Dryer
User Manual
LTK 21003W
Please read these instructions first before using your appliance
Thank you for choosing a Blomberg appliance.
Please take some time to read this user manual before using your appliance, to ensure you
know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the appliance is correctly
connected and fitted prior to use.
Please write your product model and serial number on the last page of this user manual, and
store in a safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences between
models will be listed.
If you have any questions or concerns, please call our contact centre or find help and
information online at www.blomberguk.com
Explanation of symbols used throughout this User Manual
Read the instructions.
C
Important information or useful hints about usage.
A
Warning for hazardous situations with regard to life and property.
B
Warning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
1 Important safety and environmental
instructions
1.1 General safety .....................................4
1.1.1 Electrical safety .............................5
1.1.2 Product safety................................6
1.2 Mounting over a washing machine ......8
1.3 Intended use ...................................... 10
1.4 Child safety ........................................ 10
1.5 Compliance with the WEEE regulation
and disposing of the waste product ......... 11
1.6 Compliance with RoHS Directive:......11
1.7 Package information ..........................11
1.8 Technical specifications .....................12
2 Your Dryer 13
2.1 Overview............................................13
2.2 Package contents ..............................14
3 Installation 15
3.1 Appropriate installation location ......... 15
3.2 Removing the transportation safety
assembly .................................................15
3.3 Connecting to the drain .....................15
3.4 Adjusting the feet ...............................16
3.5 Electrical connection..........................16
3.6 Transportation of the dryer ................16
3.7 Changing the illumination lamp ........16
4 Electrical Connection 17
4.1 Attention!............................................17
4.2 Electrical requirements ......................17
4.3 Fitting a different plug .......................17
4.4 Washer/dryer combination ................. 17
5 Preparation 18
5.1 Laundry suitable for drying in the dryer 18
5.2 Laundry not suitable for drying in the
dryer ........................................................18
5.3 Preparing laundry for drying ..............18
5.4 Things to be done for energy saving .18
5.5 Correct load capacity ......................... 19
6 Operating the product 20
6.1 Control panel .....................................20
6.2 Screen symbols .................................20
6.3 Preparing the machine ......................21
6.4 Programme selection.........................21
6.5 Main Programmes .............................21
6.6 Extra Programmes.............................21
6.7 Programme selection and consumption
table ......................................................... 23
6.8 Auxiliary functions .............................. 24
6.9 Warning symbols ...............................24
6.10 End duration ....................................24
6.11 Starting the Programme ...................25
6.12 Child Lock ........................................ 25
6.13 Changing the Programme after it is
started......................................................25
6.14 Cancelling the Programme ..............26
6.15 Programme end ............................... 26
7 Maintenance and cleaning 27
7.1 Cleaning Lint Filter / Loading Door Inner
Surface ....................................................27
7.2 Cleaning the sensor ..........................28
7.3 Draining the water tank......................28
7.4 Cleaning the condenser;....................29
8 Troubleshooting 30
TABLE OF CONTENTS
Dryer / User Manual4 / EN
1 Important safety and environmental
instructions
This section contains safety instructions that will help protect
from risk of personal injury or property damage. Failure to
follow these instructions shall void any warranty.
1.1 General safety
• The dryer can be used by children at and above 8
years old and by persons whose physical, sensory or
mental capabilities were not fully developed or who
lack experience and knowledge provided that they are
supervised or trained on the safe usage of the product
and the risks it brings out. Children should not play with
the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by
someone.
• Children of less than 3 years should be kept away unless
continously supervised.
• Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced with
materials such as carpet, wood and tape. This will cause
problems with the dryer.
• Always have the installation and repairing procedures
carried out by the Authorised Service. Manufacturer
shall not be held liable for damages that may arise from
procedures carried out by unauthorised persons.
• Never wash the dryer by spraying or pouring water onto it!
There is the risk of electric shock!
Dryer / User Manual 5 / EN
1.1.1 Electrical safety
A
Electrical safety instructions should be followed while
electrical connection is made during the installation.
A
The appliance must not be supplied through an
external switching device, such as a timer,or
connected to a circuit that is regularly switched on
and off by utility.
• Connect the dryer to a grounded outlet protected by a
fuse at the value specified on the type label. Have the
grounding installation performed by a qualified electrician.
Our company shall not be liable for any damages that
will arise when the dryer is used without grounding in
accordance with the local regulations.
• The voltage and allowed fuse protection is stated on the
type label plate.
• The voltage specified on the type label must be equal to
your mains voltage.
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation,
maintenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by
pulling on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to
connect the dryer to power supply in order to decrease the
risk of fire and electric shock.
• Power cable plug must be easily accessible after
installation.
Important safety and environmental
instructions
Dryer / User Manual6 / EN
B
Damaged mains cable should be changed by an
Authorised Service agent.
B
If the dryer is faulty, it must not be operated unless it
is repaired by an authorised service agent! There is
the risk of electric shock!
1.1.2 Product safety
• Superheating of the clothes inside of the dryer can
occur if you cancel the programme or in the event
of a power failure whilst the dryer is running, this
concentration of heat can cause self-combustion
and fire so always activate the ventilation
programme to cool down or quickly remove all
laundry from the dryer in order to hang them up
and dissipate the heat.
Points to be taken into consideration for fire
hazard:
Below specified laundry or items must not be dried
in the dryer because of fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone, alcohol, fuel oil,
kerosene, stain removers, turpentine, paraffin or
solvents must be washed in hot water with plenty of
detergent before being dried in the dryer.
