Hisense HV651D60UK Diswasher

User Manual - Transcript

• Page 1: EN OPERATING INSTRUCTIONS DISHWASHER HV6131UK wwwgorenjecom
• Page 2 - English - : Contents Front panel Safety instructions Before washing for the first time Loading the dishwasher Using the dishwasher Settings Care and cleaning Troubleshooting Installation Service Information for test institute Technical information Front panel 321 4 75 6 10 13 11 12 1 Main power switch 2 Programme selector 3 Auto wash 4 Intensive wash 5 Eco wash 6 Quick wash 7 Rinse 8 Speed wash 9 Auto open 10 Half load 11 Delayed start 12 Display 13 Rinse aid indicator 14 Salt indicator
• Page 3 - English - : Safety instructions General Read the operating instructions and keep them in a safe place Never use the dishwasher for any purpose other than that specified in these operating instructions Do not load the dishwasher door or dishwasher baskets with anything other than dishes Never leave the dishwasher door open as someone may trip on it Use only dishwasher detergent This machine can be used by children aged 8 and upwards and by people with reduced physical capacity mental ability memory loss or lacking experience and knowledge These individuals must be supervised when using the machine or have instructions on how to use the machine and understand the risks that can occur Cleaning of the machine must not be carried out by children without supervision Damaged mains cables must only be replaced by a qualified electrician Only use the dishwasher in householdtype environments for dishwashing household dishes All other use is prohibited Never place dishes with solvent residues in the dishwasher due to the risk of explosion Nor may dishes that contain ash wax or lubricants be washed in the dishwasher WARNING Knives and other pointed items must be placed horizontally in the dishwashers special cutlery baskets Installation See the section Installation Child safety Children must be watched Do not allow children to use or play with the dishwasher Be especially vigilant when the door is open Some detergent may remain inside After adding detergent always start the dishwasher immediately WARNING Children must be supervised dishwasher detergent is corrosive Winter storagetransport Store the dishwasher above freezing and avoid long transport distances in very cold weather Transport the dishwasher upright or laying on its back Overflow guard function The overflow protection starts pumping out the machine and turns off the water supply if the water level in the dishwasher exceeds the normal level If the overflow protection is triggered turn off the water supply and call the service department Packing material The packaging protects the product during transport The packaging material is recyclable Separate the different packaging materials to help reduce raw material use and waste Your dealer can take the packaging for recycling or direct you to the nearest recycling centre The packaging is comprised of Corrugated cardboard made from up to 100 recycled material Expanded polystyrene EPS with no added chlorine or fluorine
• Page 4 - English - : Supports made from untreated wood Protective plastic made from polyethylene PE Disposal The dishwasher is manufactured and labelled for recycling When the dishwasher has reached the end of its service life and is to be disposed of it should immediately be made unusable Pull out the power cable and cut it as short as possible Contact your local authority for information about where and how your dishwasher should be correctly recycled Before washing for the first time The water softener In order to achieve good dishwashing results the dishwasher needs soft water water with low mineral content Hard water leaves a white coating on dishes and the dishwasher Water hardness is specified using the following scales The German water hardness scale dH and the French water hardness scale fH A water supply with a water hardness in excess of 6dH 9fH must be softened This is done automatically with the aid of the builtin water softener In order for the water softener to function optimally it must be adjusted to the hardness of the water supply If the water hardness exceeds 50dH 89fH we recommend connecting an external water softener Contact the local waterworks to check the water hardness in your area Adjusting the water softener Chapter Settings on page 13 describes how to adjust the water softener Top up with salt Before you begin using a dishwasher with a water softener you must fill the salt compartment with salt for the water supply to be softened automatically Use large grain salt or special dishwasher salt WARNING In order to avoid rust stains a dishwashing programme must be started immediately after adding salt Never pour dishwasher detergent into the salt compartment This destroys the water softener
