4-081-454-21
KV-13M42
KV-20M42
KV-20S90
© 2001 by Sony Corporation
Trinitron
Color TV
®
Operating Instructions
User Guide
WARNING
To reduce the risk of fire or electric shock, do not expose the TV to rain or moisture.
This symbol is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the
appliance.
Note to the CATV Installer
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building as close to the
point of cable entry as practical.
SAFETY PRECAUTIONS
Operate the TV only on 120 V AC.
One blade of the power plug is wider than the other for safety purposes and will fit
into the power outlet only one way. If you are unable to insert the plug fully into the
outlet, contact your dealer.
If any liquid or solid object falls into the TV, unplug it and have it checked by qualified
personnel before operating it further.
CAUTION
When using TV games, computers, and similar products with your TV, keep the brightness
and contrast functions at low settings. If a fixed (non-moving) pattern is left on the screen
for long periods of time at a high brightness or contrast setting, the image can be
permanently imprinted onto the screen. Continuously watching the same channel can cause
the imprint of station logos onto the TV screen. These types of imprints are not covered by
your warranty because they are the results of misuse.
To reduce the risk of electric shock, do not use this polarized plug with an
extension cord, receptacle, or other outlet unless the blades can be fully
inserted to prevent blade exposure.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
ATTENTION
CAUTION
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Connecting Additional Equipment
NOTIFICATION
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference with radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antennas.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Protecting the TV
To prevent internal heat build-up, do not block the ventilation openings.
Do not install the TV in a hot or humid place, or in a place subject to excessive dust or
mechanical vibration.
Note on Caption Vision
This television receiver provides display of television closed captioning in accordance with
§ 15.119 of the FCC rules.
Use of this television for other than private viewing of programs broadcast on UHF or VHF
or transmitted by cable companies for the use of the general public may require
authorization from the broadcaster-cable company and/or program owner.
Owner’s Record
The model and serial numbers are located on the front cover of this manual and the rear of
your TV.
Trademarks and Copyrights
ENERGY STAR
®
is a registered mark.
You are cautioned that any changes or modifications not expressly approved in this
manual could void your authority to operate this equipment.
As an ENERGY STAR
®
Partner, Sony has determined that this product or product
model meets the E
NERGY STAR
®
guidelines for energy efficiency.
User Guide
Important Safeguards
For your protection, please read these instructions completely, and keep this manual for
future reference. Carefully observe and comply with all warnings, cautions and instructions
placed on the set, or described in the operating instructions or service manual.
WARNING
To guard against injury, the following basic safety precautions should be observed in the
installation, use, and servicing of the set.
Use
Power Sources
This set should be operated only from the
type of power source indicated on the
serial/model plate. If you are not sure of
the type of electrical power supplied to
your home, consult your dealer or local
power company. For those sets designed to
operate from battery power, refer to the
operating instructions.
Grounding or Polarization
This set is equipped with a polarized AC
power cord plug (a plug having one blade
wider than the other), or with a three-wire
grounding type plug (a plug having a third
pin for grounding).
Follow the instructions below:
For the set with a polarized AC power
cord plug
This plug will fit into the power outlet only
one way. This is a safety feature. If you are
unable to insert the plug fully into the
outlet, try reversing the plug. If the plug
should still fail to fit, contact your
electrician to have a suitable outlet
installed. Do not defeat the safety purpose
of the polarized plug by forcing it in.
Alternate Warning
For the set with a three-wire
grounding type AC plug
This plug will only fit into a grounding-
type power outlet. This is a safety feature.
If you are unable to insert the plug into the
outlet, contact your electrician to have a
suitable outlet installed. Do not defeat the
safety purpose of the grounding plug.
Connecting Additional Equipment
Overloading
Do not overload wall outlets, extension
cords or convenience receptacles beyond
their capacity, since this can result in fire or
electric shock. Always turn the set off
when it is not to be used. When the set is
left unattended and unused for long
periods of time, unplug it from the wall
outlet as a precaution against the
possibility of an internal malfunction that
could create a fire hazard.
Object and Liquid Entry
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the set.
Attachments
Do not use attachments not recommended
by the manufacturer, as they may cause
hazards.