Important safety and environmental
instructions
Dryer / User Manual 7 / EN
Below specified laundry or items must not be
dried in the dryer due to the fire hazard:
• Garments or pillows bolstered with rubber foam
(latex foam), shower caps, water resistant textiles,
materials with rubber reinforcement and rubber
foam pads.
• Clothing cleaned with industrial chemicals.
Items such as lighters, matches, coins, metal parts,
needle etc. may damage the drum set or may lead to
functional problems. Therefore check pockets off the
laundry that you will load into your dryer.
Never stop your dryer before the programme
completes. If you must do this, remove all laundry
quickly and lay them out to dissipate the heat.
Clothes that are washed inadequately may ignite on
their own and even may ignite after drying ends.
• You must provide enough ventilation in order to prevent
gases exiting from devices operating with other types of
fuels including the naked flame from accumulating in the
room due to the back fire effect.
A
Clothing that contains metal reinforcements should
not be dried in the dryer. Dryer may be damaged
if metal reinforcements come loose and break off
during drying.
C
Use softeners and similar products in accordance
with the instructions of their manufacturers.
C
Always clean the lint filter before or after each
loading. Never operate the dryer without the lint filter
installed.
Important safety and environmental
instructions
Dryer / User Manual8 / EN
• Never attempt to repair the dryer by yourself. Do not
perform any repair or replacement procedures on the
product even if you know or have the ability to perform the
required procedure unless it is clearly suggested in the
operating instructions or the published service manual.
Otherwise, you will be putting your life and others' lives in
danger.
• There must not be a lockable, sliding or hinged door that
may block the opening of the loading door in the place
where your dryer is to be installed.
• Install your dryer in a suitable place that is dry, well
ventilated and unlikely to get below 5 degrees Centigrade.
• Make sure that pets do not enter the dryer. Check the
inside of the dryer before operating it.
• Do not lean on the loading door of your dryer when it is
open, otherwise it may fall over.
• The lint must not be allowed to accumulate around the
tumble dryer
Important safety and environmental
instructions
Dryer / User Manual 9 / EN
1.2 Mounting over a washing machine
• A fixing device should be used between the two machines
when installing the dryer above a washing machine. The
fitting device can be obtained through spare part suppliers.
• Total weight of the washing machine and the dryer -with
full load- when they are placed on top of each other
reaches to approx. 180 kilograms. Place the products on a
solid floor that has sufficient load carrying capacity!
A
Washing machine cannot be placed on the dryer.
Pay attention to the above warnings during the
installation on your washing machine.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm
Can be stacked
Can be
stacked
Cannot be
stacked
60 cm
Can be stacked
Cannot be
stacked
Important safety and environmental
instructions
Dryer / User Manual10 / EN
1.3 Intended use
• Dryer has been designed for domestic use. It is not
suitable for commercial use and it must not be used out of
its intended use.
• Use the dryer only for drying laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from
incorrect usage or transportation.
• Original spare parts will be available to repair the dryer for
a period of 10 years.
1.4 Child safety
• Packaging materials are dangerous for the children. Keep
packaging materials away from children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is operating. Do not
let them tamper with the dryer. Use the child-proof lock in
order to prevent the children to tamper with the dryer.
C
Child-proof lock is on the control panel. (See Child
lock)
• Keep loading door closed even when the dryer is not in
use.
Important safety and environmental
instructions
Dryer / User Manual 11 / EN
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product does not contain the harmful and
prohibited substances which are specified in the
“Control of the Waste Electrical and Electronic
Equipment” as published by Republic of Turkey
Ministry of Environment and Urbanization. It
complies with the WEEE Directive.
This product was made of high quality items and materials
which are recyclable and reusable. Therefore, do not
dispose of the product at the end of its service life with the
domestic and other wastes. Take it to a collection point for
the recycling of electrical and electronic equipment. Please
consult your local authorities to learn the nearest collection
point. Help protect the environment and natural resources
by recycling used products. For children's safety, cut the
power cable and break the locking mechanism of the door, if
any, so that it will be non-functional before disposing of the
product.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take
them to the packaging material collection points designated
by the local authorities.
Important safety and environmental
instructions
Dryer / User Manual12 / EN
Important safety and environmental
instructions
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 65,4 cm
Capacity (max.) 10 kg**
Net weight (± 4 kg) 40 kg
Width
See type label***Voltage
Rated power input
1.8 Technical Specifications
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened
maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
C
Technical specifications of the dryer are subject to
specification without notice to improve the quality of
the product.
C
Figures in this manual are schematic and may not
match the product exactly.
C
Values stated on markers on the dryer or in the other
published documentation accompanying with the
dryer are obtained in laboratory in accordance with
the relevant standards. Depending on operational and
environmental conditions of the dryer, these values
may vary.
Dryer / User Manual 13 / EN
2
Your Dryer
2.1 Overview
1
8
7
6
11
9
2
4
3
10
5
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In in models where the tank is placed below,
the water tank is inside the toe board
8. Type label
9. Lint lter
10. Water tank drawer (in models where the tank
is placed above)
11. Power cord
Dryer / User Manual14 / EN
2.2 Package Contents
1
2 3
5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.
Your Dryer
Dryer / User Manual 15 / EN
3 Installation
Before the calling the nearest Authorised
Service for the installation of the dryer, en-
sure that electrical installation and water
drain is appropriate referring to the user’s
manual.(See 3.3 Connecting to the drain
and 3.5 Electrical connection) If they are
not suitable, contact a qualied electrician
and technician to make necessary arrange-
ments.
C
Preparation of the dryer's location
as well as the electrical and
waste water installations is under
customer's responsibility.
A
Prior to installation, visually check
if the dryer has any defects on it. If
the drier is damaged, do not have
it installed. Damaged products
cause risks for your safety.
