WTG9532VH
WTG9532WH
WTG8532WH
MFL69022796 www.lg.com
Please read this manual carefully before operating
your washing machine and retain it for future reference.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 1
Product Features
The Turbo Drum DD washing machine does not operate with the lid open.
If the lid is opened during wash, rinse and spin cycles, the machine will stop automatically.
Please close the door gently. Closing the door in an agressive manner can cause damage and or
injury.
●
The advanced Brushless DC motor rotates the Tub directly without the need of belts
or clutches. thereby reducing the noise of the washer.
●
The washing machine adjusts to the optimum rotating speeds according to the type of
clothing in the load.
Low Noise Direct Drive System
●
Should you experience any technical difficulty with your washing machine, it has
the capability of transmitting data by phone to the Customer Information Center.
The Consultant records the data transmitted from your machine and uses it to
analyze the issue, providing a fast and effective diagnosis.
SmartDiagnosis
TM
●
The Tag On function allows you to conveniently use the LG Smart Diagnosis™,
Cycle Download, Laundry Stats and Tag On Cycle Set features to communicate with
your appliance right from your own smart phone.
Tag On function
New DD type washing with fabric care
Affective agitation
accelerates detergent
dissolving and improves
detergent penetration
into the clothes.
The half cycle
rotations of the wash
tub helps improve
stain removal.
The Waveforce action allows
greater soil removal by
creating centrifugal
water forces which also
helps reduce clothes wear
due to washing
Smart Drum achieved by DD Motor Technology
●
The incorporated Smart Drum allows a more cleaner and hygienic wash tub that also protects
against fabric wear due to washing.
Automatic heating system
●
Using its in built heater, the water for the Allergy and Stain Care cycle is heated
to a predetermined temperature, even when cold water is only connected.
The half cycle
rotations of the tub
also helps balance
the load and
reduce tangling.
START
WASHING
AUTO
POWER
OFF
SENSING
Laundry Sensor
Water Level Sensor
SETTING
Optimum
W
ashing
C
ondition
Normal logic control
●
A built-in load sensor automatically detects and measures the laundry load and a microprocessor
optimizes washing conditions such as ideal water
consumption and washing time.
●
Advanced technology is built into the Electronic Control
System which ensures the best washing result.
2
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 2
Contents
3
Introduction
Before Starting to
Wash
Washing Programs
Additional Function
Program
Installation
Care and Maintenance
Troubleshooting
Specification
Safety Information 4
Identification of Parts 7
Function Information 8
Preparation Before Washing 9
Use of Water, Dispenser Drawer, Detergent, Bleach and Softener
10
Special Guide for Stain Removal 13
Function of each Button 14
Cotton Wash 16
Stain Care Wash 16
Allergy Care Wash 16
Extra Rinse 16
Eco Cotton 16
Quick Wash 18
Delicates Wash 18
Towels Wash 18
Duvet Wash 18
Quiet Wash 18
Soak Wash 20
Intensive Rinse 21
Tub Clean 22
Air Dry 23
Option Washing 24
Time Delay (RESERVATION) Wash 25
Other Useful Functions 26
Using Tag On Function 27
Placing and Leveling 30
Connecting Water Supply Hose 31
Connecting the Drain Hose 34
Cleaning and Maintenance 35
Soft Safety Door (where fitted) 37
Common washing problems 38
Troubleshooting 39
SmartDiagnosis
TM
40
Specification 41
READ THIS MANUAL
Inside you will find many helpful hints on how to use and maintain your washer properly. Just a lit-
tle preventive care on your part can save you a great deal of time and money over the life of your
washer. You will find many answers to common problems in the Troubleshooting section. If you
review our chart of Troubleshooting Tips first, you may not need to call for service at all.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 3
Safety Information
4
Read carefully and thoroughly through this booklet as it contains important safety information
that will protect the user from unexpected dangers and prevent potential damages to the product.
This booklet is divided into 2 parts : Warning and Caution.
: This is a warning sign specifying user’s applications which might
be dangerous.
: This is a sign specifying ‘Strictly Forbidden’ applications.
WARNING
: Failure to comply with the instructions under this
sign may result in major physical injuries or death.
CAUTION
: Failure to comply with the instructions under this
sign may result in minor physical injuries or product
damages.
WARNING
• Under certain conditions hydrogen gas may be produced in a water heater that has not been
used for two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the HOT water has not been used for two weeks or more, prevent the possibility of
damage or injury by turning on all Hot water faucets and allowing them to run for several
minutes. Do this before using any electrical appliance which is connected to the HOT
water system. This simple procedure will allow any built-up hydrogen gas to escape. Since
the gas is flammable, do not smoke or use an open flame or appliance during this process.
• The base opening must not be obstructed by carpeting when the washing machine is installed on a
carpeted floor. This washer should not be used in any mobile application.
• Install or store where it will not be exposed to temperatures below freezing or exposed to the weather.
If the product is exposed to such conditions, electric shock, fire, break down or
deformation may occur.
• Properly ground washer to conform with all governing codes and ordinances. Follow details in
Installation Instructions.
If not grounded properly, break down and leakage of electricity may occur, which may
cause electric shock.
• Must be positioned so that the plug is accessible.
If the plug is placed between the wall and the machine, it may get damaged, possibly
causing fire or electric shock.
• Make sure the plug is completely pushed into the outlet.
Failure to do so may cause electric shock and fire due to overheating.
• This machine must not be installed outdoors, in a humid environment or in any sheltered outdoor area
where it is subject to weathering conditions.
WATER
HEATER
SAFETY
CAUTION
PROPER
INSTALLATION
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 4
Safety Information
5
Warning
• Keep the area underneath and around your appliances free of combustible
materials such as lint, paper, rags, chemical, etc.
Operating with such materials around the machine may trigger
explosion or fire.
• Close supervision is necessary if this appliance is used by or near children.
Do not allow children to play on, with, or inside this or any other appliance.
There is potential danger that children might drown in the tub.
Do not touch the power plug with a wet hand.
It will cause electric shock
Do not put your hand, foot or anything under the washing machine while
the washing machine is in operation.
There is a rotating mechanism under the machine, so you could be injured.
• Make sure that drainage is working properly.
If water is not drained properly, your floor may get flooded. Flooded floors
may induce electricity leakage, further resulting in electric shock or fire.
• If, during spinning, opening the lid does not stop the tub within about 15 seconds,
immediately discontinue operating the machine.
Call for repair. A machine that spins with its door open may cause injuries.
Never reach into washer while it the tub is still spinning.
Wait until the machine has completely stopped before opening the lid.
Even slow rotation can cause injury.
Never attempt to operate this appliance if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts, including a damaged cord or plug.
Operating with a damaged plug may cause electric shock.
Do not use water hotter than 65°C.
Use of excessively hot water may cause damage to delicate fabrics or
cause leakage of water.
• Use this appliance only for its intended purpose as described in this Owner’s Manual.
• The laundry process can reduce the flame retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s wash and care instructions.
• To minimize the possibility of electric shock, unplug this appliance from the power
supply or disconnect the washer at the household distribution panel by removing the
fuse or switching off the cirduit breaker before attempting any maintenance or cleaning.
• Do not place hands into the tub while it is rotating. Doing so can cause serious injury.
The machine should only be used for domestic household applications. Do not use the
washer for washing rugs, mats, shoes or pet blankets.
YOUR
LAUNDRY
AREA
Caution
WHEN USING
THE WASHER
NOTE : Pressing Power button to turn off does NOT
disconnect the appliance from the power supply.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 5
Safety Information
6
WARNING
Do not use a plug socket and wiring equipment for more than their rated capacity.
Exceeding the limit may lead to electric shock, fire , break down, and/or
deformation of parts.
Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce toxic gases which may cause death.
Do not wash or dry articles that have been cleaned in, washed in, soaked in, or spotted
with combustible or explosive substances (such as wax, oil, paint, gasoline,
dry-cleaning solvents, kerosene, etc). Do not add these substances to the wash water.
Do not use or place these substances around your washer or dryer during operation.
They may ignite causing an explosion or fire.
• Turn off water faucets to relieve pressure on hoses and valves and to minimize leakage
if a break or rupture should occur. Check the condition of the fill hoses; they may need
replacement after 5years.
• When the air temperature is high and the water temperature is low, condensation may
occur and thus wet the floor.
• Wipe off dirt or dust on the contacts of the power plug.
Using unclean power plug may cause fire.
• Before discarding a washer, or removing it from service, remove the washer lid to
prevent children from hiding inside.
Children may be trapped and suffocated if the lid is left intact.
Do not attempt to repair or replace any part of this appliance unless specifically
recommended in this Owner’s Manual, or in published user-repair instructions
that you understand and have the skills to carry out.