• Page 5 - English - : Do as follows the first time Unscrew the salt compartment lid Place the funnel supplied with the dishwasher in the salt compartment topup hole First pour in about 1 l of water Then add salt a maximum of 15 kg until the compartment is full Wipe up any excess salt so that the lid can be screwed on firmly Run a programme to ensure that any salt in the dishwasher is rinsed away Salt compartment lid Refill salt indicator When the salt needs topping up the above symbol lights on the display When the salt runs out unscrew the cap and fill the container with salt Water is only needed the first time Wipe clean and tighten Run a programme to ensure that any salt in the dishwasher is rinsed away After topping up it may take a while before the symbol goes out Top up with rinse aid Drying is faster and a better result is achieved if you use rinse aid You will also achieve a better dishwashing result with clear and spotless dishes Open the rinse aid compartment lid Carefully top up with rinse aid to the level marked max Wipe up any splashes of rinse aid around the compartment Close the lid firmly Press to open Refill rinse aid indicator When the rinse aid needs topping up the above symbol lights on the display After topping up it may take a while before the symbol goes out Setting the rinse aid dosage The section Settings describes how to set the rinse aid dosage Rinse aid dispensing can be set from 0 Off to 5 High dose Factory settings 5 Decrease the rinse aid dosage If the dishes have a sticky whiteblue film If the dishes are streaked Buildup of foam If you have very soft water the rinse aid can be diluted 5050 with water
• Page 6 - English - : Loading the dishwasher Greener dishwashing Do not rinse under running water Simply scrape off large food particles before loading the dishwasher Choose an environmentallyfriendly detergent Read the environmental declaration on the packaging Do not start the dishwasher until it is fully loaded to save energy If the dishes are only slightly dirty you can select a programme with a low temperature Better drying results are achieved if you use the Auto open option which automatically opens the dishwasher door Wait until the dishwasher indicates that the programme has ended and the dishes have cooled before unloading the dishwasher If the dishwasher is builtin the surrounding furnishings must be resistant to any condensation from the dishwasher Fragile dishes Some cookware is not dishwasher safe This can be for several reasons Some materials cannot withstand strong heat others can be damaged by dishwashing detergent Exercise caution with for example handmade items fragile decoration crystalglassware silver copper tin aluminium wood and plastic Look for the quotDishwasher safequot marking Points to consider All dirty surfaces should face inwards and downwards Dishes should not be placed in or on each other Angle dishes with hollows such as cups so that the rinse water will run off This is also important for plastic items Make sure small items cannot fall through the dishwasher basket place them in the top cutlery tray NOTE Check that the spray arms can rotate freely The dishwashers baskets The dishwasher is equipped with a top cutlery tray an upper basket and a lower basket Top cutlery tray The top cutlery tray has space for cutlery ladles whisks serving cutlery and similar items Upper basket Place glasses cups bowls side plates and saucers in the upper basket All dirty surfaces should face inwards and downwards Wine glasses are placed on
• Page 7 - English - : the wine glass shelf and knives are placed in the knife stand on the right if fitted Raising and lowering the upper basket Pull out the upper basket Grab the sides of the upper basket with both hands and lift it up Repeatedly lift the basket with both hands to change its position The upper basket can be set in three positions When the upper basket is in the highest position lifting it will return it to the lowest position Note that both sides of the basket must always be set to the same height Foldable tines The foldable tines can be folded up or down to make it easier to load pots bowls and glasses Release the foldable tines by pressing the catch inwards before adjusting their position Lower basket Place plates side plates serving dishes and pots in the lower basket Foldable tines Fold down the foldable tines plate supports when dishwashing pots Release the foldable tines by pressing the catch inwards before adjusting their position
• Page 8 - English - : Using the dishwasher Add detergent Press to open Prewash detergent compartment Main wash detergent compartment Detergent is added according to water hardness Follow the instructions on the detergent packaging This dishwasher is fitted with a water softener so use detergent and rinse aid doses suitable for soft water Too much detergent can result in less effective dishwashing and also entails greater environmental impact The detergent compartment must be dry when adding detergent There is one compartment for the prewash and one for the main wash If powder or liquid dishwasher detergent is used add a small amount of the detergent to the prewash compartment Contact the detergent manufacturer if you have questions about the detergent NOTE Use only dishwasher detergent Washing up liquid must not be used as the foam that