KDF-E55/60A20 2-593-962-12(1)
LCD Projection TV
HD-TV
Operating Instructions
http://www.sony.net/
Printed in U.S.A.
2-593-962-12(1)
KDF-E55A20
KDF-E60A20
© 2005 Sony Corporation
™
™
2593962121Cover.indd 12593962121Cover.indd 1 9/13/2005 11:56:03 AM9/13/2005 11:56:03 AM
KDF-E55/60A20
2-593-962-12(1)
Owner’s Record
The model and serial numbers are located at the rear of
the TV, below the Sony logo, on the sticker, and also on
the TV box (white label). Record these numbers in the
spaces provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No.
Serial No.
Contacting Sony
If, after reading the following instructions, you have
additional questions related to the use of your Sony
®
TV,
please call one of the following numbers.
Customers in the continental United States contact the
Direct Response Center at:
1-800-222-SONY (7669)
or visit http://www.sony.com/TVsupport
Customers in Canada contact the Customer Relations
Center at:
1-877-899-SONY (7669)
or visit http://www.sony.com/TVsupport
1
KDF-E55/60A20
2-593-962-12(1)
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture
.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
CAUTION
To prevent electric shock, do not use this polarized AC
plug with an extension cord, receptacle or other outlet
unless the blades can be fully inserted to prevent blade
exposure.
Note on Caption Vision
This television receiver provides display of television
closed captioning in accordance with §15.119 of the FCC
rules.
NOTIFICATION
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance to the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
❑ Reorient or relocate the receiving antennas.
❑ Increase the separation between the equipment and
receiver.
❑ Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
❑ Consult the dealer or an experienced radio/TV
technician for help.
Safety
❑ The TV should be installed near an easily accessible
power outlet.
❑ Operate the TV only on 120 V AC.
❑ The plug is designed, for safety purposes, to fit into
the wall outlet only one way. If you are unable to
insert the plug fully into the outlet, contact your
dealer.
❑ If any liquid or solid object should fall inside the
cabinet, unplug the TV immediately and have it
checked by qualified service personnel before
operating it further.
❑ If you will not be using the TV for several days,
disconnect the power by pulling the plug itself.
Never pull on the cord.
❑ For details concerning safety precautions, see
“Important Safety Instructions” on page 3.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
ATTENTION
CAUTION
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
Pursuant to FCC regulations, you are cautioned
that any changes or modifications not expressly
approved in this manual could void your
authority to operate this equipment
KDF-E55/60A20
2-593-962-12(1)
2
Installing
❑ The TV should be installed near an easily accessible
power outlet.
❑ To prevent internal heat buildup, do not block the
ventilation openings.
❑ Do not install the TV in a hot or humid place, or in a
place subject to excessive dust or mechanical
vibration.
❑ Avoid operating the TV at temperature below 41°F
(5°C).
❑ If the TV is transported directly from a cold to a
warm location, or if the room temperature changes
suddenly, the picture may be blurred or show poor
color. In this case, please wait a few hours to let the
moisture evaporate before turning on the TV.
❑ To obtain the best picture, do not expose the screen
to direct illumination or direct sunlight. It is
recommended to use spot lighting directed down
from the ceiling or to cover the windows that face
the screen with opaque drapery. It is desirable to
install the TV in a room where the floor and walls
are not of a reflective material.
❑ See page 12 & 13 for more information on the
installation.
Note
This digital television is capable of receiving analog
basic, digital basic and digital premium cable television
programming by direct connection to a cable system
providing such programming. A security card provided
by your cable operator is required to view encrypted
digital programming. Certain advanced and interactive
digital cable services such as video-on-demand, a cable
operator’s enhanced program guide and data-enhanced
television services may require the use of a set-top box.
For more information call your local cable operator.
This television also includes a QAM demodulator which
should allow you to receive unscrambled digital cable
television programming via subscription service to a
cable service provider. Availability of digital cable
television programming in your area depends on the type
of programming and signal provided by your cable
service provider.
Trademark Information
As an ENERGY STAR
®
Partner, Sony
Corporation has determined that this product
meets the ENERGY STAR
®
guidelines for
energy efficiency.
ENERGY STAR
®
is a U.S. registered mark.
CableCARD
™
is a trademark of Cable Television
Laboratories, Inc.
TruSurround XT, SRS and the ( )
®
symbol are
trademarks of SRS Labs, Inc. TruSurround XT
technology is incorporated under license from SRS Labs,
Inc.
BBE and BBE Symbol are trademarks of BBE Sound,
Inc. and are licensed by BBE Sound, Inc. under U.S.
Patent No. 4,638,258 and 4,482,866.
This TV is manufactured under
license from Dolby Laboratories.
Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
This TV incorporates High-
Definition Multimedia Interface
(HDMI
™
) technology. HDMI, the HDMI logo and High-
Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
WEGA, Grand WEGA, WEGA GATE, Steady Sound,
Digital Reality Creation, CineMotion, PlayStation, and
BN Smoother are trademarks of Sony Corporation.
TV STAND:
Use the following Sony appliance(s) only with the
following TV STAND. Use with other TV STAND may
cause instability and result in possible injury.
SONY APPLIANCE MODEL NO:
KDF-E55A20
KDF-E60A20
SONY TV STAND MODEL NO:
SU-GW12
Replacement Parts
See page 4 under “Service”.
See page 76 for replacement lamp.
3
KDF-E55/60A20
2-593-962-12(1)
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A
grounding type plug has two blades
and a third grounding prong. The
wide blade or the third prong are
provided for your safety. If the
provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
11) Only use attachments/accessories
specified by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during
lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
❑
Be sure to observe the TV’s “For Safety”
section on page 5.
KDF-E55/60A20
2-593-962-12(1)
4
Antennas
Outdoor Antenna Grounding
If an outdoor antenna is installed, follow the precautions
below. An outdoor antenna system should not be located
in the vicinity of overhead power lines or other electric
light or power circuits, or where it can come in contact
with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA
SYSTEM, EXTREME CARE SHOULD BE TAKEN TO
KEEP FROM CONTACTING SUCH POWER LINES
OR CIRCUITS AS CONTACT WITH THEM IS
ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static
charges.
Section 810 of the National Electrical Code (NEC) in
USA and Section 54 of the Canadian Electrical Code in
Canada provides information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
Antenna Grounding According to the NEC
Refer to section 54-300 of Canadian Electrical Code for
Antenna Grounding.
Cleaning
❑ Clean the cabinet of the TV with a
dry soft cloth. To remove dust from
the screen, wipe it gently with a soft
cloth. Stubborn stains may be
removed with a cloth slightly
dampened with solution of mild soap and warm
water. Never use strong solvents such as thinner or
benzine for cleaning. If the picture becomes dark
after using the TV for a long period of time, it may
be necessary to clean the inside of the TV. Consult
qualified service personnel.
❑ Unplug the AC power cord when cleaning this unit.
Cleaning this unit with a plugged AC power cord
may result in electric shock.
On Contamination on the Screen Surface
The screen surface has a special coating to reduce
reflections. To prevent screen damage, clean the screen as
follows:
❑ Clean the screen with a soft cloth.
❑ To remove hard contamination, use a cloth
moistened with a solution of mild detergent and
water. Do not spray cleaning solution directly onto
the TV. It should only be sprayed to moisten the
cleaning cloth.
❑ Do not use any type of abrasive pad, alkaline
cleaner, acid cleaner, scouring powder, chemical
cloth, or solvent such as alcohol, benzene or thinner,
as these may scratch the screen's coating.
Service
Damage Requiring Service
Do not attempt to service the set by yourself
since opening the cabinet may expose you to
dangerous voltage or other hazards.
Unplug the set from the wall outlet and refer
servicing to qualified service personnel.
Replacement Parts
When replacement parts are required, be sure the service
technician certifies in writing that he has used
replacement parts specified by the manufacturer that have
the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric
shock or other hazards.
See “Replacing the Lamp” on page 76.
Antenna lead-in wire
Ground clamps
Antenna lead-in wire
(NEC Section 810-20)
Grounding conductors
(NEC section 810-21)
Power service grounding
electrode system (NEC Art
250 Part H)
Ground clamp
Electrical
service
equipment
NEC: National
Electrical Code
❑ Clean the rear cover area of the TV regularly. Dust
in the rear cover area may cause a problem with the
cooling system of the TV set.
5
KDF-E55/60A20
2-593-962-12(1)
For Safety
Be Careful when Moving
the TV
When you place the TV in position,
be careful not to drop it on your foot
or fingers.
Watch your footing while installing
the TV.
Carry the TV in the Specified
Manner
If you carry the TV in a manner other than
the specified manner and without the
specified number of persons, it may drop
and a serious injury may be caused. Be
sure to follow the instructions mentioned below.
❑ Carry the TV with the specified number of persons
(see page 12).
❑ Do not carry the TV holding the speaker grill.
❑ Hold the TV tightly when carrying it.
❑ Before carrying the TV, disconnect any accessories
or cables.
About the LCD projection TV
Although the LCD projection TV is made with high-
precision technology, black dots may appear or bright
points of light (red, blue, or green) may appear constantly
on the LCD screen. This is a structural property of the
LCD panel and is not a defect.
Installation
❑ If direct sunlight or other strong illumination shines
on the screen, part of the screen may appear white
due to reflections from behind the screen. This is a
structural property of the LCD projection TV.
Do not expose the screen to direct illumination or
direct sunlight.
❑ The picture quality may be affected by your viewing
position. For the best picture quality, install your TV
according to “Recommended Viewing Area” on
page 13.
❑ When installing your TV against a wall, keep it at
least 4 inches (10 cm) from the wall.
Projection Lamp
❑ Your TV uses a projection lamp as its light source. It
is time to replace the lamp with a new one (not
supplied) when:
• the lamp replacement indicator on the front panel
blinks in red,
• screen images become dark,
• no image appears on the display after prolonged
use.
❑ In rare instances, the bulb may pop inside the lamp
unit, but the lamp unit is designed to contain all of
broken glass pieces inside the lamp unit. (see
“Replacing the Lamp” on page 76)
Cooling Fan
❑ This TV uses a cooling fan. You may hear the noise
of fan running, depending on the placement of your
TV. The noise may be more noticeable during the
night or when the background noise level is low.
❑ When the lamp eventually burns out, you may hear
a noticeable pop sound. This is normal and is
inherent in this type of lamp.
KDF-E55/60A20
2-593-962-
12(1)
6
Contents
Introducing the Sony TV
Presenting the Sony TV ...........................................8
Package Contents.............................................8
Features............................................................8
Enjoying Your TV .................................................10
Notes on the TV.............................................10
Screen.............................................................10
Indicators .......................................................11
Projection Lamp.............................................11
Installing the TV ....................................................12
Carrying Your TV..........................................12
Take Precaution during Installation...............13
To Prevent the TV from Falling ....................13
When Installing Your TV Against a Wall .....13
Recommended Viewing Area........................13
TV Front Panel and Connectors.............................14
Front Panel .....................................................14
Front and Rear Panel Connectors ..................15
Connecting the TV
Overview................................................................17
Making Video and Audio Connections .........17
About Using S VIDEO ..................................18
About Using HDMI to DVI Adapter .............18
Basic Connections..................................................19
Cable System or VHF/UHF...........................20
Cable Box and Antenna .................................21
Cable Box ......................................................22
Satellite Receiver ...........................................23
Digital Cable Box
Or Digital Satellite Receiver..........................24
Using CableCARD
TM
Device................................25
About Using CableCARD
TM
Device.............25
Activating CableCARD Service ....................25
Removing the CableCARD
TM
Device...........26
Equipment with HDMI Connection...............27
Equipment with DVI Connection ..................28
Equipment with Digital Audio (Optical) .......29
Setting Up the TV Channel List ............................30
Using Initial Setup .........................................30
Connecting Optional Equipment ...........................31
VCR and Cable ..............................................32
VCR and Cable Box ......................................33
Two VCRs for Tape Editing..........................35
DVD Player with Component
Video Connectors ..........................................36
DVD Player with
S VIDEO and Audio Connectors...................37
Camcorder or PlayStation..............................38
Audio Receiver ..............................................39
Watching the TV
Overview................................................................41
Inserting Batteries into the Remote Control ..........41
Button Descriptions ...............................................42
Programming the Remote Control.........................44
Manufacturer’s Codes............................................45
Using Other Equipment with Your Remote
Control ...........................................................46
Special Buttons on the Remote Control.................48
Using the GUIDE Button...............................48
Using the WIDE Button.................................50
Using the FREEZE Button ............................51
Using the JUMP Button.................................51
Introducing WEGA GATE
Overview of WEGA GATE...................................52
Using Favorites in WEGA GATE .........................54
Using Cable in WEGA GATE...............................54
Using Antenna in WEGA GATE ..........................55
Using External Inputs in WEGA GATE ...............55
Using Settings in WEGA GATE ...........................55
Using the Settings
Overview................................................................56
Accessing the Video Settings ................................58
Selecting Video Options................................58
Accessing the Audio Settings ................................60
Selecting Audio Options................................60
Accessing the Screen Settings ...............................62
Selecting Screen Options...............................62
Accessing the Channel Settings.............................64
Selecting Channel Options ............................64
Accessing the Parental Lock Settings....................66
Selecting Parental Lock Options ...................66
Viewing Blocked Programs...........................67
Selecting Custom Rating Options..................68
7
KDF-E55/60A20
2-593-962-
12(1)
Accessing the Setup Settings .................................70
Selecting Setup Options.................................70
Programming Caption Vision ........................72
Accessing the Applications Settings......................73
Selecting Applications Options .....................73
Other Information
Overview................................................................75
Contacting Sony.....................................................75
Replacing the Lamp ...............................................76
How to Replace the Lamp .............................76
Troubleshooting .....................................................80
Remote Control..............................................80
CableCARD
TM
Device ..................................80
Video..............................................................81
Audio .............................................................82
Channels.........................................................82
General...........................................................83
Specifications.........................................................84
Optional Accessories .............................................85
Index
Index ......................................................................87
8
KDF-E55/60A20
2-593-962-12(1)
Introducing the Sony TV
Presenting the Sony TV
Thank you for purchasing this Sony’s HD LCD Projection TV.
This manual is for models KDF-E55A20 and KDF-E60A20.
Instructions in this manual are written for the remote control. Similar
controls are also found on the TV console.
Package Contents Along with your new TV, the packing box contains a remote control and two
AA (R6) batteries. These items are all you need to set up and use the TV.
Also included in the box are this operating manual and a Quick Setup Guide
poster.
Features Some of the features that you will enjoy with your new TV include:
❑ WEGA GATE
™
: WEGA GATE is a new feature that allows you to
easily navigate to the most convenient TV functions: favorite channels,
cable channels, antenna channels, external input list or settings.
❑ WEGA Engine: Delivers superb picture quality from any video source
by minimizing the signal deterioration caused by digital-to-analog
conversion and stabilizing the signal processing. This engine features
unique Sony technology, including:
● The first step in the digital processing system, Composite
Component Processor (CCP-X), which enhances input signal-to-
noise ratio by chroma decoder digital processing.