Operating the machine with improperly replaced parts may be a
cause for fire or electric shock.
Do not tamper with controls.
It may lead to electric shock, fire , break down, deformation.
Do not yank the power cord in an attempt to disconnect the power plug.
Securely hold the power plug to unplug the machine.
Failure to observe these instructions may cause electric shock or fire
due to short-circuit .
When you are cleaning the washing machine, do not apply water directly to any
part of the washing machine.
It will cause short circuit and electric shock.
WHEN USING
THE WASHER
CAUTION
WHEN NOT
IN USE
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 6
Identification of Parts
7
WATER SUPPLY
H
OSE
M
ake sure the water
does not leak.
JET SPRAY CAP
FUNCTION
SELECTOR
INNER TUB
BASE
ADJUSTABLE LEGS
Use to level the washing
machine for correct
balance & spin
operation.
DRAIN HOSE
Check if the drain hose
is installed and secured
before operating the
washing machine.
Do not lay the outlet end
of the drain hose on the
ground as water will
syphon out.
DOOR SWITCH
P
OWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid hazard.
START/PAUSE
BUTTON
Use to start or
stop the washing
machine
temporarily.
POWDER AND LIQUID
DETERGENT BOX
S
OFT SAFETY DOOR
(
some models only)
TEMPERED GLASS
BLEACH
DISPENSER
Body
“✽” Part can be different according to the model.
NOTE
* Picture might be different by model.
Accessories
Water supply hoses
(same for Hot & Cold)
Drain hose
Height adjustment piate
2 Pieces
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 7
Function Information
8
Our machine provides various washing methods which suits various conditions and types of laundry.
Cotton Wash
Extra Rinse
Delicates Wash
Quick Wash
Soak Wash
Time Delay (RESERVATION) Wash
Option Wash
Use this Program for everyday washing e.g. sheets, towels, T-shirts.
(refer to page 16)
Eco Cotton
For a normally soiled cotton load
. (refer to page 16)
Quiet Wash
Use this program to wash quietly at night. (refer to page 18)
Duvet Wash
Use for blankets or duvet with care labels that indicate hand wash.
(refer to page 18)
Stain Care Wash
Washing is the best temperature (40 degrees) by heating the clean clothes when you want to use.
(refer to page 16)
(Proper Water Temp. Hot:60°C / Cold:15 °C)
Allergy Care Wash
This cycle is a powerful, high temperature cycle designed specifically to reduce certain allergens.
(refer to page 16)
(Proper Water Temp. Hot:60°C / Cold:15 °C)
Towels Wash
Use this program to wash Towels, Sheets, mixed cotton loads.
(refer to page 18)
Use this program to get better rising performance. (refer to page 16)
Wool clothes (lingerie, wool, etc.) which may be easily damaged and should be washed according to their care label. (refer to page 18)
The fibers of machine washable woolens have been specifically modified to prevent felting when they are machine washed.
Most handknitted garments are not made of machine washable wool and we recommend that you hand wash them
• Before washing your woolens check the care label for the washing instructions.
• When washing woolens use a mild Detergent recommended for washing wool.
• Hand washed woolens may be spun in a washing machine to reduce the time they take to dry.
• To dry woolens lay down them flat on a towel and pat into shape. Dry woolens out of direct sunlight. (The heat and tumble action of a
dryer may cause shrinkage or felting of woolen garments.) Some wool underlays and sheepskin products can be washed in a washing
machine but may cause pump blockages. (Ensure that the whole article is suitable for machine washing and not just the backing mate-
rial.) You may wish to handwash these articles and place them in the machine to spin dry.
Quick Wash can be selected to wash lightly soiled clothes of less than 3.0 kg in a short time. (refer to page 18)
Soak Wash can be selected to wash heavily soiled laundry by soaking in water for some time to remove dirt and grime. (refer to page 20)
Intensive Rinse
Use Intensive Rinse to remove detergents more effectively. (refer to page 21)
Time Delay (RESERVATION) Wash is used to delay the finishing time of the operation.
The number of hours to be delayed can be set by the user accordingly. (refer to page 25)
When the user needs only Spin, Rinse/Spin, Rinse, Wash/Rinse, Wash, Wash/Rinse/Spin, Soak/Wash/Rinse/Spin (refer to page 24)
Tub Clean
Use this program to clean the inside of washing machine especially Inner tub & Outer tub . (refer to page 22)
Washing according to the condition of laundry
Other washing options
Different types of laundry washing
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 8
Preparation Before Washing
9
• Check all pockets to make sure that they are empty. Things such as nails, hairclips, matches,
pens, coins, and keys can damage both your washer and your clothes.
• Mend any torn garments or loose buttons. Tears or holes may become larger during washing.
• Remove belts, underwires, etc. to prevent damage to the machine or your clothes.
• Pretreat any dirt and stains.
• Make sure the clothes are washable in water.
• Check the washing instructions.
• Remove tissue from pockets.
To get the best results, different fabrics need to be washed in different ways.
• SOIL (Heavy, Medium, Light)
Separate clothes according to the type and amount of soil.
• COLOUR (Whites, Lights, Darks) Separate white fabrics from colored fabrics.
• LINT (Lint producers, Collectors) Separate lint producers and lint collectors.
Lint Producers Terry cloth, Chenille, Towels, Nappies, Diapers
Lint Collectors Synthetics, Corduroy, Permanent Press, Socks
Sorting
Check before Loading
* Look for a care label on your clothes. This will tell you about the fabric content of your garment
and how it should be washed.
Sort clothes into loads that can be washed with the same wash cycle, Water Temperature and spin speed.
Care Labels
CAUTION
Long laundry items
Use nylon nets for long, DELICATE items. For laundry with long strings or long length, a net will
prevent tangling during washing.
Fasten zippers, hook, and strings to make sure that these items don't
snag on other clothes.
※ Nylon net is not supplied by LG.
Light and Large-sized clothing
Clothes like downs and woollens are light weight, large and float easily. Use a nylon net and
wash them in a small amount of water. If the laundry floats during the wash cycle, it may
become damaged. Use dissolved Detergent to prevent the Detergent from clumping.
Do not wash fabrics containing flammable materials (waxes, cleaning fluids, etc.).
Load Size
The WATER LEVEL should just cover the clothes. Adjust the load size
accordingly. Loosely load clothes no higher than the top row of holes in the
washer tub. To add items after washer has started, press Start button and sub-
merge additional items. Close the lid and press Start button again to restart.
Do not wash or spin any item labeled or known to be water-proof or water-resistant, even if the product care
label on the item permits machine washing. Failure to follow these instructions could result in severe damage to
your laundry, your washer and/or property damage as a result of abnormal vibration of the washer.
- Examples of water-proof or water-resistant items include certain mattress pads, mattress covers, rain gear, camping
gear, skiing apparel , outdoor gear and similar items.
Loading
• Pretreat shirt collars and cuffs with a pre-wash product or liquid Detergent when placing them in the washer.
Before washing treat special stains with bar soaps, liquid Detergent or a paste of water and granular Detergent.
• Use a pretreat soil and stain remover.
Treat stains AS SOON AS POSSIBLE. The longer they are left the harder they are to remove. (For
more detail refer to page13)
Pretreatment on stains or heavy soil
WARNING
Fire Hazard
Never place items in the washer that are damp-
ened with gasoline or other flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of
oil on it (including cooking oils).
Doing so can result in death, explosion, or fire.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 9
Use of Water, Dispenser Drawer, Detergent, Bleach and Softener
10
• The machine sets the appropriate temperature automatically according to the wash program .
• The temperature of the water impacts the effectiveness of all laundry additives and therefore, the cleaning results.
We recommend temperatures of:
- HOT 49~60°C White items, nappies underclothing and heavily soiled, colorfast items.
- WARM 29~40°C Most items
- COLD* 18~24°C Only very bright colors with light soil.
• When washing in COLD water additional steps may be needed:
- Adjust Detergent amount and pre-dissolve Detergent in WARM water
- Pretreat spots and stains
- Soak heavily soiled items
- Use appropriate bleach
* Temperature below 18°C will not activate laundry additives and may cause linting & soap residue, poor cleaning, etc.
In addition, Detergent manufactures and care labels define COLD water as 26~29°C.
If the temperature of the water in the tub is too cold for your hands, the Detergent will not activate and clean effectively.
Water Temperature
Using Water
• This machine detects the weight of the of laundry automatically, then sets the Water Level
and indicates the recommended amount of detergent to be added by the detergent level indicator.
• When you select a wash program, the Water Level will be shown on the control panel.
• The following table shows the amount of water.
• When the Water Level is automatically detected, it may differ depending on the quantity
of laundry even though the same Water Level is indicated on the control panel. If bulky
light weight items are loaded, then it may be necessary to increase the water level manually.
