Electric Fireplace Insert with Heater
OWNER’S MANUAL
Model No. FP200
PLEASE SAVE THESE INSTRUCTIONS
WARNING: READ THIS OWNER’S MANUAL CAREFULLY BEFORE USE.
2
Thank you for choosing our Electric Fireplace. This owner’s manual will provide you with
valuable information necessary for the proper care and maintenance of your new
product. Please take a few moments to thoroughly read the instructions and familiarize
yourself with all the operational aspects of your new heater.
IMPORTANT INSTRUCTIONS
When using this electric unit, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
1. Read ALL instructions before using this unit.
2. CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater by
yourself.
3. This heater may get hot when in use. To avoid burns, DO NOT let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
4. Keep combustible materials, such as furniture, pillows, bedding, paper, clothes,
and curtains at least 3 ft from the front of the heater and keep them away from
the sides, top, and rear. DO NOT place towels or other objects on the heater.
5. Extreme caution is necessary when any heater is used by or near children or the
disabled, or when the heater is left operating and unattended.
6. DO NOT operate any heater with a damaged cord or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or mechanical adjustment,
or repair.
7. This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. NEVER locate heater where it may fall into a bathtub or other
water container. To protect against electrical hazards, DO NOT immerse in
water or other liquids.
8. DO NOT touch the control panel or plug with a wet hand.
9. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners,
or similar coverings. Arrange cord away from traffic area and where it will not be
tripped over.
10.DO NOT insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
11.To prevent a possible fire, DO NOT block the air intakes or exhaust in any
manner. DO NOT use on soft surfaces, like a bed, where openings may become
blocked.
12.A heater has hot and arcing or sparking parts inside. DO NOT use in areas
where gasoline, paint, explosive and/or flammable liquids are used or stored.
Keep unit away from heated surfaces and open flames.
13.Always plug heaters directly into a wall outlet receptacle. Never use with an
extension cord or relocatable power tap (outlet/power strip).
3
14.To avoid fire or shock hazard, plug the unit directly into a 120 V AC electrical
outlet.
15.To disconnect heater, turn controls to OFF, then remove plug from outlet. Pull
firmly on the plug, DO NOT unplug by pulling on the cord.
16.Always unplug the unit before moving or cleaning, or whenever the heater is not
in use.
17.Use only for intended household use as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric shock, or injury
to persons. The use of attachments not recommended or sold by unauthorized
dealers may cause hazards.
18.Always use on a dry, level surface. Use on floor only.
19.DO NOT use outdoors.
20.WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit
with any solid-state speed control device.
21.DO NOT attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void your warranty. The inside of the unit contains no user
serviceable parts. Qualified personnel should perform all servicing only.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Voltage Rating
120V (60Hz)
Power
Consumption
500W
Unit Size
9.1in. (W) x 6in. (D) x 9.9 in. (H)
Unit Weight
3.68 LBS
SAFETY FEATURES
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the heaters internal
components reach a certain temperature that could cause overheat and possible fire,
the heater will automatically shut off.
WARNING: It is normal for the power cord to feel warm to the touch; however, a loose
fit between the outlet and the plug may cause overheating of the plug. If this occurs, try
inserting the plug into a different outlet. Contact a qualified electrician to inspect the
original outlet for damage.
4
IN THE BOX
*ELECTRIC STOVE *LEG (4pcs) *SCREW(12pcs) *INSTRUCTION BOOKLET
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Tools Required for Assembly (not included): Phillips screwdriver
ASSEMBLY INSTRUCTIONS
Lay stove upside down on a padded surface with the underside accessible. Attach leg
to stove by inserting the tab on the top of the leg into the corresponding slot on the
bottom of the stove. Insert screws into predrilled holes and tighten securely. Repeat with
remaining three legs.
Leg
Fixing screws
5
PRODUCT DIAGRAM
1. The main power switch---turn on or off the flame and heating function.
Air outlet
Control switch
Control switch
1
Carbon bed
6
OPERATING YOUR HEATER
Once the stove has been properly assembled and connected to a electrical outlet, it is ready
to operate:
1.Gear switch“0”
Turn the knob arrow to the position of "0",
indicating that the product is off.
2. Gear switch“ ”
Turn the knob arrow to the position of “ ” ，
indicating that the product flame is on.
3.Gear switch“ ”
Turn the knob arrow to the position of “ ” ，
indicating that the product flame is on and in the
heating state.
7
PREPARATION
Place the heater on a firm, level surface and plug into a 120V 60Hz power outlet. It can
be used.
MAINTENANCE
1. Glass Information
* Under no circumstances should this product be operated with missing or broken glass.
* Do not strike or slam the glass.
* Do not use abrasive cleaners to clean the glass.
* Replacement glass is available from the manufacturer and replacement should be
carried out by a qualified service person.
2. Cleaning
*To clean the unit, first turn off controls on unit and unplug unit from power source.
*To clean the glass door: remove dust with clean dry cloth or to remove finger prints and
other marks clean glass with clean damp cloth. Do not use abrasive cleaners or spray
liquids on glass door surfaces.
*Metal and metal painted parts should be cleaned with clean damp cloth only. Do not
use abrasive cleaners or spray liquids on this surface.
TROUBLE SHOOTING
If the heater will not operate, please check the following before seeking repair of service:
1. Check if the power cord is plugged into an electrical outlet, if not, plug in.
2. Check if electricity to the outlet is working.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-
up, use the original packaging to repack the unit.
CONTACT US
Thank you for choosing our TRUSTECH Electric Fireplace.
If you need help please contact us directly:
