Camera User Guide
ENGLISH
DIGITAL CAMERA
Camera User Guide
0
Disclaimer
z
While every effort has been made to ensure that the
information contained in this guide is accurate and
complete, no liability can be accepted for any errors or
omissions.
z
Canon Inc. reserves the right to change the
specifications of the hardware and software described
herein at any time without prior notice.
z
No part of this guide may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated
into any language in any form, by any means, without
the prior written permission of Canon Inc.
z
Canon makes no warranties for damages resulting from
corrupted or lost data due to a mistaken operation or
malfunction of the camera, the software, the
CompactFlash™ cards (CF cards), personal
computers, peripheral devices, or use of non-Canon CF
cards.
Trademark Acknowledgements
z
Canon and PowerShot are trademarks of Canon.
z
CompactFlash is a trademark of SanDisk Corporation.
z
iBook and iMac are trademarks of Apple Computer, Inc.
z
Macintosh, PowerBook, Power Macintosh and
QuickTime are trademarks of Apple Computer, Inc,
registered in the United States and other countries.
z
Microsoft, Windows, and Windows NT are either
registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
z
Other names and products not mentioned above may be
registered trademarks or trademarks of their respective
companies.
Use of genuine Canon accessories is
recommended.
This product is designed to perform optimally when used
with genuine Canon accessories. Canon shall not be
liable for any damage to this product and/or accidents
such as fire, etc., caused by the malfunction of non-
genuine Canon accessories (e.g., a leakage and/or
explosion of a battery pack). Please note that this
warranty does not apply to repairs arising out of the
malfunction of non-genuine Canon accessories, although
you may request such repairs on a chargeable basis.
1
Flowchart and Reference Guides
This Guide
Shooting with the Camera
Software Starter Guide
Installing the Software
This Guide
Connecting the Camera to a Computer
Software Starter Guide
Downloading Images to a Computer
Direct Print User Guide
Printer User Guide
Using the Printer and Printing
Symbols Used
:This mark denotes issues that may affect the
camera's operation.
:This mark denotes additional topics that
complement the basic operating procedures.
2
Table of Contents
Items marked with are lists or charts that
summarize camera functions or procedures.
Components Guide. . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Batteries/CF Card . . . . . . . . . . . . . . . 14
Turning the Power On/Off. . . . . . . . . . . . . . . . . . . . 19
Setting the Date/Time. . . . . . . . . . . . . . . . . . . . . . . 21
Setting the Language . . . . . . . . . . . . . . . . . . . . . . . 23
Using the Viewfinder and the LCD Monitor . . . . . . 24
Auto Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Reviewing an Image Right after Shooting . . . . . . . 30
Changing the Resolution and Compression. . . . . . 32
Using the Built-in Flash. . . . . . . . . . . . . . . . . . . . 34
Displaying Images Individually . . . . . . . . . . . . . . . . 39
Magnifying Images . . . . . . . . . . . . . . . . . . . . . . 40
Viewing Images in Sets of Nine (Index Playback) . 41
JUMP Jumping Between Images . . . . . . . . . . . . . . 42
Read This First
Chapter 1. Preparing the Camera
Chapter 2. Shooting-The Basics
Chapter 3. Playback-The Basics
Erasing Images Individually . . . . . . . . . . . . . . . . 43
Erasing All Images . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using the Mode Dial (Image Zone) . . . . . . . . . . . . 45
Portrait
Landscape
Night Scene
Fast Shutter
Slow Shutter
Shooting Panoramic Images (Stitch Assist) . . . 47
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . 49
Digital Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Continuous Shooting . . . . . . . . . . . . . . . . . . . . 52
Movie Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Viewing/Editing Movies . . . . . . . . . . . . . . . . . . . . . 57
Selecting Menus and Settings . . . . . . . . . . . . . . . . 61
Resetting the Settings to Default . . . . . . . . . . . . . . 68
Registering Settings to the Shortcut Button . . . . . . 69
Using the Mode Dial (Creative Zone). . . . . . . . . . . 71
Program AE
Setting the Shutter Speed
Setting the Aperture
Manually Setting the Shutter
Selecting an AF Frame. . . . . . . . . . . . . . . . . . . 75
Chapter 4. Erasing
Chapter 5. Useful Shooting Functions
Chapter 6. Shooting-Advanced Functions
3
Switching between Light Metering Modes . . . . 76
Adjusting the Exposure . . . . . . . . . . . . . . . . . . . . . 78
Adjusting the Tone (White Balance) . . . . . . . . . . . 79
Changing the ISO Speed. . . . . . . . . . . . . . . . . . . . 81
Changing the Photo Effect. . . . . . . . . . . . . . . . . . . 82
Auto Exposure Bracketing (AEB Mode) . . . . . . . . 84
Focus Bracketing (Focus-BKT Mode) . . . . . . . . . . 85
Locking the Exposure Setting (AE Lock) . . . . . . . . 86
Locking the Flash Exposure Setting (FE Lock) . . . 87
Switching between Built-in Flash Adjustment Settings . .
88
Switching the Timing at which the Flash Fires . . . 90
Shooting Images at Set Intervals (Intervalometer) 91
Shooting Problem Subjects for the Autofocus . . . . 93
Switching between Focus Settings . . . . . . . . . . . . 97
Saving Custom Settings . . . . . . . . . . . . . . . . . . 98
Rotating Images in the Display . . . . . . . . . . . . . . 100
Attaching Sound Memos to Images. . . . . . . . . 101
Automated Playback (Slide Show) . . . . . . . . . . . 102
Protecting Images . . . . . . . . . . . . . . . . . . . . . . . . 106
Setting the Power Saving Function . . . . . . . . . . . 107
Setting the Auto Rotate Function. . . . . . . . . . . . . 108
Resetting the File Numbers . . . . . . . . . . . . . . . . . 110
Customizing the Camera (My Camera Settings) . 111
Chapter 7. Playback-Advanced Functions
Chapter 8. Camera Settings
Downloading Images to a Computer . . . . . . . . . . 115
Downloading Directly from a CF Card. . . . . . . . . 117
Viewing Images on a TV Set . . . . . . . . . . . . . . . . 118
About Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Print Settings (DPOF Print Settings) . . . . . . . . . . 121
Image Transmission Settings (DPOF Transfer Order) .
126
List of Messages . . . . . . . . . . . . . . . . . . . . . . . . . 128
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . 130
Using the Wireless Controller (Sold Separately) . 135
Using Conversion Lenses (Sold Separately). . . . 137
Using the Power Kits (Sold Separately) . . . . . . . 140
Replacing the Date Battery . . . . . . . . . . . . . . . . . 144
Camera Care and Maintenance . . . . . . . . . . . . . 145
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Photo Tips and Information . . . . . . . . . . . . . . . . . 154
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Functions Available in Each Shooting Mode. . . . 162
Chapter 9. Additional Features
Appendix
4
Read This First
Please Read
Test Shots
Before you try to photograph important subjects, we
highly recommend that you shoot several trial
images to confirm that the camera is operating and
being operated correctly. Please note that Canon
Inc., its subsidiaries and affiliates, and its distributors
are not liable for any consequential damages arising
from any malfunction of a camera or accessory,
including CompactFlash™ cards, that results in the
failure of an image to be recorded or to be recorded
in a format that is machine sensible.
Warning Against Copyright Infringement
Please note that Canon digital cameras are intended
for personal use and should never be used in a
manner that infringes upon or contravenes
international or domestic copyright laws and
regulations. Please be advised that in certain cases
the copying of images from performances,
exhibitions, or commercial properties by means of a
camera or other device may contravene copyright or
other legal rights even if the image was shot for
personal use.
Warranty Limitations
This camera's warranty is only effective in the
country of sale. If a problem arises while the camera
is in use abroad, please convey it back to the country
of sale before proceeding with a warranty claim to a
Canon Customer Support Help Desk.
