User Manual Bosch HBN331E9B Serie 2 Built-in Oven
Documents for Bosch HBN331E9B
The following documents are available:
User Manual
User Manual - (English)
Read Online
|
Download pdf
Photos
Photos:
View Photos
User Manual
For HBN331E9B.
Page 1/24
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 24
Contents
Table of Contents
Search
Previous
Next
Troubleshooting
Bookmarks
en
Instruction manual
Built-in ov
en
HBN331.9B
Loading ...
Loading ...
Loading ...
1
2
3
4
5
6
>
Summary of Contents for Bosch HBN331E9B:
en Instruction manual
1
Built-in oven
1
HBN331.9B
1
Table of contentsen Instruction manual
3
: Important safety information
3
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
3
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
3
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
3
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
3
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
3
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
3
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
3
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
3
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
3
Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
4
Risk of fire!
4
■ Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...
4
Risk of fire!
4
■ A draught is created when the appliance door is opened. Greaseproof paper may come into contact with the heating element and catch fire. Do not place greaseproof paper loosely over accessories during preheating. Always weight down the greaseproof...
4
Risk of burns!
4
■ The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
4
Risk of serious burns!
4
■ Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.
4
Risk of burns!
4
■ Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care
4
Risk of scalding!
4
■ The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance.
4
Risk of scalding!
4
■ When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance.
4
Risk of scalding!
4
■ Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment.
4
Risk of injury!
4
Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
4
Risk of electric shock!
4
■ Incorrect repairs are dangerous. Repairs may only be carried out by one of our trained after-sales engineers. If the appliance is faulty, unplug the mains plug or switch off the fuse in the fuse box. Contact the after-sales service.
4
Risk of electric shock and serious injury!
4
■ The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.
4
Risk of electric shock!
4
■ Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
4
Risk of electric shock!
4
■ When replacing the cooking compartment bulb, the bulb socket contacts are live. Before replacing the bulb, unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
4
Risk of electric shock!
4
■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
4
Causes of damage
4
Caution!
4
Your new oven
5
Control panel
5
Control knobs
5
Function selector
5
Buttons and display
6
Temperature selector
6
Grill settings
6
Cooking compartment
6
Oven light
6
Cooling fan
6
Caution!
6
Your accessories
6
Inserting the accessories
6
Note
6
Optional accessories
7
Oven door - Additional safety precautions
7
Before using the oven for the first time
7
Setting the clock
7
1. Press the 0 button. The time 12:00 appears in the display and the 0 symbol flashes.
7
2. Use the + or - button to change the clock.
7
Heating up the oven
7
1. Use the function selector to set Top/bottom heating %.
7
2. Set the temperature selector to 240 °C.
7
Cleaning the accessories
7
Setting the oven
8
Types of heating and temperature
8
1. Use the function selector to select the required type of heating.
8
2. Use the temperature selector to set the temperature or the grill setting.
8
Switch off the oven
8
Changing the settings
8
If the oven is to switch off automatically
8
1. The function selector is used to set the type of heating.
8
2. The temperature selector is used to set the temperature or grill setting.
8
3. Press the 0 Clock button. The x Cooking time symbol flashes.
8
4. Use the @ or A button to set the cooking time. Default value for the @ button = 30 minutes Default value for the A button = 10 minutes
8
The cooking time has elapsed
8
Changing the setting
8
Cancelling the setting
8
Setting the cooking time if the clock is hidden
8
If the oven is to switch on and off automatically
9
1. The function selector is used to set the type of heating.
9
2. The temperature selector is used to set the temperature or grill setting.
9
3. Press the 0 Clock button.
9
4. Use the @ or A button to set the cooking time.
9
5. Press the 0 Clock button repeatedly until the y End symbol flashes. You can see in the display when the meal will be ready.
9
6. Use the @ button to set a later end time. The setting is adopted after a few seconds. The end time is shown in the display until the oven starts.
9
The cooking time has elapsed
9
Note
9
Rapid heating
9
1. Move the function selector to the J position.
9
2. Use the temperature selector to set the temperature.
9
The rapid heating process is complete
9
Cancelling rapid heating
9
Setting the clock
9
1. Press the 0 Clock button. 12.00 appears in the display and the 0 symbol flashes.
9
2. Use the + or - button to change the clock. After a few seconds, the time is saved. The 0 symbol goes out.
9
Setting the timer
10
1. Press the S Timer button. The S symbol flashes.
10
2. Use the - or + button to change the timer duration. Default value for + button = 10 minutes Default value for - button = 5 minutes
10
Childproof lock
10
Oven
10
Notes
10
Care and cleaning
10
Notes
10
Cleaning agents
10
When cleaning the oven do not use
10
Detaching and refitting the rails
11
Unhooking the rails
11
1. Hold the shelf frames from underneath and pull slightly forward. Pull the extension pins at the bottom of the rails out of the mounting holes (Fig. A).
