Dryer
User Manual
LTH3842W
Please read this user manual first!
Dear Customer,
Thank you for prefering a Blomberg product. We hope that your product which has been
manufactured with high quality and technology will give you the best results. We advise you to
read through this manual and the other accompanying documentation carefully before using
your product and keep it for future reference. If you transfer the product to someone else, give
its manual as well. Pay attention to all details and warnings specified in the user manual and
follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints about usage.
A
Warning for hazardous situations with regard to life and property.
B
Warning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
1 Important safety and environmental
instructions 4
1.1 General safety .....................................4
1.1.1 Electrical safety .............................5
1.1.2 Product safety................................6
1.2 Mounting over a washing machine ......8
1.3 Intended use ........................................ 9
1.4 Child safety .......................................... 9
1.5 Compliance with the WEEE regulation
and disposing of the waste product .........10
1.6 Compliance with RoHS Directive:......10
1.7 Package information .......................... 10
1.8 Technical specifications ..................... 11
2 Your Dryer 12
2.1 Overview............................................12
2.2 Package Contents .............................13
3 Installation 14
3.1 Appropriate installation location ......... 14
3.2 Removing the transportation safety
assembly .................................................14
3.3 Connecting to the drain .....................14
3.4 Adjusting the feet ...............................15
3.5 Electrical connection..........................15
3.6 Transportation of the dryer ................15
3.7 Warnings about sounds .....................16
3.8 Changing the illumination lamp ........16
4 Electrical Connection 17
4.1 Attention!............................................17
4.2 Electrical requirements ......................17
4.3 Fitting a different plug ........................17
4.4 Washer/dryer combination ................. 17
5 Preparation 18
5.1 Laundry suitable for drying in the dryer 18
5.2 Laundry not suitable for drying in the
dryer ........................................................18
5.3 Preparing laundry for drying ..............18
5.4 Things to be done for energy saving .18
5.5 Correct load capacity ......................... 19
6 Operating the product 20
6.1 Control Panel ..................................... 20
6.2 Screen symbols .................................20
6.3 Preparing the dryer ............................ 21
6.4 Programme selection.........................21
6.5 Programme selection and consumption
chart.........................................................22
6.6 FasterDry ........................................... 25
6.7 Auxiliary functions .............................. 25
6.8 Warning symbols ...............................26
6.9 Starting the program .......................... 27
6.10 Program progress status .................27
6.11 Child Lock ........................................27
6.12 Changing the program after it is
started......................................................28
6.13 Cancelling the program ...................29
6.14 End of programme ........................... 29
7 Maintenance and cleaning 30
7.1 Cleaning Lint Filter / Loading Door Inner
Surface ....................................................30
7.2 Cleaning the sensor ..........................31
7.3 Draining the water tank......................31
7.4 Cleaning the filter drawer ..................32
7.5 Cleaning the evaporator ....................33
8 Troubleshooting 34
TABLE OF CONTENTS
Dryer / User Manual
Important safety and environmental
instructions
4 / EN
1 Important safety and environmental
instructions
This section contains safety instructions that will help protect
from risk of personal injury or property damage. Failure to
follow these instructions shall void any warranty.
1.1 General safety
• The dryer can be used by children at and above 8
years old and by persons whose physical, sensory or
mental capabilities were not fully developed or who
lack experience and knowledge provided that they are
supervised or trained on the safe usage of the product
and the risks it brings out. Children should not play with
the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by
someone.
• Children of less than 3 years should be kept away unless
continously supervised.
• Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced with
materials such as carpet, wood and tape. This will cause
problems with the dryer.
• Always have the installation and repairing procedures
carried out by the Authorised Service. Manufacturer
shall not be held liable for damages that may arise from
procedures carried out by unauthorised persons.
• Never wash the dryer by spraying or pouring water onto it!
There is the risk of electric shock!
Dryer / User Manual
Important safety and environmental
instructions
5 / EN
1.1.1 Electrical safety
A
Electrical safety instructions should be followed while
electrical connection is made during the installation.
A
The appliance must not be supplied through an
external switching device, such as a timer,or
connected to a circuit that is regularly switched on
and off by utility.
• Connect the dryer to a grounded outlet protected by a
fuse at the value specified on the type label. Have the
grounding installation performed by a qualified electrician.
Our company shall not be liable for any damages that
will arise when the dryer is used without grounding in
accordance with the local regulations.
• The voltage and allowed fuse protection is stated on the
type label plate.
• The voltage specified on the type label must be equal to
your mains voltage.
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation,
maintenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by
pulling on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to
connect the dryer to power supply in order to decrease the
risk of fire and electric shock.
• Power cable plug must be easily accessible after
installation.
B
Damaged mains cable should be changed by an
Authorised Service agent.
Dryer / User Manual
Important safety and environmental
instructions
6 / EN
B
If the dryer is faulty, it must not be operated unless it
is repaired by an authorised service agent! There is
the risk of electric shock!
1.1.2 Product safety
• Superheating of the clothes inside of the dryer can
occur if you cancel the programme or in the event
of a power failure whilst the dryer is running, this
concentration of heat can cause self-combustion
and fire so always activate the ventilation
programme to cool down or quickly remove all
laundry from the dryer in order to hang them up
and dissipate the heat.
Points to be taken into consideration for fire
hazard:
Below specified laundry or items must not be dried
in the dryer because of fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone, alcohol, fuel oil,
kerosene, stain removers, turpentine, paraffin or
solvents must be washed in hot water with plenty of
detergent before being dried in the dryer.
