WARNING
To reduce the risk of re or electric shock,
do not expose this apparatus to rain or
moisture.
To reduce the risk of re, do not cover the
ventilation opening of the apparatus with
newspapers, tablecloths, curtains, etc.
Do not place the naked ame sources such
as lighted candles on the apparatus.
To reduce the risk of re or electric shock,
do not expose this apparatus to dripping
or splashing, and do not place objects
lled with liquids, such as vases, on the
apparatus.
As the main plug is used to disconnect
the unit from the mains, connect the unit
to an easily accessible AC outlet. Should
you notice an abnormality in the unit,
disconnect the main plug from the AC
outlet immediately.
Do not install the appliance in a conned
space, such as a bookcase or built-in
cabinet.
Do not expose batteries or apparatus with
battery-installed to excessive heat such as
sunshine, re or the like.
e unit is not disconnected from the
mains as long as it is connected to the
AC outlet, even if the unit itself has been
turned o.
Excessive sound pressure from earphones
and headphones can cause hearing loss.
CAUTION
e use of optical instruments with this
product will increase eye hazard.
is appliance is classied as a CLASS 1
LASER product. is marking is located
on the rear exterior.
Notice for customers: the following
information is only applicable
to equipment sold in countries
applying EU directives.
e manufacturer of this product is Sony
Corporation, 1-7-1 Konan Minato-ku,
Tokyo, 108-0075 Japan. e Authorized
Representative for EMC and product safety
is Sony Deutschland GmbH, Hedelnger
Strasse 61, 70327 Stuttgart, Germany. For
any service or guarantee matters, please
refer to the addresses given in separate
service or guarantee documents.
is symbol is intended
to alert the user to the
presence of uninsulated
“dangerous voltage”
within the product’s
enclosure that may be
of sucient magnitude
to constitute a risk
of electric shock to
persons.
is symbol is intended
to alert the user to the
presence of important
operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
3
GB
Owner’s Record
e model and serial numbers are located
on the rear of the unit. Record these
numbers in the space provided below.
Refer to them whenever you call upon
your Sony dealer regarding this product.
M
o
del No.
Ser
ial No.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) D
o not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
ampliers) that produce heat.
9)
D
o not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. e wide blade or
the third prong are provided for your
safety. If the provided plug does not t
into your outlet, consult an electrician
for replacement of the obsolete outlet.
10)
P
rotect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
11)
On
ly use attachments/accessories
specied by the manufacturer.
12) U
se only with the cart,
stand, tripod, bracket,
or table specied by
the manufacturer,
or sold with the
apparatus. When
a cart is used, use
caution when moving
the cart/apparatus
combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long
periods of time.
14) R
efer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to
rain or moisture, does not operate
normally, or has been dropped.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
4
GB
The following FCC statement applies
only to the version of this model
manufactured for sale in the U.S.A.
Other versions may not comply with
FCC technical regulations.
NOTE:
is equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. ese limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. is equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications. However, there
is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment o and on,
the user is encouraged to try to correct
the interference by one or more of the
following measures:
Reorient or relocate the receiving
antenna.
I
ncrease the separation between the
e
quipment and receiver.
C
onnect the equipment into an
o
utlet on a circuit dierent from that
to which the receiver is connected.
C
onsult the dealer or an experienced
radio/T
V technician for help.
CAUTION
You are cautioned that any changes or
modications not expressly approved in
this manual could void your authority to
operate this equipment.
Disposal of Old
Electrical & Electronic
Equipment
(Applicable in the
European Union
and other European
countries with
separate collection
systems)
is symbol on the product or on its
packaging indicates that this product
shall not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product
is disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. e recycling of materials will
help to conserve natural resources. For
more detailed information about recycling
of this product, please contact your
local Civic Oce, your household waste
disposal service or the shop where you
purchased the product.
Applicable accessories: Remote
commander
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
5
GB
Disposal of waste
batteries (applicable
in the European Union
and other European
countries with
separate collection
systems)
is symbol on the battery or on the
packaging indicates that the battery
provided with this product shall not be
treated as household waste. On certain
batteries this symbol might be used in
combination with a chemical symbol.
e chemical symbols for mercury (Hg)
or lead (Pb) are added if the battery
contains more than 0.0005% mercury or
0.004% lead. By ensuring these batteries
are disposed of correctly, you will help
prevent potentially negative consequences
for the environment and human health
which could otherwise be caused by
inappropriate waste handling of the
battery. e recycling of the materials will
help to conserve natural resources.
In case of products that for safety,
performance or data integrity reasons
require a permanent connection with an
incorporated battery, this battery should
be replaced by qualied service sta only.
To ensure that the battery will be treated
properly, hand over the product at end-of-
life to the applicable collection point for
the recycling of electrical and electronic
equipment.
For all other batteries, please view the
section on how to remove the battery from
the product safely. Hand the battery over
to the applicable collection point for the
recycling of waste batteries.
For more detailed information about
recycling of this product or battery, please
contact your local Civic Oce, your
household waste disposal service or the
shop where you purchased the product.
About this manual
e instructions in this manual are
for models MHC-GZR33Di and LBT-
LCD7Di. Each model consists of the
following components.
MHC-GZR33Di
Main unit:
HCD-GZR33D
Speaker system:
SS-GZR77D (Front speakers)
LBT-LCD7Di
Ma
in unit:
HCD-LCD7Di
Speaker system:
SS-LCD7Di (Front speakers)
In this manual, the MHC-GZR33Di is
used for illustration purposes unless
stated otherwise.
Icons, such as
, listed at the top
of each explanation indicate what kind
of media can be used with the function
being explained.
e Control Menu items may be
di
erent depending on the disc.
e Control Menu items may vary
dep
ending on the area.
e Setup Menu items may be dierent
dep
ending on the area.
e order of the displayed items may
b
e dierent from the actual display.
DivX video les can only be played
b
ack on MHC-GZR33Di.
MPEG4 video les can only be played
b
ack on MHC-GZR33Di. However,
you can view any video les (including
MPEG4 video les) on LBT-LCD7Di,
when les are stored in your iPod.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
6
GB
Table of Contents
iPod
Playing the iPod ..................................67
USB Device
Before using the USB device with
this system ............................................74
Transferring music from a disc to a
USB device ............................................75
Recording analog audio to a USB
device .....................................................80
Playing a le of the USB device .....81
Sound Adjustment
Adjusting the sound .........................89
Singing along: Karaoke ....................92
Other Operations
Using the timers .................................97
Changing the display .......................99
Hooking up optional
components ...................................... 104
About this manual ...............................5
Playable discs ........................................ 8
Guide to parts and controls ...........11
Getting Started
Hooking up the system
securely ..................................................23
Hooking up the TV.............................27
Setting the LCD ...................................31
Setting the clock ................................32
Performing “QUICK” setup ..............33
Using the “THEATRE SYNC”
function .................................................35
Disc
Playing a disc .......................................36
Using play mode ................................44
Restricting playback of the disc
(PARENTAL CONTROL) ......................56
Using the Setup Menu .....................58
Tuner
Listening to the radio .......................64
Using the Radio Data System (RDS)
(European model only) ....................66
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
7
GB
Additional Information
Troubleshooting .............................. 107
Precautions ........................................ 124
Specications ................................... 126
Compatible devices with this
system ................................................. 130
Compatible iPod models with this
system ................................................. 132
Guide to the Control Menu
display ................................................. 133
Playback priority of le types ..... 137
Language code list ......................... 138
Glossary .............................................. 140
Index .................................................... 144
License and Trademark Notice ... 146
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
8
GB
Playable discs
Type Disc logo Characteristics Icon
DVD VIDEO
DVD VIDEO
DVD-R/DVD-RW in DVD
VIDEO format or video mode
DVD+R/DVD+RW in DVD
VIDEO format
VR (Video
Recording)
mode
DVD-R/DVD-RW in VR (Video
Recording) mode (except for
DVD-R DL)
VIDEO CD
VIDEO CD (Ver. 1.1 and 2.0
discs)
Super VCD
CD-R/CD-RW/CD-ROM in
video CD format or Super VCD
format
CD
Audio CD
CD-R/CD-RW in audio CD
format
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
9
GB
Type Disc logo Characteristics Icon
DATA CD
CD-R/CD-RW/CD-ROM in
DATA CD format, containing
MP3 les, JPEG image les,
DivX video les and MPEG4
video les, and conforming to
ISO 9660 Level 1/Level 2, or
Joliet (extended format)
DATA DVD
DVD-ROM/DVD-R/DVD-RW/
DVD+R/DVD+RW in DATA
DVD format, containing MP3
les, JPEG image les, DivX
video les and MPEG4 video
les, and conforming to UDF
(Universal Disk Format)
MP3 les: MP3 (MPEG 1 Audio Layer 3) is a standard format dened by ISO/MPEG which
compresses audio data. MP3 les must be in MPEG 1 Audio Layer 3 format.
JPEG image les: JPEG image les must conform to the DCF image le format (DCF “Design rule
for Camera File System”: Image standards for digital cameras regulated by “Japan Electronics and
Information Technology Industries Association” (JEITA)).
DivX video les: DivX video les must be recorded in DivX format with the extension “.avi” or
“.divx” (MHC-GZR33Di only).
MPEG4 video les: MPEG4 video les must be recorded in MP4 le format with the extension
“.mp4” or “.m4v” (MHC-GZR33Di only).
ISO 9660: A logical format of les and folders on CD-ROMs, dened by ISO (International
Organization for Standardization).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
10
GB
Discs that cannot be played
CD-ROMs recorded in PHOTO CD
format
DATA CDs recorded in MP3 PRO
f
ormat
Data part of CD-Extras
1)
Data part of Mixed CDs
2)
Super Audio CDs
DVD Audio discs
DVD-RAMs
CPRM compatible DVD-R/RW
r
ecorded in Copy-once programs
3)
Discs of non-standard shape (for
example, heart, square, star)
Discs that have adhesive tape, paper, or
s
ticker attached to them
Rental or used discs with attached seals
w
here the glue extends beyond the seal
Discs that have labels printed using ink
t
hat feels tacky when touched
1)
CD-Extra: is format records audio
(AUDIO CD data) on the tracks in session 1
and data on the tracks in session 2.
2)
Mixed CD: is format records data on the
rst track and audio (AUDIO CD data)
on the second and subsequent tracks of a
session.
3)
CPRM: “Content Protection for Recordable
Media” is a coding technology that protects
copyright for Copy-Once programs.
See “Region code of DVD VIDEOs you
can play back on this system” and “Notes
on discs” (page 124) regarding the region
code and notes on discs.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
11
GB
Guide to parts and controls
Guide to parts and controls
is manual mainly explains operations using the remote, but the same operations can
also be performed using the buttons on the unit having the same or similar names.
Main unit
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
12
GB
(on/standby) button
(page 76, 80, 84, 98)
Press to turn on or o the system.
STANDBY indicator (page 107)
Lights up when the system is turned o.
Display
iPod Dock (page 26)
Place an iPod into the iPod Dock to listen
to audio contents stored in the iPod.
LCD DISPLAY ON/OFF button
Press to turn on or o the front panel
display.
/// buttons (page 37, 50,
77, 78, 83)
Press to select the menu items.
DVD TOP MENU button (page 37)
Press to display the DVD title on the TV
screen.
DVD/TUNER MENU button
(page 40, 49, 53, 65, 82)
Press to turn on or o the menu items on
the TV screen.
Press to preset the radio station.
ENTER button (page 29, 30, 32,
33, 34, 41, 42, 43, 44, 45, 46, 47,
49, 50, 52, 53, 54, 55, 56, 57, 58,
64, 65, 68, 70, 71, 76, 77, 78, 80,
82, 83, 85, 86, 87, 90, 94, 96, 97,
98, 100)
Press to enter the settings.
DISPLAY button (page 29, 34,
42, 43, 44, 46, 47, 49, 52, 53, 54,
55, 56, 58, 76, 82, 85, 86, 94, 95,
104)
Press to turn on or o the Control Menu
on the TV screen.
e Control Menu is displayed only
when the “DVD” function or “USB”
function is selected.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
13
GB
Guide to parts and controls
CLEAR button (page 33, 43, 44,
45, 47, 48, 51, 63, 78, 84, 86, 87)
Press to delete a pre-programmed track
or le.
Press to erase les or folders from the
connected optional USB device.
RETURN button
Press to return to the previous menu on
the TV screen.
* (play) button (page 26, 36,
37, 41, 42, 45, 47, 48, 49, 50, 53,
58, 82, 83, 87)
Press to start playback.
* (pause) button (page 28, 37,
68, 71)
Press to pause playback.
(stop) button (page 37, 42, 49,
50, 53, 64, 68, 71, 76, 78, 80, 82,
83, 84, 106)
Press to stop playback.
/ (rewind/fast forward)
button (page 37, 68, 71)
Press to nd a point in a track, le,
chapter or video le.
/ button (page 37)
Press to watch the slow-motion play.
TUNING +/ button (page 64)
Press to tune in the desired station.
REC TO USB button (page 76, 80)
Press to transfer music from a disc or
record the sound from an analog audio
source to the connected USB device.
Press to mark track numbers during
recording.
OPEN/CLOSE button
Press to load or eject a disc.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
14
GB
OPERATION DIAL (page 37, 65)
Turn to select a track, chapter or video
le.
Turn to select the preset station.
DISC 1 DISC 3* buttons
(page 38, 76)
Press to select a disc.
Press to switch to the “DVD” function
from other function.
Lights up when a disc is in the disc tray,
and ashes when the disc tray is selected.
Disc tray
MIC 2 jack (page 92)
Connect a microphone.
MIC 2 LEVEL (page 92)
Turn to adjust the microphone volume.
ECHO LEVEL (page 93)
Turn to adjust the echo level.
(USB) port (page 75, 78, 80, 81)
Connect an optional USB device.
(USB) indicator
Lights up in blue when the system is
turned on.
Lights up in red when transferring or
recording to the connected optional USB
device or when erasing audio les or
folders.
MIC 1 jack (page 92)
Connect a microphone.
MIC 1 LEVEL (page 92)
Turn to adjust the microphone volume.
PHONES jack
Connect the headphones.
OPTIONS button (page 30, 100)
Press to enter the option menus.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
15
GB
Guide to parts and controls
DISC SKIP/EX-CHANGE button
(page 36)
Press to select a disc.
Press to exchange a disc while playing.
GROOVE button (page 89)
Press to reinforce the bass.
PRESET EQ button (page 89)
Press to select the sound eect.
EQ BAND/MEMORY button
(page 90)
Press to select the frequency band when
adjusting the equalizer.
SOUND FIELD button (page 91)
Press to select the sound eld for the
surround sound.
DVD* button (page 26, 29, 33, 36,
76, 92)
Press to select the “DVD” function.
USB* button (page 78, 81, 92)
Press to select the “USB” function.
iPod/OPR* button (page 68, 69)
Press to select the “iPod” function.
Press to switch the operating mode to
iPod Display mode or Main Display
mode.
TUNER/BAND* button (page 64)
Press to select the “TUNER” function.
Press to switch among FM and AM band.
VIDEO/SAT* button (page 106)
Press to select the “VIDEO” or “SAT”
function.
Remote sensor (page 108)
DISPLAY button (page 28, 32, 99,
100)
Press to display the disc information or
clock in the front panel display.
MASTER VOLUME
Turn to adjust the volume.
* Lights up when selected.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
16
GB
Remote
(on/standby) button
(page 32, 76, 80, 84, 98)
Press to turn on or o the system.
TV
1)
(on/standby) button
(page 30)
Press to turn on or o the TV.
DISC SKIP button (page 38, 76)
Press to select a disc.
FUNCTION +/ button (page 28,
29, 33, 36, 64, 67, 68, 69, 76, 78,
80, 81, 92, 106)
Press to select the function.
PICTURE NAVI button (page 50,
83)
Press to display the thumbnail pictures.
REPEAT/FM MODE button
(page 48)
Press to listen to a disc, a USB device, a
single track or le repeatedly.
Press to select FM reception mode
(monaural or stereo).
AUDIO button (page 40, 92, 103)
Press to select the desired audio signal on
the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
17
GB
Guide to parts and controls
Continued
SUBTITLE button (page 38)
Press to switch the language of the
subtitle (DVD VIDEO only).
D. TUNING button (page 64)
Press to switch to the direct tuning mode.
MEMORY SELECT button
(page 87, 88)
Press to select the playback source
or transferring destination on a Sony
Ericsson mobile phone.
ANGLE button (page 38)
Press to change the angle (DVD VIDEO
with multi-angles only).
+/ button (page 37)
Press to select a folder.
DVD/TUNER MENU button
(page 40, 49, 53, 65, 82)
Press to turn on or o the menu items on
the TV screen.
Press to preset the radio station.
SOUND FIELD button (page 91)
Press to select the sound eld for the
surround sound.
VOLUME +/
2)
button
Press to adjust the volume.
TV VOL +/
1)2)
button
Press to adjust the TV volume.
DISPLAY button (page 29, 34,
42, 43, 44, 46, 47, 49, 52, 53, 54,
55, 56, 58, 76, 82, 85, 86, 94, 95,
104)
Press to turn on or o the Control Menu
on the TV screen.
e Control Menu is displayed only
when the “DVD” function or “USB”
function is selected.
PRESET + button (page 65)
Press to select the preset station.
(go forward) button
(page 35, 37, 42, 51, 68, 71, 84,
100)
Press to select a track, chapter or video
le.
TV CH +
1)
button (page 30)
Press to change the TV channels.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
18
GB
2)
(play) button (page 36, 37,
41, 42, 45, 47, 48, 49, 50, 53, 58,
68, 71, 82, 83, 87)
Press to start playback.
/ (rewind/fast forward)
button (page 37, 68, 71)
Press to nd a point in a track, le,
chapter or video le.
SLOW/SLOW button
(page 37)
Press to watch the slow-motion play.
(pause) button (page 28, 37,
68, 71)
Press to pause playback.
(stop) button (page 37, 42, 49,
50, 53, 64, 68, 71, 76, 78, 80, 82,
83, 84, 106)
Press to stop playback.
TUNING +/ button (page 64)
Press to tune in the desired station.
TV
1)
button (page 30)
Press to operate the TV functions.
PRESET button (page 65)
Press to select the preset station.
(go backward) button
(page 34, 37, 42, 68, 71, 100)
Press to select a track, chapter or video
le.
TV CH
1)
button (page 30)
Press to change the TV channels.
STEP button (page 37)
Press to play one frame at a time when
playback is paused.
ADVANCE button (page 38)
Press to advance the current scene during
playback.
REPLAY button (page 38)
Press to replay the previous scene during
playback.
RETURN button (page 51, 78,
84)
Press to return to the previous menu on
the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
19
GB
Guide to parts and controls
Continued
ENTER button (page 29, 30, 32,
33, 34, 41, 42, 43, 44, 45, 46, 47,
49, 50, 52, 53, 54, 55, 56, 57, 58,
64, 65, 68, 70, 71, 76, 77, 78, 80,
82, 83, 85, 86, 87, 90, 94, 96, 97,
98, 100)
Press to enter the settings.
/// buttons (page 37, 50,
77, 78, 83)
Press to select the menu items.
DVD TOP MENU button (page 37)
Press to display the DVD title on the TV
screen.
CLEAR button (page 33, 43, 44,
45, 47, 48, 51, 63, 78, 84, 86, 87)
Press to delete a pre-programmed track
or le.
Press to erase audio les or folders from
the connected optional USB device.
-/--
1)
button (page 30)
Press to enter a single digit or double
digit number.
Numeric buttons
2)
(page 30, 37,
41, 42, 43, 44, 56, 57, 58, 64, 65)
Press to select a track, chapter or video
le.
Press to enter a password.
10/0
1)
button
Press to enter a double digit number.
KEY CONTROL button
(page 93)
Press to change the key to suit your vocal
range.
SCORE button (page 96)
Press to start or stop calculating your
vocal score.
KARAOKE MODE button
(page 93)
Press to select the Karaoke mode.
KARAOKE PON button (page 94)
Press to activate the “Karaoke Pon”
function.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
20
GB
DISPLAY button (page 28, 32, 99,
100)
Press to display the disc information or
clock in the front panel display.
TIME/TEXT button (page 100,
101, 102)
Press to change the information
appearing in the front panel display or on
the TV screen.
TV INPUT
1)
button
Press to switch the input sources.
SLEEP button (page 35, 97)
Press to set the Sleep Timer.
TIMER MENU button (page 32,
97, 98)
Press to set the clock and the timers.
THEATRE SYNC button (page 35)
Press to activate the “THEATRE SYNC”
function.
1)
is button is used to operate a Sony TV. For
details, see “Operating a Sony TV” (page 31).
2)
e numeric button 5, TV VOL +,
VOLUME + and buttons on the remote
have a tactile dot. Use the tactile dot as a
reference when operating the system.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
21
GB
Guide to parts and controls
Indicators
TIMER indicator (page 97)
Lights up when the Play Timer or Rec
Timer is set, and ashes when the Sleep
Timer is set.
Dolby D (Dolby Digital) indicator
(page 140)
DTS indicator (page 140)
Indicates the current surround format.
Continued
USB MEMORY indicator (page 75)
Lights up when the USB device is
recognized.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
22
GB
Display
e front panel display for MHC-GZR33Di and LBT-LCD7Di are liquid crystal displays
(LCD). You can conrm contents and the Control Menu displayed on the TV screen in
the LCD.
To set the LCD, see “Setting the LCD” (page 31).
Displays the text information. You can conrm contents and the
C
ontrol Menu displayed on the TV
screen.
PICTURE MODE and WIDE MODE
menus are displayed when setting the
LCD.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
23
GB
Getting Started
Getting Started
Hooking up the system securely
To front speaker (Right)
AM loop antenna
FM lead antenna (Extend it horizontally.)
To front speaker (Left)
To wall outlet
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
24
GB
FM/AM antennas
Find a location and an orientation that
provide good reception, and then set up
the antenna.
Keep the antennas away from the speaker
cords, the power cord and the USB cable
to avoid picking up noise.
Speakers
Insert only the stripped portion of the
speaker cords.
e speaker cords are color-coded with
their respective speaker terminals.
e type of speakers supplied varies
according to the model you purchased
(see “About this manual” (page 5)).
Front speakers
Insert only the stripped
portion of the speaker cords
Black ()
Red ()
Note
Be sure to connect the speakers securely and
correctly.
Power
Connect the power cord to a wall outlet.
e demonstration appears in the display.
When you press /, the system turns
on and the demonstration automatically
ends.
If the supplied adaptor on the plug does
not t your wall outlet, detach it from the
plug (only for models equipped with an
adaptor).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
25
GB
Getting Started
Attaching the speaker foot
Attach the supplied speaker foot at each
corner on the bottom of the speakers to
prevent them from slipping.