● DRC
®
(Digital Reality Creation)-MF V1: Unlike conventional
line doublers, the DRC Multifunction feature replaces the signal’s
NTSC waveform with the near-HD equivalent by digital mapping
processing. The DRC Palette option lets you customize the level of
detail (Reality) and smoothness (Clarity) to create up to three
custom palettes.
❑ Integrated HDTV: You can watch digital television programs and
enjoy the improved audio/video quality offered by these programs.
❑ CableCARD
™
slot: Provides cable subscribers with access to digitally
encrypted cable channels — without the need for a set-top box — that
will enable you to receive not only standard definition but also high
definition television. The CableCARD device, which is provided by
your cable TV company, is inserted into the TV’s rear panel
CableCARD slot. After the service is activated with your cable TV
company, the card replaces the need for a separate set-top box. (Check
with your cable TV company about CableCARD service details,
limitations, pricing, and availability. For more information about
CableCARD device in this manual, see page 25.)
Introducing the Sony TV
9
Introducing the Sony TV
KDF-E55/60A20
2-593-962-12(1)
❑ HDMI (High-Definition Multimedia Interface): Provides an
uncompressed, all-digital audio/video interface between this TV and
any HDMI-equipped audio/video component, such as a set-top box,
DVD player, and A/V receiver. HDMI supports enhanced, or high-
definition video, plus multi-channel digital audio.
❑ Component Video Inputs: Offer the best video quality for DVD (480p,
480i) and digital set-top box (1080i, 720p, 480p, 480i) connections.
❑ S VIDEO Inputs: Provide a high-quality image from connected
equipment.
❑ CineMotion
®
: Using the reverse 3-2 pull down technology, the
CineMotion feature provides smoother picture movement when playing
back movies or other video sources on film.
❑ Steady Sound
®
: Equalizes volume levels so there is consistent output
between programs and commercials.
❑ Wide Screen Mode: Allows you to watch 4:3 normal broadcasts in
wide screen mode (16:9 aspect ratio).
❑ Favorite Channels: Allows you to navigate a list of up to sixteen
favorite channels without leaving the current channel.
❑ Parental Control: V-Chip technology allows parents to block
unsuitable programming from younger viewers.
Introducing the Sony TV
10
KDF-E55/60A20
2-593-962-12(1)
Enjoying Your TV
To enjoy your TV for years to come and maintain its original picture quality,
you should perform periodic maintenance.
Notes on the TV To enjoy clear picture
❑
Prevent sunlight or other light sources from shining directly on to the
screen.
❑ The screen surface is easily scratched. Do not rub, touch, or tap it with
sharp or abrasive objects (see “Cleaning” on page 4).
When not using the TV for a long period of time
❑
Unplug the AC power cord from the outlet if you anticipate not using
the TV for more than a week.
When turning off the power
❑
The cooling fan will continue to operate for about two minutes. Allow
several minutes before unplugging from the outlet or switching the
breaker off.
On moisture condensation
❑
If your TV is moved directly from a cold to a warm location or is placed
in a humid room, or if the room temperature changes suddenly, the
picture may blur or show poor color. This is caused by moisture
condensation on the lenses inside. Wait a few hours to let the moisture
evaporate before turning on the TV. When the condensation has
evaporated, the picture will return to normal.
Screen To minimize reflection, the screen surface has a special coating.
Inappropriate cleaning methods could damage the screen surface. Special
care is required.
Cleaning the Screen Surface
Dust and dirt on the screen can affect the picture quality. To dust off the
screen use a soft cloth. Be sure to follow the cleaning instruction on page 4
for stubborn stains and dirt.
Temporary Image Retention
When high contrast non-moving images such as station logos and channel
numbers are displayed for a long period of time, there may be some image
retention on the screen. This is only a temporary condition. Turning off the
power for a while or letting the TV run on another channel will eliminate the
retained image.
Introducing the Sony TV
11
Introducing the Sony TV
KDF-E55/60A20
2-593-962-12(1)
Indicators The indicators show the current status of your TV. If there is a change in the
condition or a problem with the TV, the indicators will flash or light up in
the manner described below to let you know that it requires your attention.
Projection Lamp Your TV uses a projection lamp as its light source. As with any lamp, it has
lifespan and needs to be replaced when the Lamp indicator flashes or the
screen becomes darker. The projection lamp is located under the Control
Panel cover as shown in the diagram above. Note the following:
❑ After turning on your TV, it may take a while (1 minute or less) before
the picture appears.
❑ When the projection lamp wears out, the screen goes dark. Replace the
lamp with a new Sony XL-2200 replacement lamp (not supplied).
LAMP TIMER POWER
POWER
Screen
Projection lamp
Indicators
Indicator Flashing because...
POWER
(green) flashing
The lamp for the light source is preparing to turn on. When
it is ready, it turns on.
POWER
(red) flashing
The lamp cover is not securely attached. The red indicator
will continue to flash in intervals of 3 blinks at a time until
the lamp cover is placed correctly. When the lamp cover is
securely attached the TV will turn on with green indicator.
TIMER indicator is
lit.
When one of the timer is set, the indicator will remain lit
(will not flash) even when the TV is turned off.
LAMP indicator
flashes.
The projection lamp has burned out. Replace it with a new
one (see page 14).
How to replace the lamp,
see page 76.
✍ The light emitted from the lamp is quite bright when your TV is in use. To
avoid eye discomfort or injury, do not look into the light housing when
the power is on.
Introducing the Sony TV
12
KDF-E55/60A20
2-593-962-12(1)
Installing the TV
Carrying Your TV Carrying the TV requires at least two people. Do not hold by the pedestal or
the front panel of the TV. Doing so may cause these parts to break off.
When moving the TV, place one hand in the hole on the lower portion of the
TV while grasping the top with the other hand, as shown in the illustration
below.
If you have connected cables and cords, be sure to unplug them before
moving the TV.
Do not grasp the pedestal
or the front panel of the
TV.
Introducing the Sony TV
13
Introducing the Sony TV
KDF-E55/60A20
2-593-962-12(1)
Take Precaution
during Installation
To ensure the safety of children and the TV, keep children away from the TV
during installation. Climbing on or pushing the TV or its stand may cause it
to fall and damage the TV.
To Prevent the TV
from Falling
As a protective measure, secure the TV as follows.
Using the TV stand with support belts
❑
Sony strongly recommends using the TV stand SU-GW12 with a
support belt designed for your TV.
When Installing Your
TV Against a Wall
Keep your TV at least 4 inches (10 cm) away from the wall to provide proper
ventilation.
Recommended
Viewing Area
Your viewing position may affect the picture quality.
For the best picture quality, install your TV within the areas shown below.
Model Viewing distance
KDF-E55A20 min. 6.8 ft. (approx. 2.1 m)
KDF-E60A20 min. 7 ft. (approx. 2.2 m)
27.5˚
27.5˚
60"
55"
min. 7 ft. (approx. 2.2 m)
min.
min.
6.8 ft.
6.8 ft.
(approx.
(approx.
2.1 m
2.1 m
)min.
6.8 ft.
(approx.
2.1 m
)
62.5
62.5
65
65
˚
62.5˚
62.5˚
min. 6.6 ft. (approx. 2.0 m)
min. 6.6 ft. (approx. 2.0 m)
50"
50"
min. 7 ft. (approx. 2.2 m)
60"
min. 5.9 ft. (approx. 1.8 m)
min. 5.9 ft. (approx. 1.8 m)
42"
42"
min. 6.8 ft. (approx. 2.1 m)
55"
Horizontal Viewing Area
Vertical Viewing Area
When using the SU-GW12
stand for your TV, you
must use the support belt.
Introducing the Sony TV
14
KDF-E55/60A20
2-593-962-12(1)
TV Front Panel and Connectors
Front Panel
Item Description
1 POWER Press to turn on/off the TV.
2 POWER LED Lights up in green when the TV set is turned on. The LED
light does not light up when the main power is turned off.
If the LED blinks continuously, this may indicate the
display unit needs servicing (see “Contacting Sony” on
page 75).
3 TIMER LED When lit, indicates one of the timers is set. When the
timer is set, this LED will remain lit even if the TV set is
turned off. For details, see page 73.
4 LAMP LED
Lights up in red when the lamp for the light source has burned
out. For details, see “Replacing the Lamp” on page 76.
5 (IR) Infrared
Receiver
Receives IR signals from the remote control. Do not put
anything near the sensor, as its function may be affected.
6 CHANNEL +/–
Press to scan through channels. To scan quickly through
channels, press and hold either CHANNEL.
7 VOLUME +/– Press to adjust the volume.
8 TV/VIDEO Press to select among the TV’s tuner and other video
equipment inputs.
The CHANNEL +
button has a tactile dot.
Use the dot as a
reference when
operating the TV.
z
LAMP TIMER POWER
POWER
POWER
LAMP TIMER POWER
3
3
#
#
TV/VIDEO
VOLUME
CHANNEL
6
7
8
15 4 3 2
Introducing the Sony TV
15
Introducing the Sony TV
KDF-E55/60A20
2-593-962-12(1)
Front and Rear
Panel Connectors
LAMP TIMER POWER
VIDEO 2 INPUT
S VIDEO VIDEO L (MONO) R AUDIO
1 2
POWER
Front Panel of TV
Press up lightly
to release the
console
Connection Description
1 S VIDEO
(Front and rear)
Connects to the S VIDEO OUT jack of your VCR or other
S VIDEO-equipped video component. Provides better
picture quality than the Video IN jack.
2 VIDEO/ L(MONO)-
AUDIO-R
(Front and rear)
Connects to the audio and video OUT jacks on your VCR
or other video component. A fourth video input (VIDEO 2)
is located on the front panel of the TV.
3 HD/DVD IN (1080i/
720p/480p/480i)
Connects to your DVD player’s or digital set-top box’s
component video (YPbPr) and audio (L/R) jacks.
4 AUDIO OUT
(VAR/FIX) L/R
Connects to the left and right audio inputs of your audio or
video component.
✍ AUDIO OUT jacks are operable only when the TV’s
Speaker is set to Off.
(Continued)
Introducing the Sony TV
16
KDF-E55/60A20
2-593-962-12(1)
*
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Connection Description
5 CableCARD slot CableCARD device provides cable subscribers with access
to secure, digitally encrypted cable channels - without the
need for a set-top box - that will enable you to receive not
only standard definition but also high definition television.
For more information, see page 25.
6 DIGITAL AUDIO
(OPTICAL OUT)
(PCM/DOLBY*
DIGITAL)
Connects to the optical audio input of a digital audio
component that is PCM/Dolby Digital compatible.
7 VHF/UHF Connects to your VHF/UHF antenna.
8 CABLE Connects to your cable signal. This CABLE input jack, in
conjunction with the VHF/UHF input jack, lets you set up
your TV to switch between scrambled channels (coming
through a cable box) and unscrambled cable channels.
9 HDMI
(VIDEO 6 IN)
HDMI (High-Definition Multimedia Interface) provides an
uncompressed, all-digital audio/video interface between
this TV and any HDMI-equipped audio/video component,
such as a set-top box, DVD player, and A/V receiver.
HDMI supports enhanced, or high-definition video, plus
two-channel digital audio.
1
2
3
4
56
7
9
8
VIDEO IN
VHF/UHF CABLE
S VIDEO
VIDEO
AUDIO
Y
P
B
P
L
R
L
(MONO)
R
1
AUDIO
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL)
OUT
L
R
3
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
6
L
R
AUDIO
AUDIO IN
EJECT
Rear of TV
17
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Connecting the TV
Overview
Your new LCD Projection TV can receive both analog and digital
broadcasting signals from antenna, satellite and cable TV.
To display clear crisp pictures, you must connect your TV correctly and
choose the correct display format (see Wide button on page 50). It is strongly
recommended to connect the antenna using a 75-ohm coaxial cable to
receive optimum picture quality signal. A 300-ohm twin lead cable can be
easily affected by radio noise and the like, resulting in signal deterioration.
If you use a 300-ohm twin lead cable, keep it as far away as possible from
the TV.
Making Video and
Audio Connections
The signals that enter your TV and connected devices will need to output in
the correct format using the suitable connections. Below are different types
of video connectors available these days. Your TV comes with all types of
connectors with the exception of the DVI connector but your cable box or
satellite receiver may be equipped with this type. When connecting your TV,
use the inputs that are available on your devices that provide the best video
performance, as described below.
* An adapter is necessary when connecting DVI equipped device to this TV,
see page 18.
Best Video
Performance
Connector Type
Separate Audio
connection
required
HDMI (High-Definition
Multimedia Interface)
No
DVI (Digital Visual
Interface)
*
Yes
(not supplied)
Component
S VIDEO
Composite
RF/Coaxial No
Connecting the TV
18
KDF-E55/60A20
2-593-962-12(1)
About Using
S VIDEO
If the optional equipment you are connecting has an S VIDEO jack
(shown at left), you can use an S VIDEO cable for improved picture
quality (compared to an A/V cable). Because S VIDEO carries only
the video signal, you also need to connect audio cables for sound, as
shown below.
Example of an S VIDEO Connection
About Using HDMI
to DVI Adapter
If you are connecting equipment with DVI connector with this TV, you will
need to use an adapter. You can use an HDMI to DVI cable or an HDMI
adapter (not supplied). Both are available at your local electronics store.
When you use the adapter, you will also need to use separate audio cables for
sound as DVI connector is for video signals only.
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Rear of TV
S VIDEO
cable
Equipment with S VIDEO
Audio cable
HDMI to DVI Cable
Audio cable
HDMI adapter
Connecting the TV
19
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Basic Connections
The way in which you connect your TV will vary, depending on how your
home receives a signal (antenna and satellite, cable, cable box) and whether
or not you plan to connect a VCR.
If you are connecting a VCR
❑
See the connections described on pages 32 and 33.
If You Are Connecting See Page
Cable System or VHF/UHF
❏ No cable box or VCR
20
Cable Box and Antenna
❏ Cable box unscrambles only some channels
(usually premium channels)
❏ No VCR
21
Cable Box
❏ Cable box unscrambles all channels
❏ No VCR
22
Satellite Receiver 23
Digital Cable Box or Digital Satellite
Receiver
24
Connecting the TV
20
KDF-E55/60A20
2-593-962-12(1)
Cable System or
VHF/UHF
For best results, use this connection if you:
❑
Have a cable and/or an antenna.
(This is convenient if you are using a separate rooftop antenna to receive
additional channels that are not provided by your cable TV company.)
❑ Do not have a cable box or VCR. (If you have a cable box, see pages 21
to 22. If you have a VCR, see pages 32 and 33.)
Notes on Using This Connection
Antenna System
Cable Type Connect As Shown
Cable TV
(CATV) and
Antenna
To Do This... Do This ...
Switch
the TV’s input between
the cable and antenna
Press ANT to switch back and forth between the
TV’s VHF/UHF and CABLE inputs.
✍ Do not use an indoor antenna, which is especially susceptible to radio
noise.
Antenna cable
CATV cable
Connecting the TV
21
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Cable Box and
Antenna
For best results, use this connection if:
❑
Your cable company scrambles some channels, such as premium
channels (which requires you to use a cable box), but does not scramble
all channels.
