OWNER’S MANUAL
MONITOR SIGNAGE
72WS70MS
Please read this manual carefully before operating the your set and
retain it for future reference.
MONITOR SIGNAGE MODELS
ENG
ENGLISH
background
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
background
2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
4 LICENSES
5 ASSEMBLING AND
PREPARING
5 Accessories
6 Partsandbuttons
7 PortraitLayout
8 Mountingonawall
9 REMOTE CONTROL
11 USING THE MONITOR
11 ConnectingtoaPC
12 - RGBconnection
12 - DVI-Dconnection
13 - HDMIconnection
13 - DisplayPortconnection
14 Adjustingthescreen
14 - Selectinganimagemode
14 - Customizingimageoptions
15 - CustomizingPCdisplayoptions
15 Adjustingthesound
15 - Selectingansoundmode
16 - Customizingsoundoptions
16 Usingadditionaloptions
16 - Adjustingaspectratio
18 - Usingtheinputlist
19 ENTERTAINMENT
19 - Connectingtoawirednetwork
20 - NetworkStatus
21 - ConnectingUSBstoragedevices
22 - Browsingfiles
23 - Viewingmovies
27 - Viewingphotos
30 - Listeningtomusic
32 - ViewingtheContentsList
33 - DivX®VODGuide
34 - UsingPIP/PBP
36 CUSTOMIZING SETTINGS
36 Accessingmainmenus
37 - PICTUREsettings
40 - AUDIOsettings
41 - TIMEsettings
42 - OPTIONsettings
47 - NETWORKsettings
48 MAKING CONNECTIONS
49 ConnectingtoaHDreceiver,DVD,
Camcorder,Camera,GamingDeviceor
VCRplayer
49 - HDMIconnection
49 - Componentconnection
50 - AV(CVBS)connection
50 ConnectingtoaUSB
51 ConnectingtotheLAN
51 - LANconnection
52 DaisyChainMonitors
53 TROUBLESHOOTING
56 SPECIFICATIONS
background
3
ENG
ENGLISH
TABLE OF CONTENTS
60 IR CODES
61 CONTROLLING THE MULTIPLE
PRODUCT
61 Connectingthecable
61 RS-232CConfigurations
61 CommunicationParameter
62 Commandreferencelist
64 Transmission/Receivingprotocol
background
ENGLISH
4
LICENSES
LICENSES
Supportedlicensesmaydifferbymodel.Formoreinformationofthelicenses,visitwww.lg.com.
HDMI,theHDMIlogoandHigh-DefinitionMultimediaInterfacearetrademarks
orregisteredtrademarksofHDMILicensingLLC.
ABOUTDIVXVIDEO:DivX isadigitalvideoformatcreatedbyDivX,LLC,a
subsidiaryofRoviCorporation.ThisisanofficialDivXCertified devicethat
playsDivXvideo.Visitdivx.comformoreinformationandsoftwaretoolsto
convertyourfilesintoDivXvideos.
ABOUTDIVXVIDEO-ON-DEMAND:ThisDivX
Certified devicemustberegisteredinordertoplaypurchasedDivXVideo-
on-Demand(VOD)movies.Toobtainyourregistrationcode,locatethe
DivXVODsectioninyourdevicesetupmenu.Gotovod.divx.comformore
informationonhowtocompleteyourregistration.
DivXCertified toplayDivX videouptoHD1080p,includingpremium
content.
DivX ,DivXCertified andassociatedlogosaretrademarksofRovi
Corporationoritssubsidiariesandareusedunderlicense.
CoveredbyoneormoreofthefollowingU.S.patents:7,295,673;7,460,668;
7,515,710;7,519,274
ManufacturedunderlicensefromDolbyLaboratories.“Dolby”andthe
double-DsymbolaretrademarksofDolbyLaboratories.
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Accessories
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Donotuseanypirateditemstoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
Remote control and Batteries Power Cord
CD (Owner's Manual)
/ Card
D-sub 15 pin signal cable
CAUTION
NOTE
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
POWER
OK
S.MENU
ID
BACK
TILE
ON
OFF
EXIT
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
YoucansetthePowerindicatortoonoroffbyselectingOPTIONinthemainmenu.
Parts and buttons
Screen Marks Description
INPUT Changestheinputsource.
MENU Accessesthemainmenus,orsavesyourinputandexitsthemenus.
Adjusttheupanddown.
Adjuststhevolumelevel.
AUTO/SET Displaysthecurrentsignalandmode.
Pressthisbuttontoadjustthescreenautomatically(availableonlyinRGBmode)
/I
Turnsthepoweronoroff.
IRReceiver Thisiswheretheunitreceivessignalsfromtheremotecontrol.
PowerIndicator ThisIndicatorlightsupredwhenthedisplayoperatesnormally(onmode).Ifthedisplay
Insleepmode(InPowerSavingmode),thisindicatorcolorchangestoamber.
NOTE
Connection panel
IR Receiver /
Power Indicator
LightingOn:Turnedon
LightingOff:Turnedoff
Screen Buttons
Screen Marks
background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Portrait Layout
-Onlyonsomemodels.
WheninstallinginaPortraitLayout,rotatethe
monitorclockwise90degrees(whenfacingthe
screen).
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
Forproperventilation,allowaclearanceof10
cmoneachsideandfromthewall.Detailed
installationinstructionsareavailablefromyour
dealer,seetheoptionalTiltWallMountingBracket
InstallationandSetupGuide.
10cm
10cm
10cm
10cm
10cm
IfyouintendtomounttheMonitortoawall,attach
Wallmountinginterface(optionalparts)totheback
oftheset.
WhenyouinstalltheMonitorusingthewall
mountinginterface(optionalparts),attachit
carefullysoitwillnotfall.
1
 Please,Usethescrewandwallmountinterface
inaccordancewithVESAStandards.
2
Ifyouusescrewlongerthanstandard,the
monitormightbedamagedinternally.
3
 Ifyouuseimproperscrew,theproductmight
bedamagedanddropfrommountedposition.
Inthiscase,LGElectronicsisnotresponsible
forit.
4
VESAcompatible.
5
PleaseuseVESAstandardasbelow.
785mm(31inch)orgreater
*Fasteningscrew:Diameter6.0mmxPitch1.0
mmxLength10mm
Disconnectthepowerbeforeinstallingor
movingthemonitor.Otherwiseelectricshock
mayoccur.
IfyouinstalltheMonitoronaceilingor
slantedwall,itmayfallandresultinsevere
injury.UseanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
Donotovertightenthescrewsasthismay
causedamagetotheMonitorandvoidyour
warranty.
Usescrewsandwallmountsthatmeetthe
VESAstandard.Anydamagesorinjuriesby
misuseorusinganimproperaccessoryare
notcoveredbythewarranty.
UsescrewsthatarelistedontheVESA
standardscrewspecifications.
Thewallmountkitincludesaninstallation
manualandnecessaryparts.
Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
Formoreinformation,refertotheinstructions
suppliedwiththewallmount.
CAUTION
NOTE
background
9
ENG
ENGLISH
REMOTE CONTROL
REMOTE CONTROL
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
/I(POWER)
TurnstheMonitoronoroff.
MONITOR ON / OFF
Turnoffthemonitorandthen
turnitbackon.
1/a/A Button
Thisbuttonselectionisnot
applicable.
ENERGY SAVING
Adjuststhebrightnessof
thescreentoreduceenergy
consumption.
INPUT
Selectstheinputmode.
Number and Alphabet buttons
Entersnumbers.
Thealphabetselectionisnot
applicable.
CLEAR
Thisbuttonselectionisnot
applicable.
PSM
SelectsthePictureStatus
Mode.
MUTE
Mutesallsounds.
ARC
SelectstheAspectRatio
Mode.
Volume Up / Down
Adjuststhevolumelevel.
BRIGHTNESS Key
Adjustthebrightnessby
pressingtheUpandDown
buttonsontheremotecontrol.
InUSBmode,theOSDmenu
hasthePagefunctiontomove
tothenextfilelist.
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
1
. , !
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
1/a/A
0
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
P
A
G
E
INPUT
ENERGY
S
AVIN
G
MARK
AR
C
1
!
2
ABC
3
D
E
F
4
G
HI
5
J
K
L
6
M
N
O
7
PQ
R
S
7
7
8
T
U
V
9
1/a/A
0
-
*
#
WXYZ
C
LEA
R
ON
OF
F
MONITOR
MONITOR
PSM
MU
T
E
BRI
G
H
T
N
ESS
PO
WE
R
Thedescriptionsinthismanualarebasedonthebuttonsoftheremotecontrol.Pleasereadthismanual
carefullyandusetheMonitorcorrectly.
Toreplacebatteries,openthebatterycover,replacebatteries(1.5VAAA)matching and endstothe
labelinsidethecompartment,andclosethebatterycover.
Toremovethebatteries,performtheinstallationactionsinreverse.
Donotmixoldandnewbatteries,asthis
maydamagetheremotecontrol.
Makesuretopointtheremotecontrolatthe
remotecontrolsensorontheMonitor.
CAUTION
background
10
ENG
ENGLISH
REMOTE CONTROL
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
S.MENU
(SuperSignMenuKey)
Thisbuttonselectionisnot
applicable.
EXIT
Clearsallon-screendisplays
andreturnstoMonitor
viewingfromanymenu.
TILE
SelectstheTILEMode.
MENU (Seep.36)
Accessesthemainmenus
orsavesyourinputandexit
menus.
Navigation buttons
Scrollsthroughmenusor
options.
OK
Selectsmenusoroptionsand
confirmsyourinput.
BACK
Allowstheusertomoveback
onestep.
USB Menu control buttons
Controlsmediaplayback.
ID ON/OFF
Whenmorethanonemonitor
ispresentinthesameroom,
thisallowsyoutocontrolthem
individually.
AUTO
Automaticallyadjustspicture
positionandminimizesimage
instability.(RGBinputonly)
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
1
. , !
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
1/a/A
0
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
OK
S
.MEN
U
A
U
T
O
MEN
U
ID
BA
C
K
T
IL
E
ON
O
FF
E
XIT
background
11
ENG
ENGLISH
USING THE MONITOR SET
USING THE MONITOR
Connecting to a PC
YourMonitorsupportsthePlug&Play*feature.
*Plug&Play:ThisisthefunctionthatallowsaPC
tousethemonitorwithoutinstallingadriver.
NOTE
Connect the signal
input cable and tighten
itby turning the screws
clockwise.
D o n o t p r es s t h e
screen with your finger for a long time as
thismayresultintemporarydistortiononthe
screen.
Avoiddisplayingafixedimageonthescreen
for a long period of time to prevent image
burn.Useascreensaverifpossible.
ItisrecommendedtousetheMonitorwith
theHDMIconnectionforthebestimage
quality.
Useashieldedsignalinterfacecable,such
asD-sub15pinsignalcableandDVIcable,
withaferritecoretomaintainstandard
compliancefortheproduct.
IfyouturntheMonitoronwhentheset
becomescold,thescreenmayflicker.This
isnormal.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
CAUTION
background
12
ENG
ENGLISH
USING THE MONITOR SET
DVI-D connection
TransmitsthedigitalvideosignalfromyourPCto
theMonitor.ConnectthePCandtheMonitor
setwiththeDVIcableasshownthefollowing
illustrations.
SelectDVI-Dinputsourceonthemonitor.
RGB connection
TransmitstheanalogvideosignalfromyourPCto
theMonitor.ConnectthePCandtheMonitor
setwiththe15pinsignalcableasshownthe
followingillustrations.
SelectRGBinputsourceonthemonitor.
Use the standard Macintosh
adaptersince an incompatible
adapter is av ailable in the
market. (Different signaling
system)
Applecomputersmayrequireanadapterto
connecttothismonitor.Callorvisittheirweb
siteformoreinformation.
NOTE
RGB OUT (PC) AUDIO OUT
AUDIO OUT
DVI OUT
MacintoshAdapter
(notincluded)
(notincluded)
(notincluded)
(notincluded)
background
13
ENG
ENGLISH
USING THE MONITOR SET
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCtotheMonitor.ConnectthePCandthe
MonitorwiththeHDMIcableasshowninthe
followingillustrations.
SelectHDMIinputsource.
Display Port connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCtotheMonitor.ConnectthePCandthe
MonitorwiththeDisplayPortcableasshownin
thefollowingillustrations.
SelectDisplayPortinputsource.
UseaHighSpeedHDMI™Cable.
PleasecheckthePCenvironmentifyou
cannothearthesoundinHDMImode.Some
PCsrequireyoutomanuallychangethe
defaultaudiooutputtoHDMI.
IfyouwanttouseHDMIPCmode,youmust
setPC/DTVtoPCmode.
WhenHDMIPCisused,acompatiblity
problemmightoccur.
NOTE
HDMI
DP OUT
(notincluded)
(notincluded)
background
14
ENG
ENGLISH
USING THE MONITOR SET
Adjusting the screen
Selecting an image mode
Displayimagesinitsoptimizedsettingsby
selectingoneofthepresetimagemodes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
Customizing image options
Customizebasicandadvancedoptionsofeach
imagemodeforthebestscreenperformance.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
5
Selectandadjustthefollowingoptions,and
thenpressOK.
Mode Description
Vivid Adjuststhevideoimagefortheretail
environmentbyenhancingthecontrast,
brightness,color,andsharpness.
Standard Adjuststheimageforanormal
environment.
Cinema Optimizesthevideoimageforacinematic
looktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighand
dynamicactionsbyemphasizingprimary
colorssuchaswhite,grass,orskyblue.
Game Optimizesthevideoimageforafast
gamingscreensuchasPCsorgames.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Option Description
Backlight Adjuststhebrightnessofthescreen
bycontrollingtheLCDbacklight.If
youdecreasethebrightnesslevel,
thescreenbecomesdarkerandthe
powerconsumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthegradient
ofthevideosignal.Youmayuse
Contrastwhenthebrightpartsofthe
picturearesaturated.
Brightness Adjuststhebaselevelofthesignalin
thepicture.YoumayuseBrightness
whenthedarkareasofthepictureare
saturated.
Sharpness Adjuststhelevelofcrispnessinthe
edgesbetweenthelightanddark
areasofthepicture.Thelowerthe
level,thesoftertheimage.
Color Adjustsintensityofallcolors.
Tint Adjuststhebalancebetweenredand
greenlevels.
Color Temp. SettowarmtoenhancehotterColors
suchasred,orsettocooltomake
picturebluish.
Advanced
Control
Customizestheadvancedoptions.
RefertotheAdvancedimageoptions.
(Seep.39)
Picture Reset Restorestheoptionstothedefault
setting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
15
ENG
ENGLISH
USING THE MONITOR SET
Customizing PC display options
Customizeoptionsofeachimagemodeforthe
bestimagequality.
Thisfunctionworksinthefollowingmode:
RGB[PC]mode.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
ScreenandpressOK.
4
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Resolution Selectsaproperresolution.See
“CustomizingPCdisplayoptions”.
Auto
Config.
Adjuststhescreenposition,clock,and
phaseautomatically.
Thedisplayedimagemaybeunstablefor
afewsecondswhiletheconfigurationis
inprogress.
Position/
Size/Phase
Adjuststheoptionswhenthepictureis
notclear,especiallywhencharactersare
shaky.RunAutoConfig.beforeadjusting
these.
Reset Restorestheoptionstothedefault
setting.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Adjusting the sound
Selecting an sound mode
ThisMonitorhas5presetsoundmodesto
complimentdifferenttypesofvideocontent.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
Mode Description
Standard Selectwhenyouwantstandard-quality
sound.
Music Selectwhenyoulistentomusic.
Cinema Selectwhenyouwatchmovies.
Sport Selectwhenyouwatchsportevents.
Game Selectswhenyouplaygames.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
16
ENG
ENGLISH
USING THE MONITOR SET
Customizing sound options
Youmaycustomizeoptionsofeachsoundmode
forthebestsoundquality.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
5
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Infinite
Sound
LG'sInfinitySoundoptionprovides5.1
channelstereoqualitysoundfromtwo
speakers.
Treble Controlsthedominantsoundsinthe
output.Whenyouturnupthetreble,it
willincreasetheoutputofthehigher
frequencyrange.
Bass Controlsthesoftersoundsinthe
output.Whenyouturnupthebass,it
willincreasetheoutputofthelower
frequencyrange.
Reset Resetsthesoundmodetothedefault
setting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Using additional options
Adjusting aspect ratio
Resizetheimagetoviewtheimageatitsoptimal
sizebypressingARC whileyouarewatching
content.
Ifafixedimagedisplaysonthescreenfora
longperiodoftime,itwillbeimprintedand
becomeapermanentdisfigurementonthe
screen.Thisis“imageburn”or“burn-in”and
notcoveredbythewarranty.
Iftheaspectratioissetto4:3foralong
periodoftime,imageburnmayoccuronthe
letterboxedareaofthescreen.
Youcanalsochangetheimagesizeby
accessingthemainmenus.
CAUTION
NOTE
MODE
ARC
AV Component RGB Display
Port
DVI-D HDMI
PC DTV PC DTV PC DTV PC
16:9
o o o o o o o o o
Just Scan
x o x o x o x o x
1:1
x x o x o x o x o
4:3
o o o o o o o o o
Zoom
o o x o x o x o x
Cinema
Zoom 1
o o x o x o x o x
background
17
ENG
ENGLISH
USING THE MONITOR SET
-4:3 :Thisselectionwillallowyoutoviewa
picturewithanoriginal4:3aspectratio,black
barswillappearonboththeleftandrightofthe
screen.
-Zoom :Thisselectionwillallowyoutoviewthe
picturewithoutanyalteration,whilefillingthe
entirescreen.However,thetopandbottomof
thepicturewillbecropped.
-Cinema Zoom 1 :ChooseCinemaZoom
whenyouwanttoenlargethepictureincorrect
proportion.Note:Whenenlargingorreducing
thepicture,theimagemaybecomedistorted.
-16:9 :Thisselectionwillallowyoutoadjustthe
picturehorizontally,inlinearproportion,tofillthe
entirescreen(usefulforviewing4:3formatted
DVDs).
-Just Scan :ThisSelectionwillallowyouview
thepictureofbestqualitywithoutlossoforiginal
pictureinhighresolutionimage.Note:Ifthereis
noiseinoriginalPicture,Youcanseethenoise
attheedge.
-1:1 :Theaspectratioisnotadjustedfromthe
original.(OnlyDisplayPortPC,HDMIPC,
DVI-DPC,RGBPC)
Just Scan
background
18
ENG
ENGLISH
USING THE MONITOR SET
Using the input list
Selecting an input source
1
PressINPUTtoaccesstheinputsourcelist.
-Theconnecteddevicedisplaysoneachinput
source.
2
PresstheNavigationbuttonstoscrolltooneof
theinputsourcesandpressOK.
Input source Description
AV(CVBS) WatchvideofromaVCRorother
externaldevices.
Component WatchcontentfromaDVDorother
externaldevices,orthrougha
digitalset-topbox
RGB ViewaPCdisplayonthescreen
Display Port WatchcontentfromaPC,DVD
ofDigitalset-topboxotherhigh
definitiondevices
DVI-D ViewaPCdisplayonthescreen
HDMI WatchcontentfromaPC,DVD
ofDigitalset-topboxotherhigh
definitiondevices
background
19
ENG
ENGLISH
ENTERTAINMENT
ENTERTAINMENT
Connecting to a wired network
(Dependingonmodel)
Connectthedisplaytoalocalareanetwork(LAN)
viatheLANportasshownonthefollowingillustra-
tionandsetupthenetworksettings.
Thismonitoronlysupportsawirednetworkcon-
nection.
Aftermakingaphysicalconnection,asmall
numberofhomenetworksmayrequirethedisplay
networksettingstobeadjusted.Formosthome
networks,thedisplaywillconnecttoautomatically
withoutanyadjustments.
Fordetailinformation,contactyourinternetpro-
viderorroutermanual.
Donotconnectamodularphonecabletothe
LANport.
Sincetherearevariousconnectionmeth-
ods,pleasefollowthespecificationsofyour
telecommunicationcarrierorinternetservice
provider.
Networksettingmenuwillnotbeavailable
untilthedisplayisconnectedtophysical
network.
Sincetherearevariousconnectionmeth-
ods,pleasefollowthespecificationsofyour
telecommunicationcarrierorinternetservice
provider.
Tosetupthenetworkseetings:(Evenifyourdis-
playhasalreadyconnectedautomatically,running
setupagainwillnotharmanything),
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrolltoNET-
WORKandpressOK.
3 PresstheNavigationbuttonstoselectNet-
work SettingandpressOK.
4 IfyoualreadysetNetworkSetting,select
Resetting.Thenewconnectionsettingsresets
thecurrentnetworksettings.
5 SelectIP Auto SettingorIP Manual Setting.
-IfselectingIP Manual Setting,pressthe
NavigationandNumberbuttons.IPaddress-
eswillneedtobeinputmanually.
-IP Auto Setting:Selectthisifthereisa
DHCPserver(Router)onthelocalareanet-
work(LAN)viawiredconnection,thedisplay
willautomaticallybeallocatedanIPaddress.
Ifyou’reusingabroadbandrouterorbroad-
bandmodemthathasaDHCP(Dynamic
HostConfigurationProtocol)serverfunction.
TheIPaddresswillautomaticallybedeter-
mined.
6 Whenyouarefinished,pressEXIT.
LAN
Router
LAN WAN
Cable modem
ETHERNET
@
Internet
Internet
CAUTION
CAUTION
background
20
ENG
ENGLISH
ENTERTAINMENT
IfyouwanttoaccesstheInternetdirectlyon
yourdisplay,theinternetconnectionshould
alwaysbeon.
IfyoucannotaccesstheInternet,check
thenetworkconditionsfromaPConyour
network.
WhenyouuseNetwork Setting,checkthe
LANcableorcheckifDHCPintherouteris
turnedon.
Ifyoudonotcompletethenetworksettings,
thenetworkmaynotworkproperly.
Tips for Network setting
UseastandardLANcablewiththisdisplay.Cat5
orbetterwithaRJ45connector.
Manynetworkconnectionproblemsduringset
upcanoftenbefixedbyre-settingtherouter
ormodem.Afterconnectingthedisplaytothe
homenetwork,quicklypoweroffand/ordiscon-
nectthepowercableofthehomenetworkrouter
orcablemodem.Thenpoweronand/orconnect
thepowercableagain.
Dependingontheinternetserviceprovider
(ISP),thenumberofdevicesthatcanreceive
internetservicemaybelimitedbytheapplicable
termsofservice.Fordetails,contactyourISP.
LGisnotresponsibleforanymalfunctionofthe
displayand/ortheinternetconnectionfeature
duetocommunicationerrors/malfunctionsas-
sociatedwithyourinternetconnection,orother
connectedequipment.
LGisnotresponsibleforproblemswithinyour
internetconnection.
Youmayexperienceundesiredresultsifthe
networkconnectionspeeddoesnotmeetthe
requirementsofthecontentbeingaccessed.
Someinternetconnectionoperationsmaynot
bepossibleduetocertainrestrictionssetbythe
Internetserviceprovider(ISP)supplyingyour
Internetconnection.
AnyfeeschargedbyanISPincluding,without
limitation,connectionchargesareyourrespon-
sibility.
A10Base-Tor100Base-TXLANportis
requiredwhenusingawiredconnectiontothis
display.Ifyourinternetservicedoesnotallowfor
suchaconnection,youwillnotbeabletocon-
nectthedisplay.
ADSLmodemisrequiredtouseDSLservice
andacablemodemisrequiredtousecable
modemservice.Dependingontheaccess
methodofandsubscriberagreementwithyour
ISP,youmaynotbeabletousetheinternet
connectionfeaturecontainedinthisdisplayor
youmaybelimitedtothenumberofdevicesyou
canconnectatthesametime.(IfyourISPlimits
sub-scriptiontoonedevice,thisdisplaymay
notbeallowedtoconnectwhenaPCisalready
connected.)
Theuseofa“Router”maynotbeallowedorits
usagemaybelimiteddependingonthepolicies
andrestrictionsofyourISP.Fordetails,contact
yourISPdirectly.
Network Status
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrolltoNET-
WORKandpressOK.
3 PresstheNavigationbuttonstoselectNet-
work Status.
4 PressOKtocheckthenetworkstatus.
5 Whenyouarefinished,pressEXIT.
Option Description
Setting Returntothenetworksettingmenu.
Test
Testthecurrentnetworkstatusafterset-
tingthenetwork.
Close Returntothepreviousmenu.
NOTE
background
21
ENG
ENGLISH
ENTERTAINMENT
Tips for using USB storage devices
OnlyaUSBstoragedeviceisrecognizable.
IftheUSBstoragedeviceisconnected
throughaUSBhub,thedeviceisnotrecog-
nizable.
AUSBstoragedeviceusinganautomatic
recognitionprogrammemaynotberecog-
nized.
AUSBstoragedevicewhichusesitsown
drivermaynotberecognized.
TherecognitionspeedofaUSBstorage
devicemaydependoneachdevice.
Pleasedonotturnoffthedisplayorunplug
theUSBdevicewhentheconnectedUSB
storagedeviceisworking.Whensuchdevice
issuddenlyseparatedorunplugged,the
storedfilesortheUSBstoragedevicemay
bedamaged.
PleasedonotconnecttheUSBstorage
devicewhichwasartificiallymaneuveredon
thePC.Thedevicemaycausetheproductto
malfunctionorfailtobeplayed.Neverforget
touseonlyaUSBstoragedevicewhichhas
normalmusicfiles,imagefilesormoviefiles.
PleaseuseonlyaUSBstoragedevicewhich
wasformattedasaFAT32filesystemor
NTFSfilesystemprovidedwiththeWin-
dowsoperatingsystem.Incaseofastorage
deviceformattedasadifferentutilityprogram
whichisnotsupportedbyWindows,itmay
notberecognized.
PleaseconnectpowertoaUSBstorage
device(over0.5A)whichrequiresanexternal
powersupply.Ifnot,thedevicemaynotbe
recognized.
PleaseconnectaUSBstoragedevicewith
thecableofferedbythedevicemaker.
SomeUSBstoragedevicesmaynotbesup-
portedoroperatedsmoothly.
FilealignmentmethodofUSBstorage
deviceissimilartoWindowXPandfilename
canrecognizeupto100Englishcharacters.
Besuretobackupimportantfilessincedata
storedinaUSBmemorydevicemaybe
damaged.Wewillnotberesponsibleforany
dataloss.
Connecting USB storage devices
YoucanconnectUSBstoragedevicessuchas
aUSBflashmemory,externalharddrivetothe
displayandusemultimediafeatures.
ConnectaUSBflashmemoryorUSBmemory
cardreadertotheDisplayasshownonthefollow-
ingillustration.TheMymediascreenappears.
DonotturnthedisplayofforremoveaUSB
storagedevicewhiletheEMF(mymedia)
Menuisactivated,asthiscouldresultin
lossoffilesordamagetotheUSBstorage
device.
BackupyourfilessavedonaUSBstorage
devicefrequently,asyoumayloseordam-
agethefilesandthismaybenotcoveredby
thewarranty.
CAUTION
or
background
22
ENG
ENGLISH
ENTERTAINMENT
IftheUSBHDDdoesnothaveanexternal
powersource,theUSBdevicemaynotbe
detected.Sobesuretoconnecttheexternal
powersource.
-Pleaseuseapoweradaptorforanexternal
powersource.WedonotguaranteeanUSB
cableforanexternalpowersource.
IfyourUSBmemorydevicehasmultiple
partitions,orifyouuseaUSBmulti-card
reader,youcanuseupto4partitionsorUSB
memorydevices.
IfaUSBmemorydeviceisconnectedtoa
USBmulti-cardreader,itsvolumedatamay
notbedetected.
IftheUSBmemorydevicedoesnotwork
properly,disconnectandreconnectit.
HowfastaUSBmemorydeviceisdetected
differsfromdevicetodevice.
IftheUSBisconnectedinStandbyMode,
specificharddiskwillautomaticallybe
loadedwhenthedisplayisturnedon.
Therecommendedcapacityis1TBorless
foraUSBexternalharddiskand32GBor
lessforUSBmemory.
