the
title.
3.
Press
TITLE
to
exit.
Disc
Menu
Press
MENU
and
the
disc
menu
is
displayed.
Press
MENU
again
to
exit.
Changing
the
Audio
Language
Press
AUDIO
repeatedly
during
playback
to
hear
a
different
audio
lan-
guage
or
audio
track.
With
DVD-RW
discs
recorded
in
VR
mode
that
have
both
a
main
and
a
Bilingual
audio
channel,
you
can
switch
between
Main
(L),
Bilingual
(R),
or
a
mix
of
both
(Main
+
Bilingual)
by
pressing
AUDIO.
Camera
Angle
If
the
disc
contains
scenes
recorded
at
different
camera
angles,
you
can
change
to
a
different
camera
angle
during
playback.
1.
Press
DISPLAY
during
playback.
2.
Press
D/E
to
select
Angle
item.
3.
Press
F/G
repeatedly
until
the
desired
Angle
is
selected.
TIP
The
angle
indicator
will
blink
on
the
screen
during
scenes
recorded
at
different
angles
as
an
indication
that
angle
switching
is
possible.
Subtitles
Press
SUBTITLE
repeatedly
during
playback
to
see
the
different
subtitle
languages.
NOTES
?
The
subtitle
file
of
the
DivX
file
is
displayed
only
smi,
srt
and
sub.
?
If
there
is
no
information
or
there
is
a
code
that
can
not
read
in
the
DivX
file,
"
1
"
etc
are
displayed.
Last
Scene
Memory
This
player
memorizes
last
scene
from
the
last
disc
that
is
viewed.
The
last
scene
remains
in
memory
even
if
you
remove
the
disc
from
the
player
or
switch
off
the
player.
If
you
load
a
disc
that
has
the
scene
memorized,
the
scene
is
automatically
recalled.
NOTES
?
Settings
are
stored
in
memory
for
use
any
time.
?
This
player
does
not
memorize
settings
of
a
disc
if
you
switch
off the
player
before
commencing
to
play
it.
Screen
Saver
The
screen
saver
appears
when
you
leave
the
DVD
player
in
Stop
mode
for
about
five
minutes.
If
the
Screen
Saver
is
displayed
for
five
minutes,
the
DVD
Player
automatically
turns
itself
off.
Changing
the
Audio
Channel
Press
AUDIO
repeatedly
during
playback
to
hear
a
different
audio
chan-
nel
(STEREO,
LEFT,
or
RIGHT).
General
Features
(continued)
24
25
Advanced Operations
The
DVD
player
can
play
MP3/WMA
formatted
recordings
on
CD-ROM,
CD-R,
or
CD-RW
discs.
Audio
CD
Once
you
insert
an
audio
CD
a
menu
appears
on
the
screen.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER
and
playback
starts.
MP3
/
WMA
1.
Press
v
/
V
to
select
a
folder,
and
press
ENTER
to
see
the
folder
contents.
2.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER.
Playback
starts.
ID3
TAG
?
When
playing
a
file
containing
information
such
as
track
titles,
you
can
see
the
information
by
pressing
DISPLAY.
[
Title,
Artist,
Album,
Year,
Comment
]
?
If
there
is
no
information,
"NO
ID3
TAG"
appears
on
the
display.
TIPS
?
If
you
are
in
a
file
list
on
the
MUSIC
menu
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
to
highlight
and
press
ENTER.
?
Press
MENU
to
move
to
the
next
page.
?
On
a
CD
with
MP3/WMA
and
JPEG
you
can
switch
MP3/WMA
and
JPEG.
Press
TITLE
and
MUSIC
or
word
on
top
of
the
menu
is
highlighted.
Playing
an
Audio
CD
or
MP3/WMA
Disc
Program
List
Track1
Track2
Track3
Track4
Track5
Track6
Track7
Track8
AUDIO
CD
0:52:07
1/12
Clear
All
Program
List
0:00:00
1/12
Clear
All
MUSIC
2-Music2
1-Music1
3-Music3
4-Music4
5-Music5
6-Music6
7-Music7
Audio
CD
and
MP3
/
WMA
Disc
Features
Pause
1.
Press
PAUSE
during
playback.
2.
To
return
to
playback,
press
PLAY,
ENTER
or
press
PAUSE
again.
Moving
to
another
Track
1.
Press
SKIP/SEARCH
(.
or
>)
briefly
during
playback
to
go
to
the
next
track
or
to
return
to
the
beginning
of
the
current
track.
2.
Press
SKIP/SEARCH
.
twice
briefly
to
go
back
to
the
previous
track.
3.
You
can
play
any
track
by
inputting
its
number.
Search
1.
Press
and
hold
SKIP/SEARCH
(.
or
>)
for
about
two
seconds
during
playback.
The
player
will
now
go
into
SEARCH
mode.
2.
Press
and
hold
SKIP/SEARCH
(.
or
>)
repeatedly
to
select
the
required
speed:
mX2,
mX4,
mX8
(backward)
or
MX2,
MX4,
MX8
(forward).
Search
speed
and
direction
are
indicated
on
the
menu
screen.
3.
To
exit
SEARCH
mode,
press
PLAY.
Repeat
Track/All/Off
You
can
play
a
track/all
on
a
disc.
1.
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2.
Press
REPEAT
to
select
a
desired
repeat
mode.
?
Track:
repeats
the
current
track
?
All:
repeats
all
the
tracks
on
a
disc.
?
Off(No
display):
does
not
play
repeatedly.
NOTE
If
you
press
SKIP
(>)
once
during
Repeat
Track
playback,
the
repeat
playback
cancels.
Repeat
A-B
1.
To
repeat
a
sequence
during
disc
playback
press
A-B
at
your
chosen
starting
point.
The
Repeat
icon
and
"A"
appear
on
the
menu
screen.
2.
Press
A-B
again
at
your
chosen
end
point.