3.1 Appropriate installation
location
Install the dryer on a stable and level
surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and
tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer will
be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
B
Do not place the dryer on the
power cable.
3.2 Removing the
transportation safety assembly
A
Remove the transportation safety
assembly before using the dryer
for the first time.
Open the loading door.
There is a nylon bag inside the drum that
contains a piece of styrofoam. Hold it from its
section marked with XX XX.
Pull the nylon towards yourself and remove
the transportation safety assembly.
A
Check that no part of the
transportation safety assembly
remains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser unit,
water accumulates in the water tank during
the drying cycle. You should drain accumu-
lated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.
If there is an accessories pack supplied with
your product, please see the detailed de-
scription.
Connecting the water drain hose
1-2 Pull hose at the behind of the dryer by
hand in order to disconnect it from where it is
connected. Do not use any tools to remove
the hose.
3 Connect one end of the drain hose sup-
plied with the dryer to the connection point
from where you removed the hose of the
product in previous step.
Dryer / User Manual16 / EN
4 Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
1
3 4
2
A
Hose connection should be made
in a safe manner. Your house
will be flooded if the hose comes
out of its housing during water
discharge.
C
Water drain hose should be
attached to a height of maximum
80 cm.
C
Make sure that the water drain
hose is not stepped on and it is
not folded between the drain and
the machine.
3.4 Adjusting the feet
In order to ensure that the dryer operates
more silently and vibration-free, it must stand
level and balanced on its feet. Balance the
machine by adjusting the feet.
Turn the feet to left or right until the dryer
stands level and rmly.
C
Never unscrew the adjustable feet
from their housings.
3.5 Electrical connection
For specic instructions for electrical connec-
tion required during installation (see 1.1.1
Electrical Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the
dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when looked
from the front.
3.7 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer
To change the Bulb/LED used for illumination
of your tumble dryer, call your Authorised
Service.
The lamp(s) used in this appliance is not
suitable for household room illumination. The
intended purpose of this lamp is to assist the
user to place laundry in the tumble dryer in a
comfortable way. The lamps used in this aps-
pliance have to withstand extreme physical
conditions such as vibrations and tempera-
tures above 50 °C
Installation
Dryer / User Manual 17 / EN
Make sure that you have an earthed power
outlet socket rated at 13 amps (minimum).
4.1 Attention!
When installed, the socket must be
reachable after installation, or a separate
switch (which can disconnect the two poles)
must be used in the installation. Check for
suitability.
For a permanent connection, a master switch
with at least 3mm contact clearance and
minimum 13 A rating must be used.
4.2 Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a suitable
switched and fused socket in a readily
accessible position.
Should the mains lead of the appliance
become damaged or need replacing at
any time, it must be replaced by a special
purpose made mains lead which can only be
obtained from a Authorised Service Agent.
A
Warning
This appliance must be earthed
If the fitted moulded plug is not suitable for
your socket, then the plug should be cut off
and an appropriate plug fitted.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse
need to be replaced an ASTA approved
BS1362 fuse of the same rating must be
used. Do not forget to refit the fuse cover.
In the event of losing the fuse cover, the
plug must not be used until a replacement
fuse cover has been fitted. Colour of the
replacement fuse cover must be the same
colour as that visible on the pin face of the
plug. Fuse covers are available from any
good electrical store.
In order to avoid hazards, damaged
supply cord should be replaced by the
manufacturer, its service agent or similarly
qualified people.
Built-under installation
This appliance can be installed under a
worktop.
A
Do not operate without the top
cover fitted. Risk of injury.
A
Important
4.3 Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals on your plug, proceed as follows:
1 Connect the green - yellow or green (earth)
wire to the terminal in the plug marked ‘E’
or with the symbol or coloured green and
yellow or green.
2 Connect the blue (neutral) wire to the
terminal in the plug marked ‘N’ or coloured
black.
3 Connect the brown (live) wire to the
terminal in the plug marked ‘L’ or coloured
red.
With the alternative plugs a 13A fuse must
be fitted either in the plug or adaptor or in the
main fuse box. If in doubt contact a qualified
electrician.
4.4 Washer/dryer combination
Do not stack washing machine on top of
the tumble dryer. This would damage both
appliances and guarantees would become
void. It is also unsafe to stack an appliance
on top of another without using a suitable
and approved stacking kit obtained from the
manufacturer of the appliances.
• A special stacking kit is required as an
optional extra please contact customer
service.
Green and yellow
or green
N
Blue or black
L
Brown or red
4 Electrical Connection
Dryer / User Manual18 / EN
5 Preparation
5.1 Laundry suitable for drying in the dryer
• Always obey the instructions given on the garment tags. Dry only the laundry having a
label stating that they are suitable for drying in a dryer and make sure that you select the
appropriate programme.
Drying
Settings
At any temperature
At high temperature
At medium
temperature
At low temperature
Without heating
Hang to dry
Lay to dry
Hang wet to dry
Lay in shadow
to dry
Dry-cleanable
Iron -
Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature
200
0
C 150
0
C 110
0
C
LAUNDRY DRYING SYMBOLS
Drying
Symbols
Suitable for
dryer
No Iron
Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry
Do not dry-
clean
5.2 Laundry not suitable for
drying in the dryer
C
Delicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
5.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
5.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-efcient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.Sort out the
laundry depending on their type and
thickness. Dry the same type of laundry
together. For example thin kitchen towels
and table clothes dries earlier than thick
bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.
• Do not add wet laundry while the dryer is
in operation
Dryer / User Manual 19 / EN
• Clean the lint filter before or after each
drying cycle
• Clean the condenser regularly at least
once every month or after every 30
drying cycles.
