User Manual Philips SMP3700/3800 Speechmike Premium Touch Dictation Microphone

You need to download and install the free Philips SpeechControl driver and configuration software (Philips Device Control Center).
To find the software:
1.search for SMP4000 or SMP4010 in the search bar.
2. Select your product.
You will be forwarded to the product page.
3.On the product page, go to the "Support" tab. You will find the software in the" Software and drivers" section.

ISO files are a common way to distribute software that would previously have required a CD or DVD.

In Windows 8 and also Windows 10 you can simply double-click an ISO file to mount it as a virtual CD/DVD drive.

That virtual drive shows up in File Explorer with its own drive letter, and it acts just like a CD or DVD. You can copy files from the virtual DVD to any other storage medium for example local hard drive or network folder.

The software ISO file contains installation media, so you can run the setup directly, without additional step of extracting files.

The easiest way to mount an ISO image is by double-clicking the ISO file.
You can also right-click the .iso file and click the Mount option.
Alternatively, you can open File Explorer, select .iso file, and from the Manage tab, click the Mount button.
Once you mounted ISO File, you can start with the installation process.
Once you're done with the installation, you can quickly unmount (eject) the software by right-clicking the virtual drive

Requirement: The Philips SpeechControl application need to be installed on the Computer.

To upgrade the firmware, do the following:

Download ZIP file with the firmware software from the webpage
Before you start with the next step, unzip the file.
Launch SpeechControl application.
On the “Device” - “Firmware upgrade” page, click “Import” and select the folder which contains the firmware to be imported.
Browse for the target folder with the firmware and click on OK
Select the firmware version from the Available firmware versions dialog and click Upgrade
Confirm the firmware upgrade by clicking - Yes, upgrade the device. The Firmware upgrade dialog is displayed: the upgrade process can be followed on a progress bar. The device is ready to use again after the dialog is getting closed