Cleaning
Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth
lightly dampened with water for cleaning
the exterior of the set.
If a snapping or popping sound from a TV
set is continuous or frequent while the TV
is operating, unplug the TV and consult
your dealer or service technician. It is
normal for some TV sets to make
occasional snapping or popping sounds,
particularly when being turned on or off.
Installation
Water and Moisture
Do not use power-line operated sets near
water — for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in
a wet basement, or near a swimming pool,
etc.
User Guide
Accessories
Do not place the set on an unstable cart,
stand, tripod, bracket, table, or shelf. The
set may fall, causing serious injury to a
child or an adult, and serious damage to
the set. Use only a cart or stand
recommended by the manufacturer for the
specific model of TV any mounting of the
product should follow the manufacturer’s
instructions, and should use a mounting
accessory recommended by the
manufacturer. An appliance and cart
combination should be moved with care.
Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
Ventilation
The slots and openings in the cabinet and
in the back or bottom are provided for
necessary ventilation. To ensure reliable
operation of the set, and to protect it from
overheating, these slots and openings must
never be blocked or covered.
• Never cover the slots and openings
with a cloth or other materials.
• Never block the slots and openings
by placing the set on a bed, sofa, rug
or other similar surface.
• Never place the set in a confined
space, such as a bookcase, or built-in
cabinet, unless proper ventilation is
provided.
• Do not place the set near or over a
radiator or heat register, or where it
is exposed to direct sunlight.
Power-Cord Protection
Do not allow anything to rest on or roll
over the power cord, and do not place the
set where the power cord is subject to wear
or abuse.
Connecting Additional Equipment
Grounding or Polarization
This set may be equipped with a polarized alternating current line plug (a plug having one
blade wider than other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact you electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
Antennas
Outdoor Antenna Grounding
If an outdoor antenna is installed, follow the precautions below. An outdoor antenna
system should not be located in the vicinity of overhead power lines or other electric light or
power circuits, or where it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM, EXTREME CARE SHOULD
BE TAKEN TO KEEP FROM CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some protection against voltage
surges and built-up static charges. Section 810 of the National Electrical Code (NEC) in USA
and Section 54 of the Canadian Electrical Code in Canada provides information with respect
to proper grounding of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
Antenna Grounding According to the NEC
Refer to section 54-300 of Canadian Electrical Code for Antenna Grounding.
Lightning
For added protection for this television receiver during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the receiver due to lightning and
power-line surges.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRIC CODE
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ARTICLE 250, PART H)
User Guide
Service
Damage Requiring Service
Unplug the set from the wall outlet and
refer servicing to qualified service
personnel under the following conditions:
• When the power cord or plug is
damaged or frayed.
• If liquid has been spilled into the set
or objects have fallen into the
product.
• If the set has been exposed to rain or
water.
• If the set has been subject to
excessive shock by being dropped,
or the cabinet has been damaged.
• If the set does not operate normally
when following the operating
instructions. Adjust only those
controls that are specified in the
operating instructions. Improper
adjustment of other controls may
result in damage and will often
require extensive work by a
qualified technician to restore the set
to normal operation.
• When the set exhibits a distinct
change in performance — this
indicates a need for service.
Servicing
Do not attempt to service the set yourself
since opening the cabinet may expose you
to dangerous voltage or other hazards.
Refer all servicing to qualified service
personnel.
Replacement Parts
When replacement parts are required, be
sure the service technician certifies in
writing that he has used replacement parts
specified by the manufacturer that have the
same characteristics as the original parts.
Unauthorized substitutions may result in
fire, electric shock, or other hazards.
Safety Check
Upon completion of any service or repairs
to the set, ask the service technician to
perform routine safety checks (as specified
by the manufacturer) to determine that the
set is in safe operating condition, and to so
certify. When the set reaches the end of its
useful life, improper disposal could result
in a picture tube implosion. Ask a qualified
service technician to dispose of the set.
