For answers to your Monogram, GE Café
™
, GE Profile
™
or GE Appliances
product questions, visit our website at geappliances.com or call
GE Answer Center
®
Service, 800.626.2000.
Specification Revised 8/20
PGS930YP/BP
GE Profile
™
30" Smart Slide-In Front-Control Gas Fingerprint Resistant Range
with No Preheat Air Fry
NOTE: Door handle protrudes 3" from door face. Cabinets
and drawers on adjacent 45° and 90° walls should be placed
to avoid interference with the handle.
NOTE: Cabinets installed adjacent to slide-in ranges must
have an adhesion spec of at least 194° temperature rating.
INSTALLATION INFORMATION: Before installing,
consult installation instructions packed with product for
current dimensional data.
For all installations, install the required rear trim to
back of range with 4 screws provided.
36 1/4"
+/- 1/4"
29 7/8"
26 7/8"
w/o handle
29 1/2"
w/handle
47 1/2"
1 1/8"
30" min
See note A
Note A: 30" Minimum to bare cabinet, see
installation instructions heights less than 30"
18"
minimum
to cabinets
above counter
6" right side
6" left side
minimum
to side wall
0"
minimum
to cabinets
below
cooktop
16"
max to
cabinets
above
counter
36"
12 1/2"
5"
2"
13"
9"
4 1/2"
4"
30"
Side Wall
supply
electrical
and
Gas
14 1/2"
30"
24"
GAS PIPE AND ELECTRICAL OUTLET LOCATIONS
PGS930_JGS760
36 1/4"
+/- 1/4"
29 7/8"
26 7/8"
w/o handle
29 1/2"
w/handle
47 1/2"
1 1/8"
30" min
See note A
Note A: 30" Minimum to bare cabinet, see
installation instructions heights less than 30"
18"
minimum
to cabinets
above counter
6" right side
6" left side
minimum
to side wall
0"
minimum
to cabinets
below
cooktop
16"
max to
cabinets
above
counter
36"
12 1/2"
5"
2"
13"
9"
4 1/2"
4"
30"
Side Wall
supply
electrical
and
Gas
14 1/2"
30"
24"
GAS PIPE AND ELECTRICAL OUTLET LOCATIONS
PGS930_JGS760
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
ADA
COMPLIANT
Specification Revised 8/20
PGS930YP/BP
GE Profile
™
30" Smart Slide-In Front-Control Gas Fingerprint Resistant Range
with No Preheat Air Fry
PGS930BELTS
PGS930SELSS
P2S930SELSS
FEATURES AND BENEFITS
Visit geappliances.com for more info
No Preheat Air Fry – With this air fryer right in the oven, you can cook healthier, crispier versions of your
favorite foods. There's no preheat required and it shortens the cook time because every minute counts.
Built-in WiFi – This smart oven features built-in WiFi so you can control oven functions with the
SmartHQ app on your smart device.
Fingerprint Resistant Stainless – A stainless finish that makes it easy to keep your appliances free of
smudges and prints.
Fit Guarantee – This gas range will fit your existing 30" cut-out, or GE Appliances will help pay for
modifications up to $300.
Edge-to-Edge Cooktop – Continuous, edge-to-edge cooktop give you a large cooking space and can handle
any cookware.
Tri-Ring Burner – A versatile burner offers three different-sized flame rings on a single burner element,
so it's like having three burners in one.
Reversible Grill and Griddle – This extra-large, reversible griddle and grill combination lets you enjoy the
best in cooking versatility.
Dual Purpose Center Burner – This flexible gas cooktop burner lets you choose between round and oval
burner shapes.
Backlit Glass Touch Controls – Backlit touch controls give this oven a high-tech look with a display that
disappears when not in use and reappears when touched.
Power Boil Burner – This 18,000-BTU power boil element produces intense heat to boil water fast.
Synchronized Clocks and Lights – Synchronize your oven and GE Appliances over-the-range microwave
so that clocks are always matching and lights and ventilation automatically come on when a burner is
activated with Chef Connect.
True Convection – This oven features True Convection, an advanced convection system that uses
a third heating element and fan for the highest level of heat and air circulation.
Never-Scrub Oven Racks – These durable oven racks can be left in the oven during the self-clean cycle
so you never have to scrub.
Model PGS930YPFS – Fingerprint Resistant Stainless
Model PGS930BPTS – Black Stainless