Amount of WATER LEVEL
Using the Dispenser Drawer
NOTE
If iron is present in the water the clothes may become an all-over yellow or they may be stained with brown or orange spots
or streaks. Iron is not always visible. Installation of a water softener or an iron filter may be necessary for severe cases.
NOTE
[ Minimum water amount ]
The washer has the ability to detect the weight of the clothes to determine the appropriate water level, but cannot detect
the volume of clothes, therefore it will be necessary to increase the water level manually to avoid linting and tangling
when washing bulky light weight loads.
• Liquid Fabric Softener
• Liquid or Powder Low-Sudsing, High-Efficiency Detergent
The dispenser automatically dispenses additives at the proper time in the wash cycle.
1. Slowly open the dispenser drawer by pulling the drawer out until it stops.
2. After adding laundry products, slowly close the dispenser drawer. Closing the drawer
too quickly could result in early dispensing of additives.
• Avoid overfilling or splashing when adding laundry products to the dispenser.
Doing so could result in early dispensing of laundry products.
At the end of the cycle, you may see water in the compartments. This is part of the
normal operation of the washer.
NOTE : Do not use bleach in the dispenser drawer. Powdered detergent should only be used in the soap dispenser compartment.
For optimum results, it may be necessary to dilute the Liquid Fabric softener before adding it to the softener dispenser.
Using Dispenser Drawer
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 10
11
How much Detergent
The correct amount of Detergent will vary depending on the amount of soil in your clothes (Jeans and work
clothes may need more Detergent, while bath towels usually need less.).
For liquid and concentrated Detergents, follow the recommendations of the Detergent manufacturer.
Note: To check that you are using the correct amount of Detergent, lift the lid of your machine about
half-way through the wash. There should be a thin layer of foam over the surface of the water. Lots of
foam may look good, but it does not contribute to cleaning your clothes. No foam means not enough
Detergent has been used; soil and lint can settle back on the clothes or the washing machine.
If excess Detergent is used, the rinse will not be as clean and efficient. Also, it could cause
environmental pollution, so use it accordingly.
Add measured powdered detergent to the detergent compartment of the dispenser drawer.
The dispenser drawer MUST ALWAYS be in place before you start your washer
Detergent usage may need to be adjusted for water temperature, water hardness, size and soil level of the load.
Avoid using too much detergent in your washer, as it can lead to oversudsing and detergent residue being left on
the clothes.
Adding Detergent
Using Detergent
Detergent
Follow the Detergent package directions. Using too little Detergent is a common cause of laundry problems.
Use more Detergent if you have hard water, large loads, greasy or oily soils or lower Water Temperature.
Choosing the right Detergent
We recommend the use of domestic Detergent, (powder, liquid or concentrated). Soap flakes or granulated
soap powders should not be used in your washing machine. When washing woolens remember to use
Detergent suitable for washing woolens.
Attention
Using liquid detergent without diluting, or leaving laundry for a long time after pouring
diluted liquid detergent into the tub might cause damage, bleaching or discoloration of the clothes.
Note : Using Liquid detergent
- Dilute Liquid detergent with water and pour into the tub, start the cycle.
- Delay wash course is not available if you use liquid detergent.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 11
Use of Water, Dispenser Drawer, Detergent, Bleach and Softener
12
Using Fabric Softener
If you wish to use fabric softener we recommend
Attention
■ Do not mix with Detergent or bleach.
■ Never pour fabric softener directly on clothes. It may stain them.
■ Do not stop the washer during the first spin for timely dispensing.
■ Option washing is not designed to be used with fabric softener dispenser.
If desired, pour the recommended amount of liquid
fabric softener into the right-hand compartment.
Use only liquid fabric softener.
Dilute with water to the maximum fill line.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the fabric
softener, which could stain clothes.
NOTE : Do not pour fabric softener directly on the
wash load. It may stain the clothes.
Scrud(Waxy Build up)
Scrud is the name given to the waxy build-up that can occur within any washer when the fabric softener comes into
contact with Detergent. This build-up is not brought about by a fault in the machine.
If scrud is allowed to build-up in the machine it can result in stains on your clothes or an unpleasant smell in
your washer.
• Using fabric softener sparingly.
• When filling the dispenser, do not splash or overfill.
• Clean dispenser as soon as the cycle is finished.
• Clean your machine regularly. (refer to page 22 or 36)
• Cold water washing increases the chance of this build-up occurring. We recommend a regular WARM or HOT wash
e.g. every 5th wash should be at least a warm one.
• Fabric softener with a thinner consistency is less likely to leave residue on the dispenser and contribute to a build-up.
Bleach dispenser
• Check clothing care label for special instructions and separate the
laundry to be bleached
• Dilute liquid chlorine bleach.
• Measure the recommended amount of liquid bleach carefully
following instructions on the bottle.
• Before starting the washer, pour measured amount of bleach directly
into bleach dispenser. Avoid splashing or overfilling. Powdered
bleach should be mixed with water before pouring.
Using Liquid Bleach
NOTE
■ Never pour undiluted liquid bleach directly onto clothes or into the wash basket.
This may cause change of color or damage the laundry.
■ Do not pour powdered bleach into bleach dispenser.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 12
Special Guide for Stain Removal
13
For successful stain removal:
• Remove stains promptly.
• Determine the kind of stain, then follow the recommended treatment in the stain
removal chart below.
• To pretreat stains, use a prewash product, liquid Detergent, or a paste made from
granular Detergent and water.
• Use COLD water on unknown stains because HOT water can set stains.
• Check care label instructions for treatments to avoid on specific fabrics.
• Check for colorfastness by testing stain remover on an inside seam.
• Rinse and wash items after stain removal.
Follow fabric care
label instructions
WARNING
TREATMENT
■
Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or
p
roducts containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death.
■
To reduce the risk of fire or serious injury to persons or property, comply with the basic warnings listed below:
• Read and comply with all instructions on stain removal products.
• Keep stain removal products in their original labeled containers and out of children’s reach.
•
Thoroughly wash any utensil used.
• Do not combine stain removal products, especially ammonia and chlorine bleach. Dangerous fumes may result.
• Never wash items which have been previously cleaned in, washed in, soaked in or spotted with gasoline, dry cleaning solvents or
other flammable or explosive substances because they give off vapors that could ignite or explode.
•
Never use highly flammable solvents, such as gasoline, inside the home. Vapors can explode on contact with flames or sparks.
Stain Removal
STAIN
Adhesive tape, chewing gum, rub-
ber cement
Baby formula, dairy products, egg
Beverages (coffee, tea, soda, juice,
alcoholic beverages)
Blood
Candle wax, crayon
Chocolate
Collar or cuff soil, cosmetics
Dye transfer on white fabric
Grass
Grease, oil, tar (butter, fats, salad
dressing, cooking oils, car grease,
motor oils)
Ink
Mildew, scorch
Mud
Mustard, tomato
Nail polish
Paint, varnish
Rust, brown or yellow
discoloration
Shoe polish
Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with prewash stain remover or
nonflammable dry cleaning fluid.
Use product containing enzymes to pretreat or soak stains.
Pretreat stain. Wash using COLD water and bleach safe for fabric.
Rinse with COLD water. Rub with bar soap. Or pretreat or soak with product containing enzymes. Wash using
bleach safe for fabric.
Scrape off surface wax. Place stain face down between paper towels. Press with warm iron until wax is absorbed.
Replace paper towels frequently. Treat remaining stain with prewash stain remover or nonflammable dry cleaning
fluid. Hand wash to remove solvent. Wash using bleach safe for fabric.
Pretreat or soak in WARM water using product containing enzymes. Wash using bleach safe for fabric.
Pretreat with prewash stain remover or rub with bar soap.
Use packaged color remover. Wash using bleach safe for fabric.
Pretreat or soak in WARM water using product containing enzymes. Wash using bleach safe for fabric.
Scrape residue from fabric. Pretreat. Wash using hottest water safe for fabric. For heavy stains and tar, apply
nonflammable dry cleaning fluid to back of stain. Wash towels with stains frequently. Rinse throughly. Wash
using hottest water safe for fabric.
Some inks may be impossible to remove. Washing may set some inks. Use prewash stain remover, denatured
alcohol or nonflammable dry cleaning fluid.
Wash with chlorine bleach if safe for fabric. Or, soak in oxygen bleach and HOT water before washing. Badly
mildewed fabrics may be permanently damaged.
Brush off dry mud. Pretreat or soak with product containing enzymes.
Pretreat with prewash stain remover. Wash using bleach safe for fabric.
May be impossible to remove. Place stain face down on paper towels. Apply nail polish remover to back of stain.
Repeat, replacing paper towels frequently. Do not use on acetate fabrics.