Connecting Additional Equipment
Introduction
Trinitron
®
Color TV Features............................ 1
Batteries for the Remote Control....................... 2
About this Manual .............................................. 2
Connecting Your TV
Basic Connections................................................ 3
Connecting Additional Equipment .................. 4
Using the Remote Control and Basic Functions
Using the Remote Control.................................. 9
Setting Up the TV Automatically.................... 11
Quick Start to the Menus.................................. 12
Using the Menus
Using the VIDEO menu .............................. 13
Using the AUDIO menu .............................. 14
Using the TIMER menu............................... 15
Using the SET UP menu.............................. 16
CHANNEL SET UP menu ............................... 17
Using PARENTAL CONTROL ....................... 18
Other Information
Troubleshooting ................................................ 25
Specifications...................................................... 27
Index.......................................................................... 29
Contents
User Guide
Connecting Additional Equipment
1
Introduction
Congratulations on your purchase of the Sony Trinitron
®
Color TV.
Before you begin using this manual, please check the model number
located on the rear of your TV or on the front cover of this manual.
The menu and illustrations used in these instructions are for KV-20S90 to
show the maximum number of features available. Differences in
operation or features will be indicated in the text, for example, “KV-20S90
only.”
Trinitron
®
Color TV Features
Depending on your TV, some of the features you will enjoy include:
PARENTAL CONTROL
— A tool for parents to help monitor what their
children watch on TV by establishing rating limits.
FAVORITE CHANNEL — Instant access to your favorite channels with
the touch of a button.
Energy Star — A recognized symbol of energy efficiency.
Direct MTS — Allows direct access to changing your Multi-Channel
TV Sound: STEREO, SAP (Second Audio Programming), or MONO,
with the touch of a button (KV-20S90 only).
ON/OFF TIMER — Program your TV for scheduled viewing, (except
KV-13M42).
Trilingual Menus — Choose between English, French, or Spanish
menus (KV-20S90 only).
Front Panel Controls — Allows access to the on-screen menus
without the use of a remote control.
Front A/V inputs — A quick connection for video games, camcorders,
or stereo/mono equipment (except KV-13M42).
2
Operating Instructions
Batteries for the Remote Control
Insert two AA (R6) batteries (supplied) into the remote control using the
following illustration as a guide.
About this Manual
This manual provides instructions to help you enjoy your new TV. It
shows you how to connect to an antenna or cable, cable box, VCR or
camcorder. Once you’re connected, follow the instructions to learn how
to use the remote control to access the on-screen menus.
Under normal conditions, batteries will last up to six months. If the remote
control does not operate properly, the batteries might be worn out.
Remove the batteries to avoid possible damage from battery leakage if you
will not be using the remote control for an extended period of time.
Connecting Your TV
3
Connecting Your TV
Read this chapter before setting up your TV for the first time. This section
covers basic connections in addition to any optional equipment you may
be connecting.
Basic Connections
TV with indoor or outdoor antenna, or CATV cable
Depending on the cable available in your home, choose one of the
connections below:
If you are connecting to an indoor or outdoor antenna, it will be necessary to
adjust the orientation of the antenna for best reception.
4
Operating Instructions
Connecting Additional Equipment
TV and VCR
1 Connect the coaxial cable from your TV antenna or cable service to
the IN jack on your VCR.
2 Connect a coaxial cable (not supplied) from the OUT jack on your
VCR to the VHF/UHF IN jack on the TV.
Optional Connection
If your VCR is equipped with video outputs, you can get better picture
quality by connecting Audio/Video cables (not supplied) from AUDIO
and VIDEO OUT on your VCR to AUDIO/VIDEO IN on your TV.
To watch video programs from your VCR, tune your TV to channel 3 or 4 (as
set on the rear of your VCR).
You can use the button to switch between the VHF/UHF and VIDEO
inputs.
Rear of TV
Video (yellow)
Audio L (white)
Audio R (red)
Connecting Your TV
5
TV and Cable Box
1 Connect the coaxial cable from your cable service to the IN jack on
your cable box.
2 Connect a coaxial cable (not supplied) from the OUT jack on your
cable box to the VHF/UHF IN jack on the TV.
To view channels from your cable box, tune your TV to channel 3 or 4 (as set
on the rear panel of your cable box) and use the cable box’s remote control to
change channels.