For Canon Customer Support contacts, please
see the Canon Limited Warranty supplied with
your camera.
5
Camera Body Temperature
If your camera is used for prolonged periods, the
camera body may become warm. Please be aware
of this and take care when operating the camera for
an extended period.
About the LCD Monitor
The LCD monitor is produced with extremely high-
precision manufacturing techniques. More than
99.99% of the pixels operate to specification. Less
than 0.01% of the pixels may occasionally misfire or
appear as red or black dots. This has no effect on
the recorded image and does not constitute a
malfunction.
Video Format
Please set the camera's video signal format to the
one used in your region before using it with a TV
monitor (p. 67).
Language Setting
Please see page 23 to change the language setting.
Please read through the "Read This First" section
(p. 4) before using your camera.
Safety Precautions
z Before using the camera, please ensure that you
read and understand the safety precautions
described below. Always ensure that the camera is
operated correctly.
z The safety precautions noted on the following
pages are intended to instruct you in the safe and
correct operation of the camera and its accessories
to prevent injuries or damage to yourself, other
persons and equipment.
z In the next few pages, the term "equipment" refers
primarily to the camera, its batteries, separately
sold battery charger and separately sold compact
power adapter.
6
Warnings
zDo not aim the camera directly into the sun or at other intense
light sources which could damage your eyesight.
zDo not trigger the flash in close proximity to human or animal
eyes. Exposure to the intense light produced by the flash may
damage eyesight. In particular, remain at least one meter (39
inches) away from infants when using the flash.
zStore this equipment out of the reach of children and infants.
Accidental damage to the camera or batteries by a child could
result in serious injury. In addition, placement of the strap around a
child’s neck could result in asphyxiation.
zDo not attempt to disassemble or alter any part of the
equipment that is not expressly described in this guide.
Disassembly or alteration may result in high-voltage electrical
shock. Internal inspections, alterations and repairs should be
conducted by qualified service personnel authorized by your
camera distributor or a Canon Customer Support Help Desk.
zTo avoid the risk of high-voltage electrical shock, do not touch
the flash portion of the camera if it has been damaged.
Similarly, never touch internal portions of the equipment that
become exposed as a result of damage. There is a risk of high-
voltage electrical shock. Please take the first opportunity to consult
your camera distributor or a Canon Customer Support Help Desk.
zStop operating the equipment immediately if it emits smoke or
noxious fumes. Failure to do so may result in fire or electrical
shock. Immediately turn the camera's power off, remove the
batteries and unplug the power cord from the power outlet. Confirm
that smoke or fume emissions have ceased. Please consult your
camera distributor or the closest canon Customer Support Help
Desk.
zStop operating the equipment immediately if it is dropped or
the casing is damaged. Failure to do so may result in fire or
electrical shock. Immediately turn the camera's power off, remove
the batteries or unplug the power cord from the power outlet.
Please consult your camera distributor or the closest Canon
Customer Support Help Desk.
zDo not allow the equipment to come into contact with, or
become immersed in, water or other liquids. Do not allow
liquids to enter the interior. The camera has not been waterproofed.
If the exterior comes into contact with liquids or salt air, wipe it dry
with a soft, absorbent cloth. In the event that water or other foreign
substances enter the interior, immediately turn the camera's power
off and remove the batteries or unplug the power cord from the
power outlet. Continued use of the equipment may result in fire or
electrical shock. Please consult your camera distributor or the
closest Canon Customer Support Help Desk.
zDo not use substances containing alcohol, benzene, thinners
or other flammable substances to clean or maintain the
equipment. The use of these substances may lead to fire.
7
zRemove the power cord on a regular periodic basis and wipe
away the dust and dirt that collects on the plug, the exterior of
the power outlet and the surrounding area. In dusty, humid or
greasy environments, the dust that collects around the plug over
long periods of time may become saturated with humidity and
short-circuit, leading to fire.
zDo not cut, damage, alter or place heavy items on the power
cord. Any of these actions may cause an electrical short circuit,
which may lead to fire or electrical shock.
zDo not handle the power cord if your hands are wet. Handling it
with wet hands may lead to electrical shock. When unplugging the
cord, ensure that you hold the solid portion of the plug. Pulling on
the flexible portion of the cord may damage or expose the wire and
insulation, creating the potential for fires or electrical shocks.
zUse only the recommended power accessories. Use of power
sources not expressly recommended for this equipment may lead
to overheating, distortion of the equipment, fire, electrical shock or
other hazards.
zDo not place the batteries near a heat source or expose them
to direct flame or heat. Neither should you immerse them in
water. Such exposure may damage the batteries and lead to the
leakage of corrosive liquids, fire, electrical shock, explosion or
serious injury.
zDo not attempt to disassemble, alter or apply heat to the
batteries. There is serious risk of injury due to an explosion.
Immediately flush with water any area of the body, including the
eyes and mouth, or clothing that comes into contact with the inner
contents of a battery. If the eyes or mouth contact these
substances, immediately flush with water and seek medical
assistance.
zAvoid dropping or subjecting the batteries to severe impacts
that could damage the casings. It could lead to leakage and
injury.
zDo not short-circuit the battery terminals with metallic objects,
such as key holders. It could lead to overheating, burns and other
injuries.
zBefore you discard a battery, cover the terminals with tape or
other insulators to prevent direct contact with other objects.
Contact with the metallic components of other materials in waste
containers may lead to fire or explosion. Discard the batteries in
specialized waste facilities if available in you area.
zPlease use Canon AA-size NiMH batteries and charger
recommended for use with these batteries. Use of another
charger may cause batteries to overheat or deform, posing risk of
fire injury and damage to the surroundings.
zDisconnect the battery charger or the compact power adapter
from both the camera and power outlet after recharging and
when the camera is not in use to avoid fires and other hazards.
zThe camera terminal of the separately sold compact power
adapter is designed for exclusive use with your camera. Do not
use it with other products or batteries. There is a risk of fire and
other hazards.
8
zExercise due caution when screwing on the separately sold
wide converter, tele-converter and conversion lens adapter. If
they loosen, fall off and shatter, the glass shards may cause an
injury.
CAUTIONS
zAvoid using, placing or storing the equipment in places
subject to strong sunlight or high temperatures, such as the
dashboard or trunk (boot of a car. Exposure to intense sunlight
and heat may cause the batteries to leak, overheat or explode,
resulting in fire, burns or other injuries. High temperatures may also
cause deformation of the casing. Ensure that there is good
ventilation when using the battery charger to charge the batteries.
zDo not store the equipment in humid or dusty areas. Storage in
such areas could lead to fire, electrical shock or other damage.
zBe careful not to bang the camera or subject it to strong
impacts or shocks that could lead to injury or damage the
equipment when wearing or holding it by the strap.
zBe careful not to cover the flash with your fingers or clothing
when shooting. The flash may be damaged and emit smoke or
noise. In addition, do not touch the surface of the flash after taking
several pictures in rapid succession. Either action could result in
burns.
zDo not operate the flash with dirt, dust or other items stuck to
its lens. The resulting heat build-up could damage the flash.
zEnsure that the battery charger or compact power adapter is
plugged into a power outlet of the specified rating, not over
the specified rating. The plug of the battery charger or compact
power adapter varies according to region.
zDo not use the battery charger or compact power adapter if
the power cord is damaged or if the plug is not fully inserted
into the power outlet.
zDo not allow metal objects (such as pins or keys) or dirt to
contact the charger terminals or plug.
zIf your camera is used for prolonged periods, the camera body
may become warm. Please take care when operating the camera
for an extended period as your hands may experience a burning
sensation.
9
Preventing Malfunctions
Avoid Strong Magnetic Fields
Never place the camera in close proximity to electric
motors or other equipment generating strong
electromagnetic fields. Exposure to strong magnetic
fields may cause malfunctions or corrupt image data.
