User Manual Thermador T24UW900RP 24-Inch Under-Counter Wine Reserve

• Owner's manual - (English, French, Spanish)

USE & CARE GUIDE Glass Door Wine Reserve Thermador T24UW900RP

Table of Contents

• Important Safety Instructions
• Definition
• Before you switch ON the appliance
• Technical safety
• Important information when using the appliance
• Children in the household
• General regulations
• Information concerning disposal
• Disposal of packaging
• Disposal of your old appliance
• Installing the appliance
• Transporting
• Installation location
• Ventilation
• Getting to know your appliance
• Getting started with your appliance …
• Touch control
• Switching the appliance on
• Setting the temperature
• Controlling the cabinet lighting
• Special functions:
• Sabbath Mode
• Fahrenheit / Celsius Display
• Off Mode
• Toe-Kick
• Cleaning the appliance
• Proceed as follows:
• Cleaning behind the Toe-kick
• Odors
• Light (LED)
• Tips for saving energy
• Operating noises
• Normal noises
• Preventing noises
• Troubleshooting

Cleaning the appliance

Proceed as follows:

1. Before cleaning: switch the appliance off.
2. Clean the appliance, and the glass shelves with a soft cloth, lukewarm water and a little pH neutral detergent.
3. Clean the appliance with a soft cloth, lukewarm water and a little pH neutral detergent
4. Wipe the drawer seals with clear water only and then wipe dry thoroughly.
5. After cleaning switch the appliance back on

Cleaning behind the Toe-Kick

1. Before cleaning: switch the appliance off.
2. Remove the Toe-Kick.
3. Use a vacuum cleaner with an extended attachment to clean the accessible areas when they are dusty or dirty.
4. Replace the Toe-Kick.
5. Switch the appliance on.

Light (LED)

• Your appliance features a maintenance-free LED light located at the top of the interior cabinet and under the mullion. This light must be repaired by authorized technicians only.

Tips for saving energy

• Install the appliance in a dry, well ventilated room. The appliance should not be installed in direct sunlight or near a heat source (e.g. radiator, cooker). If required, use an insulating plate.
• Do not block the ventilation openings in the appliance.
• Open the appliance door as briefly as possible.

Operating noises

Normal noises

• Droning: Motors are running (e.g. refrigeration units, fan).
• Bubbling, humming or gurgling noises: Refrigerant is flowing through the tubing.
• Clicking: Motor, switches or solenoid valves are switching On/Off.

Preventing noises

• Be sure the appliance is leveled: Please align the appliance with a spirit level. Use the height-adjustable feet.
• Bottles or containers are touching each other: Move the bottles or containers slightly away from each other.