If you will be controlling all channel selection through your cable box, you
should consider using the CHANNEL FIX feature by setting your TV to channel
3 or 4, (see page 17).
Rear of TV
Cable Box
6
Operating Instructions
TV, VCR, and Cable box
1 Connect the coaxial cable from your cable service to the IN jack on
your cable box.
2 Connect a coaxial cable (not supplied) from the OUT jack on your
cable box to the IN jack on your VCR.
3 Connect a coaxial cable (not supplied) from OUT on your VCR to
VHF/UHF jack on your TV.
Optional Connection
If your VCR is equipped with video outputs, you can get better picture
quality by connecting Audio/Video cables (not supplied) from AUDIO
and VIDEO OUT on your VCR to AUDIO/VIDEO IN on your TV.
If you will be controlling all channel selection through your cable box, you
should consider using the CHANNEL FIX feature by setting your TV to channel
3 or 4, (see page 17).
You can use the button to switch between the VHF/UHF and VIDEO
inputs.
OUT
IN
3
Rear of TV
VCR
Cable Box
Connecting Your TV
7
Connecting a Camcorder
Using Audio/Video cables (not supplied), connect AUDIO and VIDEO
OUT on your camcorder to AUDIO and VIDEO IN on your TV.
Connecting Headphones
Connect your headphones to the jack on the front of your TV.
For model KV-13M42, this connection can be made to the Audio/Video input
located on the rear of the TV.
Front A/V Panel
A/V output
L
(MONO)
-AUDIO-RVIDEO
VIDEO INPUT
Front A/V Panel
9
Using the Remote Control and Basic Functions
Using the Remote Control and
Basic Functions
This section shows you how to use more advanced buttons on the remote control
and how to use the on-screen menus.
.
Button Description
Press when you want to turn the TV on
and off.
Turns the TV off automatically in
approximately 30, 60 or 90 minutes. Cancel
by pressing until SLEEP OFF appears.
Instantly turns off the sound. Press again
or press to restore sound.
Cycles through the available video inputs.
Press once to show current time, (if set)
and channel number. Press again to
activate CAPTION VISION settings, if
available. To cancel, press again until
DISPLAY OFF appears.
Cycles through the Multi-Channel TV
Sound (MTS) options: STEREO, SAP
(Second Audio Programming) and
MONO, (KV-20S90 only).
Press for channel selection, the channel
will change after 2 seconds.
Press after selecting a channel using the
buttons to immediately activate
selection.
Alternates back and forth between the last
two channels selected with the
buttons.
Displays the on-screen menu. Press again
to exit the menu at any time.
Activates highlighted selections in the
on-screen menu.
The remote control shown (RM-Y155) is for KV-20S90. For KV-13M42 and
KV-20M42 models, your remote control does not have the MTS button.
JUMP ENTER
SLEEP
POWER
MUTING
MTS
CHVOL
RESET SELECT
MENU
RM-Y155
TV
0 9
0 9
0 9
10
Operating Instructions
Moves the cursor in the on-screen menu.
Press to restore factory settings while in
the on-screen menu.
Press when you want to change channels.
Press when you want to adjust the volume.
If you lost your remote control, see page 26
11
Using the Remote Control and Basic Functions
Setting Up the TV Automatically
After you have finished connecting your TV, you will want to run AUTO
PROGRAM to set up your channels, (KV-13M42, see page 17 for
information on AUTO PROGRAM).
For models KV-20M42, KV-20S90 only
1 Press to turn on the TV, the Initial setup screen appears.
(U.S. models only) (Canadian models only)
2 Make your language selection, the on-screen menus will change to
reflect your choice.
3 Follow the on-screen instructions to continue AUTO SET UP or for a
DEMO of the menus.
For U.S. models only
4 Press to operate the on-screen menus without the remote
control. Follow the on-screen instructions to make adjustments to
your TV settings.
To perform Auto Setup again
Press the and buttons on the front panel of the TV and follow
steps 2-4.
To reset your TV to factory settings, turn the TV on. Then, while pressing the
button on the remote control, press POWER on the TV. The TV will turn
itself off, then back on, the original settings will be restored.
