OWNER’S MANUAL

Thank you for choosing a JL Audio Evolution™ C2 Coaxial Speaker System

for your automotive sound system.

These Evolution™ Speakers have been designed and manufactured to

exacting standards in order to ensure years of musical enjoyment in your

vehicle. For maximum performance, we highly recommend that you have

your new speakers installed by an authorized JL Audio dealer. Your

authorized dealer has the training, expertise and installation equipment

to ensure optimum performance from this product. Should you

decide to install the speakers yourself, please take the time

to read this manual thoroughly so as to familiarize yourself

with its installation requirements and setup procedures.

If you have any questions regarding the instructions in this

manual or any aspect of your amplifier’s operation, please contact your

authorized JL Audio dealer for assistance. If you need further assistance,

please call the JL Audio Technical Support Department

at (954) 443-1165 during business hours.

5 x 7-inch (125 x 180 mm) Coaxial Loudspeakers

2 | JL Audio - C2-570x Owner’s Manual

Due to ongoing product development, all specifications are subject to change without notice.

Woofer Physical Dimensions

Frame Outer Diameter (A) 5.47 x 7.68 in. / 139.0 x 195.0 mm

Magnet Outer Diameter (B) 2.76 in. / 70.0 mm w/o cover

Frontal Tweeter Protrusion (C) 0.47 in. / 11.9 mm

Mounting Depth (D) 2.43 in. / 61.9 mm w/o cover

2 | JL Audio - C2-570x Owner’s Manual

C2-570x SPECIFICATIONS:

Woofer: Injection-molded, Mica-filled, Polypropylene Cone,

Butyl Rubber Surround, 1 in. Voice Coil on Kapton® Former,

Flat, Symmetrical Roll Spider, Ferrite Magnet

Tweeter: 0.75 in. (19 mm) Silk Dome, Ferrofluid Cooling /

Damping, Neodymium Magnet

Crossover: Natural Roll-Off Low-Pass, 1st Order High-Pass

Filter with Electrolytic Capacitor

Continuous Power Handling: 60 Watts

Recommended Amp Power: 15-100 Watts per channel (RMS)

Efficiency: 90.5 dB @ 1W/1m | 96.5 dB @ 1W/0.5m

Sensitivity: 93.5 dB @ 2.83V/1m

Nominal Impedance: 4 ohm

Frequency Response: 53 Hz - 22 KHz ± 3 dB

Included Components and Parts:

• Two C2-570x 5 x 7-inch (125 x 180 mm) Coaxial loudspeakers

• Two Woofer Spacer Gaskets

• Eight #8 x 1 1/4-inch (30mm) sheet metal screws

• Eight Mounting Clips

• Two 5.2 mm female crimpable connectors

• Two 2.8 mm female crimpable connectors

GETTING STARTED

•Turnofftheaudiosystem.Itisalso

advisabletodisconnectthenegative(–)

terminalofyourvehicle’sbatterywhenever

performinginstallationwork.

•Beforecutting,drillingorinsertinganyscrew,

checkclearancesonbothsidesoftheplanned

mountingsurface.Alsocheckforanypotential

obstacles,suchaswindowtracksandmotors,

wiringharnesses,etc.Checkbothsidesofthe

vehicle,manyvehiclesarenotsymmetrical!

•Alwayswearprotectiveeyewear.

SPEAKER PLACEMENT CONSIDERATIONS

Inmostcases,yourspeakerswillbeplacedinto

factoryspeakerlocations.Ifyouhavesomespeaker

mountingflexibility,keepthefollowinginmind:

Lowermountinglocations,suchasthelowerfront

cornerofadoororakick-panelprovidethegreatest

pathlengthdistancesforthesoundemittedbythe

speakers.Forthisreason,theyaregenerallymore

desirablethanhighermountinglocations.Higher

mountinglocationswillusuallyresultinextreme

near-sidesoundstagebiaswhichcompromisesthe

stereolisteningexperience.