❑ You do not have a VCR. (If you have a VCR, see pages 32 and 33.)
With this connection you can:
❑
Use the TV’s remote control to change channels coming through the
cable box to the TV’s cable input. (You must first program the remote
control for your specific cable box; see “Programming the Remote
Control” on page 44.)
❑ Use the TV’s remote control to change channels coming directly into
the TV’s VHF/UHF input jack.
Notes on Using This Connection
Before connecting a
cable box, see “Using
CableCARD Device” on
page 25.
IN OUT
VHF/UHF Cable
CATV cable
Rear of TV
Cable box
Coaxial
cable
Antenna
cable
To Do This ... Do This ...
Use the cable box Tune the TV to the channel the cable box is set to (usually channel 3
or 4) and then use the cable box to switch channels.
Set up the TV remote control to operate the cable
box
Program the remote control. See “Programming the Remote
Control” on page 44.
Activate the remote control to operate the cable
box
Press SAT/CABLE (FUNCTION) once, and the SAT/CABLE
indicator lights up.
Prevent the accidental switching of TV channels When using the cable box, ensure that the TV remains tuned to the
channel that the cable box is set to (usually channel 3 or 4).
Switch
the TV’s input between the cable box and
antenna
Press ANT to switch back and forth between the TV’s VHF/UHF
(scrambled channels) and CABLE (unscrambled) inputs.
Connecting the TV
22
KDF-E55/60A20
2-593-962-12(1)
Cable Box For best results, use this connection if:
❑
Your cable company scrambles all channels, which requires you to use a
cable box.
❑ You do not have a VCR. (If you have a VCR, see pages 32 and 33.)
With this connection you can:
❑
Use the TV’s remote control to change channels coming through the
cable box to the TV’s VHF/UHF jack. (You must first program the
remote control for your specific cable box.)
To connect the cable box
1 Connect the CATV cable to the cable box’s input jack.
2 Use a coaxial cable to connect the cable box’s output jack to the TV’s
VHF/UHF jack.
3 Run Auto Program, as described in “Setting Up the TV Channel List”
on pages 30.
Notes on Using This Connection
Before connecting a
cable box, see “Using
CableCARD Device” on
page 25.
VHF/UH
F
CATV cable
Coaxial cable
Rear of TV
Cable box
OUT
IN
To do this... Do This ...
Use the cable box Tune the TV to the channel the cable box is set to (usually channel 3
or 4) and then use the cable box to switch channels.
Set up the TV remote control to operate the cable
box
Program the remote control. See “Programming the Remote
Control” on page 44.
Activate the remote control to operate the cable
box
Press SAT/CABLE (FUNCTION) once, and the SAT/CABLE
indicator lights up.
Prevent the accidental switching of TV channels When using the cable box, ensure that the TV remains tuned to the
channel that the cable box is set to (usually channel 3 or 4).
Connecting the TV
23
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Satellite Receiver Disconnect all power sources before making any connections.
1 Connect the satellite antenna cable to the satellite receiver’s
SATELLITE IN jack.
2 Use A/V and S VIDEO cables to connect the satellite receiver’s AUDIO
and S VIDEO OUT jacks to the TV’s AUDIO and S VIDEO IN jacks.
3 Use a coaxial cable to connect your cable to the TV’s CABLE jack, or
your antenna to the TV’s VHF/UHF jack.
VHF/UHF CABLE
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
Satellite receiver
A/V cable (not supplied)
Rear of TV
VIDEO (yellow)
AUDIO-L (white)
AUDIO-R (red)
Satellite
antenna
cable
S VIDEO
S VIDEO cable (not supplied)
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Coaxial cable
✍ If your satellite receiver is not equipped with S VIDEO, use a VIDEO cable
(yellow) instead of the S VIDEO cable.
Connecting the TV
24
KDF-E55/60A20
2-593-962-12(1)
Digital Cable Box
Or
Digital Satellite
Receiver
Disconnect all power sources before making any connections.
1 Connect the RF coaxial cable from the CATV or Satellite dish to the
INPUT of the digital cable box or digital satellite receiver.
2 Use a component video cable to connect the YPBPR jacks of your digital
cable box or digital satellite receiver to the TV’s component jacks.
3 Use an audio cable to connect the AUDIO OUT jack of the digital cable
box or digital satellite receiver to the TV’s AUDIO IN jacks.
Y
P
B
P
L
R
AUDIO
L
R
HD/DVD IN
(1080i/720p/
480p/480i)
4 5
AUDIO
OUT
(VAR/FIX)
R
AUDIO
Rear of TV
Y
P
B
PR
AUDIO-L
(white)
AUDIO-R
(red)
Audio cable
(not supplied)
Digital cable box or satellite
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Component video cable
(not supplied)
RF coaxial cable
✍ Component video (YPBPR) connection is necessary to view digital
broadcastings in 1080i, 720p, 480i and 480p. This TV displays all format
types of picture in a resolution of 1,368 dots x 768 lines.
✍ The component Jacks (YPBPR) do not provide audio, so audio cables
must be connected to provide sound.
Connecting the TV
25
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Using CableCARD Device
The CableCARD
device provides cable subscribers with access to digitally
encrypted cable channels — without the need for a set-top box — that will
enable you to receive not only standard definition but also high definition
television. The CableCARD device, which is provided by your cable TV
company, is inserted into the TV’s rear panel CableCARD slot. After the
service is activated with your cable TV company, the card replaces the need
for a separate set-top box.
About Using
CableCARD
Device
If you are planning to use a separate cable box for digital cable TV services,
you may be able to receive programming using this TV with the
CableCARD device instead — except in the following circumstances:
❑ Your cable TV company does not provide CableCARD service in your
viewing area.
❑ You want to access your cable TV company’s interactive or advanced
features (such as video-on-demand or, in some cases, pay-per-view). At
this time, these services require a bidirectional link, which are only
available through the use of a separate set-top box. CableCARD device is
currently a unidirectional device only, and cannot provide these advanced
services.
Check with your cable TV company for CableCARD service details,
limitations, pricing, and availability, all of which are determined by your
cable TV company — not Sony.
Activating
CableCARD Service
Before you can use CableCARD service, you need to insert the CableCARD
device (supplied by your cable TV company) and activate the service, as
described below:
1 Insert the CableCARD device into the TV’s CableCARD slot.
VIDEO IN
VHF/UHF CABLE
S VIDEO
VIDEO
AUDIO
Y
P
B
P
L
R
L
(MONO)
R
1
AUDIO
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL)
OUT
L
R
3
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
6
L
R
AUDI O
AUDIO IN
EJECT
✍ CAUTION: Inserting the CableCARD device incorrectly may result in
permanent damage to the card and the TV.
(Continued)
Connecting the TV
26
KDF-E55/60A20
2-593-962-12(1)
2 Gently push the card into the slot until it locks into place.
3 After 1-2 minutes, the CableCARD device setup screen is automatically
displayed. This screen includes information your cable TV company
will request before they can activate your service.
4 Follow the displayed instructions: Phone your cable TV company. A
representative will guide you through the activation process.
5 After your CableCARD device is activated, your cable TV company
will download the service information, including the channel list, to the
CableCARD device. After the CableCARD device has acquired
channels from your cable TV company, the TV tunes to the lowest
available channel.
Removing the
CableCARD
Device
In the event you want to cancel your service, contact your cable TV
company.
1 Push the eject button on the TV’s CableCARD slot to release the card.
2 Pull the CableCARD device straight out of the slot to remove it.
To install a different CableCARD
device, follow the instructions in
“Activating CableCARD Service” on page 25.
You can also access
information about your
CableCARD device in
the Applications Menu
(see page 74).
z
✍ Once the CableCARD
device is removed, your TV will no longer decrypt
digital cable TV programming services that require CableCARD device.
Eject button
Connecting the TV
27
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Equipment with
HDMI Connection
Use this hookup if:
❑ Your equipment has a High-Definition Multimedia Interface (HDMI).
Disconnect all power sources before making any connections
Use an HDMI cable (not supplied) to connect the equipment’s HDMI OUT
jack to the TV’s HDMI IN jack.
Use the HDMI IN 6 input connection.
The HDMI jack
provides both video
and audio signals, so it
is not necessary to
connect the audio
cable.
z
VIDEO IN
VHF/UHF CABLE
S VIDEO
VIDEO
AUDIO
Y
P
B
P
L
R
L
(MONO)
R
1
AUDIO
L
R
3
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
6
L
R
AUDIO
AUDIO IN
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL)
OUT
EJECT
Rear of TV
HDMI cable (not supplied)
Equipment with HDMI output
Connecting the TV
28
KDF-E55/60A20
2-593-962-12(1)
Equipment with DVI
Connection
If you are connecting with DVI-HDTV output, you can connect to the TV’s
HDMI IN jack by using an HDMI-to-DVI cable or an adaptor (both not
supplied).
VIDEO IN
VHF/UHF CABLE
S VIDEO
VIDEO
AUDIO
Y
P
B
P
L
R
L
(MONO)
R
1
AUDIO
L
R
3
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
6
L
R
AUDIO
AUDIO IN
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL)
OUT
EJECT
Rear of TV
HDMI-to-DVI adapter or
cable (not supplied)
Audio cable
(not supplied)
Equipment with HDMI output
AUDIO-R (red)
AUDIO-L (white)
✍ When using a DVI-HDMI cable or an adapter, be sure to connect the DVI
output connector first; then connect to the HDMI input on your TV.
Connecting the TV
29
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Equipment with
Digital Audio
(Optical)
You can use the TV's DIGITAL AUDIO (OPTICAL) OUT jack to connect a
digital audio device that is PCM/Dolby Digital compatible, such as an audio
amplifier.
Use an optical audio cable to connect the device's OPTICAL IN jack to the
TV's DIGITAL AUDIO (OPTICAL) OUT jack.
VIDEO IN
VHF/UHF CABLE
S VIDEO
VIDEO
AUDIO
Y
P
B
P
L
R
L
(MONO)
R
1
AUDIO
L
R
3
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
6
L
R
AUDIO
AUDIO IN
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL)
OUT
EJECT
OPTICAL
IN
LINE
OUT
L AUDIO R
LINE
IN
Optical audio cable (not supplied)
Rear of TV
Audio amplifier
The DIGITAL AUDIO
(OPTICAL) OUT jack is
available only when a
digital TV channel is
received.
Connecting the TV
30
KDF-E55/60A20
2-593-962-12(1)
Setting Up the TV Channel List
After you finish connecting the TV, you can run the Initial Setup to create a
list of available analog and digital channels. The Initial Setup screen appears
when you turn on the TV for the first time after hooking it up. If you choose
to set up the channels at a later time select the Auto Program option in the
Channel menu to scan available channels (see below).
Using Initial Setup To run Initial Setup the first time you turn on your TV
1 Press to turn on the TV.
The Initial Setup screen appears.
2 Press V or v to highlight the on-screen
display language. Then press . The
message “First please connect cable/
antenna” appears. This may require 50+
minutes for completion and “Start auto program now?” appears.
3 Press V or v to highlight “Yes” then press .
Auto Program performed through Initial Setup will automatically create a
list of receivable channels from both VHF/UHF antenna and cable TV
channels if both sources are connected.
To run Auto Program at a later time
1 Select Settings in WEGA GATE, and then go to Channel settings.
2 Select Auto Program then select Start.
✍ The Auto Program feature does not apply for installations that use a
cable box for all channel selection.
✍ Auto Program may take a while (20 to 50 minutes) to complete. A
progress bar is displayed while available channels are being scanned. If
you cancel the Auto Program before all receivable channels are scanned,
you may want to perform the task later (see “To run Auto Program at a
later time” below).
✍ If you selected “No” during the Initial Setup, the Initial Setup message
will appear each time you turn on the TV until you complete the Auto
Program as a reminder.
✍ Auto Program will create a list of receivable channels for the current
input (UHF/VHF antenna or CABLE). You will be required to run Auto
Program for each RF input to create a list of available channels from both
inputs.
TV POWER
Connecting the TV
31
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Connecting Optional Equipment
You can connect variety of optinal equipment to your TV. This section
provides some of the individual connections you can have. For multiple
connections please refer to the Quick Setup Guide.
If You Are Connecting Page
VCR and Cable 32
VCR and Cable Box 33
Two VCRs for Tape Editing 35
DVD Player with Component Video Connectors 36
DVD Player with S VIDEO and Audio Connectors 37
Camcorder or PlayStation 38
Audio Receiver 39
Connecting the TV
32
KDF-E55/60A20
2-593-962-12(1)
VCR and Cable Use this hookup if:
❑ You have cable TV that does not require a cable box.
Disconnect all power sources before making any connections.
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the output jack of the splitter to the
TV’s CABLE jack.
3 Use a coaxial cable to connect the splitter’s other output jack to the
VCR’s input jack.
4 Use A/V and S VIDEO cables to connect the VCR’s AUDIO and
S VIDEO OUT jacks to the TV’s AUDIO and S VIDEO IN jacks.
VHF/UHF CABLE
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
Coaxial cable
Rear of TV
VIDEO (yellow)
AUDIO-L (white)
AUDIO-R (red)
Cable
VCR
A/V cable
(not supplied)
S VIDEO
S VIDEO cable (not supplied)
Coaxial cable
Splitter
✍ If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow)
instead of the S VIDEO cable.
Connecting the TV
33
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
VCR and Cable Box Use this hookup if:
❑ Your cable TV company scrambles some channels, but not all of them
(pay channels vs. regular cable channels) and you need to use a cable
box.
With this setup you can:
❑ Use the TV’s remote control to change channels on your cable box
when the signal is scrambled. To program your Sony remote control to
operate your cable box, see “Programming the Remote Control” on
page 44.
❑ Use the TV’s remote control to change channels on your TV when the
signal is not scrambled. Your TV’s tuner provides a better picture
quality than the output of your cable box.
Disconnect all power sources before making any connections.
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the splitter’s two output jacks to
the TV’s CABLE jack.
3 Use a coaxial cable to connect the splitter’s other output jack to the
cable box’s input jack.
4 Use a coaxial cable to connect the cable box’s output jack to the VCR’s
RF input jack.
5 Use an A/V cable to connect the cable box’s A/V output jacks to the
TV’s A/V input jacks.
6
Use an A/V and S VIDEO cables to connect the VCR’s AUDIO and
S VIDEO OUT jacks to the TV’s AUDIO and S VIDEO IN input
jacks.
7 Run Auto Program, as described in “Setting Up the TV Channel List”
on page 30.
Before connecting a
cable box, see “Using
CableCARD Device” on
page 25.
✍ To view scrambled channels, tune the TV to the channel the cable box is
set to (usually channel 3 or 4) and then use the cable box to switch
channels.
(Continued)
Connecting the TV
34
KDF-E55/60A20
2-593-962-12(1)
VHF/UHF CABLE
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
Cable box
VCR
Rear of TV
A/V cable
(not supplied)
Coaxial
cable
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
S VIDEO cable
(not supplied)
CATV
cable
Coaxial
cable
Splitter
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
If you are connecting a
digital cable box, you will
need a special bi-
directional splitter
designed to work with
your cable box.