Avoid Condensation Related Problems
Moving the equipment rapidly between hot and cold
temperatures may cause condensation (water
droplets) to form on its external and internal surfaces.
You can avoid this by placing the equipment in an
airtight, resealable plastic bag and letting it adjust to
temperature changes slowly before removing it from
the bag.
If Condensation Forms Inside the Camera
Stop using the camera immediately if you detect
condensation. Continued use may damage the
equipment. Remove the CF card, batteries or
compact power adapter from the camera and wait
until the moisture evaporates completely before
resuming use.
Extended Storage
When not using the camera for extended periods of
time, remove the batteries from the camera or battery
charger and store the equipment in a safe place.
Storing the camera for extended periods with
batteries installed will cause battery leakage and
damage the camera.
10 1. Preparing the Camera
1. Preparing the Camera
Components Guide
*
The following cables are used to connect the camera
to a computer or printer.
Computer:
Interface Cable IFC-400PCU (supplied
with the camera)
Direct Print Compatible Printers (Sold Separately):
z
CP Printers: Interface Cable IFC-400PCU (supplied
with the camera) or the Direct Interface Cable DIF-
100 (supplied with the printer).
z
Bubble Jet Printers
• Bubble Jet Direct Compatible Printers: Please refer
to your Bubble Jet printer user guide.
• PictBridge Compliant Printers: Interface Cable IFC-
400PCU (supplied with the camera)
z
PictBridge Compliant Non-Canon Printers: Interface
Cable IFC-400PCU (supplied with the camera)
Please refer to the System Map or the Direct Print User
Guide supplied with the camera for direct print
compatible printer information.
Tripod Socket
Battery Cover
p. 14, 141
Ring Release Button p. 138
Lens
CF Card Slot Cover
p. 15
Red-eye Reduction Lamp p. 36
Flash p. 34, 35, 36
Self-timer Lamp p. 49
Tally Lamp p. 53, 65
Neck Strap Mounts
Remote Sensor
1. Preparing the Camera 11
Attaching the Neck Strap
Attach the strap as illustrated.
Check that the strap does not come loose from the
strap mount when pulled. Perform the same steps
on the other side of the camera.
Avoid waving the camera about or catching it
on other items when suspending it from the
strap.
Attaching the Lens Cap
Fit the lens cap over the lens casing so that it
covers the entire lens. Always replace the lens cap
after use.
Attach the lens cap cord to the strap.
Remove the lens cap before turning on the
camera's power.
12 1. Preparing the Camera
Controls
Mode Lever p. 20
Viewfinder p. 24, 26
Shutter button p. 28
(Flash) Button
p. 35
Diopter Adjustment Dial p. 26
(Self-timer)/ (Continuous)
Button p. 49, 52
MF (Manual Focus)
Button p. 95
IS (Image Stabilizer)
Button p. 29
Speaker
Omni Selector
S(Up) T(Down) W(Left) X(Right)
SET/ (AF Frame Selector) Button p. 75
MENU Button p. 62
FUNC. (Function)/ (Single Image Erase)
Button p. 43, 61
(Light Metering) / (Microphone) Button p. 76, 101
(Shortcut)/JUMP Button p. 42, 69
DISPLAY Button p. 24
A/V OUT(Audio/Video Out) Terminal p. 118
DIGITAL Terminal p. 116
DC IN Terminal p. 143
LCD Monitor
p. 26
Terminal Cover
Movie Button p. 53
OFF Button
Zoom Lever
Shooting: (Telephoto)/ (Wide Angle) p. 27, 50
Playback: (Zoom in)/ (Zoom out) p. 40
Microphone
1. Preparing the Camera 13
Mode Dial
Use the mode dial to switch between
the Shooting modes.
z : Auto p. 27
The camera automatically selects
settings.
z Image Zone p. 45
The camera automatically selects
settings according to the image
composition type.
: Portrait
: Landscape
: Night Scene
: Fast Shutter
: Slow Shutter
: Stitch Assist p. 47
: Movie p. 53
z Creative Zone p. 71
The user selects exposure, aperture
or other settings to achieve special
effects.
: Program AE
: Shutter Speed-priority AE
: Aperture-priority AE
: Manual Exposure
: Custom
The indicator lights or blinks when the shutter button is pressed or the following operations are
underway.
z Power/Mode Indicator
Orange:Shooting mode
Green: Playback mode/Printer connection
Yellow: Computer connection
z
zz
z Indicator
Blinking Red:Recording to CF card/Reading CF card/Erasing from CF card/Transmitting data
(during a computer connection)
14 1. Preparing the Camera
Installing the Batteries/CF Card
Install the batteries and the CF card to get
ready for shooting.
Please use four AA-size alkaline batteries or
separately sold nickel metal hydride (NiMH)
batteries.
The use of the separately sold Compact Power
Adapter CA-PS700 is recommended to power the
camera during long usage sessions (p. 143).
The separately sold battery charger kit lets you
use rechargeable NiMH batteries to power the
camera (p. 140).
See Battery Performance (p. 150).
For information about the Battery and Charger Kit
and AA-size rechargeable NiMH batteries, see
the System Map (separate from this guide).
When the indicator blinks, the camera is writing,
reading, erasing or transmitting an image to or
from the card. Do not perform the following or
image data may be lost or corrupted:
zDo not shake the camera.
zDo not turn off the power or open the CF card
slot cover or the battery cover.
a
aa
aBe sure that the camera power is off
(p. 19). Slide the battery cover lock in
the direction of the arrow and open
the cover.
b
bb
bInsert the batteries as shown.
z You can check the orientation the batteries
should go in on the seal inside the battery
compartment.
c
cc
cClose the battery cover.
a
b
Battery cover lock
1. Preparing the Camera 15
a
aa
aSlide the CF card slot cover in the
direction of the arrow, and open it.
b
bb
bInsert the CF card with the label
facing up, then close the CF card slot
cover.
z Push the card in until the CF card eject button
fully extends. To remove the CF card, push the
CF card eject button and pull the card out.
b
CF card Eject Button
Label
a
Proper Battery Handling
z
Use AA-size alkaline or Canon AA-size NiMH batteries
(sold separately) only. For information on handling the
AA-size rechargeable NiMH batteries, see Using the
Power Kits (Sold Separately) (p. 140).
z
Never use manganese or lithium batteries, as these
battery types may overheat in the camera.
z
zz
z
Since the performance of alkaline batteries may
differ according to brand, the operating time of the
batteries you purchase may not be as long as the
batteries that came with the camera.
z
Camera operating time may shorten at low temperatures
when alkaline batteries are used. Also due to their
specifications, alkaline batteries may expire faster than
NiMH batteries. If you are using the camera in cold areas
or for a long time, we recommend using Canon’s AA-size
NiMH Battery Kit (a four-piece set).
zSee CF Cards and Estimated Capacities
(Recordable Images) (p. 151).
zYou are recommended to use CF cards that
have been formatted in your camera (p. 18).
The card supplied with the camera may be
used without further formatting.
16 1. Preparing the Camera
z
While it is possible to use AA-size nickel-cadmium
batteries, performance is unreliable and their use is not
recommended.
z
zz
z
Never mix unused and partially used batteries.
Always load four fresh (or fully recharged) batteries
at the same time.
z
zz
z
Be careful to load the batteries with their positive (+)
and negative (-) ends in the right direction.
z
zz
z
Never mix batteries of different types or from
different manufacturers. All four batteries should be
identical.
z
Before inserting the batteries, wipe the battery terminals
well with a dry cloth. Oil from one's skin or other dirt may
cause a considerable reduction in the number of
recordable images or reduce usage time.
z
Battery performance deteriorates at low temperatures
(especially with alkaline batteries). If you are using the
camera in cold areas and batteries are running down
faster than they should, you may be able to restore
performance by placing batteries in an inner pocket to
warm them up prior to use. But be careful that you don’t
put the batteries into a pocket together with a metal key
chain or other metallic objects, as these objects may
cause batteries to short-circuit.
z
If you do not plan to use the camera for a long time,
remove the batteries from the camera and store them in
a safe place. Batteries may leak and damage the camera
if left installed during prolonged periods of non-use.