Front speakers (Left (4)/Right (4))
Inserting batteries
Slide and remove the battery
compartment lid, and insert the two
supplied R6 (size AA) batteries, side
rst, matching the polarities shown
below.
Note
If you do not use the remote for a long period
of time, remove the batteries to avoid possible
damage from battery leakage and corrosion.
Tip
With normal use, the batteries should last for
about six months. When the remote no longer
operates the system, replace both batteries with
new ones.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
26
GB
When carrying this system
Perform the following procedure to
protect the DVD mechanism.
Use buttons on the unit for the operation.
1
Press / to turn on the system,
then press DVD.
2
Make sure that no disc is loaded
in the system and check that
“NO DISC” appears.
3
Hold down , and then press
/ until “STANDBY” appears
in the display. Then, “LOCK”
appears in the display.
4
Unplug the power cord.
Using the iPod
Insert an iPod Dock Adapter into the
Dock before use. e iPod Dock Adapter
is not supplied with the system. Use
an iPod Dock Adapter supplied with
your iPod. For details on the iPod Dock
Adapter, refer to the user’s guide of your
iPod.
To remove the iPod Dock
Adapter, pull it up with your
ngernail or a at object using
the slot inside the adapter.
iPod Dock Adapter
Connector
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
27
GB
Getting Started
Hooking up the TV
Connect the video input jack of your
TV to the VIDEO OUT jack with the
supplied video cord.
When connecting a video deck
Connect the video deck to the TV using
a video cord (not supplied). However, do
not connect this unit to the TV through
the video deck. Otherwise, you may
experience video leakage when watching
video images from this system. Connect
this unit directly to the TV as shown
below.
TV
UnitVideo deck
Do not connect
directly
When connecting to the COMPONENT
VIDEO OUT jack
For higher quality video images,
use the optional component video
cords to connect the COMPONENT
VIDEO input jacks on your TV to the
COMPONENT VIDEO OUT jacks
of this unit (page 105). If your TV is
compatible with progressive format
signals, use this connection and set
“PROGRESSIVE (COMPONENT
OUT)” to “ON” (page 30).
Notes
You cannot output the video signal from the
VIDEO/SAT VIDEO IN jack through the
COMPONENT VIDEO OUT jacks of this
unit.
You cannot output the video signal from an
iP
od through the COMPONENT VIDEO
OUT jacks of this unit.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
28
GB
5
Press / on the unit while holding
down on the unit.
e system turns on automatically and
the color system is changed.
“COLOR NTSC” or “COLOR PAL” (or
either “iPod COLOR NTSC” or “iPod
COLOR PAL”) appears in the display.
Note
You cannot change the color system for any
optional component connected to the VIDEO/
SAT VIDEO IN jack.
Changing the color system
(Australian model only)
Set the color system of the DVD and
your iPod to PAL or NTSC depending on
the color system of your TV.
e default setting for color system is
dierent depending on the area.
Each time you perform the procedure
below, the color system changes as
follows:
NTSC
PAL
1
Press / to turn on the system.
2
Select the function.
For DVD color system:
Press FUNCTION +/ repeatedly to
select “DVD” (or press DVD on the
unit).
For iPod color system:
Press FUNCTION +/ repeatedly to
select “iPod” (or press iPod/OPR on
the unit).
3
Press / to turn o the system.
4
Press DISPLAY repeatedly until “Sony
DEMO” appears in the display.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
29
GB
Getting Started
Changing the format of the
video signal output from
COMPONENT VIDEO OUT jacks
Progressive is a method for displaying
TV images that reduces ickering and
sharpens the image. To use this method,
you need to connect to a TV that can
accept progressive signals.
You can output video signals from
COMPONENT VIDEO OUT jacks in
Interlace or Progressive format.
1
Press FUNCTION +/ repeatedly
to select “DVD” (or press DVD on
the unit).
2
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
3
Press or repeatedly to
select
(SETUP), then press
ENTER.
e options for “SETUP” appear.
4
Press or repeatedly to select
“CUSTOM,” then press ENTER.
e Setup Menu appears.
5
Press or repeatedly to
select “VIDEO SETUP,” then press
ENTER.
e options for “VIDEO SETUP”
appear.
6
Press or repeatedly to select
“PROGRESSIVE (COMPONENT
OUT),” then press ENTER.
e options for “PROGRESSIVE
(COMPONENT OUT)” appear.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
30
GB
7
Press or repeatedly to select
the desired setting, then press
ENTER.
e default setting is underlined.
OFF: Outputs interlace signals.
Select this setting when:
your TV does not accept
progressive signals.
your TV is connected to jacks
other than the COMPONENT
VIDEO OUT jacks.
ON: Outputs progressive signals.
S
elect this setting when:
your TV accepts progressive
signals.
your TV is connected to the
COMPONENT VIDEO OUT
jacks.
When you select “ON,” the
conrmation display appears. Follow
the steps below.
8
Press or repeatedly to select
“START,” then press ENTER.
e system outputs the progressive
signal for 5 seconds. Check that the
screen is displayed correctly.
9
Press or repeatedly to select
“YES.”
e system outputs the progressive
signal. When you select “NO,”
the system does not output the
progressive signal.
Note
ere would be no image on your TV or the
image is not clear if your setting does not
match your TV or connection.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
31
GB
Getting Started
When using a TV
Turn on the TV and select the video
input so that you can view the pictures
from this system.
Operating a Sony TV
You can use the following buttons to
operate a Sony TV. ese buttons have
been marked in yellow.
To Press
Turn the TV on
or o
TV / while
holding down TV.
Switch the TV’s
input source
between the TV
and other input
sources
TV INPUT while
holding down TV.
Select the TV
channels
TV CH +/ or
numeric buttons*
while holding down
TV.
Adjust the
volume of the TV
speaker(s)
TV VOL +/ while
holding down TV.
* For double digit number, hold down TV
and press -/-- , then press the number. (For
example, hold down TV, press -/-- , then 2
and 5 for entering 25.)
Setting the LCD
You can make adjustments to pictures
displayed in the LCD.
Use buttons on the unit and conrm
operations in the LCD, for the following
settings.
Note
Playback settings stored in the disc take
priority over the LCD settings. erefore, some
of the LCD settings may not be performed.
1
Press OPTIONS on the unit
repeatedly until “PICTURE
MODE” or “WIDE MODE” appears
in the LCD.
2
Press
or
repeatedly to select
the desired setting, then press
ENTER.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
32
GB
Setting the clock
Use buttons on the remote to set the
clock.
1
Press / to turn on the system.
2
Press TIMER MENU.
e hour indication ashes in the
display.
If “PLAY SET?” ashes in the display,
press
or
repeatedly to select
“CLOCK SET?,” then press ENTER.
3
Press
or
repeatedly to set
the hour, and then press ENTER.
4
Use the same procedure to set
the minutes.
Note
e clock settings are canceled when you
disconnect the power cord or if a power failure
occurs.
To display the clock when the system
is o
Press DISPLAY repeatedly until the clock
is displayed.
e clock is displayed for about
8 seconds.
Setting the LCD
e default setting is underlined.
PICTURE MODE
Allows you to select options best suited
for videos and pictures, respectively.
STANDARD: For standard pictures.
Recommended for home entertainment.
VIVID: Enhances picture contrast and
sharpness.
CINEMA: For viewing lm-based
content.
PHOTO: For viewing photographs.
WIDE MODE
FULL: Select this when you view pictures
in a 16:9-format. is setting displays
pictures in full screen mode.
NORMAL: Select this when you view
pictures in a 4:3-format. is setting
displays a normal picture with bands on
the le and right portions of the screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
33
GB
Getting Started
Performing “QUICK”
setup
Before using the system, you can make
the minimum basic adjustments in
“QUICK” setup. If you do not want to
perform “QUICK” setup, press CLEAR in
step 3. e guide message will disappear
from the TV screen.
1
Turn on your TV and select the
video input*.
* is step is not required when using the
LCD for performing “QUICK” setup.
2
Press / to turn on the system.
Notes
Make sure there is no disc in the unit.
Otherwise, the guide message does not
appear.
Make sure that the headphones or
micr
ophones are not connected.
Otherwise, you cannot perform
“SPEAKER SETUP.”
3
Press FUNCTION +/ repeatedly
to select “DVD” (or press DVD on
the unit).
e guide message appears at the
bottom of the TV screen.
4
Press ENTER without loading a
disc.
“LANGUAGE SETUP” appears on
the TV screen.
5
Press
or
repeatedly to select
a language, then press ENTER.
e setting is selected and “VIDEO
SETUP” appears on the TV screen.
Tips
e selected language is for “OSD,”
“MENU” and “SUBTITLE .”
e selectable language is dierent
dep
ending on the area.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
34
GB
6
Press
or
repeatedly to select
the setting that matches your TV
type.
If you have a 4:3 standard TV:
Select “4:3 LETTER BOX” or “4:3
PAN SCAN” (page 60)
If you have a wide-screen TV or a
4:
3 standard TV with wide-screen
mode:
Select “16:9” (page 60)
7
Press ENTER.
e setting is selected and “QUICK
SETUP is complete.” appears on the
TV screen.
e system is ready for playback.
If you want to change each setting
individually, see “Using the Setup
Menu” (page 58).
If you make a mistake
Press , then select the item again.
To quit “QUICK” setup
Press DISPLAY.
To recall “QUICK” setup settings
1
Press DISPLAY when playback is
stopped.
e Control Menu appears on the TV
screen.
2
Press or repeatedly to select
(SETUP), then press ENTER.
3
Press or repeatedly to select
“QUICK,” then press ENTER.
Note
e guide message appears at the bottom of
the TV screen when you turn on the system
for the rst time or aer performing “RESET”
(pa
ge 120).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
35
GB
Getting Started
Using the “THEATRE
SYNC” function
THEATRE SYNC allows you to turn on
your Sony TV and this system, changes
the system’s function to “DVD” and then
switches the TV’s input source you have
set with just one button.
Preparing to use the “THEATRE
SYNC” function
Register the TV’s input source connected
to this system.
To select the TV’s input
Press the following buttons while holding
down SLEEP.
Press TV’s input source
0 No input source
(Default)
1 to 8 VIDEO 1 to VIDEO 8
9 COMPONENT 1
CLEAR COMPONENT 2
COMPONENT 3
+
COMPONENT 4
e selected TV’s input source is
memorized into the remote.
Operating the “THEATRE SYNC”
function
Keep the remote pointed in the
direction of the TV until the TV is
turned on and the input source
is changed correctly, then press
THEATRE SYNC.
If this function does not work, change the
transmission time. e transmission time
varies depending on the TV.
To change the transmission time
Press the following buttons while holding
down .
Press Transmission time
(seconds)
1 0.5 (Default)
2 1
3 1.5
4 2
5 2.5
6 3
7 3.5
8 4
Note
is function is only for Sony TV series,
however, some TV products may also not work.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
36
GB
Disc
Playing a disc
Depending on the DVD VIDEO or
VIDEO CD, some operations may
be dierent or restricted. Refer to the
operating instructions supplied with the
disc.
DivX and MPEG4 video les can only be
played back on MHC-GZR33Di.
Note on the maximum number of
tracks, les and folders on a DATA
CD/DVD
is system cannot play a DATA CD/
DVD in the following cases.
When the number of tracks or les on
a f
older exceeds 150.
When the number of folders on a disc
ex
ceeds 200.
ese numbers may vary depending on
the track structure, the le structure and
the folder structure.
1
Press FUNCTION +/ repeatedly
to select “DVD” (or press DVD on
the unit).
2
Press OPEN/CLOSE on the
unit.
3
Load a disc with the label side
facing up on the disc tray.
To load additional discs, press DISC
SKIP/EX-CHANGE on the unit to
rotate the disc tray.
When you play back an 8 cm disc such as a CD
single, place it on the inner circle of the tray.
4
Press OPEN/CLOSE on the
unit to close the disc tray.
Do not forcibly push the disc
tray to close it as this may cause a
malfunction.
If the playback does not start
automatically, press (or on
the unit).
5
Press VOLUME +/ (or turn
MASTER VOLUME on the unit) to
adjust the volume.
Note
Depending on the system status, the volume
level may not appear on the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
37
GB
Disc
Other operations
To Do this
Stop playback Press . To resume
playback where you
stopped the disc, press
(or on the
unit). To play back
from the beginning of
the disc, press twice,
then press (or
on the unit).
Pause playback Press
1)
. Press
again or press (or
on the unit) to
resume playback.
Select a track,
audio le,
chapter or
video le
2)
Press or
repeatedly (or turn
OPERATION DIAL
on the unit clockwise
or counterclockwise)
during playback.
Or, press the numeric
buttons when the
Control Menu is
turned o, then press
ENTER
3)
.
Select a title
4)
Press DVD TOP
MENU, then press
/// or numeric
buttons.
To Do this
Select a folder
5)
Press +/
repeatedly during
playback or when
playback is paused.
Locate a point
quickly in fast
forward or fast
reverse (Lock
Search)
6)
Press or
during playback.
Each time you press
or , the
playback speed changes
cyclically
7)
.
To return to normal
playback, press (or
on the unit).
Watch frame by
frame (Slow-
motion Play)
8)
Press SLOW
9)
or
SLOW (or either
9)
or on the
unit) when playback is
paused.
Each time you
press SLOW or
SLOW , the playback
speed changes.
To return to normal
playback, press (or
on the unit).
Play one
frame at a
time (Freeze
Frame)
8)
Press STEP
9)
or
STEP to reverse
or advance frame by
frame when playback is
paused.
Each time you press
STEP or STEP ,
the frame changes.
To return to normal
playback, press (or
on the unit).
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
38
GB
To Do this
Replay the
previous scene
(Instant
Replay)
10)
Press REPLAY
during playback.
Briey fast
forward the
current scene
(Instant
Advance)
10)
Press ADVANCE
during playback.
Change the
angle
11)
Press ANGLE
repeatedly during
playback. Each time
you press ANGLE, the
angle changes.
Display the
subtitle
Press SUBTITLE
repeatedly during
playback. Each time
you press SUBTITLE,
the subtitle language
changes
12)
or turns
o
13)
.
Select a disc Press DISC SKIP on
the remote (or one of
DISC 1 DISC 3 on
the unit).
Switch to DVD
function from
another source
Press one of DISC 1
DISC 3 on the unit
(Automatic Source
Selection).
Exchange other
discs while
playing
Press DISC SKIP/EX-
CHANGE on the unit.
1)
ere may be some disturbance in the video
image.
2)
Except for JPEG image les. You cannot
select an audio track or le during Lock
Search operation of MP3 les.
3)
DVD VIDEO, DVD-R/-RW in VR mode,
VIDEO CD, AUDIO CD and video les only.
4)
DVD VIDEO only.
5)
MP3 les, JPEG image les, DivX video les
and MPEG4 video les only.
6)
Except for JPEG image les.
7)
Depending on the disc, the actual speed may
dier.
8)
DVD VIDEO, DVD-R/-RW in VR mode,
video les and VIDEO CD only.
9)
Except for VIDEO CD and video les.
10)
DVD VIDEO and DVD-R/-RW in VR mode
only.
11)
Multi-angle DVD VIDEO only.
12)
For DVD VIDEO, DVD-R/-RW in VR
mode or DivX video les with multilingual
subtitles.
13)
For DVD VIDEO, DVD-R/-RW in VR mode
or DivX video les with subtitles.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
39
GB
Disc
Notes
You cannot perform resume playback during
Shue Play or Program Play.
Resume playback may not work properly
w
ith some discs.
Resume playback is canceled when
you press when playback is stopped.
you open the disc tray.
you change the function.
you change the settings in the Setup
M
enu.
you changed the “PARENTAL
C
ONTROL” level.
You cannot search for a still picture on a
D
VD-R/-RW in VR mode.
You may not be able to use the Instant Replay
o
r Instant Advance function in Repeat Play
mode or with some scenes.
Depending on the DVD VIDEO, you may
not be able to change the angle, even if multi-
angles are recorded on the DVD VIDEO.
Depending on the DVD VIDEO, you may
n
ot be able to change the subtitles even if
multilingual subtitles are recorded on the
DVD VIDEO. You also may not be able to
turn the subtitles o.
You can change the subtitles if the DivX
video le has an “.avi” or “.divx” extension
and contains subtitle information within the
same le.
On Multi-disc Resume
(DVD VIDEO and VIDEO CD only)
is system can store the point where
you stopped the playback of the disc
for up to 10 discs and resumes playback
when you insert the same disc again. If
you store a playback resume point for the
11th disc, the playback resume point for
the rst disc will be deleted.
e default setting is “ON.” To turn
o this function, set “MULTI-DISC
RESUME” in “SYSTEM SETUP” to
“OFF” (page 63).
Notes
If “MULTI-DISC RESUME” in “SYSTEM
SETUP” is set to “ON” and you play back a
recorded disc such as DVD-R, the system
may play back other recorded discs from
the same playback resume point. To start
playback from the beginning of the disc,
press twice and then press (or on
the unit).
e playback resume point is deleted when
the power cord is disconnected.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
40
GB
Changing the language/sound
Press AUDIO repeatedly during
playback to select the desired
audio format or mode.
e default setting is underlined.
When playing a DVD VIDEO:
Depending on the DVD VIDEO, the
option of language and audio format
varies.
When a 4-digit number is displayed, the
digits represent a language code (see
“L
anguage code list” (page 138)). When
the same language is displayed two or
more times, the DVD VIDEO is recorded
in multiple audio formats. Note that the
sound changes automatically depending
on the disc.
Some DVD VIDEOs allow you to select
items such as the language for the
subtitles and the language for the sound
using DVD/TUNER MENU.
When playing a DivX video le
(MHC-GZR
33Di only):
e options for audio format dier
depending on the DivX video les.
When playing a DVD-R/-RW in VR
mode:
e number of audio tracks recorded on
a disc are displayed.
Example:
1: MAIN: the main sound of the audio
track 1.
1: SUB: the sub sound of the audio
track 1.
1: MAIN+SUB: the main and sub
sound of the audio track 1.
2: MAIN*: the main sound of the audio
track 2.
2: SUB*: the sub sound of the audio
track 2.
2: MAIN+SUB*: the main and sub
sound of the audio track 2.
* ese items do not appear if only one audio
stream is recorded on the disc being played
back.
When playing a VIDEO CD, AUDIO CD,
or MP3 le:
You can select the sound from the right
or le channel and listen to the sound
of the selected channel through both
the right and le speakers. For example,
when playing a track with the vocals on
the right channel and the instruments
on the le channel, you can hear the
instruments from both speakers by
selecting the le channel.
STEREO: the standard stereo sound.
1/L: the sound of the le channel
(monaural).
2/R: the sound of the right channel
(monaural).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
41
GB
Disc
When playing a Super VCD:
1: STEREO: the stereo sound of the
audio track 1.
1: 1/L: the sound of the le channel of
the audio track 1 (monaural).
1: 2/R: the sound of the right channel
of the audio track 1 (monaural).
2: STEREO: the stereo sound of the
audio track 2.
2: 1/L: the sound of the le channel of
the audio track 2 (monaural).
2: 2/R: the sound of the right channel
of the audio track 2 (monaural).
Note
While the system is playing a Super VCD
on which the audio track 2 is not recorded,
no sound will come out when you select
“2:
STEREO,” “2: 1/L” or “2: 2/R.”
Playing VIDEO CDs with PBC
functions (PBC Playback)
(Version 2.0)
You can use the PBC (Playback Control)
menus included on the VIDEO CDs
(Version 2.0 only) on your TV screen to
enjoy the disc’s interactive soware. e
menu format and structure may dier
depending on each disc.
1
Press (or on the unit) to
start playing a VIDEO CD.
e PBC menu appears on the TV
screen. Depending on the VIDEO
CD, the menu may not appear.
2
Press the numeric buttons to
select the desired item number.
3
Press ENTER.
Depending on the VIDEO CD,
“Press ENTER” may appear as
“Press SELECT” in the operating
instructions supplied with the disc.
In this case, press (or on the
unit).
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
42
GB
4
Continue playback according to
the instructions on the menus.
Refer to the operating instructions
supplied with the VIDEO CD, as
the operating procedure may dier
depending on the VIDEO CD.
Note
PBC playback is canceled when Shue Play,
Program Play or Repeat Play is activated.
To cancel playback with PBC
functions
1
Press or repeatedly or
press the numeric buttons to select a
track when playback is stopped.
2
Press (or on the unit) or
ENTER.
Playback starts from the selected track.
Still images, such as the menu screens,
will not be shown.
To return to PBC playback, press
twice, then press (or on the
unit).
Selecting “ORIGINAL” or “PLAY
LIST”
is function is only available for DVD-
Rs/-RWs in VR mode with a playlist
created.
1
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(ORIGINAL/PLAY LIST),
then press ENTER.
e options for “ORIGINAL/PLAY
LIST” appear on the TV screen.
3
Press
or
repeatedly to select
the desired setting.
PLAY LIST: play back according to
the playlist created on the disc.
ORIGINAL: play back according to
t
he originally recorded sequence.
4
Press ENTER.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
43
GB
Disc
Searching for items on a disc by
the assigned numbers
You can search by dierent information
recorded on a disc, such as title, track,
scene, le, and folder. Each item is
assigned a unique number on the disc,
and you can select the numbered item
you want from the Control Menu. You
can also search for a particular point
using the time code (Time Search) (DVD
VIDEO and DVD-R/-RW in VR mode
only).
1
Press DISPLAY. (If “MEDIA” is
set to “MUSIC/PHOTO,” press
DISPLAY twice.)
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
the search item.
Example: when you select
(CHAPTER)
“** (**)” is selected (** refers to a
number). e number in parentheses
indicates the total number of titles,
chapters, tracks, indexes, scenes,
folders or les.
Selected row
3
Press ENTER.
“** (**)” change to “– – (**).”
4
Press
or
repeatedly or the
numeric buttons to select the
title, track, folder or le, etc.
If you make a mistake, press CLEAR
to cancel the number.
5
Press ENTER.
e system starts playback from the
selected title, track, folder or le, etc.
Tip
When the Control Menu display is turned o,
you can search for a chapter (DVD VIDEO and
DVD-R/-RW in VR mode) or track (AUDIO
CD and VIDEO CD) or le (video les in
DATA CD/DVD) by pressing the numeric
buttons and ENTER.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
44
GB
To search for a particular point using
the time code (Time Search)
(DVD VIDEO and DVD-R/-RW in VR
mode only)
1
Press DISPLAY.
2
Press
or
repeatedly to select
(TIME).
“T **:**:**” (elapsed playing time of
the current title) is selected.
3
Press ENTER.
“T **:**:**” changes to “T--:--:--.”
4
Input the time code using the
numeric buttons, then press ENTER.
For example, to nd the scene at 2
hours, 10 minutes, and 20 seconds
aer the beginning, enter “21020.”
If you make a mistake, press CLEAR to
cancel the number.
Note
Depending on the disc, you cannot perform
Time Search.