The
Repeat
icon
and
"A-
B"
appear
on
the
menu
screen,
and
the
sequence
begins
to
play
repeatedly.
3.
To
exit
the
sequence
and
return
to
normal
play,
press
A-B
again.
Playing
an
Audio
CD
or
MP3/WMA
Disc
(continued)
26
27
Advanced Operations
MP3
/
WMA
disc
compatibility
with
this
player
is
limited
as
follows:
?
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48kHz
(WMA)
?
Bit
rate:
within
8
-
320kbps
(MP3),
32
-
192kbps
(WMA)
?
The
player
cannot
read
an
MP3/WMA
file
that
has
a
file
extension
other
than
".mp3"
/
".wma".
?
CD-R
physical
format
should
be
ISO
9660
?
If
you
record
MP3
/
WMA
files
using
software
that
cannot
create
a
file
system
(eg.
Direct-CD)
it
is
impossible
to
playback
MP3
/
WMA
files.
We
recom-
mend
that
you
use
Easy-CD
Creator,
which
creates
an
ISO
9660
file
system.
?
File
names
should
have
a
maximum
of
8
letters
and
must
incorporate
an
.mp3
or
.wma
extension.
?
They
should
not
contain
special
letters
such
as
/
?
*
:
"
< >
l
etc.
?
The
total
number
of
files
on
the disc
should
be
less
than
650.
This
DVD
player
requires
discs
and
recordings
to
meet
certain
technical
standards
in
order
to
achieve
optimal
playback
quality.
Pre-recorded
DVDs
are
automatically
set to
these
standards.
There
are
many
different
types
of
recordable
disc
formats
(including
CD-R
containing
MP3
or
WMA
files)
and
these
require
certain
pre-existing
conditions
(see
above)
to
ensure
compatible
playback.
Customers
should
note
that
permission
is
required
in
order
to
download
MP3
/
WMA
files
and
music
from
the
Internet.
Our
com-
pany
has
no
right
to
grant
such
permission.
Permission should
always
be
sought
from
the
copyright
owner.
Playing
an
Audio
CD
or
MP3/WMA
Disc
(continued)
The
program
function
enables
you
to
store
your
favorite
tracks
from
any
disc
in
the
player
memory.
A
program
can
contain
30
tracks.
1.
Insert
a
disc.
Audio
CD
or
MP3/WMA
Discs:
AUDIO
CD
or
MUSIC
menu
appears.
2.
Press
PROG.
The mark
will
appear
to
the
right
of
the
word
"Program"
on
the
right
side
of
the
menu
screen.
NOTE
Press
PROG.
again,
then
the
mark
will
disappear
to
exit
the
Program
Edit
mode.
Audio
CD
Menu
MP3/WMA
Menu
Video
CD:
Press
PROG.
while
playback
is
stopped.
The
program
menu
appears.
Press
PROG.
again
and
hold
it
down
for
a
few
seconds
to
exit
the
menu.
NOTE
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
Off
on
the
setup
menu
to
use
the
programmed
playback
(See
"PBC"
on
page
36).
Video
CD
Menu
3.
Select
a
track
on
the
"List",
then
press
ENTER
to
place
the
selected
track
on
the
"Program"
list.
Repeat
to
place
additional
tracks
on
the
list.
4.
Press
B.
Select
the
track
you
want
to
start
playing
on
the
"Program"
list.
5.
Press
PLAY
or
ENTER
to
start.
Playback
begins
in
the
order
in
which
you
programmed
the
tracks.
Playback
stops
after
all
of
the
tracks
on
the
"Program"
list
have
played
once.
6.
To
resume
normal
playback
from
programmed
playback,
select
a
track
of
AUDIO
CD
(or
MUSIC)
list
and
then
press
PLAY.
E
E
Programmed
Playback
28
Program
List
Track1
Track1
Track4
Track7
Track5
Track2
Track3
Track4
Track5
Track6
Track7
Track8
AUDIO
CD
0:52:07
1/12
Clear
All
E
Program
List
0:00:00
1/12
Clear
All
E
MUSIC
2-Music2
2-Music2
4-Music4
6-Music6
1-Music1
1-Music1
3-Music3
4-Music4
5-Music5
6-Music6
7-Music7
Program
List
Track1
Track1
Track3
Track2
Track5
Track2
Track3
Track4
Track5
Clear
All
E
VIDEO
CD
29
Advanced Operations
Repeat
Programmed
Tracks
1.
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2.
Press
REPEAT
to
select
a
desired
repeat
mode.
?
Track:
repeats
the
current
track
?
All:
repeats
all
the
tracks
on
programmed
list.
?
Off(No
display):
does
not
play
repeatedly.
NOTE
If
you
press
>
once
during
Repeat
Track
playback,
the
repeat
play-
back
cancels.
Erasing
a
Track
from
Program
List
1.
Use
vVBto
select
the
track
that
you
wish
to
erase
from
the
Program
list.
2.
Press
CLEAR.
Repeat
to
erase
additional
tracks
on
the
list.
Erasing
the
Complete
Program
List
1.
Press
B
to
move
to
the
"Program"
list.
2.
Use
v
/
V
to
select
"Clear
All",
then
press
ENTER.
NOTE
The
programs
are
also
cleared
when
the
disc
is
removed.
Programmed
Playback
(continued)
Using
this
DVD
Player
you
can
view
discs
with
JPEG
files.
1.
Insert
a
disc
and
close
the
tray.
The
menu
appears
on
the
screen.
2.
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
previ-
ous
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
highlight
and
press
ENTER.
3.
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
Viewing
the
file
proceeding
starts.
While
viewing
a
file,
you
can
press
STOP
to
move
to
the
previous
menu
(PHOTO
menu).
TIPS
?
Press
MENU
to
move
to
the
next
page.
?
There
are
three
Slide
Speed
options
:
>>>
(Fast),
>>
(Normal)
and
>
(Slow).