WARNING
Never use damaged batteries or batteries whose
outer seal is completely or partially missing or
peeled off, as there is risk that such batteries may
leak, overheat, or burst. Always check the seals on
store-bought batteries before loading them, as
some batteries may come with defective seals. Do
not use batteries with defective seals.
Never use batteries that look like this.
Batteries with all or part of the seal
(electrical insulation sheath) peeled off.
The positive electrode (plus terminal) is flat.
The negative terminal is correctly formed
(protruding from the metal base), but the
seal does not extend up over the edge of the
metal base.
1. Preparing the Camera 17
Battery Status Indications
The following icons or messages indicate the battery
status on the LCD monitor (or viewfinder).
CF Card Handling Precautions
z CF cards are high-precision electronic devices. Do
not bend, force, or subject them to shocks or
vibration.
z Do not attempt to disassemble or alter a CF card.
z Moving a CF card rapidly between temperature
extremes may cause condensation to form in the
card, leading to potential malfunctions. To avoid
condensation formation, place the CF card in a
sealed plastic bag before moving it into a different
temperature zone and allow it to adjust slowly to
the new temperature. If condensation forms on the
CF card, put it aside until the water droplets have
evaporated completely.
z Place the CF card in the supplied case for storage.
Batteries are beginning to run low. Replace or
recharge the batteries if you wish to continue
using the camera.
Change the
batteries
Batteries are fully depleted and the camera
can no longer operate. You should replace the
batteries immediately.
z Do not use or store CF cards in the following types
of locations.
- Locations subject to dust or sand
- Locations subject to high humidity and high
temperatures
Microdrives are a recording medium with a hard
disk. Their merits are a large capacity and a low
price per megabyte of capacity. However, they can
be more susceptible to vibrations and shocks than
CF cards, which use durable flash memories.
Please be careful, therefore, not to subject the
camera to vibrations or shocks when using a
microdrive, especially while recording or playing
back.
18 1. Preparing the Camera
Formatting a CF Card
You should always format a new CF card or one from
which you wish to erase all images and other data.
If the camera does not work properly, the
inserted CF card may be malfunctioning.
Reformatting the CF card may solve the
problem.
When a non-Canon brand CF card is
malfunctioning, reformatting it may solve the
problem.
CF cards formatted in another camera,
computer or peripheral device may not operate
correctly. When that happens, reformat the CF
card with this camera.
The capacity of the CF card displayed after
formatting will be less than the rated capacity
of the CF card. This is not a malfunction of the
CF card or camera.
Please note that formatting (initializing) a CF
card erases all data, including protected
images and other file types. Please check the
contents of the CF card before formatting it.
a
aa
aTurn the power on (p. 19).
b
bb
bPress the MENU button, and then the
X
XX
X arrow on the omni selector.
The [ (Set up)] menu appears.
c
cc
cSelect [Format] using the S
SS
S or T
TT
T
arrow on the omni selector, then
press the SET button.
b
c
a
1. Preparing the Camera 19
a
aa
aSelect [OK] using the W
WW
W or X
XX
X arrow
on the omni selector, then press the
SET button.
The indicator blinks red and formatting starts. Wait
until the indicator goes off.
z To cancel instead of erasing, select [Cancel] and
press the SET button.
b
bb
bPress the MENU button.
b
a
Indicator
Turning the Power On/Off
The power/mode indicator remains lit while the power of
the camera is on. The power/mode indicator indicates
the state of the camera as follows.
Orange: Shooting mode
Green: Playback mode/Printer connection mode*
Yellow: Computer connection mode*
Off: The power of the camera is off.
*
For printer connection mode, see the Direct Print
User Guide. For computer connection mode, see
the Software Starter Guide.
You will hear a start-up sound and see the start-
up image when the power comes on (p. 111).
The start-up image does not appear when the
viewfinder display is on in Shooting mode or
the A/V OUT terminal is connected to a TV.
Be careful not to touch the lens when shooting.
Please also refrain from forcing the lens with
fingers or other objects. It could lead to
malfunctions or damage the camera. If this
occurs, turn the camera off and back on.
Turning on the camera without the start-up
sound and image
Press and hold the button, then turn on the
power. You can also turn the power on with the
LCD monitor closed.
20 1. Preparing the Camera
a
aa
aTurn the mode lever to (Shooting)
or (Playback) while pressing the
release button.
The power/mode indicator lights orange or green.
b
bb
bPress the OFF button to turn the
power off.
ab
Switching Between Shooting and Playback
You can quickly switch between Shooting mode and
Playback mode. This is convenient when you wish to
shoot again after checking or deleting an image
immediately after it is shot.
Shooting Mode Playback Mode
Turn the mode lever to (Playback) while
pressing the release button (p. 39).
z The camera switches to Playback mode, but the
lens does not retract (the lens will retract if you turn
the mode lever to (Playback) once more).
Playback Mode Shooting Mode
Remove the lens cap and press the shutter button
halfway.
You can also turn the mode lever to (Shooting)
while pressing the release button (p. 27).
1. Preparing the Camera 21
Setting the Date/Time
The first time the camera power is turned on or
whenever the lithium battery charge is low,
start from Step .
Setting the date and time settings does not
cause the date/time stamp to appear on
images. For printing images with the date on
them, refer to the Direct Print User Guide or
Software Starter Guide.
See Replacing the Date Battery (p. 144).
a
aa
aTurn the power on (p. 19).
b
bb
bPress the MENU button, and then the
X
XX
X arrow on the omni selector.
The [ (Set up)] menu appears.
b
a
22 1. Preparing the Camera
a
aa
aSelect [Date/Time] using the S
SS
S or T
TT
T
arrow on the omni selector, then
press the SET button.
a
a
aa
aSet the date and time.
z Select the item you wish to set using W or X
and set its value using the S or T arrow on the
omni selector.
b
bb
bCheck that the date and time display
correctly, press the SET button and
press the MENU button.
z The date can be set up to the year 2037.
a
b
1. Preparing the Camera 23
Setting the Language
a
aa
aTurn the power on (p. 19).
b
bb
bPress the MENU button, and then the
X
XX
X arrow on the omni selector.
The [ (Set up)] menu appears.
z In Playback mode, you can change the
language by holding the SET button while you
press the JUMP button. This function cannot be
used during movie playback or during a printer
connection.
b
a
a
aa
aSelect [Language] using the S
SS
S or T
TT
T
arrow on the omni selector, then
press the SET button.
b
bb
bSelect a language using the S
SS
S, T
TT
T, W
WW
W
or X
XX
X arrow on the omni selector, then
press the SET button.
c
cc
cPress the MENU button.
c
b
a
a
b
24 1. Preparing the Camera
Using the Viewfinder and the LCD Monitor
Viewfinder Display
(Information View)
Pressing the DISPLAY button switches the LCD monitor display mode.
A
lso, closing the LCD monitor causes the viewfinder to display.
Shooting Mode
LCD Monitor Display
(No Information)
LCD Monitor Display
(Information View)
About the AF Frame
Green: Focusing Complete
Yellow: Focusing Difficulty
*The AF frame does not
appear when it is set to Auto
or during Reverse Display.
MF Indicator
Shots Remaining or
Remaining Movie
Time/Elapsed Time
(Shooting Mode)
Aperture Value
Shutter Speed
AF Frame
Spot Metering Frame
Playback Mode
Detailed Display
Standard Display
Single Image Playback
Index Playback
: Press the DISPLAY button
No Information
Histogram (p. 154)
The combined optical
zoom and digital zoom
factor displays.
