Installation Instructions
Free-Standing Electric Ranges
TOOLS YOU WILL NEED:
1
REMOVE PACKAGING MATERIALS:
Failure to remove packaging materials could result in damage to the
appliance. Remove all packing parts from oven, racks, heating elements
and drawer. Also, remove protective film and labels on the door, cooktop
and backguard.
NOTE: Cut the orange shipping ties from the power cord, being
careful not to damage the cord.
Questions? Call 1.800.561.3344 or Visit our Website at:
www.GEAppliances.ca
FOR YOUR SAFETY:
If you did not receive an anti-tip bracket with
your purchase, call 1.800.561.3344 to receive
one at no cost. For installation instructions of the
bracket, visit: www.GEAppliances.ca.
Anti-Tip Bracket
Kit Included
WARNING
³
Before beginning the installation,
switch power off at service panel and lock the service
disconnecting means to prevent power from being switched on
accidentally. When the service disconnecting means cannot be
locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
2
PREPARE THE OPENING
(FOR INDOOR USE ONLY)
See illustrations for all rough-in and spacing dimensions.
NOTE: Use a 1.2 m (4’) power cord to prevent interference with the
storage drawer. Power cords 1.4 to 1.8 m
(4
1
ø2’ to 6’) long may have to be dressed to allow for proper drawer
closing.
MINIMUM DIMENSIONS BETWEEN COOKTOP,
WALLS AND ABOVE THE COOKTOP:
A. The range must be placed with 12 mm
(
1
ø2”) minimum clearance at the back
wall and side walls of the cabinet. Make
sure the wall covering, countertop,
flooring and cabinets around the
range
can withstand the heat
(up to 93.3
Û&
Û)
generated by the range.
B. Allow 76.2 cm (30”) minimum
clearance between surface units
and bottom of unprotected wood or
metal cabinet, or allow a 60 cm (24”) minimum when bottom
of wood or metal cabinet is protected by no less than 0.6 cm
µWKLFNIODPHUHWDUGDQWPLOOERDUGFRYHUHGZLWKQRWOHVVWKDQ
No 28 MSG sheet metal (.015”), .015” thick stainless steel, .024”
aluminum or .020” copper.
C. A 15.2 cm (6”) spacing to surfaces less than 38.1 cm (15”) above
the cooktop is recommended to reduce exposure to steam,
grease splatter and heat.
To reduce the risk of burns or fire when reaching over hot surface
elements, cabinet storage space above the cooktop should be
avoided. If cabinet storage space is to be provided above the
cooktop, the risk can be reduced by installing a range hood that
projects at least 12.7 cm (5”) beyond the front of the cabinets.
Cabinets installed above the cooktop must be no deeper than
40.64 cm (16”).
6
FINAL INSTALLATION CHECKLIST
• Check to make sure the circuit breaker is closed (RESET) or the circuit
fuses are replaced.
• Be sure power is in service to the building.
• Check to be sure that all packing materials and tape have been
removed. This will include tape on metal panel under control knobs (if
applicable), adhesive tape, wire ties, cardboard and protective plastic.
Failure to remove these materials could result in damage to the
appliance once the appliance has been turned on and surfaces have
heated.
• Check to make sure that the door and drawer are parallel
to each other and that both operate smoothly. If they do not, see the
Owner’s Manual for proper replacement.
• Check to make sure that the rear leveling leg is fully inserted into the
Anti-Tip bracket and that the bracket is securely installed.
OPERATION CHECKLIST
• Turn on one of the surface units to observe that the element glows
within 60 seconds. Turn the unit off when glow is detected. If the glow is
not detected within the time limit, recheck the range wiring connections.
If change is required, retest again. If no change is required, have
building wiring checked for proper connections and voltage.
• Check to make sure the Clock (on models so equipped) display is
energized. If a series of horizontal red lines appear in the display,
disconnect power immediately. Recheck the range wiring connections.
If change is made to connections, retest again. If no change is required,
have building wiring checked for proper connections and voltage. It is
recommended that the clock be changed if the red lines appear.