11
2. Then fold the rails upwards and carefully remove them (Fig. B).
11
Installing the frames
11
1. Insert the two hooks carefully into the upper holes. (Figure A- B)
11
: Incorrect assembly!
11
2. the two hooks must be inserted fully into the upper holes. Now move the frame slowly and carefully downwards and insert in the lower holes (figure D).
11
3. Insert both frames into the side walls of the oven (figure E).
11
Detaching and attaching the oven door
11
: Risk of injury!
11
Detaching the door
12
1. Open the oven door fully.
12
2. Fold up the two locking levers on the left and right (figure A).
12
3. Close the oven door as far as the limit stop. With both hands, grip the door on the left and right-hand sides. Close the door a little further and pull it out (figure B).
12
Attaching the door
12
1. When attaching the oven door, ensure that both hinges are inserted straight into the opening (figure A).
12
2. The notch on the hinge must engage on both sides (figure B).
12
3. Fold back both locking levers (figure C). Close the oven door.
12
: Risk of injury!
12
Removing and installing the door panels
12
Removal
12
1. Detach the oven door and lay it on a cloth with the handle facing down.
12
2. Pull off the cover at the top of the oven door. Press in the tabs on the left and right using your fingers (fig. A).
12
3. Lift the top panel up and pull it out (fig. B).
12
4. Lift the panel up and pull it out (fig. C).
12
: Risk of injury!
12
Installation
12
1. Insert the panel at an angle towards the back (fig. A).
12
2. Insert the top panel at an angle towards the back into the brackets. The smooth surface must face outwards. (fig. B).
12
3. Put the cover back in place and press on it.
12
4. Attach the oven door.
12
Troubleshooting
13
Malfunction table
13
: Risk of electric shock!
13
Caution!
13
Replacing the bulb in the oven ceiling light
13
: Risk of electric shock!
13
1. Place a tea towel in the oven when it is cold to prevent damage.
13
2. Unscrew the glass cover by turning it anti-clockwise.
13
3. Replace the bulb with one of the same type.
13
4. Screw the glass cover back in.
13
5. Remove the tea towel and switch on the circuit breaker.
13
Glass cover
13
After-sales service
13
E number and FD number
13
To book an engineer visit and product advice
13
Energy and environment tips
14
Saving energy
14
Environmentally-friendly disposal
14
Measures to be noted during transport
14
If the original packaging is no longer available
14
Tested for you in our cooking studio
14
Notes
14
Cakes and pastries
14
Baking on one level
14
Baking and roasting on two or more levels
14
Baking tins
14
Tables
15
Baking tips
16
Meat, poultry, fish
16
Ovenware
16
Roasting
16
Grilling
16
Roasting
17
Grilling
17
Tips for roasting and grilling
17
Preprepared products
18
Note
18
The universal pan may warp when cooking frozen dishes. The reason for this is the large temperature differences that the accessory is subjected to. The deformation disappears as early as during the cooking process.
18
Special dishes
18
1. Bring 1 litre of milk (3.5 % fat) to the boil and cool down to 40 °C.
18
2. Stir in 150 g of yoghurt (at refrigerator temperature).
18
3. Pour into cups or small screw-top jars and cover with cling film.
18
4. Preheat the cooking compartment as indicated.
18
5. Place the cups or jars on the cooking compartment floor and incubate as indicated.
18
1. Prepare the dough as usual, place it in a heat-resistant ceramic dish and cover.
18
2. Preheat the cooking compartment as indicated.
18
3. Switch off the oven and place the dough in the cooking compartment and leave it to prove.
18
Defrosting
18
Drying
18
Preserving
19
Caution!
19
Preparation
19
1. Fill the jars, but not to the top.
19
2. Wipe the rims of the jars, as they must be clean.
19
3. Place a damp rubber seal and a lid on each jar.
19
4. Seal the jars with the clips.
19
Making settings
19
1. Insert the universal pan at level 2. Arrange the jars on it so that they do not touch each other.
19
2. Pour ½ litre of hot water (approx. 80 °C) into the universal pan.
19
3. Close the oven door.
19
4. Set $ Bottom heating.
19
5. Set the temperature to between 170 and 180 °C.
19
Preserving
19
Taking out the jars
19
Caution!