AF Frame
Spot Metering Frame
1. Preparing the Camera 25
Display Contents
Function Icon
Shooting
Mode
Playback
Mode
Reference Page
Information View
No Information
Detailed Display
Standard Display
Shooting
Modes
{ –
*1
{
*2
–
p. 45, 71
Exposure
Compensation
{ – {
*3
–p.78
AE Lock/FE Lock
{{––
p. 86, 87
Light Metering
Mode
{ – { –p.76
White Balance
(WB)
*4
{ – { –p.79
Drive Mode { –––
p. 49, 52
ISO Speed { – { –p.81
Photo Effect { – { –p.82
Bracket { ––– p.84
Flash { ––– p.34
Red-eye
Reduction
{ ––– p.36
Flash Exposure
Compensation
{ – {
*3
–p.89
-2 – +2
*
1
(Movie) appears even in No Information display mode.
*2
(Custom) does not appear.
*3
The value for each content also appears.
*4
The icon does not display in Playback mode.
*5
Zoom powers reflect the combined optical and digital zoom
effects. "10x" is the telephoto-end setting of the optical zoom.
Flash Output { ––– p.89
Compression { – {{ p. 32
Resolution { – {{ p. 32
Resolution
(Movies)
{ – { –p.32
Frame Rate
(Movies)
{ – { –p.32
Digital Zoom
*5
{{–– p.50
Low Battery {{{{ p. 17
Auto Rotate { – – – p. 108
Camera Shake
Warning
{{–– p.26
Manual Focus {{–– p.95
Image Stabilizer
{ ––– p.29
Movie Recording
{{–– p.53
Sound Memo
(WAVE file)
––{{ p. 101
Movie – – {{ p. 57
Protection Status
––{{ p. 106
10x 13x 16x 20x 25x 32x
z
(red)
26 1. Preparing the Camera
Even in the no information display mode,
shooting information appears for approximately 6
seconds (shooting information may not appear
depending on the camera settings at that time).
The camera shake warning icon will appear
on the LCD monitor (or viewfinder) in low light
conditions while the camera is preparing to
shoot. When this icon appears, use one of the
following shooting methods.
- Set the flash to On or Auto
- Set the image stabilizer function to On (p. 29)
- Fix the camera to a tripod
Please note that image information recorded
by this camera may not display correctly on
other cameras and image information recorded
by other cameras may not display correctly on
this camera.
Overexposure Warning
Overexposed portions of the image blink. The
overexposure warning appears at the following
times.
When reviewing an image right after it is shot
in the LCD monitor (information view) or in the
viewfinder
In the detailed display mode of the Playback
mode
Using the LCD Monitor
The LCD monitor can be opened to the following
range of positions.
Opened from left to right 180
degrees. Tilted forward 180
degrees toward the lens or
backward 90 degrees.
z
When the LCD monitor is
opened left 180 degrees and
tilted 180 degrees toward the
lens, the displayed image is
automatically flipped and
reversed (the Reverse Display
function) so that it appears
correctly from in front of the lens.
Fold the LCD monitor back
against the camera body until it
clicks into place.
zIf it is not fully closed, the
image will appear reversed.
Always keep the LCD monitor
closed to protect it when the
camera is not in use.
Using the Viewfinder
If the surroundings are too bright (for example, when
you are shooting outdoors) and images on the LCD
monitor are not clear, use the viewfinder for shooting.
Adjust the viewfinder focus with the diopter
adjustment dial (p. 12) so the displayed information
(p. 24) appears clearly.
a
b
2. Shooting-The Basics 27
2. Shooting-The Basics
Auto Mode
a
aa
aTurn the mode lever to (Shooting).
b
bb
bSet the mode dial to .
c
cc
cIf you are using the LCD monitor,
open it.
z The LCD monitor can also be rotated. When the
LCD monitor is tilted 180 degrees, the displayed
image is automatically flipped and reversed (the
Reverse Display function) so that it appears
correctly from in from of the lens (you can
disable the Reverse Display function (p. 65)).
b
Standard shooting
a
Seen from the lens side
c
a
aa
aAim the camera at the subject.
b
bb
bUse the zoom to achieve the desired
composition in the LCD monitor (or
viewfinder).
z Turning the zoom lever toward magnifies the
subject (telephoto). Turning the zoom lever toward
decreases the size of the subject (wide angle).
The speed at which the magnification change is
determined by the way the zoom lever is turned.
Turning the zoom lever in one swift movement
completely to the right/left enables fast zooming.
For slow zooming, slowly turn the zoom lever
halfway.
z The angle of view can be adjusted within the 38 to
380 mm range, in 35mm film equivalent.
b
Wide angle
Telephoto
a
AF Frame
28 2. Shooting-The Basics
z The combined use of the digital zoom and optical
zoom enables magnified shooting up to approx.
32x (p. 50). The digital zoom cannot be used with
some shooting modes (p. 162). Images become
coarser the more they are digitally zoomed.
a
aa
aLightly press the shutter button
(pressing halfway) to focus.
Two beeps will sound when the camera has finished
focusing, and the AF frame appears green.
z The AF frame will light yellow and the beep will
sound one time if the subject is difficult to focus
on. When the AF frame is set to Auto, it will not
appear.
z The shutter speed and aperture value are
automatically determined and show on the LCD
monitor (or viewfinder). The exposure
compensation (p. 78) and focus (p. 95) are also
automatically set.
a
b
b
bb
bPress the shutter button all the way.
You will hear the shutter sound when the shot is
complete. Do not move the camera until you hear
this sound. The picture appears for two seconds.
See page 162 for settings that can be changed
in this mode.
The LCD monitor and viewfinder have a field of
vision of approximately 100% of the actual
shooting image.
Images are first saved into the camera's
internal memory before being recorded onto
the CF card, allowing the next images to be
taken immediately as long as sufficient space
is available in the internal memory.
The indicator blinks red while data is recorded
onto the CF card.
The beep and shutter sound can be set to On/
Off using the menu (p. 66).
If the shutter sound is set to [Off] and the mute
option is set to [Off], the camera will beep once
when the shutter button is pressed all the way.
Shots cannot be taken while the flash is
charging.
2. Shooting-The Basics 29
You can change the length of time images
show on the LCD monitor after shooting, or set
it so they do not show at all (p. 31).
Image Stabilizer Function
The image stabilizer function allows you to minimize
the camera shake effect (blurred images) when you
shoot distant subjects that have been magnified or
when you shoot in dark conditions. This function's
default setting is [On].
z Pressing the IS button switches the function On
and Off. When it is set to On, appears.
z Holding the IS button allows you to select the
image stabilizer mode. The following icons appear.
Select a setting using the W or X arrow on the
omni selector and press the IS button.
(Standard): Standard Shooting
(With teleconverter lens):
Select when the separately sold
teleconverter lens (p. 137) is
mounted.
(With wide angle lens):
Select when the separately sold wide
angle lens (p. 137) is mounted.
30 2. Shooting-The Basics
zCamera shake may not be fully corrected
when shooting with slow shutter speeds with
such shooting scenes as evening shots. In
this case, affix the camera to a tripod.
zIf camera shake is too strong, it may not be
fully corrected.
Reviewing an Image Right after Shooting
After a photo is taken, the image displays for
two seconds (to change this setting, see page
31). There are two ways to display the image
for longer:
z Keeping the shutter button pressed
z Pressing the SET button while the image
is displayed
Press the shutter button halfway again to stop
displaying it and shoot an image.
You can perform the following while images are
displayed.
Display images in detailed display mode
(p. 26)
Magnify images (p. 40)
Erase images individually (p. 43)
Attach Sound Memos (p. 101)
Mode Dial
2. Shooting-The Basics 31
Changing the Image Display Duration
a
aa
aTurn the power on (p. 19), and press
the MENU button.
The [ (Rec.)] menu appears.
a
b
a
c
b
bb
bSelect [Review] using the S
SS
S or T
TT
T
arrow on the omni selector and
select a duration setting using the W
WW
W
or X
XX
X arrow on the omni selector.
