INSTALLATION MANUAL
C SERIES C6R/C6R SST
ROUND SPEAKERS
Box Contents
C Series C6R in-ceiling speaker box contains:
(2) C Series C6R
(2) paintable grilles
(2) mounting cut-out templates
C Series C6R SST in-ceiling speaker box contains:
(1) C6R SST speaker
(1) paintable grille
(1) mounting cut-out template
Speaker Placement
Stereo Speaker Placement (2-Channel System)
• Place the left and right speakers anywhere from 6 - 10 feet
(1.8m – 3m) apart, with the main listening position as close to
midway between the speakers as possible.
• In most cases pivoting the C6R tweeter of each speaker
directly towards the main listening position will help maximize
the stereo soundstage. (The SST tweeters do not pivot)
Use the Left and Right speaker placement in Figures 2 and 3, on the
left side of image, as a guide.
Introduction
Thank you for purchasing Sonance C Series C6R/ C6R SST Round
Speakers. When properly installed your new speakers will give you
years of entertainment pleasure.
Home Theater Speaker Placement
Left, Center & Right Speakers
(see Figure 2)
• Place the left, center and right speakers 1 – 2 feet (0.3m – 0.6m)
in front of the video screen, 6 – 10 feet (1.8m – 3m) apart, with the
center channel speaker as close to midway between the left and
right speakers as possible.
• The main listening position should be 4 – 10 feet (1.2m – 2m) away
from the speakers.
Surround Speakers — 5.1-Channel System (see Figure 2)
• Locate the left and right surround speakers 2 – 6 feet (0.6m
–1.8m) behind the listening position. The speakers should be 6 –
10 feet (1.8m – 3m) apart.
Surround Speakers — 7.1-Channel System (see Figure 3)
• Left & Right Surround Speakers: Place the left and right surround
speakers directly to the sides of the listening position, 6 –10 feet
(1.8m – 3m) apart.
• Surround Back Speakers: Place the surround back speakers 2 – 6
feet (0.6m – 1.8m) behind the listening position. The surround
back speakers should be closer together than the left and right
surround speakers, 3 – 6 feet (0.9m – 1.8m) apart.
1