12
Operating Instructions
Quick Start to the Menus
The following settings are available in your on-screen menus:
Menu Allows you to
Make adjustments to your
picture settings.
Choose from available audio
features, such as Multi-
Channel Sound, (KV-20S90
only).
Set the clock on your TV
(CURRENT TIME SET) and
program scheduled viewing
(ON/OFF TIMER)
(Except KV-13M42).
Program your channels, set
TV rating, or select menu
language.
The CHANNEL SET UP
menu is a sub-menu that
provides further options for
setting up your channels.
The menus shown are for KV-20S90. Your menus may not look like those
illustrated.
Using the Menus
13
Using the Menus
This chapter shows the options available for setting up and adjusting
your TV.
To access a menu
1 Press .
2 Use the F or f buttons to highlight a menu.
3 Press to access the menu.
Using the VIDEO menu
Item Press f to Press F to
PICTURE Decrease picture contrast Increase picture contrast
BRIGHTNESS Darken the picture Brighten the picture
COLOR Decrease color intensity Increase color saturation
HUE Increase the red tones Increase the green tones
SHARPNESS Soften the picture Sharpen the picture
14
Operating Instructions
Using the AUDIO menu
KV-20S90 only
MTS
Multi-Channel
TV Sound
STEREO: Select when viewing a broadcast in stereo.
SAP: Listen to bilingual or other Second Audio Programs
(SAP).
MONO: Select to reduce noise in areas with poor reception.
If your TV is set to SAP, all non-SAP programs will be muted. If your TV does
not have sound, check your AUDIO settings.
For direct MTS settings, press the button on your remote control.
Using the Menus
15
Using the TIMER menu
Except KV-13M42
DAYLIGHT
SAVING
YES: Select in spring to compensate for Daylight Savings.
NO: Select in fall at the end of Daylight Savings.
CURRENT
TIME SET
With the menu open:
1 Press .
2 Press F or f to cycle through the days, then press .
3 Press F or f until the current hour is displayed, then
press .
4 Press F or f until the current minute is displayed, then
press .
ON/OFF TIMER
Scheduled
viewing
CURRENT TIME SET must be programmed before the
ON/OFF TIMER is available.
With the menu open:
1 Press .
2 Press F or f until the desired day or range of days is
displayed, then press .
3 Indicate the time that you want the TV to turn on by
pressing F or f and the , (for hour and minutes).
4 Press F or f to set the duration, up to 6 hours, then press
.
5 Press F or f to set the channel and press .
When you perform AUTO PROGRAM, all ON/OFF TIMER settings will be
cleared.
Any loss of power will cause the ON/OFF TIMER settings to be cleared.
When the ON/OFF TIMER is programmed, the light on the front of your TV will
be turned on.
16
Operating Instructions
Using the SET UP menu
PARENTAL
CONTROL
The PARENTAL CONTROL feature provides parents several
options for programming the TV to block shows based on their
rating, (see page 18).
FAVORITE
CHANNEL
Quick access
to favorite
channels
With the FAVORITE CHANNEL menu open:
1 Press .
2 Use the F or f buttons to select AUTO or MANUAL,
(selecting AUTO will display the last five channels accessed
by the buttons).
3 Select the position (1-5) where you want to program a
channel. Then press .
4 Using the F or f buttons, select the desired channel.
5 Press , the TV will change to the channel entered.
CAPTION
VISION
Closed-
captioning
CC1, 2, 3, 4: Displays printed dialogue and sound effects of a
program.
TEXT1, 2, 3, 4: Displays network/station information.
XDS (Extended Data Services): Displays information about the
network and current program, if available.
LANGUAGE Display all menus in your language of choice.
1 Point cursor at LANGUAGE and press .
2 Using the F or f buttons, highlight the desired language and
press .
0 9
To use FAVORITE CHANNEL, exit all menus and press . A window picture
will display your favorite channel numbers. Move the cursor to a channel
number and press
to view.
Press the button to activate your CAPTION VISION setting.
Using the Menus
17
CHANNEL SET UP menu
CABLE ON: Select if you are receiving cable channels with a CATV
cable.
