Quick guide Hood Whirlpool WHSS

FIRST TIME USE

AIR VENT (FOR THE SUCTION VERSIONS)

• Use a duct of the minimum indispensible length.
• Use a duct with as few elbows as possible (maximum elbow angle: 90°).
• Avoid drastic changes in the duct cross-section.
• The company declines any responsibility whenever these regulations are not respected.

FILTERING OR DUCTING?

• Your cooker hood is ready to be used in suction version. To use the hood in filtering version the special ACCESSORY KIT must be installed.

CONTROL PANEL

• T1. ON/OFF “Night Light”
• T2. Hob lights ON/OFF – Select the colour temperature
• T3. Operation “ZEN Mode”
• T4. Motor ON/OFF
• T5. "POWER BOOST 1" function
• T6. "POWER BOOST 2" function
• T7. Automatic Mode“Cook Sense”
• T8. Filter saturation indicator
• T9. ON/OFF operating mode “Daily Air Sense”
• T10. ON/OFF operating mode“Intensive Air Sense “

CLEANING AND MAINTENANCE

• Do not use steam-cleaning equipment.
• Disconnect the appliance from the mains. Important: do not use corrosive or abrasive detergents. If any such products unintentionally come into contact with the appliance, clean the appliance immediately with a damp cloth. Do not use alcohol.
• Clean the surfaces with a damp cloth. If it is very dirty, add a few drops of washing-up detergent to the water. Finish off with a dry cloth. Important: do not use abrasive sponges or metallic scrapers or scourers. Over time, these can ruin the enamel surfaces.
• Use detergents specifically designed for cleaning the appliance and follow the manufacturer's instructions. Important: clean the filters at least once a month to remove oil and grease residue.

MAINTENANCE OF THE GREASE FILTERS

• This must be cleaned once a month (or when the filter saturation indication system - if envisaged on the model in possession - indicates this necessity) using non aggressive detergents, either by hand or in the dishwasher, which must be set to a low temperature and a short cycle.
• When washed in a dishwasher, the grease filter may discolour slightly, but this does not affect its filtering capacity.
• Pull out the handle to remove the filter.
• Once the filter has been washed and left to dry, proceed in reverse order to refit the filter.

MAINTENANCE OF THE CHARCOAL FILTER (FOR FILTRATION MODELS ONLY)

• This filter retains the unpleasant odours produced during cooking. Saturation of the carbon filter occurs after a relatively long use, however this depends on the type of cooking and how regularly the grease filter is cleaned. Regardless, it is necessary to replace the cartridge every 4 months. It CANNOT be washed or recycled.

Fitting or replacing the carbon filter

1. Disconnect the hood from the mains.
2. Remove the grease filters.
3. Fit 2 carchoal filters (one each side of the conveyour), bajonet attachment.
4. Reinstall the grease filter in place.

REPLACING THE LAMPS

• The hood is equipped with an LED lighting system. LEDs ensure excellent illumination, have a service life up to 10 times longer than traditional bulbs, and offer up to 90% energy savings.
• Note: For replacement LED, please contact the Technical After-sales Service Centre.

TROUBLESHOOTING

The appliance does not work.

• Check the mains voltage and whether the appliance is connected to the power supply;
• Check that a speed has been selected;
• Switch the appliance off and on again to see if the fault persists.

The hood is not extracting air sufficiently.

• Check that the air extraction speed is set to the desired level;
• Check that the filters are clean;
• Check the air vents for any obstructions.

The hood has turned off during normal functioning.

• Check that the power has not been disconnected;
• Check that the omnipolar disconnection device has not tripped