Dryer / User Manual
Important safety and environmental
instructions
7 / EN
Below specified laundry or items must not be
dried in the dryer due to the fire hazard:
• Garments or pillows bolstered with rubber foam
(latex foam), shower caps, water resistant textiles,
materials with rubber reinforcement and rubber
foam pads.
• Clothing cleaned with industrial chemicals.
Items such as lighters, matches, coins, metal parts,
needle etc. may damage the drum set or may lead to
functional problems. Therefore check pockets off the
laundry that you will load into your dryer.
Never stop your dryer before the programme
completes. If you must do this, remove all laundry
quickly and lay them out to dissipate the heat.
Clothes that are washed inadequately may ignite on
their own and even may ignite after drying ends.
• You must provide enough ventilation in order to prevent
gases exiting from devices operating with other types of
fuels including the naked flame from accumulating in the
room due to the back fire effect.
A
Clothing that contains metal reinforcements should
not be dried in the dryer. Dryer may be damaged
if metal reinforcements come loose and break off
during drying.
C
Use softeners and similar products in accordance
with the instructions of their manufacturers.
C
Always clean the lint filter before or after each
loading. Never operate the dryer without the lint filter
installed.
Dryer / User Manual
Important safety and environmental
instructions
8 / EN
• Never attempt to repair the dryer by yourself. Do not
perform any repair or replacement procedures on the
product even if you know or have the ability to perform the
required procedure unless it is clearly suggested in the
operating instructions or the published service manual.
Otherwise, you will be putting your life and others' lives in
danger.
• There must not be a lockable, sliding or hinged door that
may block the opening of the loading door in the place
where your dryer is to be installed.
• Install your dryer in a suitable place that is dry, well
ventilated and unlikely to get below 5 degrees Centigrade.
• Make sure that pets do not enter the dryer. Check the
inside of the dryer before operating it.
• Do not lean on the loading door of your dryer when it is
open, otherwise it may fall over.
• The lint must not be allowed to accumulate around the
tumble dryer
1.2 Mounting over a washing machine
• A fixing device should be used between the two machines
when installing the dryer above a washing machine. The
fitting device can be obtained through spare part suppliers.
• Total weight of the washing machine and the dryer -with
full load- when they are placed on top of each other
reaches to approx. 180 kilograms. Place the products on a
solid floor that has sufficient load carrying capacity!
A
Washing machine cannot be placed on the dryer.
Pay attention to the above warnings during the
installation on your washing machine.
Dryer / User Manual
Important safety and environmental
instructions
9 / EN
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm
Can be stacked
Can be
stacked
Cannot be
stacked
60 cm
Can be stacked
Cannot be
stacked
1.3 Intended use
• Dryer has been designed for domestic use. It is not
suitable for commercial use and it must not be used out of
its intended use.
• Use the dryer only for drying laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from
incorrect usage or transportation.
• Original spare parts will be available to repair the dryer for
a period of 10 years.
1.4 Child safety
• Packaging materials are dangerous for the children. Keep
packaging materials away from children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is operating. Do not
let them tamper with the dryer. Use the child-proof lock in
order to prevent the children to tamper with the dryer.
C
Child-proof lock is on the control panel. (See Child
lock)
• Keep loading door closed even when the dryer is not in
use.
Dryer / User Manual
Important safety and environmental
instructions
10 / EN
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product does not contain the harmful and
prohibited substances which are specified in the
“Control of the Waste Electrical and Electronic
Equipment” as published by Republic of Turkey
Ministry of Environment and Urbanization. It
complies with the WEEE Directive.
This product was made of high quality items and materials
which are recyclable and reusable. Therefore, do not
dispose of the product at the end of its service life with the
domestic and other wastes. Take it to a collection point for
the recycling of electrical and electronic equipment. Please
consult your local authorities to learn the nearest collection
point. Help protect the environment and natural resources
by recycling used products. For children's safety, cut the
power cable and break the locking mechanism of the door, if
any, so that it will be non-functional before disposing of the
product.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take
them to the packaging material collection points designated
by the local authorities.
Dryer / User Manual
Important safety and environmental
instructions
11 / EN
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 60,9 cm
Capacity (max.) 8 kg**
Net weight (plastic front door usage) 48,5 kg
Net weight (glass front door usage) 51 kg
Voltage
See type label***Rated power input
Model code
1.8 Technical Specifications
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened
maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
C
Technical specifications of the dryer are subject to
specification without notice to improve the quality of
the product.
C
Figures in this manual are schematic and may not
match the product exactly.
C
Values stated on markers on the dryer or in the other
published documentation accompanying with the
dryer are obtained in laboratory in accordance with
the relevant standards. Depending on operational and
environmental conditions of the dryer, these values
may vary.
Dryer / User Manual12 / EN
2 Your Dryer
2.1 Overview
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. Kick plate
8. Type label
9. Lint lter
10. Water tank drawer
11. Power cord
Dryer / User Manual 13 / EN
2.2 Package Contents
1
2 3
5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.
Your Dryer
Dryer / User Manual14 / EN
3 Installation
Before the calling the nearest Authorized
Service for the installation of the dryer,
ensure that electrical installation and water
drain is appropriate referring to the user’s
manual. (See 3.3 Connecting to the
drain and 3.5 Electrical connection) If
they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
C
Preparation of the dryer's location
as well as the electrical and
waste water installations is under
customer's responsibility.
A
Prior to installation, visually check
if the dryer has any defects on
it. If the drier is damaged, do
not have it installed. Damaged
products cause risks for your
safety.
A
Let your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer will
be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall
be placed against a wall.
B
Do not place the dryer on the
power cable.
