OWNER’S MANUAL
Remote
Level
Mode
All
|
5- 8
|
7&8
Input Mode
2 Ch.
|
4 Ch.
|
8 Ch.
CH. 7
(
L
)
CH. 8
(
R
)
CH. 7 & 8
Filter Mode
Filter Freq. (Hz)
Input
Sens.
O
|
HP
|
LP
CH. 5
(
L
)
CH. 6
(
R
)
CH. 3
(
L
)
CH. 4
(
R
)
CH. 1
(
L
)
CH. 1 & 2
CH. 3 & 4 CH. 5 & 6
CH. 2
(
R
)
Filter Mode
Filter Freq. (Hz)
Input
Sens.
O
|
HP
|
LP
Filter Mode
Filter Freq. (Hz)
Input
Sens.
O
|
HP
|
LP
Filter Mode
Filter Freq. (Hz)
Input
Sens.
O
|
HP
|
LP
CH. 1
CH. 2
CH. 3
CH. 4
CH. 5
CH. 6
(
L
)
(
R
)
CH. 7
CH. 8
INPUT SECTION
+12 VDC Ground Remote
Turn-On
Mode
Rem.
|
Oset
|
Signal
Input Voltage
Low
|
High
2 Ch. Input 1 feeds CH. 1, CH. 3, CH. 5 & CH. 7
Input 2 feeds CH. 2, CH. 4, CH. 6 & CH. 8
4 Ch. Input 1 feeds CH. 1 & CH. 3
Input 2 feeds CH. 2 & CH. 4
Input 5 feeds CH. 5 & CH. 7
Input 6 feeds CH. 6 & CH. 8
8 Ch. Each input feeds its
corresponding output channel
INPUT MODES:
Marine 8 Channel Amplifier
Thank you for purchasing a JL Audio amplifier for
your marine sound system.
Your amplifier has been designed and manufactured to exacting
standards in order to ensure years of musical enjoyment in your vessel.
For maximum performance, we highly recommend that you have
your new amplifier installed by an authorized JL Audio dealer. Your
authorized dealer has the training, expertise and installation equipment
to ensure optimum performance from this product. Should you
decide to install the amplifier yourself, please take the time
to read this manual thoroughly so as to familiarize yourself
with its installation requirements and setup procedures.
If you have any questions regarding the instructions in this
manual or any aspect of your amplifier’s operation, please contact your
authorized JL Audio dealer for assistance. If you need further assistance,
please call the JL Audio Technical Support Department
at (954) 443-1100 during business hours.
800W Marine 8 Channel Amplier