OFF: Select if you are using an antenna.
CHANNEL FIX 2-6: Select when you want to control all channel selection
through a cable box. Select the appropriate channel
(usually 3 or 4) and use the cable box’s remote control for
channel selection.
VIDEO: Select from available inputs when you have
connected video equipment (e.g. satellite receiver) and you
want your TV fixed to it.
AUTO
PROGRAM
Run AUTO PROGRAM whenever setting up your TV. It
will cycle through all available channels and program any
receivable channels.
CHANNEL
SKIP/ADD
Use this feature after you run AUTO PROGRAM to skip
unwanted channels or add new ones.
1 Use the or CH +/- buttons to access the desired
channel.
2 Press ito SKIP or ADD (only one option will be
available).
After changing your CABLE settings, you will need to run AUTO PROGRAM.
FAVORITE CHANNEL cannot be used when CHANNEL FIX is set.
0 9
18
Operating Instructions
Using PARENTAL CONTROL
The PARENTAL CONTROL feature is designed to help parents monitor
what their children watch on television. This section shows you the
different rating systems available and how to set your TV’s rating.
Overview of the Ratings
Once you have become familiar with these rating systems, you should be
ready to set your TV’s rating.
TV RATINGS
The TV ratings are divided into two groups: age-based and
content-based.
The content ratings will increase depending on the level of the age-based
rating. For example, a program with a TV-PG V (Violence) rating may contain
moderate violence, while a TV-14 V (Violence) rating may contain more
intense violence.
Age
Content
Age Defined as
TV-Y All children
TV-Y7 Directed to older children
TV-G General audience
TV-PG Parental Guidance
suggested
TV-14 Parents Strongly
cautioned
TV-MA Mature Audience only
Contents Defined as
FV Fantasy Violence
D Suggestive
dialogue
L Strong language
S Sexual situations
V Violence
Using the Menus
19
MOVIE RATINGS
(U.S. models only)
This system defines the rating levels of movies shown on the big screen
and those on prime cable channels.
UNRATED
(U.S. models only)
You have the option of blocking TV programs or movies that are not
rated.
If you choose to block unrated TV programs, please be aware the following
programs may be blocked: emergency broadcasts, political programs, sports,
news, public service announcements, religious programs and weather.
Rating Defined as
G General audience
PG Parental Guidance suggested
PG-13 Parents Strongly cautioned
R Restricted
NC-17 No one 17 and under admitted
X Adult audience only
Rating Defined as
VIEW ALL No block
BLOCK
TV
Block all unrated TV
programs
BLOCK
MOVIE
Block all unrated movies
BLOCK
ALL
Block all unrated
programming
20
Operating Instructions
ENGLISH RATINGS
(Canadian models only)
These ratings are for Canadian programs that are broadcast in English.
FRENCH RATINGS
(Canadian models only)
These ratings are for Canadian programs that are broadcast in French.
U.S.A. RATINGS
(Canadian models only)
For programs from the United States. Please see, “TV RATINGS” on
page 18 for information on U.S.A. RATINGS.
Rating Defined as
C Children
C8+ Children 8 years and older
G General programming
PG Parental Guidance
14+ Viewers 14 and older
18+ Adult programming
Rating Defined as
G General
8 ans+ Not recommended for younger
children
13 ans+ Not recommended for children
under age 13
16 ans+ Not recommended for ages under 16
18 ans+ This program is restricted to adults
Using the Menus
21
Initial access into PARENTAL CONTROL
1 In the SET UP menu, point the cursor to PARENTAL CONTROL
and press , (you will be asked to set 4-digit password for any
future access into PARENTAL CONTROL).
2 Press , then use the buttons to enter a 4-digit password.
3 Confirm your password by entering it again.
Once your password is set correctly, you will be taken into the
PARENTAL CONTROL menu.
Activating PARENTAL LOCK
In order to change the RATING, you will need to set PARENTAL LOCK
to ON.
1 Point the cursor to PARENTAL LOCK and press .
2 Using the F or f buttons, highlight ON and press to activate.
Keep this instruction manual in a safe place. In the event that you forget your
password, please see page 26.