19
Acrylamide in foodstuffs
19
Test dishes
20
Baking
20
Grilling
20
File type: PDF
File name: 78823563_hbn331e9b.pdf
File size: 2.94 MB
File Language: English
Pages: 24
Author: Bosch
File created: 2015-03-12
Published: 2021-03-31
Updated: 2023-06-11
Verified by
Kathryn Cummings
on 2023-06-11
Download File
Specifications
Brand:
Bosch
Model: HBN331E9B
Category:
Ovens
See other models:
HHF133BS0B
WAE28262GB
PGQ7B5B90
DWA64BC50B
DWG64BC50B
Photos
Download User Manual
Bosch in United States
1-800-944-2904
Twitter
Website
Related Products
Bosch HBF113BR0A
Bosch HBN331E6B
Bosch HBN331E5B
Bosch HBN331E3B
Bosch HBN331S5B
Bosch HBN331E8B
Bosch HBN331E4B
Bosch HBN331S4B
Bosch HBN531E1B
Bosch HBN231E0B
Bosch HBN331E2/15
Bosch HBN331E2/12
Bosch HBN331E4J/03
Bosch HBN3550UC
Bosch HBN301E4Q
Table of Contents
×
en Instruction manual
1
Built-in oven
1
HBN331.9B
1
Table of contentsen Instruction manual
3
: Important safety information
3
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
3
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
3
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
3
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
3
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
3
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
3
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
3
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
3
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
3
Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
4
Risk of fire!
4
■ Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...
4
Risk of fire!
4
■ A draught is created when the appliance door is opened. Greaseproof paper may come into contact with the heating element and catch fire. Do not place greaseproof paper loosely over accessories during preheating. Always weight down the greaseproof...
4
Risk of burns!
4
■ The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
4
Risk of serious burns!
4
■ Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.
4
Risk of burns!
4
■ Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care
4
Risk of scalding!
4
■ The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance.
4
Risk of scalding!
4
■ When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance.
4
Risk of scalding!
4
■ Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment.
4
Risk of injury!
4
Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
4
Risk of electric shock!
4
■ Incorrect repairs are dangerous. Repairs may only be carried out by one of our trained after-sales engineers. If the appliance is faulty, unplug the mains plug or switch off the fuse in the fuse box. Contact the after-sales service.
4
Risk of electric shock and serious injury!
4
■ The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.
4
Risk of electric shock!
4
■ Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
4
Risk of electric shock!
4
■ When replacing the cooking compartment bulb, the bulb socket contacts are live. Before replacing the bulb, unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
4
Risk of electric shock!
4
■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
4
Causes of damage
4
Caution!
4
Your new oven
5
Control panel
5
Control knobs
5
Function selector
5
Buttons and display
6
Temperature selector
6
Grill settings
6
Cooking compartment
6
Oven light
6
Cooling fan
6
Caution!
6
Your accessories
6
Inserting the accessories
6
Note
6
Optional accessories
7
Oven door - Additional safety precautions
7
Before using the oven for the first time
7
Setting the clock
7
1. Press the 0 button. The time 12:00 appears in the display and the 0 symbol flashes.
7
2. Use the + or - button to change the clock.
7
Heating up the oven
7
1. Use the function selector to set Top/bottom heating %.
7
2. Set the temperature selector to 240 °C.
7
Cleaning the accessories
7
Setting the oven
8
Types of heating and temperature
8
1. Use the function selector to select the required type of heating.
8
2. Use the temperature selector to set the temperature or the grill setting.
8
Switch off the oven
8
Changing the settings
8
If the oven is to switch off automatically
8
1. The function selector is used to set the type of heating.
8
2. The temperature selector is used to set the temperature or grill setting.
8
3. Press the 0 Clock button. The x Cooking time symbol flashes.
8
4. Use the @ or A button to set the cooking time. Default value for the @ button = 30 minutes Default value for the A button = 10 minutes
8
The cooking time has elapsed
8
Changing the setting
8
Cancelling the setting
8
Setting the cooking time if the clock is hidden
8
If the oven is to switch on and off automatically
9
1. The function selector is used to set the type of heating.
9
2. The temperature selector is used to set the temperature or grill setting.
9
3. Press the 0 Clock button.
9
4. Use the @ or A button to set the cooking time.
9
5. Press the 0 Clock button repeatedly until the y End symbol flashes. You can see in the display when the meal will be ready.
9
6. Use the @ button to set a later end time. The setting is adopted after a few seconds. The end time is shown in the display until the oven starts.
9
The cooking time has elapsed
9
Note
9
Rapid heating
9
1. Move the function selector to the J position.
9
2. Use the temperature selector to set the temperature.
9
The rapid heating process is complete
9
Cancelling rapid heating
9
Setting the clock
9
1. Press the 0 Clock button. 12.00 appears in the display and the 0 symbol flashes.
9
2. Use the + or - button to change the clock. After a few seconds, the time is saved. The 0 symbol goes out.
9
Setting the timer
10
1. Press the S Timer button. The S symbol flashes.
10
2. Use the - or + button to change the timer duration. Default value for + button = 10 minutes Default value for - button = 5 minutes
10
Childproof lock
10
Oven
10
Notes
10
Care and cleaning
10
Notes
10
Cleaning agents
10
When cleaning the oven do not use
10
Detaching and refitting the rails
11
Unhooking the rails
11
1. Hold the shelf frames from underneath and pull slightly forward. Pull the extension pins at the bottom of the rails out of the mounting holes (Fig. A).