forms prevents the dishwasher from operating effectively Dishwasher tablets Halve the tablet if it is difficult to close the dispenser lid There is a risk that the detergent will not be released properly if the lid is tight and will not open correctly NOTE Dishwasher tablets are not recommended for short programmes less than 75 minutes Use powder or liquid dishwasher detergent instead Allinone detergent There are many types of allinone detergents on the market Read through the directions for these products carefully Chapter Settings describes how to activate TAB 3in1 Allinone detergent Note that salt must be put in the salt compartment If you are not satisfied with the dishwashing or drying results deactivate the setting TAB 3in1 Allinone detergent and top up with salt detergent and rinse aid See Chapter Before washing for the first time NOTE Optimal washing and drying results are achieved by using normal dishwasher detergent together with separately dispensed rinse aid and salt The main power switch Press and hold the main power switch until the display lights up Also check that the water tap is on
• Page 9 - English - : PROGRAM Select a programme Select a programme to suit the type of dishes and how dirty they are Press the Programme selector one or more times until the desired programme symbol is activated Auto wash The dishwasher can measure how dirty the dishes are and adjust water consumption and temperature accordingly When newly installed the programme needs to be run five times before it is fully adapted and can provide the best results Auto wash 1 Speed wash Auto open An effective programme for daily use for slightly dried leftovers This programme is not intended for burnt food such as on oven dishes Intensive wash Programme for very dirty dishes such as pans casserole dishes and oven dishes Also ideal for situations where demands on hygiene are especially high such as when dishwashing baby bottles and cutting boards If these dishes do not completely fill the dishwasher you can add plates and the like Eco wash This programme is intended for cleaning normally dirty dishes and is the most effective programme in terms of combined energy and water consumption Quick wash This programme is used for glasses and porcelain that is slightly dirty such as coffee cups In combination with Speed wash a shorter programme is achieved 15 minutes Rinse Used to rinse dishes while you wait for the dishwasher to become fully loaded EXTRA Select an option To select an option press one of the option buttons until the option is activated The available options vary between programmes and some options cannot be combined available options glow dimly Speed wash This option shortens the programme time but uses more energy and water Auto open The dishwasher door opens automatically which improves the drying results Wait until the dishwasher indicates that the programme has ended and the dishes have cooled before unloading the dishwasher If the dishwasher is builtin the surrounding furnishings must be resistant to any condensation from the dishwasher NOTE The dishwasher door must not be blocked when set to open automatically This can disrupt door lock functionality 1 This combination Auto wash Speed wash Auto open is also known as QuickIntensive 90 minutes
• Page 10 - English - : Half load This option adapts the dishwashing programme to a halffilled dishwasher using less energy and water Delayed start When you select Delayed start the dishwasher will start 124 hours after you close the door Press the button once to activate Delayed start Press the button several times or hold it in to set the desired number of hours Close the door and the dishwasher counts down 1 hour at a time and starts after the selected delay If you want to cancel the Delayed start option open the door and press and hold the main power switch until the display turns off Starting the dishwasher Close the door to start the dishwasher If the main power switch is on the dishwasher will start automatically when the door is closed TIME Time remaining Once you have chosen a programme and options the time the programme took when last used is displayed Stopping or changing a programme If you want to change programme after starting the dishwasher open the door then press and hold the main power switch until the display turns off Add more detergent if the lid of the detergent dispenser has opened Then press the main power switch choose a new programme and close the door If you want to load more dishes Open the door The dishwasher stops automatically Add the dishes and close the door After a while the dishwasher continues the programme If the dishwasher is turned off due to a power failure If the dishwashing programme was not finished the interrupted programme continues when power is restored NOTE During drying the programme is interrupted if the power is cut or the door is open for more than 2 minutes Once the programme has finished The dishwasher switches off automatically after the programme ends Shut off the water tap after each use How to get the best drying results Fully load the dishwasher Angle dishes with hollows such as cups so that the rinse water will run off This is also important for plastic items Top up with rinse aid or increase the rinse aid dosage level Activate the Auto open option Allow the dishes to cool before unloading the dishwasher Unloading the dishwasher Hot porcelain is more fragile Leave the dishes to cool in the dishwasher before unloading them Unload the lower basket first to avoid any water drops from the upper basket falling onto the dishes in the lower basket