4 | JL Audio - C2-570x Owner’s Manual

Custom Location:Runspeakerwiretothedesired

mountinglocations.Ifyouarerunningwiresinto

adoor,useexistingfactorywiringbootswhenever

possible.Ifyouaredrillingnewholes,filetheiredges

andinstallrubbergrommetsintoeachhole.Wires

shouldthenbecoveredwithaprotective,flexible

PVCsleeveandthenrunthroughthedoorjamb.

Makesurethatthewireswillcleardoorhingesand

otherstructuresinthedoor.Ifyouareunsureabout

anypartofthisprocess,pleasecontactyourJLAudio

dealerforinstallationhelp.

WARNING



Double check the clearance for both speakers

before proceeding. Many cars are different from

one side to the other!

Selectanevensurface.Tighteningaspeakeronto

anunevensurfacecandamageit.Usethesupplied

templatetomarkthedesiredmountinglocation.

Markthecenterandtheoutlineofthemounting

holeaswellasthemountingscrewpositions.Before

drillingorcuttingonyourinteriorpanels,usea

utilityknifetocutanyfabric,vinylorleatherfrom

holelocations.Thesematerialscaneasilybesnagged

byadrillorasaw,causingdamagetothepanel

andpossiblebodilyinjury.Drillfour1/8-inch(3

mm)holesforthespeaker’smountingscrewsatthe

positionsyouhavemarked.Alsodrillapilothole

inthecenterofthespeakermountingholeatthis

time.Then,usingasabersaw,makethecircular

cutoutforthespeaker.Fileanyroughedges.Insert

themountingclipswiththeflatsidetowardsthe

speakerasshowninDiagramsB/C(Page5).

Itisabsolutelyvitalthatthespeakerframe

fitsintothemountingholecleanly.Thismustbe

checkedpriortotighteningthescrews.Donot

tightenthespeakerontoanunevensurface!This

willdamageyourspeakers.Thespeakershould

alsofitsothatnoairleaksaroundthemounting

flange.Airleakswillcauseaseveredegradation

insoundquality.Sealanyairleakswithsilicone,

ropecaulkorsimilarsealantmaterial.

Aspacergaskethasbeenincludedto

fine-tunespeakerfitment.Thisgasketcan

bemountedonthefrontofthemounting

flange,thebackofthemountingflangeor

simplynotbeusedintheinstallation.

SPEAKER INSTALLATION

Thespeakershouldbeinstalledinoneofthe

followingwaysdependingonlocation:



Factory Location:Runspeakerwiretothe

desiredmountinglocations.Ifyouarerunning

wiresintoadoor,useexistingfactorywiringboots

wheneverpossible.Ifyouaredrillingnewholes,file

theiredgesandinstallrubbergrommetsintoeach

hole.Wiresshouldthenbecoveredwithaprotective,

flexiblePVCsleeveandthenrunthroughthedoor

jamb.Makesurethatthewireswillcleardoorhinges

andotherstructuresinthedoor.Ifyouareunsure

aboutanypartofthisprocess,pleasecontactyour

JLAudiodealerforinstallationhelp.

Yournewspeakershavebeendesignedtoinstall,

withoutmodifications,intomostvehiclesthataccept

a5x7-inch(125x180mm)speaker.Mostfactory

5x7-inchspeakersusefourmountingscrewswhichwill

lineupwiththemountingholesonyourspeakers.

Aspacergaskethasbeenincludedtofine-tune

speakerfitment.Thisgasketcanbemountedonthe

frontofthemountingflange,thebackofthemounting

flangeorsimplynotbeusedintheinstallation.

Itisabsolutelyvitalthatthespeakerframe

fitsintothemountingholecleanly.Thismustbe

checkedpriortotighteningthescrews.Donot

forcetheframeintoaholethatistoosmall.Do

nottightenthespeakerontoanunevensurface.

Thiswilldamageyourspeakers.Thespeaker

shouldalsofitsothatairdoesnotleakaround

themountingflange.Airleakswillcauseasevere

degradationinsoundquality.Sealanyairleaks

withanautomotive-gradesealantmaterial.

Connectthespeakerwirestobothsetsof

terminalsoneachspeaker,observingcorrect

polarityandmakingsurethatthetweeterand

wooferwirescorrespondtothecorrectterminals

onboththespeakerandthecrossover.