WATER BASED : Rinse fabric in cool water while stain is wet. Wash. Once paint is dry, it cannot be removed,
OIL BASED AND VARNISH : Use solvent recommended on can label. Rinse throughly before washing.
For spots, use rust remover safe for fabric. For discoloration of an entire load, use phosphate Detergent and
nonchlorine bleach. Do not use chlorine bleach because it may intensify discoloration.
LIQUID : Pretreat with a paste of granular Detergent and water. PASTE : Scrape residue from fabric.
Pretreat with prewash stain remover or nonflammable dry cleaning fluid. Rub Detergent into dampened area,
Wash using bleach safe for fabric.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 13
Function of each Button
14
NOTE
* For optimizing the washing algorithm, the displayed time may change during washing-increased by a maximum
of 10 minutes (not including spin irregularity correction time) or decrease by a maximum of 4 minutes.
* The Vapour Mode option cannot be used with all cycles.
* Vapour may not be clearly visible during the Vapour Mode cycles.
This is normal. Too much vapour could damage clothing.
* Do not use Vapour Mode with delicate fabrics such as wool, silk, or easily discolored fabrics.
Intensive Wash button
Vapour Mode button
Hot and cold wash laundry button
Water Level button and
Detergent amount indicator
Remaining wash, reservation
time, and error message display
• Laundry progress is indicated here.
• A flashing indicator means that the
process is in operation, an indicator
which is on but not flashing means
it is awaiting that process and
process indicators that are not lit
means that the process is complete
or was not selected.
• Allows a higher agitation
intensity.
• It is set to Medium intensity
by default (Select is off.)
Select Intensive Wash by
pressing the button. (Can be
set on all courses except
Delicates, Allergy Care,
Quiet Wash and Tub Clean.)
• Vapour Mode can be selected
with the Stain Care and
Cotton Wash courses.
It increases the wash
temperature to 60Deg C for
a short period of the wash
cycle.
• Vapour Mode is automatically
selected with the Allergy
care course.
Time Delay
(Reservation) button
• Use for laundry
reservation.
• To cancel, press
the power button.
(refer to page 25)
•
To select hot water, cold water, or warm water washing.
•
Can be changed during operation.
•
If hot wash is selected, laundry will be done with hot water and rinse will
be done with cold water..
•
The preset water temperature for Delicates is Cold water only.
(The laundry can be damaged if Hot water is used)
•
Warm water (Hot + Cold Wash)is automatically selected on the Stain care,
Allergy Care, Extra Rinse and Tub Clean cycles.
• Press to manually select
the Water Level.
• It can be changed during
operation.
• Detergent indicator
suggests the recommended
powdered detergent
amount to add.
• During operation this indicates the
remaining wash time.
• If there is a malfunction, the error
message will be displayed to assist
in troubleshooting the problem.
Wash Status display
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 14
15
* For optimal Vapour cleaning performance, limit laundry loads to 4 kg or less.
* When the Vapour mode option is selected for the Medium Soiled the water level
will not exceed level ‘7’ in order to maintain optimal performance.
* The control panel may differ according to different models.
Wash, Rinse, Spin button Child lock function Program button
Air dry
START/PAUSE button
SmartDiagnosis
TM
Function Display
Power button
•
To change the wash time,
number of rinses, strength
of spin dry.
•
Increase the amount of
Rinses to effectively
remove detergent residue.
•
Stops any accidental
changes by making the
keypad inoperative.
•
Press 'Rinse' button for 3
seconds to select or
deselect.
(refer to page 26)
•
Selects the Wash
cycle course.
•
Select the
appropriate wash
Cycle to suit the
clothes type and
soil level.
• To shorten dry time.
•
Press the Spin button
for 3 seconds
to select, press power
button to deselect.
(refer to page 23)
• Use to start or pause
the washing process.
• After 4 minutes in
pause status, the
washer will
automatically turn
off.
• It marks the place
to put the phone to
receive the SDS signals
when prompted to by
a Customer Care
Consultant.
(refer to page 40)
• Use to turn the power
on or off.
• Push again and power
goes on or off.
• The power turns off
automatically about
10 seconds after the
wash is finished.
•
Do not touch the lid
during Vapour Mode
cycles.
The lid Surface can
become warm..
Allow the lid lock to
release before
opening the door.
• Do not attempt to
override the lid lock
mechanism or reach
into the washer
during a Vapour
Mode cycle.
WARNING
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 15
Washing Programs
16
Washing
Programs
Add the
laundry
Add
the Detergent
Used for Cotton wash loads, this
mode automatically selects the most
appropriate conditions and completes
the sequence in one operation. The
built-in sensor detects the weight of
the load and the ideal wash power
and wash, rinse and spin times are set
accordingly.
Is best used when a hygienic wash
is required. The internal heater
heats the water if necessary to 40
degrees during the main wash.
Vapour Mode can be selected with
the Stain Wash Program to increase
the wash temperature briefly to 60
Deg C.
This cycle is a powerful, high
temperature cycle designed
specifically to reduce certain
allergens. The water temperature
for a brief period of the wash
cycle will be 60Deg C
Use this program to increase rinsing
performance. This would include
underwear and baby clothes. If
someone has sensitive skin then this
program is recommended to be used.
1
2
3
•
The water will commence
filling when the wash cycle
begins.
1
2
3
4
Eco Cotton cycle consumes less water
and electricity to wash normally Soiled
cotton loads.
•
Select the
Eco Cotton
program on the
Control panel.
• Select the Extra
Rinse program on
the Control panel.
• Add the appropriate quantity
of Detergent As indicated by
the Water Level. Or follow
the Detergent Manufacturer's
instructions.
1
2
3
4
1
2
3
4
1
2
3
4
• Select the Stain
Care program on
the Control
panel.
• Do not load
more than
5kg.
• Do not load
more than
4kg.
• Select the
Allergy Care
manufactures’
program on the
Control panel.
• Add the appropriate quantity
of Detergent As indicated by
the Water Level. Or follow
the Detergent Manufacturer's
instructions.
•
Add designated amount of detergent
by Water Level and close the door.
Use exclusive neutral detergent or
dry detergent
.
• Add the appropriate quantity of
Detergent as indicated by the
Detergent level indicator.
Or follow the Detergent
manufacturer's instructions.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 16
17
Close the lid Finish Caution & Note
• The tub will repeatedly rotate
briefly to detect the weight of
the clothes and indicate the
set water level. The water
l
evel can then be manually
i
ncreased if necessary.
• The Detergent level indicator
will suggest the detergent
amount that should be added.
• The water will
commence filling when
the wash cycle begins.
• When the wash
program ends, the
buzzer will ring for
10 seconds before
the Power goes off
automatically.
• If water is already in the tub, or putting wet laundry into the
tub before starting will increase the Water Level.
• With lightweight bulky loads, Water Level can be set low.
• Changes to Water Temperature (Hot Wash/Cold Wash)
and wash level are possible during operation.
(refer to page 10)
5
4
6
6
5
7
6
5
7
6
5
7
6
5
7
•
Stain care 40 degree course selects both Hot and Cold water
when filling. When the water is filling, the Hot and Cold valves
may turn on and off repeatedly to achieve the 40 degrees. The
i
nternal heater may operate if necessary.
※ Stains that easily removed at 40℃ : coffee, cola, orange juice,
grape juice, soy sauce etc.
•
If only hot wash is selected, the wash time will be reduced as
heating time is shortened, however this can damage clothes if
the temperature of the hot water tap is too hot.
•
If only cold water is connected, the wash time is longer as
heating time lengthens. Uses cold wather and hot water together.
•
While heating, the wash tub will rotate slowly. This is a part of
normal operation.
•
While heating, because of humidity condensation may form on
the glass door. This is normal. Just wipe it after the washing has
ended.
•
It is normal for the exterior of the machine to become warm.
•
Allergy Care course selects both Hot and Cold water when filling.
When the water is filling, the Hot and Cold valves may turn on and
off repeatedly to achieve the 60 degrees. The internal heater may also
operate if necessary.
※ Stains that easily removed at 60℃: milk, blood, sebum, egg, animal
fat and vegetable oil.
•
If only Hot Wash is selected, the wash time will be reduced as
heating time shortens.
•
If only Cold water is connected, the wash time is longer as heating
time lengthens. Uses cold water and hot water together.
•
While heating, the wash tub will rotate slowly. This is a part of
normal operation.
•
While heating, because of humidity condensation may form on the
glass door. This is normal. Just wipe it after the washing has ended.
•
It is normal for the exterior of the machine to become warm.
•
The Allergy Care course can reduce allergens in bedding and
clothing.
•
Due to the higher energy and temperatures used, the Allergy Care
course is not recommended for wool, silk, leather, or any other
delicate or temperature sensitive items.
• During Rinse, the tub will rotate slowly while water is supplied.