3.2 Removing the
transportation safety assembly
A
Remove the transportation safety
assembly before using the dryer
for the first time.
• Open the loading door.
• There is a nylon bag inside the drum that
contains a piece of styrofoam. Hold it
from its section marked with XX XX.
• Pull the nylon towards yourself and
remove the transportation safety
assembly.
A
Check that no part of the
transportation safety assembly
remains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water tank
during the drying cycle. You should drain
accumulated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.
Connecting the water drain hose
1-2 Pull hose at the behind of the dryer by
hand in order to disconnect it from where
it is connected. Do not use any tools to
remove the hose.
3 Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose
of the product in previous step.
Dryer / User Manual 15 / EN
4 Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
1
3 4
2
A
Hose connection should be made
in a safe manner. Your drain
house will be flooded if the hose
comes out of its housing during
water discharge.
C
Water drain hose should be
attached to a height of maximum
80 cm.
C
Make sure that the water drain
hose is not stepped on and it is
not folded between the drain and
the machine.
3.4 Adjusting the feet
• In order to ensure that the dryer operates
more silently and vibration-free, it must
stand level and balanced on its feet.
Balance the machine by adjusting the
feet.
• Turn the feet to left or right until the dryer
stands level and firmly.
C
Never unscrew the adjustable
feet from their housings.
3.5 Electrical connection
For specific instructions for electrical
connection required during installation (see
1.1.1 Electrical Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the
dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when looked
from the front.
Installation
Dryer / User Manual16 / EN
3.7 Warnings about sounds
C
It is normal to hear a metallic
noise from the compressor
sometimes during operation.
C
Water collected during operation
is pumped to water tank. It is
normal to hear pumping noise
during this process.
3.8 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance is not
suitable for household room illumination. The
intended purpose of this lamp is to assist
the user to place laundry in the tumble dryer
in a comfortable way. The lamps used in
this appliance have to withstand extreme
physical conditions such as vibrations and
temperatures above 50 °C
Installation
Dryer / User Manual 17 / EN
Make sure that you have an earthed power
outlet socket rated at 13 amps (minimum).
4.1 Attention!
When installed, the socket must be reachable
after installation, or a separate switch (which
can disconnect the two poles) must be used
in the installation. Check for suitability.For a
permanent connection, a master switch with
at least 3mm contact clearance and minimum
13 A rating must be used.
4.2 Electrical requirements
Before you insert the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating label corresponds to your
electricity supply.
We recommend that this appliance be con-
nected to the mains supply via a suitable
switched and fused socket in a readily acces-
sible position. Should the mains lead of the
appliance become damaged or need replac-
ing at any time, it must be replaced by a spe-
cial purpose made mains lead which can only
be obtained from a Authorised Service Agent.
A
Warning
This appliance must be earthed
If the tted moulded plug is not suitable for
your socket, then the plug should be cut off
and an appropriate plug tted.
The moulded plug on this appliance incorpo-
rates a 13A fuse. Should the fuse need to be
replaced an ASTA approved BS1362 fuse of
the same rating must be used. Do not forget
to ret the fuse cover. In the event of losing
the fuse cover, the plug must not be used un-
til a replacement fuse cover has been tted.
Colour of the replacement fuse cover must
be the same colour as that visible on the pin
face of the plug. Fuse covers are available
from any good electrical store.
In order to avoid hazards, damaged supply
cord should be replaced by the manufacturer,
its service agent or similarly qualied people.
Built-under installation
This appliance can be installed under a work-
top.
A
Do not operate without the top
cover tted. Risk of injury.
A
Important
4.3 Fitting a different plug
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals
on your plug, proceed as follows:
1 Connect the green - yellow or green (earth)
wire to the terminal in the plug marked ‘E’ or
with the symbol or coloured green and yel-
low or green.
2 Connect the blue (neutral) wire to the termi-
nal in the plug marked ‘N’ or coloured black.
3 Connect the brown (live) wire to the termi-
nal in the plug marked ‘L’ or coloured red.
With the alternative plugs a 13A fuse must
be tted either in the plug or adaptor or in the
main fuse box. If in doubt contact a qualied
electrician.
4.4 Washer/dryer combination
Do not stack washing machine on top of the
tumble dryer. This would damage both appli-
ances and guarantees would become void.
It is also unsafe to stack an appliance on top
of another without using a suitable and ap-
proved stacking kit obtained from the manu-
facturer of the appliances.
• A special stacking kit is required as an op-
tional extra please contact customer service.
Green and yellow
or green
N
Blue or black
L
Brown or red
4 Electrical Connection
Dryer / User Manual18 / EN
5 Preparation
5.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label
stating that they are suitable for drying in a dryer and make sure that you select the
appropriate programme.
5.2 Laundry not suitable for
drying in the dryer
C
Delicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight items
and tulle curtains are not suitable
for machine drying.
5.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
5.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-efficient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and table clothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.
• Do not add wet laundry while the dryer is
in operation
Drying
Settings
At any temperature
At high temperature
At medium
temperature
At low temperature
Without heating
Hang to dry
Lay to dry
Hang wet to dry
Lay in shadow
to dry
Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature
200
0
C 150
0
C 110
0
C
LAUNDRY DRYING SYMBOLS
Drying
Symbols
Suitable for
dryer
No Iron
Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry
Do not dry-
clean
Dryer / User Manual 19 / EN
• Clean the lint filter before or after each
drying cycle. (See 7.1 Cleaning Lint
Filter / Loading Door Inner Surface)
• Clean the filter periodically when there
is visible air collection on it or when the
symbol lights up, if there is a filter drawer
cleaning warning symbol «
»available.