Coaxial cable
A/V cable
(not supplied)
✍ If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow)
instead of the S VIDEO cable.
Connecting the TV
35
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Two VCRs for Tape
Editing
If you connect two VCRs, you can record from one VCR to the other while
using your TV to monitor what is being recorded.
Disconnect all power sources before making any connections.
1 Use A/V cables to connect the playback VCR’s AUDIO and VIDEO
OUT jacks to the recording VCR’s AUDIO and VIDEO IN jacks.
2 Use A/V cables to connect the recording VCR’s AUDIO and VIDEO
OUT jacks to the TV’s AUDIO and VIDEO IN jacks.
Using
S VIDEO jacks?
See page 18.
7
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
Rear of TV
VCR (playback)
VCR (recording)
A/V cable (not supplied)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
A/V cable (not supplied)
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
✍ To perform tape editing, set the TV to the video input intended for
playback by pressing TV/VIDEO on the remote control.
✍ You may need to change the video input on your VCR. Consult your
VCR’s operating manual for instructions.
✍ If your VCRs have S VIDEO jacks: For best picture quality, use an
S VIDEO connection instead of the yellow video cable on your combined
A/V cable.
Use an S VIDEO cable to connect the playback VCR’s S VIDEO OUT jack
to the recording VCR’s S VIDEO IN jack. S VIDEO does not provide audio,
so audio cables must be connected to provide sound.
✍ You cannot record signals from equipment connected to the YPBPR input.
Connecting the TV
36
KDF-E55/60A20
2-593-962-12(1)
DVD Player with
Component
Video Connectors
Use this hookup if:
❑ Your DVD player has component (Y, B-Y, R-Y) jacks.
Disconnect all power sources before making any connections.
1 Use a component video cable to connect the DVD player’s Y, B-Y and
R-Y jacks to the TV’s YP
BPR jacks. Use the HD/DVD IN 4 or 5
connections.
2 Use an audio cable to connect the DVD player’s AUDIO OUT jacks to
the TV’s AUDIO IN jacks. Be sure to use the same row of inputs that
you used for the video connection (HD/DVD IN 4 or 5).
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
✍ The Y, B-Y and R-Y jacks on your DVD player are sometimes labeled
Y, C
B and CR, or YPbPr. If so, connect the cables to like colors.
Y
P
B
P
L
R
HD/DVD IN
(1080i/720p/
480p/480i)
4 5
R
AUDIO
Component video cable
(not supplied)
Rear of TV
Audio cable (not supplied)
DVD player
AUDIO-R (red)
AUDIO-L (white)
Y
P
B
PR
✍ To take advantage of the Wide Mode feature on your TV, set the DVD
player’s aspect ratio to 16:9. For details, refer to the operating
instructions supplied with your DVD player.
Connecting the TV
37
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
DVD Player with
S VIDEO and Audio
Connectors
Use this hookup if:
❑ Your DVD player does not have component (Y, B-Y, R-Y) jacks.
Disconnect all power sources before making any connections.
1 Use an audio cable to connect the DVD player’s AUDIO OUT jacks to
the TV’s AUDIO IN jacks.
2 Use a S VIDEO cable to connect the DVD player’s S VIDEO jack to the
TV’s S VIDEO jack.
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
VIDEO IN
S VIDEO
VIDEO
AUDIO
L
(MONO)
R
1 3
DVD player
Rear of TV
Audio cable (not supplied)
S VIDEO
cable
S VIDEO
AUDIO-R
(red)
AUDIO-L
(white)
VIDEO
(yellow)
✍ If your DVD player is not equipped with S VIDEO, use a VIDEO cable
(yellow) instead of the S VIDEO cable.
✍ To watch a DVD, press TV/VIDEO repeatedly to select the DVD input
(VIDEO 1 in the illustration). If you have a non-Sony DVD player, and
want to set up the TV remote control to operate the DVD player you
must program the remote control. See “Programming the Remote
Control” on page 44.
✍ To control DVD functions with the TV remote control, see “Operating
a DVD Player or DVD Changer” on page 46.
✍ Label Video Inputs to easily identify equipment connected to the TV.
See the instructions for setting up Video Labels on page 70.
Connecting the TV
38
KDF-E55/60A20
2-593-962-12(1)
Camcorder or
PlayStation
Disconnect all power sources before making any connections.
For easy connection to a camcorder or PlayStation, the TV has front audio
and video inputs (shown below).
Use A/V and S VIDEO cables to connect the camcorder or PlayStation’s
AUDIO and S VIDEO OUT jacks to the TV’s AUDIO and S VIDEO IN
jacks.
✍ If your camcorder is not equipped with S VIDEO, use a VIDEO cable
(yellow) instead of the S VIDEO cable.
VIDEO 2 INPUT
RAUDIOS VIDEO VIDEO L (MONO)
VIDEO (yellow)
To A/V output
AUDIO-L (white)
AUDIO-R (red)
S VIDEO
A/V cable
(not supplied)
S VIDEO cable
(not supplied)
Front of TV
To S VIDEO
output
Camcorder
PlayStation
Connecting the TV
39
Connecting the TV
KDF-E55/60A20
2-593-962-12(1)
Audio Receiver For improved sound quality, you may want to play the TV’s audio through
your stereo system (see page 61).
Disconnect all power sources before making any connections.
Use A/V cables to connect the TV’s AUDIO OUT (VAR/FIX) jacks to the
audio receiver’s audio LINE IN jacks.
✍ AUDIO OUT jacks are operable only when the TV’s Speaker is set to Off.
Y
P
B
P
L
R
AUDIO
L
R
HD/DVD IN
(1080i/720p/
480p/480i)
45
AUDIO
OUT
(VAR/FIX)
R
AUDIO
Rear of TV
AUDIO-L (white)AUDIO-R (red)
A/V cable
(not supplied)
Line
input
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Audio receiver
41
KDF-E55/60A20
2-593-962-12(1)
Watching the TV
Overview
The table on the next page describes the buttons on the remote control.
Inserting Batteries into the Remote Control
Insert two size AA (R6) batteries (supplied) by matching the e and E on
the batteries to the diagram inside the battery compartment.
Topic Page
Inserting Batteries into the Remote Control 41
Button Descriptions 42
Programming the Remote Control 44
Manufacturer’s Codes 45
Using Other Equipment with Your Remote Control 46
Using Special Buttons 48
✍ To avoid possible damage from battery leakage, remove the batteries if
you anticipate the remote control will not be used for an extended period.
✍ Handle the remote control with care. Avoid dropping it, getting it wet, or
placing it in direct sunlight, near a heater, or in high humidity.
✍ Your remote control can be programmed to operate most video
equipment. (See “Programming the Remote Control” on page 44.)
12
Watching the TV
42
KDF-E55/60A20
2-593-962-12(1)
Button Descriptions
Button Description
1
MUTING Press to mute the sound. Press again or press VOL + to unmute.
2
TV/VIDEO
Press to cycle through the video equipment connected to your
TV
’s
video inputs.
3
FUNCTION
Buttons
The FUNCTION button indicator lights up momentarily when
pressed to show which external equipment the remote control is
operating. When the remote control is set to operate the external
equipment these buttons will operate the equipment you choose. You
must first press one of these FUNCTION buttons to operate the
corresponding equipment. See page 44 for “Programming the Remote
Control”.
4
0-9, ENT Press 0-9 to select a channel: the channel changes after 2 seconds.
Press ENT to change channels immediately.
5
Use with 0-9 and ENT buttons to select digital channels (for
example, 2.1). For details on selecting digital channels, see
page 48
.
6
JUMP Press to jump back and forth between two channels. The TV alternates
between the current channel and the last channel that was selected.
7
ANT Press to change between the VHF/UHF input and the CABLE input.
8
SOUND Press to cycle through different sound settings: Dynamic for
enhanced treble and bass, Standard for spoken dialog and Custom
for flat setting.
9
PICTURE Press repeatedly to cycle through the available video picture modes:
Vivid, Standard, Custom. The video picture modes can be also
accessed in the Video menu. For details, see “Selecting Video
Options” on page 58.
0
GUIDE Press to display the TV’s program guide.
qa
RETURN Press to return to normal viewing.
qs
DVR, DVD/VCR
Operating
Buttons
When FUNCTION is switched on DVR or DVD/VCR, these buttons
operate the video equipment you have programmed into the remote
control. For details, see “Using Other Equipment with Your Remote
Control” on page 46.
&m PREVIEW: Press to replay the current program from the
previous Chapter Mark (if any) or from the beginning of the live TV
cache.
B
z
REPLAY: Press to replay the current program for a set period of
time.
z
b ADVANCE: Press to advance forward a set period of time when
playing back a recorded program.
M& NEXT: Press to advance forward to the next Chapter Mark (if
any) or to live TV when playing back a recorded program.
m (fast reverse): Press to play a program in fast rewind mode.
H PLAY: Press to play a program at a normal speed.
M (fast forward): Press to play a program in fast forward mode.
X PAU S E: Press to pause playback.
x STOP: Press to stop the playback of a recorded program.
qd
VISUAL
SEARCH
To be used only with your connected external equipment with
visual search function. (Non-operable button for TV)
qf
VOL +/–
Press to adjust the volume.
ENT
RETURN
TOOLS
TV/VIDEO
TV
MUTING
DVD/
VCR
SAT/
CABLE
DVR
POWER
TV POWER
JUMP ANT MTS/SAP
FREEZE
SOUND PICTURE
TV/SAT
SUR
WIDE
W
EGA
VISUAL SEARCH
CH
VOL
REC
REC PAUSE
REC STOP
TOP MENU
MENU
F1
F2
POWER SAVING
G
UIDE
DI
SP
LAY
REPLAY
GATE
ADVANCE
PLAY
PAUSE
PREV
NEXT
STOP
TV
Watching the TV
43
KDF-E55/60A20
2-593-962-12(1)
Watching the TV
qg DVD/VCR
Record Buttons
z REC: Press to record. By pressing this button alone will start the
recording.
X REC PAUSE: Press to pause the recording.
x REC STOP: Press to stop the recording.
qh
TOP MENU Press to display the disc menu from your connected DVD player.
qj
MENU Press to display the menu of your connected DVD player.
qk
POWER
SAVING
Press to cycle through
Standard
and
Reduced
to benefit the power
consumption. For additional benefits see page 71.
ql
POWER Press to turn on/off the external equipment selected from the
FUNCTION button
3.
w;
TV POWER Press to turn on/off the TV.
wa
MTS/SAP Press repeatedly to cycle through the Multi-channel TV Sound (MTS)
options: Stereo, Auto SAP (Second Audio Program), and Mono.
The MTS setting can be also accessed in the Audio menu. For more
details, see “Selecting Audio Options” on page 60.
ws
FREEZE Press to freeze the current picture. Press again to restore the picture.
For details, see “Using the FREEZE Button” on page 51.
wd
SUR/TV/SAT SUR: Press SUR (Surround Sound) repeatedly to step through the
available audio effect models: TruSurround XT, Simulated, Off.
TV/SAT: While in SAT/CABLE FUNCTION, press to switch
between the satellite receiver and antenna.
wf
WIDE Press repeatedly to step through the Wide Screen Mode setting: Wide
Zoom, Normal, Full and Zoom. The Wide Screen Mode setting can
be also accessed in the Screen menu. For details, see “Using the
WIDE Button” on page 50.
wg
DISPLAY Press once to display channel number, label, current time and other
information. Press again to turn Display off. See page 73 for details on
setting the time.
wh
V/v/B/b
Press V/v/B/b to move the on-screen cursor. To select an item, press
.
wj
TOOLS To be used only with your connected external equipment that supports
this TOOLS function. (This button does not operate for the TV.)
wk
WEGA GATE Press to acess the following through the WEGA GATE menu:
Watch TV (see pages 54 and 55)
Select channels from the Favorite Channels you stored (see page 54)
View signals from external equipment such as DVD, VCR and others
(see page 55).
Adjust or customize TV settings (see Using the Settings on page 56
through 74).
wl
CH +/– Press to scan through channels. To scan quickly through channels,
press and hold down either CH button.
e;
F1 Press to select the function of connected components. For details, see
“Using Other Equipment with Your Remote Control” on page 46.
ea
F2 Press to select the function of connected components. For details, see
“Using Other Equipment with Your Remote Control” on page 46.
Button Description
The 5 button, CH +
button, MTS/SAP button
and PLAY button have a
tactile dot. Use the dot
as a reference when
operating the TV.
z
Watching the TV
44
KDF-E55/60A20
2-593-962-12(1)
Programming the Remote Control
The remote control is preset to operate Sony brand video equipment.
Follow the steps below to program your TV’s remote control to operate the
other video equipment.
Find the three-digit code for your equipment from the “Manufacturer’s
Codes” listed on page 45. If more than one code number is listed, try
entering from the code listed first.
1 Press and hold the , or FUNCTION button you want to
program on the remote control and press the button simultaneously.
The selected FUNCTION button (DVR, DVD/VCR or SAT/CABLE)
will flash.
2 Enter the three-digit manufacturer’s code number using the - – 9
buttons while the button is lit. If code is not entered within 10 seconds,
you must perform the step 1 again.
3 Press button.
When programmed correctly, the selected FUNCTION button will flash
twice, and when not, it flashes five times.
To check if the code works
Aim your TV’s remote control at the equipment, and press the green
button. If the equipment turns on and off, the programming is completed. If
not, try the next code listed.
Sony Equipment Programmable Code Number
DVR 772
DVD/VCR 601 (Sony Dream System)
SAT/Cable 801 (Sony Satellite Receiver)
✍ If no code is input within the above specified time, or an invalid or
incorrect code number is input, the remote control automatically goes
back to the previous setting.
✍ In some cases, you may not be able to program your remote control to
operate other equipment. In such cases, use the equipment’s own
remote control.
✍ Removing the batteries or using dead batteries may cause the
programmed codes to be lost and revert back to the factory setting.
Reprogramming the codes may be necessary.
ENT
RETURN
TOOLS
TV/VIDEO
TV
MUTING
DVD/
VCR
SAT/
CABLE
DVR
POWER
TV POWER
JUMP ANT MTS/SAP
FREEZE
SOUND PICTURE
TV/SAT
SUR
WIDE
W
EGA
VISUAL SEARCH
CH
VOL
REC
REC PAUSE
REC STOP
TOP MENU
MENU
F1
F2
POWER SAVING
G
UIDE
D
I
SP
LAY
REPLAY
GATE
ADVANCE
PLAY
PAUSE
PREV
NEXT
STOP
TV
1
1
3
2
DVR
POWER
Watching the TV
45
Watching the TV
KDF-E55/60A20
2-593-962-12(1)
Manufacturer’s Codes
DVD Players
DVD Changers
DVD/VCR Combo Units
HDD/DVD Combo Units
5.1ch DVD AV System
AV Receivers
VCRs
Cable Boxes
Satellite Receivers
* If an Aiwa VCR does not work even
though you enter the code for Aiwa,
enter the code for Sony instead.