0 9
22
Operating Instructions
Setting the RATING
If you are not familiar with the Parental Guidelines rating system, you
should use one of the following preselected categories: CHILD, YOUTH
or YOUNG ADULT.
1 Point the cursor to RATING and press .
2 Using the F or f buttons, select the desired rating and press .
Using the CUSTOM menu
You should be familiar with the rating systems before attempting to set
CUSTOM ratings. Refer to pages 18-20, “Overview of the Ratings,” for a
description of the available rating systems.
1 In the RATING option, use F or f to highlight CUSTOM and press
.
2 Using the F or f buttons, select the desired rating category and
press .
3 Use F or f to select the maximum rating or content and press .
4 Press F or f to block ( ) or unblock ( _ ) the rating or content and
press .
Rating
TV will allow a maximum rating of:
CHILD TV-Y, TV-G, G (U.S. models only), G (Canadian models
only)
YOUTH TV-PG, PG (U.S. models only), PG (Canadian models only)
YOUNG ADULT TV-14, PG-13 (U.S. models only), 14+ (Canadian models
only)
CUSTOM
Select to set more restrictive ratings, (see next
section).
Once you have blocked a rating or content, all higher ratings or contents will
be automatically blocked.
Using the Menus
23
Resetting your password
1 Use the F or f buttons to move the cursor to CHANGE PASSWORD
and press .
2 Follow the directions for, “Initial Access into Parental Control,” on
page 21, for information on changing your password.
Information for Parents
To view a program that exceeds the TV rating
Press on the remote control, then use the buttons to enter your
password.
Entering your password to view a blocked program will temporarily turn
PARENTAL LOCK to OFF. To reactivate your PARENTAL LOCK settings, turn the
TV off then back on; the TV will return to the settings that you have selected.
0 9
25
Other Information
Other Information
Troubleshooting
If you are having a problem with your TV, try the suggestions below. If
the problem persists, contact your nearest Sony dealer.
No picture, no
sound
Make sure the power cord is plugged in.
If a red light is flashing on the front of your TV for
more than a few minutes, disconnect and reconnect
the power cord to restore the TV. If the problem
continues, call your local service center.
Check the TV/VIDEO settings: when watching TV, set
to TV; when watching video equipment, set to VIDEO
(page 9).
Check your PARENTAL CONTROL settings, (see
pages 21-23).
Make sure the batteries have been inserted correctly
into the remote control.
Try another channel, it could be station trouble.
Poor or no
picture, good
sound
Adjust PICTURE in the VIDEO menu (page 13).
Adjust BRIGHTNESS in the VIDEO menu (page 13).
Check the antenna and/or cable connections (page 3).
Good picture,
no sound
Press so that MUTING disappears from the
screen (page 9).
Check your AUDIO settings. Your TV may be set to
SAP (page 14).
No color
Adjust COLOR in the VIDEO menu (page 13).
Only snow
appears on the
screen
Check the CABLE setting in the CHANNEL SET UP
menu (page 17).
Check the antenna and/or cable connections (page 3).
Make sure the channel selected is currently
broadcasting.
Dotted lines or
stripes
Adjust the antenna.
Move the TV away from other electronic equipment.
Some electronic equipment can create electrical noise,
which can interfere with TV reception.
Double images
or ghosts
Check your outdoor antenna or call your cable service.
MUTING
26
Operating Instructions
If, after reading these operating instructions, you have additional questions related to the use of your
Sony television, please call our Direct Response Center at 1-800-222-SONY (7669) (U.S. customers
only) or (416) 499-SONY (7669) (Canadian customers only).
Cannot receive
higher number
channels (UHF)
when using an
antenna
Make sure CABLE is set to OFF in the CHANNEL SET
UP menu (page 17).
Use AUTO PROGRAM to add channels that are not
presently in the memory (page 17).
Cable stations
don’t seem to
work
Make sure CABLE is set to ON in the CHANNEL SET
UP menu (page 17).
Use AUTO PROGRAM to add channels that are not
presently in the memory (page 17).
Remote control
does not
operate
Batteries could be weak. Replace them (page 2).
Move the TV 3-4 feet away from fluorescent lights.