Use
vVbBto
highlight
the
Speed.
Then,
use
b
/
B
to
select
the
option
you
want
to
use
then
press
ENTER.
?
On
a
disc
with
MP3/WMA
and
JPEG
you
can
switch
MP3/WMA
and
JPEG.
Press
TITLE
and
MUSIC
or
word
on
top
of
the
menu
is
highlighted.
?
Press
RETURN,
information
of
file
is
hidden.
Slide
Show
Use
vVbBto
highlight
the
(Slide
Show)
then
press
ENTER.
Still
1.
Press
PAUSE
during
slide
show.
The
player
will
now
go
into
PAUSE
mode.
2.
To
return
to
the
slide
show,
press
PLAY
or
press
PAUSE
again.
JPEG
JPEG
Viewing
a
JPEG
Disc
30
Preview
List
JPEG
Folder
1
JPEG
Folder
2
JPEG
Folder
3
JPEG
Folder
4
JPEG
Folder
5
JPEG
Folder
6
JPEG
Folder
7
JPEG
Folder
8
31
Advanced Operations
Moving
to
another
File
Press
SKIP/SEARCH
(.
or
>)
or
cursor
(b
or
B)
once
while
viewing
a
to
advance
to
the
next
or
previous
file.
Zoom
Use
zoom
to
enlarge
the
image.
(see
23
page)
To
r
otate
Press
v
/
V
during
showing
a
to
rotate
the
clockwise
or
counter
clockwise.
To
listen
to
MP3/WMA
music
while
watching
You
can
display
files
while
listening
to
MP3/WMA
music
files
recorded
on
the
same
disc.
1.
Insert
the
disc
containing
the
two
types
of
file
in
the
player.
2.
Press
TITLE
to
display
menu.
3.
Press
v
/
V
to
select
a
file.
4.
Use
B
to
select
icon
then
press
ENTER.
Playback
starts.
The
playback
will
continue
until
STOP
is
pressed.
TIP
To
listen
to
only
the
desired
music
watching
picture,
programmed
the
desired
tracks
from
the
"MUSIC"
menu
and
then
proceed
as
above.
JPEG
disc
compatibility
with
this
player
is
limited
as
follows:
?
Depending
upon
the
size
and
number
of
JPEG
files,
it
could
take
a
long
time
for
the
DVD
player
to
read
the
disc's
contents.
If
you
don't
see
an
on-screen
display
after
several
minutes,
some
of
the
files
may
be
too
large
---
reduce
the
resolution
of
the
JPEG
files
to
less
than
2M
pixels
as
2760
x
2048
pixels
and
burn
another
disc.
?
The
total
number
of
files
and
folders
on
the disc
should
be
less
than
650.
?
Some
discs
may
be
incompatible
due
to
a
different
recording
format
or
the
condition
of
disc.
?
Ensure
that
all
the
selected
files
have
the
".jpg"
extensions
when
copying
into
the
CD
layout.
?
If
the
files
have
".jpe"
or
".jpeg"
extensions,
please
rename
them
as
".jpg"
file.
?
File
names
without
".jpg"
extension
will
not
be
able
to
be
read
by
this
DVD
player.
Even
though
the
files
are
shown
as
JPEG
files
in
Windows
Explorer.
Viewing
a
JPEG
Disc
(continued)
This
unit
will
play
DVD-R/RW
discs
recorded
using
the
DVD-Video
format
that
have been
finalized
using
a
DVD-recorder.
?
This
unit
will
play
DVD-RW
discs
recorded
using
the
Video
Recording
(VR)
format.
1.
Insert
a
disc
and
close
the
tray.
The
DVD-VR
menu
appears
on
the
screen.
2.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER
and
playback
starts.
NOTES
?
Unfinalized
DVD-R/RW
discs
cannot
be
played
in
this
player.
?
Some
DVD-VR
disc
are
made
with
CPRM
data
by
DVD
RECORDER.
Player
does
not
support
these
kinds of
discs
and
display
the
"CHECK
DISC".
What
is
'CPRM'?
CPRM
is
a
copy
protection
system
(with
scramble
system)
only
allowing
the
recording
of
'copy
once'
broadcast
programs.
CPRM
stands
for
Content
Protection
for
Recordable
Media.
This
player
is
CPRM
compatible,
which
means
that
you
can
record
copy-once
broadcast
programs,
but
you
cannot
then
make
a
copy
of
those
recordings.
CPRM
recordings
can
only
be
made
on
DVD-RW
discs
formatted
in
VR
mode,
and
CPRM
recordings
can
only
be
played
on
players
that
are
specifically
com-
patible
with
CPRM.
Playing
a
DVD
VR
format
Disc
32
DVD-VR
33
Advanced Operations
Using
this
DVD
Player
you
can
play
DivX
video
disc.
1.
Insert
a
disc
and
close
the
tray.
The
MOVIE
menu
appears
on
the
screen.
2.
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
high-
light
and
press
ENTER.
3.
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
4.
Press
STOP
to
exit.
TIP
?
Press
MENU
to
move
to
the
next
page.
?
On
a
CD
with
MP3/WMA,
JPEG
and
MOVIE
file,
you
can
switch
MUSIC,
and
MOVIE
menu.
Press
TITLE
and
MUSIC,
and
MOVIE
word
on
top
of
the
menu
is
highlighted.
DivX
disc
compatibility
with
this
player
is
limited
as
follows:
?A
vailable
resolution
size
of
the
DivX
file
is
under
720x576
(W
x
H)
pixel.
?
The
file
name
of
the
DivX
subtitle
is
limited
to
56
characters.
?
If
there
is
impossible
code
to
express
in
the
DivX
file,
it
may
be
displayed
as
"
_
"
mark
on
the
display.
?
If
the
frame
rate
is
over
30
frames
per
second,
this
unit
may
not
operate
normally.