Manufacturer Code
Sony 751
General Electric 755
Hitachi 758
JVC 756
Magnvox 757
Mitsubishi 761
Panasonic 753
Philips 757
Pioneer 752, 778
RCA/PROSCAN 755
Samsung 758
Tosh iba 7 54
Zenith 760
Manufacturer Code
Sony 765
Panasonic 766
Manufacturer Code
Sony 767
Broksonic 776
JVC 775
Panasonic 777
Samsung 774
Toshiba 773
Zenith 768
Manufacturer Code
Sony 772, 770, 771
Manufacturer Code
Sony (DAV) 601, 602, 603, 604
Manufacturer Code
Sony 764
Manufacturer Code
Sony 301, 302, 303
Admiral
(M. Ward)
327
Aiwa* 338, 344
Audio Dynamic 314, 337
Broksonic 319, 317
Canon 309, 308
Citizen 332
Craig 302, 332
Curtis Mathes 304, 338, 309
Daewoo 341, 312, 309
DBX 314, 336, 337
Dimensia 304
Emerson 319, 320, 316, 317,
318, 341
Fisher 330, 335
Funai 338
General Electric 329, 304, 309
Go Video 322, 339, 340
Goldstar 332
Hitachi 306, 304, 305, 338
Instant Replay 309, 308
JC Penney 309, 305, 304, 330,
314, 336, 337
JVC 314, 336, 337, 345,
346, 347
Kenwood 314, 336, 332, 337
LG 332
LXI (SEARS) 332, 305, 330, 335,
338
Magnavox 308, 309, 310
Marantz 314, 336, 337
Marta 332
Memorex 309, 335
Minolta 305, 304
Mitsubishi/MGA 323, 324, 325, 326
Multitech 325, 338, 321
NEC 314, 336, 337
Olympic 309, 308
Optimus 327
Orion 317
Panasonic 308, 309, 306, 307
Pentax 305, 304
Philco 308, 309
Philips 308, 309, 310
Pioneer 308
Quasar 308, 309, 306
RCA/PROSCAN 304, 305, 308, 309,
311, 312, 313, 310,
329
Realistic 309, 330, 328, 335,
324, 338
Sansui 314
Samsung 322, 313, 321
Sanyo 330, 335
Manufacturer Code
Scott 312, 313, 321, 335,
323, 324, 325, 326
Sharp 327, 328
Signature 2000
(M. Ward)
338, 327
SV2000 338
Sylvania 308, 309, 338, 310
Symphonic 338
Tashiro 332
Tatung 314, 336, 337
Teac 314, 336, 338, 337
Technics 309, 308
Toshiba 312, 311
Wards 327, 328, 335, 331,
332
Yamaha 314, 330, 336, 337
Zenith 331
Manufacturer Code
Sony 230
Hamlin/Regal 222, 223, 224,
225, 226
Jerrold/
General Inst./
Motorola
201, 202, 203,
204, 205, 206,
207, 208, 218, 222
Oak 227, 228, 229
Panasonic 219, 220, 221
Pioneer 211, 214, 215
Scientific Atlanta 209, 210, 211
Tocom 216, 217
Zenith 212, 213
Manufacturer Code
Sony 801
Dish Network 810
Echostar 810
General Electric 802
Hitachi 805
Hughes 804
Mitsubishi 809
Panasonic 803
Philips 811
RCA/PROSCAN 802, 808
Toshiba 806, 807
Samsung 812
Manufacturer Code
Watching the TV
46
KDF-E55/60A20
2-593-962-12(1)
Using Other Equipment with Your Remote Control
To operate other connected equipment with your TV, first turn to page 44
and program the necessary code. For operating video equipment, press
TV/VIDEO repeatedly until you see the video input on the screen for your
connected equipment. Remote control operation tips are provided below.
Operating a Cable Box
Operating a Satellite Receiver
Operating a VCR
Operating a DVD Player or DVD Changer
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the cable box
SAT/CABLE
(FUNCTION)
Select a channel 0-9, ENT
Change channels CH +/–
Turn on/off POWER Back to previous channel JUMP
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the satellite receiver
SAT/CABLE
(FUNCTION)
Display channel number DISPLAY
Display SAT Guide GUIDE
Turn on/off POWER Display SAT Menu MENU
Select a channel 0-9, ENT Move highlight (cursor) V v B b
Change channels CH +/– Select item
Back to previous channel JUMP
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the VCR
DVD/VCR
(FUNCTION)
Fast forward M
Rewind the tape m
Turn on/off POWER Pause X (press again to resume
normal playback)
Change channels CH +/–
Record z Search the picture forward or
backward
M or m during
playback
Play H
Stop x (release to resume normal
playback)
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the DVD
DVD/VCR
(FUNCTION)
Step through different
tracks of the disc
M to fast forward or
m to fast reverse
Turn on/off POWER Step through different
chapters of the disc
M& to step forward or
&m to step backward
If you have a DVD changer,
to skip disk
F1
Select a track directly 0-9, ENT
Play H Display the disc menu MENU
Stop x Display the Top menu TOP MENU
Pause X (press again to resume
normal playback)
Operate the DVD menu V v B b,
Watching the TV
47
KDF-E55/60A20
2-593-962-12(1)
Watching the TV
Operating a 5.1ch DVD AV System (Sony DAV)
Operating a DVD/VCR Combo Unit
Operating an AV Receiver
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the DVD
DVD/VCR
(FUNCTION)
Play H
Stop x
Turn on/off POWER Pause X
Select other equipment
connected to the DAV
F1 Search the picture forward or
backward
M or m during
playback
Skip a disc F2 Move highlight (cursor) V v B b
Display the Top menu TOP MENU Select item
Display the disc menu MENU Master Volume VOL+/–, MUTING
To Do This ... Press To Do This ... Press
Activate the remote control to
operate the DVD/VCR
DVD/VCR
(FUNCTION)
Pause X
Search the picture forward or
backward
M or m during
playback
Turn on/off POWER
If you have a DVD/VCR combo component, Replay
B
z
Select the DVD F1 Advance
z
b
Select the VCR F2 Move highlight (cursor)
and select (DVD)
V v B b
Display the Top menu TOP MENU Record (VCR) z
Display the disc menu MENU Change channels (VCR) CH +/– or 0-9, ENT
Play H (using tuner)
Stop x Adjust tracking (VCR) CH +/– (during tape
playback)
To Do This ... Press
Activate the remote control to
operate the AV Receiver
DVD/VCR
(FUNCTION)
Turn on/off POWER
Change the volume VOL +/–, MUTING
Select other equipment
connected to the AV Receiver
F1
Watching the TV
48
KDF-W55/60A20
2-593-962-12(1)
Watching the TV
Special Buttons on the Remote Control
This TV comes with convenient features that can be accessed directly by
pressing their buttons on your remote control.
Using the GUIDE
Button
This TV is equipped to show program information if it is available from the
station. The Program Guide lets you review program information, and select
both analog and digital channels.
To display the Program Guide:
1 Tune your TV to a channel by using the 0-9, , and ENT buttons.
2 Press GUIDE on the TV’s remote control. The Program Guide will
appear with the currently selected program showing in the background.
✍ Program information in the guide is provided by the broadcasters. As a
result, it may sometimes include only the channel number, without a
program title or description.
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
Time remaining: 1:26
FAM
TV-G
CC
1 ABC
10 DISC
23.1
FAM
36 TLC
65 HIST
68 SHOW
C23.1
Channel number,
call letters, etc.
Program title and
description,
program
duration, time
remaining, rating
information,
closed-caption
availability, etc.
Selectable
channel list.
Watching the TV
49
Watching the TV
KDF-W55/60A20
2-593-962-12(1)
Using the Program Guide
The Program Guide allows you to select the channels from a drop down list.
The Guide also provides information about the current program being shown
on each channel.
Using the Program Options Menu
The Program Options menu allows you to customize the program settings on
the currently tuned channel.
✍ Subchannels are additional channels of programming broadcast
simultaneously. For example, channel 4 might include three subchannels
(4.1, 4.2, 4.3) that are showing programs at the same time.
Option Description
Alternate
Video
(When
available)
Each program has a main video stream (the video that you see when
the channel is first tuned), and may have alternate video streams. This
option allows you to switch among these alternate video streams.
Alternate
Audio
(When
available)
Each program has a main audio stream (the audio you hear when the
channel is first tuned). This option allows you to switch among these
alternate audio streams (e.g., for different languages).
Main
Video 1
Video 2
Video 3
Make Way for Ducks!
Series follows the aquatic misadventures of Henry and Riley, two
wayward ducks on a unique mission.
Time remaining: 1:26
TV-G
CC
Alternate Video
Alternate Audio
FAM
C23.1
1 ABC
10 DISC
23.1
FAM
36 TLC
65 HIST
68 SHOW
Watching the TV
50
KDF-W55/60A20
2-593-962-12(1)
Using the WIDE
Button
Wide screen mode lets you watch 4:3 normal broadcasts in several wide
screen modes (16:9 aspect ratio).
Wide Zoom
Normal
Full
Zoom
Wide Zoom
Full
Zoom
16:9 Original source
(High definition)
4:3 Original source
(Standard definition)
✍ When the TV receives a 720p or 1080i signal, Normal cannot be
selected.
When the TV receives
a 720p or 1080i signal
that is in 4:3 aspect
ratio picture with a
black bar at each side,
Full returns the picture
to its original size.
You can also access
the Wide Mode settings
from the Screen menu.
For details, see page
62.
z
z
Changing the wide screen mode
4:3 Original source
This mode is not available
16:9 Original source
Wide Zoom
Full
Zoom
Normal
Standard definition High definition
Watching the TV
51
Watching the TV
KDF-W55/60A20
2-593-962-12(1)
Using the FREEZE
Button
The FREEZE button allows you to temporarily capture a program’s picture.
You can use this feature to write down information such as phone numbers,
recipes, etc.
To Freeze
To cancel FREEZE for normal viewing, press again.
Using the JUMP
Button
The JUMP button allows you to jump back and forth between the current
channel and the last channel that was selected.
FREEZE
FREEZE
J
U
M
P
J
U
M
P
52
KDF-E55/60A20
2-593-962-12(1)
Introducing WEGA GATE
Overview of WEGA GATE
A push of a button on your remote control provides a whole new experience
of TV viewing. It enables you to perform a variety of tasks intuitively with a
control panel on the screen rather than using complicated remote control
button presses.
When you press the button, you can select from basic TV function:
watching TV, selecting from Favorite Channels, viewing external equipment
signals or adjusting or adjusting TV settings.
1 Press on the remote.
WEGA GATE control panel appears.
2 Press V/v to highlight the item.
3 Press to select.
4 Press to exit.
WEGA
GATE
WEGA
GATE
TOP MENU MENU GUIDE SLEEP
F1
FUNCTION
F2
RETURN
WEGA
GATE
Press to exit
WEGA GATE
Favorites
Cable
Antenna
External Inputs
Settings
WEGA GATE
C
C
WEGA
GATE
Introducing WEGA GATE
53
Introducing WEGA GATE
KDF-E55/60A20
2-593-962-12(1)
The WEGA GATE screen gives you access to the following items:
Icon Description
Favorites
The Favorites feature lets you select programs from a list of
up to 16 favorite channels that you specify. For details, see
page 54.
Cable
The Cable feature takes you to the most recently viewed
channel on the cable input. When tuned to the channel, the
Program Banner and Channel number will be displayed.
Antenna
The Antenna feature takes you to the most recently viewed
channel on the antenna input. When tuned to the channel, the
Program Banner and Channel number will be displayed.
External Inputs
The External Inputs feature lets you select equipment that is
connected to your TV, such as a DVD player. You can assign
a label to the equipment. For details, see page 55.
Settings
The Settings feature lets you adjust the Video, Audio,
Screen, Channel, Parental Control, Setup and
Applications menus. For details, see page 55.
Introducing WEGA GATE
54
KDF-E55/60A20
2-593-962-12(1)
Using Favorites in WEGA GATE
The Favorites feature lets you select programs from a list of up to 16
favorite channels that you specify. You can create a list using the Add to
Favorites option.
1 Select Favorites from the WEGA GATE control panel and press .
The Favorite Channels list appears. Make your selection.
2Press M/m to highlight the desired channel and press .
• To add the current channel to the list of Favorite Channels, highlight
Add to Favorites and press .
• When the Favorite Channel list is full, select Edit Favorites to
remove a channel from the list or go to the Channel settings and
select Favorites Channels then edit the channel.
Using Cable in WEGA GATE
The Cable feature takes you to the most recently viewed channel on the cable
input. When tuned to the channel, the Program Banner and Channel number
will be displayed.
Select Cable from the WEGA GATE control panel and press
.
Favorite Channels
Add to Favorites
15
15.2 KPBS-DT
Edit Favorites
Exit
Regularly Scheduled Programming
No program information is available.
0:24 Remaining 480i 4:3
KNSD-WX
Unrated
C39.2
Introducing WEGA GATE
55
Introducing WEGA GATE
KDF-E55/60A20
2-593-962-12(1)
Using Antenna in WEGA GATE
The Antenna feature takes you to the most recently viewed channel on the
antenna input. When tuned to the channel, the Program Banner and Channel
number will be displayed.
Select Antenna from the WEGA GATE control panel and press
.
Using External Inputs in WEGA GATE
The External Inputs feature lets you view from a selected external input
connected to your TV. You can assign a label or skip over unused inputs by
selecting Edit Video Labels. Input label assignment can also be done by
going to Setup settings and select Label Video Inputs (see page 70).
1 Select External Inputs from the WEGA GATE control panel and press
.
The External Inputs list appears. Make your selection.
2Press M/m to highlight the desired external input and press .
Using Settings in WEGA GATE
The Settings feature lets you enter to the menu screen where most of
advanced settings and adjustments are performed (see page 56).
✍ If you have not completed the initial channel setup (see page 64) both
Cable and Antenna will tune to the lowest channel number. To run Auto
Program see page 64.
Full Focus
Sd Film Festivals Growth
0:29 Remaining 720p 16:9
KPBS-HD
Unrated
15.1
6:29PM
External Inputs
Exit
Video 1 VHS
Video 2
Video 3
Video 4
Video 5
Video 6
Edit Video Labels
56
KDF-E55/60A20
2-593-962-12(1)
Using the Settings
Overview
The Settings gives you access to the following features:
(Depending on the signal tuned, you may see a different Setting options on your
screen. Settings displayed here are with the 720p signal.)