Using play mode
Creating your own program
(Program Play)
You can make a program of up to 99
steps in the order you want them to be
played back.
You can only program the tracks from
the current disc.
1
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(PROGRAM), then press
ENTER.
e options for “PROGRAM” appear
on the TV screen.
3
Press
or
repeatedly to select
“SET
,” then press ENTER.
Track number
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
45
GB
Disc
4
Press
.
e cursor moves to the track list “T”
(in this case, “01”).
5
Select the track you want to
program.
For example, select track “02.”
Press
or
repeatedly to select “02”
under “T,” then press ENTER.
Selected track
Total time of the programmed tracks
6
To program other tracks, repeat
steps 4 to 5.
7
Press (or on the unit).
Program Play starts.
When the Program Play ends, you
can restart the same program by
pressing (or on the unit).
To change a programmed step:
Press
or
repeatedly to select the
programmed step number you want
to change. en, press
and select
the desired track number.
To delete a programmed step:
Press
or
repeatedly to select the
programmed step number you want
to delete. en, press CLEAR.
To delete all of the programmed
steps in the program list:
Press
to select “ALL CLEAR.” en,
press ENTER.
To cancel Program Play
Press CLEAR or select “OFF” in step 3.
To play back the same program again,
select “ON” in step 3 and press ENTER.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
46
GB
Notes
When Program Play is activated, the
“REPEAT” setting is automatically changed
to “ON” if the current setting is “ALL DISCS,”
“ONE DISC” or “TRACK.”
You cannot perform Program Play with
VID
EO CDs during PBC playback.
Tip
e Program Play is canceled and the program
list is cleared when
you open the disc tray.
you change the disc.
you turn o the system.
you change the function.
Playing in random order
(Shue Play)
You can play back the tracks on the
current disc in random order. Each time
you perform Shue Play, the playing
order may dier.
Shue Play is only available for the
tracks on the current disc.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(SHUFFLE), then press
ENTER.
e options for “SHUFFLE” appear
on the TV screen.
3
Press
or
repeatedly to select
the desired setting.
When playing a VIDEO CD or
AUDIO CD:
TRACK: all tracks on the current
disc are played back randomly.
When Program Play is activated:
ON: all tracks in the program list is
played back randomly.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
47
GB
Disc
When playing a DATA CD/DVD
(except for video les):
ON (MUSIC): all MP3 les in the
s
elected folder on the current disc
are played back randomly.
When no folder is selected, the rst
folder is played back randomly.
4
Press ENTER.
5
Press (or on the unit).
Shue Play starts.
To cancel Shue Play, press CLEAR
or select “OFF” in step 3.
Notes
You cannot perform Shue Play with
VIDEO CDs during PBC playback.
e same song may be played back
r
epeatedly for MP3 les.
Tip
Shue Play is canceled when
you open the disc tray.
you change the disc.
you turn o the system.
you change the function.
you perform Track/Index Search.
you set “MEDIA” to “PHOTO” when
p
layback is stopped.
you perform CD Synchro Recording and
US
B TRANSFER.
you transfer music from a disc to a USB
de
vice.
Playing repeatedly (Repeat
Play)
You can play the contents on a disc
repeatedly.
You can select Shue Play and Program
Play at the same time.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(REPEAT), then press
ENTER.
e options for “REPEAT” appear on
the TV screen.
3
Press
or
repeatedly to select
the desired setting.
e default setting is underlined.
When playing a DVD VIDEO or
DVD-R/DVD-RW in VR mode:
OFF: does not play back repeatedly.
ALL DISCS: repeats all discs.
ONE DISC: repeats all the titles on
t
he current disc.
TITLE: repeats the current title.
CHAPTER: repeats the current
chapter.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
48
GB
When playing a VIDEO CD or
AUDIO CD:
OFF: does not play back repeatedly.
ALL DISCS: repeats all discs.
ONE DISC: repeats all the tracks
o
n the current disc.
TRACK: repeats the current track.
W
hen playing a DATA CD or DATA
DVD:
OFF: does not play back repeatedly.
ALL DISCS: repeats all discs.
ONE DISC: repeats all the folders
o
n the current disc.
FOLDER: repeats the current
folder.
TRACK
1)
: repeats the current audio
le.
FILE
2)
: repeats the current le.
1)
MP3 les only.
2)
Video les only.
When Program Play or Shue
Play is activated:
OFF: does not play back repeatedly.
ON: repeats the Program Play or
S
hue Play.
4
Press ENTER.
5
Press (or on the unit).
Repeat Play starts.
To cancel Repeat Play, press CLEAR
or select “OFF” in step 3.
Notes
You can also change the Repeat Play setting
by pressing REPEAT/FM MODE repeatedly.
Depending on the DVD VIDEO, you cannot
p
erform Repeat Play.
You cannot perform Repeat Play with
VID
EO CDs during PBC playback.
When playing a DATA CD/DVD which
co
ntains MP3 les and JPEG image les, the
audio sound will not match the image if their
playing time are dierent.
Repeat Play is canceled when
you open the disc tray.
you change the disc (except when “ALL
D
ISCS” is selected).
you turn o the system.
you change the function (except when
“
ALL DISCS” is selected).
you perform CD Synchro Recording and
US
B TRANSFER.
you transfer music from a disc to a USB
de
vice.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
49
GB
Disc
4
Press
or
repeatedly to select
the desired option, then press
ENTER. When the desired option
has already been selected, press
DVD/TUNER MENU.
A list of folders that contain the les
of the selected le type appears on the
TV screen.
5
Press
or
repeatedly to select
a folder.
Playing a folder:
Press (or on the unit).
e system starts playback from the
rst le of the selected folder.
To stop playback, press .
Playing an MP3 le:
1
Press ENTER.
“TRACK LIST” appears.
2
Press
or
repeatedly to select
the desired MP3 le, then press
ENTER.
e system starts playing the
selected MP3 le.
To stop playback, press .
Selecting a folder/le using
the on-screen display
DivX and MPEG4 video les can only be
played back on MHC-GZR33Di.
1
Load a disc on the disc tray.
“FOLDER LIST” appears on the TV
screen.
2
Press DISPLAY.
e Control Menu appears on the TV
screen.
3
Press
or
repeatedly to select
(MEDIA), then press
ENTER.
e options for “MEDIA” appear on
the TV screen.
MUSIC/PHOTO: for playing both
MP3
les and JPEG image les
in the same folder as a slide show
(page 137)
MUSIC: for playing MP3 les
VIDEO: for playing DivX video
les or MPEG4 video les
PHOTO: for playing JPEG image
les
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
50
GB
Playing an image le:
1
Press PICTURE NAVI.
umbnail picture for the rst
16
JPEG image les in the selected
folder is displayed.
If there are more than 16 image
les in the selected folder, the scroll
bar appears at the right.
2
Press
/
/
/
to select the
image you want to view, then
press (or on the unit).
e slide show starts from the
selected image le.
To stop playback, press .
e slide show stops when you
press
or
.
Playing a video le:
1
Press ENTER.
“FILE LIST” appears.
2
Press
or
repeatedly to select
the desired video le, then press
ENTER.
e system starts playback of the
selected video le.
To stop playback, press .
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
51
GB
Disc
Other operations
To Do this
Display
the next or
previous page
of “TRACK
LIST,”
“FOLDER
LIST” or “FILE
LIST”
Press
or
repeatedly.
Play back the
next folder of
MP3 les or
video les
Press repeatedly
until the last le of the
current folder, then
press once. To
select the previous
folder, select the folder
from “FOLDER LIST.”
Return to
“FOLDER
LIST” when
“TRACK LIST,”
or “FILE LIST”
is displayed.
Press RETURN.
Play back the
next folder of
JPEG image
les
Press
repeatedly
until the last le of the
current folder, then
press
once. To select
the previous folder,
select the folder from
“FOLDER LIST.”
Rotate the
image by
90
degrees
Press
or
repeatedly
while viewing an
image. To return to
the original view, press
CLEAR.
Notes
e system can play back MP3 les and
JPEG image les. e system will play back
any data with the extension “.mp3”, “.jpg” or
“.jpeg” even if they are not in MP3 or JPEG
format. Playing this data may generate a
loud noise which could damage your speaker
system.
D
epending on the encoding/writing
s
oware, recording device, or the recording
media used to record an MP3 le, you may
encounter problems such as cannot play
back, sound interruptions and noise.
e following discs/situations can increase
t
he time it takes to start playback:
a disc recorded with a complicated tree
s
tructure.
a disc recorded in Multi Session.
a disc to which data can be added (non-
n
alized disc).
when the tracks or les in another folder
h
ave just been played back.
Some CD-Rs/-RWs or DVD-Rs/-RWs/+Rs/
+R
Ws cannot be played back on the system
depending on the le format.
e system can play back to a depth of
8
folders only.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
52
GB
e system may not play certain types of
JPEG image les (ex. a JPEG image le that is
less than 8 (width) × 8 (height)).
When you press
o
r
to select the next or
previous image, the image will return to its
original view even if you have rotated the
image previously.
e slide show stops when you press
o
r
.
e system may not play back a video le
w
hen the le has been combined from two or
more video les.
e system cannot play back a video le size
o
f more than 720 (width) × 576 (height)/
2GB.
Depending on the video le, the picture may
b
e unclear or the sound may skip.
e system cannot play back some video les
t
hat are longer than 3 hours.
Depending on the video le, the picture
m
ay pause or be unclear. In this case, it is
recommended that you create the le at a
lower bit rate. If the sound is still noisy, MP3
is the recommended audio format.
Due to the compression technology used for
v
ideo les, it may take some time aer you
press for the picture to appear.
Depending on the video le, the sound may
n
ot match the pictures on the screen.
Tip
If the number of viewing times has been preset,
you can play back the DivX video les as many
times as the preset number. e following
occurrences are counted:
when the system is turned o.
when the disc is removed.
when another video le is played back.
To play MP3 les and JPEG image les
as a slide show with sound
(DATA CD and DATA DVD only)
You can play back a slide show with
sound by rst placing both JPEG image
les and MP3 les in the same folder on a
DATA CD/DVD.
1
Press DISPLAY when playback is
stopped.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(MEDIA), then press ENTER.
e options for “MEDIA” appear on
the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
53
GB
Disc
3
Press
or
repeatedly to select
“MUSIC/PHOTO,” then press ENTER.
When “MUSIC/PHOTO” has already
been selected, press DVD/TUNER
MENU.
“FOLDER LIST” appears on the TV
screen.
4
Press
or
repeatedly to select the
desired folder, then press (or
on the unit).
e slide show with sound starts from
the selected folder.
To stop playback, press .
To cancel the slide show with sound,
select “MUSIC” or “PHOTO” in
s
t
ep 3.
Note
If you play back a large data size of MP3 les
and JPEG image les at the same time, the
sound may skip.
To specify the slide show speed
(JPEG image les only)
1
Press DISPLAY. (If “MEDIA” is set to
“MUSIC/PHOTO,” press
DISPLAY
twice.)
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(INTERVAL), then press ENTER.
e options for “INTERVAL” appear
on the TV screen.
3
Press
or
repeatedly to select the
desired transition interval.
e default setting is underlined.
NORMAL: Sets to the standard
duration.
F
AST: Sets the duration shorter
t
han “NORMAL.”
SLOW 1: Sets the duration longer
t
han “NORMAL.”
SLOW 2: Sets the duration longer
t
han “SLOW 1.”
4
Press ENTER.
e selected setting takes eect.
Note
Some JPEG image les (especially progressive
JPEG image les or JPEG image les with
3,000,000 pixels or more) may take a longer
time to display than others, which may make
the transitions seem longer than that of the
option you selected.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
54
GB
To select a transition eect for image
les in the slide show
(JPEG image les only)
1
Press DISPLAY. (If “MEDIA” is set to
“MUSIC/PHOTO”, press
DISPLAY
twice.)
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(EFFECT), then press ENTER.
e options for “EFFECT” appear on
the TV screen.
3
Press
or
repeatedly to select the
desired setting.
e default setting is underlined.
MODE 1: e image sweeps in
from top to bottom of the screen.
M
ODE 2: e image sweeps in
f
rom le to right of the screen.
MODE 3: e image stretches out
f
rom the center of the screen.
MODE 4: e image randomly
c
ycles through the eects.
MODE 5: e next image slides
o
ver the current image.
OFF: Turns o this function.
4
Press ENTER.
e selected setting takes eect.
To select playback priority of the le
type
You can select playback priority when
mixed media (MP3 les, JPEG image les
or video les) are in the disc.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(MEDIA), then press ENTER.
e options for “MEDIA” appear on
the TV screen.
3
Press
or
repeatedly to select the
desired setting.
MUSIC/PHOTO: See page 137.
MUSIC: MP3 le playback has
priority.
VIDEO: Video le playback has
priority.
PHOTO: JPEG image le playback
has priority.
4
Press ENTER.
For details of the playback priority
of le types under “MEDIA” setting,
see “Playback priority of le types”
(pa
ge 137).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
55
GB
Disc
Adjusting the delay between
the picture and sound (“A/V
SYNC”)
When the sound does not synchronize
with the pictures on the screen, you can
adjust the delay between the picture and
sound.
“A/V SYNC” does not work for MP3 les
and JPEG image les in DATA CD/DVD.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(A/V SYNC), then press
ENTER.
e options for “A/V SYNC” appear
on the TV screen.
3
Press
or
repeatedly to select
the desired setting.
e default setting is underlined.
OFF: Does not adjust.
ON: Adjusts the dierence between
picture and sound.
4
Press ENTER.
Note
Depending on the input stream, this function
may not be eective.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
56
GB
Restricting playback
of the disc (PARENTAL
CONTROL)
You can limit the playback of some DVD
VIDEOs according to a predetermined
level such as the age of the users. When
a limited scene is played back, that scene
may be skipped or replaced with dierent
scenes.
1
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to
select
(SETUP), then press
ENTER.
e options for “SETUP” appear on
the TV screen.
3
Press
or
repeatedly to select
“CUSTOM,” then press ENTER.
e Setup Menu appears on the TV
screen.
4
Press
or
repeatedly to select
“SYSTEM SETUP,” then press
ENTER.
5
Press
or
repeatedly to select
“PARENTAL CONTROL,” then
press ENTER.
If you have not registered a
password:
e display for registering a new
password appears on the TV screen.
Enter a 4-digit password using the
numeric buttons, then press ENTER.
e display for conrming the
password appears on the TV screen.
When you have already registered
a password:
e display for entering the password
appears on the TV screen.
If you make a mistake when
entering your password:
Press
repeatedly to delete the
number you have entered, then
r
e
-enter your password again.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
57
GB
Disc
6
Enter or re-enter your 4-digit
password using the numeric
buttons, then press ENTER.
e display for setting the playback
limitation level appears on the TV
screen.
7
Press
or
repeatedly to select
“STANDARD,” then press ENTER.
e options for “STANDARD” appear
on the TV screen.
8
Press
or
repeatedly to
select a geographic area as the
playback limitation level, then
press ENTER.
e area is selected.
When you select “OTHERS
,”
enter the area code for the geographic
area you want by using the numeric
buttons (see “Parental Control area
code list” (page 139)).
9
Press
or
repeatedly to select
“LEVEL,” then press ENTER.
e options for “LEVEL” appear on
the TV screen.
10
Press
or
repeatedly to select
the desired level, then press
ENTER.
“PARENTAL CONTROL” setting is
completed.
e lower the value, the stricter the
limitation.
To turn o the “PARENTAL CONTROL”
function
Set “LEVEL” to “OFF” in step 10.
To change the password
1
Press
or
repeatedly to select
“CHANGE PASSWORD,” then press
ENTER in step 7 of “Restricting
playback of the disc.”
2
Enter your 4-digit password using the
numeric buttons, then press ENTER.
3
Enter a new 4-digit password using
the numeric buttons, then press
ENTER.
4
To conrm your password, re-enter
it using the numeric buttons, then
press ENTER.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
58
GB
If you forget your password
Remove the disc and repeat steps 1 to
5 of “Restricting playback of the disc
(PARENTAL CONTROL)” (page 56).
When you are asked to enter your
password, enter “199703” using the
numeric buttons, then press ENTER. e
display will ask you to enter a new 4-digit
password. Aer you enter a new 4-digit
password, reload the disc and press
(or on the unit). When the display
for entering your password appears, enter
your new password.
To play back a disc for which
“PARENTAL CONTROL” is set
1
Load the disc and press (or
on the unit).
e display for entering your password
appears on the TV screen.
2
Enter your 4-digit password using the
numeric buttons, then press ENTER.
e system starts playback.
Notes
When you play back DVD VIDEOs which
do not have the “PARENTAL CONTROL”
function, playback cannot be limited on this
system.
Depending on the DVD VIDEO, you
may be asked to change the “PARENTAL
CONTROL” level while playing the disc. In
this case, enter your password, then change
the level. If resume playback is canceled, the
level returns to the original level.
Using the Setup Menu
By using the Setup Menu, you can make
various adjustments to items such as
picture and sound.
Displayed items vary depending on the
country or region.
Note
Playback settings stored in the disc take
priority over the Setup Menu settings.
erefore, some of the Setup Menu settings
may not be performed.
1
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to
select
(SETUP), then press
ENTER.
e options for “SETUP” appear on
the TV screen.
3
Press
or
repeatedly to select
“CUSTOM,” then press ENTER.
e Setup Menu appears on the TV
screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
59
GB
Disc
4
Press
or
repeatedly to
select the setup item from the
displayed list, then press ENTER.
e setup item is selected.
Setup items:
: LANGUAGE SETUP
: VIDEO SETUP
: AUDIO SETUP
: SYSTEM SETUP
: SPEAKER SETUP
Example: “VIDEO SETUP”
Selected item
Setup items
5
Press
or
repeatedly to select
the desired item, then press
ENTER.
e options for the selected item
appear on the TV screen.
Example: “TV TYPE”
Options
6
Press
or
repeatedly to select
the desired setting, then press
ENTER.
e setting is selected and setup is
completed.
Selected setting
Setting the language
“LANGUAGE SETUP”
Set various languages for the on-screen
display or sound track.
OSD
(On-Screen Display)
Switches the language of the on-screen
display.
MENU*
(DVD VIDEO only)
Select the language for the DVD menu.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
60
GB
AUDIO*
(DVD VIDEO only)
Switches the language of the sound track.
When you select “ORIGINAL,” the
language given priority in the disc is
selected.
SUBTITLE*
(DVD VIDEO only)
Switches the language of the subtitle.
When you select “AUDIO FOLLOW,”
the language for the subtitles changes
according to the language you selected
for the sound track.
*
When you select a language in “MENU,”
“AUDIO,” or “SUBTITLE” that is not
recorded on the DVD VIDEO, one of the
recorded language is automatically selected.
However, depending on the disc, the
language may not be selected automatically.
I
f y
ou select “OTHERS
” in “MENU,”
“AUDIO,” and “SUBTITLE,” enter a language
code using the numeric buttons (see
“
L
anguage code list” (page 138)).
Setting the TV screen
“VIDEO SETUP”
Choose the settings according to the TV
you connected.
e default setting is underlined.
TV TYPE
1)
(DVD VIDEO only)
16:9: Select this when you connect a
wide-screen TV or a TV with a wide
mode function.
4:3 LETTER BOX: Select this when you
connect a 4:3 screen TV. is setting
displays a wide picture with bands on the
upper and lower portions of the screen.
4:3 PAN SCAN
2)
: Select this when you
connect a 4:3 screen TV. is setting
displays the wide picture on the entire
screen and cuts o the portions that do
not t.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
61
GB
Disc
PROGRESSIVE (COMPONENT OUT)
Sets the progressive signal output from
the COMPONENT VIDEO OUT jacks
to on or o.
OFF: Outputs interlace signals.
ON: Outputs progressive signals.
For details, see “Changing the format
of the video signal output from
COMPONENT VIDEO OUT jacks”
(pa
ge 28).
COLOR SYSTEM (VIDEO CD)
(Australian model only)
Select the output video signal when you
play back a VIDEO CD.
AUTO: Outputs the video signal
according to the color system of the disc,
either PAL or NTSC.
PAL: Changes the video signal of an
NTSC disc and output it in PAL system.
NTSC: Changes the video signal of a PAL
disc and output it in NTSC system.
BLACK LEVEL
(LBT-LCD7Di only)
Selects the black level (setup level) for the
video signals output from the jacks other
than COMPONENT VIDEO OUT.
ON: Sets the black level of the output
signal to the standard level.
OFF: Lowers the standard black level.
Use this when the picture becomes too
white.
BLACK LEVEL (COMPONENT OUT)
(LBT-LCD7Di only)
Selects the black level (setup level)
for the video signals output from the
COMPONENT VIDEO OUT jacks.
“BLACK LEVEL (COMPONENT OUT)”
setting is not available when the system
outputs progressive signal.
OFF: Sets the black level of the output
signal to the standard level.
ON: Raises the standard black level. Use
this when the picture becomes too black.
PAUSE MODE
(DVD VIDEO and DVD-R/-RW in VR
mode only)
AUTO: e picture, including subjects
that move dynamically, is output with no
jitter. Normally select this position.
FRAME: e picture, including subjects
that do not move dynamically, is output
in high resolution.
1)
e default setting varies depending on the
country or region.
2)
Depending on the DVD VIDEO, “4:3
LETTER BOX” may be selected automatically
instead of “4:3 PAN SCAN” or vice versa.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
62
GB
Setting the audio
options
“AUDIO SETUP”
Congure audio related settings.
e default setting is underlined.
AUDIO DRC
1)
(Dynamic Range
Compression)
(DVD VIDEO only)
OFF: No compression of dynamic range.
STANDARD: Reproduces the sound
track with the kind of dynamic range that
the recording engineer intended. Useful
for watching movies at low volume late
at night.
MAX: Narrows the dynamic range fully.
TRACK SELECTION
(DVD VIDEO only)
Gives priority to the sound track which
contains the highest number of channels
when you play back a DVD VIDEO
on which multiple audio (PCM, DTS,
MPEG audio, or Dolby Digital) formats
2)
are recorded.
OFF: No priority given.
AUTO
3)
: Priority given.
1)
“AUDIO DRC” can only be performed with
Dolby Digital sources.
2)
If each audio sound track has the same
number of channels, the system selects the
audio sound tracks in the order from PCM,
DTS, Dolby Digital, to MPEG.
3)
When you set “TRACK SELECTION” to
“AUTO,” the language may change. e
“TRACK SELECTION” setting has higher
priority than the “AUDIO” settings in
“L
ANGUAGE SETUP” (page 33). However,
depending on the disc, this function may not
be performed.
Setting the system
“SYSTEM SETUP”
SCREEN SAVER
e screen saver will help prevent your
display device from becoming damaged
(ghosting). Press any button (e.g., ) to
cancel the screen saver.
ON: e screen saver image appears if
you do not operate the system for about
15 minutes.
