User Guide Jbl Bar 5.1 Soundbar
Table of contents
- INTRODUCTION
- WHAT’S IN THE BOX
- PLACE YOUR SOUNDBAR
- PLACE THE SOUNDBAR ON THE TABLE
- WALL MOUNT THE SOUNDBAR
- WALL MOUNTING THE SURROUND SPEAKER
- OPTIONAL)
- CONNECT YOUR SOUNDBAR
- CONNECTING THE SOUNDBAR TO YOUR TV
- CONNECTING THE SOUNDBAR TO OTHER DEVICES
- POWER ON YOUR SYSTEM
- PAIR WITH THE SUBWOOFER
- USE YOUR SOUNDBAR SYSTEM
- TO CONTROL
- USING THE WIRELESS SPEAKERS
- HOW TO USE BLUETOOTH
- HOW TO USE SOUNDSHIFT WITH BLUETOOTH
- HOW TO USE USB AUDIO
Connecting to TV through HDMI (ARC)
- An HDMI connection supports digital audio and is the best option to connect to your soundbar.
- If your TV supports HDMI ARC, you can hear the TV audio through your soundbar by using a single HDMI cable.
- This HDMI connection is required if you intend to connect other video devices to the soundbar inputs to display on your TV.
Standby Mode
1. The wireless surround speakers feature standby mode. In this condition the speakers should automatically reconnect to the main soundbar without any other action.
2. The wireless surround speakers automatically enter standby for a total of 10 minutes if one presses POWER OFF on the remote control or the soundbar top-panel buttons.
3. The wireless surround speakers automatically switch to standby after 10 minutes of button inactivity and no audio/video play from a connected device.
4. The wireless surround speakers automatically power off after 20 minutes of button inactivity and no audio/video play from a connected device
USB device requirement
• Devices which require additional program installation connected to a computer, are not supported.
• Do not extract the USB device while in operation.
• For a large capacity USB, it may take longer than a few minutes to be searched.This unit is not supported when the total number of files is 2000 or more.
• The Soundbar USB Port cannot be connected to PC and it cannot be used as a storage device.
• The exFAT and NTFS file system is not supported on this unit. (FAT16/FAT32