?
If
the
video
and
audio
structure
of
recorded
file
is
not
interleaved,
either
video
or
audio
is
outputted.
?
If
the
file
is
recorded
with
GMC,
the
unit
supports
only
1-point
of the
record
level.
*
GMC?
GMC
is
the
acronym
for
Global
Motion
Compensation.
It
is
an
encoding
tool
specified
in
MPEG4
standard.
Some
MPEG4
encoder,
like
DivX
or
Xvid,
have
this
option.
There
are
different
levels
of
GMC
encoding,
usually
called
1-point,
2-point,
or
3-point
GMC.
Playable
DivX
file
z
".avi
",
".mpg
",
".mpeg
"
Playable
Codec
format
z
"DIVX3.xx
",
"DIVX4.xx
",
"DIVX5.xx
",
"XVID
",
"MP43
",
"3IVX
".
Playable
Audio
format
z
"Dolby
Digital
",
"DTS
",
"PCM
",
"MP3
",
"WMA
".
?
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48kHz
(WMA)
?
Bit
rate:
within
8
-
320kbps
(MP3),
32
-
192kbps
(WMA)
Playing
a
DivX
Movie
Disc
List
Movie
Folder
1
Movie
Folder
2
Movie
Folder
3
Movie
Folder
4
Movie
Folder
5
Movie
Folder
6
Movie
Folder
7
Movie
Folder
8
MOVIE
0:00:00
34
By
using
the
Setup
menu,
you
can
make
various
adjustments
to
items
such
as
and
sound.
You
can
also
set
a
language
for
the
subtitles
and
the
Setup
menu,
among
other
things.
For
details
on
each
Setup
menu
item,
see
pages
34
to
39.
To
display
and
exit
the
Menu:
Press
SETUP
to
display
the
menu.
A
second
press
of
SETUP
will
take
you
back
to
initial
screen.
To
go
to
the
next
level:
Press
B
on
the
remote
control.
To
go
back
to
the
previous
level:
Press
b
on
the
remote
control.
General
Operation
1.
Press
SETUP.
The
Setup
menu
appears.
2.
Use
v
/
V
to
select
the
desired
option
then
press
B
to
move
to
the
second
level.
The
screen
shows
the
current
setting
for
the
selected
item,
as
well
as
alternate
setting(s).
3.
Use
v
/
V
to
select
the
second
desired
option
then
press
B
to
move
to
the
third
level.
4.
Use
v
/
V
to
select
the
desired
setting
then
press
ENTER
to
confirm
your
selection.
Some
items
require
additional
steps.
5.
Press
SETUP
or
PLAY
to
exit
the
Setup
menu.
LANGUAGE
Menu
Language
Select
a
language
for
the
Setup
menu
and
on-screen
display.
Disc
Audio
/
Subtitle
/
Menu
Select
the
language
you
prefer
for
the
audio
track
(disc
audio),
subtitles,
and
the
disc
menu.
Original:
Refers
to
the
original
language
in
which
the
disc
was
recorded.
Other:
To
select
another
language,
press
number
buttons
then
ENTER
to
enter
the
corresponding
4-digit
number
according
to
the
language
code
list
in
the
reference
chapter.
If
you
enter
the
wrong
language
code,
press
CLEAR.
DVD
Initial
Settings
Menu
Language
Original
English
Off
Original
Disc
Audio
Disc
Subtitle
Disc
Menu
Move
Select
LANGUAGE
35
Initial Settings
DISPLAY
TV
Aspect
4:3:
Select
when
a
standard
4:3
TV
is
connected.
16:9
Wide:
Select
when
a
16:9
wide
TV
is
connected.
Display
Mode
Display
Mode
setting
works
only
when
the
TV
Aspect
mode
is
set
to
"4:3".
LetterBox:
Displays
a
wide
with
bands
on
the
upper
and lower
portions
of
the
screen.
Panscan:
Automatically
displays
the
wide
on
the
entire
screen
and
cuts
off the
portions
that
do
not
fit.
AUDIO
Each
DVD
disc
has
a
variety
of audio
output
options.
Set
the
player
's
AUDIO
options
according
to
the
type
of
audio
system
you
use.
Dolby
Digital
/
DTS
/
MPEG
Bitstream:
Select
"Bitstream"
if
you
connect
the
DVD
Player's
DIGITAL
OUT
jack
to
an
amplifier
or
other
equipment
with
a
Dolby
Digital,
DTS
or
MPEG
decoder.
PCM
(for
Dolby
Digital
/
MPEG):
Select
when
connected
to
a
two-channel
digital
stereo
amplifier.
DVDs
encoded
in
Dolby
Digital
or
MPEG
will
be
automatically
downmixed
to
two-channel
PCM
audio.
Off
(for
DTS):
If
you
select
"Off",
the
DTS
signal
is
not
output
through
the
DIGITAL
OUT
jack.
DivX
DVD
DVD
DVD
Initial
Settings
(continued)
DISPLAY
TV
Aspect
Widescreen
16:9Wide
Display
Mode
Move
Select
Dolby
Digital
Bitstream
PCM
48
kHz
On
Bitstream
DTS
MPEG
Sample
Freq.
DRC
On
Vocal
Move
Select
AUDIO
Sample
Freq.
(Frequency)
If
your
receiver
or
amplifier
is
NOT
capable
of
handling
96
kHz
signals,
select
48
kHz.
When
this
choice
is
made,
this
unit
automatically
converts
any
96
kHz
signals
to
48
kHz
so
your
system
can
decode
them.
If
your
receiver
or
amplifier
is
capable
of
handling
96
kHz
signals,
select
96
kHz.
When
this
choice
is
made,
this
unit
passes
each
type
of
signal
through
without
any
further
processing.
Check
the
documentation
for
your
amplifier
to
verify
its
capabilities.