Anydevicewithmorethantherecommended
capacitymaynotworkproperly.
IfaUSBexternalharddiskwitha“Energy
Saving”functiondoesnotwork,turnthe
harddiskoffandonagaintomakeitwork
properly.
USBstoragedevicesbelowUSB2.0are
supportedaswell.Buttheymaynotwork
properlyinthemovielist.
Maximumof999foldersorfilescanberec-
ognizedunderonefolder.
ItisrecommendedtouseacertifiedUSB
storagedeviceandcable.Otherwise,aUSB
storagedevicemaynotbedetectedora
playbackerrormayoccur.
OnlyaUSBmemorystickcanbeusedto
playbackthefilesdistributedandstored
bySuperSignManager.AUSBharddiskor
multi-cardreaderwillnotwork.
OnlyanFAT32fileformattedstoragedevice
canplaybackthefilesdistributedandstored
bySuperSignmanager.
AUSB3.0storagedevicemaynotwork.
Browsing files
Accessthephoto,music,ormovielistsandbrowse
files.
1
ConnectaUSBstoragedevice.
2
PressMENUtoaccessthemainmenus.
3
PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
4
PresstheNavigationbuttonstochoose
fromMovie List, Photo List,Music Listor
Contents ListandpressOK.
No. Description
1
Movestoupperlevelfolder
2
Currentpage/Totalpages
3
Correspondingbuttonsonthe
remotecontrol
4
Currentpage/totalpagesof
contentsunderthefolder
focusedon
1
5
Contentsunderthefolder
focusedon
1
Buttom Description
Green
button
Repeatedly,presstheGREENbuttonto
convertedtoMovie List->Photo List,
Photo List->Music List,Music List-
>Contents ListorContents List->Movie
List.
Yellow
button
A method to view in 5 large thumbnail
or simple list.
Blue
button
ConverttoMarkMode.
Page1/1
PhotoList
Drive1
Page1/1
USBExternal
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
ToMusicList
ChangeNumbers
MarkMode
Exit
11
2
3
4
5
View
Move
PageChange
Mark
MovieList
MusicList
PhotoList
ContentsList
background
23
ENG
ENGLISH
ENTERTAINMENT
Supported File Formats
Viewing movies
Playvideofilesondisplay.Yourdisplayshowsall
ofthevideofilessavedinaUSBstoragedeviceor
sharedfolderonaPC.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoMovie
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Type Supported file format
Movie DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T
RP,TP,ASF,WMV,FLV)
Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*.vob/*.
mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*.wmv/*.flv/*.
avi(motion-jpeg)/*.
mp4(motion-jpeg)/*.mkv(motion-jpeg))supporting
file
Video format:DivX3.11,DivX4.12,DivX5.x,
DivX6,Xvid1.00,Xvid1.01,Xvid1.02,Xvid1.03,
Xvid1.10beta-1/beta-2,
Mpeg-1,Mpeg-2,Mpeg-4,H.264/AVC,VC1,
JPEG,SorensonH.263
Audio format:DolbyDigital,AAC,Mpeg,MP3,
LPCM,HE-AAC,ADPCM,WMA
Bit rate:within32kbpsto320kbps(MP3)
External Subtitle format:*.smi/*.srt/*.sub
(MicroDVD,Subviewer1.0/2.0)/*.ass/*.ssa/*.
txt(TMPlayer)/*.psb(PowerDivX)
Internal Subtitle format :only,XSUB(Itisthe
subtitleformatusedinDivX6files)
Photo JPEG
Baseline:64x64to15360x8640
Progressive:64x64to1920x1440
YoucanplayJPEGfilesonly.
Non-supportedfilesaredisplayedintheform
ofpredefinedicon.
Music MP3
Bitrate32to320
SamplingrateMPEG1Layer3:32kHz,44.1
kHz,48kHz
SamplingrateMPEG2Layer3:16kHz,22.05
kHz,24kHz
SamplingrateMPEG2.5Layer3:8kHz,
11.025kHz,12kHz
Content
(when
using
SuperSign
Manager)
FileExtensions:*.cts/*.cse
Movie
File Extensions:*.mpg/*.mpeg/*.dat/*.ts/*.
trp/*.tp/*.vob/*.mp4/*.mov/*.mkv/*.avi/*.asf/*.
wmv/*.avi(motionJPEG)/*.mp4(motionJPEG)/*.
mkv(motionJPEG)
Video format:MPEG1,MPEG2,MPEG4,H.264/
AVC,DivX3.11,DivX4.12,DivX5.x,DivX6,
Xvid1.00,Xvid1.01,Xvid1.02,Xvid1.03,Xwvid
1.10-beta1/2,JPEG,VC1(WVC1/WMV3)
Audio format:MP2,MP3,DolbyDigital,LPCM,
AAC,HE-AAC,LPCM,ADPCM,WMA,MP3
File
Extensions
Item Profile
Photo JPEG
JPG
PNG
BMP
supported
fileformat
SOF0:
baseline
SOF1:
Extend
Sequential
SOF2:
Progressive
Photosize
Min:64x64
MaxType:
1366x768
Music MP3 Bitrate 32kbpsto320
kbps
Sampling
rate
32kHz,44.1
kHz,48kHz
(MPEG1L3)
16kHz,22.05
kHz,24kHz
(MPEG2L3)
8kHz,11.025
kHz,12kHz
(MPEG2.5L3)
background
24
ENG
ENGLISH
ENTERTAINMENT
Menu Description
Play Marked Playtheselectedmoviefile.
Onceamoviefilefinishesplaying,
thenextselectedonewillbeplayed
automatically.
Mark All Markallmoviefilesonthescreen.
Unmark All Deselectallmarkedmoviefiles.
Exit Mark Mode ExittheMarkMode.
5 Playamovie.
Non-supportedfilesaredisplayedthepreview
imagebyicononly .
Abnormal files are displayed in the form of
bitmap .
6 Controlplaybackbyusingthefollowingbuttons.
Button Description
Stopstheplayback
Playsavideo
Pausesorresumestheplayback
Scansbackwardinafile
Scansforwardinafile
ShowtheOptionmenu.
Hidethemenuonthefull-sizedscreen.
ReturntoMovie List.
or
Skipstospecificpointsinafiledur-
ingplayback.Thetimeofaspecific
pointwillappearonthestatusbar.In
somefiles,thisfunctionmaynotwork
properly.
ENERGY
SAVING
Pressthe
ENERGY SAVINGbutton
repeatedlytoincreasethebrightness
ofyourscreen.
01:02:30/02:30:25
Option
Hide
Exit
NOTE
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
ToPhotolist
ChangeNumbers
MarkMode
Exit
003
001 002
004
005 006
Play
Move
PageChange
Mark
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
PlayMarked
MarkAll
UnmarkAll
Exit
003
001 002
004
005 006
MarkMode
ExitMarkMode
051.Apple_......
02:30:25
Mark
Move
PageChange
Mark
background
25
ENG
ENGLISH
ENTERTAINMENT
Video options
1 PressMENUtoaccessthePop-Upmenus.
2 PresstheNavigationbuttonstoscrolltoSet
Video Play., Set Video. or Set Audio. and
pressOK.
OptionvalueschangedinMovie Listdoes
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic ListarechangedlikewiseinPhoto List
andMusic ListexcludingMovie List.
Whenreplayingthevideofileafterstopping,
youcanplayfromwhereitstoppedprevi-
ously.
Tips for using playing video files
Someuser-createdsubtitlesmaynotwork
properly.
Somespecialcharactersarenotsupported
insubtitles.
HTMLtagsarenotsupportedinsubtitles.
Subtitlesinlanguagesotherthanthesup-
portedlanguagesarenotavailable.
Thescreenmaysuffertemporaryinterrup-
tions(imagestoppage,fasterplayback,etc.)
whentheaudiolanguageischanged.
Adamagedmoviefilemaynotbeplayed
correctly,orsomeplayerfunctionsmaynot
beusable.
Moviefilesproducedwithsomeencoders
maynotbeplayedcorrectly.
Ifthevideoandaudiostructureofrecorded
fileisnotinterleaved,eithervideooraudiois
outputted.
HDvideoswithamaximumof
1920x1080@25/30Por1280x720@50/60P
aresupported,dependingontheframe.
Videoswithresolutionshigherthan
1920X1080@25/30Por1280x720@50/60P
maynotworkproperlydependingonthe
frame.
Moviefilesotherthanthespecifiedtypesand
formatsmaynotworkproperly.
Maxbitrateofplayablemoviefileis20Mbps.
(only,MotionJPEG:10Mbps)
Wedonotguaranteesmoothplaybackof
profilesencodedlevel4.1orhigherinH.264/
AVC.
DTSAudiocodecisnotsupported.
Amoviefilemorethan30GBinfilesizeis
notsupportedforplayback.
ADivXmoviefileanditssubtitlefilemustbe
locatedinthesamefolder.
Avideofilenameanditssubtitlefilename
mustbeidenticalforittobedisplayed.
PlayingavideoviaaUSBconnectionthat
doesn’tsupporthighspeedmaynotwork
properly.
FilesencodedwithGMC(GlobalMotion
Compensation)maynotbeplayed.
WhenyouarewatchingthemoviebyMovie
Listfunction,youcanadjustanimageby
EnergySavingkeyontheremotecontrol.
Usersetupforeachimagemodedoesnot
operate.
NOTE
background
26
ENG
ENGLISH
ENTERTAINMENT
Code Page Support Language
Latin1 English,Spanish,French,
German,Italian,Swedish,Finnish,
Dutch,Portuguese,Danish,Roma-
nian,Norwegian,Albanian,Gaelic,
Welsh,Irish,Catalan,Valencian
Latin2 Bosnian,Polish,Croatian,Czech,
Slovak,Slovenian,Serbian,
Hungarian
Latin4 Estonian,Latvian,Lithuanian
Cyrillic Bulgarian,Macedonian,Russian,
Ukrainian,Kazakh
Greek Greek
Korean Korean
Only10,000ofsyncblockscanbesupport-
edwithinthesubtitlefile.
Whenplayingavideo,youcanadjustthe
PictureSizebypressingtheRATIObutton.
Subtitlesinyourlanguageareonlysup-
portedwhentheOSDmenuisalsointhis
language.
Thecodepageoptionsmaybedisabledde-
pendingonthelanguageofthesubtitlefiles.
Selecttheappropriatecodepageforthe
subtitlefiles.
WhenyouselecttheSet Video Play,,
1 PresstheNavigationbuttonstoscrolltoshow
thePicture Size, Audio Language, Subtitle
LanguageorRepeat.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
Menu Description
Picture Size Selectsyourdesiredpicture
formatduringmovieplay.
Audio
Language
ChangestheLanguageGroupofthe
audioduringmovieplay.Files
withasingleaudiotrackcannotbe
selected.
Subtitle Lan-
guage
Turnon/offthesubtitle.
Language ActivatedforSMIsubtitleand
canselectthelanguagewithinthe
subtitle.
Code Page Canselectthefontforsubtitle.
Whensettodefault,samefontas
generalmenuwillbeused.
Sync Adjuststhetimesynchronisationof
thesubtitlefrom-10secsto+10secs
bystepsof0.5secsduringmovie
play.
Position Changesthepositionofthe
subtitleeitherupordownduring
movieplay.
Size SelectsyourdesiredSubtitlesize
duringmovieplay.
Repeat Turnon/offrepeatfunctionof
movieplayback.Whenturnedon,the
filewithinthefolderwillbeplayed
backrepeatedly.Evenwhenthe
repeatedplayback
isturnedoff,itcanruntheplaybackif
thefilenameissimilartotheprevious
file.
NOTE
background
27
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Video,,
1 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,,
1 PresstheNavigationbuttonstoscrolltoshow
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
Viewing photos
ViewimagefilessavedinaUSBstoragedevice.
Thedisplaysonthescreenmaydifferfromthe
model.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoPhoto
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
5 Viewphotos.
Non-supportedfilesaredisplayedthepre-
viewimagebyicononly .
Abnormalfilesaredisplayedintheformof
bitmap .
Menu Description
View Marked Displaytheselectedphotofile.
Mark All Markallphotofilesonthescreen.
Unmark All Deselectallmarkedphotofiles.
Exit Mark Mode ExittheMarkMode.
NOTE
Page1/1
PhotoList
Drive1
Page1/1
USB1USBDrive
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
ToMusicList
ChangeNumbers
MarkMode
Exit
View
Move
PageChange
Mark
Page1/1
PhotoList
Drive1
Page1/1
USB1USBDrive
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
MarkMode
ViewMarked
MarkAll
UnmarkAll
Exit
ExitMarkMode
Mark
Move
PageChange
Mark
background
28
ENG
ENGLISH
ENTERTAINMENT
Photo options
1 PressMENUtoshowtheOptionmenus.
2 Press the Navigation buttons to scroll to Set
Photo View., Set Video. or Set Audio. and
pressOK.
Option values changed in Movie List does
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic Listarechanged likewise inPhoto List
andMusic ListexcludingMovie List.
Option Description
Slideshow Startsorstopsaslideshowwithselected
photos.
Iftherearenoselectedphotos,allpho-
tossavedinthecurrentfolderdisplay
duringaslideshow.
SelectOptiontosetthespeedandview
modeoftheslideshow.
BGM Turnsthebackgroundmusiconoroff.
Tosetthebackgroundmusicfolder,
selectOption.
YoucanadjustOptionbyMENUbutton
ontheremotecontrol.
Rotate
Rotatesphotosclockwise(90°,180°,
270°,360°).
Zoom
Enlargestheimageto200%or400%.
NumberofselectedphotosOptions
ENER-
GY SAVING
PresstheENERGY SAVINGbutton
repeatedlytochangethebrightnessof
yourscreen.
Option
Slide Speed: Selects a slideshow
speed(Fast,Medium,Slow).
TransitionEffect: Settheviewmode
oftheslideshow.
BGM:Selectsamusicfolderforthe
backgroundmusic.
Hide
Hidestheoptionwindow.
Todisplaytheoptions,pressOK.
EXIT
ReturntoPhoto List.
Using photo options
Usethefollowingoptionswhileviewingphotos.
