4-433-536-81(1)
1
Installing speakers
Installation des enceintes
2
Connecting the speakers
Raccordement des enceintes
STR-DA5800ES
Quick Setup Guide
Guide d’installation rapide
This Quick Setup Guide describes how to connect speakers, a
subwoofer, a monitor, and a Blu-ray Disc Player so that you can enjoy
multi-channel surround sound. Refer to the operating instructions
supplied with the receiver for details.
Ce Guide d’installation rapide décrit la procédure de connexion des
enceintes, d’un caisson de graves, d’un écran et d’un lecteur de
disque Blu-ray afin de pouvoir écouter du son surround multicanal.
Pour plus de détails, reportez-vous au mode d’emploi fourni avec
l’ampli-tuner.
Installing speakers
Installation des enceintes
Connecting the speakers
Raccordement des enceintes
Connecting the monitor
Racco
rdement de l’écran
Conn
ecting a Blu-ray Disc Player
Raccordement d’un lecteur
Blu-ray Disc
Connect all power cords last
Raccordez tous les cordons
d’alimentation e
n dernier lieu
Turning on the r
eceiver
Mise sous tension de l’ampli-
tuner
Setting up the receiver
Configuration de l
’ampli-tuner
The illustration on the left shows an example of a 9.1 channel speaker system using 9 speakers (front, front high, surround, surround
back, and center speakers) and one subwoofer. The illustration on the right shows an example of a 7.1 channel speaker system using 7
speakers (front, surround, surround back, and center speakers) and one subwoofer.
L’illustration à gauche montre un exemple d’une chaîne stéréophonique de 9.1canaux utilisant 9enceintes (enceintes avant, avant
supérieures, surround, surround arrière et centrale) et un caisson de graves. L’illustration à droite montre un exemple d’une chaîne
stéréophonique de 7.1canaux utilisant 7enceintes (enceintes avant, surround, surround arrière, et centrale) et un caisson de graves.
10 mm (13/32")
Front left speaker
Enceinte avant gauche
Front right speaker
Enceinte avant droite
Center speaker
Enceinte centrale
Surround left speaker
Enceinte surround gauche
Surround right speaker
Enceinte surround droite
Surround back left speaker
Enceinte surround arrière gauche
Surround back right speaker
Enceinte surround arrière droite
Left high speaker
Enceinte gauche supérieure
Right high speaker
Enceinte droite supérieure
Subwoofer
Subwoofer
Connecting the Lighting Control
Adapter
Branchement du Lighting Control
Adapter
© 2014 Sony Corporation Printed in Malaysia