• Ventilate the room, where the dryer is
located, well during drying.
5.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
C
It is not recommended to load
the dryer with laundry exceeding
the level indicated in the figure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry
Approximate weights
(g)*
Cotton quit covers
(double)
1500
Cotton quit covers
(single)
1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces)
100
T-Shirts 125
*Dry laundry weight before washing.
Preparation
Dryer / User Manual20 / EN
6 Operating the product
1 2
456
3
Volume
up
Mute
Anti
Creasing
Filter
cleaning
Child-proof
lock
Ta n k
full
1. Programme selection knob
2. Remaining duration indicator
3. On/Off button
4. Start/pause button
5. End duration button
6. Sound warning button
6.2 Screen symbols
6.1 Control panel
Dryer / User Manual 21 / EN
6.3 Preparing the machine
1. Plug in the machine
2. Place laundry inside the machine.
3. Press the On/Off button.
4. When your machine turns on for the
first time, it turns on with the declaration
(cotton cabinet dryness) Programme.
C
Pressing the On/Off button
doesn‘t mean the Programme
starts.
Press the Start / Pause button to
start the Programme.
6.4 Programme selection
1. Determine the appropriate Programme
from the chart below containing the
drying levels.
2. Select the Programme you desire using
the Programme Selection knob.
Extra Dry
Only cotton laundry is dried
in normal temperature.
Thick and multi-layered laun-
dry (towels, sheets, jeans
etc.) are dried so that they
can be placed into wardrobe
without ironing.
Cottons Eco
Normal laundry (tablecloths,
underwear etc.) are dried so
that they can be placed into
wardrobe without ironing.
Cupboard
dry
Normal laundry (Ex: table-
cloths, underwear) are
again dried so that they can
be placed into the wardrobe
but more so than the ward-
robe dryness option.
Iron Dry
Normal laundry (shirts,
dresses etc) are dried ready
for ironing.
C
For detailed Programme
information see. „Programme
selection and consumption
table“..
6.5 Main Programmes
The main Programmes are given below
based on fabric type.
• Cotton
Dry durable laundry with this Programme. It
dries in normal temperature. Recommended
for use with your cotton laundry (sheets, bed
covers, towels, bathrobes etc.)
• Synthetic
Dry laundry that is not very durable with this
Programme. Recommended for use with
your synthetic laundry.
6.6 Extra Programmes
The following extra Programmes are avail-
able in the machine for special conditions.
C
Extra Programmes may vary
according to the specifications of
your machine.
C
In order to receive better
results from drying machine
Programmes, your laundry
should be washed with the
appropriate Programme in your
washing machine and wringed
with recommended wringing
revolution..
• Jeans
Use to dry jeans that are wringed with high
rpm in washing machine.
• Sport
Used to dry the laundry that are made of
synthetic, cotton or mixed fabrics and have
a tag indicating that they are suitable for dry-
ing.
• Shirts 15’
Dries shirts more delicately and thus causes
less wrinkles for easy ironing.
• Baby Protect
Programme used for baby clothing with can
be dried approval on the label.
C
Very little dampness might remain
on the shirts after the Programme.
It is recommended that you do
not leave the shirts in the drying
machine.
• Delicates
You can dry your delicates suitable for dry-
ing or laundry that is recommended to hand
wash (silk blouses, thin underwear etc.) in
low temperature.
Operating the product
Dryer / User Manual22 / EN
C
It is recommended to dry your
delicates in laundry bag to
prevent wrinkles and damage.
When the Programme ends, take
your laundry out of the machine
immediately and hang them to
prevent wrinkles.
• Freshen Up
It only performs ventilation for 10 minutes
without blowing hot air. You can ventilate the
cotton and linen clothing that has remained
closed for a long duration and remove their
odor.
• Timed Programmes
You can select the 10 mins, 20 mins, 40
mins and 60 mins time Programmes to
achieve the desired nal drying level with low
temperature.
C
On this Programme, the machine
dries as long as the set duration,
regardless of the drying level.
Operating the product
Dryer / User Manual 23 / EN
Operating the product
EN
Programmes Capacity (kg)
Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
A
Extra dry
10 1000 % 60 185
A
Cottons Eco
10 1000 % 60 165
A
Cupboard dry
10 1000 % 60 175
A
Iron dry
10 1000 % 60 125
Shirt 15’
0,5 1200 % 60 15
Jeans
4 1200 %50 90
Sport
4 1000 %60 92
Delicates
2 600 %40 50
Babyprotect
3 1000 % 60 75
Synthetics
B
Cupboard dry
5 800 % 40 65
B
Iron dry
5 800 % 40 55
Energy consumption values
Programs Capacity (kg)
Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Energy
consumption
value kWh
Cottons Eco*
10 1000 % 60 5,73
Cottons Iron dry
10 1000 % 60 4,70
Synthetic cupboard dry
5 800 % 40 2,10
6.7 Programme selection and consumption table
* : Energy Label standard Programme (EN 61121:2012) “All the lters must be cleaned prior
to test series.”All the values in the table are determined according to EN 61121:2012 stan-
dard. Consumption values may vary from the values in the table depending on laundry type,
wringing revolution, ambient conditions and changes in voltage.
„Cottons Eco Programme“ used at full and partial load is the standard drying
Programme to which the information in the label and the fiche relates, that this
Programme is suitable for drying normal wet cotton laundry and that it is the most
efficient Programme in terms of energy consumption for cotton.
C
When selecting the Cottons programme, send the condensed water out through
the drain hose.