OFF: e screen saver does not appear.
BACKGROUND
Selects the background color or picture
to be displayed on the TV screen. e
background color or picture is displayed
when playback is stopped or while
playing an AUDIO CD and MP3 les.
JACKET PICTURE: e jacket picture
(still picture) appears in the background,
but only when the jacket picture is
already recorded on the disc (DVD
VIDEO, CD-Extra, etc.). If the disc
does not contain a jacket picture, the
“GRAPHICS” picture appears.
GRAPHICS: A preset picture stored in
the system appears in the background.
BLUE: e background color is blue.
BLACK: e background color is black.
PARENTAL CONTROL
Sets the playback restrictions. For details,
see “Restricting playback of the disc
(P
ARENT
AL CONTROL)” (page 56).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
63
GB
Disc
DivX
(MHC-GZR33Di only)
Displays the registration code for this
system.
For more information, go to http://www.
divx.com on the Internet.
MULTI-DISC RESUME
(DVD VIDEO and VIDEO CD only)
ON: Stores the resume playback point in
the memory for up to 10 discs.
OFF: Does not store the resume playback
point in the memory. Playback starts at
the resume playback point only for the
current disc in the system.
RESET*
Returns “SETUP” settings to the default
settings. For details, see “To return the
“SETUP” settings to the default settings*,
p
er
form reset as follows:” (page 120).
* Except for “PARENTAL CONTROL” settings
Setting the speakers
1)
“SPEAKER SETUP”
CONNECTION
FRONT: YES
SUBWOOFER
2)
:
YES: Select this if you have connected
the subwoofer.
NONE: Select this if the subwoofer is not
connected.
LEVEL (FRONT)
L 0.0 dB
R 0.0 dB
SUBWOOFER 0.0 dB
3)
1)
To return to the default setting when
changing a setting, press CLEAR before you
press ENTER. However, note that you cannot
return the setting of “CONNECTION” to
default setting. Note that you cannot perform
“SPEAKER SETUP” when you connect
headphones or microphones to the unit.
2)
Depending on the settings of other speakers,
the subwoofer may output excessive sound.
3)
e items that are set to “NONE” in
“CONNECTION” cannot be selected.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
64
GB
Tuner
Listening to the radio
You can listen to a radio station either by
selecting a preset station, or by manually
tuning in the station.
1
Press FUNCTION +/ (or press
TUNER/BAND on the unit)
repeatedly to select “FM” or “AM.”
2
Perform tuning.
For automatic scanning
Press and hold TUNING +/ until
the frequency indication changes and
then release.
“AUTO” appears on the TV screen.
Scanning stops automatically when
a station is tuned in and “TUNED”
appears on the TV screen. When
a FM stereo program is tuned in,
“STEREO” appears on the TV screen.
If “TUNED” does not appear and the
scanning does not stop, press and
perform manual tuning.
For manual tuning:
Press TUNING +/ repeatedly.
For direct tuning:
Press D.TUNING, then use the
numeric buttons to enter the
frequency of the desired station. For
example, press 1, 0, 2, 5 and 0 to enter
th
e frequency of FM 102.50 MHz,
then press ENTER. If you cannot
tune in the station, make sure you
have entered the right frequency. If
you still cannot tune in the station,
the frequency is not used in your
area. To cancel direct tuning, press
D.TUNING.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
65
GB
Tuner
Presetting a radio station
1
Tune in the desired station.
2
Press DVD/TUNER MENU.
“Memory?” ashes in the display.
3
Press ENTER or .
A preset number ashes in the
display.
e stations are stored from preset
number 1.
Preset number
4
Press or repeatedly (or press
the numeric buttons) to select
the desired preset number.
5
Press ENTER.
e station is stored.
6
Repeat steps 1 to 6 to store
other stations.
You can preset up to 20 FM stations
and 10 AM stations.
To cancel presetting, press DVD/
TUNER MENU.
7
To call up a preset number, press
PRESET +/ repeatedly (or turn
OPERATION DIAL on the unit
clockwise or counterclockwise)
to select the desired preset
number.
You can also press the numeric
buttons, then press ENTER to select a
preset station.
Tips
To improve broadcast reception, adjust the
supplied antennas, or connect an external
antenna.
When an FM stereo program has static noise,
p
ress REPEAT/FM MODE repeatedly until
“MONO” appears in the display. ere will
be no stereo eect, but the reception will
improve.
You can also set the frequency by viewing the
t
uner information on the TV screen.
To change the AM tuning interval, see “To
c
hange the AM tuning interval” (page 119).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
66
GB
Using the Radio
Data System (RDS)
(European model only)
Radio Data System (RDS) is a
broadcasting service that allows radio
stations to send additional information
along with the regular program signal.
is tuner oers convenient RDS features
such as station name. RDS is available
only on FM stations*.
* Not all FM stations provide RDS service, nor
do they provide the same type of services. If
you are not familiar with the RDS system,
check with your local radio stations for
details on RDS services in your area.
Note
RDS may not work properly if the station you
are tuned in is not transmitting the RDS signal
properly or if the signal is weak.
Receiving RDS broadcasts
Select a station from the FM band.
When you tune in a station that provides
RDS services, the station name appears
on the TV screen.
To check the RDS information
While receiving an RDS station, press
DISPLAY repeatedly.
RDS information appears on the TV
screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
67
GB
iPod
iPod
Playing the iPod
You can listen to music stored in your
iPod.
See “Compatible iPod models with this
system” (page 132) for iPod models that
can be connected to this system.
You can select operating mode from the
following to operate your iPod connected
to this system.
iPod Display mode (page 68):
You can operate the system with buttons
on the connected iPod, in addition to
buttons on the unit and the remote.
In this mode, the iPod display can be
viewed on iPod itself.
Main D
isplay mode (page 69):
You can view the iPod display on the
TV screen. In this mode, you cannot use
control buttons on the connected iPod.
Place an iPod into the iPod Dock on
the unit.
To use the system as a battery charger
You can use the system as a battery
charger for the iPod when the system
is on.
e charging begins when the iPod is
placed on the iPod Dock. e charging
status appears in the iPod display. For
details, see the user’s guide of your iPod.
To stop charging the iPod
Remove the iPod.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
68
GB
Notes
When placing or removing the iPod, handle
the iPod in the same angle as that of the iPod
connector on the unit and do not twist or
sway the iPod to prevent connector damage.
Do not carry the unit with an iPod set
o
n the connector. Doing so may cause a
malfunction.
When placing or removing the iPod, brace
t
he unit with one hand and take care not to
press the controls of the iPod by mistake.
Before disconnecting the iPod, pause
p
layback.
To change the volume level, use VOLUME
+/
. e volume level does not change even
if adjusted on the iPod.
e iPod Dock on the unit is designed for
iP
od only. You cannot connect any other
portable audio players.
To use an iPod, refer to the user’s guide of
y
our iPod.
Sony cannot accept responsibility in the event
t
hat data recorded to iPod is lost or damaged
when using an iPod with this system.
Using iPod Display mode
1
Select the iPod function.
Press FUNCTION +/ repeatedly.
2
Press iPod/OPR on the unit to
select the operating mode until
“iPod DISPLAY MODE” appears.
Basic operations
To Press
Start playback .
Pause playback /.
Scroll up/down
the iPod menus
/. You can scroll
up or down the iPod
menus much like the
Click Wheel operations
of the iPod or the drag
up-or-down operations
of the iPod touch.
Select a track
or chapter of
audiobook/
podcast
/. To fast-
forward or fast-rewind,
hold down the button.
Choose the
selected item
/ENTER. You can
choose the selected
item much like the
center button on the
iPod or the touch
operation of the iPod
touch.
Find a point
in a track or
chapter of
audiobook/
podcast
Hold down /
during playback, and
release the button at
the desired point.
Return to the
previous menu
or select a
menu
/
DISPLAY/
RETURN. You can
return to the previous
menu or select a menu
much like the Menu
button on the iPod or
the touch operation of
the iPod touch.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
69
GB
iPod
Notes
Depending on the connected iPod,
operations may dier.
Before enjoying video, adjust the video
s
ettings on the iPod to the appropriate
settings according to your situation.
It may take time to start playback depending
o
n the contents.
e volume cannot be adjusted using the
v
olume control on the iPod.
Hold down / to fast-forward (fast-
r
ewind) while playing video if / does
not function.
Using the Main Display mode
1
Select the iPod function.
Press FUNCTION +/ repeatedly.
2
Press iPod/OPR on the unit
to select the operating mode
until “iPod DISPLAY MODE”
disappears.
Selected menu title
Current settings (
, Repeat,
Shue)
[Main Menu] list ([Music], [Videos],
[S
ettings])
Selected menu
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
70
GB
Current playing le
Artist name
Album name
Elapsed time
Currently playing le number/total
n
umber of les
Playback status (Play, Pause, Fast-
f
orward, Fast-rewind)
Notes
In this mode, you cannot use the iPod’s
control buttons.
When the system cannot display a character,
i
t is displayed as “*”.
Depending on the connected iPod, switching
t
o iPod Display mode (page 67) will be
necessary in order to display video/photo
images.
Before disconnecting the iPod, pause
p
layback.
While “Loading…” is displayed on the TV, do
n
ot disconnect the iPod.
It may take time to start playback depending
o
n the contents.
Before enjoying video, adjust the video
s
ettings on the iPod to the appropriate
settings according to your situation.
To enjoy music and video while
browsing information on the TV screen
Example: Music playlists
1
Select [Music] from [Main
Menu], then press ENTER.
e [Music] menu display appears.
2
Select [Playlists] from [Music]
menu, then press ENTER.
e [Playlists] menu display appears.
3
Select the desired playlist, then
press ENTER.
Files in the selected playlist appear.
4
Select the desired le, then
press ENTER.
Playback of the selected le starts.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
71
GB
iPod
Basic operations
To Press
Start playback .
Pause playback /.
Scroll up/down
the iPod menus
/. You can scroll
up or down the iPod
menus much like the
Click Wheel operations
of the iPod or the drag
up-or-down operations
of the iPod touch.
Select a track
or chapter of
audiobook/
podcast
/. To fast-
forward or fast-rewind,
hold down the button.
Choose the
selected item
/ENTER. You can
choose the selected
item much like the
center button on the
iPod or the touch
operation of the iPod
touch.
Find a point
in a track or
chapter of
audiobook/
podcast
Hold down /
during playback, and
release the button at
the desired point.
Return to the
previous menu
or select a
menu
/
DISPLAY/
RETURN. You can
return to the previous
menu or select a menu
much like the Menu
button on the iPod or
the touch operation of
the iPod touch.
Continued
Notes
Depending on the connected iPod,
operations may dier.
It may take time to start playback depending
o
n the contents.
Settings menu
In the Settings menu, you can select
this unit’s settings: [Screen Saver],
[Color eme], [Shue], [Repeat],
[Audiobooks]. e setting switches by
pressing ENTER or
repeatedly.
e default settings are underlined.
Note
[Screen Saver] and [Color eme] can be
selected by pressing ENTER, and their settings
can be changed even when the iPod is not
placed into the unit.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
72
GB
Screen Saver
e screen saver image appears on the
TV aer about 15 minutes of inactivity.
Press any button to cancel the screen
saver.
[ON] Turns on the screen
saver.
[OFF] Turns o the screen
saver.
Note
e display does not switch to the screen saver
image while playing video.
Color Theme
Selects the on screen display color on the
connected TV.
[Auto] e color is selected
automatically according
to your iPod.
[White] e color is white.
[Black] e color is black.
[Green] e color is green.
[Red] e color is red.
[Blue] e color is blue.
Shue
Plays the songs/albums in random order.
e setting is determined by the iPod
settings.
[OFF] Does not play in
random order.
[Songs] Plays songs in random
order.
[Albums] Plays albums in
random order.
Note
When video contents are played, the [Shue]
setting turns [OFF] automatically.
Repeat
Plays songs repeatedly.
e setting is determined by the iPod
settings.
[OFF] Does not play
repeatedly.
[Repeat to
One]
Repeat one song.
[Repeat to All] Repeat all songs.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
73
GB
iPod
Audiobooks
Changes the Audiobook playback speed.
e setting is determined by the iPod
settings.
[Slower] Plays Audiobook
slowly.
[Normal] Plays Audiobook at
normal speed.
[Faster] Plays Audiobook
rapidly.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
74
GB
USB Device
Before using the USB
device with this system
See “Compatible devices with this
system” (page 130) for a list of USB
devices that can be connected to this
system.
Notes
When USB cable connection is necessary,
connect the USB cable supplied with the USB
device to be connected. See the operating
instructions supplied with the USB device
to be connected for details on the operation
method.
It may take about 10 seconds before
“
Reading.” appears in the display depending
on the type of USB device connected.
Do not remove the USB device during
t
ransfer, recording or erase operations. Doing
so may corrupt the data on the USB device or
damage the USB device itself.
Do not connect the system and the USB
de
vice through a USB hub.
When the USB device is inserted, the system
r
eads all the les on the USB device. If there
are many folders or les on the USB device,
it may take a long time to nish reading the
USB device.
A
lways turn o the system before removing
the USB device. Removing the USB device
while the system is on may corrupt the data
on the USB device.
Compatibility with all encoding/writing
s
oware, recording devices, and recording
media cannot be guaranteed. Incompatible
USB device may produce noise or interrupted
audio or may not play at all.
Note on the maximum number of
les and folders on a USB device
is system cannot transfer, record or playback
les and folders of the USB device in the
following cases.
When the number of les in a folder exceeds
150.
When the number of folders on a USB
de
vice exceeds 200.
ese numbers may vary depending on the le
structure and the folder structure. Do not save
other types of les or unnecessary folders on a
USB device that has audio les, video les or
JPEG image les.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
75
GB
USB Device
Transferring music
from a disc to a USB
device
You can connect an optional USB device
to the (USB) port on the unit and
transfer music from a disc to the USB
device.
You can transfer music only from an
AUDIO CD or DATA CD/DVD (MP3
les only).
e audio format of les transferred by
this system is MP3. When transferring
music from an AUDIO CD, the tracks
are transferred as 128 kbps MP3 les.
When transferring music from a DATA
CD/DVD, MP3 les are transferred with
the same bit rate as the original MP3 les.
e amount of free space required on the
USB device is about 1 MB per minute
when transferring music from an AUDIO
CD.
Required free space may be larger when
transferring music from a DATA CD/
DVD (MP3 les only).
You can easily transfer all the music on a
disc to a USB device (USB TRANSFER).
You can also transfer a single audio track
or le during playback (REC1).
1
Connect the USB device to the
(USB) port.
Insert a USB device
Note
Do not use the USB devices other than
those listed in “Compatible devices with
this system” (page 130). Operation of
models not listed is not guaranteed.
Operation may not always be ensured even
when using compatible USB devices.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
76
GB
2
Press FUNCTION +/ repeatedly
to select “DVD” (or press DVD on
the unit), then load the disc you
want to transfer.
If you have loaded the disc, press
DISC SKIP repeatedly (or DISC 1
DISC 3 on the unit) to select the disc.
When the system automatically starts
playback, press twice to cancel
resume playback.
3
Set the USB device to stand by
for transferring.
USB TRANSFER:
Press REC TO USB on the unit.
REC1:
Start playback of the track or MP3 le
you want to transfer, then press REC
TO USB on the unit.
e USB device stands by for
transferring.
4
Start transferring.
Press ENTER.
Transferring starts.
When the transfer is completed,
access to the USB device and the disc
player stops automatically.
To stop transferring
Press .
To remove the USB device
1
Press to stop playback.
2
Press to turn o the system.
3
Remove the USB device.
Using the on-screen display
You can also transfer music using the
on-screen display.
1
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
77
GB
USB Device
Continued
2
Press
or
repeatedly to select
(USB TRANSFER), then
press ENTER.
e options for “USB TRANSFER”
appear on the TV screen.
3
Press
or
repeatedly to select
the desired option, then press
ENTER.
For AUDIO CD:
TRACK: e tracks on the AUDIO
CD a
ppear. You can transfer the
desired track.
For DATA CD/DVD:
TRACK: e folders on the DATA
CD/D
VD appear. You can transfer
the desired MP3 le.
FOLDER: e folders on the DATA
CD/D
VD appear. You can transfer
all MP3 les in the folder.
“Reading.” appears, and the tracks or
folders appear on the TV screen.
Note
It may take some time to display the tracks
or folders depending on the number of
tracks or folders.
4
Select the tracks you want to
transfer.
For AUDIO CD:
Press
or
repeatedly to select the
track, then press ENTER.
e tracks are marked in the order
that you select. To cancel the
selection, press ENTER again.
Remaining space of
the USB device
Tracks to be transferred
To select all tracks on the AUDIO
CD
Press
/
/
/
repeatedly to select
“ ALL,” then press ENTER. To
cancel the selection, select “ ALL,”
then press ENTER.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
78
GB
For DATA CD/DVD:
Press
or
repeatedly to select
the MP3 les or folders, then press
ENTER.
e MP3 les or folders are marked.
To cancel the selection, press ENTER
again.
Remaining space of
the USB device
MP3 les or folders to be transferred
To select all tracks or folders on
the DATA CD/DVD
Press
/
/
/
repeatedly to select
“ ALL,” then press ENTER. To
cancel the selection, select “ ALL,”
then press ENTER.
5
Press
/
/
/
repeatedly to
select “START,” then press ENTER.
e system starts transferring and the
transfer status appears. No sound is
output during transfer.
To stop transferring, press .
To return to the previous display
Press RETURN.
To erase audio les or folders from the
USB device
You can erase audio les or folders on the
USB device.
1
Connect the USB device to the
(USB) port.
2
Press FUNCTION +/ repeatedly
to select “USB” (or press USB on the
unit).
“FOLDER LIST” appears.
3
Press
or
repeatedly to select a
folder.
To erase all audio les in a folder, press
CLEAR.
To erase an audio le, press ENTER.
“TRACK LIST” appears.
Press
or
repeatedly to select the
desired audio le, then press CLEAR.
4
Press
or
repeatedly to select
“YES.”
To cancel the erase operation, select
“NO.”
5
Press ENTER.
e selected audio le or folder is
erased.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
79
GB
USB Device
Folder and le generation rules
When rst transferring music to the
USB device, a “MUSIC” folder is created
directly below the “ROOT” folder.
Folders and les are generated within this
“MUSIC” folder as follows.
USB TRANSFER
1)
Music
source
Folder name File name
MP3 Same as the music source
2)
CD-DA “FLDR001”
3)
“TRACK001”
3)
REC1
Music
source
Folder name File name
MP3 “REC1-MP3”
4)
Same as the
music source
2)
CD-DA “REC1-CD”
4)
“TRACK001”
3)
1)
Except when resuming playback.
2)
Up to 64 characters of folder name and
60 characters of le name are assigned.
3)
Folder and le numbers are assigned serially
thereaer.
4)
A new le is created in the “REC1-MP3”
or “REC1-CD” folder each time REC1 is
performed.
Notes
When transferring music from a CD, the
tracks are transferred as 128 kbps MP3 les.
When transferring music from an MP3 disc,
MP3 les are transferred with the same bit
rate as the original MP3 les.
If you start transferring in shue play mode
o
r repeat play mode, the selected play mode
is automatically canceled and the play mode
switches to normal play mode.
CD text information is not transferred in the
cr
eated MP3 les.
If you cancel music being transferred
p
artway, an incomplete MP3 le, generated
on the USB device, will be deleted.
Transferring stops automatically if:
you change the function.
you turn o the system.
the USB device runs out of space during
t
he transfer process.
the number of les or folders on the USB
de
vice reaches the limit for the number
that the system can recognize.
You cannot change the sound eld when
t
ransferring to the USB device.
If the folder to be erased contains non-
MP3/WMA (W
indows Media Audio)/AAC
(Advanced Audio Coding) audio les or sub
folders, these are not erased.
If a folder or audio le that you are trying
t
o transfer already exists on the USB device
with the same name, a sequential number is
added aer the name without overwriting the
original folder or le.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
80
GB
Recording analog
audio to a USB device
You can record the sound from analog
audio sources. e sound is recorded as
128 kbps MP3 le.
1
Connect the USB device to the
(USB) port.
2
Press FUNCTION +/ repeatedly
to select the desired source.
TUNER FM/AM: To record from
this system’s tuner.
VIDEO/SAT: To record from the
o
ptional component connected to
the VIDEO SAT AUDIO IN L/R
jacks.
3
Press REC TO USB on the unit.
“Please Wait” appears and the display
cycles between “Free xx.x GB” (free
space on the USB device) and “Push
Enter.”
e USB device stands by for
recording.
4
Start playing the desired source
to record, then press ENTER.
To stop recording
Press .
To remove the USB device
1
Press to stop recording.
2
Press to turn o the system.
3
Remove the USB device.
To mark track numbers
You can mark the track numbers during
recording of any source.
Press REC TO USB on the unit at the
point you want to add a track mark.
e system pauses recording for a few
seconds and adds track mark, showing
message “New Track.” No sound is
recorded during pause time.
Note
e track numbers are automatically marked
when you record more than 60 minutes.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
81
GB
USB Device
Folder and le generation rules
When rst recording the analog audio
to the USB device, a “MUSIC” folder
is created directly below the “ROOT”
folder.
Folders and les are generated within this
“MUSIC” folder as follows.
Music
source
Folder name File name
Tuner “FM001”* or
“AM001”*
“TRACK001”*
VIDEO/
SAT
AUDIO IN
L/R
“VIDEO001”*
or “SAT001”*
“TRACK001”*
* F
older and le numbers are assigned serially
thereaer.
Note
Recording stops automatically when:
you change the function.
you change the band.
you turn o the system.
the USB device runs out of space during the
r
ecording.
the number of les or folders on the USB
de
vice reaches the limit for the number that
the system can recognize.
Playing a le of the
USB device
See “Compatible devices with this
system” (page 130) for a list of USB
devices that can be connected to this
system.
You can listen to music stored in the USB
device.
e audio formats that can be played
back by this system are as follows: MP3*/
WMA*/AAC*
You can view image les and video les
stored in the USB device.
e image les and video le formats that
can be played back by this system are as
follows: JPEG/DivX/MP4
DivX and MPEG4 video les can only be
played back on MHC-GZR33Di.
* Files with copyright protection (Digital
Rights Management) cannot be played back
by this system.
1
Press FUNCTION +/ repeatedly
to select “USB” (or press USB on
the unit).
2
Connect the USB device to the
(USB) port.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
82
GB
3
Press DISPLAY when playback
is stopped.
e Control Menu appears on the TV
screen.
4
Press
or
repeatedly to select
(MEDIA), then press
ENTER.
e options for “MEDIA” appear on
the TV screen.
MUSIC: for playing audio les
VIDEO: for playing DivX video
les or MPEG4 video les
PHOTO: for playing JPEG image
les
5
Press
or
repeatedly to select
the desired option, then press
ENTER. When the desired option
has already been selected, press
DVD/TUNER MENU.