Settings Allows you to set/change
Video Picture Mode (page 58)
Reset (page 58)
Picture (page 58)
Brightness (page 58)
Color (page 58)
Hue (page 58)
Color Temp. (page 58)
Sharpness (page 58)
Noise Reduction (page 59)
DRC Mode (page 59)
DRC Palette (page 59)
Advanced Video (page 59)
Audio Sound Mode (page 60)
Reset (page 60)
Tre bl e (page 60)
Midrange (page 60)
Bass (page 60)
Balance (page 60)
Steady Sound (page 60)
Volume Offset (page 60)
Effect (page 60)
BBE (page 61)
MTS (page 61)
Speaker (page 61)
Audio Out (page 61)
A/V Sync (page 61)
Screen Wide Mode (page 62)
Game Picture (page 62)
4:3 Default (page 63)
Display Area (page 63)
Vertical Center (page 63)
Ver tical Size (page 63)
Antenna
Video
Press WEGA GATE to exit
Picture Mode Vivid
Reset
Picture Max
Brightness 50
Color 55
Hue 0
Color Temp. Cool
Sharpness 40
Noise Reduction
On
Antenna
Audio
Press WEGA GATE to exit
Sound Mode Custom
Reset
Treble 0
Midrange 0
Bass 0
Balance 0
Steady Sound Off
Volume Offset 0
Effect Off
BBE Off
Antenna
Screen
Press WEGA GATE to exit
Wide Mode Full
Game Picture 0
4:3 Default Off
Display Area Normal
Vertical Center 0
Vertical Size 0
Using the Settings
57
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
Channel Favorite Channels (page 64)
Auto Program (page 64)
Digital Channels (page 64)
Show/Hide Channels (page 64)
Label Channels (page 65)
Parental Lock Parental Lock (page 66)
Change Password (page 67)
Select Country (page 67)
Setup Caption Vision (page 70)
Info Banner (page 70)
Label Video Inputs (page 70)
Language (page 71)
Menu Color (page 71)
Power Saving (page 71)
Image Shift (page 71)
High Altitude (page 71)
CineMotion (page 71)
Applications Clock/Timers (page 73)
Diagnostics (page 74)
CableCARD (page 74)
Settings Allows you to set/change
Antenna
Channel
Press WEGA GATE to exit
Auto Program
Digital Channels
Show/Hide Channels
Label Channels
Favorite Channels
Antenna
Parental Lock
Press WEGA GATE to exit
Password
Antenna
Setup
Press WEGA GATE to exit
Caption Vision On
Info Banner On
Label Video Inputs
Language English
Menu Color Gray
Power Saving Standard
Image Shift Auto
High Altitude Off
CineMotion Off
Antenna
Applications
Press WEGA GATE to exit
Clock/Timers
Diagnostics
CableCARD
Using the Settings
58
KDF-E55/60A20
2-593-962-12(1)
Accessing the Video Settings
Selecting Video
Options
The Video settings include the following options:
1. Press WEGA GATE.......
2.
Select Settings..............
3.
Highlight......................
4. Press to select...............
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Video, press .
W
E
G
A
G
A
T
E
Antenna
Video
Press WEGA GATE to exit
Picture Mode Vivid
Reset
Picture Max
Brightness 50
Color 55
Hue 0
Color Temp. Cool
Sharpness 40
Noise Reduction
On
WEGA
GATE
Option Description
Mode
Customized
viewing
Vivid Select for enhanced picture contrast and sharpness.
Standard Select for standard picture settings. Recommended
for home entertainment.
Custom Select to display a picture with minimum
enhancements.
✍
You can alter the Video settings (Picture, Brightness, Color,
etc.) for each Picture Mode and each video input.
✍
You may set up a Picture Mode (Vivid, Standard, Custom)
independently for each Video input (Video 1-Video 6,
including the Antenna input). Your Picture Mode settings
are automatically saved after each selection. This allows
you to customize the Picture Mode setting for each type of
signal source.
Reset Select OK to reset all settings and adjustments to the default setting
for each Picture Mode (Vivid, Standard, Custom) (except for the
options grayed out).
Picture Adjust to increase picture contrast and deepen the color or decrease
picture contrast and soften the color.
Brightness Adjust to brighten or darken the picture.
Color Adjust to increase or decrease color intensity.
Hue Adjust to increase or decrease the green tones.
Color Temp.
White
intensity
adjustment
Choose from three color temperatures:
Cool Select to give the white colors a blue tint.
Neutral Select to give the white colors a neutral tint.
Warm When selected Custom in Picture Mode, select to
give the white colors a red tint.
To quickly and easily
change from one
Picture Mode to
another, use PICTURE
on the remote control.
z
Using the Settings
59
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
Sharpness Adjust to sharpen or soften the picture.
Noise
Reduction
On Select to reduce the noise level of signal from
connected equipment and from the VHF/UHF jack.
Off Select to turn off Noise Reduction.
DRC Mode High
Density
Creates a high-resolution picture with 4 x density, for
high quality sources (i.e., DVD player, satellite
receiver).
Progressive
Recommended for moving pictures.
✍ DRC Mode is not available when using the Freeze feature;
also not available when watching 480p, 720p or 1080i
sources.
DRC Palette
Custom
Allows you to customize the level of detail (Reality)
and smoothness (Clarity) for up to three input
sources. For example, you can create one Custom
setting to optimize your cable input's picture, and
create another to optimize your DVD player's picture.
You can switch among the three Custom settings.
1 Press the arrow buttons to highlight Custom
then press
.
The DRC palette appears.
2 Press the arrow buttons to adjust the position of
the marker (z). As you move the z higher
along the Reality axis, the picture becomes more
detailed. As you move the z to the right along
the Clarity axis, the picture becomes smoother.
3 To save the setting, press .
✍ DRC Palette is not available when using the Freeze
feature; also not available when watching 480p, 720p or
1080i sources.
Advanced
Video
Available in
“Custom
Mode”
Program Select Program to choose among the options:
Gamma (High/Medium/Low/Off ), Clear White (On/
Off), Color Corrector (High/Low/Off ).
Select Black Corrector to enhance the black colors to
give the picture strong contrast (High/Medium) or
lesser contrast (Low/Off).
Option Description
Custom
Press
Reality
(25)
Clarity
(1)
to exit
Using the Settings
60
KDF-E55/60A20
2-593-962-12(1)
Accessing the Audio Settings
Selecting Audio
Options
The Audio settings include the following options:
1. Press WEGA GATE........
2. Select Settings...............
3. Highlight........................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Audio, press .
W
E
G
A
G
A
T
E
Antenna
Audio
Press WEGA GATE to exit
Sound Mode Custom
Reset
Treble 0
Midrange 0
Bass 0
Balance 0
Steady Sound Off
Volume Offset 0
Effect Off
BBE Off
WEGA
GATE
Option Description
Sound
Mode
Dynamic Select to enhance treble and bass.
Standard Suitable for spoken dialogue.
Custom Flat setting.
Reset Select OK to reset all settings and adjustments to the default setting
for each Sound Mode (Dynamic, Standard, Custom) (except for the
options grayed out).
Treble Adjust to increase or decrease higher-pitched sounds.
Midrange Adjust to increase or decrease the sounds between the Treble and
Bass.
Bass Adjust to increase or decrease lower-pitched sounds.
Balance Adjust to emphasize left or right speaker balance.
Steady
Sound
On Select to stabilize the volume across all programs
and commercials.
Off Select to turn off Steady Sound.
Volume
Offset
Adjust to increase or decrease the sound level of the current input
(TV or video input) relative to other inputs.
Effect TruSurround
XT
Select for surround sound (for stereo programs
only).
Simulated Adds a surround-like effect to mono programs.
Off Normal stereo or mono reception.
TruSurround XT
attempts to create the
same surround effect
produced by a
multichannel system
using the left and right
speakers.
z
Using the Settings
61
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
BBE On Select to give sound more impact by compensating
for phase effects in speakers.
Off Select for normal stereo or mono reception.
MTS
Enjoy stereo,
bilingual and
mono
programs
Stereo Select for stereo reception when viewing a program
broadcast in stereo.
Auto SAP Select to automatically switch to second audio
programs when a signal is received. (If no SAP
signal is present, the TV remains in Stereo mode.)
Mono Select for mono reception. (Use to reduce noise
during weak stereo broadcasts.)
✍ MTS is available only for analog programs.
Speaker On Select to turn on the TV speakers.
Off Select to turn off the TV speakers and listen to the
TV’s sound only through your external audio
system speakers.
✍ The MUTING button on your remote control becomes
nonfunctional when the Speaker is set to Off.
Audio Out This option can be set only when the Speaker option is set to Off.
Easy control
of volume
adjustments
Var iable The TV's speakers are turned off, but the audio
output from your audio system can still be
controlled by the TV's remote control.
Fixed The TV’s speakers are turned off and the audio
output of the TV is fixed. Use your audio receiver’s
volume control to adjust the volume (and other
settings) through your audio system.
A/V Sync Off/1/2/3 Use this option to make adjustments to audio and
video synchronization when you have external
equipment connected to DIGITAL AUDIO
(OPTICAL )OUT of the TV. Select Off (factory
default setting) to make no adjustments. Select 1, 2
or 3 to adjust so that the video and audio from your
connected external equipment are synchronized.
Option Description
Using the Settings
62
KDF-E55/60A20
2-593-962-12(1)
Accessing the Screen Settings
Selecting Screen
Options
The Screen settings include the following options:
1. Press WEGA GATE........
2. Select Settings...............
3. Highlight.......................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Screen, press .
W
E
G
A
G
A
T
E
Antenna
Screen
Press WEGA GATE to exit
Wide Mode Full
Game Picture 0
4:3 Default Off
Display Area Normal
Vertical Center 0
Vertical Size 0
WEGA
GATE
Option Description
Wide Mode
Select a screen
mode to use for
4:3 sources.
Wide Zoom Select to enlarge the 4:3 picture, to fill the 16:9
screen, keeping the original image as much as
possible.
Normal Select to return the 4:3 picture to its original
size and aspect ratio.
✍ Normal is not available when watching 720p or 1080i
sources.
Full Select to enlarge the 4:3 picture horizontally
only, to fill the wide screen.
Zoom Select to proportionally enlarge 1080i and
720p sources. For 480p and 480i sources,
Zoom will vertically stretch the image to fill
the screen.
✍ To change from one Wide Mode setting to another, use WIDE button
on the remote control (see page 50).
Game Picture Allows you to move the position of the picture left and right in
the window. (This feature also allows you to adjust the picture
from any connected equipment.) Select while watching the
picture to be adjusted. The TV stores the position in memory
for each input. Press
B or b and press to choose a
correction between
+5 and –5.
✍ Not available in Full and Normal mode when sources are in
720p or 1080i.
Wide Mode is
unavailable while in
Freeze (page 51).
z
Using the Settings
63
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
4:3 Default
Select the default
screen mode to
use for 4:3
sources.
Wide Zoom Select to enlarge the 4:3 picture, to fill the 16:9
screen, keeping the original image as much as
possible.
Normal Select to return the 4:3 picture to normal
mode.
Full Select to enlarge the 4:3 picture horizontally
only, to fill the wide screen.
Zoom Select to enlarge the 4:3 picture horizontally
and vertically to an equal aspect ratio that fills
the wide screen.
Off Select to continue using the current screen
mode setting when the channel or input is
changed.
Display Area Select Normal to return to the default Display Area. Select –1
or –2 to keep the edge of the picture out of screen.
Vertical Center Adjust Allows you to move the position of the picture
up and down in the window. (Available only in
Wide Zoom and Zoom modes.)
Press V or v and press
to choose a
correction between +5 and –5.
Vertical Size Adjust Allows you to adjust the vertical size of the
picture. (Available only in Wide Zoom and
Zoom modes.)
Press V or v and press
to choose a
correction between +5 and –5.
Option Description
If 4:3 Default is set to
anything but Off, the
Wide Mode setting
changes only for the
current channel. When
you change channels
(or inputs), Wide Mode
is automatically
replaced with the 4:3
Default setting. To
retain the current Wide
Mode setting as
channels and inputs
are changed, set 4:3
Default to Off.
z
Using the Settings
64
KDF-E55/60A20
2-593-962-12(1)
Accessing the Channel Settings
Selecting Channel
Options
The Channel settings include the following options:
1. Press WEGA GATE........
2. Select Settings...............
3. Highlight.......................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Channel, press .
W
E
G
A
G
A
T
E
Antenna
Channel
Press WEGA GATE to exit
Auto Program
Digital Channels
Show/Hide Channels
Label Channels
Favorite Channels
WEGA
GATE
Option Description
Favorite
Channels
Lets you set up a list of your favorite channels. For details, see
“Using Favorites in WEGA GATE” on page 54.
Digital Channels Add Select to add digital channels.
Auto Program Automatically sets up the channel list on the TV for all
receivable channels for the current input (VHF/UHF or
CABLE). Select to start the Auto Program.
✍ Auto Program may take up to 20 to 50 minutes to
complete. A progress bar will display the approximate
progress of the Auto Program and Digital Channels/
Add sequences.
Show/Hide
Channels
Allows you to show or hide channels that appear in the Program
Guide (page 48) and when you use the CH+/- buttons to channel
surf. Channels that are set to Hidden do not appear in the
Program Guide or when you use the CH+/- buttons.
1 Press V or v to highlight the channel that you want to show
or hide.
To move between the Major and Digital subchannel lists,
press B or b.
2 To change a channel’s setting to Shown or Hidden, press
.
3 To show or hide more channels, repeat steps 1 and 2.
Channels that you set
to Hidden can only be
accessed with the 0-9
buttons.
z
Using the Settings
65
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
✍ If you select to hide or show a major digital channel, all the sub-channels
are automatically hidden or shown. To show or hide an individual sub-
channel within a digital channel, you must individually select that sub-
channel to show or hide.
✍ If you hide all sub-channels of a major digital channel, that digital
channel is automatically set to Hidden.
Label Channels Allows you to assign labels (such as station call letters) to
channel numbers.
1 Press V or v to scroll through the channel numbers. Then
press
to select the channel number that you want to
assign a label.
2 Press V or v to scroll through the label characters (A-Z, 0-
9, etc.). Then press
to select the highlighted character.
Repeat to add characters to the label.
3 Press B to return to the Channel menu, or press WEGA
GATE to exit the menus.
Option Description
Using the Settings
66
KDF-E55/60A20
2-593-962-12(1)
Accessing the Parental Lock Settings
Selecting Parental
Lock Options
The Parental Lock settings include the following options:
1. Press WEGA GATE........
2. Select Settings..............
3. Highlight.......................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Parental Lock, press .
W
E
G
A
G
A
T
E
Antenna
Parental Lock
Press WEGA GATE to exit
Password
WEGA
GATE
✍ You need your password for any future access into the Parental Lock
menu. If you lose your password, see “Lost password” on page 83.
Option Description
Parental Lock
Turn ratings on/off and
select a rating system
Off Turn Parental Lock off. No programs are
blocked from viewing.
Child Maximum ratings permitted are:
US: TV-Y, TV-G, G
Canada: C, G, TV-Y
Yo u th Maximum ratings permitted are:
US: TV-PG, PG
Canada: C8+, PG, 8 ans+, TV-PG
Y. Adult Maximum ratings permitted are:
US: TV-14, PG-13
Canada: 14+, 13 ans+, TV-14
Custom Select to set ratings manually.
US: See page 68 for details.
Canada: See page 69 for details.
Using the Settings
67
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
To deactivate the parental control feature
❑
Set Parental Lock to OFF when in the Parent menu.
To change the password
1 In the Parent menu, use the arrow buttons to highlight Change
Password
, and press to select it.
2 Enter a new four-digit password using the 0-9 buttons.
3 Confirm the new password by entering it again.
4 Press WEGA GATE to exit the menu screen.
Viewing Blocked
Programs
You can view a blocked program by entering the password.
1 Press ENT when tuned to a blocked program.
2 Enter your password using the 0-9 buttons.
Parental Lock will be canceled temporarily until you turn your TV off.