2/13
Slideshow BGM
Hide
Option
Exit
The supported photo size is
limited. You cannot rotate a
photo if the resolution of the
rotatedwidthislargerthanthe
supportedresolutionsize.
NOTE
Youcannotchangethemusic
folder while the background
musicisplaying.
You can only select the MP3
foldersavedonthedevicethat
currentlydisplaysthephoto.
NOTE
NOTE
NOTE
Zoom to 200% or 400% only
work for image of 1372×772
pixelsizeorlarger.
For image of 960×540 pixel
size or larger, only zoom to
400%worksproperly.
background
29
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Photo View,
1 PresstheNavigationbuttonstoscrolltoselectSlide Speed,Transition Effect or BGM.
2 PresstheNavigationbuttonstoscrolltomakeappropriateadjustments.
Transition Effect Option
Option Description
Sliding Pushesthecurrentslideoutofviewasitplaystothenextslide.
Stairs Pushesthecurrentslideinastaircaseshapeasitplaystothenextslide.
Door Open
/Close
Pushesthecurrentslidelikeopeningorclosingthedoorasitplaystothenextslide.
Shutter Pushesthecurrentslidelikedrawingorpullingdowntheblindasitplaystothenextslide
Fade In Fadestheslideoutslowlybeforeplayingtothenextslide.
background
30
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Video,
1 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,
1 PresstheNavigationbuttons to scrolltoshow
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
5 Playmusic.
Listening to music
1 PresstheNavigationbuttonstoscrolltoMy Me-
diaandpressOK.
2 PresstheNavigationbuttonstoscrolltoMusic
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoafolder
youwantandpressOK.
4 Pressthe Navigation buttons toscroll to afile
youwantandpressOK.
Menu Description
Play Marked Displaytheselectedmusicfile.
Mark All Markallmusicfilesonthescreen.
Unmark All Deselectallmarkedmusicfiles.
Exit Mark Mode ExittheMarkMode.
Page1/1
MusicList
Drive1
Page1/1
001.-B01.mp3
00:00
002.-B02.mp3
00:00
003.B03.mp3
00:00
004.-B04.mp3
00:00
005.-B05.mp3
00:00
USB1USBDrive
ToMovieList
ChangeNumbers
MarkMode
Exit
Play
Move
PageChange
Mark
Page1/1
MusicList
Drive1
Page1/1
001.-B01.mp3
00:00
002.-B02.mp3
00:00
003.B03.mp3
00:00
004.-B04.mp3
00:00
005.-B05.mp3
00:00
USB1USBDrive
PlayMarked
MarkAll
UnmarkAll
Exit
MarkMode
ExitMarkMode
Mark
Move
PageChange
Mark
background
31
ENG
ENGLISH
ENTERTAINMENT
Timeelapsed/Duration
002.B02.mp3
00:31/04:04
filename
Non-supported files are displayed the pre-
viewimagebyicononly .
Abnormal files are displayed in the form of
bitmap .
Adamagedorcorruptedmusicdoesnotplay
butdisplays00:00inplaytime.
Amusicdownloadedfromapaidservicewith
copyright protection does not start but dis-
playsinappropriateinformationinplaytime.
IfyoupressOK, buttons,screensaveris
stopped.
ThePLAY( ),Pause( ), , , but-
tonsontheremotecontrolarealsoavailable
inthismode.
Youcanusethe buttontoselectthenext
musicandthe buttontoselecttheprevi-
ousmusic.
6 Controlplaybackbyusingthefollowingbuttons.
Page1/1
MusicList
Drive1 Page1/1
3file(s)Marked
004.-B04.mp3
00:00
005.-B05.mp3
00:00
006.-B06.mp3
00:00
007.-B07.mp3
00:00
008.-B08.mp3
00:00
005.-B05.mp3
02:30/03:25
Hide Exit
Option
PlaywithPhoto
Button Description
Stopsplayback
Playsamusicfile
Pausesorresumesplayback
Skipstothenextfile
Skipstothepreviousfile
or Whenplaying,
Whenyoupressthe button,thepre-
viousmusicfilewillbeplayed.
Whenyoupressthe button,thenext
musicfilewillbeplayed.
Green
button
Startplayingtheselectedmusicfilesand
thenmovetothePhoto List.
ENERGY
SAVING
Press the
ENERGY SAVING button
repeatedly to change the brightness of
yourscreen.
Option
ShowtheOptionmenu.
Hide
Hidestheoptionwindow.
Todisplaytheoptions,pressOK.
EXIT
When you press the EXIT button while
the Music player is displayed, only the
musicwillbestoppedandtheplayerwill
notreturntonormalviewing.
When you press the EXIT button while
themusicisstoppedorwhilethemusic
playerishidden,theplayerwillreturnto
normalviewing.
or
When using the < or > button during
playbackacursorindicatingtheposition
canbeplayed.
Tips for playing music files
This unit doesn't support the ID3 Tag
embeddedMP3files.
NOTE
background
32
ENG
ENGLISH
ENTERTAINMENT
1 PressMENUtoaccessthePop-Upmenus.
2 PresstheNavigationbuttonstoscrolltoSet Au-
dio Play. or Set Audio. andpressOK.
Music options
Option values changed in Movie List does
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic Listarechanged likewise inPhoto List
andMusic ListexcludingMovie List.
WhenyouselecttheSet Audio Play.,
1 PresstheNavigationbuttonstoscrolltoselect
theRepeatorRandom.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,,
1 PresstheNavigationbuttonstoscrolltoselect
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
NOTE
WhileplayingmediafilesfromContentsList,
onlytheBACK,EXITorVolumebuttonare
available.SelectingtheBACKorEXITbutton
stopsplayingmediafilesandreturnstothe
screenviewmode.
IfthereistheAutoPlayfolderintheUSB
deviceanditsfilesareinsupportedformats,
theycanbeplayedbackautomaticallywhen
theUSBdeviceisconnectedtothemonitor.
NOTE
Viewing the Contents List
PlaysbackthestoredfilesusingtheExportoption
inSuperSignManager.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoCon-
tents ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Page1/1
ContentsList
Drive1
Page1/1
test1.cts
07/01/2011
test2.cts
07/01/2011
test3.cts
07/01/2011
test4.cts
07/01/2011
test5.cts
07/01/2011
USB1USBDrive
ToMovieList
ChangeNumbers
Exit
Play
Move
Page ChangeP
background
33
ENG
ENGLISH
ENTERTAINMENT
DivX® VOD Guide
DivX® VOD Registration
In order to play purchased or rented DivX® VOD
contents, you should register your device with 10
digit DivX registration code from your device at
www.divx.com/vod.
1 PressMENUtoaccessthemainmenus.
2 Press the Navigation buttons to scroll to MY
MEDIAandpressOK.
3 PresstheBluebutton.
4 Pressthe Navigation buttonsto scroll to DivX
Reg. CodeandpressOK.
5 Viewtheregistrationcodeofyourdisplay.
6 Whenyouarefinished,press EXIT.
When you return to the previous menu, press
BACK.
Whileyouarecheckingtheregistrationcode,
somebuttonsmaynotwork.
IfyouusetheDivXregistrationcodeof
anotherdevice,youcannotplaytherented
orpurchasedDivXfile.Makesuretousethe
DivXregistrationcodeassignedtoyourTV.
Thevideooraudiofilesthatarenotcon-
vertedbythestandardDivXcodecmaybe
corruptedornotbeplayed.
TheDivXVODcodeallowsyoutoactivate
upto6devicesunderoneaccount.
Youmustregisteryourdevice
toplayDivX protectedvideos.
Registrationcode:**********
Registerathttp://vod.divx.com
Close
NOTE
background
34
ENG
ENGLISH
ENTERTAINMENT
Oncethederegistrationisexecuted,you
mustregisteryourdeviceagaintosee
DivX®VODcontents.
DivX® VOD Deregistration
Youshouldderegisteryourdevicewith8digitDivX
deregistrationcodefromyourdeviceatwww.divx.
com/vod.
1 PressMENUtoaccessthemainmenus.
2 Press the Navigation buttons to scroll to MY
MEDIAandpressOK.
3 PresstheBluebutton.
4 PresstheNavigationbuttonstoscrolltoDeacti-
vationandpressOK.
5 Press the Navigation buttons to select Yes to
confirm.
Deregistrationcode:
********
Deregisterathttp://vod.divx.com
Continuewithregistration?
Yes No
6 Whenyouarefinished,press EXIT.
When you return to the previous menu, press
BACK.
NOTE
Using PIP/PBP
VideosorpicturesstoredontheUSBdevicecan
bedisplayedonasinglemonitorbydividingthem
intothemainandsubscreens.(Seep.46)
1 Press the MENU button to move to OPTION
andpressOK.
2 PressPIP/PBPtoselectPIPorPBPandthen
pressOK.
Move
PIP/PBP
Off
PIP
PBP
Prev.
Mode
Position
Size
3 SelectMovieListorPhoto ListfromMy
Media.
MovieList MusicListPhotoList
ContentsList
background
35
ENG
ENGLISH
ENTERTAINMENT
4 SelectafileyouwantandthenpressOK.
5 SelectthePIPorPBPiconfromtheplaylist.
6 ForsoundselecteitherMainorSub.Youmust
to select the output sound before running the
PIP orPBPfunction.
Selectthesoundpath.
Main Sub
7 Thesubscreenisdisplayedonthemainscreen.
01:02:30/02:30:25
Option
Hide
Exit
< MOVIE LIST >
< PHOTO LIST >
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
ToPhotolist
ChangeNumbers
MarkMode
Exit
003
001 002
004
005 006
Play
Move
PageChange
Mark
051.Apple_...
02:30:25
2/13
Slideshow BGM
Hide
Option
Exit
background
36
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Accessing main menus
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltooneofthefollowingmenusand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyouwant
andpressOK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
P
A
G
E
MARK
ARC
OK
S.MENU
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
OPTION
NETWORK
AUDIO TIME
MY MEDIA
PICTURE (Seep.37)
Adjuststheimagesize,
quality,oreffect.
AUDIO(Seep.40)
Adjuststhesoundquality,
effect,orvolumelevel.
NETWORK(Seep.47)
Setsupthenetwork
setting.
OPTION (Seep.42)
Customizesthegeneral
settings.
TIME(Seep.41)
Setsthetime,date,or
Timerfeature.
MY MEDIA(Seep.22)
Displayandplaymovie,
photoandmusiccontent
storedonyourUSB
background
37
ENG
ENGLISH
CUSTOMIZING SETTINGS
PICTURE settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoPICTUREand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK. 
Theavailablepicturesettingsaredescribedinthefollowing:
Setting Description
Aspect Ratio Changestheimagesizetoviewimagesatitsoptimalsize(Seep.16).
Energy Saving
Setstoautomaticallyadjustthescreenbrightnesscorrespondingtothesurroundings.
Level
Auto Adjustautomatically
Off DisablesEnergySavingfunction
Minimum/
Medium/
Maximum
Selectsthebrightnesslevelofthebacklight.
Screen off Thescreenturnsoffin3seconds.
Smart Energy
Saving
Adjuststhebacklightandcontrastdependingonthescreenbrightness.
Level
Off DisablestheSmartEnergySavingfunction.
On EnablestheSmartEnergySavingfunctiontosavepowerconsumptionasmuch
asthevaluesetinthesmartenergysavingrate.
Picture Mode SelectsoneofthepresetimageorcustomizesoptionsineachmodeforthebestMonitorscreen
performance.Youarealsoabletocustomizeadvancedoptionsofeachmode.
TheavailablepresetpicturemodesvarydependingontheMonitor.
Mode
Vivid Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,
brightness,Colour,andsharpness.
Standard Adjuststheimageforthenormalenvironment.
Cinema Optimizesthevideoimageforacinematiclooktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighanddynamicactionsbyemphasizingprimary
Colourssuchaswhite,grass,orskyblue.
Game OptimizesthevideoimageforafastgamingscreensuchasPCsorgames.
Move
OK
Aspect Ratio
Energy Saving
Smart Energy Saving
Picture Mode
Screen
background
38
ENG
ENGLISH
CUSTOMIZING SETTINGS
WhenusingtheSmartEnergySavingfunction,thescreenmaylooksaturatedinthewhiteareaofa
stillimage.
IfEnergySavingissettoMinimum,Medium,orMaximum,theSmartEnergySavingfunctionis
disabled.
Picture Mode options
Setting Description
Backlight AdjuststhebrightnessofthescreenbycontrollingtheLCDbacklight.Ifyoudecreasethe
brightnesslevel,thescreenbecomesdarkerandthepowerconsumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthegradientofthevideosignal.YoumayuseContrastwhenthe
brightpartofthepictureissaturated.
Brightness Adjuststhebaselevelofthesignalinthepicture.YoumayuseBrightnesswhenthedarkpart
ofthepictureissaturated.
Sharpness Adjuststhelevelofcrispnessintheedgesbetweenthelightanddarkareasofthepicture.
Thelowerthelevel,thesoftertheimage.
Color Adjustsintensityofallcolors.
Tint Adjuststhebalancebetweenredandgreenlevels.
Color Temp. SettowarmtoenhancehotterColorssuchasred,orsettocooltomakepicturebluish.
Advanced Control Customizestheadvancedoptions.RefertotheAdvancedimageoptions.(Seep.39).
Picture Reset Restorestheoptionstothedefaultsetting.
Setting Description
SCREEN
(In RGB
Mode Only)
CustomizesthePCdisplayoptionsinRGBmode.
Option
Resolution Selectsaproperresolution.See“CustomizingPCdisplayoptions”.
Auto Config. Adjuststhescreenposition,clock,andphaseautomatically.
Thedisplayedimagemaybeunstableforafewsecondswhiletheconfigurationis
inprogress.
Position/Size/
Phase
Adjuststheoptionswhenthepictureisnotclear,especiallywhencharactersare
shaky.RunAutoConfig.beforeadjustingthese.
Reset Restoresalloptionstothedefaultsetting.
NOTE
background
39
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Dynamic Contrast
(Off/High/Medium/Low)
Adjuststhecontrasttokeepitatthebestlevelaccordingtothebrightnessofthescreen.