A list of folders that contain the les
of the selected le type appears on the
TV screen.
6
Press
or
repeatedly to select
a folder.
Playing a folder:
Press (or on the unit).
e system starts playback from the
rst le of the selected folder.
To stop playback, press .
Playing an audio le:
1
Press ENTER.
“TRACK LIST” appears.
2
Press
or
repeatedly to select
the desired audio le, then press
ENTER.
e system starts playback of the
selected audio le.
To stop playback, press .
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
83
GB
USB Device
Continued
Playing an image le:
1
Press PICTURE NAVI.
umbnail picture for the rst
16
JPEG image les in the selected
folder is displayed.
If there are more than 16 image
les in the selected folder, the scroll
bar appears at the right.
2
Press
/
/
/
to select the
image you want to view, then
press (or on the unit).
e slide show starts from the
selected image le.
To stop playback, press .
e slide show stops when you
press
or
.
Playing a video le:
1
Press ENTER.
“FILE LIST” appears.
2
Press
or
repeatedly to select
the desired video le, then press
ENTER.
e system starts playing the
selected video les.
To stop playback, press .
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
84
GB
Other operations
To Do this
Display
the next or
previous page
of “TRACK
LIST,”
“FOLDER
LIST” or “FILE
LIST”
Press
or
repeatedly.
Playback the
next folder of
audio les or
video les
Press repeatedly
until the last le of the
current folder, then
press once. To
select the previous
folder, select the folder
from “FOLDER LIST.”
Return to
“FOLDER
LIST” when
“TRACK LIST,”
or “FILE LIST”
is displayed.
Press RETURN.
Playback the
next folder of
JPEG image
les
Press
repeatedly
until the last le of the
current folder, then
press
once. To select
the previous folder,
select the folder from
“FOLDER LIST.”
Rotate the
image by 90
degrees
Press
or
repeatedly
while viewing an
image. To return to
the original view, press
CLEAR.
To remove the USB device
1
Press to stop playback.
2
Press to turn o the system.
3
Remove the USB device.
Notes
e le formats that this system can play are
as follows:
MP3: le extension “.mp3”
WMA: le extension “.wma”
AAC: le extension “.m4a”
JPEG: le extension “.jpg” or “.jpeg”
MP4: le extension “.3gp” or “.mp4”
DivX: le extension “.avi” or “.divx”
N
ote that even when le names have the
above le extensions, if the actual les dier,
playing these les may generate a loud noise
which could damage the speaker system and
the system may malfunction.
e following USB devices/situations can
in
crease the time it takes to start playback:
a USB device recorded with a complicated
t
ree structure.
when the les in another folder have just
b
een played back.
when you play back an AAC le.
e system can play back to a depth of
8
folders only.
Resume play back is canceled when you turn
o
the system or change the function.
is system does not necessarily support all
t
he functions provided in a connected USB
device.
e playback order for the system may dier
f
rom the order of the connected USB device.
Folders that have no audio les or JPEG
im
age les are skipped.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
85
GB
USB Device
Continued
To specify the slide show speed
(JPEG image les only)
1
Press DISPLAY repeatedly until the
Control Menu for JPEG image les
appears on the TV screen.
2
Press
or
repeatedly to select
(INTERVAL), then press ENTER.
e options for “INTERVAL” appear
on the TV screen.
3
Press
or
repeatedly to select the
desired transition interval.
e default setting is underlined.
NORMAL: Sets to the standard
duration.
F
AST: Sets the duration shorter
t
han “NORMAL.”
SLOW 1: Sets the duration longer
t
han “NORMAL.”
SLOW 2: Sets the duration longer
t
han “SLOW 1.”
4
Press ENTER.
e selected setting takes eect.
Note
Some JPEG image les (especially progressive
JPEG image les or JPEG image les with
3,000,000 pixels or more) may take a longer
time to display than others, which may make
the transitions seem longer than that of the
option you selected.
To select a transition eect for image
les in the slide show
(JPEG image les only)
1
Press DISPLAY repeatedly until the
Control Menu for JPEG image les
appears on the TV screen.
2
Press
or
repeatedly to select
(EFFECT), then press ENTER.
e options for “EFFECT” appear on
the TV screen.
3
Press
or
repeatedly to select the
desired setting.
e default setting is underlined.
MODE 1: e image sweeps in
from top to bottom of the screen.
M
ODE 2: e image sweeps in
f
rom le to right of the screen.
MODE 3: e image stretches out
f
rom the center of the screen.
MODE 4: e image randomly
c
ycles through the eects.
MODE 5: e next image slides
o
ver the current image.
OFF: Turns o this function.
4
Press ENTER.
e selected setting takes eect.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
86
GB
Playing in random order
(Shue Play)
You can play back the les on the USB
device in random order. Each time you
perform Shue Play, the playing order
may dier.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(SHUFFLE), then press
ENTER.
e options for “SHUFFLE” appear
on the TV screen.
3
Press
or
repeatedly to select
the desired setting.
ON (MUSIC): all audio les in the
selected folder on the USB device
are played back randomly.
When no folder is selected, the rst
folder is played back randomly.
4
Press ENTER.
Shue Play starts.
To cancel Shue Play, press CLEAR
or select “OFF” in step 3.
Notes
Shue Play is canceled when:
you remove the USB device.
you turn o the system.
you change the function.
you set “MEDIA” to “PHOTO” when
p
layback is stopped.
e same song may be played back
r
epeatedly for audio les.
Playing repeatedly (Repeat
Play)
You can play the audio les and JPEG
image les on the USB device repeatedly.
You can select Shue Play at the same
time.
1
Press DISPLAY.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(REPEAT), then press
ENTER.
e options for “REPEAT” appear on
the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
87
GB
USB Device
Continued
3
Press
or
repeatedly to select
the desired setting.
MEMORY: repeats all the folders
on the USB device.
FOLDER: repeats the current
folder.
TRACK*: repeats the current le.
* Audio les only.
When Shue Play is activated:
ON: repeats the Shue Play.
4
Press ENTER.
5
Press (or on the unit).
Repeat Play starts.
To cancel Repeat Play, press CLEAR
or select “OFF” in step 3.
Note
Repeat Play is canceled when:
you remove the USB device.
you turn o the system.
you change the function.
Tip
You can also change the Repeat Play setting by
pressing REPEAT/FM MODE repeatedly.
Selecting the playback source
or transferring destination
on the Sony Ericsson mobile
phone
When listening to music from a Sony
Ericsson mobile phone (W302 / W595 /
W760i / W890i / W902 / W910i) or
when transferring music from this
system to the mobile phone, you can
select the playback source or transferring
destination as follows:
internal memory of the mobile phone
Memory Stick
To select the playback source in the
“USB” function
Press MEMORY SELECT repeatedly.
You can select the internal memory or
Memory Stick of the mobile phone.
Selected memory number
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
88
GB
To select the transferring destination
in the “DVD” function
1
Load a CD, DATA CD or DATA DVD.
2
Press MEMORY SELECT repeatedly.
You can select the internal memory or
Memory Stick of the mobile phone.
Notes
You cannot select the playback source or
transferring destination during playback or
transferring. Stop playback or transferring,
and then select the playback source or
transferring destination.
You can check the selected memory number
o
n the TV screen.
Selected memory number
You can select a Memory Stick when the
selected memory number is as follows:
Model name Memory number
W302 #1
W595 #2
W760i #2
W890i #2
W902 #2
W910i #2
If there is no Memory Stick inserted in the
mobile phone, you cannot select playback
source or the transferring destination.
Select a transferring destination before
t
ransfer.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
89
GB
Sound Adjustment
Sound Adjustment
Adjusting the sound
To Do this
Reinforce the
sound
Press GROOVE on
the unit. Each time
you press the button,
the display changes as
follows:
GROOVE ON
1)
Z-GROOVE ON
1)
GROOVE OFF
GROOVE ON …
Select the
preset eect
Press PRESET EQ on
the unit repeatedly
2)
.
1)
e volume switches to power mode and the
equalizer curve changes.
2)
e last selected preset eect appears when
PRESET EQ on the unit is pressed once.
Preset eect options
Eect Category
ROCK
POP
JAZZ
DANCE
SOUL
TECHNO
HIP HOP
Standard music sources
MP3 EQ MP3 les
USER EQ 1,
2, 3
User equalizer setting
(see “To adjust the
graphic equalizer and
store the user equalizer
setting” (page 90))
FLAT Original music source
(cancels the preset
eect)
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
90
GB
To adjust the graphic equalizer and
store the user equalizer setting
You can adjust the sound by raising or
lowering the level of specic frequency
band, then store up to three user
equalizer settings, in the memory.
1
Press EQ BAND repeatedly to select a
frequency band or surround eect.
2
Press / to adjust the level or
select surround eect you want.
Equalizer level
3
Repeat steps 1 and 2 to adjust the
level of other frequency bands and
surround eect.
4
Press ENTER.
“MEMORY EQ-1” appears in the
display.
5
Press / to select a user
equalizer number (1 – 3) for the
equalizer setting (“MEMORY EQ-1”
through “MEMORY EQ-3”) you want
to store.
6
Press ENTER.
is setting is automatically stored as
the user equalizer setting you selected
in step 5.
e previous setting stored at this
memory location is erased and
replaced by the new setting.
Tip
If you do not want to store the setting, press
/ to select “EXIT?” and then press
ENTER.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
91
GB
Sound Adjustment
Selecting the sound eld
You can take advantage of the surround
sound simply by selecting one of the
sound elds. ey bring the exciting and
powerful sound of movie theaters into
your home.
Press SOUND FIELD.
e last selected sound eld appears in
the display, and then you can select the
desired sound eld.
When the headphones are not
connected:
2CH STEREO
Reproduces stereo output from multi
channel sources such as DVD VIDEOs
during “DVD” function. e system
outputs the original sound during
functions other than “DVD” and during
playback of stereo sources such as
AUDIO CD, VIDEO CD and MP3 les.
2CH SURR
Reproduces stereo output with surround
eect from multi channel sources such as
DVD VIDEO during “DVD” function.
e system outputs the original sound
with surround eect during functions
other than “DVD”.
VIRTUAL A*
Creates 3 sets of virtual surround
speakers from the sound of the front
speakers. is sound eld is only eective
when you play back multi channel
sources.
VIRTUAL B*
Creates 1 set of virtual surround speakers
from the sound of the front speakers
without using actual surround speakers.
is mode is eective when the distance
between the front speakers is short. is
sound eld is only eective when you
play back multi channel sources.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
92
GB
When the headphones are connected:
HP 2CH
e normal sound eld for headphones.
HP SURR
e sound eld for headphones with
surround eect.
HP VIRTUAL*
e sound eld for headphones with
virtual surround eect. is sound eld
is only eective when you play back multi
channel sources.
* ese sound elds cannot be selected when:
the system is in stand by or during
t
ransfer or recording.
the Karaoke mode is turned on.
Notes
Depending on the disc, the surround eect
may not be as much as expected.
You cannot change the sound eld when
t
ransferring or recording to the USB device.
Singing along: Karaoke
You can enjoy Karaoke by setting the
system to Karaoke mode.
1
Press FUNCTION +/ repeatedly
to select “DVD” or “USB” (or press
DVD or USB on the unit).
2
Turn MIC 1/2 LEVEL on the
unit to “MIN” to reduce the
microphone volume.
3
Connect a microphone to MIC
1/2 jack on the unit.
e Karaoke mode is turned on.
“KARAOKE MODE: ON” appears on
the TV screen.
4
Start playing the music and
adjust the volume.
DVD VIDEO, DVD-R/-RW in VR
mode, video les:
e system outputs the audio format
that you have selected.
AUDIO CD, VIDEO CD, MP3 les:
e audio setting automatically
changes to “1/L” and the system
outputs the le channel audio.
If you want to hear vocal:
Press AUDIO repeatedly to select
another audio channel.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
93
GB
Sound Adjustment
5
Start singing along with
the music and adjust the
microphone volume by turning
MIC 1/2 LEVEL.
To turn o the Karaoke mode
Disconnect the microphone or press
KARAOKE MODE. “KARAOKE MODE:
OFF” appears on the TV screen.
To adjust the microphone echo level
Turn ECHO LEVEL on the unit.
To cancel the echo eect, turn ECHO
LEVEL on the unit to “MIN.”
Notes
e sound input from the microphone is not
output from the DVD DIGITAL OUT jack.
Karaoke mode is automatically turned o
w
hen:
you turn o the system.
you change the function (except for the
“
DVD” function or “USB” function).
you connect the headphones.
you disconnect the microphone.
If howling occurs:
move the microphone away from the
s
peakers.
change the direction of the microphone.
lower the MIC 1/2 LEVEL or ECHO
LE
VEL.
press VOLUME repeatedly (or
t
urn MASTER VOLUME on the unit
counterclockwise).
Changing the key (Key Control)
You can change the key to suit your vocal
range, except when the system is in stop
mode.
Press KEY CONTROL / to suit
your vocal range in Karaoke mode.
You can adjust the key higher or lower in
13 steps (6 6).
Notes
Depending on the disc, you may not be able
to change the key.
e key automatically returns to the original
k
ey when:
you turn o the system.
you change the function.
you change the disc.
you open the disc tray.
you stop playback.
the title, track or audio le changes.
you change the folder.
the play item is changed during PBC
p
layback.
you perform Lock Search.
you cancel Karaoke mode.
DVD layer is changed.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
94
GB
Playing Karaoke with any
stereo disc (“Karaoke Pon”)
You can enjoy Karaoke with a stereo-
recorded disc, even if it is a non-Karaoke
disc, by reducing the sound of the vocals.
Press KARAOKE PON in Karaoke
mode.
To cancel “Karaoke Pon” mode, press
KARAOKE PON again.
Notes
is function may not work well when:
only a few instruments are playing.
a duet is playing.
the vocals on the disc deviate from the
cen
ter.
playing monaural-recorded discs (the
acco
mpaniment is also reduced).
playing multiplex discs.
During “Karaoke Pon” mode, the stereo eect
i
s reduced.
“Karaoke Pon” mode is automatically
c
anceled when:
you turn o the system.
you change the function.
y
ou change the disc.
y
ou open the disc tray.
you press AUDIO.
you set “VOCAL SELECT” to other than
“
OFF.”
you cancel Karaoke mode.
Selecting the vocals (Vocal
Select)
When playing a DVD with the “Dolby
Digital Karaoke” format in Karaoke
mode, you can turn on or o the guide
vocal recorded in the Karaoke track.
When playing a VIDEO CD or AUDIO
CD in Karaoke mode, you can listen to
the vocals.
You can also change the guide vocal
channel. You can select dierent kinds
of vocals.
1
Press DISPLAY in Karaoke
mode.
e Control Menu appears on the TV
screen.
2
Press
or
repeatedly to select
(VOCAL SELECT), then
press ENTER.
e options for “VOCAL SELECT”
appear on the TV screen.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
95
GB
Sound Adjustment
3
Press
or
repeatedly to select
the desired vocal channel.
e output channel changes as
follows.
e default setting is underlined.
When playing a DVD VIDEO
OFF: Turns o the guide vocal.
1+2: Guide vocal 1+2
1: Guide vocal 1
2: Guide vocal 2
When playing a VIDEO CD or
AUDIO CD
OFF: Turns o the guide vocal.
L+R: e same sound is output
from both speakers.
STEREO: e standard stereo
sound
When playing a Super VCD
OFF: Turns o the guide vocal.
1:L+R: e same sound of the
audio track 1 is output from both
speakers.
1:STEREO: e stereo sound of the
audio track 1
2:L+R: e same sound of the
audio track 2 is output from both
speakers.
2:STEREO: e stereo sound of the
audio track 2
4
Press ENTER.
Notes
When playing a DVD VIDEO, the function
works only with the “Dolby Digital Karaoke”
format.
Depending on the disc, you may not be able
t
o change the guide vocal channel.
e channel returns to the default setting
w
hen:
you turn o the system.
you change the function.
you change the disc.
you open the disc tray.
you press AUDIO.
you cancel Karaoke mode.
you set “Karaoke S” mode to on.
When playing a DVD VIDEO recorded only
w
ith one kind of guide vocal, select “1.”
Selecting the scoring mode
(Score Mode)
When Karaoke mode is turned on, you
can use the scoring mode.
Your score is calculated by comparing
your voice with the music source.
1
Press DISPLAY in Karaoke
mode.
e Control Menu appears on the TV
screen.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
96
GB
2
Press
or
repeatedly to select
(SCORE MODE), then
press ENTER.
e options for “SCORE MODE”
appear on the TV screen.
3
Press
or
repeatedly to select
a setting.
e default setting is underlined.
BEGINNER 1: Beginner level. e
score updates every 3 seconds.
BEGINNER 2: Beginner level.
EXPERT 1: Advance level. e
score updates every 3 seconds.
EXPERT 2: Advance level.
DEMO: Demonstration mode.
e score is displayed regardless of
singing.
4
Press ENTER.
5
Start playing the music.
6
Press SCORE before singing a
song in Karaoke mode.
e previous highest score appears
on the TV screen and the display
changes as follows according to the
level selected for “SCORE MODE.”
: When you select “BEGINNER
1” or “EXPERT 1.”
: When you select “BEGINNER
2” or “EXPERT 2.”
: When you select “DEMO.”
7
After singing for more than a
minute, press SCORE again to
view your score.
Your score is calculated from a scale
of 0 to 99.
Your score is displayed for 5 seconds,
during which time the system enters
pause mode.
Aer your score, the ranking is
displayed as follows:
e ranking is displayed as a list
w
ith top 3 scores.
Your score and ranking for the last
s
ong ash.
If you are in the top 10, your
ra
nking is displayed. If not, “10+” is
displayed.
If your score is “0,” your score is not
di
splayed in the ranking list.
Notes
e highest score is reset when the system is
turned o.
e “SCORE MODE” function may be
c
anceled when certain remote buttons are
pressed.
In some cases, you may not be able to use the
s
coring mode.
Tip
e “SCORE MODE” setting is automatically
changed to “BEGINNER 1” when the system
is turned o.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
97
GB
Other Operations
Other Operations
Using the timers
e system oers three timer functions.
You cannot activate both the Play Timer
and the Rec Timer at the same time. If
you use either with the Sleep Timer, the
Sleep Timer has priority.
Use buttons on the remote to use the
timer functions.
Sleep Timer
You can fall asleep to music. is
function works even if the clock is not
set.
Press SLEEP repeatedly to select
the time you want.
e system turns o aer the preset time.
Play Timer
You can wake up to DVD, tuner or
optional USB device at a preset time.
Make sure you have set the clock.
Rec Timer
You can record from a preset radio
station at a specied time.
Make sure you have set the clock.
1
Prepare the sound source.
For Play Timer:
Prepare the sound source, and
then press VOLUME +/ (or turn
MASTER VOLUME on the unit) to
adjust the volume.
For Rec Timer:
Tune in the desired radio station or
call up the desired preset station.
2
Select the timer set mode.
Press TIMER MENU.
3
Press or repeatedly to select
“PLAY SET?” or “REC SET?,” then
press ENTER.
“ON” appears and the hour indication
ashes in the display.
4
Set the time to start playback or
recording.
Press or repeatedly to set the
hour, then press ENTER.
e minute indication ashes in the
display. Use the procedure above to
set the minute. “OFF” appears and the
hour indication ashes in the display.
5
Use the same procedure as in
step 4 to set the time to stop
playback or recording.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
98
GB
6
Select the sound source when
using Play Timer, or prepare
the USB device when using Rec
Timer.
For Play Timer:
Press or repeatedly until the
desired sound source appears, and
then press ENTER. e display shows
the timer settings.
For Rec Timer:
e display shows the timer settings.
When recording to a USB device,
perform steps 1 and 2 of “Playing a
le o
f the USB device” (page 81).
7
Press to turn o the system.
When you set the Rec Timer, the
system turns on 90 seconds before
the preset time. When you set the
Play Timer, the system turns on 30
seconds before the preset time.
If the system is on at the preset time,
the Play Timer and the Rec Timer will
not play. Do not operate the system
from the time the system turns on
until the playback or recording starts.
To check the setting
1
Press TIMER MENU.
“TIMER SELECT?” ashes in the
display.
2
Press ENTER.
3
Press or repeatedly to select
“PLAY SELECT?” or “REC SELECT?.”
4
Press ENTER.
To change the setting
Start over from step 1.
To cancel the timer
1
Press TIMER MENU.
“TIMER SELECT?” ashes in the
display.
2
Press ENTER.
3
Press or repeatedly to select
“TIMER OFF.”
4
Press ENTER.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
99
GB
Other Operations
Notes
e Play Timer and Rec Timer will not be
activated if the system is turned on or if
“STANDBY” ashes in the display. Be sure
to turn o the system at least 120 seconds
before the preset time.
e volume is reduced to minimum during
R
ec Timer.
e track numbers are automatically marked
w
hen you record more than 60 minutes.
Tips
e Play Timer setting remains as long as the
setting is not canceled manually.
e Rec Timer is canceled automatically aer
t
he Rec Timer has been activated.
Changing the display
Turning o the display
Power Saving Mode
e demonstration display and the clock
display can be turned o to minimize
the amount of power consumed during
standby mode (Power Saving Mode).
Press DISPLAY repeatedly while the
system is turned o.
Demonstration
1)
No display (Power Saving Mode)
Clock
2)
Demonstration
...
1)
e display changes and the indicators ash
even when the system is turned o.
2)
e clock display automatically turns to
Power Saving Mode aer 8 seconds.
Note
You cannot perform the following operations
during Power Saving Mode:
Setting the clock (page 32).
Changing the AM tuning interval
(p
age 119).
Changing the color system (Australian
m
odel only) (page 28).
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
100
GB
Changing the power
illuminator
You can change the illumination pattern
around the MASTER VOLUME on the
unit.
1
Select the illumination setting.
Press OPTIONS on the unit
repeatedly until “ILLUMINATION”
appears in the display.
2
Press or to select the
desired illumination pattern,
then press ENTER.
Viewing information about the
disc in the front panel display
Press DISPLAY.
Each time you press DISPLAY, the
display changes from
…
Disc information
Clock display (for 8 seconds)
Effect name (for 4 seconds)
Checking the elapsed playing time,
remaining time and titles
Press TIME/TEXT during playback.