• Page 11 - English - : Programme chart Consumption values 1 Final rinseNumber of rinses Main washPrewashesEXTRA Options Detergent compartment 1 2 ml PROGRAM Programme Water cons L Energy approx kWh Dishwashing time approx hrsmin 1120091521025065 C235065 C13Auto open 25Auto wash 171725570 C270 C210 25Intensive wash 9508630049 C255 C1Auto open 25 Eco wash 2 100202025 C135 C 10Quick wash 3001007 C1 Rinse 1 Consumption values vary depending on the temperature of the incoming water room temperature load size selected additional functions and more 2 This dishwashing programme is the standard cleaning cycle used to compile the energy labelling information It is intended for washing normally dirty dishes and is the most effective programme in terms of combined energy and water consumption
• Page 12 - English - : Settings Open the settings menu First open the door Turn off the machine Press and hold the main power switch until the display lights up Within 10 seconds press the Programme selector and the option button for Speed wash The display shows the settings menu current setting and its currently set value Exit the menu by browsing through the menu or pressing the main power switch Navigate the settings menu Press to save the set value and continue to the next setting Current setting Current setting value Press to browse between setting values You can now adjust the following settings OptionsSettings Rinse aid dosage setting100 105Rinse aid1 Increase the rinse aid dosage If the dishes have water marks Decrease the rinse aid dosage If the dishes have a sticky whiteblue film If the dishes are streaked Buildup of foam If you have very soft water the rinse aid can be diluted 5050 with water
• Page 13 - English - : OptionsSettings Adjusting the water softener Read off the appropriate setting from the water hardness table below dH 05 68 911 1214 1519 2024 2529 3039 4049 09 1014 1520 2125 2634 3543 4452 5370 7188 fH dH fH 200 209Water hardness2 Do not forget to put salt in the salt compartment after you have set the water softener to 201 209 For a water supply with a hardness under 6dH 9fH select 200 The water softener is deactivated and no salt is needed You can activate this setting when using 3in1 Allinone detergent The dishwashing programmes automatically adapt to provide the best possible dishwashing and drying results every time If this setting is activated there is no need to add rinse aid since this option disables rinse aid dispensing It also reduces the amount of salt added to the water softener Note that salt must be put in the salt compartment 300 Off 301 On TAB 3in1allinone detergent NOTE In order to achieve good dishwashing results it is essential to check which type of detergent or allinone product best suits your needs Read the detergent packaging carefully for information on proper use Always follow the directions for use or information on the detergent packaging
• Page 14 - English - : Care and cleaning Coarse filter The coarse filter traps larger food particles which cannot get past the drainage pump Empty the coarse filter as necessary Coarse filter Lift the coarse filter by the handle Empty the coarse filter Remember to replace it Fine filter Debris that collects on the fine filter is automatically rinsed away during each wash Clean the fine filter when necessary Fine filter Turn the handle anticlockwise Lift the filter straight up using the handle Free the coarse filter to clean the fine filter Replace in reverse order Check that the edges seal properly when replacing the fine filter Lock the filter in place by turning the handle clockwise to the stop position The handle should point straight out from the dishwasher NOTE Dishwashing results may be affected if the filters are incorrectly fitted Note that the dishwasher must not be used without the filters in place