The
pictureisimprovedbymakingbrightpartsbrighteranddarkpartsdarker.(Functionworksin
thefollowingmode-AV(CVBS),Component,HDMI-DTV,DisplayPort-DTV)
Dynamic Color
(Off/High/Low)
AdjustsscreenColorssothattheylooklivelier,richerandclearer.Thisfeatureenhances
hue,saturationandluminancesothatred,blue,greenandwhitelookmorevivid.(Function
worksinthefollowingmode-AV(CVBS),Component,HDMI-DTV,DisplayPort-DTV)
Clear White
(Off/High/Low)
Makethewhiteareaofscreenbrighterandmorewhite.
Skin Color
(-5 to 5)
Itdetectstheskinareaofvideoandadjustsittoexpressanaturalskincolor.
Noise Reduction
(Off/High/Medium/Low)
Reducesscreennoisewithoutcompromisingvideoquality.(Functionworksinthefollowing
mode-AV(CVBS),Component,HDMI-DTV,DisplayPort-DTV)
Digital Noise Reduction
(Off/High/Medium/Low)
Thisoptionreducesthenoiseproducedwhilecreatingdigitalvideosignals.
Gamma
(High/Medium/Low)
Setyourowngammavalue.Onthemonitor,highgammavaluesdisplaywhitishimagesand
lowgammavaluesdisplayhighcontrastimages.
Black Level
(High/Low)
Low:Thepictureofthescreengetsdarker.
High:Thepictureofthescreengetsbrighter.
Setblacklevelofthescreentoproperlevel.
(Functionworksinthefollowingmode-AV(CVBS),Component,HDMI-DTV,DisplayPort-
DTV)
Advanced Control
background
40
ENG
ENGLISH
CUSTOMIZING SETTINGS
AUDIO settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoAUDIOandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableaudiooptionsaredescribedinthefollowing:
Setting Description
Clear Voice ll Bydifferentiatingthehumansoundrangefromothers,ithelpsusersmakesdialogeasierto
understand.
Balance Adjustsbalancebetweentheleftandrightspeakersaccordingtoyourroomenvironment.
Sound Mode Mode
Standard Selectwhenyouwantstandard-qualitysound.
Music Selectwhenyoulistentomusic.
Cinema Selectwhenyouwatchmovies.
Sport Selectwhenyouwatchsportevents.
Game Selectswhenyouplaygames.
Digital Audio
Input
HDMI/Display Port:OutputsthesoundofdigitalsignalfromHDMIanddisplayportsthroughthe
monitorspeaker.
Audio In:OutputsthesoundthroughthemonitorspeakerbyconnectingHDMIanddisplayports
totheAudioInport.
Speaker ON:Enablessoundtothemonitorspeaker.(*Themonitorspeakerissoldseparately.)
OFF:Disablessoundtothemonitorspeaker.Usethisoptionwhenusinganexternalsounddevice.
Move
OK
AUDIO
Clear Voice II
Balance
Sound Mode
Digital Audio Input
Speaker
Sound Mode options
Setting Description
Infinite Sound LG'sInfinitySoundoptionprovides5.1channelstereosoundfromtwospeakers.
Treble Controlsthedominantsoundsintheoutput.Whenyouturnupthetreble,itwillincreasethe
outputtothehigherfrequencyrange.
Bass Controlsthesoftersoundsintheoutput.Whenyouturnupthebass,itwillincreasetheoutput
tothelowerfrequencyrange.
Reset Resetsthesoundmodetothedefaultsetting.
background
41
ENG
ENGLISH
CUSTOMIZING SETTINGS
TIME settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoTIMEandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailabletimesettingsaredescribedinthefollowing:
Setting Description
Clock Setsthetimefeature.
Off/On Time SetsthetimetoturnonorofftheMonitor.
Sleep Timer SetsthelengthoftimeuntiltheMonitortoturnsoff.WhenyouturntheMonitoroffandturn
itonagain,theSleepTimerwillbesettooff.
Power on delay Whenconnectingmultiplemonitorsandturningthepoweron,themonitorsareturnedonindividually
topreventoverload.
Auto off IfAutooffisactiveandthereisnoinputsignal,thesetswitchestooffmodeautomaticallyafter15
minutes.
Automatic
Standby
Ifyoudonotusethemonitorformorethan4hours,itwillbeinoffmodeautomatically.
Move
OK
TIME
Clock
Off Time
On Time
Sleep Timer
Power On Delay
Auto Off
Automatic Standby
Off/OnTimecanbesavedforuptosevenschedules;theMonitoristurnedonoroffatthepresettimeintheschedule
list.Ifmultiplepresettimesarestoredintheschedulelist,thisfunctionworksatthenearesttimefromthecurrenttime.
Thescheduledpower-offfunctionworksproperlyonlywhenthedevicetimeissetcorrectly.
Whenthescheduledpower-onandpower-offtimesarethesame,thepower-offtimehaspriorityoverthepower-ontime
ifthesetisturnedon,andviceversaifthesetisturnedoff.
"The""AutomaticStandby""and""Autooff""functionsmaynotbeavailableinsomecountries."
NOTE
background
42
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Language Tochoosethelanguageinwhichthecontrolnamesaredisplayed.
Power Indicator UsethisfunctiontosetthepowerindicatoronthefrontsideoftheproducttoOnorOff.
ISM Method AfrozenorstillpicturefromaPC/Videogamedisplayedonthescreenforprolongedperiods
couldresultinaghostimageremainingevenwhenyouchangetheimage.Avoidallowingafixed
imagetoremainonthescreenforalongperiodoftime.
Setting
Normal Leaveonnormalifyoudon'tforeseeimageburninbeingaproblem.
Orbiter May help prevent ghost images. However,itisbestnot to allowany fixed
image toremain onthescreen.Toavoidapermanentimageonthescreen,
thescreenwillmoveevery2minutes.
Inversion This function inverts the panel color of the screen. The panel color is
automaticallyinvertedevery30minutes.
White Wash White washfillsthe screen with solidwhite.Thishelpsremoves permanent
imagesburnedintothescreen.Apermanentimagemaybeimpossibletoclear
entirelywithwhitewash.
DPM Select Ausercanchoosetoturnthepowersavingmodeon/off.
Fail Over Ifthereisnoinputsignal,itautomaticallyswitchestoanotherinputwithsignal.
Setting
Off Stopsautoswitchoftheinputsource.
Auto Switchestoanotherinputsourcewithvideosignalifnovideosignalcomes
fromthecurrentinputsource.
Manual Selectsthepriorityofinputsourceforautoswitch.
Whenseveralinputsourcesarefound,theinputsourcewithahigherpriority
willbeselected.
Factory Reset Selectthisoptiontoreturntothedefaultfactorysettings.
Set ID YoucanassignauniqueSetIDNO(nameassignment)toeachproductwhenseveralproducts
areconnectedfordisplay.Specifythenumber(1to99)usingthebuttonandexit.Usethe
assignedSetIDtoindividuallycontroleachproductusingtheProductControlProgram.
OPTION settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoOPTIONandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableoptionsettingsaredescribedinthefollowing:
Move
OK
OPTION
Language
Power Indicator
ISM Method
DPM Select
Fail Over
Factory Reset
Set ID
Tile Mode
PIP/PBP
Key Lock
Product/Service Info.
Portrait Mode
background
43
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Tile Mode Tile Mode Tousethisfunction
-Mustbedisplayedwithvariousotherproducts.
-MustbeinafunctionthatcanbeconnectedtoRGBCablebydistributorand
RS-232C.
TilemodeandchooseTilealignmentandsettheIDofthecurrentproductto
setlocation.
*OnlyafterpressingtheSETbuttontheadjustmentsmadetothesettingswill
besaved.
-Tilemode:columnxrow(c=1,2,3,4,5r=1,2,3,4,5)
-5x5available.
-Configurationofanintegrationscreenisalsoavailableaswellas
configurationofOnebyoneDisplay.
Auto Config. Adjuststhescreenpositionautomatically.
The displayed image may be unstable for a few seconds while the
configurationisinprogress.
PC Position Movingthescreenpositionhorizontallyandvertically.
PC Size Adjustthehorizontalandverticalsizeofthescreentakingintoaccountthesize
ofthebezel.
Natural Theimageisomittedbythedistancebetweenthescreenstobenaturally
shown.
Reset FunctiontoinitializeandreleaseTile.
AllTilesettingarereleasedwhenselectingTilerecallandthescreenreturnsto
Fullscreen.
NOTE
IfTileModeisenabled,SmartEnergySavingandtheAutooptioninEnergySavingwillbe
disabledtoprovidethesamepicturequalityasotherdisplays.
PIP/PBP VideosorphotosstoredontheUSBdevicecanbedisplayedonasinglemonitorbydividingthem
intothemainandsubscreens.
Option
Mode Setsthetypeofsecondaryscreen.
*OFF:Disablesthesecondaryscreen.
*PIP(PictureInPicture):Displaysthesecondaryscreeninthemainscreen.
*PBP(PictureByPicture):Displaysthesecondaryscreennexttothemain
screen.
Position Adjuststhepositionofthesubscreen(topleft,bottomleft,topright,bottom
right)Thedefaultvalueisinthebottomright.
Size Adjuststhesizeofthesubscreen(Size0-10).ThedefaultsizeofthePIP(Size:
0)is480x240;themaximumsize(Size:10)is960x540.
NOTE
ThePositionandSizeoptionsareenabledonlyinPIPmode.
background
44
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Key Lock Keyinputdoesnotwork.Thispreventsinvalidkeyinput.
Product/Service
Info.
Displaysthemodelname,softwareversion,serialnumber,IPaddress,MACaddressandhome
page.
Portrait mode RotateOSDclockwise(90°,270°)
Option
90° RotateOSDclockwise90°.
270° RotateOSDclockwise270°.
270°
Move OK
AUDIO
ClearVoiceII
Balance
SoundMode
DigitalAudioOut
Speaker
90°
Move OK
AUDIO
ClearVoiceII
Balance
SoundMode
DigitalAudioOut
Speaker
background
45
ENG
ENGLISH
CUSTOMIZING SETTINGS
Tile Mode
Thismonitorcanbetiledwithadditionalmonitors
tocreatealargetileddisplay.
Tile Mode - Natural mode
Whenactive,thepartoftheimagethatwould
normallybedisplayedinthegapbetweenthe
monitorsisomitted.
ID1
ID2
ID3
ID4
ID1
ID2
ID4
ID5
ID3
ID6
ID7
ID8
ID9
3X3
Whenusing9monitors
ID1
ID2
ID5
ID6
ID3
ID7
ID9
ID10
ID11
ID4
ID8
ID12
ID13
ID14
ID15
ID16
ID1
ID2
ID6
ID7
ID3
ID8
ID11
ID12
ID13
ID4 ID5
ID9 ID10
ID14 ID15
ID16
ID21
ID17
ID22
ID18
ID23
ID19
ID24
ID20
ID25
Off
WhentheTileMode
optionisdisabled
2X1
Whenusing2monitors
2X2
Whenusing4monitors
5X5
Whenusing25monitors
4X4
Whenusing16monitors
ID1
ID2
TileID
Before
After
background
46
ENG
ENGLISH
CUSTOMIZING SETTINGS
PIP/PBP
DisplaysvideosorphotosstoredintheUSBdevice
onasinglemonitorbydividingitintothemainand
subscreens.(Seep.34)
Position
Mode
Size
top left top right
bottom left bottom right
*PIP(Picture In Picture):DisplaystheSubscreen
inthemainscreen.
*PBP(Picture By Picture):DisplaystheSub
screennexttothemainscreen.
Adjuststhepositionofthesubscreen(topleft,
bottomleft,topright,bottomright)
Adjuststhesizeofthesubscreen(Size0-10).
< 1920x1080 >
PBP
960x1080
0 :
480x270
PIP
10 : 960x540
Thesubscreenisonlysupportedwhenusingthe
USBdevice.
Sub
USB
Main
Component O
RGB O
HDMI/DVI-D/Display Port O
AV X
YoucanonlychangethesizeandpositioninPIP
mode.
WithPBPselected,theAspectRatiooptioninthe
PICTUREmenuisdisabled(Fixedas16:9).
WhilerunningthePBPfunction,theTileModefunction
doesnotwork.
Youmustselecttheoutputsoundbeforerunning
thePIPorPBPfunctions.(SelecteitherMainor
Sub.)
IfyoufailtoselectMainorSubfromthesound
selectionbox,andiftheOSDdisappearsafter
eitheraperiodoftimeorwhentheExitorBack
keyispressed,thePIP/PBPsubscreenisnot
activated.
Youcannotchangethesoundwhilerunningthe
PIPorPBPfunctions.Ifyouwanttochangethe
sound,pleaserestartPIP/PBP.
Thepicturequalityofthesubscreenisset
accordingtothevaluesselectedinthemainmenu,
nottheUSBdevice.
Evenwhenthepoweristurnedofforon,ifthe
USBdeviceisconnected,thePIP/PBPmodeplays
againfromwhereitleftoff.
IfyouplayvideosyouselectedinPIP/PBPmode,
thevideoswillplaybackrepeatelyinsuccession.
ThebuttonsbelowworkinPIPmode.
Button Photo Movie
NOTE
Main
screen
Sub
screen
PIP PBP
background
47
ENG
ENGLISH
CUSTOMIZING SETTINGS
NETWORK settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoNETWORKand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableoptionsettingsaredescribedinthefollowing:
Move
OK
NETWORK
Player Name
Network Setting
Network Status
Server IP Setting
Server IP Status
Setting Description
Player Name SetstheplayernameusedinSuperSignManager.(Upto20characters)
Network Setting Configurethenetworksettings.
Network Status
Displaythenetworkstatus.
-Internetisconnected:Extermallyconnected
-Homenetworkisconnected:Onlyinternallyconnected
-Notconnected:Whenthereisnonetworkconnection
Server IP Setting SetstheIPaddressofthecomputer(server)onwhichSuperSignManagerisinstalled.
Server IP Status Displaystheconnectionstatuswiththeserver.
-Notconnected:WhenthereisnonetworkconnectionwithSuperSignserver
-Waitingforapproval:WhennetworkconnectionwithSuperSignserverhasbeenmade,but
accesstoserverhasnotbeenapprovedbytheserver
-Rejected:WhennetworkconnectionwithSuperSignserverhasbeenmade,butaccessto
serverhasbeenrejectedbytheserver
-Internetisconnected:WhennetworkconnectionwithSuperSignserverhasbeenmadeand
accesstoserverhasalsobeenapprovedbytheserver
WhensettingthePlayerName,inputdelaymayoccurifyoupressthebuttonsontheremotecontrol
continuously.