(See 7. 4 Cleaning the filter drawer)
• Ventilate the room, where the dryer is
located, well during drying.
5.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
C
It is not recommended to load
the dryer with laundry exceeding
the level indicated in the figure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry
Approximate
weights (g)*
Cotton quit covers
(double)
1500
Cotton quit covers
(single)
1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces)
100
T-Shirts 125
*Dry laundry weight before washing.
Preparation
Dryer / User Manual20 / EN
6 Operating the product
6.1 Control Panel
1. Program Selection button
2. Display
3. On-Off button
4. Start/Stand-by button
5. End Time button
6. FasterDry button
7. Buzzer button
8. Dryness Settings Selection button
6.2 Screen symbols
1 2
45678
3
Rem aining tim e indicat or*
Clean filter drawer warning symbol
Filter cleaning warning symbol Child lock warn in g sym bol
Clos e t - d r y
Wat er t ank w arnin g sym bol
En d t im e
An t i- creas e
En d of cycle
Start/hold symbol
Steam symbol
Dryness level
Iron- dry
* Tim e displayed in dicat es th e rem ain in g tim e t o t h e en d of t h e cycle an d t h is
tim e varies as per t h e hum idit y of t h e lau n dry.
Buzzer level symbol
Dryer / User Manual 21 / EN
6.3 Preparing the dryer
Plug in the tumble dryer
Open device door.
Place the laundry into the tub in a slight
loosely.
Close the door by pushing.
C
Make sure there is nothing
door and the device while closing
the door.
Press and hold On/Off/Cancel button for 1
second.
• When dryer is used for the first time,
declaration program (cupboard dry
cottons) is selected.
C
Program doesn’t start
immediately only by pressing the
On/Off/Cancel button. Start the
program with the On/Off/Cancel
button after program selection.
Operating the product
6.4 Programme selection
Your dryer has 16 different programs.
Delicates
Freshen Up
• Select the desired program by turning the
program selection button..
• Displayed program selection and
consumption chart are based on sorting
by preferences of majority of users.
Dryer / User Manual22 / EN
6.5 Programme selection and consumption chart
Operating the product
Programme Programme Description
Capacity
(kg)*
Spin
Speed in
Washing
Machine
(rpm)
Drying
Time
(Min.)
RapiDry
(Min.)
Cottons
Cupboard
Dry
You may dry all your cotton laundry in this
program. (T-shirt, pants, pyjamas, baby
clothes, underwear, linen, etc.) You can put
your laundry in the wardrobe without ironing.
8 / 4 1000 152 / 95 115
Cottons Iron
Dry
You may dry your cotton laundry to be ironed
in this program to have them slightly damp for
ease of ironing. (Shirt, T-shirt, tablecloth, etc.)
(Hemden, T-Shirts, Tischdecken usw.)
8 1000 124 95
Cottons
Extra Dry
You may dry your thick cotton laundry in this
program such as towels, bathrobe, etc. You
can put your laundry in the wardrobe without
ironing.
8 1000 165 130
Synthetics
Cupboard
Dry
You may dry all your synthetic laundry in
this program. (Shirt, T-shirt, underwear,
tablecloth, etc.) You can put your laundry in
the wardrobe without ironing.
4 800 75 50
Synthetics
Iron Dry
You may dry your synthetic laundry to be
ironed in this program to have them slightly
damp for ease of ironing. (Shirt, T-shirt,
tablecloth, etc.)
4 800 59 34
Jeans
You may dry denim pants, skirts, shirts or
jackets in this program.
4 1200 117 85
Sport
Use for drying laundry made out of synthetic,
cotton or mixed type of fabrics.
4 1000 105 70
Shirts 30’
Use this programme to make 2 shirts ready
for ironing in 30 minutes.
0,5 1200 30 23
BabyProtect
This programme is used for baby clothes that
bear machine dryable approval on its label.
3 1000 95 71
Mix
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
4 1000 110 75
Dryer / User Manual 23 / EN
Operating the product
Bedding
Dry fiber quilts with ‘machinedryable’ label
only. Make sure you are loading the quilt in
the correct way to avoid damages on the
machine and the quilt. Take out the quilt cover
before loading the quilt in the machine. Fold
the quilt in two before loading. - Do not load
more than 1 doublesize fiber quilt (200x200
cm). Do not dry items containing cotton such
as quilts, pillows and etc. - Do not dry items
other than quilts such as carpets, rugs or
mats. Permanent damage may arise in your
machine.
2,5 1000 120 -
Night
In this programme the level of noise emitted
to the environment will be the lowest. Volume
level will be fifty percent lower with respect to
the ‘wardrobe dry for cottons’ programme.
8 1000 240
Delicates
You may dry your delicate laundry or laundry
with hand wash symbol (silk blouses, thin
underwear, etc.) at low temperature in this
program.
2 600 50
WoolProtect
Use this programme to dry woolen garments
such as jumpers that are washed according
to the instructions. It is recomended that
garments would be removed at the end of the
programme.
1,5 600 146
Freshen Up
It just provides airing for 10 minutes without
any hot air. You can air the cotton and linen
laundry that are kept closed for a long time ,
and eliminate the odour in them.
- - 10
Timer
programmes
You can select the timer programs from 10
mins to 160 mins to achieve the desired final
drying level under low temperature. In this
program, the dryer dries for the time set,
regardless of the dryness of the laundry.
- - -
* Weight of dry laundry before washing
Dryer / User Manual24 / EN
Operating the product
„Cotton cupboard dry programme“ used at full and partial load is the standard dry-
ing programme to which the information in the label and the che relates, that this
programme is suitable for drying normal wet cotton laundry and that it is the most
efcient programme in terms of energy consumption for cotton.
