Visit our website for additional help and instructional videos: www.ihomeaudio.com/support/airplay/
10:09 PM
Livingroom Speaker
Name
SaveCancel
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
This name will be displayed when selecting your
speaker from a list of available AirPlay devices.
Wi-Fi Networks
10:09 PM
Your Wi-Fi Network
Choose a Network for iW2...
Other Wi-Fi Network
Settings
Other Wi-Fi Network
Other Wi-Fi Network
Other Wi-Fi Network
Step 2 - Network Setup for AirPlay
2
Connect your iOS device to the iW2
using the included USB sync cable.
1
Verify that the iW2 is powered on.
1
Verify that the iW2 is powered on.
Rename your iW2 speaker, press ‘Save’, and proceed
to Step 3 if connected to your Wi-Fi network.
5
Note: Ethernet cable not included. To revert back to setup option A or B unplug ethernet cable and re-boot iW2.
Option C - Connecting directly via Ethernet
Connected Not Connected Problem?
1. Verify that the Network Status LED is green to confirm if the iW2 is successfully connected to a network.
2. Disconnect your Mac/PC from “iHome Setup ######” and then connect your computer to the same network
the iW2 is on.
3. Keep reading to learn how to use the iW2 and control your iTunes and iOS audio content.
Success!
Reset the iW2 Speaker:
- Unplug power, wait 30 seconds then reconnect
- Press & hold power button (3 seconds)
- Repeat iW2 Wi-Fi Network Setup process if necessary
If the Network Status LED is flashing red, the iW2 is
not connected to a network because, either:
- The iW2 has not been connected to a Wi-Fi network
- There is a problem with your Wi-Fi network
- Or, the iW2 is out of range
If the Network Status LED is green, the iW2 is
connected to a network
Connecting to a network may take up to 2 minutes.
Make sure you have your password ready.
30-120s
Not Connected
Status
Connected
Status
Wi-Fi
Name
Not Connected
iHome iW2
Select above to change the iW2 network
settings and to set the name your speaker will
use to appear on the Network.
How to use AirPlay
About iHome Connect
10:09 PM
Connect
10:09 PM
Download our free iHome Connect app from
the App Store and launch.
3
Option B - Connecting with your Mac or PC over Wi-Fi
Rename the iW2 speaker and click ‘Save’.
(optional)
5
Network Setup
Device Name
Save
Current Network:
This name will be displayed when selecting your speaker from a list
of available AirPlay devices.
Connect the iW2 speaker to the same network as your AirPlay
source (iTunes, iPad, iPhone, or iPod touch(.
iHome iW2
Available Networks
http://192.168.1.12
Launch a web browser (ex. Safari or Explorer) and
enter http://192.168.1.12 in the address bar.
4
- If the page is not initially available, reload the page.
If at any point the page becomes unresponsive, reload the page.
If problem persists, see “Troubleshooting”.
30-120s
15s
If the Status LED continues to flash green for more than 2 minutes,
reset the iW2 speaker and repeat the Wi-Fi Network Setup process.
Select preferred Wi-Fi network from the list of
available and click ‘Join Network’.
6
1
Disconnect AC power cable.
2
Connect ethernet cable to the
iW2 and router (or network).
3
Connect AC power cable and
power ON iW2.
directly connect to router or wall
ethernet port
Option A - Connecting with your iPod touch, iPhone, or iPad over Wi-Fi
Network Setup
Device Name
Save
Current Network:
View Network Details
This name will be displayed when selecting your speaker from a list
of available AirPlay devices.
Connect the iW2 speaker to the same network as your AirPlay
source (iTunes, iPad, iPhone, or iPod touch).
iHome Setup
iHome Bedroom
Available Networks
Network Setup
Device Name
Save
Current Network:
View Network Details
This name will be displayed when selecting your speaker from a list
of available AirPlay devices.
Connect the iW2 speaker to the same network as your AirPlay
source (iTunes, iPad, iPhone, or iPod touch).
iHome Setup
iHome Bedroom
Available Networks
Join Network
Step 1 - Getting Started
power adaptorStart Guide iW2 Speaker
What’s in the Box
USB sync
cable
Check list before proceeding to Step 2
Powering on the iW2
outlet
press & hold power button (3 seconds) to power unit ON
connect to power source
1 2
To enjoy AirPlay wireless audio, you must have the following:
- iTunes or an iOS device (iPod touch, iPhone, or iPad).
- A functioning home network with Wi-Fi.
Download the latest software updates for iTunes and your iOS device to ensure that you are able to enjoy the latest
AirPlay enhancements and compatibility.
Download the iHome Connect app for iPod touch, iPhone and iPad.
Have your Wi-Fi network name (SSID) and password (if applicable) available for reference.
Verify that your Wi-Fi network and router is discoverable.
If you use security for your network, use WPA/WPA2 security (not WEP or WPA/WPA2 enterprise)
If you use Ethernet, please enable your router DHCP function.
Note: AirPlay requires iTunes 10.1 (Mac and PC) or later; OR an iPad, iPad 2, iPhone 4, iPhone 3GS, iPod touch (4th, 3rd,
and 2nd generations) with iOS 4.2 or later. The iHome Connect app requires iOS 4.0 or later.
Overview
Controls and Indicators
allow 20 seconds to allow system to startup
remote
reset
bass treble
Rz14
3
select the network called "iHome Setup
######" from Wi-Fi network settings on
your Mac or PC.
upper right corner of
Mac screen
lower right corner of
PC Screen
30s
30s
AirPort: On
Turn AirPort Off
Your Wi-Fi network
Another network
Another network
iHome Setup ######
Join Other Nework...
Create Network...
Open Network Preferences...
YOUR Wi-Fi NETWORK
iHome Setup ######
Open Network and Sharing Center
9:42
01/15/2011
Internet access
Connect
Information sent over this network
miight be visible to others.
Currently connected to:
Press and hold (3 sec.) Network Setup button
on the back of unit.
2
network setup
status
power
press & hold power button (3 seconds)
to power ON iW2
Customize
speaker name
Select your
Wi-Fi network
4
Select your preferred Wi-Fi network from the
list of available networks.
The Network Status LED will soon begin flashing
green and the top control panel will also flash.
status LED
power
aux-in
network setupstatus
12V 3A
USB Port
(Sync, Charge, Play and firmware updates)
AC power
ethernet
(direct network connection)
REAR PANEL
TOP PANEL
Wi-Fi network status LED
Wi-Fi network setup
firmware status LED
volume
iPod and iTunes
music controls
aux-in
power
AirPlay Wireless Audio mode
(audio via iOS device or iTunes)
Local iPod Audio mode
(play audio via USB sync cable or aux-in)
aux-in
network setupstatus
12V 3A
12V
12V
network setup
status
network setup
status
iW2 Start Guide
Visit our website for additional help and how-to videos
www.ihomeaudio.com/support/airplay/