Dynamic
Range
Control
(DRC)
With
the
DVD
format,
you
can
hear
a
program's
soundtrack
in
the
most
accurate
and
realistic
presentation
possible,
thanks
to
digital
audio
tech-
nology.
However,
you
may
wish
to
compress
the
dynamic
range
of
the
audio
output
(the
difference
between
the
loudest
sounds
and
the
quietest
ones).
This
allows
you
to
listen
to
a
movie
at
a
lower
volume
without
losing
clarity
of
sound.
Set
DRC
to
On
for
this
effect.
Vocal
Set
to
On
only
when
a
multi-channel
karaoke
DVD
is
playing.
The
karaoke
channels
on
the
disc
mix
into
normal
stereo
sound.
OTHERS
The
PBC,
Auto
Play,
B.L.E.
and
DivX(R)
VOD
settings
can
be
changed.
PBC
Set
Playback
Control
(PBC)
to
On
or
Off.
On:
Video
CDs
with
PBC
are
played
according
to
the
PBC.
Off:
Video
CDs
with
PBC
are
played
the
same
way
as
Audio
CDs.
Auto
Play
You
can
set
up
the
DVD
Player
so
a
DVD
disc
automatically
starts
play-
ing
whenever
the
DVD
is
inserted.
If
Auto
Play
mode
is
set
to
On,
this
DVD
player
will
search
for
title
that
has
the
longest
playback
time
and
then
play
back
the
title
automatically.
On:
Auto
Play
function
is
active.
Off:
Auto
Play
function
is
not
active.
NOTE
The
Auto
Play
function
may
not
work
for
some
DVDs.
DVD
VCD
DVD
DivX
DVD
DVD
Initial
Settings
(continued)
36
PBC
Off
Move
Auto
Play
OTHERS
On
Select
On
B.L.E.
Select
DivX(R)
VOD
37
Initial Settings
B.L.E.
(Black
Level
Expansion)
To
select
the
black
level
of
playback
pictures.
Set
your
preference
and
monitor's
ability.
On:
Expanded
grey
scale.
(0
IRE
cut
off)
Off:
Standard
grey
scale.
(7.5
IRE
cut
off)
DivX(R)
VOD
You
can
display
the
DivX
DRM
(Digital
Rights
Management)
Registration
code
for
your
unit
only.
The
Registration
code
is
used
for
VOD
(Video-On-Demand)
service
agent.
You
can
purchase
or
rent
an
encrypt
movie
file.
NOTES
If
you
rent
the
DivX
VOD
file,
it
has
several
options
of
viewing
limits
as
shown
below.
?
Display
the
number
which
you
can
watch
the
file.
?
The
rental
has
been
expired.
?
Display
the
authorization
error.
DivX
Initial
Settings
(continued)
LOCK
(Parental
Control)
Rating
Some
movies
contain
scenes
that
may
not
be
suitable
for
children
to
view.
Many
of
these
discs
contain
parental
control
information
that
applies
to
the
complete
disc
or
to
certain
scenes
on
the
disc.
Movies
and
scenes
are
rated
from
1
to
8,
depending
on
the
country.
Some
discs
offer
more
suitable
scenes
as
an
alternative.
The
parental
control
feature
allows
you
to
block
access
to
scenes
below
the
rating
you
input,
thereby
preventing
your
children
from
being
able
to
view
material
you
believe
is
unsuitable.
1.
Select
"Rating"
on
the
LOCK
menu
then
press
B.
2.
To
access
the
Rating,
Password
and
Area
Code
features,
you
must
input
the
4-digit
security
code
you
created.
If
you
have
not
yet
entered
a
security
code
you
are
prompted
to
do
so.
Input
a
4-digit
code
and
press
ENTER.
Enter
it
again
and
press
ENTER
to
verify.
If
you
make
a
mistake
before
pressing
ENTER,
press
CLEAR.
3.
Select
a
rating
from
1
to
8
using
the
v
/
V
buttons.
Rating
1-8:
Rating
one
(1)
has
the
most
restrictions
and
rating
eight
(8)
is
the
least
restrictive.
Unlock
If
you
select
unlock,
parental
control
is
not
active
and
the
disc
plays
in
full.
NOTE
If
you
set
a
rating
for
the
player,
all
disc
scenes
with
the
same
rating
or
lower
are
played.
Higher
rated
scenes
are
not
played
unless
an
alternate
scene
is
available
on
the
disc.
The
alternative
must
have
the
same
rating
or
a
lower
one.
If
no
suitable
alternative
is
found,
playback
stops.
You
must
enter
the
4-digit
password
or
change
the
rating
level
in
order
to
play
the
disc.
4.
Press
ENTER
to
confirm
your
rating
selection,
then
press
SETUP
to
exit
the
menu.
DVD
Initial
Settings
(continued)
38
LOCK
Rating
New
Unlock
Password
Area
Code
Move
Select
US
39
Initial Settings
Password
(Security
Code)
You
can
enter
or
change
password.
1.
Select
Password
on
the
LOCK
menu
then
press
B.
2.
Follow
step
2
as
shown
left
(Rating).
"Change"
or
"New"
is
highlighted.
3.
Enter
the
new
4-digit
code,
then
press
ENTER.
Input
it
again
to
veri-
fy.
4.
Press
SETUP
to
exit
the
menu.
If
you
forget
your
Security
Code
If
you
forget
your
security
code
you
can
clear
it
using
the
following
steps:
1.
Press
SETUP
to
display
the
Setup
menu.
2.
Input
the
6-digit
number
"210499"
and
the
security
code
is
cleared.
3.
Enter
a
new
code
as
described
above.
Area
Code
Enter
the
code
of
the
area
whose
standards
were
used
to
rate
the
DVD
video
disc,
based
on
the
list
in
the
reference
chapter.
1.
Select
"Area
Code"
on
the
LOCK
menu
then
press
B.
2.
Follow
step
2
as
shown
left
(Rating).
3.