The water will drain out after each rise. During spray rinse, it is
normal for the water to be drained out simultaneosly.
INFORMATION FOR ENERGY TEST
• Select the water temperature to suit wash cycles. Always follow
garment manufacture's care label or instructions when washing.
• Set program of Eco cotton, Spin Ultra, Rinse 5, Wash 6, Water Level 2, Cold Wash,
Hot Wash, Soak 1:00 is for normally soiled load and testing in accordance or in
conformity with AS/NZS 2040. 1.
• The test results depend on water pressure, water hardness, water inlet temperature,
room temperature, type and amount of load, degree of soiling utilized detergent,
fluctuations in the main electricity supply and chosen additional options.
•
For best washing results, we recommend dilute the detergent powder (Drum Type) in
WARM water and pour directly into tub.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 17
Washing Programs
18
Washing
Programs
Add the
laundry
Add
the Detergent
Use this cycle when washing
lightly soiled clothes for a short
time. This cycle is most effective
and should only be used with
loads weighing less than 3.0kg.
1
2
4
• Add the appropriate quantity
of Detergent as indicated by
the Detergent level indicator.
Or follow the Detergent
manufacturer’s instructions.
1
2
3
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Use this program to wash quietly in
Silent especially during late night
and early morning when less noise
is preferable.
Use for blanket or bedclothes or
pillow and quilt covers.
Use this cycle for Bath towels, bath
robes, hand towels etc.
•
Select the Quiet
wash program
on the Control
panel.
• Select the Duvet
program on the
Control panel.
• Add the appropriate
quantity of Detergent as
indicated by the Detergent
level indicator.
Or follow the Detergent
manufacturer's instructions.
•
Select the Towels
program on the
Control panel.
• Add the appropriate
quantity of Detergent
As indicated by the
Detergent level indicator.
Or follow the Detergent
Manufacturer's
instructions.
• Pour the detergent
directly into the tub after
dissolving it with warm
water. if Cold water
washing can cause
detergent residue to
remain.
• Select the
Quick Wash
program on
the Control
panel.
• Select the
Delicates
program on the
Control panel.
Use this program for washing
delicate fabrics such as lingerie
and woolens. (wash only “water
washable” clothes)
Before washing your woolens
check the care label for the
washing instructions.
• Use neutral Detergent
appropriate for the
clothes.
• When washing woolens
use a mild Detergent
recommend-ed for
washing wool.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 18
19
Close the lid Finish Caution & Note
6
5
7
6
5
7
• Quiet wash
program has a longer washing
time than the Cotton Wash program.
•
To reduce the overall noise during spin, the
spin speed is reduced, therefore the clothes
will have a higher moisture level at the end
of the wash.
6
5
7
6
5
7
6
5
7
•
Lay out onto a cool floor or on a hanger
covered by a towel to dry these type of
clothes.
•
The Spin intensity or spinning time cannot
be changed in this cycle as higher spin
speeds can damage delicate clothing.
• When washing bulkier loads the water
level should be manually increased to
reduce linting and detergent residue.
• Cashmere bedclothes, acrylic blanket, mixed
spinning blanket, woolen blanket, infilling
(polyester 100), and bed sheets may be damaged
if not washed in laundry nets or bags.
• Separate bed clothes from general clothes. They
may become entangled or ball together and cause
abnormal washing, especially if the water level is
too low. It can be increased manually during the
wash.
• Spin dry may take longer if the load becomes
lumped together and then attempted to be
automatically corrected by the machine, by
refilling with water.
• Never wash electric blankets, mats , rugs or shoes in
the machine as it will cause a malfunction and can
damage the machine.
• Use laundry bags or nets with items that can inflate
with air and float during the wash.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 19
20
Soak Wash
1
2
3
4
5
6
Press the POWER button to turn power on.
Load the clothes and Press the Program button to select the
Washing Program.
•
Soak is not selectable with the Stain Care, Allergy Care, Delicates,
Quick Wash and Tub clean programs.
Press the rinse and Spin buttons to select the number of Rinses and the
Spin speed intensity.
Press the START/PAUSE button.
•
Water will then be supplied and the Soak wash will begin.
Add the suggested detergent indicated by the detergent level indicator
and close the Lid.
When the Soak wash program ends, the chime will sound for
10 seconds before the Power turns off automatically.
Press the Soak button.
•
“Soak” can be selected by pressing the Soak button which then turns on the
soak indicator( )
•
Soak selection : 15 ▶ 30 ▶ 45 ▶ 1:00 ▶ 2:00 ▶ 3:00 ▶ off ▶ 15
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 20
1
2
3
4
5
6
times times times times times times times times
times
timestimes
21
Intensive Rinse
Press the Rinse button to scroll through the number of Rinses. The
Intensive Rinse will be selected on every second press of the Rinse
button and indicated by the Intensive indicator.( ).
Press the POWER button to turn power on.
Load the clothes and Press the Program button to Select the Washing
Program.
•
Intensive Rinse can only be selected with the Cotton Wash and Extra Rinse courses.
Press the START/PAUSE button.
Press the Wash and Spin buttons to select the wash time and spin
speed intensity.
When the wash program ends, the chime will sound for
10 seconds before the Power turns off automatically.
Add the suggested detergent indicated by the detergent level indicator and
close the Lid.
• Use Intensive Rinse to remove detergents more effectively.
• Intensive Rinse will be cancelled if the Water Level is changed during operation.
NOTE
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 21
22
Tub Clean
Press the POWER button to turn power on.
When the cleaning program ends, the chime will sound for 10
seconds before the Power turns off automatically.
Press the Program button to Select Tub Clean Program.
『Hot Wash』, 『Cold Wash』and Water Level of 『1』will be selected automatically.
Press the START/PAUSE button.
The Tub Clean duration will be displayed on the washers display.
Place the recommend dose of a suitable cleaning agent into the
tub and close the Lid.
NOTE: Do not add clothes or any items into the tub during this
program.
If scrud is allowed to build-up in the machine it can result in stains on your clothes or an unpleasant smell in your
washer.
Scrud is the way build-up that can occur within any washer when the fabric softener comes into contact with
Detergent, water quality and temperature will also contribute to the build up of this substance. the Tub clean cycle
can help prevent or prolong the build up.
Recommended cleaner :
(1) Powder bleaching agent :
Purchase a suitable product and refer to usage instructions on the product packaging.
(2) Liquid bleaching agent:
Read the manufacturer’s instructions carefully.
Do not put laundry for laundry tub course.
• Use oxide bleaching agent (300g). (do not use chlorine bleaching agent.)
• We recommend this program be used at regular intervals. (once a month)
• Remove all lint from the tub before commencing this program.
Automatic Tub Clean reminder.
• If after pressing the Power On button the is displayed, it suggests it is time for
Tub Cleaning.
•If you want to skip the Tub Clean, press the Program and option buttons to continue on to the
desired cycle. The Tub Clean reminder will reappear after 3 or so washes if it is skipped, and
continue to do so until the Tub Clean cycle is carried out.
• After performing tub clean, will disappear until next Tub clean reminder.
• Tub Clean reminder is automatically determined by the washer's usage.
(Generally once after 30 usages)
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 22
23
Air Dry
Press the POWER button to turn power on.
Then load up to 2kg of damp or moist clothes into the tub.
This function will have no effect on clothes that are soaking wet.
Press the START/PAUSE button.
When the Air Dry program ends, the chime will sound for
10 seconds before the Power turns off automatically.
Press the Spin button
for 3 seconds to select Air Dry.
•
Other functions cannot be selected during Air Dry.
•
This Function is automatically set to 60 minutes upon selection.
•
Press the Spin button repeatedly to select the duration (90min
. ▶
120 min
.
▶
60 min.)
•
To deselect Air Dry press power button.
When you select Air Dry for more than 60 minutes
1) You can reduce the clothes drying time by minimzing the moisture in the clothes,
however, this function will not dry clothes completely but will aid the clothes drying
time when they are removed from the tub.
2) Always keep the laundry amount to 2kg or less and make sure to spread it out evenly.
3) Select 60 minutes for cotton clothing and 120 minutes for synthetic fiber clothing for
effective Moisture removal.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 23
24
Option Washing
Add the clothes into the washing tub.
Press the START/PAUSE button.
Press the Water Level button to select the water level
according to the amount of laundry. If you do not select a
level, it will remain on the middle level default setting.
The correct water level is when the clothes are completely
submerged in water..
Add the detergent and close the lid.
3
4
5
6
2
Press the POWER button to turn power on.
• When a Wash, Wash/Rinse or Rinse only option is selected, after the wash is completed the water will not
be drained out. If you wish to drain the water, but not engage the spin, then follow the above Drain Only
instructions, after the Wash, Wash/Rinse or Rinse only program has ended.
• If you do not specify the water level, then Medium will be automatically selected.