CAUTION
background
48
ENG
ENGLISH
MAKING CONNECTIONS
HDMI-Seep.49
Component-Seep.49
AV(CVBS)-Seep.50
RGB-Seep.12
DVI-D-Seep.12
HDMI-Seep.13
DisplayPort-Seep.13
LAN-Seep.51
HDMI-Seep.49
Component-Seep.49
AV(CVBS)-Seep.50
HDMI-Seep.49
Component-Seep.49
AV(CVBS)-Seep.50
AV(CVBS)-Seep.50
Component-Seep.49
HDMI-Seep.49
Component-Seep.49
AV(CVBS)-Seep.50
MAKING CONNECTIONS
ConnectvariousexternaldevicestotheportsontheMonitor’sbackpanel.
1
FindanexternaldeviceyouwanttoconnecttoyourMonitorshownonthefollowingillustration.
2
Checktheconnectiontypeoftheexternaldevice.
3
Gototheappropriateillustrationandchecktheconnectiondetails.
IfyouconnectagamingdevicetotheMonitor,usethecablesuppliedwiththegamingdevice.
HD Receiver DVD VCR
USB
PC
Camcorder/Camera
Gaming device
Speaker
Memorystorage
–Seep.21
NOTE
background
49
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a HD receiver,
DVD, Camcorder, Camera,
Gaming Device or VCR player
ConnectaHDreceiver,DVD,orVCRplayertothe
Monitorandselectanappropriateinputmode.
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
anexternaldevicetotheMonitor.Connectthe
externaldeviceandtheMonitorwiththeHDMI
cableasshownonthefollowingillustration.
UseaHighSpeedHDMI™Cable.
HighSpeedHDMI™Cablesaretestedto
carryanHDsignalupto1080pandhigher.
NOTE
Component connection
Transmitstheanalogvideoandaudiosignals
fromanexternaldevicetotheMonitor.Connect
theexternaldeviceandtheMonitorwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.Todisplayimagesbyusingprogressive
scan,makesuretousethecomponentcable.
HDMI
V
IDE
O
AU
D
I
O
OUT
(notincluded)
(notincluded)
(notincluded)
background
50
ENG
ENGLISH
MAKING CONNECTIONS
AV(CVBS) connection
Transmitstheanalogvideoandaudiosignals
fromanexternaldevicetotheMonitor.Connect
theexternaldeviceandtheMonitorwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.
Connecting to a USB
ConnectaUSBstoragedevicesuchassUSB
flashmemory,externalharddrive,MP3playeror
aUSBmemorycardreadertotheMonitorand
accesstheUSBmenutousevariousmultimedia
files.
AU
DI
O
OUT
V
IDE
O
OUT
(notincluded)
(notincluded)
or
background
51
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to the LAN
UsingLANestablishescommunication
betweenyourPCandthemonitorand
enablestousetheOSDmenusonthePCas
wellasonthemonitor.
LAN connection
A
ConnectPCtoMonitordirectly.
B
Usingarouter(Switch)
C
UsingtheInternet.
NOTE
PC
Monitor
Network
LAN
Monitor
PC
Network
LAN
Network
Monitor
PC
Switch
LAN
background
52
ENG
ENGLISH
MAKING CONNECTIONS
RGB OUT
(
PC
)
V
IDE
O
AU
DI
O
OUT
V
IDE
O
OUT
Daisy Chain Monitors
UsethisfunctiontosharetheRGBvideosignalwithothermonitorswithouthavingtouseaseparatesignal
splitterbox.
TousedifferentproductsconnectedtoeachotherConnectoneendofthesignalinputcable(15-pinD-Sub
SignalCable)totheRGBOUTconnectorofproduct1andconnecttheotherendtotheRGBINconnector
ofotherproducts
RGB
Mode
Component
Mode
AV(CVBS)
Mode
15-pinD-SubSignalCable
(Max3m)
Monitor1 Monitor2 Monitor3 Monitor4
Thenumberofmonitorsthatcanbeconnectedtooneoutputmayvarydependingonsignalstatus
andcableloss.Ifthesignalstatusisgood,andthereisnocableloss,itispossibletoconnectupto
9monitors.Ifyouwanttoconnectmorethanthisnumberofmonitors,itisrecommendedtousea
distributor.
Whenmulti-connectingin/outcascadeformat,nolosscablesarerecommended.
NOTE
background
53
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
No image is displayed
Problem Resolution
Istheproductpowercord
connected?
Seeifthepowercordisproperlyconnectedtotheoutlet.
Isthepowerindicatorlighton?
Seeifthepowerswitchisturnedon.
Mayneedservice.
Powerison,powerindicator
isredbutthescreenappears
extremelydark.
Adjustbrightnessandcontrastagain.
Backlightmayneedrepair.
Thepowerindicatoramber?
Iftheproductisinpowersavingmode,movethemouseorpressany
key.
Turnbothdevicesoffandthenbackon.
Doesthe'Outofrange'
messageappear?
ThesignalfromthePC(videocard)isoutoftheverticalorhorizontal
frequencyrangeoftheproduct.Adjustthefrequencyrangeby
referringtotheSpecificationsinthismanual.
*Maximumresolution
RGB,HDMI,DVI-D,DisplayPort:1920x1080@60Hz
Doesthe'Checksignalcable'
messageappear?
ThesignalcablebetweenPCandproductisnotconnected.Check
thesignalcable.
Pressthe'INPUT'menuintheremoteControltochecktheinput
signal.
'Unknown Product' message appears when the product is connected.
Problem Resolution
Didyouinstallthedriver?
Installtheproductdriver,whichisprovidedwiththeproduct,or
downloaditfromthewebsite.(http://www.lg.com)
Seeiftheplug&playfunctionissupportedbyreferringtothevideo
cardusermanual.
background
54
ENG
ENGLISH
TROUBLESHOOTING
'Key Lock On' message appears.
Problem Resolution
The'KeyLockOn'message
appearswhenpressingthe
Menubutton.
TheLockfunctionpreventstheOSDsettingsfrombeingchanged
inadvertently.Toreleasethelock,gotoMenuandOptionanddisable
theKeyLockoption.
The screen image looks abnormal.
Problem Resolution
Isthescreenpositionwrong?
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselecttheoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usethePositionOSD
menu.
Seeifthevideocardresolutionandfrequencyaresupportedbythe
product.Ifthefrequencyisoutofrange,settotherecommended
resolutionintheControlPanel"Display"Settingmenu.
Dothinlinesappearonthe
backgroundscreen?
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselectanoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usetheClockOSD
menu.
Horizontalnoiseappearsorthe
characterslookblurred.
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselectanoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usethePhaseOSD
menu.
Thescreenisdisplayed
abnormally.
Theproperinputsignalisnotconnectedtothesignalport.Connect
thesignalcablethatmatcheswiththesourceinputsignal.
After-image appears on the product.
Problem Resolution
After-imageappearswhenthe
productisturnedoff.
Ifyouuseafixedimageforalongtime,thepixelsmaybedamaged
quickly.Usethescreen-saverfunction.
background
55
ENG
ENGLISH
TROUBLESHOOTING
Screen color is abnormal.
Problem Resolution
Screenhaspoorcolorresolution
(16colors).
Setthenumberofcolorstomorethan24bits(truecolor)Select
ControlPanel-Display-Settings-ColorTablemenuinWindows.
Screencolorisunstableor
mono-colored.
Checktheconnectionstatusofthesignalcable.Or,re-insertthePC
videocard.
Doblackspotsappearonthe
screen?
Severalpixels(red,green,whiteorblackcolor)mayappearonthe
screen,whichcanbeattributabletotheuniquecharacteristicsofthe
LCDpanel.ItisnotamalfunctionoftheLCD.
The operation does not work normally.
Problem Resolution
Thepowersuddenlyturnedoff.
Isthesleeptimerset?
Checkthepowercontrolsettings.Powerinterrupted
The audio function does not work.
Problem Resolution
Nosound?
Seeiftheaudiocableisconnectedproperly.
Adjustthevolume.
Seeifthesoundissetproperly.
Soundistoodull.
AdjusttheClearVoicell,TrebleandBassappropriately.
Soundistoolow.
Adjustthevolume.
background
56
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
LCDPanel ScreenType 72"class(72"diagonal)TFT(ThinFilmTransistor)
LCD(LiquidCrystalDisplay)Panel.
Visiblediagonalsize:1830.616mm
PixelPitch 0.831mm(H)x0.831mm(V)
VideoSignal Max.Resolution RGB:1920X1080@60Hz
HDMI,DVI-D,DisplayPort:1920X1080@60Hz
-ItmaynotbesupporteddependingontheOSorvideocardtype.
RecommendedResolution RGB:1920X1080@60Hz
HDMI,DVI-D,DisplayPort:1920X1080@60Hz
-ItmaynotbesupporteddependingontheOSorvideocardtype.
HorizontalFrequency
RGB:30kHzto83kHz
HDMI,DVI-D,DisplayPort:30kHzto83kHz
VerticalFrequency RGB:56Hzto75Hz
HDMI,DVI-D,DisplayPort:56Hzto60Hz
SynchronizationType SeparateSync,CompositeSync,Digital
InputConnector 15-pinD-Sub,HDMI,DVI-D,DisplayPort,RS-232C,LAN,
USB,Audio
Power RatedVoltage 100-240V~50/60Hz5.7A
PowerConsumption OnMode:500WTyp.
SleepMode(RGB):≤1W
SleepMode(HDMI,DVI-D,DisplayPort)
:≤1W(SetOnly)/≤2W(WithExternalDevice)
OffMode:≤0.5W
Environmental
conditions
OperatingTemperature
OperatingHumidity
0°Cto40°C
10%to80%
StorageTemperature
StorageHumidity
-20°Cto60°C
5%to95%
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
background
57
ENG
ENGLISH
SPECIFICATIONS
Dimensions
(WidthxHeightx
Depth)/Weight
1677.4mmx979.4mmx100.7mm/57.0kg
* Applicable only for models that support the speakers
Audio RMSAudioOutput 10W+10W(R+L)
InputSensitivity 0.7Vrms
SpeakerImpedance 8Ω
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
background
58
ENG
ENGLISH
SPECIFICATIONS
Dimensions
Theillustrationsinthismanualmaydifferfromtheactualproductandaccessories.
Pleaseseethe"Mountingonawall"sectionforsizesofscrews.(Seep.8)
(Unit:mm)
49::17
<319
4331:
86;1:
5615
59415
5;<1:
533
4964
733
933
70P9#+Zdoo#Prxqw,
6;1:
6;1:
<:<17
6;1:
6;1:
;<:18#+Dfwlyh#Duhd,
48<818#+Dfwlyh#Duhd,
Product specifications shown above may be changedwithout prior notice due toupgrade of product
functions.
background
59
ENG
ENGLISH
SPECIFICATIONS
RGB (PC) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
640x350
31.469 70.8
720x400
31.468 70.8
640x480
31.469 59.94
640x480
37.5 75
800x600
37.879 60.317
800x600
46.875 75
832x624
49.725 74.55
1024x768
48.363 60
1024x768
60.123 75.029
1280x720
44.772 59.855
1366x768
47.7 60
1280x1024
63.981 60.02
1280x1024
79.98 75.02
1680x1050
65.290 59.954
1920x1080
67.5 60
HDMI,DVI-D,Display Port (PC) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
640x480
31.469 59.94
800x600
37.879 60.317
1024x768
48.363 60
1280x720
44.772 59.855
1366x768
47.7 60
1280x1024
63.981 60.02
1680x1050
65.290 59.954
1920x1080
67.5 60
WhenthecableisconnectedtotheHDMIor
thedisplayport,youcanselectthePC/DTV
modeoptionally.Itisrecommendedyouto
settothePCmodewhenconnectingtoPC;
theDTVmodewhenconnectingtoDTV.
DTV Mode
Resolution Component
HDMI,Display
Port (DTV)
480i o x
480p o o
576i o x
576p o o
720p o o
1080i o o
1080p o o
Power Indicator
Mode Product
OnMode Red
SleepMode Amber
OffMode -
NOTE
Verticalfrequency:Toenabletheuserto
watchtheproductdisplay,screenimage
shouldbechangedtensoftimesevery
secondlikeafluorescentlamp.Thevertical
frequencyorrefreshrateisthetimesof
imagedisplaypersecond.TheunitisHz.
Horizontalfrequency:Thehorizontalinterval
isthetimetodisplayoneverticalline.When
1isdividedbythehorizontalinterval,the
numberofhorizontallinesdisplayedevery
secondcanbetabulatedasthehorizontal
frequency.TheunitiskHz.
NOTE
background
60
ENG
ENGLISH
IR CODES
Code (Hexa) Function Note
95 R/CBUTTON
08
ON/OFF
R/CBUTTON
0B R/CBUTTON
C4 R/CBUTTON
(DiscreteIRCode)
C5 R/CBUTTON
(DiscreteIRCode)
43 R/CBUTTON
40 Up R/CBUTTON
41 Down R/CBUTTON
07 Left R/CBUTTON
06 Right R/CBUTTON
44
R/CBUTTON
28
R/CBUTTON
5B R/CBUTTON
4D R/CBUTTON
02
Volume
R/CBUTTON
03
Volume
R/CBUTTON
09 R/CBUTTON
E0 ( UP) R/CBUTTON
E1 ( Down) R/CBUTTON
10to19 NumberKey to R/CBUTTON
72
RedKey
R/CBUTTON
71
GreenKey
R/CBUTTON
63 YellowKey R/CBUTTON
61 BlueKey R/CBUTTON
7B R/CBUTTON
5A AV(CVBS) DiscreteIRCode
BF Component DiscreteIRCode
D5 RGB DiscreteIRCode
CE DisplayPort DiscreteIRCode
C6 DVI-D DiscreteIRCode
E9 HDMI DiscreteIRCode
76 (4:3) DiscreteIRCode
77 (16:9) DiscreteIRCode
AF (ZOOM,CinemaZoom1) DiscreteIRCode
79 R/CBUTTON
(DiscreteIRCode)
99 AutoConfig. R/CBUTTON
(DiscreteIRCode)
B1 R/CBUTTON
B0 R/CBUTTON
BA R/CBUTTON
8F R/CBUTTON
8E R/CBUTTON
IR CODES
background
61
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
CONTROLLING THE MULTIPLE PRODUCT
UsethismethodtoconnectseveralproductstoasinglePC.Youcancontrolseveralproductsata
timebyconnectingthemtoasinglePC.