Change Password Select to change your password.
Select Country U.S.A. Select to use U.S.A. ratings (see page 68).
Canada Select to use Canadian ratings (see page 69).
Option Description
If you are not familiar
with the Parental
Guideline rating
system, you should
select Child, Yo u t h , or
Y. A d u l t to help simplify
the rating selection. To
set more restrictive
ratings, select Custom.
For descriptions of
Child, Yo u t h, and
Y. A d u l t ratings, see
page 66.
z
z
(Continued)
Using the Settings
68
KDF-E55/60A20
2-593-962-12(1)
Selecting Custom
Rating Options
US custom rating options
If you selected U.S.A. as the country of residence on page 67, the Custom
Rating menu includes the following options. (If you selected Canada, see
page 69.)
Option Description
Movie Rating G All children and general audiences.
PG Parental guidance suggested.
PG-13 Parental guidance for children under 13.
R Restricted viewing, parental guidance is suggested
for children under 17.
NC-17
and X
No one 17 and under.
TV Rating
Block programs
by their rating,
content or both
Age-Based Options
TV-Y All children.
TV-Y7 Directed to children age 7 and older.
TV-G General audience.
TV-PG Parental guidance suggested.
TV-14 Parents strongly cautioned.
TV-MA Mature audience only.
Content-Based Options
FV Fantasy violence.
D Suggestive dialog.
L Strong language.
S Sexual situations.
V Violence.
Unrated
Block programs
or movies that are
broadcast without
a rating
Allow Allows programs and movies that are broadcast
without a rating.
Block Blocks all programs and movies that are broadcast
without a rating.
✍ The content ratings will increase depending on the level of the age-based rating.
For example, a program with a
TV-PG V (Violence) rating may contain
moderate violence, while a
TV-14 V (Violence) rating may contain more intense
violence.
To ensure maximum
blocking capability, the
age-based ratings
should be blocked.
z
If you select Block, be
aware that the following
programs may be
blocked: news, sports,
weather, emergency
broadcasts, political
programs, public
service
announcements, and
religious programs.
z
Using the Settings
69
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
Canadian custom rating options
If you selected Canada as the country of residence on page 67, the Custom
Rating menu includes the following options. (If you selected U.S.A., see
page 68.)
Option Description
English Rating C All children.
C8+ Children 8 years and older.
G General programming.
PG Parental guidance.
14+ Viewers 14 and older.
18+ Adult programming.
French Rating G General programming.
8 ans+ Not recommended for ages under 8.
13 ans+ Not recommended for ages under 13.
16 ans+ Not recommended for ages under 16.
18 ans+ Programming restricted to adults.
U.S.A. Rating See “TV Rating” on page 68 for details.
Using the Settings
70
KDF-E55/60A20
2-593-962-12(1)
Accessing the Setup Settings
Selecting
Setup Options
The Setup settings include the following options:
1. Press WEGA GATE........
2. Select Settings..............
3. Highlight.......................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Setup, press .
W
E
G
A
G
A
T
E
Antenna
Setup
Press WEGA GATE to exit
Caption Vision On
Info Banner On
Label Video Inputs
Language English
Menu Color Gray
Power Saving Standard
Image Shift Auto
High Altitude Off
CineMotion Off
WEGA
GATE
Option Description
Caption Vision Allows you to select from four closed caption modes (for
programs that are broadcast with closed captioning).
On Caption Vision is turned on.
Off Caption Vision is turned off.
Program Allows you to set basic and advanced
Caption Vision options. See
“Programming Caption Vision” on
page 72.
Info Banner Set to On or Off. Select On to display the program name, time
remaining and other information (if the broadcaster offers this
service). Also displays when the channel is changed or the
DISPLAY button is pressed.
Label Video
Inputs
Allows you to label the audio/video equipment you have
connected to the TV so you can identify them when using TV/
VIDEO. When in this menu:
1
Press V or v to highlight an input to label, then
press to select it.
2 Use the arrow buttons to scroll through the labels.
3 Press to select the equipment you connected to
each of the input jacks on the back of your TV.
Select Skip if you do not have any equipment
connected to a particular input.
Using the Settings
71
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
Video 1-6 VHS, DVD, Receiver, Satellite,
Cable Box, 8mm, DTV, Game,
LD, Beta, HD, DVR, Camcorder,
Skip
✍ If you select Skip, your TV skips the selected
connection when you press TV/VIDEO.
Language Select to display all on-screen menus in your language of
choice: English, Español, Français.
Menu Color Enables you to select a specific color for the on-screen menus.
Power Saving Standard Select to view picture without the
benefit of Power Saving.
Reduced Select to view picture with reduced
poser consumption. The picture
becomes darker, but also enhances the
black level.
Image Shift Corrects the image on your TV.
Before adjusting After adjusting
Auto (Factory setting) Automatically
corrects double images.
Level 1-4 Select a level from 1-4 to align the
images and improve the picture.
High Altitude Select On to use the TV at an altitude of 5,000 feet (1,500 m) or
higher. Select Off to use the TV at normal altitude.
CineMotion Select On to optimize the screen display automatically
detecting film content and applying a reverse 3-2 pulldown
process. Moving picture will appear clearer and more natural
looking. Select Off will disabling the detection.
Option Description
Setup
Press WEGA GATE to exit
Antenna
Off
On
English
Gray
Auto
Auto
Off
Off
Caption Vision
High Altutude
CineMotion
Antenna
Antenna
Antenna
Setup
S
etu
p
Setup
Press WEGA GATE to exit
Press WEGA GATE to exiPress WEGA GATE to exit
Info Banner
Label Video Inputs
Language
Menu Color
Power Saving
Image Shift
Caption Vision
C
a
p
tion Visio
n
Caption Vision
Off
OfOf
Info Banner
Info Banne
Info Banne
On
On
On
Label Video Inputs
L
abel V
i
deo In
p
ut
s
Label Video Inputs
Language
L
an
g
ua
ge
Language
English
E
n
g
l
i
s
h
English
Menu Color
Menu Color
Menu Colo
Gray
G
ra
y
Gray
Power Saving
P
ower Savin
g
Power Saving
Auto
Auto
Auto
Image Shift
Ima
g
e Shi
fImage Shif
Auto
AutoAuto
High Altitude
H
i
g
h Altutu
d
High Altutud
Off
Of
Of
CineMotion
CineMotion
CineMotion
Off
Of
Of
Antenna
Setup
Press WEGA GATE to exit
Caption Vision On
Info Banner On
Label Video Inputs
Language English
Menu Color Gray
Power Saving Standard
Image Shift Auto
High Altitude Off
CineMotion Off
(Continued)
Using the Settings
72
KDF-E55/60A20
2-593-962-12(1)
Programming
Caption Vision
If you selected the Program option under Caption Vision (see page 70), you
can change the following settings:
Option Description
Basic Allows you to select basic analog (EIA-608) closed caption options.
CC1, CC2,
CC3, CC4
Displays a printed version of the dialog or sound
effects of a program. (Should be set to CC1 for most
programs.)
Text 1 ,
Text 2 ,
Text 3 , Tex t 4
Displays network/station information presented using
either half or the whole screen (if available).
Advanced Allows you to select advanced digital (EIA-708) closed caption
options. Select from the available options.
Digital CC Allows you to set digital closed captioning to Basic (digital EIA-608)
or Advanced (digital EIA-708).
Advanced
Settings
Allows you to make additional settings for digital (EIA-708) closed
caption options.
As Broadcast
Small Text
Large Text
Custom... Allows you to customize the following settings:
Character Size Small, Standard,
Large
Character Style Style 1-7
Character Color Color 1-8
Character Opacity Solid,
Translucent
Edge Color Color 1-8
Edge Type None, Raised,
Depressed,
Outline, Left
shadow, Right
shadow
Background Color Color 1-8
Background Opacity Solid,
Translucent
Window Color None,
Color 1-8
Window Opacity Solid,
Translucent
Using the Settings
73
Using the Settings
KDF-E55/60A20
2-593-962-12(1)
Accessing the Applications Settings
Selecting
Applications
Options
The Applications settings include the following options:
1. Press WEGA GATE........
2. Select Settings...............
3. Highlight........................
4.Press to select................
To highlight an option and to change settings, press V v B b.
Press
to confirm the selection.
To exit the Applications, press .
W
E
G
A
G
A
T
E
Antenna
Applications
Press WEGA GATE to exit
Clock/Timers
Diagnostics
CableCARD
WEGA
GATE
Option Description
Clock/Timers Select to set the clock and to program your TV to turn on and
off at two scheduled viewing times.
Sleep Allows you to select the amount of
time (Off, 15 minutes, 30 minutes,
45 minutes, 60 minutes or 90
minutes) that you want the TV to
remain on before shutting off
automatically.
Timer 1
Timer 2
You can use the Timers to program the
TV to turn on and off and tune to a
specific channel at two scheduled
viewing times.
Timer 1 and Timer 2 cannot be set until you set the Current
Time.
1 Press V or v to highlight Timer 1 or Timer 2. To set the
timer, press b.
✍ To go directly to programming Timer 1 or 2, press
instead of pressing b.
(Continued)
Using the Settings
74
KDF-E55/60A20
2-593-962-12(1)
2 Press V or v to highlight one of the following options, then
press
.
Program Select to set the Timer by day, time,
duration, and channel.
Off Select to turn off the Timer. (Your
previous settings are saved.)
3 If you selected Program in step 2, press V and v to set the
day(s), hour, minute, duration, and channel number. Press
or press b to confirm each setting and move to the next
setting.
Press B to go back to the previous setting.
4 Press WEGA GATE to exit the menu screen. An LED on
the front panel will light, indicating the Timer has been set.
Current Time You can set the current time.
1 Press
to select Current Time.
2 Press V and v to set the current time (day, hour, minute,
and AM/PM). Press
(or press b) to confirm each
setting and move to the next setting. Press B to go back the
previous setting.
3 Press WEGA GATE to exit the menu screen.
Diagnostics Display diagnostics information about the TV. This can be
useful in providing information to an authorized technician or
repair person.
CableCARD This list of selectable CableCARD options will vary, depending
on your cable service provider.
Option Description
75
KDF-E55/60A20
2-593-962-12(1)
Other Information
Overview
This chapter includes the following topics:
Contacting Sony
If, after reading these operating instructions, you have additional questions
related to the use of your Sony television, please call our Customer
Information Services Center.
For US residents: 1-800-222-SONY (7669)
or visit: http://www.sony.com/TVsupport
For Canadian residents: 1-877-899-SONY (7669)
or visit: http://www.sony.com/TVsupport
Before calling Sony customer support, please write down the model and
serial numbers of your TV. You’ll find this information on the front cover of
this manual.
Topic Page
Contacting Sony 75
Replacing the Lamp 76
Troubleshooting 80
Specifications 84
Optional Accessories 85
Index 87
Other Information
76
KDF-E55/60A20
2-593-962-12(1)
Replacing the Lamp
The projection lamp, which illuminates the picture, has a limited life.
If the screen becomes dark, the color looks unusual, or the LAMP indicator
on the front of the TV flashes, it is time to replace the lamp with a new one
(not supplied).
❑ Use a Sony XL-2200 replacement lamp (not supplied) for replacement.
Use of any other lamp may damage the TV.
❑ Do not remove the lamp for any purpose other than replacement. Doing
so may cause injury or fire.
❑ Do not put flammable materials and metal objects inside the lamp
receptacle of the TV after removing the lamp. Doing so may cause fire
or electrical shock. Do not touch the lamp receptable once the lamp has
been removed.
❑ When the lamp eventually burns out, you may hear a noticeable pop
sound. This is normal and it is inherent to this type of lamp.
❑ In rare instances, the bulb may pop inside the lamp unit, but the lamp
unit is designed to contain all of broken glass pieces inside the lamp
unit.
❑ The lamps contain mercury, for proper disposal of the used lamps follow
and observe the local ordinances. See page 79.
How to Replace
the Lamp
1 Turn off the power on the main unit. Wait several minutes, then unplug
the power cord.
(The cooling fan will continue to operate for about two minutes after
turning the power off.)
2 Wait at least 30 minutes after unplugging the power cord to allow the
lamp to cool down before replacing it. To avoid being burned, do not
touch the lamp receptable once the lamp has been removed.
3 Take the new lamp out of the box.
Do not touch the glass portion of the new lamp.
WARNING
Electric appliances can cause fire or high temperature, resulting in injury
or death. Be sure to follow the instructions below.
✍ Do not shake the lamp. Vibration can damage the lamp or shorten
its life.
✍ Avoid touching the front glass of a new lamp or the glass of the
lamp receptacle. This may reduce picture quality or lamp life.
Other Information
77
Other Information
KDF-E55/60A20
2-593-962-12(1)
4 Loosen the screws on the rear side panel.
5 Remove the front panel.
6 Pull out the lamp.
Loosen the right screw on the cover with a coin or similar object.
Remove the screw from the lamp cover. Pull down the cover toward you.
Unscrew the lamp and pull out the lamp horizontally.
ST
D
/DUO
P
O
W
ER
PR
O
(Continued)
Other Information
78
KDF-E55/60A20
2-593-962-12(1)
7 Place the new lamp into its place, then tighten the screw.
Mount the new lamp securely. Failure to mount correctly may cause a
fire or the screen to go dark.
Push the cover back on. Make sure that the hole on the cover aligns with
the hole on the unit. Reattach the lamp cover by tightening the screw.
8 Reattach the front panel securely.
✍ The lamp is very hot immediately after use. Never touch the glass
portion of the lamp or the surrounding parts.
✍ After it has cooled, place the used lamp into the empty box of the
replacement lamp. Never put the used lamp into a plastic bag.
✍ If the lamp cover screw is inserted incorrectly, the lamp may not
operate properly. In such a case, remove the screw, insert it
correctly and then tighten the screw completely (see “Indicators” on
page 11).
✍ If the lamp cover is not reattached securely, the self-diagnostic
function may be triggered and the POWER indicator flashes three
times (see page 11).
STD/DUO
POWER
PR
O
Other Information
79
Other Information
KDF-E55/60A20
2-593-962-12(1)
9 Tightly screw the side panel in its place.
The used lamp
For customers in the United States:
This product contains mercury. Disposal of this product may be regulated if
sold in the United States. For disposal or recycling information, please
contact your local authorities or the Electronics Industries Alliance
(http://www.eiae.org).
❑ Do not leave the used lamp near flammable materials or within the reach
of children.
❑ Do not pour water onto the used lamp or put any object inside the lamp.
Doing so may cause the lamp to burst.
✍ Consult your Sony dealer for a Sony XL-2200 replacement lamp.
✍ Take great care when replacing the lamp or plugging in/unplugging
the connecting cords. Rough handling may cause the TV to fall,
damaging the TV, the TV stand and/or the floor.
For replacement lamp information visit:
U.S. residents: http://www.sonystyle.com/tv/
Canadian residents: http://www.sonystyle.ca/tv/
Other Information
80
KDF-E55/60A20
2-593-962-12(1)
Troubleshooting
Remote Control
CableCARD Device
Problem Possible Remedies
Remote control does not
operate
❏ The batteries could be weak. Replace the batteries.