NOTE
Press the
Rinse
button to
select the desired number
of Rinses.
Rinse Only
Press the
Spin
button to
select the desired Spin
speed intensity.
Spin Only
1
Press the
Wash
button to
select the desired wash
time.
Wash Only
Press the
Rinse
button to
select the desired number
of Rinses.
Press the
Spin
button to
select the desired Spin
speed intensity.
Rinse and Spin Only
Can be used when draining
of the remaining tub water
in required.
Turn on the machine and
press the Spin button then
press START/PAUSE. The
POWER can then be turned
off when the remaining
water has drained just
before the Spin starts.
Drain Only
Press the
Wash
button to
select the desired wash
time.
Press the
Rinse
button to
select the desired number
of Rinses.
You can use this option
for preventing wrinkles by
not allowing the tub to
spin after the Rinse.
Wash and Rinse only
When you only need the Wash, Wash/Rinse or Rinse cycles, these can be set manually.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 24
25
Time Delay (RESERVATION) Wash
1
2
3
4
Press the POWER button to turn power on.
Load the clothes and add the powdered detergent to the soap dispenser
and Press the Program button to select the desired Washing Program.
•
Do not use liquid detergent in the soap dispenser drawer. Doing so will cause it to
dispense immediately and harden in the wash tub.
•
This program will not work in Delicates and Tub Clean Program.
Close the door and press the START/PAUSE button.
•
The Time Delay indicator will flash and the display will show the set delay time.
The Wash cycle will be completed at the end of the Delayed time
indication.
•
The end time may vary slightly due to environmental conditions such as water
temperature and water inlet pressure.
Press Time Delay (Reservation) button to set the delayed wash ending time.
•
If reservation button is pressed, it will turn on the Delay Time indicator and show 3:00.
•
The Time Delay can be set from 3~18 hours by 1 hour intervals up to 3~12hours
and 2 hour intervals for 12~18 hours.
•
A Time Delay of less than 3 hours cannot be selected.
Eg: It is 1:00 PM and you want to finish the laundry by 7:00 PM
•
Keep press reservation button to set desired laundry ending time.
(1:00 to 7:00 = 6:00 Hours)
•
To cancel any Time Delay setting, press Time Delay (Reservation) button repeatedly until the
reservation is canceled or press the POWER button to turn off the power.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 25
26
Other Useful Functions
• After all washing conditions are set according to the manual.
Press the POWER button.
Press the
START/PAUSE button to start washing.
• Turn Power on.
If you want to lock all the keys to prevent settings from being changed by a child, you can use the child lock option.
For safety reasons, the POWER button will still function whilst the Child Lock mode is activated.
Child Lock Function
How to Lock
2
1
•
The button lock is set, it will not be released
automatically if the cycle is terminated.
•
Therefore it will be necessary to turn the POWER
back on and cancel the Child Lock function by
holding down the "Rinse" button.
Press the Rinse button.
If you want to unlock during wash, press the Rinse button again.
How to Unlock
• “CJ” & the remaining time are alternatively shown on the display while the child lock is active during the wash.
NOTE
3
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:39 페이지 26
Using Tag On Function
27
• The Tag On function allows you to conveniently use the LG SmartDiagnosis
TM
1 and Cycle
Download features to communicate with your appliance from your own smart phone.
• To use the Tag On function:
1. Download the LG Smart Laundry & DW Global App to your smart phone.
2. Tum on the NFC (Near Field Communication) function in your smart phone.
• The Tag On function can only be used with most smart phones equipped with the NFC
function and based on the Android operating system (OS).
1. Enter the "Settings" menu of the smart phone and select "Share &
Connect" or "More ... " under "WIRELESS & NETWORKS".
2. Set the "NFC" and "Direct Android Beam" to ON.
3. Check "Use Read and Write/P2P receive".
■ Turning on the NFC function of the smart phone
• Depending on the smart phone manufacturer and Android OS
version, the NFC activation process may differ.
• Refer to the manual of your smart phone for details.
NOTE
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 27
Using Tag On Function
28
• Tag 0n:
Look for the Tag On icon next to the LED screen on the control
panel. This is where you position your smart phone when using
the Tag On function with the LG SmartDiagnosis
TM
and Cycle
Download features of the LG Smart Laundry & DW Global App.
• When you use the Tag On function, position your smart
phone so that the inbuilt NFC antenna in the back of your
smart phone matches the position of the Tag On icon on
the appliance.lf you do not know the position of your NFC
antenna, move your smart phone very slightly in a circular
motion until the application verifies the connection.
■ Turning on the NFC function of the smart phone
► Tag On position
• Because of the characteristics of NFC, if the transmission distance is too far, or if there is a metal
sticker or a protective case on the phone, transmission will not be good. In some cases, NFC-equipped
phones may be unable to transmit successfully.
• Press in the LG Smart Laundry & DW Global App for a more detailed guide on how to use
the Tag On function.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 28
Using Tag On Function
29
■ Tag On Cycle Download
This function will allow you to choose an additional cycle (available from a list in the LG Smart Laundry &
DW Global app) and download the cycle to the "Download Cycle" option on the front of the washing machine
control panel.
To use this function, simply select "Tag On Cycle Download" in the LG Smart Laundry & DW Global app
(refer to "Before using the Tag On Function" in this manual) and then select your desired cycle from the list,
then simply hold your phone next to 'Tag On" icon on the front of the washing machine and your desired cycle
data will be downloaded to the washing machine "Download Cycle" option on the front control panel.
• If the washing machine is currently in the middle of any cycle, you cannot transfer a new cycle to
the "Download Cycle" option on the front of the washing machine control panel, an error message
"Notice- the appliance is running" will be displayed on the application.
• After the cycle data has been downloaded to the washing machine from the LG Smart Laundry &
DW Global app, the "Download Cycle' option will memorise and retain the cycle data, even if the
ashing machine is switched off then back on at the power point.
• After the cycle data has been downloaded to the washing machine from the LG Smart Laundry &
DW Global app, the cycle will not start automatically, you can start the cycle by pressing the
"Start/Pause" button on the front of the washing machine control panel.
• As the washing machine is not able to display the additional cycles anywhere on the front control
panel, you can check what cycle is currently in use by selecting "Tag On Cycle Download", and
tapping the refresh symbol. The app will then prompt you to ''Tag on Target Area"
NOTE
■ Laundry Stats
This function will tell you when the next Tub Clean cycle is needed tor your washing machine and also tell
you the 3 below points of data from the washing machine:
• The history of the 10 most recently used cycles (in no specific order)
• The most "frequently used cycle"
• The last cycle that was used or that is currently in use
To use this function simply select "Laundry Stats" in the LG Smart Laundry & DW Global app and the
above cycle data will be displayed.
■ Tag On Cycle Set
This function will explain in more detail, the recommended applications for some certain cycles that are
available on the front of the washing machine control panel. (excluding "Download Cycle").
To use this function simply select the "Tag On Cycle Set" on your LG Smart Laundry & DW Global app, then
select your applicable cycle, then simply hold your phone up to "Tag On" icon of the front of the washing
machine and the desired cycle will automatically start.
• If washing machine is turned off from the power point and then back on, the washing machine will
still memorise and retain all 3 above points of cycle data.
• If the unit is currently in the middle of any cycle, you can still use the "Laundry Slats" function of the
LG Smart Laundry & DW Global app.
NOTE
• If the unit is currently in the middle of a cycle, you cannot set a "Tag On Cycle Set, an error
message "Notice- the appliance is running" will be displayed on the application.
NOTE
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 29
30
Placing and Leveling
Please ensure any foam transit restraint has been removed from the machines packaging before.
If the washer is installed on an uneven, tilted, or weak timber floor causing excessive vibration,
a spin failure or “UE” error can occur.
It must be placed on a firm and level floor to prevent spin failure.
Top view of the machine
more than 10 cm
m
ore
t
han
2
c
m
more than
2 cm
Place the machine on a flat and firm surface which allows proper clearance.
We suggest a minimum clearance of 2 cm to the
right and left sides of the machine for ease of
installation.
At the rear, a minimum clearance of 10 cm is sug-
gested.
Check that the machine is level
Open the lid and look from above to see if it is
same as shown.
Leveling the machine
Lift the front of the washing machine and twist
the appropriate Adjustable Leg until the surface
bubble is (some models only) located in the
center.
1
2
3
NOTE
Adjustable legs
Caution
How to use the rubber adjusting plates
•
Use the adjusting plates to level the washer
when the adjustable legs cannot cover the gap.
If an extension cord or power board is used, ensure it is positioned so that it is not exposed to water or
moisture. This machine should be connected to a 230~240v town mains power outlet.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 30
31
Connecting Water Supply Hose
Before connecting the Water Supply Hose to the water tap, check the hose type and then choose the
correct instruction here under.