Energy consumption values
Programs
Capacity
(kg)
Spin speed in
washing machine
(rpm)
Approximate amount
of remaining humidity
Energy
consumption
value kWh
RapiDry
kWh
Cottons linen Ready to wear**
8 / 4 1000 % 60 1,43 / 0,84 2,33
Cottons Ready to iron
8 1000 % 60 1,15 1,99
Synthetics Ready to wear
4 800 % 40 0,51 0,87
Power consumption of the off-mode for the standart cotton programme at full load, PO
(W)
0,1
Power consumption of the left-on mode for the standart cotton programme at full load,
PL (W)
1,0
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed.
R134a / 0,52 kg - GWP:1430 - 0,744 tCO
2e
C
To get better results from drying machine programs, your laundry should be
washed with suitable program in your washing machine and wrung with recom-
mended wringing speed.
C
Shirt might remain slightly damp at the end of the program. It is recommended not
to leave the shirts inside the drying machine.
C
When the program ends for not having wrinkles on your delicate laundry, take out
your laundry immediately and hang them.
The wool drying cycle of this machine has been approved by The Woolmark
Company for the drying ofmachine washable wool products provided that the
products are washed and dried according to the instructions on the garment label
and those issued by the manufacturer of this machine.The Woolmark symbol
is a Certication mark in many countries. M1721.
** : Energy Label standard program (EN 61121:2012)
All the values on the chart are identied according to EN 61121:2012 standard. Consumption
values may vary from the valued in the chart depending on laundry type, wringing speed, am-
bient conditions and voltage levels.
Dryer / User Manual 25 / EN
Volume level low
Volume level high
Dryness settings selection
Dryness settings button is used for ad-
justing to desired dryness. Program time may
change depending on the selection.
C
You can activate this function only
prior to start of program.
Operating the product
6.6 FasterDry
This application is available for all pro-
grammes highlighted with dark colour on the
control panel.
For example in case of “wardrobe ready for
cotton” the usual programme duration is 2:32,
the ExpressDy feature reduces the required
time to 1:55.
6.7 Auxiliary functions
Audible warning
Machine makes an audible warning
when the program is completed. To adjust the
sound level, use the Sound Warning Level
button.
C
You can change the sound level
before the program starts or while
the program continues..
Dryer / User Manual26 / EN
Operating the product
Drying level damp
Drying level normal
Drying level extra
6.8 Warning symbols
C
Warning symbols may vary
depending on the model of your
machine.
Fibre filter cleaning
When the program is completed, the warning
symbol for lter cleaning turns on.
C
For detailed information, See 6
Maintenance and cleaning.
C
If filter cleaning symbol constantly
flashes See.7 Troubleshooting.
Emptying the water tank
When the program is completed, the warning
symbol to empty the water tank turns on.
C
For detailed information, See 6
Maintenance and cleaning.
If the water tank lls up while the program
continues, the warning symbol starts ash-
ing and the machine goes into stand-by. In
this case, empty the water tank and start the
program by pressing the Start / Stand-by but-
ton. Warning symbol turns off and program
resumes.
Cleaning the filter drawer
Warning symbol ashes to remind that the
lter drawer needs to be cleaned.
C
For detailed information, See 6
Maintenance and cleaning.
Loading cover is open
If loading cover of the dryer is open while dry-
ing, Stand-by symbol turns on and program
progress symbol ashes.
Dryer / User Manual 27 / EN
End time
You can delay the end time of the program up
to 24 hours with end time function.
• Open the loading door and place the
laundry.
• Select drying program, spin cycle and if
needed, additional functions.
• Press the End Time selection button and
set the delay time you wish. End Time
symbol turns on. (When pressed and hold
the button, End Time proceeds non-stop).
• Press the Start / Stand-by button. End
time countdown starts and Start symbol
turns on. “:” Separator in the middle of
displayed delay time flashes.
C
You can add or remove laundry
within end time. End Time
symbol will turn off at the end
of countdown, drying starts and
duration of program is displayed.
Displayed time is the sum of
normal drying time and end time.
Changing the end time
If you want to change the duration during the
countdown:
• Press the On/Off/Cancel button for 3
seconds to cancel the program. Turn on
the machine again and repeat the Delay
Setting process for the duration you wish.
• When your machine is turned on for the
first time, it turns on with the declaration
program (cotton wardrobe dry).
Operating the product
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
• Press the On/Off/Cancel button for 3
seconds to cancel the program.
• Press the On/Off/Cancel button to start
you previously selected program.
6.9 Starting the program
Press the Start/Stand-by button to start the
program.
Indicating start of the program, Start sym-
bol turns on, “:” separator in the middle of
remaining time keeps ashing. Program
Progress Symbol turns on.
6.10 Program progress status
6.11 Child Lock
The machine has a child lock which prevents
the program ow from being interrupted when
the buttons are pressed during a program. To
activate the child lock
• Press and hold time programs and audio
warning buttons for 3 seconds.
• When the child lock is activated, the lock
symbol on the screen turns on.
Dryer / User Manual28 / EN
Operating the product
• When the child lock is activated, all
buttons on the panel except the On/
Off/Cancel and Child Lock buttons are
deactivated.
• When the child lock is activated, indicator
symbols don’t change if the position of
Program Selection button is changed.
When Program Selection button is turned
and function buttons are pressed, the
letters “CL” flashes on the screen.
• The child lock has to be deactivated to
be able to start a new program after the
current program is finished or to be able
to interfere with the program.