Select
the
first
character
using
v
/
V
buttons.
4.
Press
ENTER
and
select
the
second
character
using
v
/
V
buttons.
5.
Press
ENTER
to
confirm
your
area
code
selection.
Initial
Settings
(continued)
The
and
sound
of
a
nearby
TV,
VCR,
or
radio
may
be
distorted
during
playback.
If
this
occurs,
position
the
player
away
from
the
TV,
VCR,
or
radio,
or
turn
off
the
unit
after
removing
the
disc.
DVD
Player
Connections
Depending
on
your
TV
and
other
equipment
there
are
various
ways
you
can
connect
the
player.
Please
refer
to
the
manuals
of
your
TV,
stereo
system
or
other
devices
as
necessary
for
additional
connection
information.
Video
and
Audio
Connections
to
Your
TV
Make
sure
the
DVD
player
is
connected
directly
to
the
TV
and
not
to
a
VCR,
otherwise
the
DVD
could
be
distorted
by
the
copy
protec-
tion
system.
Video:
Connect
the
VIDEO
OUT
jack
on
the
DVD
player
to
the
video
in
jack
on
the
TV
using
the
video
cable.
Audio
Connection
to
Your
TV:
Connect
the
AUDIO
OUT
jacks
of
the
DVD
Player
to
the
audio
left
and
right
IN
jacks
on
the
TV
using
the
audio
cables.
Do
not
connect
the
DVD
Player
's
AUDIO
OUT
jack
to
the
phone
in
jack
(record
deck)
of
your
audio
system.
You
must
set
the
A/V
IN/OUT
switch
to
the
"A/V
OUT"
mode
Setting
up
the
Player
40
Audio/
Video
cable
(Supplied)
(Yellow)
(Black)
41
Connections
Audio
Connection
to
Optional
Equipment
Connect
the
DVD
player
to
your
optional
equipment
for
audio
output.
You
must
set
the
A/V
IN/OUT
switch
to
the
"A/V
OUT"
mode
Amplifier
equipped
with
2-channel
analog
stereo
or
Dolby
Pro
Logic
ll
/
Pro
Logic:
Connect
the
AUDIO
OUT
jacks
on
the
DVD
player
to
the
audio
left
and
right
IN
jacks
on
your
amplifier,
receiver,
or
stereo
system,
using
the
audio
cables.
Amplifier
equipped
with
2-channel
digital
stereo
(PCM)
or
audio
/
video
receiver
equipped
with
a
multi-channel
decoder
(Dolby
DigitalTM,
MPEG
2,
or
DTS):
Connect
one
of
the
DVD
Player
's
DIGITAL
AUDIO
OUT
jack
to
the
corresponding
in
jack
on
your
amplifier.
Use
an
optional
digital
audio
cable.
Digital
Multi-channel
sound
A
digital
multi-channel
connection
provides
the
best
sound
quality.
For
this
you
need
a
multi-channel
audio
/
video
receiver
that
supports
one
or
more
of
the
audio
formats
supported
by
your
DVD
player
such
as
MPEG
2,
Dolby
Digital
and
DTS.
Check
the
receiver
manual
and
the
logos
on
the
front
of
the
receiver.
NOTES
?
If
the
audio
format
of
the
digital
output
does
not
match
the
capabilities
of
your
receiver,
the
receiver
produces
a
strong,
distorted
sound
or
no
sound
at
all.
?
Six
Channel
Digital
Surround
Sound
via
a
digital
connection
can
only
be
obtained
if
your
receiver
is
equipped
with
a
Digital
Multi-channel
decoder.
?T
o
see
the
audio
format
of
the
current
DVD
in
the
on-screen
display,
press
AUDIO.
Setting
up
the
Player
(continued)
R
L
AUDIO
INPUT
DIGITAL
INPUT
OPTICAL
Optical
cable
(Not
supplied)
Audio/
Video
cable
(Supplied)
or
(Black)
Tr
oubleshooting
42
Symptom
No
power.
No
on
the
LCD
or
TV
(including
video
from
another
unit).
No
sound.
The
DVD
player
does
not
start
playback.
No
response
when
buttons
are
pressed.
The
remote
control
does
not
work
properly.
Correction
?
Plug
the
power
cord
into
the
wall
outlet
securely.
?
Recharge
the
battery.
?
Connect
the
video
cable
into
the
jacks
securely.
?
Set
the
A/V
IN/OUT
switch
correctly.
-
While
you
are
playing
a
disc,
set
the
A/V
IN/OUT
switch
to
OUT
mode
-
While
you
are
viewing
video
from
other
equipment,
set
the
A/V
IN/OUT
switch
to
In
mode.
?
Select
a
LCD
mode
other
than
OFF.
?
Adjust
the
brightness.
?
Select
the
appropriate
video
input
mode
on
the
TV
so
the
from
the
DVD
player
appears
on
the
screen.
?
Select
the
correct
input
mode
of
the
audio
receiver
so
you
can
listen
to
the
sound
from
the
DVD
player.
?
Connect
the
audio
cable
into
the
jacks
securely.
?
Insert
a
playable
disc.
(Check
the
disc
type,
color
system
and
Regional
code.)
?
Cancel
the
Rating
function
or
change
the
rating
level.
?"
"
may
appear
on
the
screen
during
operation.
?
Operate
the
remote
control
within
about
23
ft
(7
m).
Cause
?
The
power
cord
is
disconnected.
?
The
battery
is
discharged.
?
The
video
cable
is
not
connected
securely.
?
The
A/V
IN/OUT
switch
is
not
set
correctly.
?
LCD
mode
is
set to
OFF.
?
Check
that
Brightness
control
is
set to
"--".
?
The
TV
is
not
set to
receive
DVD
signal
output.
?
The
equipment
connected
with
the
audio
cable
is
not
set
to
receive
DVD
signal
output.
?
The
audio
cables
are
not
connected
securely.