Each time you press TIME/TEXT, the
display changes from …
…
When playing a DVD VIDEO or DVD-
R/-RW in VR mode:
When the menu or the title without a
chapter is played back
Elapsed playing time of the menu
o
r the current title
Disc title
1)
When a chapter other than above
condition is played back
Elapsed playing time of the current
t
itle
Remaining time of the current title
Elapsed playing time of the current
chapter
Remaining time of the current
chapter
Disc title
1)
Title and chapter
2)
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
101
GB
Other Operations
When playing an AUDIO CD or VIDEO
CD without PBC function:
Elapsed playing time of the current
track
Remaining time of the current track
Elapsed playing time of the disc
3)
Remaining time of the disc
3)
Track name
1)
Track and index
4)5)
When playing a VIDEO CD with PBC
function:
Elapsed playing time of the current
scene
Disc title
1)
Scene number
6)
When playing MP3 les or video les
on a DATA CD/DVD:
Elapsed playing time of the current
le
File name
7)8)
Checking the total playing time and
titles
Press TIME/TEXT repeatedly when
playback is stopped.
Each time you press TIME/TEXT, the
display changes from
…
DVD VIDEO or DVD-R/-RW in VR
mode:
Total number of titles on the disc
Disc title
1)
AUDIO CD or VIDEO CD without PBC
playback:
Total number of the tracks on the disc
a
nd the total playing time of the disc
Disc title
1)
VIDEO CD with PBC playback:
Total number of scenes on the disc
Disc title
1)
1)
“NO TEXT” appears in the display if the
DVD VIDEO is not a DVD-TEXT disc, the
AUDIO CD is not a CD-TEXT disc or the
VIDEO CD does not have text information.
2)
Title and chapter are displayed for 2 seconds
before the display returns to the elapsed
playing time.
3)
When Program Play or Shue Play is
turned on, the elapsed playing time and the
remaining time of the disc would be skipped.
4)
VIDEO CD only
5)
e current track number and the current
index number (for a disc without PBC) or the
current scene number (for a disc with PBC)
are displayed for 2 seconds before the display
returns to the elapsed playing time.
6)
e current scene number is displayed for
2 seconds before the display returns to the
elapsed playing time.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
102
GB
7)
When playing video les, the current folder
number and the current le number are
displayed for 2 seconds before the display
returns to elapsed playing time when you
press TIME/TEXT during display of title of
the le.
8)
If an MP3 le has the ID3 tag, the system will
display an album name or title name from
the ID3 tag information.
e system supports ID3 ver 1.0/1.1/2.2/2.3.
ID3 ver 2.2/2.3 tag information display has
priority when both ID3 ver 1.0/1.1 and ver
2.2/2.3 tags are used for a single MP3 le.
Notes
If you play back a disc containing JPEG
image les only, “JPEG” or “NO AUDIO”
appears in the display.
You cannot use TIME/TEXT to change the
di
splay of disc information when:
a JPEG image le is played back.
playback is stopped for DATA CD/DVD
w
ith MP3 les and/or JPEG image les.
playback is stopped for DATA CD/DVD
w
ith video les.
Characters that cannot be displayed appear
a
s “_.”
e elapsed playing time of MP3 les and
v
ideo les may not be displayed correctly.
Viewing information about the
disc in the on-screen display
Press TIME/TEXT.
Each time you press TIME/TEXT while
playing the disc, the display changes from
… …
e time display that you can view on the
TV screen depends on the disc you are
playing.
T: title or track
C: chapter
D: disc
Bit rate
Time information
Folder name
Track/le name
Note
e Control Menu display will show dierent
items depending on the disc type.
When playing a DVD VIDEO or DVD-
R/-RW in VR mode:
Elapsed playing time of the current
title
Remaining time of the current title
Elapsed playing time of the current
chapter
Remaining time of the current chapter
Elapsed playing time of the current
title and disc title
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
103
GB
Other Operations
When playing a VIDEO CD with PBC
function:
Elapsed playing time of the current
scene
Disc title
When playing an AUDIO CD or VIDEO
CD without PBC function:
Elapsed playing time of the current
t
rack
Remaining time of the current track
Elapsed playing time of the disc
Remaining time of the disc
Elapsed playing time of the current
track and track name
When playing MP3 les or video les
on a DATA CD/DVD:
Elapsed playing time of the current le
and folder/le name*
* If an MP3 le has the ID3 tag, the system
will display an album name or title name
from the ID3 tag information. e system
supports ID3 ver 1.0/1.1/2.2/2.3. ID3 ver
2.2/2.3 tag information display has priority
when both ID3 ver 1.0/1.1 and ver 2.2/2.3
tags are used for a single MP3 le.
Notes
Only alphabet letters, numbers and some
symbols can be displayed.
Depending on the disc, the system can only
di
splay a limited number of characters.
For MP3 les with format other than ISO
9660 L
evel 1 and Level 2, folder name and le
name may not be displayed.
Displaying the audio information of
the disc
(DVD VIDEO and video les only)
When you press AUDIO repeatedly
during playback, the format of the
current audio signal is displayed on the
TV screen.
When playing a DVD VIDEO:
For example, in Dolby Digital format,
multiple signals ranging from monaural
to 5.1 channel signals can be recorded on
a DVD VIDEO.
Example:
For Dolby Digital 5.1 channel:
2 Surround components
2 Front components +
1 Center component
1 LFE (Low Frequency
Eect) component
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
104
GB
When playing a video le:
Example: MP3 le
Bit rate
Checking the date information of JPEG
image les
When “Exif”* tag is recorded in the
JPEG image les, you can check the date
information in the Control menu by
pressing DISPLAY during playback.
Date information
* “Exchangeable Image File Format” is a
digital camera image format dened by
the “Japan Electronics & Information
Technology Industries Association” (JEITA).
Note
e date information format varies depending
on the area.
Hooking up optional
components
To enhance your system, you can connect
optional components. Refer to the
operating instructions provided with
each component.
Rear panel
SUBWOOFER OUT jack
Connect the audio input jack of an
optional subwoofer*.
* SA-GNV111D is recommended. In some
areas, the SA-GNV111D may not yet be
available.
Note
e eect may be limited or noise may
occur depending on the connected
subwoofer or the type of music being
played back.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
105
GB
Other Operations
VIDEO/SAT AUDIO IN L/R jacks
Connect the audio output jacks of an
optional component (such as VCR or
satellite tuner).
VIDEO/SAT VIDEO IN jack
Connect the video output jack of an
optional component (such as VCR or
satellite tuner).
COMPONENT VIDEO OUT jacks
Connect the component video input
jacks of the TV or projector. If your
TV accept progressive format signals,
you must use this connection and set
“PROGRESSIVE (COMPONENT
OUT)” to “ON” (page 29). You can
enjoy higher quality video images.
Notes
You cannot output the video signal from
the VIDEO/SAT VIDEO IN jack through
the COMPONENT VIDEO OUT jacks
of this unit.
You cannot output the video signal from
a
n iPod through the COMPONENT
VIDEO OUT jacks of this unit.
VIDEO OUT jack
Connect the video input jack of the
TV or projector.
DVD DIGITAL OUT jack
Connect the digital optical input jack
of an optional digital component
(such as amplier). You can enjoy
5.1 channel sound, if the connected
amplier equipped with Dolby Digital
or DTS decoder.
Notes
Sound is output only when the system
function is set to “DVD” or “USB.”
If you press AUDIO, SOUND FIELD
o
r the buttons related to Karaoke
mode, or if you connect or disconnect
microphones or headphones, the sound
cuts o for a moment.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
106
GB
Listening to a connected VCR or
satellite tuner
1
Press FUNCTION +/ repeatedly
(or press VIDEO/SAT on the unit)
to select “VIDEO” or “SAT.”
2
Start playing the connected
component.
To switch between the “VIDEO” and
“SAT” function
Hold down VIDEO/SAT on the unit and
press on the unit while the system is
on. e system switches the function
from “VIDEO” to “SAT” or vice versa.
Note
If the sound is distorted or too loud when
“VIDEO” is selected, change the function to
“SAT.”
Enjoying the multi channel
sound with the optional
amplier
1
Connect the digital optical cord.
See “Hooking up optional
components” (page 104).
2
Connect the speakers (not
supplied) to an optional
amplier equipped with a
decoder.
For the speakers placement, refer to
the operating instructions supplied
with the connected amplier.
3
Start playing a multi channel
source, such as a DVD VIDEO.
4
Select the desired audio format.
See “Changing the language/sound”
(page 40).
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
107
GB
Additional Information
Additional Information
Troubleshooting
Should you encounter a problem with
your system, do the following:
1
Make sure the power cord and
speaker cords are connected
correctly and rmly.
2
Find your problem in the
troubleshooting checklist below and
take the indicated corrective action.
If the problem persists aer doing all
of the above, consult your nearest Sony
dealer.
If the STANDBY indicator ashes
Immediately unplug the power cord,
and check the following items.
Are you using only the supplied
s
peakers?
Are the + and speaker cords
s
hort-circuited?
Is anything blocking the ventilation
h
oles on the rear of the system?
Aer the STANDBY indicator stops
ashing, reconnect the power cord,
and turn on the system. If the issue
persists, contact your nearest Sony
dealer.
General
The display starts ashing as soon
as you plug in the power cord even
though you have not turned on the
system.
Press DISPLAY once while the system
i
s o. e demonstration disappears.
“– –:– –” appears in the display.
A power failure has occurred. Set the
c
lock (page 32) and timer settings
(page 97) again.
The system does not turn on.
Is the power cord plugged in?
The clock or timer setting is canceled.
e power cord is disconnected or a
p
ower failure occurred. Redo “Setting
the clock” (page 32). If you have set
the timer, redo “Using the timer”
(page 97).
There is no sound.
Press VOLUME + repeatedly (or
t
urn MASTER VOLUME on the unit
clockwise).
e headphones are connected to the
P
HONES jack.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
108
GB
Check the speaker connections
(page 23).
ere is no audio output during Rec
T
imer.
e system is in pause mode, in Slow-
m
otion Play or in Lock Search. Press
(or on the unit) to start the
playback.
No sound is output when transferring
m
usic to the USB device.
There is no microphone sound.
Press VOLUME + repeatedly (or
t
urn MASTER VOLUME on the
unit clockwise) or turn MIC LEVEL
on the unit clockwise to adjust the
microphone volume.
Make sure the microphone is
co
nnected to MIC jack correctly.
Make sure the microphone is turned
o
n.
There is severe hum or noise.
A TV or VCR is placed too close to the
unit. Move the unit away from the TV
or VCR.
Move the unit away from the source of
n
oise.
Connect the unit to a dierent wall
o
utlet.
Install a noise lter (commercially
a
vailable) to the power cord.
The timer does not function.
Check the timer setting and set the
co
rrect time (page 97).
Cancel the Sleep Timer function.
T
he remote does not function.
Remove the obstacles between the
remote and the unit.
Move the remote closer to the unit.
Point the remote at the unit’s sensor.
Replace the batteries (R6/size AA).
Locate the unit away from the
uorescent light.
There is acoustic feedback.
Reduce the volume.
Move the microphone away from the
s
peakers or change the direction of the
microphone.
The color irregularity on the TV
screen persists.
Turn o the TV set once, then turn it
on aer 15 to 30 minutes. If the color
irregularity still persists, place the
speakers farther away from the TV set.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
109
GB
Additional Information
The sound from the component
connected to the VIDEO/SAT AUDIO
IN L/R jacks is distorted.
If “VIDEO” appears in the display
w
hen you press VIDEO/SAT on the
unit, switch the display to “SAT” (see
“To switch between the “VIDEO” and
“SAT” function” (page 106)).
“THEATRE SYNC” function does not
work.
If distance between the TV and this
uni
t is too far, this function may not
work. Install the unit near the TV.
Speakers
Sound comes from one channel or
unbalanced left and right volume.
Place the speakers as symmetrically as
p
ossible.
Check that the speakers are connected
s
ecurely and correctly.
e source being played back is
m
onaural.
Sound lacks bass.
Check that the speaker’s + and
t
erminals are connected correctly.
Disc Player
The disc does not eject and “LOCKED”
appears in the display.
Consult your nearest Sony dealer or
lo
cal authorized Sony service facility.
The disc tray does not close.
Load the disc correctly.
Always close the disc tray by pressing
O
PEN/CLOSE on the unit. Do not
forcibly push the disc tray to close it as
this may cause a malfunction.
The system does not eject the disc.
You cannot eject the disc when
p
erforming CD Synchro Recording or
USB TRANSFER. Press to cancel the
operation, then press OPEN/CLOSE
on the unit to eject the disc.
Consult your nearest Sony dealer.
Pla
yback does not start.
Check whether a disc is loaded.
Wipe the disc clean (page 124).
Reload the disc.
Load the disc that this system can play
b
ack (page 36).
Load the disc on the disc tray with the
l
abel side facing up.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
110
GB
Remove the disc and wipe away the
moisture on the disc, then leave the
system turned on for a few hours until
the moisture evaporates.
Press (or on the unit) to start
p
layback.
e region code on the DVD VIDEO
do
es not match the system.
The sound skips.
Wipe the disc clean (page 124).
Reload the disc.
Move the unit to a place without
v
ibration (e.g., on top of a stable
stand).
Move the speakers away from the
uni
t, or place them on separate stands.
When you listen to a track or le
with bass sounds at high volume, the
speaker vibration may cause the sound
to skip.
Playback does not start from the rst
track.
Shue Play mode, Program Play mode
o
r Repeat Play mode is selected.
Resume playback has been selected.
P
ress twice. en, press (or
on the unit) to start playback (page 37).
e title of DVD VIDEO or PBC
m
enu automatically appears on the TV
screen.
Playback starts automatically.
e DVD VIDEO features an auto
p
layback function.
Playback stops automatically.
Some discs may contain an auto pause
sig
nal. While playing such a disc, the
playback stops at auto pause signal.
You cannot perform some functions
such as Stop, Lock Search, Slow-
motion Play, Repeat Play, Shue Play
or Program Play.
Depending on the disc, you may not
b
e able to do some of the operations
above. Refer to the operating
instructions supplied with the disc.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
111
GB
Additional Information
The DATA CD/DVD (MP3 le/JPEG
image le/DivX video le/MPEG4
video le) cannot be played back.
e DATA CD is not recorded in a
f
ormat that conforms to ISO 9660
Level 1, Level 2, or Joliet (expansion
format).
e DATA DVD is not recorded
in a f
ormat that conforms to UDF
(Universal Disk Format).
e MP3 le does not have the
ext
ension “.mp3.”
e data is not stored in the desired
f
ormat.
e audio le is not stored in MP3
(MP
EG 1 Audio Layer 3) format.
e system can play back to a depth of
8 f
olders only.
e disc contains more than
200
folders.
e folder contains more than 150 les.
e JPEG image le does not have the
ext
ension “.jpg” or “.jpeg.”
e JPEG image le is larger than
3,072 (w
idth) × 2,048 (height) in
normal mode, or more than 2,000,000
pixels in Progressive JPEG mode which
is mainly used on the Internet website.
JPEG image les with a high width to
len
gth ratio cannot be played back.
For MP3 les and JPEG image les, the
D
ATA CD/DVD contains a video le.
e MPEG4 video le does not have
t
he extension “.mp4” or “.m4v.”
e DivX video le does not have the
ext
ension “.avi” or “.divx.”
e video le is larger than 720 (width)
× 576 (h
eight).
If you cannot change the “MEDIA”
s
etting, re-load the disc or turn the
system o, then on.
The MP3 les take longer time to play
back than others.
Aer the system reads all the MP3 les
on the disc, playback may take more
time than usual if:
the number of folders or MP3 les
on the disc is very large.
the le structure is extremely
complex.
“Data error” appears on the TV
screen when playing a DATA CD/DVD.
e MP3 le/JPEG image le you want
t
o play is broken.
e MP3 le does not conform to
MP
EG 1 Audio Layer 3.
e JPEG image le format does not
co
nform to DCF.
e JPEG image le has the extension
“
.jpg” or “.jpeg,” but is not in JPEG
format.
e DivX video le has the extension
“
.avi” or “.divx,” but is not in DivX
format.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
112
GB
e DivX video le does not conform
to a DivX Certied prole.
e MPEG4 video le has the
ext
ension “.mp4” or “.m4v,” but does
not conform to MPEG4 Simple Prole.
The disc title, CD-TEXT and DVD-TEXT
characters do not appear properly.
e disc is recorded in format other
t
han ISO 9660 Level 1, Level 2 or Joliet
(expansion).
e character code that can be
di
splayed by this system are as follows:
Upper cases (A to Z)
Numbers (0 to 9)
Symbols (< > * +, ? / [ ] \ _)
Other characters appear as “”.
The surround eect is dicult to hear
when you are playing a Dolby Digital
or MPEG audio sound track.
Make sure the sound eld is set
p
roperly (page 91).
Check the speaker connection
(p
age 23).
Depending on the DVD VIDEO, the
o
utput signal may not be the entire 5.1
channel. It may be monaural or stereo,
even if the sound track is recorded in
Dolby Digital or MPEG audio format.
The sound loses stereo eect when
you play back a DVD VIDEO, VIDEO
CD, A
UDIO CD, MP3 le or video le.
Unplug the microphone or press
K
ARAOKE MODE repeatedly until
“KARAOKE MODE: OFF” appears in
the display.
Make sure the system is connected
properly.
Check the speaker connection
(p
age 23).
iPod
There is no sound.
Make sure the iPod is connected
s
ecurely.
Make sure the iPod is updated with the
l
atest soware. If not, update the iPod
before using with the system.
Make sure the iPod is playing music.
Adjust the volume.
It may take time to start playback
dep
ending on the contents.
The sound is distorted.
Turn down the volume.
Set the “EQ” setting of the iPod to
“
O” or “Flat.”
The remote does not function.
Make sure the iPod is connected
s
ecurely.
Make sure the iPod is updated with the
l
atest soware. If not, update the iPod
before using with the system.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
113
GB
Additional Information
The iPod cannot be charged.
Make sure the iPod is connected
s
ecurely.
You can use the system as a battery
c
harger for iPod only when the system
is on.
Video/photo image from the iPod
does not appear on the TV screen.
Set the operating mode to the iPod
Display mode to display photo images
(page 67).
Check that the TV output setting on
t
he iPod is on. (Refer to the user’s
guide of your iPod.)
Check that the iPod is compatible with
v
ideo output. (Refer to the user’s guide
of your iPod.)
Video/photo image from the iPod
does not appear on the iPod display.
Adjust the video/photo image output
s
ettings to the appropriate settings.
On screen display does not appear on
the TV screen.
Check that the operating mode is set to
t
he Main Display mode (page 67).
USB device
You cannot start transferring or
recording to a USB device.
e following problems may have
o
ccurred.
e USB device is full.
e number of les and folders on
t
he USB device has reached the
upper limit.
e USB device is write-protected.
T
ransferring or recording is stopped
before it is nished.
You are using an unsupported USB
de
vice. See “Compatible devices
with this system” (page 130) for the
supported device types.
e USB device is not formatted
co
rrectly. Refer to the operating
instructions supplied with the USB
device for how to format.
Turn o the system and remove the
US
B device. If the USB device has a
power switch, turn the USB device
o and then on again aer removing
it from the system. en perform
transferring or recording again.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
114
GB
If the transfer, recording and erase
operations are repeated multiple times,
the le structure within the USB device
becomes fragmented. Refer to the
operating instructions supplied with
the USB device for how to deal with
this problem. If the problem persists,
contact your nearest Sony dealer.
Transferring or recording results in
an error.
You are using an unsupported USB
device. See “Compatible devices
with this system” (page 130) for the
supported device types.
Turn o the system and remove the
US
B device. If the USB device has a
power switch, turn the USB device
o and then on again aer removing
it from the system. en perform
transferring or recording again.
e USB device was disconnected
o
r the power was turned o during
the transfer or recording process.
Delete the partially-transferred le or
partially-recorded le, and perform
transferring or recording again. If this
does not x the problem, the USB
device may be broken. Refer to the
operating instructions supplied with
the USB device for how to deal with
this problem. If the problem persists,
contact your nearest Sony dealer.
MP3
les or folders on the USB
device cannot be erased.
Check if the USB device is
w
rite-protected.
e USB device was disconnected
o
r the power was turned o during
the erase operation. Delete the
partially-erased le. If this does not
x the problem, the USB device may
be broken. Refer to the operating
instructions supplied with the USB
device for how to deal with this
problem. If the problem persists,
contact your nearest Sony dealer.
Are you using a supported USB
device?
If you connect an unsupported USB
de
vice, the following problems may
occur. See “Compatible devices
with this system” (page 130) for the
supported device types.
e USB device is not recognized.
File or folder names are not
di
splayed on this system.
Playback is not possible.
e sound skips.
ere is noise.
A distorted sound is output.
Transferring or recording stops
b
efore it is nished.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
115
GB
Additional Information
“OVER CURRENT” appears.
A problem has been detected with the
le
vel of electrical current from the
(USB) port. Turn o the system and
remove the USB device from the
(USB) port. Make sure there is no
problem with the USB device. If this
display pattern persists, contact your
nearest Sony dealer.
There is no sound.
e USB device is not connected
co
rrectly. Turn o the system and
reconnect the USB device, then turn
on the system and check if “USB
MEMORY” lights up.
There is noise, skipping, or distorted
sound.
Turn o the system, then reconnect the
US
B device.
e music data itself contains noise,
o
r the sound is distorted. Noise may
have entered during the transfer or
recording process. Delete the le, and
try transferring or recording again.
e bit rate used when encoding audio
les was low. Send audio les with
higher bit rate to the USB device.
The USB device cannot be connected
into the
(USB) port.
e USB device is being connected
b
ackwards. Connect the USB device in
the correct orientation.
“READING” is displayed for an
extended time, or it takes a long time
before playback starts.
e reading process can take a long
t
ime in the following cases.
ere are many folders or les on the
US
B device.
e le structure is extremely
co
mplex.
e memory capacity is excessive.
e le size is extremely large.
e internal memory is fragmented.
us, we recommend following these
guidelines.
Total folders on USB device: 200 or
les
s
Total les per folder: 150 or less
Err
oneous display
Send the music data to the USB device
a
gain, as the data stored in the USB
device may have been corrupted.
e character code that can be
di
splayed by this system are as follows:
Upper cases (A to Z)
Numbers (0 to 9)
Symbols (< > * +, ? / [ ] \ _)
Other characters appear as “_.”
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
116
GB
The USB device is not recognized.
Turn o the system and reconnect the
US
B device, then turn on the system.
Connect the supported USB device
(s
ee “Compatible devices with this
system” (page 130)).
e USB device does not work
p
roperly. Refer to the operating
instructions supplied with the USB
device for how to deal with this
problem. If the problem persists,
contact your nearest Sony dealer.
“Data error” appears on the display
when playing a USB device.
e MP3 le/JPEG image le you want
to play is broken.
e JPEG image le format does not
co
nform to DCF.
e JPEG image le has the extension
“
.jpg” or “.jpeg,” but is not in JPEG
format.
Play does not start.
Turn o the system and reconnect the
US
B device, then turn on the system.
Connect the supported USB device
(s
ee “Compatible devices with this
system” (page 130)).
Press (or on the unit) to start
p
layback.
Play does not start from the rst
track.
Set the play mode to Normal Play
m
ode.