Off:Images do not display
2 to 10 sec.:Images appear for the time selected
even if the shutter button is released.
c
cc
cPress the MENU button.
z You can continue to display the image as long
as the shutter button is fully held pressed
regardless of the Review setting.
z Another picture can be taken even while the last
is displayed.
32 2. Shooting-The Basics
Changing the Resolution and Compression
You can change the resolution, compression
(still images) and frame rate (movies, p. 56)
settings to suit the purpose of the image you
are about to shoot.
Still Images
* Paper sizes vary according to region.
Mode Dial
Resolution
Purpose
Display Pixels
L (Large) 2048 x 1536
High
Low
zPrint A4 size* 210 x 297 mm
(8.3 x 11.7 in.) prints
zPrint letter size* 216 x 279
mm (8.5 x 11 in.) prints
M1 (Medium 1) 1600 x 1200
zPrint postcard size 148 x
100 mm (6 x 4 in.) prints
zPrint L size 119 x 89 mm
(4.7 x 3.5 in.) prints
M2 (Medium 2) 1024 x 768
Print credit card size 86 x 54
mm (3.4 x 2.1 in.) prints
S (Small) 640 x 480
zSend images as e-mail
attachments
zShoot more images
Movies
*
The compression rate for is Fine. The
compression rate for and is Normal.
Compression Purpose
Superfine
High Quality
Normal
Shoot higher quality images
Fine Shoot normal quality images
Normal Shoot more images
Resolution
Quality
Recording
Time
Purpose
640 x 480 pixels
(Fine)*
High
Normal
Short
Long
Shoot higher quality movies
640 x 480 pixels*
Shoot normal quality movies
320 x 240 pixels*
Shoot longer movies
Frame Rate Quality
Recording
Time
Purpose
Approx. 30 frames/sec.
Full-
motion
Short
Quality-priority
shooting
Approx. 15 frames/sec.
Normal Long
Time-priority shooting
2. Shooting-The Basics 33
a
aa
aPress the FUNC. button.
b
bb
bSelect * (2048 x 1536) using the S
SS
S
or T
TT
T arrow on the omni selector.
* The current setting is displayed.
c
cc
cSelect the resolution you wish to set
using the W
WW
W or X
XX
X arrow on the omni
selector, then press the SET button.
c
b
a
Number of shots remaining
(Only displayed when the
resolution or compression is
selected.)
a
aa
aSelect the compression you wish to
set using the W
WW
W or X
XX
X arrow on the
omni selector, then press the SET
button.
z You can shoot the image right after selecting
settings by pressing the shutter button. This
screen will appear again, once the image is
shot.
z In the case of a movie clip, the remaining
shooting time (in seconds) appears.
z See Image File Sizes (Estimated) (p. 152).
a
b
34 2. Shooting-The Basics
z Types of CF cards and number of shots
remaining (p. 151).
b
bb
bPress the FUNC. button and shoot
the image.
Using the Built-in Flash
Use the flash according to the guidelines
below.
The flash operates as shown below when the Flash
Pop-up option (p. 64) is set to [Auto].
It may take longer for the camera to autofocus
right after the flash pops up.
Mode Dial
Auto with red-
eye reduction
The flash fires automatically as required by
the lighting level, and the red-eye reduction
lamp fires each time the main flash fires.
Auto
The flash fires automatically as required by
the lighting level.
Flash on with
red-eye
reduction
The red-eye reduction lamp and the flash
always fire.
Flash on The flash always fires.
Flash off The flash does not fire.
2. Shooting-The Basics 35
a
aa
a
Press the button to switch between
flash modes and shoot the image.
The selected flash mode appears on the LCD
monitor (or viewfinder).
z You can switch between settings by pressing
the button. The flash setting may not switch
with certain shooting modes.
When the red-eye reduction function is on (p. 36)
When the red-eye reduction function is off
z Be sure to close the flash after use.
a
When the Flash Pop-up Function is Set to [Off]
You can manually set the flash when Flash
Pop-up is set to [Off].
a
aa
aPop up the flash by pressing the
button and shoot the image.
b
bb
bWhen you are not using the flash,
press the flash down until it clicks.
Mode Dial
Flash is open ( ) The flash always fires.
Flash is closed ( ) The flash does not fire.
a
b
36 2. Shooting-The Basics
Setting the Red-eye Reduction Function
The red-eye reduction lamp fire when the flash
is used in dark areas. This reduces light
reflecting back from the eyes and making them
appear red.
a
aa
a
Power the camera in (Shooting) mode
(p. 19) and press the MENU button.
The [ (Rec.)] menu appears.
Mode Dial
b
c
a
b
bb
bSelect [Red-eye] using the S
SS
S or T
TT
T
arrow on the omni selector.
c
cc
cSelect [On] using the W
WW
W or X
XX
X arrow
on the omni selector and press the
MENU button.
z appears on the LCD monitor (or viewfinder) if
it is set to Information View display.
z When shooting with the red-eye reduction
function, the subjects must look right at the red-
eye reduction lamp for this mode to be effective.
Try asking them to look directly at the lamp.
Even better results can be obtained by shooting
with the lens set to a wide angle, increasing the
lighting in indoor settings or approaching closer
to the subject.
Setting the Slow Synchro
You can shoot images using the flash with a slow
shutter speed. This helps brighten up dark
backgrounds when shooting night scenes or with
indoors lighting conditions.
Mode Dial
2. Shooting-The Basics 37
a
aa
aPower the camera in
(Shooting)
mode (p. 19) and press the MENU
button.
The [ (Rec.)] menu appears.
b
bb
bSelect [Slow Synchro] using the S
SS
S or
T
TT
T arrow on the omni selector.
c
cc
cSelect [On] using the W
WW
W or X
XX
X arrow
on the omni selector and press the
MENU button.
b
c
a
The flash fires with automatic adjustments
when [Flash Adjust] is set to [Auto] in the Rec.
menu. When shooting in mode, or with
[Flash Adjust] set to [Manual], the flash fires
with the manually set adjustments.
When [Flash Adjust] is set to [Auto], the flash
fires twice. A pre-flash will fire and will be
followed by the main flash. The pre-flash is
used by the camera to obtain the subject's
exposure data so that the main flash can be
set to the optimal intensity for the shot.
The fastest shutter speed for flash
synchronization is 1/250 second. The camera
automatically resets the shutter speed to 1/250
second if a faster speed is selected.
Shots cannot be taken while the flash is
charging.
When shooting with a high ISO sensitivity and
using the built-in flash, there is more of a
chance of overexposure the closer you are to
the subject.
38 2. Shooting-The Basics
The flash may take up to approximately 10
seconds to charge in some cases. Actual times
will vary according to usage and the battery
charge.
The flash exposure and the flash output can be
changed (p. 89).
When shooting with [Slow Synchro] set to [On],
camera shake may become a factor. We
recommend the use of a tripod.
The flash setting is saved when the camera is
turned off in the , , and shooting
modes.
3. Playback-The Basics 39
3. Playback-The Basics
Displaying Images Individually
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
The last recorded image appears on the LCD
monitor (or viewfinder).
b
bb
bMove between images using the W
WW
W or
X
XX
X arrow on the omni selector.
z Use W to move to the previous image and X to
move to the next. Holding W or X moves more
rapidly between images, but the images will not
appear as clearly.
b
a
z When you press the W or X arrow on the omni
selector after having pressed the JUMP button,
the camera jumps 10 images behind or ahead. If
you press the JUMP button once more, the
camera returns to the single image playback
screen.
z Press the DISPLAY button to show the data for
the displayed image (p. 24).
z Press the button to quickly deleted the
displayed image (p. 43).
You may not be able to play back images that
have been shot with another camera or edited
on a computer with other software applications.
