Installation
Instructions
BEFORE YOU BEGIN
Read these instructions carefully and completely.
• IMPORTANT — Save these instructions
for local inspector’s use.
• IMPORTANT — Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Product failure due to improper installation is not
covered under the Warranty.
•
WARNING
This appliance must be properly
grounded.
• ATTENTION INSTALLER
ALL COOKTOPS MUST BE HARD WIRED
(DIRECT WIRED) INTO AN APPROVED
JUNCTION BOX. A “PLUG AND RECEPTACLE”
IS NOT PERMITTED ON THESE PRODUCTS.
• Proper installation is the responsibility of the
installer and product failure due to improper
installation is NOT covered under warranty.
30 and 36”
Electric Cooktop - Radiant
Excludes Down-Draft Models
MATERIALS YOU WILL NEED
TOOLS NEEDED
CUTTING THE COUNTERTOP
If you are installing the cooktop in a solid surface
material such as granite, quartz or any other natural
or synthetic solid surface, we recommend that the
cutout be prepared by a professional cabinet or
countertop installer.
Cooktop cutouts in wood or wood-laminate
countertops may be able to be prepared using a
saber saw and electric drill.
PARTS INCLUDED
31-11072-4 01-19 GEA
Wire NutsJunction Box
Saber Saw
Pencil
Safety Glasses
1/8” Drill Bit & Electric or
Hand Drill
Ruler or Straightedge
Phillips Head
Screwdriver
2 Hold Down
Brackets
4 Screws
(WB01X1137)
Foam Tape
WB06K5042
90º or Straight
Squeeze Connector
for 1” Conduit
Questions? Call us at 1.800.432.2737 or visit GEAppliances.com.
In Canada, call 1.800.561.3344 or visit GEAppliances.ca.