Files cannot be played back.
e MP3 le does not have the
ext
ension “.mp3.”
e WMA le does not have the
ext
ension “.wma.”
e AAC le does not have the
ext
ension “.m4a.”
e DivX video le does not have the
ext
ension “.avi” or “.divx.”
e MP4 le does not have the
ext
ension “.mp4.”
e audio le is not stored in MP3/
WMA/AA
C/MP4 format.
e video le is not stored in MP4/
Di
vX format.
e JPEG image le does not have the
ext
ension “.jpg” or “.jpeg.”
e JPEG image le is larger than
3,072 (w
idth) × 2,048 (height) in
normal mode, or more than 2,000,000
pixels in Progressive JPEG mode which
is mainly used on the Internet website.
JPEG image les with a high width to
len
gth ratio cannot be played back.
Check the “MEDIA” setting (page 137).
USB device formatted with le systems
o
ther than FAT12, FAT16 or FAT32 are
unsupported.*
e MP3 le is not stored in MP3
(MP
EG 1 Audio Layer 3) format.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
117
GB
Additional Information
e WMA le stored in WMA DRM/
WMA Lossless/WMA PRO format
cannot be played back.
e AAC le stored in copyright-
p
rotected AAC or AAC Lossless format
cannot be played back.
AAC les encoded at a sampling
f
requency of 96 kHz cannot be played
back.
If you use a partitioned USB device,
o
nly audio les on the rst partition
can be played.
e system can play back to a depth of
8 f
olders only.
e number of folders has exceeded
200.
e number of les has exceeded 150.
Files that are encrypted or protected by
p
asswords, etc. cannot be played back.
* is system supports FAT12, FAT16 and
FAT32, but some USB devices may not
support all of these FAT. For details, see the
operating instructions of each USB device or
contact the manufacturer.
There is no picture.
e “VIDEO/SAT” function is
s
elected, but there is no input signal.
Check that the system is connected
s
ecurely.
e video cord is damaged. Replace it
w
ith a new one.
Make sure you connect the unit to the
v
ideo input jack of your TV (page 104).
Make sure you turn on the TV and
o
perate the TV correctly.
Make sure you select the video input
o
n the TV so that you can view the
pictures from the system.
Make sure you set the color system
co
rrectly, according to your TV’s color
system (Australian model only).
Make sure you connect the unit and
y
our TV using only the supplied video
cord.
Set “PROGRESSIVE (COMPONENT
O
UT)” to “OFF” if you connect your
TV to the COMPONENT VIDEO
OUT jacks and your TV cannot accept
progressive signal.
You have set to progressive format
b
ut your TV cannot accept the signal
in progressive format. In this case,
connect the VIDEO OUT jack to the
TV and set to the Interlace format
(page 28).
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
118
GB
Even if your TV is compatible with
progressive format (525p/625p)
signals, the image may be aected
when you set to progressive format. In
this case, set to interlace format (the
default setting) (page 28).
Picture noise appears.
Wipe the disc clean (page 124).
If video signal from your system has to
g
o through your VCR to your TV, the
copy-protection applied to some DVD
VIDEO programs could aect the
picture quality.
When you play back a VIDEO CD
r
ecorded in a dierent color system
from the one you set to the system,
the picture image may be distorted
(Australian model only) (page 64).
When you connect your TV to the
C
OMPONENT VIDEO OUT jacks
and play back video-based soware
in progressive signal format, some
sections of the image may appear
unnatural due to the conversion
process.
Set the color system to match your TV
(A
ustralian model only) (page 28).
The aspect ratio of the TV screen
cannot be changed even though
you can set “TV TYPE” under “VIDEO
SETUP” in the Setup Menu when you
play back a wide picture.
e aspect ratio is xed on your DVD
VID
EO.
Depending on the TV, you may not
c
hange the aspect ratio.
Messages do not appear on the TV
screen in your desired language.
Select the language for the on-screen
display in “OSD” under “LANGUAGE
SETUP” in the Setup Menu (page 33).
The language for the sound track
cannot be changed.
Multilingual tracks are not recorded on
t
he DVD VIDEO being played back.
e DVD VIDEO prohibits changing
t
he language for the sound track.
The subtitles language cannot be
changed.
Multilingual subtitles are not recorded
on the DVD VIDEO being played
back.
e DVD VIDEO prohibits changing
t
he subtitles.
The subtitles cannot be turned o.
e DVD VIDEO prohibits turning o
s
ubtitles.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
119
GB
Additional Information
The angles cannot be changed.
Multi-angles are not recorded on the
D
VD VIDEO being played back.
e DVD VIDEO prohibits changing
t
he angles.
Tuner
The radio presetting is canceled.
e power cord is disconnected or a
p
ower failure occurred for longer than
a day. Redo “Presetting a radio station”
(page 65).
There is severe hum or noise.
(“TUNED” or “STEREO” ashes in the
display.)
Set the proper band and frequency
(p
age 64).
Connect the antenna properly
(p
age 23).
Find a place and an orientation that
p
rovide good reception, then set up
the antenna again. If you cannot obtain
good reception, we recommend that
you connect a commercially available
external antenna.
e supplied FM lead antenna receives
sig
nals along its entire length, so make
sure you extend it fully.
Locate the antennas as far away from
t
he speaker cords and the power cord
as possible, to avoid picking up noise.
Try turning o the surrounding
e
lectrical equipment.
A stereo FM program cannot be
received in stereo.
Press REPEAT/FM MODE repeatedly
un
til “MONO” disappears from the
display.
Optional components
There is no sound.
Refer to General item “ere is no
s
ound.” (page 107) and check the
condition of the system.
Connect the component properly
(p
age 104) while checking:
if the cords are connected properly.
if the cord plugs are rmly inserted
all the way.
Turn on the connected component.
Refer to the operating instructions
s
upplied with the connected
component and start playback.
To change the AM tuning interval
e AM tuning interval is factory-preset
to 9 kHz or 10 kHz (for some areas).
1
Press FUNCTION +/ or TUNER/
BAND repeatedly to select “AM”.
2
Press / to turn o the system.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
120
GB
3
Press DISPLAY repeatedly until “Sony
DEMO” appears in the display.
4
Press / on the unit while holding
down TUNING + on the unit.
“AM 9K STEP” or “AM 10K STEP”
appears in the display.
When you change the interval, all the
AM preset stations are erased.
If the system still does not operate
properly after performing the
above measures or other troubles
not described above occur, reset the
system as follows:
Use buttons on the unit to reset the
system to its factory default settings.
1
Unplug the power cord.
2
Plug the power cord back in.
3
Press to turn on the system.
4
While holding down , press DISC 3
and press at the same time.
“COLD RESET” appears in the display.
e system is reset to the factory
settings except for the “SETUP”
settings. You should set the settings
you made, such as the preset stations,
clock and timer.
To return the “SETUP” settings to the
default settings*, perform reset as
follows:
1
Press DISPLAY when playback is
stopped.
e Control Menu appears on the TV
screen.
2
Press or repeatedly to select
(SETUP), then press ENTER.
3
Press or repeatedly to select
“CUSTOM,” then press ENTER.
e Setup Menu appears.
4
Press or repeatedly to select
“SYSTEM SETUP,” then press ENTER.
5
Press or repeatedly to select
“RESET,” then press ENTER.
6
Press or repeatedly to select
“YES,” then press ENTER.
It takes a few seconds to complete.
Do not press when resetting the
system.
* Except for “PARENTAL CONTROL” settings
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
121
GB
Additional Information
Self-diagnosis Function
(When letters/numbers appear in the
display)
When the self-diagnosis function
is activated to prevent the system
from malfunctioning, a 5-character
service number (e.g. C 13 50) with a
combination of a letter and 4 digits
appears on the TV screen or the front
panel display. In this case, check the
following table.
First 3
characters of
the service
number
Cause and corrective
action
C 13 is disc is dirty.
Clean the disc with a
s
o cloth (page 125).
C 31 e disc is not inserted
correctly.
Restart the system,
t
hen re-insert the
disc correctly.
E XX
(XX is a
number)
To prevent a
malfunction, the
system has performed
the self-diagnosis
function.
Contact your nearest
S
ony dealer or local
authorized Sony
service facility and
give the 5-character
service number.
Example: E 61 10
When displaying the version number
on the TV screen
When you turn on the system, the
version number [VER.X.XX] (X is a
number) may appear on the TV screen.
Although this is not a malfunction and
for Sony service use only, normal system
operation will not be possible. Turn o
the system, and then turn on the system
again to operate.
Messages
Messages similar to the following, or
more detailed information, may appear
on the TV screen during operation.
CANNOT PLAY
A disc that cannot be played back was
inserted.
A DVD VIDEO with unsupported
r
egion code was inserted.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
122
GB
DATA ERROR
You tried to play a le on the USB device
that is not playable.
DATA ERROR (for DATA CD/DVDs)
e MP3 le, JPEG image le, DivX
v
ideo le and MPEG4 video le you
want to play back is damaged.
e MP3 le does not conform to
MP
EG 1 Audio Layer 3 format.
e JPEG image le does not conform
t
o DCF format.
e MP3 le has the extension “.mp3,”
b
ut is not in MP3 format.
e JPEG image le has the extension
“
.jpg” or “.jpeg,” but is not in JPEG
format.
e DivX video le does not conform
t
o DivX Certied proles.
e DivX video le has the extension
“
.avi” or “.divx,” but is not in DivX
format.
e MPEG4 video le has the
ext
ension “.mp4” or “.m4v,” but does
not conform to MPEG4 Simple Prole.
DEVICE ERROR
e USB device could not be recognized
or an unknown device is connected.
DEVICE FULL
e USB device is full.
DVD NO DISC
ere is no disc on the disc tray.
ERASE ERROR
Erase of audio les or folders on the USB
device failed.
FATAL ERROR
e USB device has been disconnected
while transferring to the USB device.
FOLDER FULL
e number of folders on the USB device
has reached the maximum.
HUB NOT SUPPORTED
You have connected a USB hub to this
system.
INVALID
You have pressed an invalid button.
JPEG
A JPEG image le is being played back.
NO AUDIO
ere is no audio le in the selected
folder.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
123
GB
Additional Information
NO DATA
ere is no le or folder to play back.
NO USB DEVICE
No USB device is connected.
NOT IN USE
You have pressed a button whose
operation is not allowed or invalid at that
time.
NOT SUPPORT
An unsupported USB device is
connected.
OFF TIME NG!
e on time and o time of Play Timer or
Rec Timer is the same.
OVER CURRENT
An over current from the
(USB) port
was detected.
PASSWORD
“PARENTAL CONTROL” is set.
PLEASE WAIT
e system is doing initialization
p
rocess.
e system is readying for usage of a
US
B device.
PROTECTED
e USB device is write-protected.
PUSH STOP
You have pressed the buttons whose
operation is only possible when playback
is stopped.
READING
e system is reading information
o
f the disc. Some buttons are not
available.
e system is recognizing the USB
de
vice.
REC ERROR
Transferring did not start, stopped
partway, or otherwise could not be
performed.
TRACK FULL
e number of audio les on the USB
device has reached the maximum.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
124
GB
Precautions
Notes on discs
Before playing, wipe the disc with a cleaning
cloth from the center out to the edge.
Do not clean discs with solvents, such as
b
enzine, thinner, or commercially available
cleaners or anti-static spray intended for
vinyl LPs.
Do not expose discs to direct sunlight or heat
s
ources such as hot air ducts, nor leave it in a
car parked in direct sunlight.
Region code of DVD VIDEOs you can
play back on this system
Your system has a region code printed on the
back of the unit and will only play back DVD
VIDEOs labeled with identical region code.
DVD VIDEOs labeled
will also be played
back on this system.
If you try to play back any other region
code DVD VIDEO, the message “Playback
prohibited by area limitations.” will appear
on the TV screen. Depending on the DVD
VIDEO, no region code indication may be
labeled even though playing the DVD VIDEO
is prohibited by area restrictions.
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side
with digital audio material on the other side.
However, since the audio material side does not
conform to the Compact Disc (CD) standard,
playback on this product is not guaranteed.
Notes on CD-R/-RW and DVD-R/-
RW/+R/+RW
In some cases, CD-Rs/-RWs and DVD-
Rs/-RWs/+Rs/+RWs cannot be played
back on this system due to the recording
quality or physical condition of the disc, or
the characteristics of the recording device
and authoring soware. e disc will not
be played back if it has not been correctly
nalized. For more information, see the
operating instructions for the recording
device.
N
ote that some playback functions may not
w
ork with some DVD+Rs/+RWs, even if
they have been correctly nalized. In this
case, view the disc by normal playback.
A di
sc created in Packet Write format cannot
b
e played back.
Note on playback operations of DVD
VIDEOs and VIDEO CDs
Some playback operations of DVD VIDEOs
and VIDEO CDs may be intentionally set by
soware producers. Since this system play back
DVD VIDEOs and VIDEO CDs according
to the disc contents the soware producers
designed, some playback features may not
be available. Also, refer to the instructions
supplied with the DVD VIDEOs or VIDEO
CDs.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
125
GB
Additional Information
Music discs encoded with copyright
protection technologies
is product is designed to play back discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware
that among those discs, there are some that do
not conform to the CD standard and may not
be playable by this product.
Notes on Multi Session disc
If the rst session is recorded in AUDIO CD
or VIDEO CD format, only the rst session
will be played back.
e system will recognize a Multi Session
di
sc as an AUDIO CD if there is a session
recorded in AUDIO CD format on the disc.
However, the system will only play back the
disc if the rst session is recorded in AUDIO
CD format.
is system can play back Multi Session
di
scs when an MP3 le, a JPEG image le,
a DivX video le or an MPEG4 video le is
contained in the rst session. Any subsequent
MP3 les, JPEG image les, DivX video
les or MPEG4 video les recorded in later
sessions can also be played back.
Note on copyright-protected content
e transferred music is limited to private
use only. Use of the music beyond this limit
requires permission of the copyright holders.
On cleaning discs, disc/lens cleaner
Do not use a commercially available cleaning
disc or disc/lens cleaner (wet or spray type).
ese may cause apparatus to malfunction.
On operating voltage
Before operating the system, check that the
operating voltage of the unit is identical with
the voltage of your local power supply.
On safety
Completely disconnect the power cord
(mains lead) from the wall outlet (mains)
if it is not going to be used for an extended
period of time. When unplugging the unit,
always grip the plug. Never pull the cord
itself.
Should any solid object or liquid get into
t
he system, unplug the system, and have
it checked by qualied personnel before
operating it again.
On placement
Do not place the system in an inclined
position or in locations that are extremely
hot, cold, dusty, dirty, or humid or lacking
adequate ventilation, or subject to vibration,
direct sunlight or a bright light.
Be careful when placing the unit or speakers
o
n surfaces that have been specially treated
(for example, with wax, oil, polish) as
staining or discoloration of the surface may
result.
If the system is brought directly from a cold
t
o a warm location or is placed in a very
damp room, moisture may condense on the
lens inside the DVD player, and cause the
system to malfunction. In this situation,
remove the disc, and leave the system turned
on for about an hour until the moisture
evaporates.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
126
GB
On heat buildup
Heat buildup on the unit during operation is
normal and is not cause for alarm.
Do not touch the cabinet if it has been used
co
ntinuously at a high volume because the
cabinet may have become hot.
Do not obstruct the ventilation holes.
In case color irregularity is observed
on a nearby TV screen
With the magnetically shielded type of
speakers, the speakers can be installed near a
TV set. However, color irregularity may still
be observed on the TV screen depending on
the type of your TV set. In this situation, turn
o the TV, wait 15 to 30 minutes, and turn it
back on. If there is no improvement, move the
speakers far away from the TV.
IMPORTANT NOTICE
Caution: If you leave a still video image
or on-screen display image displayed on
your TV for an extended period of time via
this system, you risk permanent damage
to your TV screen. Projection TVs are
especially susceptible to this.
Cleaning the cabinet
Clean this system with a so cloth slightly
moistened with a mild detergent solution.
Do not use any type of abrasive pad, scouring
powder, or solvent, such as thinner, benzine,
or alcohol.
Specications
Main unit
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(LBT-LCD7Di e United States model
only)
W
i
th 6 ohm loads, both channels driven,
from 120 10,000 Hz; rated 85 watts per
c
hannel minimum RMS power, with no
more than 1% total harmonic distortion
f
r
om 800 milliwatts to rated output.
Amplier section
e following measured at AC 120 V, 60 Hz
(North American model)
e f
ollowing measured at AC 230 V,
50/60 Hz (European model)
e following measured at AC 240 V,
50/60 Hz (Australian model)
MHC-GZR33Di
Power output (rated):
105 W + 105 W (at 6 , 1 kHz, 1%
THD)
RMS output power (reference):
180 W + 180 W (per channel at 6 ,
1
kHz, 10% THD)
LBT-LCD7Di
Power output (rated):
105 W + 105 W (at 6 , 1 kHz, 1%
THD)
RMS output power (reference):
180 W + 180 W (per channel at 6 ,
1
kHz, 10% THD)
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
127
GB
Additional Information
Inputs
VIDEO/SAT VIDEO IN (phono jack):
1 Vp-p, 75 ohms
VIDEO/SAT AUDIO IN L/R (phono jacks):
voltage 250/450 mV, impedance
47
kilohms
MIC 1/MIC 2 (phone jacks):
sen
sitivity 1 mV, impedance
10 kilohms
Outputs
VIDEO OUT (phono jack):
max. output level 1 Vp-p, unbalanced,
Sync negative, load impedance
75
ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
P/C: 0.7 Vp-p, 75 ohms
P/C: 0.7 Vp-p, 75 ohms
DVD DIGITAL OUT (Square optical
connector jack, rear panel):
Wavelength 650 nm
PHONES (stereo mini jack):
accepts headphones of 8 ohms or
more
SUBWOOFER OUT:
Voltage 1 V, impedance 1 kilohm
FRONT SPEAKER:
MHC-GZR33Di:
Use only the supplied speaker
SS
-
GZR77D.
LBT-LCD7Di:
Use only the supplied speaker
SS-LCD7Di.
(USB) port: Type A (1)
Maximum current:
500 mA
Disc player section
System:
Compact disc and digital audio and
video system
Laser Diode Properties
Emission duration: Continuous
Laser Output*: Less than 44.6µW
* is output is the value measurement
at a distance of 200mm from the
objective lens surface on the Optical
Pick-up Block with 7mm aperture.
Frequency response
DVD (PCM 48 kHz): 2 Hz 22 kHz
(±1
dB)
CD: 2 Hz 20 kHz (±0.5 dB)
Video color system format
North American model: NTSC
Other models: NTSC and PAL
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
North American model:
87.5 108.0 MHz (100 kHz step)
Other models:
87.5 108.0 MHz (50 kHz step)
Antenna:
FM lead antenna
Antenna terminals:
75 Ω unbalanced
Intermediate frequency:
10.7 MHz
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
128
GB
AM tuner section
Tuning range:
North American and Australian
models:
531 1,710 kHz (with 9 kHz tuning
interval)
530 1,710 kHz (with 10 kHz tuning
interval)
European model:
531 1,602 kHz (with 9 kHz tuning
interval)
Antenna:
AM loop antenna
Antenna terminals:
External antenna terminal
Intermediate frequency:
450 kHz
Speaker
Front speaker (SS-GZR77D) for MHC-
GZR33Di
Front speaker (SS-LCD7Di) for LBT-
LCD7Di
Speaker system:
3-way, Bass reex, Magnetically
shielded
Speaker unit
Subwoofer: 130 mm, cone type
Woofer: 130 mm, cone type
Tweeter: 50 mm, horn type
Rated impedance: 6 ohms
Dimensions (w/h/d):
Approx. 252 × 349 × 265 mm
Mass:
Approx. 4.8 kg
General
Power requirements
North American model:
AC 120 V
, 60 Hz
European model:
AC 230 V
, 50/60 Hz
Australian model:
AC 230 240 V, 50/60 Hz
Power consumption
MHC-GZR33Di: 150 W
LBT-LCD7Di: 150 W
Dimensions (w/h/d) (excl. speakers)
MHC-GZR33Di:
Approx. 280 × 326 × 440 mm
LBT-LCD7Di:
Approx. 280 × 326 × 440 mm
Mass (excl. speakers)
MHC-GZR33Di: Approx. 11.4 kg
LBT-LCD7Di: Approx. 11.4 kg
Supplied accessories:
Remote Commander (1)
AM loop antenna (1)
FM lead antenna (1)
Video cord (1)
Speaker foot (8)
R6 (Size AA) batteries (2)
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
129
GB
Additional Information
Supported le format
MP3 (MPEG 1 Audio Layer-3)
File extension: .mp3
Bitrate: 32 320 kbps, VBR
Sampling frequencies: 32/44.1/48 kHz
WMA
File extension: .wma
Bitrate: 48 192 kbps
Sampling frequencies: 44.1 kHz
AAC
File extension: .m4a
Bitrate: 48 320 kbps
Sampling frequencies: 44.1 kHz
DivX
File extension: .avi/.divx
Video codec: DivX video
Bitrate: 8 Mbps (MAX)
Frame rate: 30 fps
Resolution: 720 × 576
Audio codec: MP3
MPEG4
File format: MP4 File Format
File extension: .mp4/.m4v
Video codec:
MPEG4 Simple Prole
(AVC is not compatible.)
Bitrate: 4 Mbps
Frame rate: 30 fps
Resolution: 720 × 576
Audio codec:
AAC-LC
(HE-AAC is not compatible.)
DRM: Not compatible
Design and specications are subject to
change without notice.
Standby power consumption: 0.5 W
Halogenated ame retardants are not used
in the certain printed wiring boards.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
130
GB
Compatible devices
with this system
You can use the following devices on this
system.
Veried Sony USB devices
Product name Model name
Walkman
®
NWD-B103 / B105 /
B103F / B105F
NWD-E023F / E025F
NWZ-A815 / A816 /
A816B / A818
NWZ-A726 / A726B /
A728 / A728B / A729 /
A826 / A828
/ A829
NWZ-B133 / B135 /
B133F / B135F
NWZ-E435F / E436F
/
E438F
NWZ-S515 / S516
/
S615F / S616F /
S618F
/ S715F /
S716F / S718F
NWZ-S636F / S638F /
S639F / S736F /
S738F
/ S739F
IC Recorder ICD-UX71 / UX81 /
UX91
ICD-SX700 / SX800 /
SX900
MICROVAULT USM512JX / 1GJX /
2GJX / 4GJX
USM512JX / 1GJX /
2GJX / 4GJX
USM1GL / 2GL /
4GL
/ 8GL / 16GL
USM1GLX / 2GLX /
4GLX / 8GLX / 16GLX
Veried Sony Ericsson mobile phone
Product name Model name
Walkman
®
phone
W302 / W350i /
W380i
/ W580i /
W595 / W660i /
W710i / W760i /
W850i / W880i /
W890i / W902 /
W910i / W960i /
W980
Notes
When formatting the USB device, be sure
to format using the device itself or the
dedicated formatting soware for that device.