To Deactivate The Child Lock:
• Press and hold the child lock button for 3
seconds.
• Child lock deactivates when the dryer is
turned off and on by the On/Off/Cancel
button.
6.12 Changing the program
after it is started
You can change the program you selected to
dry your laundry with a different program after
the machine starts running.
• For example, to select Extra Dry instead
of Iron Dry, pause the program by
pressing the Start / Stand-by button.
• Select the Extra Dry program using the
Program Selection button.
• Press the Start/Stand-by button to start
the program.
Adding and removing clothes during
stand-by
• If you want to add or remove clothes to/
from the machine after the drying program
starts:
• Press the Start/Stand-by button to put the
machine in Stand-by state. The drying
operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.
C
Adding laundry after the drying
operation starts may cause the
dried laundry inside the machine
to mix with wet laundry and leave
the laundry damp at the end of
operation.
C
Adding or removing laundry
during drying may be repeated as
many times as you wish. But this
operation continuously interrupts
the drying operation, and thus
increases program duration and
energy consumption. So, it is
recommended to add laundry
before the program starts.
C
If a new program is selected by
turning the program selection
knob while the machine is in
stand-by; the running program
terminates and new program
information is displayed on the
screen.
WARNING: Do not touch the
inner surface of the drum while
adding or removing clothes during
a continuing program. The drum
surface is hot.
Dryer / User Manual 29 / EN
6.13 Cancelling the program
If you want to cancel the program and termi-
nate the drying operation for any reason after
the machine starts running, keep the On/Off/
Cancel button pressed for 3 seconds.
A
WARNING: The inside of the
machine shall be extremely hot
when you cancel the program
during machine operation, so run
the ventilation program to allow it
to cool down.
6.14 End of programme
When the program ends, the Fibre Filter
Cleaning and Water Tank warning symbols
on the program observation indicator turn on.
Loading door may be opened and machine
becomes ready for another run.
To turn off the machine, press the On/Off/
Cancel button.
C
Wrinkle Prevention function
activates the 2 hour-Wrinkle
Prevention program if laundry
isn’t taken out of machine after
completion of the program.
C
Clean the fibre filter after each
drying. See 7.1 Cleaning Lint
Filter / Loading Door Inner
Surface
C
Empty the water tank after each
drying. See 7.3 Draining the water
tank
Operating the product
Dryer / User Manual30 / EN
7 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
7.1 Cleaning Lint Filter /
Loading Door Inner Surface
Lint and ber released from the laundry to the
air during the drying cycle are collected in the
Lint Filter.
C
Such ber and lint are generally
formed during wearing and wash-
ing.
A
Always clean the lint lter and the
inner surfaces of the loading door
after each drying process.
C
You can clean the lint lter hous-
ing with a vacuum cleaner.
To clean the lint lter:
• Open the loading door.
• Remove the lint filter by pulling it up and
open the lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
• A layer can build up on the filter pores
that can cause clogging of the filter after
using the dryer for a while. Wash the lint
filter with warm water to remove the layer
that builds up on the lint filter surface.
Dry the lint filter completely before
reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
Dryer / User Manual 31 / EN
7.2 Cleaning the sensor
There are dampness sensors in the dryer that
detect whether the laundry is dry or not.
To clean the sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is still
hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
C
Clean metal surfaces of the sen-
sors 4 times a year.
C
Do not use metal tools when
cleaning metal surfaces of the
sensors.
A
Never use solvents, cleaning
agents or similar substances for
cleaning due to the risk of re and
explosion!
7.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the wa-
ter that arise accumulates in the water tank.
Drain the water tank after each drying cycle.
A
Condensed water is not drinkable!
A
Never remove the water tank
when the program is running!
If you forget to drain the water tank, the ma-
chine will stop during the subsequent drying
cycles when the water tank is full and the
Water Tank warning symbol will ash. If this
is the case, drain the water tank and press
Start / Pause button to resume the drying
cycle.
To drain the water tank:
Pull the drawer and remove the water tank
carefully.
• Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
C
If the direct water draining is used
as an option, there is no need to
empty the water tank.
Maintenance and cleaning
Dryer / User Manual32 / EN
7.4 Cleaning the filter drawer
Lint and ber that could not be captured by
the lint lter are blocked in the lter drawer
behind the kick plate. Clean the lter periodi-
cally when there is visible air collection on
it or when the symbol lights up, if there is a
lter drawer cleaning warning symbol «
»
available.
There is an one stage lter. This one stage
lter is from sponge
To clean the lter drawer:
• Press the kick plate button to open the
kick plate.
• Remove the filter drawer cover by turning
it in the direction of arrow.
• Pull out the filter drawer.
• Open the filter drawer by pressing the
red button.
• Take out the filter drawer sponge.
• Wash the filter drawer sponge by hand to
remove the fiber and lint on the surface.
After washing the sponge, squeeze it by
hand and remove the excess water. Well-
dry the sponge before storing it.
C
It is not necessary to clean the
sponge if lint and ber accumula-
tion on it is not signicant.
• Place the sponge back into its place.
C
Please place the sponge carefully
inside the frame of the lter cas-
sette shown by arrows in order
to avoid squeezing when lter
drawer closed”.:
Maintenance and cleaning
Dryer / User Manual 33 / EN
• Close the filter drawer as to lock the red
button.
• Place the filter drawer back into its place,
turn the filter drawer cover in the arrow
direction and close it securely.
• Close the kick plate cover.
A
Drying without the lter drawer
sponge in place will damage the
machine!