Securethespeakerandspacergasket(if

applicable)tothepanelbyevenlytightening

byhandmountingscrews.Usethesupplied

mountingclipsandthetheprovided#8x1.25

inch(32mm)mountingscrewsunlessthe

factoryholesalreadyfeaturethreadedinserts.



4 | JL Audio - C2-570x Owner’s Manual

Connectthespeakerwirestobothsetsof

terminalsoneachspeaker,observingcorrect

polarityandmakingsurethatthetweeterand

wooferwirescorrespondtothecorrectterminals

onboththespeakerandthecrossover.

Securethespeakerandspacergasket(ifapplicable)

tothepanelbyevenlytighteningbyhandthe

provided#8x1.25inch(32mm)mountingscrews.

Diagram B:

Custom Location Woofer Installation

Diagram C:

Custom Location Woofer Installation

Diagram A:

Factory Woofer Location Installation

WARNING

Hand-tighten the screws evenly in a criss-cross

pattern to avoid bending the speaker frame or

stripping the mounting clips.

6 | JL Audio - C2-570x Owner’s Manual

NOTES

6 | JL Audio - C2-570x Owner’s Manual

NOTES

LIMITED WARRANTY  AUTOMOTIVE SPEAKER SYSTEMS USA

JLAUDIOwarrantsthesespeakers(andcrossovernetworks,whereapplicable)tobefreeofdefectsin

materialsandworkmanshipforaperiodofone (1) year.

Thiswarrantyisnottransferableandappliesonlytotheoriginalpurchaserfromanauthorized

JLAUDIOdealer.Shouldservicebenecessaryunderthiswarrantyforanyreasonduetomanufacturing

defectormalfunction,JLAUDIOwill(atitsdiscretion),repairorreplacethedefectiveproductwithnewor

remanufacturedproductatnocharge.Damagecausedbythefollowingisnotcoveredunderwarranty:accident,

misuse,abuse,productmodificationorneglect,failuretofollowinstallationinstructions,unauthorizedrepair

attempts,misrepresentationsbytheseller.Thiswarrantydoesnotcoverincidentalorconsequentialdamages

anddoesnotcoverthecostofremovingorreinstallingtheunit(s).Cosmeticdamageduetoaccidentornormal

wearandtearisnotcoveredunderwarranty.

Anyapplicableimpliedwarrantiesarelimitedindurationtotheperiodoftheexpresswarrantyasprovided

hereinbeginningwiththedateoftheoriginalpurchaseatretail,andnowarranties,whetherexpressorimplied,

shallapplytothisproductthereafter.Somestatesdonotallowlimitationsonimpliedwarranties,therefore

theseexclusionsmaynotapplytoyou.Thiswarrantygivesyouspecificlegalrights,andyoumayalsohaveother

rightswhichvaryfromstatetostate.



If you need service on your JL AUDIO product:

AllwarrantyreturnsshouldbesenttoJLAUDIOfreightprepaidthroughanauthorizedJLAUDIO

dealerandmustbeaccompaniedbyproofofpurchase(acopyoftheoriginalsalesreceipt.)Direct

returnsfromconsumersornon-authorizeddealerswillberefusedunlessspecificallyauthorizedby

JLAUDIOwithavalidreturnauthorizationnumber.Warrantyexpirationonproductsreturned

withoutproofofpurchasewillbedeterminedfromthemanufacturingdatecode.Coveragemaybe

invalidatedasthisdateisprevioustopurchasedate.Returnonlydefectivecomponents.Ifonespeaker

failsinasystem,returnonlythatspeakercomponent,nottheentiresystem.Non-defectiveitems

receivedwillbereturnedfreight-collect.Customerisresponsibleforshippingchargesandinsurance

insendingtheproducttoJLAUDIO.Freightdamageonreturnsisnotcoveredunderwarranty.

For Service Information in the U.S.A. please call

JL Audio Customer Service: (954) 443-1100

9:00 AM – 5:30 PM (Eastern Time Zone)

JL Audio, Inc

10369 North Commerce Pkwy.

Miramar, FL 33025

International Warranties:

Products purchased outside the United States of America are covered only

by that country’s distributor and not by JL Audio, Inc.