The TV needs
to be cleaned
Clean the TV with a soft dry cloth. Never use strong
solvents such as thinner or benzine, which might
damage the finish of the cabinet.
Lost password
for PARENTAL
CONTROL
In the password screen, enter the following master
password: 4357. After using the master password, you
must create a new password, it cannot be used to
unlock currently blocked programs.
You lost your
remote control
You can use the control buttons on the front panel of
your TV. Follow the instructions on the screen.
Contact your nearest Sony dealer to order a
replacement.
27
Other Information
Specifications
For all models (except as noted)
Design and specifications are subject to change without notice.
Television system American TV standard/NTSC
Channel coverage VHF: 2-13/UHF: 14-69/CATV: 1-125
Antenna 75-ohm external antenna terminal for VHF/UHF
Picture tube Trinitron
®
tube
Power requirements 120 V, 60 Hz
Supplied Accessories Size AA (R6) batteries (2)
Antenna connector (KV-13M42 only)
Remote Control RM-Y156 (1) (KV-13M42, KV-20M42)
RM-Y155 (1) (KV-20S90)
Antenna dipole (KV-13M42 only)
KV-13M42
Screen size Visible screen size: 13 inches (341 mm) measured
diagonally
Actual screen size: 14 inches (356 mm) measured
diagonally
Inputs/outputs 1 video, 1 audio
1 headphone jack
Speaker output 3 W
Power Consumption 75 W when in use
1 W in standby
Dimensions
(W/H/D)
358 x 355 x 401.4 mm
(14
1
/
8
x 14 x 15
7
/
8
in.)
Mass 10 kg (22 lbs.)
KV-20M42, KV-20S90
Screen size Visible screen size: 20 inches (507 mm) measured
diagonally
Actual screen size: 21 inches (533 mm) measured
diagonally
Inputs/outputs 2 video, 2 audio
1 headphone jack
Speaker output 3 W (KV-20M42)
3W x 2 (KV-20S90)
Power Consumption 80 W when in use (KV-20M42)
90 W when in use (KV-20S90)
1 W in standby
Dimensions
(W/H/D)
522 x 477 x 479 mm (KV-20M42)
(20
5
/
8
x 18
13
/
16
x 18
7
/
8
inch)
609.2 x 464.5 x 469.5 mm (KV-20S90)
(24 x 18
3
/
8
x 18
1
/
2
inch)
Mass 21.6 kg (48 lbs.) (KV-20M42)
21 kg (46.2 lbs.) (KV-20S90)
29
Index
Index
A
AUDIO menu 14
AUTO PROGRAM 17
B
Battery Installation 2
BRIGHTNESS 13
C
CAPTION VISION 16
CHANNEL FIX 17
CHANGE PASSWORD 23
CHANNEL SET UP 17
COLOR 13
Connections
Antenna/Cable
3
TV and Cable Box 5
TV and VCR 4
TV, VCR, and Cable box 6
Connecting a Camcorder 7
Connecting Headphones 7
CURRENT TIME SET 15
D
DAYLIGHT SAVING 15
DISPLAY 9
E
ENGLISH RATINGS 20
F
FAVORITE CHANNEL 1, 16
FRENCH RATINGS 20
H
HUE 13
L
LANGUAGE 16
M
Menus
AUDIO
14
CHANNEL SET UP 17
SET UP
16
TIMER 15
VIDEO 13
MOVIE RATING 19
MTS 14
MONO 14
SAP 14
STEREO 14
O
ON/OFF TIMER 1, 15
P
PARENTAL CONTROL 1, 18
Password 21
Entering 21
Lost 26
PICTURE 13
R
RATINGS 18
ENGLISH 20
FRENCH 20
MOVIE 19
TV 18
UNRATED 19
Remote Control 9
S
SET UP menu 16
SHARPNESS 13
SLEEP 9
Specifications
27
30
User GuideOperating Instructions
T
TIMER menu 15
Troubleshooting 25
TV Features 1
TV RATING 18
U
U.S.A. RATINGS 20
UNRATED 19
V
VIDEO menu 13
Sony Corporation Printed in U.S.A.