11
2. Then fold the rails upwards and carefully remove them (Fig. B).
11
Installing the frames
11
1. Insert the two hooks carefully into the upper holes. (Figure A- B)
11
: Incorrect assembly!
11
2. the two hooks must be inserted fully into the upper holes. Now move the frame slowly and carefully downwards and insert in the lower holes (figure D).
11
3. Insert both frames into the side walls of the oven (figure E).
11
Detaching and attaching the oven door
11
: Risk of injury!
11
Detaching the door
12
1. Open the oven door fully.
12
2. Fold up the two locking levers on the left and right (figure A).
12
3. Close the oven door as far as the limit stop. With both hands, grip the door on the left and right-hand sides. Close the door a little further and pull it out (figure B).
12
Attaching the door
12
1. When attaching the oven door, ensure that both hinges are inserted straight into the opening (figure A).
12
2. The notch on the hinge must engage on both sides (figure B).
12
3. Fold back both locking levers (figure C). Close the oven door.
12
: Risk of injury!
12
Removing and installing the door panels
12
Removal
12
1. Detach the oven door and lay it on a cloth with the handle facing down.
12
2. Pull off the cover at the top of the oven door. Press in the tabs on the left and right using your fingers (fig. A).
12
3. Lift the top panel up and pull it out (fig. B).
12
4. Lift the panel up and pull it out (fig. C).
12
: Risk of injury!
12
Installation
12
1. Insert the panel at an angle towards the back (fig. A).
12
2. Insert the top panel at an angle towards the back into the brackets. The smooth surface must face outwards. (fig. B).
12
3. Put the cover back in place and press on it.
12
4. Attach the oven door.
12
Troubleshooting
13
Malfunction table
13
: Risk of electric shock!
13
Caution!
13
Replacing the bulb in the oven ceiling light
13
: Risk of electric shock!
13
1. Place a tea towel in the oven when it is cold to prevent damage.
13
2. Unscrew the glass cover by turning it anti-clockwise.
13
3. Replace the bulb with one of the same type.
13
4. Screw the glass cover back in.
13
5. Remove the tea towel and switch on the circuit breaker.
13
Glass cover
13
After-sales service
13
E number and FD number
13
To book an engineer visit and product advice
13
Energy and environment tips
14
Saving energy
14
Environmentally-friendly disposal
14
Measures to be noted during transport
14
If the original packaging is no longer available
14
Tested for you in our cooking studio
14
Notes
14
Cakes and pastries
14
Baking on one level
14
Baking and roasting on two or more levels
14
Baking tins
14
Tables
15
Baking tips
16
Meat, poultry, fish
16
Ovenware
16
Roasting
16
Grilling
16
Roasting
17
Grilling
17
Tips for roasting and grilling
17
Preprepared products
18
Note
18
The universal pan may warp when cooking frozen dishes. The reason for this is the large temperature differences that the accessory is subjected to. The deformation disappears as early as during the cooking process.
18
Special dishes
18
1. Bring 1 litre of milk (3.5 % fat) to the boil and cool down to 40 °C.
18
2. Stir in 150 g of yoghurt (at refrigerator temperature).
18
3. Pour into cups or small screw-top jars and cover with cling film.
18
4. Preheat the cooking compartment as indicated.
18
5. Place the cups or jars on the cooking compartment floor and incubate as indicated.
18
1. Prepare the dough as usual, place it in a heat-resistant ceramic dish and cover.
18
2. Preheat the cooking compartment as indicated.
18
3. Switch off the oven and place the dough in the cooking compartment and leave it to prove.
18
Defrosting
18
Drying
18
Preserving
19
Caution!
19
Preparation
19
1. Fill the jars, but not to the top.
19
2. Wipe the rims of the jars, as they must be clean.
19
3. Place a damp rubber seal and a lid on each jar.
19
4. Seal the jars with the clips.
19
Making settings
19
1. Insert the universal pan at level 2. Arrange the jars on it so that they do not touch each other.
19
2. Pour ½ litre of hot water (approx. 80 °C) into the universal pan.
19
3. Close the oven door.
19
4. Set $ Bottom heating.
19
5. Set the temperature to between 170 and 180 °C.
19
Preserving
19
Taking out the jars
19
Caution!
19
Acrylamide in foodstuffs
19
Test dishes
20
Baking
20
Grilling
20
Search:
×
Search