C
A dirty lint lter and lter drawer
will cause longer drying periods
and higher energy consumption.
7.5 Cleaning the evaporator
Clean the lint accumulated on the ns of the
evaporator located behind the lter drawer
with a vacuum cleaner.
A
You can also clean by hand pro-
vided that you wear protective
gloves. Do not attempt to clean
with bare hands. Evaporator ns
can harm your hand.
Maintenance and cleaning
Dryer / User Manual34 / EN
8 Troubleshooting
Drying process takes too much time.
• Pores of the lint filter are clogged. >>> Wash the lint filter with warm water.
• Filter drawer is clogged. >>> Clean the sponge and the filter cloth in the filter drawer.
• Ventilation grids on the front side of the machine are blocked. >>> Remove the objects
(if any) that block ventilation in front of the ventilation grids.
• Ventilation may not be sufficient since the room where the machine is installed is very
small. >>> Open the door and windows of the room to avoid the room temperature
increase too much.
• Lime deposit has built up on the dampness sensor.>>> Clean the dampness sensor.
• Excessive laundry was loaded in. >>> Do not overload the dryer.
• Laundry might not be spun sufficiently. >>> Spin your laundry at a higher speed in your
washing machine.
Laundry comes out wet at the end of drying.
• It is likely that the selected programme did not suit the laundry type. >>> Checking the
care labels on clothes, select appropriate programme for the laundry type or use timer
programmes in addition.
• Pores of the lint filter are clogged. >>> Wash the lint filter with warm water.
• Filter drawer is clogged. >>> Clean the sponge and the filter cloth in the filter drawer.
• Excessive laundry was loaded in. >>> Do not overload the dryer.
• Laundry might not be spun sufficiently. >>> Spin your laundry at a higher speed in your
washing machine.
Dryer does not switch on or the programme does not start. Dryer does not start when it is
set.
• It might have not been plugged in. >>> Make sure that the machine is plugged in.
• The loading door is ajar. >>> Make sure that the loading door is closed securely.
• The Start / Pause button is not pressed. >>> Make sure that the programme is not in
the Pause position.
• Childproof lock might have been activated. >>> Deactivate the Childproof Lock.
Programme is interrupted without any cause.
• The loading door might not be closed securely. >>> Push the loading door to close until
you hear a locking sound.
• A power failure might have occurred. >>> Press Start / Pause button to start the
program.
• Water tank may be full. >>> Drain the water tank.
Laundry has shrunk, become felted or deteriorated.
• A programme suitable for the laundry type might have not been used. >>> Check the
garment tag and select a programme suitable for the fabric type.
Water leaks from the loading door.
• Lint has accumulated on the inner surfaces of the loading door and on the surfaces
of the loading door gasket. >>> Clean the inner surfaces of the loading door and the
surfaces of the loading door gasket.
Loading door opens spontaneously.
• The loading door might not be closed securely. >>> Push the loading door to close until
you hear a locking sound.
• Excessive laundry was loaded in. >>> Do not overload the dryer.
Dryer / User Manual 35 / EN
Water Tank warning symbol is on/ashing.
• Water tank may be full. >>> Drain the water tank.
• Water draining hose might be bent.>>> If the product is connected directly to a
wastewater drain, check the water drain hose.
A
CAUTION: If you cannot eliminate the problem although you follow the instructions
in this section, consult your dealer or the Authorized Service Agent. Never try to
repair a nonfunctional product yourself.
Troubleshooting
Dryer / User Manual
36 / EN
Guarantee
De
tails
Your new Blomberg product is guaranteed against faulty materials, defective components or
manufacturing defects. The guarantee starts from the date of original purchase of the product
for a period of three (3) years, unless Beko plc (the “Manufacturer”) agrees to extend the
guarantee for the product in writing. If you have any questions about the guarantee on your
product (including how long it is valid), please contact your retailer or our Call Centre on 0333
207 9870.
This guarantee does not in any way diminish or affect your statutory rights in connection with
the product. This guarantee is in addition to your statutory rights as a consumer. If you have
any questions about these rights, please contact the retailer from which you purchased the
product. In certain circumstances, it is possible that your statutory rights may offer additional
or higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
Repairs to the product required as a result of faulty materials, defective components
or manufacturing defects.
Functional replacement parts to repair a product.
The costs of a Blomberg Approved Engineer to carry out the repair.
What is not covered?
Transit and delivery damage.
Cabinet or appearance parts, including but not limited to control knobs, flaps and
handles.
Accessories and/or consumable items including but not limited to ice trays, scrapers,
cutlery baskets, filters and light bulbs.
Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Blomberg Approved
Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the
requirements contained in this guarantee or the User Instructions Booklet.
Repairs to a product operated at any time on commercial or non-residential household
premises (unless we have previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law,
Beko plc (the “Manufacturer”) does not accept and will not be held liable for any financial loss
incurred in connection with the failure of any product to operate in accordance with the
expected standards. Such financial loss includes but is not limited to loss arising from:
Time taken off work.
Damaged food, clothing or other items.
Meals taken at restaurants or from takeaways.
Dryer / User Manual 37 / EN
General compensation for inconvenience.
Important Notes
Your product is designed and built for domestic household use only.
The guarantee will automatically be void if the product is installed or is used in
commercial or non-residential domestic household premises, unless we have
previously agreed to the installation environment.
The product must be correctly installed, located and operated in accordance with the
instructions contained in the User Instructions Booklet provided with your product.
Professional installation by a qualified Electrical Domestic Appliance Installer is
recommended for all Washing Machines, Dishwashers and Electric Cookers (as
incorrect installation may result in you having to pay for the cost of repairing the
product).
Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland
for Republic of Ireland) registered gas installer.
This guarantee is given in respect of products purchased and used within the United
Kingdom and the Republic of Ireland.
This guarantee is effective from the initial date of purchase of a new product from an
authorised retailer and will be void if the product is resold.
This guarantee does not apply to graded sales (where the product is purchased as a
“second”).
Possession of a copy of these terms and conditions does not necessarily mean that a
product has the benefit of this guarantee. If you have any questions, please call our
Call Centre on the number set out above.
The Manufacturer reserves the right to terminate the guarantee if its staff or
representatives are subjected to physical or verbal abuse in the course of carrying out
their duties.
Optional extras, where available (i.e. extendable feet) are supplied on a chargeable
basis only.
Does Blomberg offer replacements?
This is a repair-only guarantee. On occasion the Manufacturer may at its sole discretion,
replace your product with a new product instead of carrying out a repair. Where a replacement
is offered, this would normally be an identical model, but when this is not possible, a model of
similar specification will be provided. The Manufacturer will cover the costs and arrange for
the delivery of the new product and for the return of the old product. Any costs related to
disconnecting the faulty product and installing the replacement product will not be borne by
the Manufacturer unless previously agreed to in writing. The original guarantee will continue
to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours
may be possible at the sole discretion of the Manufacturer but cannot be guaranteed. Whilst
our Engineers will endeavour to minimize inconvenience and to meet requests for specific
timed appointments, this cannot be guaranteed. The Manufacturer will not be liable for delays
or if it is unable to carry out a repair because a convenient appointment cannot be arranged.
Dryer / User Manual
38 / EN
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this
guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the
reasonable cost of any service call if:
You cannot provide evidence that your product is covered by this guarantee.
Where a service call has been made and the engineer finds that there is no fault with
your product.
That your product has not been installed or operated in accordance with the User
Instructions Booklet.
That the fault was caused by something other than faulty materials, defective
components or manufacturing defects.
For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice.
If you fail to pay the costs for the service call in a timely manner, the Manufacturer reserves
the right to terminate the guarantee.
If you are a resident of the United Kingdom, this guarantee will be governed by English law
and subject to the English Courts, save where you live in another part of the United Kingdom,
in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and
the Irish courts will have jurisdiction.
HOW TO OBTAIN SERVICE
Please keep your purchase receipt or other proof of purchase in a safe place; you will need to
have it should the product require attention under guarantee.
It will be useful if you complete the details below, as it will help us assist you when requesting
service. (The model number is printed on the Instruction Booklet and the serial number is
printed on the Rating Label affixed to the appliance). Recording of these details alone will not
count as proof of purchase. A valid proof of purchase is required for under guarantee service.
The area around the product must be easily accessible to the Engineer without the need for
cabinets or furniture being removed.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry
out any repairs.
…………………………………………………………………………………………………………
Model No:
Serial No:
Retailer:
Date of purchase:
…………………………………………………………………………………………………………..
For service under guarantee simply telephone the appropriate number below
Dryer / User Manual 39 / EN
UK Mainland & Northern Ireland: 0333 207 9870.
Republic of Ireland: 01 691 0160
Register your appliance at www.blomberguk.com/register
Before requesting service please check the troubleshooting guide in the Operating Instructions
as a charge may be levied where no fault is found even though your product may still be under
guarantee.
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within
the extended guarantee agreement document, otherwise please call the appropriate number
above where service can be obtained at a charge.
Should you experience any difficulty in obtaining service contact the Blomberg Customer
Helpline on Tel: 0333 207 9870 or e-mail: [email protected]berguk.com
……………………………………………………………............ ........ ......... ........ ........ ......... ........ ..
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Herts,
WD18 8QU. Beko plc is registered in England and Wales with company registration number
02415578.
(4) Scale from G (lest efficient) to A (most efficient)
(5) Weighted average value — L
WA
expressed in dB(A) re 1 pW
(1) Scale from A+++ (most efficient) to D (least efficient)
(2) Energy consumption based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of
the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
(3) "Cotton cupboard dry programme" used at full and partial load is the standard drying programme to which the information in the
label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient
programme in terms of energy consumption for cotton
: Yes - : No
Supplier name or trademark
Model name
Rated capacity (kg)
Type of Tumble Dryer
Condenser
Air Vented
Energy efficiency class
(1)
Annual Energy Consumption (kWh)
(2)
Type of Control
Energy consumption of the standard cotton programme at full load (kWh)
Energy consumption of the standard cotton programme at partial load (kWh)
Power consumption of the off-mode for the standart cotton programme at full load, P
O
(W)
Power consumption of the left-on mode for the standart cotton programme at full load, P
L
(W)
The duration of the left on mode (min)
Standard cotton programme
(3)
Programme time of the standard cotton programme at full load, T
dry
(min)
Programme time of the standard
cotton programme at partial load, T
dry1/2
(min)
Weighted programme time of the standard cotton programme at full and partial load (T
t
)
Condensation efficiency class
(4)
Average condensation efficiency of the standard cotton programme at full load, C
dry
Average condensation efficiency of the standard cotton programme at partial load, C
dry1/2
Weighted condensation efficiency of the standard cotton programme at full load and partial load, C
t
Sound power level for the standard cotton programme at full load
(5)
Built-in
PRODUCT FICHE
Complying Commission Delegated Regulation (EU) No 392/2012
Non-automatic
Automatic
-
66
A+++
176
-
1,43
0,84
0,1
1,0
30
A
91%
91%
91%
8
-
152
95
119
Blomberg
LTH3842W