Otherwise, you may be unable to transfer
music to the USB device properly on this
system.
Do not use USB devices other than these
US
B devices. Operation of models not listed
here is not guaranteed.
Operation may not always be ensured even
w
hen using these USB devices.
Some of these USB devices may not be
a
vailable for purchase in certain areas.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
131
GB
Additional Information
Notes on using the Sony Ericsson
mobile phone
Connect to this system with the power of the
mobile phone on.
When connecting to this system, set the data
t
ransfer mode of your mobile phone to File
Transfer (Mass Storage). For details, refer
to the operation manual supplied with the
mobile phone.
Use the USB cable supplied with the mobile
p
hone when connecting to this system.
While the mobile phone is connected to this
sys
tem, do not insert or remove the memory
card.
Some les supported by the mobile phone are
n
ot supported by this system.
In the case that the song which is registered
a
s the playlist in the mobile phone is erased
by this system, the playlist registration is not
deleted.
e Play Timer and Rec Timer in this system
a
re not supported.
Notes on Walkman
®
Some les supported by the Walkman
®
are
not supported by this system.
When transferring music to a Walkman
®
using “Media Manager for WALKMAN,” be
sure to transfer in MP3 format.
When connecting a Walkman
®
to the
system, be sure to connect aer the display
“Creating Library” or “Creating Database” on
the Walkman
®
has disappeared.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
132
GB
Compatible iPod models with this system
You can use the following iPod models on this system. Update your iPod with the latest
soware before using it.
iPod touch 2nd
generation
iPod nano 4th
generation
(video)
iPod touch 1st
generation
iPod nano 3rd
generation
(video)
iPod classic iPod nano 2nd
generation
(aluminum)
iPod 5th
generation
(video)
iPod nano 1st
generation
iPod 4th
generation
(color display)
iPod 4th
generation
iPod mini
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
133
GB
Additional Information
Guide to the Control Menu display
Use the Control Menu to select a function and to view related information. Press
DISPLAY repeatedly to turn on, turn o or change the Control Menu display as
follows:
Control Menu display 1 Control Menu display 2* Control Menu display o
Control Menu display 1 …
* Control Menu display 2 appears when available.
Control Menu display
e Control Menu display 1 and 2 will show dierent items depending on the disc type.
Example: Control Menu display 1 when playing a DVD VIDEO
Currently playing title number
Currently playing chapter number
Total number of titles
Total number of chapters
Playback status ( Playback,
Pause, Stop, etc.)
Type of disc being
played back
Elapsed playing time
Current setting
Options
Control Menu
items
Selected item
Function name of
selected Control
Menu item
Operation message
To turn o the Control Menu
Press DISPLAY repeatedly until the Control Menu disappears from the TV screen.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
134
GB
List of Control Menu items
Item Item Name, Function, Relevant Disc Type
[TITLE] (page 37)/[SCENE]/[TRACK] (page 37)
Selects the title, scene or track to be played back.
[CHAPTER] (page 37)/[INDEX]
Selects the chapter or index to be played back.
[TRACK]
1)
(page 37)
Selects the track or audio le to be played back.
[ORIGINAL/PLAY LIST] (page 42)
Selects the playback sequence either to the originally recorded
sequence or to the playlist created on the disc.
[TIME]
1)
(page 44)
Checks the elapsed playing time and the remaining time.
You can play from a desired point by inputting the time code (DVD
VIDEO/DVD-VR only).
[PROGRAM] (page 44)
Plays back the tracks in the order you want.
[SHUFFLE]
1)
(page 46, 86)
Plays back the tracks or audio les in random order.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
135
GB
Additional Information
Item Item Name, Function, Relevant Disc Type
[REPEAT]
1)
(page 47, 86 )
Plays back all discs repeatedly, the entire disc (all titles/all tracks/all
les/all folders) repeatedly or one title/chapter/track/folder/le
repeatedly.
[A/V SYNC] (page 55)
You can adjust the delay between the picture and sound.
[SETUP]
1)
(page 33, 58)
QUICK
Use “QUICK” Setup to choose the language of the on-screen display
and the aspect ratio of the TV screen.
CUSTOM
In addition to the “QUICK” setup setting, you can adjust other
settings.
[FOLDER]
1)
(page 48, 77)
Selects the folder to be played back.
[FILE]
1)
(page 48)
Selects the JPEG image le or video le to be played back.
[DATE]
1)
(page 104)
Displays the date when the picture was taken by a digital camera.
[INTERVAL]
1)
(page 53, 85)
Species the duration for which the slides are displayed on the TV
screen.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
136
GB
Item Item Name, Function, Relevant Disc Type
[EFFECT]
1)
(page 54, 85)
Selects the transition eects to be used for changing slides during a
slide show.
[MEDIA]
1)
(page 49, 52, 54, 82)
Selects the data type (audio le, JPEG image le, video le, or both
MP3 le and JPEG image le) to be played back.
[USB TRANSFER] (page 77)
Transfers music on an AUDIO CD or DATA CD/DVD to a USB
device.
[KARAOKE MODE]
1)
(page 92)
Sets Karaoke mode to on or o.
[VOCAL SELECT]
2)
(page 94)
Selects the guide vocal recorded on the “Dolby Digital Karaoke”
Format disc (DVD VIDEO only).
Selects the vocal type recorded on the disc (VIDEO CD, AUDIO CD
only).
Turns o the vocal.
[SCORE MODE]
1)2)
(page 96)
Calculates your vocal score by comparing your voice with the music
source.
1)
ese functions are the same when using a USB device. However, some menu items
may not be available.
2)
is function is only available during Karaoke mode.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
137
GB
Additional Information
Playback priority of le types
e table below describes the playback priority of le types under the “MEDIA” setting.
File type on
a disc or USB
device
“MEDIA” setting
VIDEO MUSIC/
MUSIC PHOTO
Disc USB
device
Disc Disc/USB
device
Disc/USB
device
Video les only Video les Video les Video les Video les Video les
JPEG image les
only
JPEG image
les
JPEG image
les
JPEG image
les
JPEG image
les
JPEG image
les
Audio les only MP3 les Audio les MP3 les Audio les* Audio les*
Video les and
JPEG image les
Video les Video les JPEG image
les
Video les JPEG image
les
Video les and
audio les
Video les Video les MP3 les Audio les* Audio les*
Audio les and
JPEG image les
MP3 les
and JPEG
image les
with slide
show
Audio les MP3 les
and JPEG
image les
with slide
show
Audio les* JPEG image
les
Video les, audio
les, and JPEG
image les
Video les Video les MP3 les
and JPEG
image les
with slide
show
Audio les* JPEG image
les
* When using a disc, you can play MP3 les only.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
138
GB
Language code list
e language spellings conform to the ISO 639:1988 (E/F) standard.
Code Language Code Language Code Language Code Language
1027 Afar 1186 Scots Gaelic 1350 Malayalam 1513 Siswati
1028 Abkhazian 1194 Galician 1352 Mongolian 1514 Sesotho
1032 Afrikaans 1196 Guarani 1353 Moldavian 1515 Sundanese
1039 Amharic 1203 Gujarati 1356 Marathi 1516 Swedish
1044 Arabic 1209 Hausa 1357 Malay 1517 Swahili
1045 Assamese 1217 Hindi 1358 Maltese 1521 Tamil
1051 Aymara 1226 Croatian 1363 Burmese 1525 Telugu
1052 Azerbaijani 1229 Hungarian 1365 Nauru 1527 Tajik
1053 Bashkir 1233 Armenian 1369 Nepali 1528 ai
1057 Byelorussian 1235 Interlingua 1376 Dutch 1529 Tigrinya
1059 Bulgarian 1239 Interlingue 1379 Norwegian 1531 Turkmen
1060 Bihari 1245 Inupiak 1393 Occitan 1532 Tagalog
1061 Bislama 1248 Indonesian 1403 (Afan) Oromo 1534 Setswana
1066 Bengali; Bangla 1253 Icelandic 1408 Oriya 1535 Tonga
1067 Tibetan 1254 Italian 1417 Punjabi 1538 Turkish
1070 Breton 1257 Hebrew 1428 Polish 1539 Tsonga
1079 Catalan 1261 Japanese 1435 Pashto; Pushto 1540 Tatar
1093 Corsican 1269 Yiddish 1436 Portuguese 1543 Twi
1097 Czech 1283 Javanese 1463 Quechua 1557 Ukrainian
1103 Welsh 1287 Georgian 1481
Rhaeto-Romance
1564 Urdu
1105 Danish 1297 Kazakh 1482 Kirundi 1572 Uzbek
1109 German 1298 Greenlandic 1483 Romanian 1581 Vietnamese
1130 Bhutani 1299 Cambodian 1489 Russian 1587 Volapük
1142 Greek 1300 Kannada 1491 Kinyarwanda 1613 Wolof
1144 English 1301 Korean 1495 Sanskrit 1632 Xhosa
1145 Esperanto 1305 Kashmiri 1498 Sindhi 1665 Yoruba
1149 Spanish 1307 Kurdish 1501 Sangho 1684 Chinese
1150 Estonian 1311 Kirghiz 1502 Serbo-Croatian 1697 Zulu
1151 Basque 1313 Latin 1503 Singhalese 1703 Not specied
1157 Persian 1326 Lingala 1505 Slovak
1165 Finnish 1327 Laothian 1506 Slovenian
1166 Fiji 1332 Lithuanian 1507 Samoan
1171 Faroese 1334 Latvian; Lettish 1508 Shona
1174 French 1345 Malagasy 1509 Somali
1181 Frisian 1347 Maori 1511 Albanian
1183 Irish 1349 Macedonian 1512 Serbian
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
139
GB
Additional Information
Parental Control area code list
Code Area Code Area Code Area Code Area
2044 Argentina 2165 Finland 2362 Mexico 2149 Spain
2047 Australia 2174 France 2376 Netherlands 2499 Sweden
2046 Austria 2109 Germany 2390 New Zealand 2086 Switzerland
2057 Belgium 2248 India 2379 Norway 2528 ailand
2070 Brazil 2238 Indonesia 2427 Pakistan 2184
United Kingdom
2079 Canada 2254 Italy 2424 Philippines
2090 Chile 2276 Japan 2436 Portugal
2092 China 2304 Korea 2489 Russia
2115 Denmark 2363 Malaysia 2501 Singapore
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
140
GB
Glossary
Auto Pause
An automatic pause according to the
signal encoded on the disc while playing
a VIDEO CD. If the CD/DVD player
does not resume playback for a long time,
perform resume playback manually.
Chapter
Subdivision of a title on a DVD VIDEO.
A title is composed of several chapters.
DivX
®
Digital video technology created by
DivX, Inc. Videos encoded with DivX
technology are among the highest quality
with a relatively small le size.
Dolby Digital
is movie theater sound format is
more advanced than Dolby Surround
Pro Logic. In this format, the surround
speakers output stereo sound with
an expanded frequency range and a
subwoofer channel for deep bass is
independently provided. is format is
also called “5.1” because the subwoofer
channel is counted as 0.1 channel (since
it functions only when a deep bass eect
is needed). All six channels in this format
are recorded separately for superior
channel separation. Furthermore, since
all the signals are processed digitally, less
signal degradation occurs.
“Dolby Digital Karaoke” format
(DVD VIDEO only)
e Dolby Digital format, which
reproduces surround sound using
5 channels, can also contain the
“Dolby Digital Karaoke” format
which is specialized for Karaoke. In
the “Dolby Digital Karaoke” format
discs, guide melody and guide vocal
tracks are recorded in addition to the
accompaniment. You can select guide
vocal when Karaoke mode is turned on.
DTS
Digital audio compression technology
developed by DTS, Inc. is technology
conforms to 2-channel surround. e
surround channel is stereo and there
is discrete subwoofer channel in this
format. DTS provides the same 2 discrete
channels of high quality digital audio.
e good channel separation is realized
because the all channel data is recorded
discrete and processed in digital.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
141
GB
Additional Information
DVD+RW
A DVD+RW (plus RW) is a recordable
and rewritable disc. DVD+RWs use a
recording format that is comparable to
the DVD VIDEO format.
File
Audio le (MP3/WMA/AAC le), JPEG
image le, DivX and MPEG4 video le
(MHC-GZR33Di only) recorded on a
DATA CD, DATA DVD or USB device.
(“File” is an exclusive denition for this
system.)
Film based software, Video based
software
DVD VIDEOs can be classied as Film
based or Video based soware. Film
based DVD VIDEOs contain the same
images (24 frames per second) that are
shown at movie theaters. Video based
DVD VIDEOs, such as television dramas
or sitcoms, display images at 30 frames
(or 60 elds) per second.
Folder
Section of a music or picture piece on a
DATA CD, DATA DVD or USB device
containing MP3 les, JPEG image les,
DivX and MPEG4 video les (MHC-
GZR33Di only).
DVD VIDEO
A disc that contains up to 8 hours of
moving pictures even though its diameter
is the same as an AUDIO CD. e data
capacity of a single-layer and single-
sided DVD VIDEO, at 4.7 GB (Giga
Byte), is 7 times that of an AUDIO CD.
Furthermore, the data capacity of a dual-
layer and single-sided DVD VIDEO is
8.5 GB, a single-layer and double-sided
DVD VIDEO 9.4 GB, and a dual-layer
and double-sided DVD VIDEO 17 GB.
e picture data uses the MPEG 2
format, one of the worldwide standards
for digital compression technology. e
picture data is compressed to about 1/40
of its original size. e DVD VIDEO
also uses variable rate coding technology
that changes the data to be allocated
according to the status of the picture.
e audio data is recorded in Dolby
Digital as well as in PCM, allowing you to
enjoy more realistic audio presence.
Furthermore, various advanced functions
such as the multi-angle, multilingual, and
Parental Control functions are provided
with the DVD VIDEO.
DVD-RW
A DVD-RW is a recordable and
rewritable disc that is the same size as
a DVD VIDEO. e DVD-RW has two
dierent modes: VR mode and Video
mode. DVD-RWs created in Video
mode have the same format as a DVD
VIDEO, while discs created in VR (Video
Recording) mode allow the contents to
be programmed or edited.
Continued
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
142
GB
Interlace format (Interlaced scanning)
e Interlace format is the NTSC
standard method for displaying TV
images at 30 frames per second. Each
frame is scanned twice-alternately
between the even numbered scanning
lines and then odd numbered scanning
lines, at 60 times per second.
Menu Playback
Playback using the menu screens
recorded on VIDEO CDs with PBC
functions. You can enjoy simple
interactive soware using the menu
playback function.
Multi-angle function
Various angles, or viewpoints of the video
camera, for a scene are recorded on some
DVD VIDEOs.
Multilingual function
Several languages for the sound or
subtitles in a picture are recorded on
some DVD VIDEOs.
Multi Session
is is a recording method that enables
adding of data using the Track-At-Once
method. Conventional CDs begin at a
CD control area called the Lead-in and
end at an area called Lead-out. A Multi
Session disc is a disc having multiple
sessions, with each segment from Lead-in
to Lead-out regarded as a single session.
Parental Control
A function of the DVD VIDEO to limit
playback of the disc by the age of the
users according to the limitation level in
each country. e limitation varies from
disc to disc; when it is activated, playback
is completely prohibited, violent scenes
are skipped or replaced with other scenes
and so on.
Playback Control (PBC)
Signals encoded on VIDEO CDs (Version
2.0) to control playback. By using menu
screens recorded on VIDEO CDs with
PBC functions, you can enjoy playing
simple interactive programs, programs
with search functions, and so on.
Progressive format (sequential
scanning)
In contrast to the Interlace format, the
progressive format can reproduce 50
60 frames per second by reproducing all
scanning lines (525 lines for the NTSC
system, 625 lines for PAL system). e
overall picture quality increases and still
images, text and horizontal lines appear
sharper. is format is compatible with
the 525 or 625 progressive format.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
143
GB
Additional Information
Region Code
is system is used to protect copyrights.
A region code is allocated on each DVD
system or DVD VIDEO according to
the sales region. Each region code is
shown on the unit as well as on the disc
packaging. e system can play back
the discs that match its region code. e
system can also play back discs with the
“ ” mark. Even when the region code
is not shown on the DVD VIDEO, the
region limit may still be activated.
Scene
On a VIDEO CD with PBC functions,
the menu screens, moving pictures and
still pictures are divided into sections
called “scenes.”
Title
e longest section of a picture or a
music piece on a DVD VIDEO; a movie,
etc., for a picture piece on video soware,
or the entire album in audio soware.
Track
Section of a music or a picture on a
VIDEO CD, CD, or section of a music
on a CD.
VIDEO CD
A compact disc that contains moving
pictures.
e picture data uses the MPEG 1
format, one of the worldwide standards
for digital compression technology. e
picture data is compressed to about 1/140
of its original size. Consequently, a 12 cm
VIDEO CD can contain up to 74 minutes
of moving pictures.
VIDEO CDs also contain compact audio
data.
Sounds outside the range of human
hearing are compressed while the
sounds we can hear are not compressed.
VIDEO CDs can hold 6 times the audio
information of conventional AUDIO
CDs.
ere are 2 versions of VIDEO CDs.
Version 1.1: You can play back only
m
oving pictures and sounds.
Version 2.0: You can play back high-
r
esolution still pictures and enjoy PBC
functions.
is system conforms to both versions.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
144
GB
Index
Numerics
16:9 60
4:3 LETTER BOX 60
4:3 PAN SCAN 60
5.1 Channel Surround 103,
105
A
A/V SYNC 55, 135
AUDIO 60
AUDIO DRC 62
AUDIO SETUP 62
Auto Pause 140
B
BACKGROUND 62
Batteries 25
BLACK LEVEL 61
BLACK LEVEL
(COMPONENT OUT) 61
C
CHAPTER 47, 134
Chapter 37, 140
COLD RESET 120
COLOR SYSTEM (VIDEO
CD) 61
COMPONENT VIDEO OUT
29, 105
Controlling the TV 31
Control Menu Display 133
CUSTOM 29, 56, 58
D
DATE 104, 135
Demonstration 99
DivX 63, 140
Dolby Digital 140
DTS 140
DVD 8, 9
DVD+RW 8, 9, 141
DVD-RW 8, 9, 141
DVD VIDEO 141
E
EFFECT 54, 85, 136
F
Fast forward 37
Fast reverse 37
FILE 48, 135
File 141
Film based soware 141
FOLDER 48, 87, 135
Folder 141
Freeze Frame 37
I
INDEX 43, 134
Instant Advance 38
Instant Replay 38
Interlace format 142
INTERVAL 53, 85, 135
J
JPEG 52, 85
K
Karaoke 92
KARAOKE MODE 92, 136
Karaoke Pon 94
Key Control 93
SCORE MODE 96, 136
VOCAL SELECT 94, 136
L
Language code list 138
LANGUAGE SETUP 33, 59
M
Main unit 11
MEDIA 52
MENU 59
Microphone 92
MP3 9, 81
Multi-angle 38, 142
MULTI-DISC RESUME
39, 63
Multilingual 142
Multi Session Disc 125, 142
O
ORIGINAL 42, 134
OSD 59
Other Component Hookup
104
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
Additional Information
145
GB
P
PARENTAL CONTROL 56
Parental Control 142
PAUSE MODE 61
PBC Playback 41
Playback Control (PBC) 142
PLAY LIST 42, 134
PROGRAM 44, 134
Program Play 44
PROGRESSIVE
(COMPONENT OUT)
29, 61
Q
Quick setup display 33
R
Radio 64
Radio Stations 64
Rear panel 104
REC 1 76
Recording 80
Region Code 143
Remote 16
REPEAT 47, 86, 135
Repeat Play 47, 86
RESET 120
S
SCENE 134
Scene 143
SCREEN SAVER 62
SETUP 135
Setup Menu 58
SHUFFLE 46, 86, 134
Shue Play 46, 86
Sleep Timer 97
Slow-motion Play 37
Sound Field 91
SPEAKER SETUP 63
SUBTITLE 60
SYSTEM SETUP 62
T
THEATRE SYNC 35
TIME 44, 134
Timer 97
TITLE 47, 134
Title 37, 143
TRACK 46, 87, 134
TRACK SELECTION 62
Transferring 75
Troubleshooting 107
TV Hookup 27
TV TYPE 60
U
Usable discs 8
USB 74
USB device 75
USB TRANSFER 76, 77, 136
V
VIDEO CD 8, 143
VIDEO SETUP 33, 60
W
WMA 81
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
146
GB
License and Trademark
Notice
is product incorporates copyright
protection technology that is protected
by U.S. patents and other intellectual
property rights. Use of this copyright
protection technology must be authorized
by Macrovision, and is intended for home
and other limited viewing uses only unless
otherwise authorized by Macrovision.
Reverse engineering or disassembly is
prohibited.
is system incorporates Dolby
1)
Digital and
DTS
2)
Digital Surround System.
1)
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-
D symbol are trademarks of Dolby
Laboratories.
2)
Manufactured under license under U.S.
Patent #'s: 5,451,942; 5,956,674; 5,974,380;
5,978,762; 6,487,535 & other U.S. and
worldwide patents issued & pending. DTS
and DTS 2.0 + Digital Out are registered
trademarks and the DTS logos and Symbol
are trademarks of DTS, Inc. ©1996-2008
DTS, Inc. All Rights Reserved.
“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD
VIDEO,” and the “CD” logos are trademarks.
Di
vX
®
is a video le compression
technology, developed by DivX, Inc. DivX,
DivX Certied, and associated logos are
trademarks of DivX, Inc. and are used under
license.
is product is an ocial DivX
®
certied
product.
MPEG Layer-3 audio coding technology and
p
atents licensed from Fraunhofer IIS and
omson.
iPod is a trademark of Apple Inc., registered
in t
he U.S. and other countries.
“WALKMAN” and “WALKMAN” logo are
r
egistered trademarks of Sony Corporation.
“Memory Stick” is a trademark of Sony
C
orporation.
Windows Media is a registered trademark of
M
icroso Corporation in the United States
and/or other countries.
MHC-GZR33Di/LBT-LCD7Di.GB.4-143-233-12(1)
Additional Information
147
GB
THIS PRODUCT IS LICENSED UNDER
THE MPEG-4 VISUAL PATENT
PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL
USE OF A CONSUMER FOR
(i) ENCODING VIDEO IN COMPLIANCE
WITH THE MPEG-4 VISUAL STANDARD
(“MPEG-4 VIDEO”)
AND/OR
(ii) DECODING MPEG-4 VIDEO THAT
WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER
LICENSED BY MPEG LA TO PROVIDE
MPEG-4 VIDEO.
NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION
INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND
COMMERCIAL USES AND LICENSING
MAY BE OBTAINED FROM MPEG LA,
LLC. SEE http://www. mpegla.com/