• Page 15 - English - : Spray arms Holes and bearings can sometimes become blocked Remove any debris using a pin or the like The spray arms also have holes underneath To facilitate cleaning you can remove the spray arms Remember to fit them firmly back into place afterwards Lower spray arm Pull the lower spray arm straight up to release it Upper spray arm Pull out the upper basket Unscrew the spray arm bearings counterclockwise to remove the spray arm from the upper basket The door and the door seal Regularly clean the sides of the door and the door seal Use a slightly damp cloth with a little cleaner if necessary Front panel Keep the buttons clean and free from grease Wipe them clean with a dry or slightly damp cloth Never use cleaners they can scratch the surface Use the main power switch to turn off the dishwasher before cleaning the buttons to avoid activating any buttons unintentionally The dishwasher tub The dishwasher tub is made of stainless steel and is kept clean through normal use Limescale deposits If you have hard water limescale deposits may build up in the dishwasher If this happens run the Intensive wash programme with two tablespoons of citric acid in the detergent compartment with no dishes in the machine Unblocking the drainage pump If the dishwasher still contains water after the programme has finished something may be blocking the drainage pump Such items are easily removed Turn off the machine using the main power switch and unplug it from the wall socket Remove the coarse filter and the fine filter Scoop out the water from the dishwasher tub
• Page 16 - English - : In order to inspect the drainage pump remove the coloured stop on the right in the bottom drain Turn the pump wheel located behind the drainage pump stop by hand Carefully remove any items Replace the drainage pump stop along with the fine and coarse filters Plug the machine in again If the dishwasher still does not start and a whirring sound is heard the overflow protection has been activated Shut off the water Remove the plug from the wall socket Call the service department Drainage pump stop NOTE Do not forget to replace the drainage pump stop Unblocking the inlet hose filter If the water supply contains small particles the outer filter on the inlet hose may become blocked which results in Water inlet fault Turn off the machine using the main power switch and unplug it from the wall socket Turn off the water tap Unscrew the inlet hose Carefully remove the outer filter from the inlet hose and clean it Replace the filter and check that the gasket is correctly positioned Screw the inlet hose firmly into place Plug the machine into the wall socket and turn on the water tap Allow the pressure to settle for a while and check that the connection is watertight Outer filter on inlet hose Gasket
• Page 17 - English - : Troubleshooting ActionType of fault on the display Clear the drainage pump See the section Care and cleaning If the problem persists call the service department OverfillingF10 See Water remains in the dishwasher in the table Problem below If the problem persists call the service department Water outlet faultF11 Check that the water tap is on If the problem persists call the service department Water inlet faultF12 Turn off the water tap and call the service departmentInlet valve leakageF40 Call the service departmentWater level faultF52 Turn off the water tap and call the service departmentOverfillingF54 Call the service departmentCirculation faultF56 Press any button to clear the error message ActionPossible causesProblem Wait a moment then try again You have pressed the buttons too soon after opening the door The buttons do not react when pressed Clean with a dry or slightly damp cloth The buttons are dirty Open the door The buttons only react to use when the door is open The door is closed
• Page 18 - English - : ActionPossible causesProblem Check that the baskets are correctly positioned horizontally The baskets are not correctly positioned Cannot close door Check that the dishes are not blocking the baskets from sliding properly into place Check the door lock If it does not click into place and lock open the door Press and hold the button for the Auto open option for 15 seconds Then wait 30 seconds Close the door Check that the door lock clicks into place and locks The door lock does not click into place and lock
• Page 19 - English - : ActionPossible causesProblem CheckThe door is not properly closed The dishwasher does not start Close the door and wait After a while the dishwasher continues the programme You have opened the dishwasher to add more dishes while a programme is in progress Check the door lock If it has not clicked into place and locked open the door Press and hold the button for the Auto open option for 15 seconds Then wait 30 seconds Close the door Check that the door lock clicks into place and locks The door lock has not clicked into place and locked CheckA fusecircuit breaker has been tripped CheckThe plug is not plugged into the wall socket CheckThe water tap is turned off CheckOverflowleaks Turn off the water tap Pull out the plug and call the service department A whirring sound the drainage pump is heard from the dishwasher and does not stop when the main power switch is turned off Press and hold the main power switch until the display turns off if you want to cancel the Delayed start option Restart the dishwasher Check that the Delayed start option has not been selected