Dryer / User Manual24 / EN
6.8 Auxiliary functions
Sound warning cancel
Drying machine makes sound warnings
when the Programme is completed. If you
don’t want sound notications, press the
“Sound Notication” button.
When you press the sound notication button
it lights up, and Programme does not make
sound notications when completed.
C
You can select this function
before or after the Programme
starts.
Anti-creasing
A 2-hour anti creasing program to prevent
laundry from creasing will be activated if you
do not take the laundry out after the program
has come to an end. This programme
rotates the laundry in 10-minute intervals to
prevent creasing.
6.9 Warning symbols
C
Warning symbols may vary
according to the specifications of
your machine.
Fiber filter cleaning
When the Programme is completed, a warn-
ing led lights up, which indicates that the
lter has to be cleaned.
C
If the filter cleaning led blinks, see
the „Troubleshooting“ chapter.
Water tank
When the Programme is completed, a warn-
ing led lights up, which indicates that the
water tank must be emptied.
If the water tank lls up while the Programme
is running, warning led starts blinking and
the machine goes into stand-by. In that
case empty the water in the water tank and
start the Programme by pressing the Start /
Pause button. Warning led turns off and the
Programme resumes.
Loading door open
Start/Pause led blinks when the loading door
of the drying machine is open.
6.10 End duration
You can delay the end duration of the
Programme for up to 24 hours with the end
duration function.
1. Open the loading door and place your
laundry.
2. Select the drying Programme.
3. Press the end duration selection button
and set the delay duration you want.
End duration led lights up. (End duration
moves continuously when you keep
pressing the button).
4. Press the Start / Pause button. End
duration countdown begins. The “:”
sign in the middle of the displayed delay
duration blinks.
C
You can add or remove laundry
for the duration of the end
duration. The duration displayed
on the screen is the sum of the
normal drying duration and the
end duration. At the end of the
countdown the end duration
led turns off, drying beings and
drying led lights up.
Changing the end duration
If you want to change the duration during the
countdown:
1. Cancel the Programme by pressing
the On/Off button. Turn on the drying
machine again by pressing the On/Off
button. When your drying machine turns
on for the first time, it turns on with the
declaration (cotton wardrobe dryness)
Programme.
2. Select the Programme you desire using
the Programme Selection knob.
Operating the product
Dryer / User Manual 25 / EN
3. Repeat the end duration operation for the
duration you want.
4. Start the Programme by pressing the
Start / Pause button.
Canceling the end duration function
If you want to cancel the end duration setting
countdown and start the Programme right
away:
1. Cancel the Programme by pressing
the On/Off button. Turn on the drying
machine again by pressing the On/Off
button. When your drying machine turns
on for the first time, it turns on with the
declaration (cotton wardrobe dryness)
Programme.
2. Select the Programme you desire using
the Programme Selection knob.
3. Start the Programme by pressing the
Start / Pause button.
6.11 Starting the Programme
Start the Programme by pressing the Start /
Pause button.
Start/Pause led and the Drying led light up,
indicating the Programme started. The “:”
sign in the middle of the remaining duration
starts to blink.
6.12 Child Lock
The machine features a child lock which pre-
vents the machine Programme ow from be-
ing affected when buttons are pressed during
operation.
When the Child Lock is active, all buttons
except for the On/Off button are deactivated.
To activate the child lock, press the Sound
Notication button and End Duration button
simultaneously for 3 seconds.
Te child lock should be deactivated to be
able to start a new Programme after the cur-
rent Programme ends or to be able to inter-
fere with the current Programme. Keep the
same buttons pressed for 3 seconds again to
deactivate the child lock.
C
The lock led on the screen
lights up when the Child Lock is
activated.
C
Child Lock deactivates when
the machine is turned off and on
again using the On/Off button.
A warning sound is heard when any button
is pressed (except for On/Off button) or the
Programme Selection knob is turned while
the child lock is active.
6.13 Changing the Programme
after it is started
After the machine starts running, you can
change the Programme you selected to dry
your laundry with a different Programme.
1. For example, to select Extra Dry
Programme instead of the Iron Dryness,
stop the Programme by pressing the
Start / Pause button.
2. Turn the Programme Selection knob to
select the Extra Dry Programme.
3. Start the Programme by pressing the
Start / Pause button.
Adding and removing laundry in
stand-by mode
If you want to add or remove laundry after
the drying Programme starts:
1. Press the Start/Pause button to take the
machine into Stand-by mode. Drying
operation stops.
2. Open the loading door, add or remove
laundry and close the loading door.
3. Start the Programme by pressing the
Start / Pause button.
C
The laundry adding made after
the drying operation started may
cause the dried laundry inside
the machine to mix with the wet
laundry and the laundry to remain
damp after the operation ends..
C
Laundry adding and removing
can be repeated as much as
desired during drying operation.
But this process would
continuously interrupt the
drying operation, and so would
cause the Programme duration
to lengthen and increase
energy consumption. Thus, it is
recommended to add laundry
before the Programme starts.
Operating the product
Dryer / User Manual26 / EN
C
If a new Programme is selected
by changing the position of the
Programme selection knob while
your machine is in stand-by
mode, the running Programme
ends.
Do not contact the inner surface
of the drum when adding or
removing laundry during a
continuing Programme. The drum
surface is hot.
6.14 Cancelling the Programme
If you want to cancel the Programme and
end the drying operation for any reason after
the machine starts running, press the On/Off
button.
A
As it will be extremely hot inside
the machine when you cancel the
Programme while the machine is
in operation; run the ventilation
Programme to cool it down.
