Page 1
Speaker Installation Guide
Car Electronics Resource Center
In This Guide: Installing car speakers
often requires removal of door, dash
or rear window shelf interior panels to
access the speaker mounting points.
Component speakers require the
additional steps of installing a sepa-
rate tweeter and passive crossover
network. Follow these easy installation
steps to ensure proper installation of
your speakers.
Phillips Screwdriver
or Allen Wrenches
Wire Cutters
(Crimpers)
Cordless Drill w/ Drill Bits
Digital Multimeter (DMM)
Tools and Supplies Needed:
Difficulty Level: Moderate to Difficult Average Installation Time: 1-3 Hours
Wire Strippers
Before You Begin
Important
This content has not been verified by Amazon for
accuracy, completeness, or otherwise. Consult
your vehicle’s owner’s manual and the product’s
manual before attempting an installation. Contact
the product’s manufacturer or consult a Mobile
Electronics Certified Professional installer if you
are uncertain about how to properly install your
product. Amazon attempts to be as accurate
as possible; however, because of the number of
vehicles and products available to consumers,
it is not possible to provide detailed installation
steps that apply universally to all vehicles and
products. Amazon does not warrant that product
descriptions or other content of this site is
accurate, complete, reliable, current, or error-free.
Further, Amazon disclaims any warranties, express
or implied, as further set forth in the ‘Conditions
of Use’ for Amazon.com.
Read all instructions carefully Disconnect the negative battery cable Protect interior surfaces
Note: Accessories, such as oval-to-round speaker mounting adapters and speaker wire, may be required to complete the installa-
tion and are available for purchase on Amazon.com
1 2
Electrical Tape
3
Blue Painter’s Tape
(protects dash surfaces)
Towel
(protects console)
Product Owner’s Manual
Installation Manual(s)
Zip Ties
Utility Knife
Sockets or Open
End Wrenches
Panel Removal Tools
Torx Socket