❏ Check the orientation of the batteries.
❏ Press TV (FUNCTION) once, and the TV indicator lights up. You may have
inadvertently pressed SAT/CABLE (FUNCTION), which changes the remote
control to SAT or CABLE mode.
❏ Make sure this unit’s power cord is connected securely to the wall outlet.
❏ Locate the unit at least 3-4 feet away from fluorescent lights.
Cannot change channels with
the remote control
❏ If you are using the TV to change channels, first press TV (FUNCTION) once,
and the TV indicator lights up.
❏ If you are using another device to change channels, be sure you have not
inadvertently switched your TV from the channel 3 or 4 setting.
❏ If you are using another device to change channels, be sure to press FUNCTION
for that device. For example, if you are using your cable box to change channels,
be sure to press SAT/CABLE (FUNCTION) once, and the SAT/CABLE indicator
lights up.
Remote control does not
operate non-Sony video
equipment
❏ If you replaced the batteries to the remote recently, the code numbers for the video
equipment may need to be reset.
❏ There may be more than one code for the equipment that you are attempting to
operate.
❏ There is a possibility that some non-Sony equipment cannot be operated by your
Sony TV remote. You may need to use the equipment’s original remote control.
Problem Possible Remedies
Problems using CableCARD
device or CableCARD services
❏ Check that the CableCARD device is inserted properly (see pages 25-26).
❏ The CableCARD device must be activated by your local cable TV provider before
you can receive digital cable TV services. See the activation instructions on pages
25-26.
❏ Check the Diagnostics and CableCARD menu options (see page 74). (This can
be useful in providing information to an authorized technician or repair person.)
❏ Contact your cable TV provider.
Other Information
81
Other Information
KDF-E55/60A20
2-593-962-12(1)
Video
Problem Possible Remedies
No picture (screen not lit), no
sound
❏ If your TV does not turn on, and a red light keeps flashing, your TV may need
service. Call your local Sony Service Center.
❏ Make sure the power cord is plugged in.
❏ Press POWER on the front of the TV.
❏ Press TV/VIDEO to cycle through the connected video sources.
❏ Try another channel; it could be station trouble.
Dark, poor or no picture
(screen lit), good sound
❏ Adjust the Picture option in the Video menu (see page 58).
❏ Adjust the Brightness option in the Video menu (see page 58).
❏ Check the antenna/cable connections.
No color/dark picture/color is
not correct
❏ Adjust the Color option in the Video menu (see page 58).
Only snow and noise appear on
the screen
❏ Check the antenna/cable connections.
❏ Try another channel; it could be station trouble.
❏ Press ANT to change the input mode (see page 42).
Dotted lines or stripes ❏ Adjust the antenna.
❏ Move the TV away from noise sources such as cars, neon signs, or hair-dryers.
Double images ❏ Using a highly directional outdoor antenna or a cable may solve the problem.
❏ Set the Image Shift to an appropriate value. The default setting is Auto. If
doubled images appear with Auto, select the best value from 1 to 4 (see page 71).
“Black box” on screen ❏ You have selected a text option in the Setup menu and no text is available. (See
page 70 to reset Setup selections.) To turn off this feature, set the Caption Vision
option to Off. If you were trying to select closed captioning, select CC1 instead of
Tex t 1 - 4.
Black bands appear at the top
and bottom of the screen
❏ Some wide-screen programs are filmed in aspect ratios that are greater than 16:9
(this is especially common with theatrical releases). Your TV will show these
programs with black bands at the top and bottom of the screen. For more details,
check the documentation that came with your DVD (or contact your program
provider).
Certain programs on DVD or
other digital sources display a
loss of detail, especially during
fast-motion or dark scenes
❏ The compression used by certain digital broadcasts and DVDs may cause your
TV’s screen to display less detail than usual, or cause artifacts (small blocks or
dots, pixelations) to appear on your screen. This is due to your TV’s large screen
and ability to show very fine detail, and is normal for certain digitally recorded
programs. Adjust the reality/clarity in the DRC Palette menu (see page 59) to
optimize the picture while viewing these sources.
Other Information
82
KDF-E55/60A20
2-593-962-12(1)
Audio
Channels
Problem Possible Remedies
Good picture, no sound ❏ Press MUTING so that Muting disappears from the screen (see page 42).
❏ Make sure the Speaker option is set to On in the Audio menu (see page 61).
❏ Make sure the MTS option is set to Stereo or Mono (see page 61).
Audio noise ❏ Communication problems may occur if infrared communication equipment (e.g.,
infrared cordless headphones) is used near the TV. Please use headphones other
than infrared cordless headphones. Also, if you use infrared communication
equipment other than infrared cordless headphones, move the infrared transceiver
away from the TV until the noise is eliminated, or move the transmitter and
receiver of the infrared communication equipment closer together.
Cannot gain enough volume
when using a cable box
❏ Increase the volume of the cable box using the cable box’s remote control. Then
press FUNCTION once, and the TV indicator lights up and adjust the TV’s
volume.
Sound seems weak or
insufficient
❏ The TV’s audio might be set to Auto SAP or Mono, when it might be better set to
Stereo. In the Audio menu (see page 61), set the MTS setting to Stereo. If
already set to Stereo, switch to Mono (which may reduce background noise
during weak stereo broadcasts).
Cannot raise the volume on
external speakers
❏ If the Speaker option is set to Off and the Audio Out option is set to Fixed (in
order to output the sound to your audio system) use your audio receiver to adjust
the sound (see page 61). Or, to use the TV remote control, set the Audio Out
option to Variable.
❏ To turn on the TV speakers, set the Speaker option to On (see page 61).
Problem Possible Remedies
Cannot receive upper channels
(UHF) when using an antenna
❏ Press ANT to select the VHF/UHF input (see page 42).
❏ Use Auto Program in the Channel menu to add receivable channels that are not
presently in the TV’s memory (see page 64).
Cannot receive any channels
when using cable TV
❏ Use Auto Program in the Channel menu to add receivable channels that are not
presently in the TV’s memory (see page 64).
❏ Press ANT to select the CABLE input (see page 42).
Cannot receive or select
channels
❏ Use Auto Program in the Channel menu to add receivable TV channels that are
not presently in TV memory (see page 64).
Some digital cable channels are
not being displayed
❏ Certain cable companies have limitations on the broadcast of digital cable
channels. Check with your cable company for more information.
❏ The digital cable channel may be set to Hidden in the Channel settings menu (see
page 64).
Other Information
83
Other Information
KDF-E55/60A20
2-593-962-12(1)
General
Problem Possible Remedies
How to restore the TV to
factory settings
❏ Turn on the TV. While holding down the V button on the remote control, press the
POWER button on the TV. (The TV will turn iteself off, then back on again.)
Release V button.
WARNING: The Factory Reset will clear all of your customized settings
including Parental Lock setting.
How to restore Video settings
to factory settings
❏ Select RESET menu option while in the Video menu (see page 58).
How to restore Audio settings
to factory settings
❏ Press RESET menu option while in the Audio menu (see page 60).
Cannot cycle through the other
video equipment connected to
the TV
❏ Be sure the Label Video Inputs option is not set to Skip (see page 70).
Cannot operate Menu ❏ If a menu option appears in gray, this indicates that the menu option is not
available.
Lost password ❏ In the password screen (see page 66), enter the following master password: 4357.
The master password clears your previous password; it cannot be used to
temporarily unblock channels.
TIMER is set ❏ The LED will remain lit even when the TV is turned off. To rest the timer or
cancel the timer, see page 73. If the LED (red) blinks continuously, this may
indicate the TV needs service.
Digital cable box does not work ❏ If you are connecting a VCR and digital cable box using a splitter, as described on
page 34, you must use a special bi-directional splitter that is designed to work
with your digital cable box. Contact your cable provider for details.
Cannot record digital channels
to VCR
❏ Only analog channels can be recorded to your VCR.
The replacement lamp does not
light up
❏ The screw of the lamp cover may be slanted. Take out the screw, insert it straight
into the screw hole, and then tighten it completely (see page 76 for both
KDF-E55A20 and KDF-E60A20).
TV cabinet creaks ❏ When the TV is in use, there is a natural rise in temperature, causing the cabinet to
expand or contract and may be accompanied by a slight creaking noise. This is not
a malfunction.
Image left on the screen (image
retention)
❏ Turn off the TV for a while or let the TV run on another channel. Unlike plasma
TV and CRT TV, image retention on this TV is not permanent
. It is only a
temporary condition, see page 10.
Other Information
84
KDF-E55/60A20
2-593-962-12(1)
Specifications
Projection System 3 LCD Panels, 1 lens projection system
LCD Panel 0.87 inch TFT LCD panel Approx. 3.28 million dots (1,042,168 pixels)
Projection Lens High Performance, large diameter hybrid lens F2.4
Antenna 75 ohm external terminal for VHF/UHF
Lamp 132W, XL-2200
Television System NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC compliant 8VSB
QAM on cable ANSI/SCTE 07 2000
Visible Screen Size
(Picture measured diagonally)
KDF-E55A20: 55 inches
KDF-E60A20: 60 inches
Channel Coverage Terrestrial (analog) 2-69
Cable TV (analog) 1-125
Terrestrial (digital) 2-69
Cable TV (digital) 1-135
Power Requirements 120V, 60 Hz
Number of Inputs/Outputs
HDMI IN Video 1080i, 720p, 480p, 480i
Audio Two channel linear PCM 32, 44.1 and 48 kHz,
16, 20 and 24 bit
Video (IN) 3 total (1 on front panel) 1 Vp-p, 75 ohms unbalanced, sync negative
S Video (IN) 3 total (1 on front panel) Y: 1 Vp-p, 75 ohms unbalanced, sync
negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Audio (IN) 6 total (1 on front panel) 500 mVrms (100% modulation)
Impedance: 47 kilohms
Component Video Input 2 (YP
BPR) Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative
P
B: 0.7 Vp-p, 75 ohms
P
R: 0.7 Vp-p, 75 ohms
AUDIO (VAR/FIX) OUT 1 500 mVrms at the maximum volume setting
(Variable)
500 mVrms (Fixed)
Impedance (output): 2 kilohms
✍ AUDIO OUT jacks are operable only when the
TV’s Speaker is set to Off.
RF Inputs 2
Digital Audio Optical Output
(PCM/Dolby Digital)
1 Optical Rectangular (1)
CableCARD Slot PCMCIA Type I/II
Speaker Output 12 W (L), 12 W (R)
Other Information
85
Other Information
KDF-E55/60A20
2-593-962-12(1)
Power Consumption
In Use 265 W
In Standby Less than 15 W
Dimensions (W × H × D) KDF-E55A20: (57
3
/8 × 37
1
/4 × 19
3
/8 inches) (1,456 × 943 × 491 mm)
KDF-E60A20: (62 × 39
5
/8 × 20
1
/2 inches) (1,574 × 1,005 × 518 mm)
Mass KDF-E55A20: 92.5 lb (42 kg)
KDF-E60A20: 101.5 lb (46.1 kg)
Supplied Accessories
Remote Control RM-YD002
AA (R6) Batteries 2 supplied for remote control
Design and specifications are subject to change without notice.
Non-metric weights and measures are approximate.
Optional Accessories
❑ HDMI cable
❑ Component video cable
❑ S VIDEO cable
❑ A/V cable
❑ Audio cable
❑ Optical cable
❑ TV Stand:
SU-GW12
❑ Lamp: XL-2200
87
KDF-E55/60A20
2-593-962-12(1)
Index
Numerics
0-9 buttons 42
A
Adding channels to the channel list
64
Adjusting audio, Steady Sound 60
Advanced Video 59
Alternate Audio 49
Alternate Video 49
ANT button 42
Applications Menu 73
Audio Menu 60
Audio receiver, connecting 39
Audio setting 56
B
Balance, adjusting 60
Bass, adjusting 60
Batteries, inserting in remote 41
Bilingual audio 61
Brightness, adjusting 58
C
Cable
with VCR, connecting 32
Cable box
connecting with VCR 33
cable box
using with remote control 46
CableCARD™ Device 25
Camcorder, connecting 38
Caption Vision 70
Channel Menu 64
Channel setting 57
Channel Show Hide 64
Channels
Auto Program 64
creating labels
65
setting up
30
Clock/Timers 73
closed caption modes 70
Color temperature, adjusting 58
Color, adjusting 58
Connecting
Audio receiver 39
Cable box
33
Camcorder or PlayStation
38
DVD player
36
VCR
32–35
D
Digital subchannels 49
DISPLAY button 42
Display unit
controls 14
Display, turning off 42
DVD 5.1Channel using with
remote control
47
DVD player
using with remote control 46
with A/V connectors,
connecting 37
with component video
connectors,
connecting
36
E
ENT button 42
F
Favorite Channel
setting up 64
Features 8
FREEZE button 43, 51
FUNCTION button 42
G
Game Picture 62
GUIDE button 42, 48
Guide menu 49
H
Hue, adjusting 58
I
Inputs, labeling 70
Installation of the projection TV
19–39
J
JUMP button 42, 51
L
Label
Channels 30, 65
video inputs
70
Lamp, replacing 76–79
M
MENU button 43
Menus
Parent 66
Screen
62
Setup
70
Mode
Custom 58
Standard
58
Vivid
58
MTS/SAP 43, 61
MUTING button 42
N
Noise Reduction 59
P
Parental control, described 9
Parental Lock Settings 66
Password, changing 67
PICTURE button 42
Picture contrast, adjusting 58
POWER LED indicator 14
problems, troubleshooting 80–83
Program Guide 48
Program Options menu 49
R
Ratings
setting 68
viewing blocked programs
67
Index
(Continued)
88
KDF-E55/60A20
2-593-962-12(1)
Rear panel controls and
connections
16
Remote control
inserting batteries 41
programming
44–45
Removing channels from the
channel list
64
S
Satellite Receiver 23
satellite receiver, using with remote
control
46
Screen Menu 62
Screen setting 56
setting up channels 30
Settings
Application 57
Audio
56
Channel
57
Parental Lock
57
Screen
56
Setup
57
Video
56
Setup menu 70
Setup setting 57
Sharpness, adjusting 58
Specifications 84–85
Steady Sound
adjusting 60
Surround sound 60, 61
T
Timer
set current 74
TIMER indicator 11, 14
Timer setting 73
Treble, adjusting 60, 62
troubleshooting 80–83
TV FUNCTION button 42
TV POWER button 43
TV/VIDEO button 43
V
VCR
using with remote control 46
with cable box, connecting
33
with cable, connecting
32
Video inputs, labeling 70
Video Modes, selecting 58
Video setting 56
VOL +/– button 42
W
WEGA GATE 43, 52–55
WIDE button 43, 50
KDF-E55/60A20 2-593-962-12(1)
LCD Projection TV
HD-TV
Operating Instructions
http://www.sony.net/
Printed in U.S.A.
2-593-962-12(1)
KDF-E55A20
KDF-E60A20
© 2005 Sony Corporation
™
™
2593962121Cover.indd 12593962121Cover.indd 1 9/13/2005 11:56:03 AM9/13/2005 11:56:03 AM