6.15 Programme end
When the Programme ends, the Final/
Wrinkle Prevention, Fiber Filter Cleaning and
Water Tank Warning leds on the Programme
follow up indicator light up. Loading door can
be opened and machine becomes ready for
a second run.
Press the On/Off button to turn off the ma-
chine.
C
In case the laundry is not
removed after the Programme is
completed, the wrinkle prevention
Programme that lasts 2 hours
start in order to prevent wrinkling
of the laundry that remains inside
the machine.
C
Clean the fibre filter after each
drying. (See. „Fibre filter and
loading door inner surface“)
C
Empty the water tank after each
drying. (See. „Emptying the water
tank“)
Operating the product
Dryer / User Manual 27 / EN
7 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
7.1 Cleaning Lint Filter /
Loading Door Inner Surface
Lint and bre released from the laundry to
the air during the drying cycle are collected
in the Lint Filter.
C
Such fibre and lint are generally
formed during wearing and
washing.
A
Always clean the lint filter and the
inner surfaces of the loading door
after each drying process.
C
You can clean the lint filter
housing with a vacuum cleaner.
To clean the lint lter:
• Open the loading door.
• Remove the lint filter by pulling it up and
open the lint filter.
• Clean lint, fibre, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
• A layer can build up on the filter pores
that can cause clogging of the filter
after using the dryer for a while. Wash
the lint filter with warm water to remove
the layer that builds up on the lint filter
surface. Dry the lint filter completely
before reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
Dryer / User Manual28 / EN
7.2 Cleaning the sensor
There are dampness sensors in the dryer
that detect whether the laundry is dry or not.
To clean the sensors:
• Open the loading doorof the dryer.
• Allow the machine to cool down if it is
still hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
C
Clean metal surfaces of the
sensors 4 times a year.
C
Do not use metal tools when
cleaning metal surfaces of the
sensors.
A
Never use solvents, cleaning
agents or similar substances for
cleaning due to the risk of fire and
explosion!
7.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the
water that arise accumulates in the water
tank. Drain the water tank after each drying
cycle.
A
Condensed water is not drinkable!
A
Never remove the water tank
when the programme is running!
If you forget to drain the water tank, the ma-
chine will stop during the subsequent drying
cycles when the water tank is full and the
Water Tank warning symbol will ash. If this
is the case, drain the water tank and press
Start / Pause button to resume the drying
cycle.
To drain the water tank:
Pull the drawer and remove the water tank
carefully.
• Drain the water in the tank.
Maintenance and cleaning
Dryer / User Manual 29 / EN
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
C
If the direct water draining is used
as an option, there is no need to
empty the water tank.
7.4 Cleaning the condenser;
Hot and humid air in the condenser is cooled
with the cold air from the room. Thus, the hu-
mid air circulating in your dryer is condensed
and then pumped into the tank.
C
Clean the condenser after every
30 drying cycles or once a month.
To clean the condenser:
1. If a drying process has been carried out,
open the door of the machine and wait
until it cools down.
2. Unlock the 2 condenser locks after
opening the kick plate.
3. Pull out the condenser.
4. Clean the condenser by applying
pressurized water with a shower head
and wait until the water drains and the
condenser is dry.
5. Place the condenser in its housing. Fasten
the 2 locks and make sure that they are
seated securely.
6. Close the kick plate cover.
Maintenance and cleaning
Dryer / User Manual30 / EN
8 Troubleshooting
Drying process lasts for a long time.
• Pores of the fibre filter might be clogged. >>> Wash the filter with warm water.
• Condenser might be clogged. >>> Wash the condenser.
• Ventilation grills at the front of machine might be blocked. >>> Remove any items in
front of the ventilation grills that block ventilation.
• Ventilation might be inadequate if the installation area is very small. >>> Open the
windows and doors in order to prevent excessive increase in room temperature.
• There might be furring on the damp sensor. >>> Clean the damp sensor.
• Laundry might be overloaded. >>> Do not overload the tumble drier.
• Laundry might not have been adequately spun. >>> Increase the rpm of tumble drier.
Laundry is still wet at the end of drying.
C
Hot laundry unloaded at the end of drying feel wetter than they really are.
• You may not have used a programme suitable for laundry type.>>> Check the
maintenance labels on the laundry and select a programme suitable for their type, or
use the time programmes additionally.
• Pores of the fibre filter might be clogged. >>> Wash the filter with warm water.
• Condenser might be clogged. >>> Wash the condenser.
• Laundry might be overloaded. >>> Do not overload the tumble drier.
• Laundry might not have been adequately spun. >>> Increase the rpm of tumble drier.
Tumble drier does not turn on or programme cannot be started. Tumble drier does not acti-
vate when set.
• The power cord might not be plugged in. >>> Make sure the power cord is plugged in.
• Loading door might be open. >>> Make sure that the loading door is properly closed.
• You may not have set the programme or pressed the Start/Pause button. >>> Make
sure that you have set the programme and it is not in Pause position.
• Child lock might be active. >>> Disable the child lock.
Programme was interrupted for no reason.
• Loading door might not be properly closed. >>> Make sure that the loading door is
properly closed.
• A power cut might have occurred. >>> Press the Start/ Pause button to start the
programme.
• Water tank might be full. >>> Drain the water tank.
Laundry is shrunk, damaged or worn out.
• You may not have used a programme suitable for laundry type. >>> Check the
maintenance labels on the laundry and select a programme suitable for their type.
The lighting inside the tumble drier does not turn on. (In models with lamps)
• You may not have turned on the tumble drier be using On/Off/Cancel button. >>> Make
sure that the tumble drier is at ‘on’ position.
• Lamp might be broken. >>> Contact the Authorised Service for the replacement of lamp.
