QuickStand 5-Second Series is a large venue free-standing "pull-up" projection screen. Its portable design makes it ideal for
conference rooms and large group presentations on the go.
Scan for product
video
2016 QuickStand 5-Second Series Product Brochure
QuickStand 5-Second Series
QuickStand 5-Second Series is a large venue free-standing "pull-up" projection screen. Its portable design
makes it ideal for conference rooms and large group presentations on the go.
1
www.elitescreens.com/qs5sec
The QuickStand 5-Second Series is a large venue free-standing "pull-up" projection screen. Its portable design makes it ideal for
conference rooms and large group presentations on the go. Other large screen may require more than a half hour to assemble, attach
the material and adjust to the right height. The QS 5-Second Screen's primary advantage is speed. It utlizes an innovative dual cross
spring mechanism that allows it to be set up in seconds.
The QuickStand 5-Second Screen is a hassle free versatile solution that can rise out of its casing to the desired height in as little as
5-seconds. It uses Elite's MaxWhite FG 1.1 Gain material with wide diffusion uniformity and is encased in an ATA wheeled aluminum
stage case for added durability during heavy travel and regular venue applications.
Screen Material
• MaxWhite Fiberglass ensures flat projection surface
• 180º wide diffusion viewing angle for large audiences
• Black masking borders enhance picture contrast
• Black-backing eliminates light penetration
Design and Setup
• Built-in ATA stage case design for professional road crews or casual presentations
• Fast-operating portable presentation screen quickly sets up in seconds
• Free-standing Large venue screen quickly sets up in seconds
• Wheeled for quick mobility and incudes handles
• Drape Kit inluded for enhanced aesthetics
Quality and Reliability
• Screen is encased in a durable aluminum stage case
• Dual-scissor support system
• Standard 2-year premium warranty
• 3-year ENR-G warranty for Education, Non-profit, Religious, and Government
• GREENGUARD Gold Certified
Scan for product
video
2
www.elitescreens.com/qs5sec
Note: Data Error ±1". The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture
modification. Although a manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable for faulty installations.
Model
Screen Diag. &
Aspect Ratio
View Height
(in)
View Width
(in)
View Height
(cm)
View Width
(cm)
N.W.
(lbs.)
G.W.
(lbs.)
Net Wt.
(Kgs)
G.W.
(Kgs)
Packing Dimensions
(LxHxW)
Gain Screen Material Case Color
Drape Kit
Included
QS150HD 150"(16:9) 73.6 130.7 186.9 332.0 147.7 163.1 67.0 74.0 143.1"X11.8"X11.8" 1.1 MaxWhite FG Black/Silver Yes
QS163VD 163"(4:3) 97.8 130.4 248.4 331.2 Please visit www.elitescreens.com 1.1 MaxWhite FG Black/Silver Yes
QS180HD
180"(16:9) 88.3 156.9 224.3 398.5 160.9 179.9 73.0 81.6 171.6"x11.8"x11.8" 1.1 MaxWhite FG Black/Silver Yes
QuickStand 5-Second Series
Model
Screen Diag. &
Aspect Ratio
Case
Length (A)
Screen
Width (A1)
View Width
(A2)
L/R Border
(A3)
Top Bar
Length (A4)
A5 A6
Overall
Height (B)
Bottom
Border (B1)
View Height
(B2)
Top Black Border
(B3)
B4
QS150HD 150"(16:9) 3525 3421 3321 50 3451 1560 1850 3303 1219 1868 120 1210
QS163VD 163"(4:3) 3525 3412 3312 50 3415 1850 1560 3303 610 2484 120 594
QS180HD 180"(16:9) 4240 4085 3985 50 4115 2050 2140 3347 889 2242 120 860
Unit: mm
Model
Screen Diag. &
Aspect Ratio
Case
Length (A)
Screen
Width (A1)
View Width
(A2)
L/R Border
(A3)
Top Bar
Length (A4)
A5 A6
Overall
Height (B)
Bottom
Border (B1)
View Height
(B2)
Top Black Border
(B3)
B4
QS150HD 150"(16:9) 138.8 134.7 130.7 2.0 135.9 61.4 72.8 130.0 48.0 73.5 4.7 47.6
QS163VD 163"(4:3) 138.8 134.3 130.4 2.0 134.4 72.8 61.4 130.0 24.0 97.8 4.7 23.4
QS180HD 180"(16:9) 166.9 160.8 156.9 2.0 162.0 80.7 84.3 131.8 35.0 88.3 4.7 33.9
Unit: inch
QuickStand 5-Second Dimensions Table