• Page 20 - English - : ActionPossible causesProblem Remove the arms and clean them The spray arms do not rotate The dishes are not clean Check that the dishes are not blocking the spray arms Avoid large packagesOld detergent Detergent is a perishable product Dose according to water hardness Far too much or far too little detergent results in poorer dishwashing results Incorrect detergent dosage Choose a longer programme Unsuitable dishwashing programme Do not cover porcelain with large bowls or the like Avoid placing very tall glasses in the corners of the baskets Dishes loaded incorrectly Place dishes to sit steadyGlasses and cups have toppled over during the programme Screw the filter firmly into place See the section Care and cleaning The filter is not correctly fitted Rinse off these types of foodstuffs if not starting the dishwasher immediately Use the Rinse programme Some foodstuffs such as mustard mayonnaise lemon vinegar salt and dressings can mark stainless steel if left for too long Spots on stainless steel or silver In order to avoid marks and tarnishing separate dishes made from different metals such as silver stainless steel and aluminium All stainless steel can cause spots on silver if they come into contact during dishwashing Aluminium can also cause spots on dishes
• Page 21 - English - : ActionPossible causesProblem Check that the salt compartment lid is properly tightened Otherwise call the service department The water softener is leaking salt Spots or films on the dishes See the section SettingsIncorrect water softener setting See the section SettingsIncorrect rinse aid dosage setting Top up with salt See the section Before washing for the first time Salt compartment empty Inactivate the setting TAB 3in1 Allinone detergent and top up salt and rinse aid 3in1 Allinone detergent is used and the setting TAB 3in1 Allinone detergent is activated Wash crystal at a low temperature and with a conservative amount of detergent Contact the detergent manufacturer Too high temperature andor too much detergent can cause etching on crystal Unfortunately this cannot be repaired only prevented Reduce the amount See the sections Before washing for the first time and Settings If you have very soft water you may want to dilute the rinse aid 5050 with water Rinse aid dosage setting too high The dishes have a sticky whiteblue film Use a detergent with a bleaching agent Lipstick and tea can be difficult to wash off Spots left after washing The detergent compartment must be dry when adding detergent The detergent compartment was damp when adding detergent Detergent residue in the detergent compartment after dishwashing Check that the dishes are placed securely Spin the spray arms to make sure they can rotate The dishes are not correctly placed or the spray arms are not rotating Rattling sound when dishwashing
• Page 22 - English - : ActionPossible causesProblem Clean the coarse and fine filters The filters are blockedWater remains in the dishwasher Clean the drainage pump See the section Care and cleaning Debris in the drainage pump Check that the hose is free from kinks and sharp bends Kink in drainage hose Disconnect the drainage hose where it connects to the sink units water trap Check that no debris has fastened and that the connection has an inner diameter of at least 14 mm Blocked drainage hose Clean with washingup brush and low foaming cleaner Dirt around the seals and in corners Bad odour in dishwasher Run a programme with a higher temperature about once a month Low temperature programmes have been selected for a prolonged period Activate the Auto open option The Auto open option is not activated The dishes are not dry enough Fully load the dishwasherThe dishwasher is not fully loaded Top up with rinse add or increase the rinse aid dosage See the sections Before washing for the first time and Settings Rinse aid needs topping up or dosage is set too low Inactivate the setting TAB 3in1 Allinone detergent and top up salt and rinse aid 3in1 Allinone detergent is used and the setting TAB 3in1 Allinone detergent is activated
• Page 23 - English - : Installation 817 890 660760 125198 mm Door length Nominal dimensions Actual measurements may vary It is important that you read through and follow the instructions and directions below Conduct installation and connection in accordance with the separate installation instructions Safety instructions Connections to electricity water and drainage must be performed by a qualified professional Always follow applicable regulations for water drainage and electricity Take care during installation Wear protective gloves There must always be two people Place a drip tray on the floor beneath the dishwasher to prevent damage from any water leaks Before screwing the dishwasher into place test the dishwasher by running the Rinse programme Check that the dishwasher fills with water and drains Check also that none of the connections leak WARNING Turn off the water supply when installing the dishwasher The plug must be disconnected or power to the socket turned off while the work is carried out Setup The recess and connection dimensions are included in the separate installation instructions Check that all dimensions are correct before starting the installation Note that the height of the cover door can be adjusted to match other fittings Make sure the area on which the dishwasher is to be installed is firm Adjust the adjustable feet so that the dishwasher is level