• Be sure all range controls are in the OFF position before leaving the
range.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•
,03257$17³Save these instructions for local inspector’s use.
•
,03257$17³Observe all governing codes and ordinances.
• Note to Installer – Be sure to leave these instructions with
Consumer.
• Note to Consumer – Keep these instructions for future reference.
• Skill level – Installation of this appliance requires a qualified
installer or electrician.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under
warranty.
:$51,1*³ This appliance must be properly
connected by means of the supplied cord and plug. If your kitchen
does not have a receptacle, you must have one installed by a
licensed electrician.
B
Both
Sides
C
A
C
A
•
'ULOOZLWKµ%LW
•
Safety Glasses
•
Adjustable Wrench
•
Tape Measure
•
Pliers
•
µ1XW'ULYHU
•
Level
31-10817-1 08-15 GE
Printed in the United States
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
• Engage the range to the anti-tip bracket by sliding the
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
4
ANTI-TIP DEVICE INSTALLATION
To reduce the risk of tipping the range, the range must be secured by a
properly installed anti-tip bracket. See installation instructions shipped
with the bracket for complete details before attempting to install.
To check if the bracket is installed and engaged properly, look
underneath the range to see that the rear leveling leg is engaged in
the bracket. On some models, the storage drawer or kick panel can be
removed for easier inspection. If visual inspection is not possible, slide
the range forward, confirm the anti-tip bracket is securely attached to
the floor or wall, and slide the range back so the leveling leg is under
the anti-tip bracket. If the range is pulled from the wall for any reason,
always repeat this procedure to verify the range is properly secured by
the anti-tip bracket. Never completely remove the leveling legs or the
range will not be secured to the antitip bracket.
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
• Engage the range to the anti-tip bracket by sliding the
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
76.2 cm
(30”)
8.3 cm
(3
1
ø2”)
76.2 cm
(30”)
59.7 cm
(23
1
ø2”)
19.7 cm
(7
3
ø4”)
91.4 cm
(36”)
64.5 cm
(25
3
ø8”)
114.3 cm
(45”)
119.4 cm
(47”)
8.3 cm
(3
1
ø2”)
7.6 cm
(3”)
Acceptable electrical outlet area.
Orient electrical receptacle so
the length is parallel to floor.
ELECTRICAL REQUIREMENTS
This appliance must be supplied with the proper voltage and frequency,
and connected to an individual, properly grounded branch circuit,
protected by a circuit breaker or fuse having amperage as noted on
rating plate. (Rating plate is located above the storage drawer on the
oven frame.)
We recommend you have the electrical wiring and hookup of your
range connected by a qualified electrician. After installation, have the
electrician show you where your main range disconnect is located.
Check with your local utilities for electrical codes which apply in your
area. Failure to wire your range according to governing codes could
result in a hazardous condition. If there are no local codes, your
UDQJHPXVWEHZLUHGDQGIXVHGWRPHHWWKHUHTXLUHPHQWVRI&$1
CSA C22.2 No. O-M91 or latest edition.
<RXPXVWXVHDWKUHHZLUHVLQJOHSKDVH$&<9ROWRU
9ROWKHUW]HOHFWULFDOV\VWHP,I\RXFRQQHFWWRDOXPLQXP
wiring, properly installed connectors approved for use with
aluminum wiring must be used.
3
5
LEVEL THE RANGE
WARNING
³ Never completely remove the leveling
leg as the range will not be secured to the anti-tip device properly.
A. Plug in the range.
B. Measure the height of your countertop at the rear
of the opening (X).
C. Adjust two rear leveling legs so that the rear of
cooktop is at the same height as the counter (Y).
D. Slide unit into place.
E. Install oven shelves in the oven and position the
range where it will be installed.
F. Check for levelness by placing a spirit level on
RQHRIWKHRYHQVKHOYHV7DNHWZRUHDGLQJV³
with the level placed diagonally first in one
direction and then the other.
G. Adjust front leveling legs until the range is level.
Rating plate
X
Y
Spirit level
Leg
leveler
Lower
range
Raise range