40 3. Playback-The Basics
Magnifying Images
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
b
bb
bTurn the zoom lever toward to
magnify the image and toward to
cancel the magnified display.
z In single image playback, images can be
magnified up to 10 times. Hold the SET button
down and turn the zoom lever toward to
cycle through each setting, approximately 2.5
times, to approximately 5 times and 10 times.
a
b
Approximate positionApproximate position
Magnified approximately 5 times Magnified approximately 10 times
z You can move around the magnified image
using the W, X, S or T arrow on the omni
selector.
z Movie frames and index playback images
cannot be magnified.
z You can magnify an image while it is displayed
on the LCD monitor (or viewfinder) immediately
after the image is shot (p. 31).
3. Playback-The Basics 41
Viewing Images in Sets of Nine (Index Playback)
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
b
bb
bTurn the zoom lever toward .
z Nine images appear at once (index playback).
a
b
Movie
Frame
a
aa
aChange the image selection using
the W
WW
W, X
XX
X, S
SS
S or T
TT
T arrow on the omni
selector.
z Press the DISPLAY button to show the data for
the displayed image (p. 24).
b
bb
bTurn the zoom lever toward .
z Index playback cancels and the display reverts
to single image playback.
a
b
Pressing the
T arrow in this
row displays
the next set of
nine images.
Pressing the
S arrow in
this row
displays the
previous set of
nine images.
42 3. Playback-The Basics
JUMP
JUMPJUMP
JUMP Jumping Between Images
a
aa
aPress the JUMP button while in
single image playback (p. 39) or
index playback (p. 41).
The jump bar appears.
b
bb
bChange the image selection using
the W
WW
W or X
XX
X arrow on the omni
selector.
z Single Image Playback: The 10th image ahead
or behind is displayed.
b
a
Jump Bar
c
z Index Playback: The previous or next 9 images
are displayed.
c
cc
cPress the JUMP button.
The jump bar disappears and the camera reverts
to single image playback or index playback.
4. Erasing 43
4. Erasing
Erasing Images Individually
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
The last recorded image appears on the LCD
monitor (or viewfinder).
Please note that erased images cannot be
recovered. Exercise caution before erasing a
file.
b
c
a
b
bb
bSelect the image you wish to erase
using the W
WW
W or X
XX
X arrow on the omni
selector and press the .
c
cc
cSelect [Erase] using the W
WW
W or X
XX
X
arrow on the omni selector.
z To cancel instead of erasing, select [Cancel].
z Protected images cannot be erased with the
erase function (p. 106).
44 4. Erasing
Erasing All Images
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
The [ (Play)] menu appears.
b
bb
bSelect [Erase all] using the S
SS
S or T
TT
T
arrow on the omni selector.
Please note that erased images cannot be
recovered. Exercise caution before erasing a
file.
b
c
a
c
cc
cSelect [OK] using the W
WW
W or X
XX
X arrow
on the omni selector.
z To cancel instead of erasing, select [Cancel].
z Protected images cannot be erased with the
erase function (p. 106).
The [Erase all] function erases all the image data
recorded on the CF card. You should format the
CF card when you want to erase not only image
data but also all the data contained on the card
(p. 18).
5. Useful Shooting Functions 45
5. Useful Shooting Functions
Using the Mode Dial (Image Zone)
Landscape
Use this mode to shoot
spacious landscape
scenes.
Portrait
Night Scene
Fast Shutter
Slow Shutter
Use this mode when
you want the subject to
appear sharp and the
background to blur.
Use this mode to
capture human subjects
against the backdrop of
an evening sky or night
scene. The subject is
illuminated with light
from the flash while the
backdrop is captured at
a slow shutter speed.
Use this mode to
shoot fast moving
objects.
Use this mode to shoot
moving objects to make
them appear blurred,
such as river rapids.
Stitch Assist (p. 47)
Use this mode when
taking shots that you want
to combine into a
panorama.
Settings fitting the shooting conditions of your subject can easily be set using the mode dial.
Movie (p. 53)
Use this mode to shoot
movies. Sound is also
recorded simultaneously.
46 5. Useful Shooting Functions
a
aa
aTurn the mode lever to the left to set
the camera to Shooting mode.
b
bb
bTurn the mode dial and set it to the
desired function as shown above.
c
cc
cUse the zoom lever to achieve the
desired composition (relative to
subject size).
d
dd
dPress the shutter button halfway to
lock the focus, then press all the way
to shoot the image.
a
b
c
d
z Shooting procedures are the same as for the
mode (p. 27).
See page 162 for settings that can be changed
in this mode.
Use the following shooting procedures
according to the selected function.
You can achieve a better blurring effect of the
background by making sure the upper half of your
subject fills the entire LCD monitor (or viewfinder).
You can enhance the blurring effect of the
background even more by setting the lens to its
telephoto end setting.
The camera shake warning icon may appear on
the LCD monitor (or viewfinder) since slower shutter
speeds are frequently used in this mode. If this
happens, affix the camera to a tripod.
The shutter speed slows down. Even if you use the
flash, tell your subjects not to move for a few
moments.
If the Night Scene mode is used to shoot mid-day
shots, the same effects as with the mode can
be obtained.
The slow synchro option automatically turns on.
Noise in the image may be more apparent with dark
subjects.
Always use a tripod to prevent camera shake.
5. Useful Shooting Functions 47
Shooting Panoramic Images (Stitch Assist)
Use this mode to shoot a series of overlapping
frames for merging (stitching) into a large
panoramic image using a computer.
Please use the bundled PhotoStitch program
to merge the images on a computer.
Framing a Subject
PhotoStitch detects the overlapping portions of
adjoining images and merges them. When
composing shots, try to include a distinctive item
(landmark, etc) in the overlapping portions.
Compose each frame so that it overlaps 30 to
50% of the adjoining image. Try to keep the
vertical misalignment to within 10% of the
image height.
Do not include moving items in the overlap.
Do not try to stitch images that include both
distant and close subjects. Objects may
appear warped or doubled up.
Make the brightness in each image consistent.
The final image will appear unnatural if the
difference in brightness is too great.
For good results, pan (swivel) the camera to
take successive shots.
48 5. Useful Shooting Functions
To shoot close-ups, slide the camera over the
subject, keeping it parallel as you move.
Shooting
Images can be shot in the following 5
sequences in Stitch Assist mode.
See page 162 for settings that can be changed
in this mode.
A custom white balance setting (p. 79) cannot
be set in mode. To use a custom white
balance setting, first set it in another shooting
mode.
The settings in place for the first image are
locked in and cannot be changed for
subsequent shots.
A TV cannot be used as the monitor for
shooting in this mode.
Horizontally, left to right
Horizontally, right to left
Vertically, bottom to top
Vertically, top to bottom
Clockwise starting at the top left
a
aa
aTurn the mode dial to .
b
bb
bSelect the shooting sequence using
the W
WW
W or X
XX
X arrow on the omni
selector, then press the SET button.
The shooting sequence is set.
z You can also press the shutter button directly to
shoot without pressing the SET button.
c
cc
cShoot the first image.
z The exposure and white balance settings are
set and locked with the first image.
b
a
5. Useful Shooting Functions 49
a
aa
aCompose and shoot the second
image so that it overlaps the first.
z Minor discrepancies in the overlap can be
corrected with the software.
z
An image can be retaken. Press the
W
,
X
,
S
or
T
arrow on the omni selector to return to that frame.
z A maximum of 26 images can be recorded
either horizontally or vertically.
b
bb
bUse the same procedures to shoot
the remaining frames.
c
cc
c
Press the SET button after the last shot.
a
c
Sequence
Sequence
Using the Self-timer
a
aa
aPress the button.
The current setting is displayed.
z Pressing the
button cycles between
settings.
