©2019 Hestan Commercial Corporation
1
EN
COLORED PANEL
REPLACEMENT
CABINETRY - AGCP SERIES
IMPORTANT - READ ALL INSTRUCTIONS BEFORE YOU BEGIN
THE INSTRUCTIONS HEREIN SHOULD BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN.
IF CABINET OR DRAWER IS NEAR AN APPLIANCE, IT MUST BE COMPLETELY COOL AND THE GAS
SOURCE MUST BE SHUT OFF. THE POWER MUST BE DISCONNECTED.
Some parts inside your cabinet or drawer have sharp edges. Care must be
taken when handling the various components to avoid personal injury. Wear
gloves when handling.
TOOLS REQUIRED:
Flat and Phillips screwdrivers
PART REPLACEMENT - TYPICAL DOOR (VARIOUS PRODUCTS)
1. Unclip door hinge from frame. Consult the
Installation Manual 009798 or 009799 which came
with your cabinet product. If door was part of a
Grill Cart, consult the manual which came with
the cart.
Remove the hinges from the back face of the door
as shown in Fig. 1.
FIG. 1
2. Lay the door on a flat surface with a blanket or
towel to protect the door finish. Remove the door
liner by removing all screws as shown in Fig. 2.
FIG. 2