Filter cleaning warning led is on.
• Fibre filter might not have been cleaned. >>> Clean the filter.
Dryer / User Manual 31 / EN
Filter cleaning warning led ashes.
• Filter bearing might be clogged with fibre. >>> Clean the filter bearing.
• There might be a layer in the filter pores that causes clogging. >>> Wash the filter with
warm water.
• Condenser might be clogged. >>> Wash the condenser.
Water is leaking from the condenser cover.
• There might be fibre build-up inside the loading door and on the surfaces of loading
door gasket. >>> Clean the inner surfaces of loading door and surfaces of loading door
gasket.
Loading door opens itself.
• Loading door might not be properly closed. >>> Push the loading door until you hear the
closing sound.
Water tank warning led is on/ashes.
• Water tank might be full. >>> Drain the water tank.
• Water drain hose might be folded. >>> Check the water drain hose if the product is
directly connected to the water outlet.
A
If you cannot eliminate the problem despite following these instructions, please
contact the vendor that sold you the product or an Authorised Service. Do not try
to repair the product yourself.
C
In an event that you encounter an issue on any part on your appliance, you can
ask for a replacement by contacting the authorized service with the appliance
model number.
Operating the appliance with non-authentic parts may lead the appliance to mal-
function.
Manufacturer and distributor are not liable for malfunctions resulting from using
non-authentic parts.
Troubleshooting
Dryer / User Manual 32
BLOMBERG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE TERMS AND CONDITIONS
Your new Blomberg product is guaranteed against faulty materials, defective components or manufacturing defects.
The standard guarantee starts from the date of original purchase of the product, and lasts for a period of thirty six
(36) months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the product in writing.
If you have any questions about the guarantee on your product (including how long it is valid), please contact your retailer or
our contact centre on 0333 207 9870 (UK and Northern Ireland) or 01 691 0160 (Republic of Ireland)
This guarantee does not in any way diminish or affect your statutory rights in connection with the product. This guarantee is in
addition to your statutory rights as a consumer. If you have any questions about these rights, please contact the retailer from
which you purchased the product. In certain circumstances, it is possible that your statutory rights may offer additional or
higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials, defective components or manufacturing defects.
• Functional replacement parts to repair a product.
• The costs of a Blomberg Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice trays, scrapers, cutlery baskets, filters and light
bulbs.
• Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Blomberg Approved Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the requirements contained in this
guarantee or the User Instructions Booklet.
• Repairs to a product operated at any time on commercial or non-residential household premises (unless we have
previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the Manufacturer does not accept
and will not be held liable for any financial loss incurred in connection with the failure of any product to operate in accordance
with the expected standards. Such financial loss includes but is not limited to loss arising from:
• Time taken off work.
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1. Your product is designed and built for domestic household use only.
2. The guarantee will automatically be void if the product is installed or is used in commercial or non-residential
domestic household premises, unless we have previously agreed to the installation environment.
3. The product must be correctly installed, located and operated in accordance with the instructions contained in the
User Instructions Booklet provided with your product.
4. Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing
Machines, Dishwashers and Electric Cookers (as incorrect installation may result in you having to pay for the cost of
repairing the product).
5. Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland for Republic of Ireland)
registered gas installer.
6. This guarantee is given in respect of products purchased and used within the United Kingdom and the Republic of
Ireland.
7. This guarantee is effective from the initial date of purchase of a new product from an authorised retailer and will be
void if the product is resold.
8. This guarantee does not apply to graded sales (where the product is purchased as a “second”).
9. Possession of a copy of these terms and conditions does not necessarily mean that a product has the benefit of this
guarantee. If you have any questions, please call our Call Centre on the number set out above.
10. The Manufacturer reserves the right to terminate the guarantee if its staff or representatives are subjected to physical
or verbal abuse in the course of carrying out their duties.
Dryer / User Manual 33
11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only.
Does Blomberg offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new
product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when
this is not possible, a model of similar specification will be provided. The Manufacturer will cover the costs and arrange for the
delivery of the new product and for the return of the old product. Any costs related to disconnecting the faulty product and
installing the replacement product will not be borne by the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole
discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and
to meet requests for specific timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable to
carry out a repair because a convenient appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of
purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if:
• You cannot provide evidence that your product is covered by this guarantee.
• Where a service call has been made and the engineer finds that there is no fault with your product.
• That your product has not been installed or operated in accordance with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials, defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice. The Manufacturer reserves the
right to terminate the guarantee if you fail to pay the costs for the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law and subject to the English Courts,
save where you live in another part of the United Kingdom, in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and the Irish courts will have
jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration number 02415578.
Dryer / User Manual 34
BLOMBERG UK AND IRELAND OPTIMA INVERTER MOTOR GUARANTEE TERMS AND CONDITIONS
This 10 year guarantee relates to Blomberg products that feature the Optima Inverter Motor.
The Optima Motor guarantee terms and conditions are in addition to our Standard guarantee terms and conditions detailed in
the previous section.
In order to activate the 10 year guarantee you MUST register the appliance within 90 days of the original purchase
date. You can register by first visiting blomberguk.com/register and by following the online instructions.
All Blomberg appliances come with a 3 year parts and labour guarantee as standard. When you register your appliance for the
Optima Inverter Motor 10 year guarantee, you are also registering your appliance for the standard 3 year parts and labour
guarantee.
Blomberg built-in or integrated products purchased from Euronics agents come with a 3 year parts and labour guarantee which
is extended to 5 years, free of charge, upon registration of the appliance. When you register your appliance for this additional 2
years, you will automatically activate the Optima Inverter Motor 10 year guarantee. You do not need to register twice. To make
a claim against your Blomberg Optima Inverter Motor Guarantee (the “Guarantee”), all customer and product details must be
registered with Beko plc using the procedure outlined below.