IntheOptionmenu,SetIDmustbebetween1and99withoutbeingduplicated.
Connecting the cable
ConnecttheRS-232Ccableasshowninthepicture.
TheRS-232CprotocolisusedforcommunicationbetweenthePCandproduct.Youcanturnthe
producton/off,selectaninputsourceoradjusttheOSDmenufromyourPC.
Communication Parameter
RS-232C Configurations
PC Set
D-Sub 9 D-Sub 9
(Female) (Female)
PC Set
D-Sub 9 D-Sub 9
(Female) (Female)
BaudRate:9600buadRate(UART)
DataLength:8bit
ParityBit:None
StopBit:1bit
FlowControl:None
CommunicationCode:ASCIIcode
Useacrossed(reverse)cable
7-WireConfigurations(StandardRS-232Ccable)
3-WireConfigurations(NotStandard)
Monitor1 Monitor2 Monitor3 Monitor4
PC
RS-232CCable(notincluded)
background
62
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
Command reference list
COMMAND DATA
1 Power k a 00Hto01H
2 AspectRatio k c 01Hto1FH
3 ScreenMute k d 00Hto01H
4 VolumeMute k e 00Hto01H
5 VolumeControl k f 00Hto64H
6 Contrast k g 00Hto64H
7 Brightness k h 00Hto64H
8 Color k i 00Hto64H
9 Tint k j 00Hto64H
10 Sharpness k k 00Hto64H
11 OSDSelect k l 00Hto01H
12 RemoteLock/keyLock k m 00Hto01H
13 Treble k r 00Hto64H
14 Bass k s 00Hto64H
15 AudioBalance k t 00Hto64H
16 Abnomalstate k z FFH
17 WhiteBalanceRedGain j m 00HtoFEH
18 WhiteBalanceGreenGain j n 00HtoFEH
19 WhiteBalanceBlueGain j o 00HtoFEH
20 ISMmode j p 01Hto08H
21 EnergySaving j q 00Hto05H
22 Autoconfiguration j u 01H
23 RemoconKey m c KeyCode
24 FailOverSelect m i 00Hto02H
25 FailOverInputSelect m j Refer’25.FailOverInputSelect’
26 4HoursOff m n 00Hto01H
27 TileModeCheck d z FFH
28 TileMode d d 00Hto55H
29 TileHPosition d e 00Hto14H
30 TileVPosition d f 00Hto14H
31 TileHSize d g 00Hto64H
32 TileVSize d h 00Hto64H
33 TileIDSet d i 01Hto19H
34 NaturalMode(InTilemode) d j 00Hto01H
35 Picturemode(PSM) d x 00Hto04H
36 Soundmode d y 00Hto05H
37 FanFaultcheck d w FFH
38 Elapsedtimereturn d l FFH
39 Temperaturevalue d n FFH
40 Lampfaultcheck d p FFH
41 Speaker d v 00Hto01H
42 SleepTime f f 00Hto08H
background
63
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
COMMAND DATA
43 AutoSleep f g 00Hto01H
44 PowerOnDelay f h 00Hto64H
45 Language f i 00Hto12H
46 DPMSelect f j 00Hto01H
47 Reset f k 00Hto03H
48 PowerIndicator f o 00Hto01H
49 Serialno. f y FFH
50 S/WVersion f z FFH
51 Time1(Years/Months/Days) f a Referto‘Time1’
52 Time2(Hours/Minutes/Seconds) f x Referto‘Time2’
53 OffTimer(Repeatmode/Time) f e Referto‘OffTimer’
54 OnTimer(RepeatMode/Time) f d Referto‘OnTimer’
55 OnTimerInput f u Referto‘OnTimerInput’
56 HPosition f q 00Hto64H
57 VPosition f r 23Hto41H
58 HSize f s 00Hto64H
59 InputSelect x b 20HtoD0H
60 ColorTemperature x u 00Hto64H
Note:WhenusingtheproductwithaUSBDivXplayer,allcommandsexceptforPower(ka),Key(mc),
Abnormalstate(kz),FanFaultcheck(dw),Elapsedtimereturn(dl),Temperaturevalue(dn),Lamp
faultCheck(dp),Serialno.Check(fy),andS/WVersion(fz)arenotexecutedandhandledaserrors.
background
64
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
Transmission
[Command1][Command2][][SetID][][Data][Cr]
*[Command1]:Firstcommand.(k,j,m,d,f,x)
*[Command2]:Secondcommand.(atou)
*[SetID]:SetuptheSetIDnumberofproduct.
range:01Hto63H.bysetting'0',servercancontrolallproducts.
*Incaseofoperatingwithmorethan2setsusingsetIDas'0'atthesametime,itshouldnotbecheckedtheack
message.Becauseallsetswillsendtheackmessage,soit'simpossiblethecheckthewholeackmessages.
*[DATA]:Totransmitcommanddata.
Transmit'FF'datatoreadstatusofcommand.
*[Cr]:CarriageReturn(ASCIIcode'0x0D')
*[]:ASCIIcodeSpace(0x20)
OK Acknowledgement
[Command2][][SetID][][OK][Data][x]
*TheProducttransmitsACK(acknowledgement)basedonthisformatwhenreceivingnormaldata.Atthistime,
ifthedataisdatareadmode,itindicatespresentstatusdata.Ifthedataisdatawritemode,itreturnsthedataof
thePCcomputer.
Error Acknowledgement
[Command2][][SetID][][NG][Data][x]
*Ifthereiserror,itreturnsNG
Transmission / Receiving protocol
background
65
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
01.Power(Command:ka)
TocontrolPowerOn/Offoftheset.
Transmission
[k][a][][SetID][][Data][Cr]
Data
00:PowerOff
01:PowerOn
Acknowledgement
[a][][SetID][][OK][Data][x]
ToshowthestatusofPowerOn/Off.
Transmission
[k][a][][SetID][][FF][Cr]
Acknowledgement
[a][][SetID][][OK][Data][x]
Data
00:PowerOff
01:PowerOn
03.ScreenMute(Command:kd)
Toselectscreenmuteon/off.
Transmission
[k][d][][SetID][][Data][Cr]
Data
00:Screenmuteoff(Pictureon)
01:Screenmuteon(Pictureoff)
Acknowledgement
[d][][SetID][][OK][Data][x]
02.AspectRatio(Command:kc)
Toadjustthescreenformat.
YoucanalsoadjustthescreenformatusingtheARC
(AspectRatioControl)buttononremotecontrolorin
theScreenmenu.
Transmission
[k][c][][SetID][][Data][Cr]
Data
01:NormalScreen(4:3)
02:WideScran(16:9)
04:Zoom
(AV,Component,HDMI/DisplayPortDTV)
09:JustScan
(Component,HDMI/DisplayPortDTV)
*WhentheRGB,DVI-D,HDMI/DisplayPortPC
mode(1:1)
10to1F:CinemaZoom1to16
(AV,Component,HDMI/DisplayPortDTV)
Acknowledgement
[c][][SetID][][OK][Data][x]
04.VolumeMute(Command:ke)
TocontrolOn/OffoftheVolumeMute.
Transmission
[k][e][][SetID][][Data][Cr]
Data
00:VolumeMuteOn(VolumeOff)
01:VolumeMuteOff(VolumeOn)
Acknowledgement
[e][][SetID][][OK][Data][x]
Data
00:VolumeMuteOn(VolumeOff)
01:VolumeMuteOff(VolumeOn)
05.VolumeControl(Command:kf)
ToadjustVolume.
Transmission
[k][f][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
Acknowledgement
[f][][SetID][][OK][Data][x]
Data
Min:00HtoMax:64H
* Real data mapping
Hexadecimal Num.
(SettingValue)
Decimal Num.
(RealValue)
0 0
A 10
F 15
10 16
20
32
64 100
background
66
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
06.Contrast(Command:kg)
Toadjustscreencontrast.
YoucanalsoadjustthecontrastinthePicturemenu.
Transmission
[k][g][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
Acknowledgement
[g][][SetID][][OK][Data][x]
Data
Min:00HtoMax:64H
*Referto'Realdatamapping’.
09.Tint(Command:kj)
Toadjustthescreentint.
YoucanalsoadjustthetintinthePicturemenu.
Transmission
[k][j][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
00H:StepR50
64H:StepG50
Acknowledgement
[j][][SetID][][OK][Data][x]
DataMin:00HtoMax:64H
*TintRealdatamapping
0:Step0toRed
64:Step100toGreen
07.Brightness(Command:kh)
Toadjustscreenbrightness.
YoucanalsoadjustthebrightnessinthePicture
menu.
Transmission
[k][h][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
*Referto'Realdatamapping’.
Acknowledgement
[h][][SetID][][OK][Data][x]
*Referto'Realdatamapping’.
10.Sharpness(Command:kk)(Videoinputonly)
ToadjustthescreenSharpness.
YoucanalsoadjustthesharpnessinthePicture
menu.
Transmission
[k][k][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
*Referto'Realdatamapping’.
Acknowledgement
[k][][SetID][][OK][Data][x]
Data
Min:00HtoMax:64H
08.Color(Command:ki)(VideoTimingonly)
Toadjustthescreencolor.
YoucanalsoadjustthecolorinthePicturemenu.
Transmission
[k][i][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
*Referto'Realdatamapping’.
Acknowledgement
[i][][SetID][][OK][Data][x]
Data
Min:00HtoMax:64H
11.OSDSelect(Command:kl)
TocontrolOSDon/offtotheset.
Transmission
[k][l][][SetID][][Data][Cr]
Data
00:OSDOff
01:OSDOn
Acknowledgement
[l][][SetID][][OK][Data][x]
Data
00:OSDOff
01:OSDOn
background
67
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
12.RemoteLock/KeyLock(Command:km)
TocontrolRemoteLockon/offtotheset.
Thisfunction,whencontrollingRS-232C,locksthe
remotecontrolandthelocalkeys.
Transmission
[k][m][][SetID][][Data][Cr]
Data
00:Off
01:On
Acknowledgement
[m][][SetID][][OK][Data][x]
Data
00:Off
01:On
15.Balance(Command:kt)
Toadjustthesoundbalance.
Transmission
[k][t][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
00H:StepL50
64H:StepR50
Acknowledgement
[t][][SetID][][OK][Data][x]
Data
Min:00HtoMax:64H
(Hexadecimalcode)
00H:Step0toL50
64H:Step100toR50
*Balance:L50toR50
13.Treble(Command:kr)
Toadjusttreble.
Transmission
[k][r][][SetID][][Data][Cr]
Data
00~64:Treble0~100
Acknowledgement
[r][][SetID][][OK/NG][Data][x]
16.Abnormalstate(Command:kz)
UsedtoReadthepoweroffstatuswhenStand-by
mode.
Transmission
[k][z][][SetID][][Data][Cr]
Data
FF:Read
Acknowledgement
[z][][SetID][][OK][Data][x]
Data
00:Normal(Poweronandsignalexist)
01:Nosignal(Poweron)
02:Turnthemonitoroffbyremotecontrol
03:Turnthemonitoroffbysleeptimefunction
04:TurnthemonitoroffbyRS-232Cfunction
08:Turnthemonitoroffbyofftimefunction
09:Turnthemonitoroffbyautoofffunction
14.Bass(Command:ks)
Toadjustbass.
Transmission
[k][s][][SetID][][Data][Cr]
Data
00~64:Bass0~100
Acknowledgement
[s][][SetID][][OK/NG][Data][x]
background
68
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
17.WhiteBalanceRedGain(Command:jm)
Toadjustwhitebalanceredgain.
Transmission
[j][m][][SetID][][Data][Cr]
Data
00~FE:Redgain0~254
Acknowledgement
[z][][SetID][][OK/NG][Data][x]
20.ISMmode(Command:jp)
Usedtoselecttheafterimagepreventingfunction.
Transmission
[j][p][][SetID][][Data][Cr]
Data
01:Inversion
02:Orbiter
04:WhiteWash
08:Normal
Acknowledgement
[p][][SetID][][OK][Data][x]
18.WhiteBalanceGreenGain(Command:jn)
Toadjustwhitebalancegreengain.
Transmission
[j][n][][SetID][][Data][Cr]
Data
00~FE:Greengain0~254
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
21.EnergySaving(Command:jq)
ToreducethepowerconsumptionoftheMonitor.
Transmission
[j][q][][SetID][][Data][Cr]
Data
04:Auto
00:Off
01:Minimum
02:Medium
03:Maximum
05:Screenoff
Acknowledgement
[q][][SetID][][OK][Data][x]
19.WhiteBalanceBlueGain(Command:jo)
Toadjustwhitebalancebluegain.
Transmission
[j][o][][SetID][][Data][Cr]
Data
00~FE:Bluegain0~25
Acknowledgement
[o][][SetID][][OK/NG][Data][x]
22.AutoConfig.(Command:ju)
Toadjustpicturepositionandminimizeimage
shaking.Automatically.NB:OnlyappliestoRGB(PC)
mode.
Transmission
[j][u][][SetID][][Data][Cr]
Data
01:Toset
Acknowledgement
[u][][SetID][][OK][Data][x]
background
69
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
23.Key(Command:mc)
TosendIRremotekeycode.
Transmission
[m][c][][SetID][][Data][Cr]
Data
Keycode:Referto‘IRCODES’.
Acknowledgement
[c][][SetID][][OK][Data][x]
26.4HoursOff(Command:mn)
Tosetthe4HoursOfffunction.
Transmission
[m][n][][SetID][][Data][Cr]
Data
00:4HoursOffOff
01:4HoursOffOn
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
24.FailOverSelect(Command:mi)
ToselectFailOvermode.