?
An
unplayable
disc
is
inserted.
?
The
Rating
level
is
set.
?
Some
discs
prohibit
certain
operations.
?
The
remote
control
is
too
far
from
the
DVD
player.
43
Reference
Use
this
list
to
input
your
desired
language
for
the
following
initial
settings:
Disc
Audio,
Disc
Subtitle,
Disc
Menu.
Language
Codes
Language
Code
Abkhazian
6566
Afar
6565
Afrikaans
6570
Albanian
8381
Ameharic
6577
Arabic
6582
Armenian
7289
Assamese
6583
Aymara
6588
Azerbaijani
6590
Bashkir
6665
Basque
6985
Bengali;
Bangla
6678
Bhutani
6890
Bihari
6672
Breton
6682
Bulgarian
6671
Burmese
7789
Byelorussian
6669
Cambodian
7577
Catalan
6765
Chinese
9072
Corsican
6779
Croatian
7282
Czech
6783
Danish
6865
Dutch
7876
English
6978
Esperanto
6979
Estonian
6984
Faroese
7079
Language
Code
Fiji
7074
Finnish
7073
French
7082
Frisian
7089
Galician
7176
Georgian
7565
German
6869
Greek
6976
Greenlandic
7576
Guarani
7178
Gujarati
7185
Hausa
7265
Hebrew
7387
Hindi
7273
Hungarian
7285
Icelandic
7383
Indonesian
7378
Interlingua
7365
Irish
7165
Italian
7384
Japanese
7465
Javanese
7487
Kannada
7578
Kashmiri
7583
Kazakh
7575
Kirghiz
7589
Korean
7579
Kurdish
7585
Laothian
7679
Latin
7665
Latvian,
Lettish
7686
Language
Code
Lingala
7678
Lithuanian
7684
Macedonian
7775
Malagasy
7771
Malay
7783
Malayalam
7776
Maltese
7784
Maori
7773
Marathi
7782
Moldavian
7779
Mongolian
7778
Nauru
7865
Nepali
7869
Norwegian
7879
Oriya
7982
Panjabi
8065
Pashto,
Pushto
8083
Persian
7065
Polish
8076
Portuguese
8084
Quechua
8185
Rhaeto-Romance
8277
Rumanian
8279
Russian
8285
Samoan
8377
Sanskrit
8365
Scots
Gaelic
7168
Serbian
8382
Serbo-Croatian
8372
Shona
8378
Sindhi
8368
Language
Code
Singhalese
8373
Slovak
8375
Slovenian
8376
Somali
8379
Spanish
6983
Sudanese
8385
Swahili
8387
Swedish
8386
Tagalog
8476
Ta
jik
8471
Tamil
8465
Ta
tar
8484
Telugu
8469
Thai
8472
Tibetan
6679
Tigrinya
8473
Tonga
8479
Turkish
8482
Turkmen
8475
Twi
8487
Ukrainian
8575
Urdu
8582
Uzbek
8590
Vietnamese
8673
Volap k
8679
Welsh
6789
Wolof
8779
Xhosa
8872
Yiddish
7473
Yoruba
8979
Zulu
9085
Choose
an
area
code
from
this
list.
Area
Codes
44
Area
Code
Afghanistan
AF
Argentina
AR
Australia
AU
Austria
AT
Belgium
BE
Bhutan
BT
Bolivia
BO
Brazil
BR
Cambodia
KH
Canada
CA
Chile
CL
China
CN
Colombia
CO
Congo
CG
Costa
Rica
CR
Croatia
HR
Czech
Republic
CZ
Denmark
DK
Ecuador
EC
Egypt
EG
El
Salvador
SV
Area
Code
Ethiopia
ET
Fiji
FJ
Finland
FI
France
FR
Germany
DE
Great
Britain
GB
Greece
GR
Greenland
GL
Islands
HM
Hungary
HU
India
IN
Indonesia
ID
Israel
IL
Italy
IT
Jamaica
JM
Japan
JP
Kenya
KE
Kuwait
KW
Libya
LY
Luxembourg
LU
Area
Code
Malaysia
MY
Maldives
MV
Mexico
MX
Monaco
MC
Mongolia
MN
Morocco
MA
Nepal
NP
Netherlands
NL
Netherlands
Antilles
AN
New
Zealand
NZ
Nigeria
NG
Norway
NO
Oman
OM
Pakistan
PK
Panama
PA
Paraguay
PY
Philippines
PH
Poland
PL
Portugal
PT
Romania
RO
Russian
Federation
RU
Area
Code
Saudi
Arabia
SA
Senegal
SN
Singapore
SG
Slovak
Republic
SK
Slovenia
SI
South
Africa
ZA
South
Korea
KR
Spain
ES
Sri
Lanka
LK
Sweden
SE
Switzerland
CH
Thailand
TH
Turkey
TR
Uganda
UG
Ukraine
UA
United
States
US
Uruguay
UY
Uzbekistan
UZ
Vietnam
VN
Zimbabwe
ZW
45
Reference
DVD
Player
Power
supply:
DC
9.5V
(AC
adapter
terminal),
DC
7.4V
(Battery)
Power
consumption:
15W
with
battery
Weight:
1.46
lbs
(0.66
kg)
(without
battery
pack)
External
dimensions
(W
x
H
x
D):
7.5x1.1x6.3inches(190x28x159.5mm)
Signal
system:
NTSC
Laser:
DVD
Laser
wavelength
662+25
/
662-15
nm
CD
Laser
wavelength
785+25
/
785-15
nm
Frequency
range
(audio):
DVD
linear
sound:
48kHz
sampling
8
Hz
to
20
kHz
96kHz
sampling
8
Hz
to
44
kHz
Signal-to-noise
ratio
(audio):
More
than
95
dB
Dynamic
range
(audio):
More
than
95
dB
Harmonic
distortion
(audio):
0.008
%
Operating
conditions:
Temperature:
5°C
to
35°C,
Operation
status:
Horizontal
Connectors
Video
input/output
(VIDEO
In/Out):
1.0
V
(p-p),
75
Ω,
negative
sync.,
ø3.5mm
mini
jack
x
1
Audio
input/output
(AUDIO
In/Out,
analog
audio):
2.0
Vrms(1
KHz,
0
dB),
ø3.5mm
mini
jack
x
1
Earphone
terminal:
ø3.5mm
stereo
mini
jack
x
2
Liquid
Crystal
Display
Panel
size:
7
inches
wide
(diagonal)
Projection
system:
Y/C
stripe
Driving
system:
TFT
active
matrix
Resolution:
234
x
480
x
3
(effective
pixel
rate:
more
than
99.99%)
Supplied
Accessories
?