1. This extra 7 years or 5 years (for built-in appliances from Euronics agents) Guarantee is only effective after the
expiration of the standard manufacturer’s guarantee.
2. It is only valid for the Optima Inverter motors of selected washing machines, washer-dryers, tumble dryers and
dishwashers. It does not cover any labour charge or any other components of the product. In addition, it is only valid
for one replacement of the Optima motor during the extra 9-year (for free standing appliances) or 8 year (for built-in
appliances) guarantee period.
3. To activate your guarantee, you MUST register your appliance within 90 days of the original purchase date, by visiting
blomberguk.com/register.
4. Customers will receive a unique reference code as proof of guarantee validation by email or post, which must be
quoted at the time of a claim being made.
5. Any repair/replacement of the Optima Inverter motor must only be carried out by an authorised Blomberg Service
Agent (the “Service Agent”).
6. Labour for the repair/replacement of the Optima Inverter motor is not included in this guarantee and is chargeable
directly by the Service Agent.
7. Any additional components fitted to the product at any time will not be covered by this guarantee and will be
chargeable directly by the Service Agent.
8. The guarantee is not transferable and cannot be exchanged for cash.
9. There are no alternative or additional offers to this Guarantee.
10. The guarantee is exclusive of the manufacturer’s standard guarantee
11. The Terms and Conditions shown above are in addition to the standard terms and conditions of your product
guarantee. Please read and refer to such Terms and Conditions when making any claim.
12. We may use the information you provide for marketing purposes and to analyse your purchasing preferences. We
may keep your information for a reasonable period for these purposes in accordance with the applicable Data
Protection Laws and General Data Protection Regulations (GDPR). You can opt into this service during the
registration process. Further details are available at http://www.blomberguk.com/cookie-and-privacy.
13. These Terms and Conditions are governed by the laws of England and Wales; manufacturer: Beko plc, Beko House,
1 Greenhill Crescent, Watford WD18 8QU. Company Registration Number: 02415578.
Dryer / User Manual 35
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a safe place; you will need to have this documentation
available should the product require attention under guarantee.
Please take a few moments to complete the details below, as you will need this information when you call us, or to use our
online services. When you call us you may be required to input your serial number into your telephone keypad. For help please
visit Blomberguk.com/support/model-finder
• The product model number is printed on the Operating Instruction Booklet / User guide
• The product model and serial number is printed on the Rating Label affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on your purchase receipt or other proof of
purchase paperwork
Recording of these details alone will not count as proof of purchase. A valid proof of purchase is required for requesting
service under guarantee.
Model number
Serial number
Purchased from
Date of purchase
For service under guarantee or for product advice please call our Contact centre
Before requesting service please check the troubleshooting guide in the Operating Instructions booklet, as a charge may be
levied where no fault is found, and even though your product may still be under guarantee.
After arranging service the area around the product must be easily accessible to the Engineer, without the need for cabinets or
furniture to be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry out any repairs.
Please have your Model number and Serial number available when you call us, as you may be required to input your serial
number into your telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9870
Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers 01 or 02, and are charged at the
basic rate. Calls from landlines and mobiles are included in free call packages but please check with your telephone service
provider for exact call charges.
Republic of Ireland:
01 691 0160
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee
agreement document, otherwise please call us using the appropriate number above, where service can be obtained at a
charge.
Should you experience any difficulty in obtaining service please call us on 0333 207 9870 or 01 691 0160
Contact us though our website
Send us a secure message through our online contact us form. Please visit our website, click Contact Us and choose a
product support topic from the list of options. Complete the required details and click send message.
Product registrations
For UK and Republic of Ireland product registrations please visit blomberguk.com/register
(4) Scale from G (lest efficient) to A (most efficient)
(5) Weighted average value — L
WA
expressed in dB(A) re 1 pW
(1) Scale from A+++ (most efficient) to D (least efficient)
(2) Energy consumption based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of
the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
(3) "Cotton cupboard dry programme" used at full and partial load is the standard drying programme to which the information in the
label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient
programme in terms of energy consumption for cotton
: Yes - : No
Supplier name or trademark
Model name
Rated capacity (kg)
Type of Tumble Dryer
Condenser
Air Vented
Energy efficiency class
(1)
Annual Energy Consumption (kWh)
(2)
Type of Control
Energy consumption of the standard cotton programme at full load (kWh)
Energy consumption of the standard cotton programme at partial load (kWh)
Power consumption of the off-mode for the standart cotton programme at full load, P
O
(W)
Power consumption of the left-on mode for the standart cotton programme at full load, P
L
(W)
The duration of the left on mode (min)
Standard cotton programme
(3)
Programme time of the standard cotton programme at full load, T
dry
(min)
Programme time of the standard
cotton programme at partial load, T
dry1/2
(min)
Weighted programme time of the standard cotton programme at full and partial load (T
t
)
Condensation efficiency class
(4)
Average condensation efficiency of the standard cotton programme at full load, C
dry
Average condensation efficiency of the standard cotton programme at partial load, C
dry1/2
Weighted condensation efficiency of the standard cotton programme at full load and partial load, C
t
Sound power level for the standard cotton programme at full load
(5)
Built-in
PRODUCT FICHE
Complying Commission Delegated Regulation (EU) No 392/2012
Non-automatic
Automatic
-
B
670
-
5,73
2,99
0,5
1,0
30
165
119
B
81%
81%
81%
66
10
85
-
Blomberg
LTK21003W