Transmission
[m][i][][SetID][][Data][Cr]
Data
00:Off
01:Auto
02:Manual
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
27.TileModeCheck(Command:dz)
TocheckTileModestatus.
Transmission
[d][z][][SetID][][Data][Cr]
Data
FF:CheckTileModestatus
Acknowledgement
[z][][SetID][][OK/NG][Data1][Data2][Data3][x]
Data1
00:TileModeOff
01:TileModeOn
Data2
00to0F:TileColValue
Data3
00to0F:TileRowValue
25.FailOverInputSelect(Command:mj)
Toselectfailovermode.
*OnlyavailableinFailOvermanualmode.
Transmission
[m][j][][SetID][][Data1][][Data2][][Data3]
[][Data4][Cr]
Data(Priority1~4)
60:RGB
70:DVI-D
90:HDMI
C0:DisplayPort
*Use0x70asdataforDVI-Dinput,0x90asdata
forHDMIinput,0xC0asdataforDisplayPortinput,
regardlesstheirinputlabels.
Acknowledgement
[j][][SetID][][OK/NG][Data1][Data2][Data3][x]
background
70
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
28.TileMode(Command:dd)
ChangeaTileMode.
Transmission
[d][d][][SetID][][Data][Cr]
Data Description
00or11 Tilemodeisoff.
12 1x2mode(columnxrow)
13 1x3mode
14 1x4mode
...
...
55 1x2mode
*Thedatacannotbesetto0XorX0except00.
Acknowledgement
[d][][SetID][][OK/NG][Data][x]
31.TileHSize(Command:dg)
TosettheHorizontalsize.
Transmission
[d][g][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
*Referto'Realdatamapping’.
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
32.TileVSize(Command:dh)
TosettheVerticalsize.
Transmission
[d][h][][SetID][][Data][Cr]
Data
Min:00HtoMax:64H
*Referto'Realdatamapping’.
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
30.TileVPosition(Command:df)
TosettheVerticalposition.
Transmission
[d][f][][SetID][][Data][Cr]
Data
Min:00HtoMax:14H
00H:Step-10(Down)
14H:Step10(Up)
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
29.TileHPosition(Command:de)
TosettheHorizontalposition.
Transmission
[d][e][][SetID][][Data][Cr]
Data
Min:00HtoMax:14H
00H:Step-10(Left)
14H:Step10(Right)
Acknowledgement
[e][][SetID][][OK/NG][Data][x]
33.TileIDSet(Command:di)
ToassigntheTileIDforTilingfunction.
Transmission
[d][i][][SetID][][Data][Cr]
Data
Min:01HtoMax:19H
(Hexadecimalcode)
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
background
71
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
34.NaturalMode(Command:dj)
ToassigntheTileNaturalmodeforTilingfunction.
Transmission
[d][j][][SetID][][Data][Cr]
Data
00:NaturalOff
01:NaturalOn
ff:ReadStatus
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
37.FanFaultcheck(Command:dw)
TochecktheFanfaultoftheSet.
Transmission
[d][w][][SetID][][Data][Cr]
*ThedataisalwaysFF(inHex).
Data
ff:ReadStatus
Acknowledgement
[w][][SetID][][OK/NG][Data][x]
*DataisthestatusvalueoftheFanfault.
Data
00:Fanfault
01:FanOk
02:N/A(NotAvaliable)
38.Elapsedtimereturn(Command:dl)
Toreadtheelapsedtime.
Transmission
[d][l][][SetID][][Data][Cr]
*ThedataisalwaysFF(inHex).
Acknowledgement
[l][][SetID][][OK/NG][Data][x]
*ThedataisalwaysFF(inHex).
(Hexadecimalcode)
36.SoundMode(Command:dy)
ToadjusttheSoundmode.
Transmission
[d][y][][SetID][][Data][Cr]
DataStructure
Data(Hex) Mode
01 Standard
02 Music
03 Cinema
04 Sport
05 Game
Acknowledgement
[y][][SetID][][OK/NG][Data][x]
35.PictureMode(Command:dx)
Toadjustthepicturemode.
Transmission
[d][x][][SetID][][Data][Cr]
DataStructure
Data(Hex) Mode
00 Vivid
01 Standard
02 Cinema
03 Sport
04 Game
Acknowledgement
[x][][SetID][][OK/NG][Data][x]
39.Temperaturevalue(Command:dn)
Toreadtheinsidetemperaturevalue.
Transmission
[d][n][][SetID][][Data][Cr]
*ThedataisalwaysFF(inHex).
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
*Thedatais1bytelonginHexadecimal.
background
72
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
40.LampfaultCheck(Command:dp)
Tochecklampfault.
Transmission
[d][p][][SetID][][Data][Cr]
*ThedataisalwaysFF(inHex).
Acknowledgement
[p][][SetID][][OK/NG][Data][x]
*Thedatais1bytelonginHexadecimal.
Data
00:LampFault
01:LampOk
02:N/A(DPM/PowerOff)
43.AutoSleep(Command:fg)
SetAutoSleep.
Transmission
[f][g][][SetID][][Data][Cr]
Data
00:Off
01:On
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
44.PowerOnDelay(Command:fh)
Setthescheduledelaywhenthepoweristurnedon
(Unit:second).
Transmission
[f][h][][SetID][][Data][Cr]
Data
00Hto64H(Datavalue)
*Referto'Realdatamapping’.
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
42.SleepTime(Command:ff)
SetSleepTime.
Transmission
[f][f][][SetID][][Data][Cr]
Data
00:Off
01:10
02:20
03:30
04:60
05:90
06:120
07:180
08:240
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
41.Speaker(Command:dv)
Turnthespeakeronoroff.
Transmission
[d][v][][SetID][][Data][Cr]
Data
00:Off
01:On
Acknowledgement
[v][][SetID][][OK/NG][Data][x]
background
73
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
47.Reset(Command:fk)
ExecutethePicture,ScreenandFactoryReset
functions.
Transmission
[f][k][][SetID][][Data][Cr]
Data
00:PictureReset
(ResetthevaluessetinthePICTUREmenu.)
01:ScreenReset
(ResetthevaluessetinundertheScreenoption.)
02:FactoryReset
(ResetthevaluessetintheOPTIONmenu.)
03:AudioReset
(ResetthevaluessetintheAUDIOmenu.)
Acknowledgement
[k][][SetID][][OK/NG][Data][x]
48.PowerIndicator(Command:fo)
TosettheLEDforPowerIndicator
Transmission
[f][o][][SetID][][Data][Cr]
Data
00:Off
01:On
Acknowledgement
[o][][SetID][][OK/NG][Data][x]
46.DPMSelect(Command:fj)
SettheDPM(DisplayPowerManagement)function.
Transmission
[f][j][][SetID][][Data][Cr]
Data
00:Off
01:On
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
45.Language(Command:fi)
SettheOSDlanguage.
Transmission
[f][i][][SetID][][Data][Cr]
Data
00:Czech
01:Danish
02:German
03:English
04:Spanish(EU)
05:Greek
06:French
07:Italian
08:Dutch
09:Norwegian
0a:Portuguese(EU)
0b:Portuguese(Brazil)
0c:Russian
0d:Finnish
0e:Swedish
0f:Korean
10:SimplifiedChinese
11:Japanese
12:TraditionalChinese
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
49.Serialno.Check(Command:fy)
ChecktheSerialno.
Transmission
[f][y][][SetID][][Data][Cr]
Data
FF(toreadtheserialnumbers)
Acknowledgement
[y][][SetID][][OK/NG][Data1]to[Data13][x]
*ThedataformatisASCIICode.
background
74
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
50.S/WVersion(Command:fz)
Checkthesoftwareversion.
Transmission
[f][z][][SetID][][Data][Cr]
Data
FFH:Read
Acknowledgement
[z][][SetID][][OK/NG][Data][x]
53.OffTimer(RepeatMode/Time)(Command:fe)
TosettheOffTimer(Repeatmode/Time)function.
Transmission
[f][e][][SetID][][Data1][][Data2][][Data3][Cr]
Data1
00:RepeatOff
01:RepeatOnce
02.RepeatDaily
03:RepeatfromMondaytoFriday
04:RepeatfromMondaytoSaturday
05:RepeatfromSaturdaytoSunday
06.RepeatonSunday
Data2
00to17:00to23Hours
Data3
00to3B:00to59Minutes
*Enter“fe[SetID]ff”forcheckingOffTimer(Repeat
mode/Time)values.
*CheckifTime1andTime2havebeensetbefore
settingthisfunction.
Acknowledgement
[e][][SetID][][OK/NG][Data1][Data2][Data3][x]
52.Time2(Hour/Minute/Second)(Command:fx)
TosettheTime2(Hour/Minute/Second)values.
Transmission
[f][x][][SetID][][Data1][][Data2][][Data3][Cr]
Data1
00to17:00to23hours
Data2
00to3B:00to59minutes
Data3
00to3B:00to59seconds
*Enter“fx[SetID]ff”forcheckingTime2values.
**Thiscommandwon’tworkifTime1hasnotbeen
setinadvance.
Acknowledgement
[x][][SetID][][OK/NG][Data1][Data2][Data3][x]
51.Time1(Year/Month/Day)(Command:fa)
TosettheTime1(Year/Month/Day)values.
Transmission
[f][a][][SetID][][Data1][][Data2][][Data3][Cr]
Data1
00to14:2010to2030
Data2
01to0C:JanuarytoDecember
Data3
01to1F:1to31
*Enter“fa[SetID]ff”forcheckingTime1values.
Acknowledgement
[a][][SetID][][OK/NG][Data1][Data2][Data3][x]
background
75
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
54.OnTimer(RepeatMode/Time)(Command:fd)
TosettheOnTimer(Repeatmode/Time)function.
Transmission
[f][d][][SetID][][Data1][][Data2][][Data3][Cr]
Data1
00:RepeatOff
01:RepeatOnce
02.RepeatDaily
03:RepeatfromMondaytoFriday
04:RepeatfromMondaytoSaturday
05:RepeatfromSaturdaytoSunday
06.RepeatonSunday
Data2
00to17:00to23Hours
Data3
00to3B:00to59Minutes
*Enter“fd[SetID]ff”forcheckingOnTimer(Repeat
mode/Time)values.
*CheckifTime1andTime2havebeensetbefore
settingthisfunction.
Acknowledgement
[d][][SetID][][OK/NG][Data1][Data2][Data3][x]
55.OnTimerInput(Command:fu)
TosettheOnTimerInputfunction.
Transmission
[f][u][][SetID][][Data][Cr]
Data
20:AV
40:Component
60:RGB
70:DVI-D
90:HDMI
C0:DisplayPort
*CheckifTime1andTime2andOnTimer(Repeat
Mode/Time)functionshavebeensetbeforesetting
thisfunction.
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
58.HSize(Command:fs)
TosettheHorizontalsize.
*OnlyavailableforTileOffmode.
Transmission
[f][s][][SetID][][Data][Cr]
Data
00~64:Size-50~+50
Acknowledgement
[s][][SetID][][OK/NG][Data][x]
57.VPosition(Command:fr)
TosettheVerticalposition.
*OnlyavailableforTileOffmode.
Transmission
[f][r][][SetID][][Data][Cr]
Data
23~41:Bottom15~Top15
Acknowledgement
[r][][SetID][][OK/NG][Data][x]
56.HPosition(Command:fq)
TosettheHorizontalposition.
*OnlyavailableforTileOffmode.
Transmission
[f][q][][SetID][][Data][Cr]
Data
00~64:Left50~Right50
Acknowledgement
[q][][SetID][][OK/NG][Data][x]
background
76
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
59.InputSelect(Command:xb)
ToselectinputsourcefortheSet.
Transmission
[x][b][][SetID][][Data][Cr]
Data
20:AV(CVBS)
40:Component
60:RGB(PC)
70:DVI-D
90:HDMI(DTV)
A0:HDMI(PC)
C0:DisplayPort(DTV)
D0:DisplayPort(PC)
Acknowledgement
[b][][SetID][][OK/NG][Data][x]
60.ColorTemperature(Command:xu)
Toadjustthescreencolortemperature.
Transmission
[x][u][][SetID][][Data][Cr]
Data
00~64:Warm50~Cool50
Acknowledgement
[u][][SetID][][OK][Data][x]
background
Make sure to read the Safety Precautions
before using the product.
Keep the Owner's Manual(CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
MODEL
SERIAL
Temporarynoiseisnormalwhenpowering ONor
OFFthisdevice.
WARNING-ThisisaclassAproduct. In adomestic
e n v i r o n m e n t t h i s p r o d u c t m a y c a u s e r a d i o
interferenceinwhichcasetheusermaybe required
totakeadequatemeasures.
Warrantyvoidifremoved.
Important
WARRANTYVOID
IFREMOVED
3850TAZ209Y
To obtain the source code under GPL, LGPL,
MPL and other open source licenses, that is
contained in this product, please visit http://
opensource.lge.com.
In addition to the source code, all referred
license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source
code to you on CD-ROM for a charge covering
the cost of performing such distribution (such
as the cost of media, shipping and handling)
upon email request to opensource@lge.com.
This offer is valid for three (3) years from the
date on which you purchased the product.
background
P/NO : 3840TRL098E (0801-REV00)
www.lge.com

Specifications

LG Electronics 72WS70MS-B Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

Product LG Electronics RS501 image
LG Electronics RS501 Lg K20 Lra
2020-10-25 1 docs
Product LG Electronics LGP925G image
LG Electronics LGP925G Lg Optimus 3d
2020-10-17 1 docs
No image
LG Electronics 65NU850BAUA 55 Inch Class LG 4K Nano UHD TV AI NU85 Smart TV 2026 - 55NU850BAUA.AUS
2026-05-22 2 docs
No image
LG Electronics 85NU700BPUA 50 Inch Class LG 4K Nano UHD TV AI NU70 Smart TV 2026 - 50NU700BPUA.AUS
2026-05-22 2 docs
No image
LG Electronics 85QNED74BUA 43 Inch Class LG QNED AI QNED74B Mini LED 4K Smart TV 2026 - 43QNED74BUA.AUS
2026-05-22 2 docs
No image
LG Electronics LRFLC2726S 27 cu. ft. Smart Counter-Depth French Door Refrigerator -
2026-05-22 4 docs