• Page 24 - English - : Affix the protective film packed in the document bag to the underside of the worktop The protective film is to protect the worktop from moisture Check that the machine is installed such that the door opens freely otherwise door lock functionality may be disrupted Drainage connection See the separate installation instructions for necessary information This dishwasher is suitable for installing in a raised recess to attain an ergonomic working height This means that the dishwasher can be placed so that the drainage hose runs to a lower level than the bottom of the dishwasher such as by routing it directly to a floor drain The dishwasher is fitted with an integrated antisiphon device to prevent the machine from being emptied of water during the wash cycle The drainage hose can also be connected to a connection nipple on the sink units water trap The connection nipple must have an internal diameter of at least 14 mm The drainage hose may be extended by a maximum of 3 m the total length of the drainage hose must not exceed 45 m Any joins and connecting pipes must have an internal diameter of at least 14 mm However the drainage hose should ideally be replaced with a new hose without joins No part of the drainage hose may be more than 950 mm above the bottom of the dishwasher Attach the drainage hose with a hose clamp Ensure that the drainage hose has no kinks Connection to water supply Use only the inlet hose supplied with the dishwasher Do not reuse old or other spare hoses The supply pipe must be fitted with a water tap stopcock The water tap must be easily accessible so that the water can be shut off if the dishwasher has to be moved Once the installation is complete turn on the water tap and allow the pressure to settle for a while Check that all connections are watertight Connection to cold water supply Connect the dishwasher to the cold water supply if the building is heated using oil electricity or gas Connection to hot water supply Connect the dishwasher to the hot water supply max 70 C if the building is heated using an energyefficient means such as district heating solar power or geothermal power Choosing a hot water connection cuts dishwashing times and reduces the dishwashers energy consumption NOTE Do not exceed the permitted water supply temperature Certain materials used in some cookware cannot withstand strong heat See Fragile dishes in the chapter Loading the dishwasher
• Page 25 - English - : Electrical connection Information about the electrical connection can be found on the serial number plate This specification must match the electricity supply The dishwasher must be connected to an earthed socket The electric wall socket must be placed outside of the installation area to be easily accessible after installing the dishwasher Do not use an extension cord NOTE Repairs and maintenance relating to safety or performance must be carried out by a qualified professional Service Read the chapter Troubleshooting before contacting the service department Provide the details on the serial number plate in all contact Include the article number 1 and the serial number 2 SERIAL NO ART NO
• Page 26 - English - : Information for test institute Request test institute information via email dishwashersappliancedevelopmentcom The request should include the details on the serial number plate Include the article number 1 and the serial number 2 SERIAL NO ART NO
• Page 28 - English - : Technical information Information on energy labelling Information sheet in compliance with Commission Delegated Regulation EU No 10592010 Hisense HV6131UKModel designation 1 Number of standard place settings AEnergy efficiency class 245 kWh per year 2 Annual energy consumptionAE C 086 kWhEnergy consumption of the standard cleaning cycleE t Power consumption 049 WOffmode P o 049 WLefton mode P l 2660 litres per year 3 Annual water consumption AW C A 4 Drying efficiency class Eco wash 5 option Auto openStandard programme 180 minutesProgramme time for the standard cleaning cycle InfiniteDuration of the lefton mode T l 47 dBA re 1 pWNoise emissions Integrated productConstruction 1 In accordance with standard EN 50242 2 Based on 280 standard cleaning cycles with a cold water connection and consumption in accordance with energy saving mode The actual energy consumption depends on how the machine is used 3 Based on 280 standard cleaning cycles The actual water consumption depends on how the machine is used 4 On a scale from G least efficient to A most efficient 5 This dishwashing programme is the standard cleaning cycle used to compile the energy labelling information It is intended for washing normally dirty dishes and is the most effective programme in terms of combined energy and water consumption Technical data 817890 mmHeight 596 mmWidth 556 mmDepth 35 kg 1 Weight 00310 MPaWater pressure See serial number plateElectrical connection See serial number plateRated power 1 Weight can vary due to different specifications Art No 785600 Rev 01 We reserve the right to make changes