RCA
Audio/Video
cable
....................................................................1
?
AC
Adapter
(DP-AC90)
....................................................................1
?
Automotive
Adapter
(DPB-C90)
......................................................1
?
Battery
Pack
(DP-BS930)
.................................................................1
?
Remote
control
..................................................................................1
?
Battery
for
Remote
control
(Lithium
Battery)
..................................1
z
Design
and
specifications
are
subject
to
change
without
notice.
Specifications
This
LG
Electronics
product,
will
be
repaired
or
replaced,
at
LG's
option,
if
it
proves
to
be
defective
in
material
or
workmanship,
under
normal
use,
during
the
warranty
period
("Warranty
Period")
listed
below,
effective
from
the
date
("Date
of
Purchase")
of
original
con-
sumer
purchase
of
the
product.
This
warranty
is
good
only
to
the
original
purchaser
of
the
product
and
effective
only
when
used
in
the
United
States,
excluding
U.S.
Territories.
THIS
WARRANTY
IS
IN
LIEU
OF
ANY
OTHER
WARRANTIES,
EXPRESS
OR
IMPLIED,
INCLUDING
WITHOUT
LIMITATION,
ANY
WARRANTY
OF
MERCHANTABILITY
OR
FITNESS
FOR
A
PARTICULAR
PURPOSE.
TO
THE EXTENT
ANY
IMPLIED
WARRANTY
IS
REQUIRED
BY
LAW,
IT
IS
LIM-
ITED
IN
DURATION
TO
THE
EXPRESS
WARRANTY
PERIOD
ABOVE.
LG
ELECTRONICS
WILL
NOT
BE
LIABLE
FOR
ANY
INCIDENTAL,
CONSE-
QUENTIAL,
INDIRECT,
SPECIAL
OR
PUNITIVE
DAMAGES
OF
ANY
NATURE,
EVEN
IF
ADVISED
OF
THE
POSSIBILITY
OF
SUCH
DAMAGES,
INCLUDING
WITHOUT
LIMITATION,
LOST
REVENUES
OR
PROFITS,
LOST
OR
CORRUPTED
PROGRAMMING
OR
DATA,
OR
ANY
OTHER
DAM-
AGE
WHETHER
BASED
IN
CONTRACT,
TORT
OR
OTHERWISE.
Some
states
do
not
allow
the exclusion
or
limitation
of
incidental
or
consequential
dam-
ages
or
limitation
on
how
long
an
implied
warranty
lasts,
so
the
above
exclusion
or
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also
have
other
rights
that
may
vary
from
state
to
state.
WARRANTY
PERIOD:
LABOR:
90
days
from
the
Date
of
Purchase.
PARTS:
One
Year
from
the
Date
of
Purchase.
*
Parts
replaced
are
warranted
for
the
remaining
portion
of
the
original
warranty
period.
HOW
SERVICE
IS
HANDLED:
Call
1-800-243-0000
for
instructions
on
getting
the
defective
unit
repaired
or
replaced.
Please
retain
dated
sales
receipt
and
your
box
to
return
the
unit
to
LG
for
repair
or
replacement.
Shipping
both
ways
will
be
paid
by
LG
during
the
Warranty
Period.
After
the
Warranty
Period,
you pay
inbound
shipping
charges
and
LG
pays
return
shipping
charges.
Visit
our
website
at:
http://www.lgservice.com
THIS
LIMITED
WARRANTY
DOES
NOT
APPLY
TO:
?
Damages
or
operating
problems
that
result
from
shipping,
installation,
adjustment
of
user
controls,
calibration,
maintenance
or
fail-
ure
to
maintain,
or
separate
system
components;
and
?
Damages
or
operating
problems
that
result
from
normal
wear
and
tear,
misuse,
abuse,
operation
outside
environmental
specifica-
tions
or
contrary
to
the
requirements
or
precautions
in
the
Operating
Guide,
accident,
lightning
strikes
or
other
natural
causes,
unauthorized
modification
or
alteration,
incorrect
electrical
current
or
voltage,
reception
problem
caused
by
inadequate
home
antenna
or
faulty
antenna
connections,
computer
software,
institutional
or
commercial
use,
or
other
causes
not
arising
out
of
defect
in
material
or
workmanship.
Therefore,
the
cost
of
repair
or
replacement
of
such
defective
product
shall
be
borne
by
the
consumer.
CUSTOMER
INTER-ACTIVE
CENTER
NUMBERS:
For
nearest
Authorized
Service
Center,
Where
to
buy,
Product
Assistance,
or
Customer
Assistance
Call
1-800-243-0000
(24
hours
a
day,
365
days
per
year)
and
select
appropriate
options
from
the
menu.
Or
visit
our
website
at
http://www.lgservice.com
LG
ELECTRONICS
U.S.A.,
INC.
1000
SYLVAN
AVENUE
ENGLEWOOD
CLIFFS,
NJ
07632
P/N
:
3834RD0084M
Printed
in
China
Issue
O
Marketed
and
distributed
in
the
United
States
by
LG
Electronics
U.S.A.,
Inc.
