AZ1833MP3-CD Soundmachine
Congratulations on your purchase and wel-
come to Philips!
To fully benefit from the support that Philips
offers, register your product at
www.philips.com/welcome.
Supplied accessories
– AC power cord
– Audio cable
Top and front panels (See 1)
1
Source selector: CD/USB/AUX, FM,
MW, OFF
–
selects CD/MP3-CD, USB, AUX or radio
–
switches off the set
2
2;
–
starts or pauses disc/USB playback
∞§
–
For disc
/ USB play:
– skips to the beginning of a current/
previous/ later track
– fast searches backwards and forwards
within a track
9
–
stops disc/USB playback;
–
erases a program
PROG – programs tracks and reviews the
program
3 Display
–
shows disc/USB play functions
4 ALBUM
+/-
– For MP3-CD/ WMA/USB play: select
albums
5 USB – enters USB mode
6
CD – enters disc mode
7
MODE – selects different play modes:
e.g. REPEAT or SHUFFLE (random order)
8 OPEN•CLOSE – opens/ closes the CD
door
9
TUNING
– tunes to radio stations
0
VOLUME
–
adjusts volume level
! USB DIRECT – connects an external USB
mass storage device
Back panel (See 1)
@ Telescopic antenna – improves FM
reception
# AUX IN jack – connects to external audio
source
$ AC~ MAINS – inlet for power cord
% Battery door – open to insert 6 x 1.5V
R-14/ UM2/ C-cells
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries
Main set (See 1)
• Insert 6 batteries, type R-14, UM2 or C-
cells (not included, preferably alkaline) with
the correct polarity.
• Incorrect use of batteries can cause elec-
trolyte leakage and will corrode the compart-
ment or cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same
type for the set.
• When inserting new batteries, do not try to
mix old batteries with the new ones.
• Remove the batteries if the set is not to be
used for a long time.
Batteries contain chemical substances, so
they should be disposed of properly.
Using AC power
1 Check if the power/mains voltage, as shown
on the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
2 If your set is equipped with a voltage
selector, adjust the selector so that it match-
es with the local power supply.
3 Connect the power cord to the
AC~ MAINS inlet and the wall socket.The
set is now ready for use.
4 To switch the set off completely, withdraw the
power cord from the wall socket.
5 Install the unit near the AC outlet and where
the AC power plug can be easily reached.
• Disconnect the power cord from the wall
socket to protect your set during heavy thun-
derstorms. Children could seriously injure
themselves as the free end of the cable may
still be live if only the connector is removed
from the MAINS socket at the back of the
unit.
The type plate is located on the
bottom of the set.
Helpful hints:
–To avoid unnecessary energy consumption,
always adjust the source selector to OFF
after using the set.
CAUTION
Use of controls or adjustments
or performance of procedures
other than herein may result in
unsafe operation.
For users in the U.K., please follow
the boxed instructions ‘Important
notes for users in the U.K.’ .
This set complies with the radio
interference requirements of the
European Community.
Basic functions
Switching on/off the set and selecting
function
1 To switch on, adjust the source selector to
CD/USB/AUX, FM or MW as desired.
2 To switch off, adjust the source selector to
OFF.
Adjusting volume
Adjust the volume with the VOLUME
control.
Radio reception
1 Push the source selector to FM or MW.
2 Tu r n TUNING to tune in a radio station.
3 To switch off the radio, adjust the source
selector to OFF.
Helpful hints:
To improve reception
• For FM, extend, incline and turn the
telescopic antenna. Reduce its length if the
signal is too strong.
• For MW, uses a built-in antenna. Direct this
antenna by turning the whole set.
English Controls / Power Suppy
Power Supply Basic Function / Radio
About MP3
The music compression technology MP3
(MPEG1 Audio Layer 3) significantly reduce
the digital data of an audio CD while
maintaining CD quality sound.
•
Getting MP3 files: you can either download
legal music files from the internet to your
computer hard disc, or create such files by
converting audio CD files in your computer
through appropriate encoder software.
(128kbps bit rate or higher is recommended
for MP3 files.)
•
Creating a MP3 CD: burn the music files
from your computer hard disc on a CDR or
CDRW using your CD burner.
Helpful hints:
– Make sure that the file names of the MP3 files
end with .mp3 or .wma.
– Number of albums: maximum 256
– Number of tracks: maximum 511
– The length of file names affects the number of
tracks for playback.With shorter file names,
more files can be burned on a disc.
Playing a disc
This player plays Audio Discs including CD-R/
CD-RW, MP3 CD and WMA. Do not try to
play a CD-ROM, CD-I, CDV,VCD, DVD or
computer CD.
IMPORTANT!
• CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
• DRM-protected WMA disc is not supported.
1 Adjust the source selector to
CD/USB/AUX.
➜ Display shows - - - with “DISC”(see 2),
or - - - with “USB” (see 3)
2 Press CD to enter CD mode if USB is dis-
played.
➜ Display will show --- with “DISC”(See 2).
3 Open the disc door.
4 Insert a disc with the printed side facing up
and press the disc door gently to close.
➜ Display:The total number of tracks
appears.
➜ The disc scanning of MP3-CD may run
longer than audio CD.
5 Press
2;
to start playback.
➜ Display:
2
and the current track number.
For MP3-CD/ WMA only:
➜ The current track number “XXX“ and
album number “XXX“ with “ALB“ will be
displayed interchangeably (See 45).
6 To pause playback press
2;
.
➜ Display:
2
and the current track number
flash.
7 Press
2;
again to resume playback.
8 To stop playback, press
9
.
Helpful hints:
The disc playback will also stop when:
–you open the disc compartment door;
–you select FM, MW or OFF position;
– the disc has reached the end of the playback.
Selecting a different track
• Press ∞ or § once or repeatedly until the
desired track number appears in the display.
For MP3-CD/WMA: First press
ALBUM
+/- once or more to find your
album.
• In the pause/stop position, press 2; to start
playback.
MP3-CD / CD Player
Printed in China JS-0731
W
CLASS 1
LASER PRODUCT
AZ1833
X
USB
DISC
DISC
DISC
DISC
DISC
WMA
USB mass
storage device
USB cable
2
8
3
6
7
4
5
Meet Philips at the Internet
http://www.philips.com
6 x R14 • UM-2 • C-CELLS
8
9
0
!
#
$
1
2
4
@
%
3
AC MAINS~
AUX IN
5
6
7
4
1
User Manual
English
Register your product and get support at
www.philips.com/welcome
9
Important notes for
users in the U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug.To change a fuse in this type of
plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362
5 Amp, A.S.T.A. or BSI approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your
socket outlets, it should be cut off and an
appropriate plug fitted in its place. If the
mains plug contains a fuse, this should have
a value of 5 Amp. If a plug without a fuse is
used, the fuse at the distribution board
should not be greater than 5 Amp.
Note:The severed plug must be disposed
of to avoid a possible shock hazard should
it be inserted into a 13 Amp socket else-
where.
How to connect a plug
The wires in the mains lead are coloured
with the following code: blue = neutral (N),
brown = live (L). As these colours may not
correspond with the colour markings identi-
fying the terminals in your plug, proceed as
follows:
• Connect the blue wire to the terminal
marked N or coloured black.
• Connect the brown wire to the terminal
marked L or coloured red.
• Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make cer-
tain that the cord grip is clamped over the
sheath of the lead - not simply over the
two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956
and The Performer’s Protection Acts 1958
to 1972.