Note that the Water Supply Hose supplied may vary from country to country, Make sure to connect the
blue inlet hose to the COLD water tap, and the orange inlet hose to the HOT water tap.
Connecting Water Supply Hose to water tap
Connector
Connector
Water
Supply Hose
screw
Untighten the screw
Untighten the screw of the connector so that the
tap can be placed in the middle.
Fixing the connector to the tap
Push the upper connector up till the rubber pack-
ing is in tight contact with the tap. Then tighten
the 4 screws.
Attach the water supply hose securely to the
connector
Push the water supply hose vertically upwards so
that the rubber seal within the hose can adhere
completely to the tap.
Check the connection of water supply hose and the connector
After connecting the hose, open the tap to check
for any water leakage.
If the water leaks, close the tap and start again
from step 1
Fixing the connector to the water supply hose
Attach the water supply hose to the connector and
then tighten it by screwing it to the right.
Normal Type
(Normal tap without thread & screw type inlet hose.)
1
2
3
4
5
Rubber packing
NOTE
The washing machine is to be connected to the water mains using new hose-sets and old hose-sets should
not be reused.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 31
32
Connecting Water Supply Hose
Separate Middle connector from Water Supply Hose
Separate Middle connector from the Water
Supply Hose by pulling the Pressing Rod and the
Pressing Handle that is attached to the Water
Supply Hose.
Loosen the fixed nuts to connect the connector to the tap
Untighten the screw of the connector so that the
tap can be placed in the middle.
Fixing Connectors to the Tap
Push the upper connector up till the rubber pack-
ing is in tight contact with the tap. Then tighten
the 4 screws.
Fixing Upper Connector and Middle Connector
Remove the fixed sticker in between the Upper
and Middle Connectors. Tighten the connectors
by holding one connector and twist middle con-
nector to the right.
Connecting Middle Connector and Water Supply Hose
Press down the pressing rod of the Water Supply
Hose which was separated from middle connector
(refer to Step1) and then join it to the middle con-
nector.
Normal Type
F
ixed Sticker
Pressing Handle
Pressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
Middle
C
onnector
Fixed Sticker
Pressing Handle
Pressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
Middle
C
onnector
Fixed Sticker
Pressing Handle
Pressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
M
iddle
C
onnector
F
ixed Sticker
Pressing Handle
Pressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
M
iddle
Connector
Fixed Sticker
Pressing Handle
Pressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
G
uide plate
Fixed sticker
screw
Middle
Connector
Fixed Sticker
Pressing Handle
P
ressing Rod
Water Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
Middle
C
onnector
Fixed Sticker
P
ressing Handle
Pressing Rod
W
ater Supply Hose
Pressing Rod
Pressing Rod
Connector
Connector
Connector
Middle
Connector
Middle
Connector
Pressing handle
Pressing rod
Water Supply Hose
Fixed sticker
Guide plate
Fixed sticker
screw
Middle
Connector
If the tap diameter is too large or is square,
untighten the 4 screws and remove the guide
plate. Then follow step1.
In case tap is too large.
NOTE
Check for water leakage
After connecting the hose, open the tap to check
for any water leakage.
If the connection leaks, close the tap and start
again from step 1.
If you skip step 1, water leakage may occur.
(Normal tap without thread & one touch type inlet hose.)
1
2
3
4
5
6
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 32
33
Water tap
Rubber Packing
Water Supply Hose
Rubber seal
Hose connector
Water tap
Rubber Packing
Water Supply Hose
Rubber seal
Hose connector
W
ater tap
Rubber Packing
Water Supply Hose
Rubber seal
Hose connector
Water tap
Rubber Packing
Water Supply Hose
Rubber seal
Hose connector
Water tap
Rubber Packing
Water Supply Hose
Rubber seal
Hose connector
Attach the water supply hose to the tap.
Push the water supply hose up so that the rubber
washer within the hose is properly seated to the tap.
Connect the water supply hose to the tap.
Connect the water supply hose to the tap and then
tighten it by screwing it to the right.
Securely Hand tighten only. Do not use any
mechanical device to tighten the hose connector.
Check for water leakage.
After connecting the hose to both the tap and the
machine, open the tap to check for any water leakage.
• Connect the water supply hose to the inlet valve
of the washing machine, and then turn the hose
connector to the right until secure. Do not use any
mechanical device to tighten. Hand tighten only.
• Make sure there is a rubber washer in both
connectors before connecting
Screw Type
Connecting Water Supply Hose to the machine
1
2
3
Connecting Water Supply Hose
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 33
34
Connecting the Drain Hose
Before connecting the Drain Hose, check your Drain Hose model and choose the correct instructions.
Hose
Guide
0.9~1.2m
Drain Hose
Within 50mm
Put the other end of the drain hose over the standpipe or
wash tub.
2
Fit the end of the drain hose to the outlet of the
drain pump and secure the clamp.
Pump Model
Hose
Guide
0.9~1.2m
Drain Hose
Wi
th
i
n
50
m
m
To prevent siphoning, the drain hose should not extend more than 50 mm from the end of the hose guide.
The discharge height should be approximately 0.9 ~ 1.2 m from the floor.
NOTE
1
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 34
35
Cleaning and Maintenance
When water supply into the tub is not clean or the inlet valve filter is clogged with particles (such as sand),
clean the filter in the inlet valve occasionally.
(The image of the power cord and water tap may vary according to the country)
To Clean the Filter in the Inlet Valve
Cold water washing
Close the taps. Turn on the washer and
press START/PAUSE. the washer will
attempt to commence washing and release
the water in the inlet valves. When there is
no more water, turn the power off from the
mains outlet switch.
• If you always use COLD water, we recommend that a WARM or HOT wash be used at a regular
intervals e.g. every 5th wash should be at least a WARM one.
When you have finished
• Turn off taps to prevent the chance of flooding should a hose burst.
• Always unplug the power cord after use.
Turning the washer off from the POWER button does not disconnect the main power.
After removing the inlet water
supply hose pull out the filter.
Then use a brush to clean the filter.
Turn off the power before
pulling out the cord.
Refit the filter after cleaning it and
reconnect the inlet hose as per the
installation instructions.
1 2
3 4
NOTE
•
before reconnecting the inlet hose, turn the tap on for 30 seconds, with the hoses in the sink so
that any impurities in the water line can be flushed out.
NOTE
•
Check for water leaks after refitting by adding a bucket of water into the tub. (The Rubber O ring
must remain in the cap)
To Clean the Pump casing (for pump model)
Cap
Guide rib
Filter
Filter
Remove the power
cord from the power
outlet and place a
towel on the floor
under the drain pump
cap. Excess water
will flow out.
Remove any foreign
objects and fluff inside
pump casing and from the
filter.
Refit the cap. Insert the filter along the
guide ribs inside the pump casing.
Filter must face the guide ribs inside
pump casing and securely turn the cap
clockwise.
1 2 3 4
Turn the cap
counter- clock-
wise and pull it
out while taking
note the config-
uration.
Cap
Guide rib
Filter
Filter
Cap
Guide rib
Filter
Filter
Cap
Guide rib
Filter
Filter
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 35
36
Cleaning and Maintenance
Inner Wash tub Leave the lid open after washing to allow moisture to evaporate. If you want to clean
the inner-tub use a clean soft cloth dampened with liquid Detergent, then rinse. (Do
not use harsh or gritty cleaners.)
Inlet Hoses
Hoses connecting washer to the tap should be replaced every 5 years.
Exterior Immediately wipe off any spills. Wipe with damp cloth. Try not to hit surface with
sharp objects.
Long Vacations Be sure that the water supply is shut off at the taps. Drain all water from hoses if
weather will be below freezing.
When there is a fear of freezing
If frozen
• Remove the water supply hose, and immerse it in HOT water at approx.. 40˚C.
• Pour approx.. 2 liters of HOT water at approx.. 40˚C, into the bowl and let it stand for 10 minutes.
• Connect the water supply hose to the water tap and confirm that the washing machine performs the
supply and drainage of water.
• Close the water taps and remove the Water Supply Hose.
• Remove the water which remains in the water supply.
• Lower the drain hose and drain the water in the bowl and the drain hose by spinning.
Cleaning the Inside of your Washer
If you use fabric softener or do regular COLD water washing, it is very important that you occasionally clean the
inside of your washer.
• Fill your washer with HOT water.
• Add about two cups of a powdered Detergent that contains phosphate.
• Let it operate for several minutes.
• Stop the washer, open the lid and leave it to soak overnight.
• After soaking, drain the washer and run it through a normal cycle.
Or use TUB CLEAN PROGRAM periodically.
Do not wash clothes during this procedure.
Products that might damage your washing machine
• Concentrated bleaches and nappy sanitizer will cause damage to the paintwork and components of your washer.
• Hydrocarbon solvents i.e. petrol, paint thinners and lacquer thinners, etc. can dissolve plastic and blister paint
(Be careful when washing garments stained with these solvents as they are flammable DO NOT put them in washer
or dryer.)
• Some pretreatment sprays or liquids can damage your washer’s control panel when applied next to the washer.
• Use of dyes in your washer may cause staining of the plastic components. The dye will not damage the machine but
we suggest you thoroughly clean your washer afterwards. We do not recommend the use of dye strippers in your
washer.
• Do not use your washer lid as a work surface.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 36
37
Soft Safety Door (where fitted)
•
Using tempered glass, the inside of the washer can be seen safely during a wash.
•
To prevent sudden close of door, it has a dampened hinge so the door closes softly.
•
Door is heavy. Be careful not to place hands in the door closing area when operating.
It might cause injury or damage to the product.
Smart Hinge
Smart Hinge
• For customer safety, the door will be locked automatically during operation When the door is locked, the '
door lock ' indicator will be on.
If more clothes need to be added, press the START/PAUSE to unlock.
• Press START/PAUSE Button again to resume operation. The machine will turn off automatically if it is
interrupted during the wash for any reason and is not resumed by pressing the START/PAUSE button again
within 4 minutes.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 37
38
Common washing problems
Many washing problems involve poor soil & stain removal, Lint and scum residue, and fabric damage.
For satisfactory washing results, follow these instructions.
WASH PROBLEM
Possible Causes
Problems
Solutions & Preventive Measures
• Use correct amount of Detergent for load size, amount of soil and
water Hardness.
• Different Water Temperature may be required according to soil type.
• Reduce load size and manually increase the water level.
• Wash with DUVET or SOAK & DUVET wash cycle for heavy soiled
items.
• Separate heavily soiled items from lightly soiled ones.
• Pretreat stains and heavy soil according to directions shown on page 9.
• Rub the stain with bar soap. Wash.
• Do not overfill fabric softener dispenser and do not pour liquid fabric
softener directly onto fabric.
See page 12 for more instructions.
• Keep the recommendations against Scrud(waxy buildup).
(refer to scrud page12.)
• Use correct amount of Detergent for load size, amount of soil and water
Hardness.
• To restore discolored load of whites, use rust remover safe for fabric.
• Install nonprecipitating water softener or an iron filter in your water
supply system for an ongoing problem.
• Before washing, run water for a few minutes to clear lines.
• Wash lint givers eg towels, flannelette sheets, separately from lint collec-
tors eg synthetic fabrics and remove tissues in pockets before wash.
See page 9 for sorting and caring before loading.
• Do not overload the washer . Manually increase the water level.
• Do not overload the washer.
• Some Detergents need to be pre-dissolved, check the Detergent instructions.
Try pre-dissolving the Detergent.
• Increase Water Temperature using HOT water safe for fabric.
• Use proper amount of Detergent.
• Never pour chlorine bleach directly on fabric.
See page 11 for adding liquid bleach.
• Fasten zippers, hooks, and buckles.
• Remove objects in pockets. See page 9 for caring before
loading.
• Do not overload the washer.
Poor soil
removal
• Not enough Detergent
• Wash Water Temperature
too cold.
• Overloading the washer
• Incorrect wash cycle
• Incorrect sorting
• Not pretreating stains
• Undiluted fabric softener
dispensed directly onto
fabric
• A buildup caused by the
interaction of fabric softener
and Detergent can flake off
and mark clothes
• Not enough Detergent
• Iron or manganese in
water supply, water pipes,
or water heater
• Incorrect sorting
• Tissues left in pocket
• Overloading the washer
• Overloading the washer
• Undissolved Detergent
• Using too much Detergent
• Incorrect use of chlorine
bleach.
• Unfastened zippers,
hooks, buckles
• Ribs, tears and broken
threads
• Overloading the washer
• Degradation of fabric
Blue Stains
Holes, tears,
or snags
Black or gray
marks on
clothes
Yellow or
brown rust
stains
Lint
Residue or
Detergent
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 38
39
Troubleshooting
B
ef
ore
c
al
l
i
ng
f
or
s
erv
i
c
e,
c
hec
k
t
he
probl
em
agai
ns
t
t
he
l
i
s
t
bel
l
ow.
Symptom Error Message
What to Check
• Is the water tap shut off?
• Is the water supply cut off ?
• Is the drain hose installed too low?
• Is the water pressure too high or too low, or is the filter of the
inlet valve clogged with impurities?
• Is the Hot hose connected to cold?
• Is the Cold hose connected to hot?
Water Supply
Failure
Drainage Failure
Spin Failure
Door(Lid) Open
Door(Lid) Lock
malfunction
Foreign objects
• Is the drain hose positioned correctly?
• Is the drain hose bent or placed too high?
• Is the internal part of the hose or drain pump
(only pump model) clogged with impurities?
• Check if electric power has gone off.
• Is the laundry evenly balanced?
• Is the washing machine placed on a flat and level surface?
Press the "Start/Pause" button to release the , now distribute
the laundry evenly and then press the "Start/Pause" button again to
resume the cycle.
• Is the lid closed?
Child Lock
• CL(Child Lock) does not indicate a malfunction.
• This function prevents accidental cycle changes or interruptions during
the wash cycle The Child Lock function will remain engaged even after
the cycle has tinished Press the Rinse button for 3 seconds to unlock.
Take care not to set up inadvertently during use.
• Is the lid closed?
• Make sure that the lid is closed properly and press the
START/PAUSE button.
The washer will not operate unless the lid is locked.
• Make sure that nothing is caught under the lid, including shipping
material or clothing.
• A
re there foreign objects, Such as coins, pins, etc., caught
between the wash pulsator and the inner tub ?
• T
urn off the washer and then press the Power button.
Pres
s the spin speed button without selecting a cycle to drain and
spin the load.
W
hen t
he spin is complete, remove the clothes and then find and
rem
ove any objects caught in the wash pulsator.
• Please call your nearest LG Electronics service center for help.
Tub Cle
a
n
R
e
minder
•
E
m
pt
y the tub, insert bleach into the detergent dispenser and select
the T
ub C
lean cycle.
•
If you want to skip the Tub Clean, press the program and option
buttons to select desired cycle. In this case, you will see the
m
essage again after a few more wash cycles. Once the Tub Clean
cycle is performed, will disappear until the next reminder to
clean the tub.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 39
Close the washer door, and press the
POWER
button to turn on the machine.
(Smart Diagnosis will not operate if the Washer has a power problem.)
Place the phone to the SmartDiagnosis
TM
display icon.
Hold the phone while data is transmitted.
Hold down the
Cold Wash button to activate smart diagnosis.
After the data transmission is completed, listen to the diagnosis result from the consultant.
1
3
4
5
2
•
Do not press any buttons other than the ones
indicated below.
•
Make sure that the
phones mic faces the
SmartDiagnosis
TM
display
•
Place the phone near the
SmartDiagnosis
TM
display, and hold down
the Cold Wash button
until tak tat tak sounds
are heard.
•
Keep the phone placed to the SmartDiagnosis
TM
display while data for smart diagnosis is being
transmitted. The time remaining for data
transmission will be displayed on the washer
display.
•
Transmission sound may be irritating. For proper
diagnosis, do not remove the phone.
•
When data transmission is completed, the
power is automatically turned off with “End”
displayed for a few seconds.
NOTE
Smart Diagnosis is a troubleshooting feature designed to assist, not replace, the traditional method of
troubleshooting through service calls. The effectiveness of this feature depends upon various factors,
including, but not limited to, the reception of the cellular phone being used for transmission, any
external noise that may be present during the transmission, and the acoustics of the room where the
machine is located. Accordingly, LG does not guarantee that Smart Diagnosis can accurately
troubleshoot any given issue.
40
SmartDiagnosis
TM
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 40
H
D
W
※ In our continuing effort to improve the quality of our appliances, it may be necessary to make
changes to the appliance without revising this manual.
WTG9532VH WTG9532WH WTG8532WH
230V~, 50 Hz
9.5 kg 8.5 kg
1650 W
50 kg
632(W) × 670(D) × 1020(H) mm
100 kPa ~ 600 kPa
IPX4
MADE IN KOREA
Model
Power supply
Wash capacity
Rated input
Weight
Size
Water tab pressure
P No. (Degree of Protection)
Country of origin
41
Specification
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 41
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 42
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 43
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 44
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 45
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 46
Memo
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 47
WTG9532VH
WTG9532WH
WTG8532WH
MFL69022796 www.lg.com
Please read this manual carefully before operating
your washing machine and retain it for future reference.
MFL69022796(영)호주향_150x210 16. 3. 25. 오전 9:40 페이지 48