Mode Dial
b
a
50 5. Useful Shooting Functions
z You can switch between the and options
through the [ (Rec.)] menu (p. 64).
z When the self-timer is set to ( ), the
shutter activates 10 (2) seconds after the shutter
button is pressed fully.
b
bb
bCheck that or is displayed and
shoot the image.
z When is selected, the self-timer sounds and
the self-timer lamp starts blinking when the
shutter button is pressed all the way. The self-
timer sound and the blinking get faster two
seconds before the shutter activates.
z When is selected, the self-timer lamp blinks
fast from the beginning. The shutter activates in
two seconds.
z You can change the self-timer sound by
changing the setting in [Selftimer Sound] in the
[ (My Camera)] menu (p. 67).
Digital Zoom
With the combined optical and digital zoom
functions, images can be zoomed as follows:
13x, 16x, 20x, 25x and 32x.
Images become coarser the more they are
digitally zoomed.
The lens will zoom the maximum optical
telephoto setting and stop. To further zoom the
image digitally, turn the zoom lever toward
once more.
To zoom back out, turn the zoom lever toward
.
Mode Dial
5. Useful Shooting Functions 51
a
aa
aTurn the mode dial to any Shooting
mode except for or .
b
bb
bPress the MENU button to display the
[ (Rec.)] menu.
c
cc
cSelect [Digital Zoom] using the S
SS
S or
T
TT
T arrow, select [On] using the W
WW
W or
X
XX
X arrow on the omni selector and
press the MENU button.
d
c
b
d
dd
dTurn the zoom lever toward and
shoot the image.
52 5. Useful Shooting Functions
Continuous Shooting
Use this mode to shoot successive frames
while the shutter button is fully pressed.
The interval between frames may lengthen
somewhat when the internal memory becomes
full.
The flash can be used, but the interval
between images will lengthen to accommodate
the flash recharge time.
Mode Dial
a
aa
aPress the button.
The current setting is displayed.
z Pressing the
button cycles between
settings.
b
bb
bSelect .
a
5. Useful Shooting Functions 53
a
aa
aPress the shutter button halfway to
lock the focus.
b
bb
bPress the shutter button all the way
to shoot.
z Shooting will stop when the shutter button is
released.
z The shooting speed is 1.7 shots/second.*
* Large/Fine (These figures reflect Canon's
testing standard. The actual figures will vary
according to the shooting conditions and
settings.)
ab
Movie Mode
a
aa
aTurn the mode dial to .
The maximum recording time (in seconds) appears.
b
bb
bPress the Movie button.
The camera beeps once and shooting starts.
Sound is recorded simultaneously.
z When the Movie button is pressed again, the
camera beeps twice and shooting stops.
z The tally lamp blinks red during movie recording
and goes off when the recording session is over.
When [Tally Lamp] is set to [Off] in the Rec.
menu, the lamp does not blink (p. 65).
a
b
54 5. Useful Shooting Functions
z The maximum movie recordable time in one
movie shooting is approx. 1 hour and the
maximum recording capacity is 1 GB. These
figures will vary according to the type of CF
cards and their capacity.
When recording time reaches 1 hour, when the
CF card is about to become full or when the file
size is about to reach 1 GB, the remaining
shooting time displayed on the lower right
corner of the LCD monitor (or viewfinder) will
blink red and recording will stop automatically
approximately 10 seconds later.
z Recording times and recording capacities may
vary according to your camera usage (shooting
conditions, exterior conditions, etc.) and the
capacity of your CF card. When the camera's
internal available memory is low, the ! mark
appears in the lower right corner of the LCD
monitor (or viewfinder), indicating that shooting
will automatically end soon, regardless of the
remaining shooting time and recording capacity.
If the ! mark frequently appears, try the following
methods to solve the problem.
- Format the CF card before recording (p. 18).
- Avoid using the zoom during shooting.
- Set the resolution to (320 x 240) or set the
frame rate to (15 fps).
- Use a high speed CF card (such as the CF-
512MSH CF card).
5. Useful Shooting Functions 55
zThe recording time may not display properly
during shooting or filming may stop
unexpectedly with the following types of CF
cards.
- Slow recording cards
- Cards formatted on a different camera or a
computer
- Cards which have had images recorded and
erased repeatedly
Although the recording time may not display
properly during shooting, the movie will be
recorded correctly on the CF card. Recording
time will display properly if you format the CF
card in this camera (excluding slow recording
CF cards).
zBe careful not to touch the microphone while
shooting.
zIf the indicator blinks after a shot, this
indicates that the movie is being written to the
CF card. You cannot shoot again until it stops
blinking.
See page 162 for settings that can be changed
in this mode.
See page 32 for resolution and frame rate
information.
Sound is recorded monaurally.
There is no shutter sound in Movie mode.
zWhen the camera's internal temperature
rises, appears in red on the lower left
corner of the LCD monitor (or viewfinder). If
the temperature continues to rise, shooting
ends automatically to protect the CF card or
micro drive from overheating, the
[Overheated! Shutting down.] message
appears and the camera powers off. If this
happens, store the camera for approximately
30 minutes and wait until it has completely
cooled down before resuming use. The CF
card or micro drive may heat up but this does
not constitute a malfunction. However, for still
image shooting, there is no need to wait 30
minutes before resuming use.
56 5. Useful Shooting Functions
QuickTime 3.0 or higher is required to play
back movie files (AVI/Motion JPEG) on a
computer. (QuickTime (for Windows) is
bundled on the supplied Digital Camera
Solution Disk. On the Macintosh platform,
QuickTime 3.0 or later is generally bundled
with Mac OS 8.5 or later operating system.)
The following operations are available during
movie recording:
- Zooming (excluding the digital zoom)
- AF lock: Press the MF button. appears on
the LCD monitor (or viewfinder). You can
cancel AF lock by pressing the MF button
again.
- AE lock, exposure compensation: Press the
button. The exposure compensation bar
appears on the LCD monitor (or viewfinder).
You can change the exposure using the W or
X arrow. You can cancel AE lock by pressing
the button again.
- Image Stabilizer: Press the IS button to turn it
on or off.
Changing the Frame Rate
The number of frames shot per second when
shooting movies can be selected.
a
aa
aTurn the mode dial to .
b
bb
bPress the FUNC. button.
c
cc
cSelect * (30fps) using the S
SS
S or T
TT
T
arrow on the omni selector and
select the frame rate you wish to set
using the W
WW
W or X
XX
X arrow.
c
b
Recordable
Movie Time
d
d
5. Useful Shooting Functions 57
* The current setting is displayed.
: Shoots 30 frames per second
: Shoots 15 frames per second
z The number of recordable frames per second
varies according to the selected resolution
setting (p. 151).
z You can shoot the movie right after selecting
settings by pressing the Movie button. This
screen will appear again once the movie is shot.
d
dd
dPress the FUNC. button then press
the Movie button to start shooting.
Viewing/Editing Movies
You can play back movies recorded with the Movie
mode and delete unwanted portions from the
beginning or the end of movie clips.
You may experience frame dropping if you are
using a slow reading CF card and the recording
resolution and frame rate are set to the following
settings.
- (640 x 480 Fine) resolution
- (640 x 480) resolution and (30 fps)
frame rate
zProtected movies cannot be edited (p. 106).
zIt may take some time to save an edited
movie as a new file depending on the file size.
If the batteries run out of charge partway
through, edited movie clips cannot be saved.
When editing movies, use separately sold,
fully charged AA-size NiMH batteries or
Compact Power Adapter CA-PS700.
58 5. Useful Shooting Functions
a
aa
aTurn the mode lever to the right to set
the camera to Playback mode.
b
bb
bSelect a movie using the W
WW
W or X
XX
X
arrow on the omni selector, then
press the SET button.
b
a
This mark
appears on
movie files
a
aa
aSelect a button from the movie
playback panel using the W
WW
W or X
XX
X
arrow on the omni selector, then
press the SET button.
Movie Playback Panel
(Exit): Returns to the screen in
Step
(Play): Plays back the movie
images and sounds
(First Frame): Shows the first frame
(Previous Frame):Rewinds if the SET button
is held down
(Next Frame): Fast forwards if the SET
button is held down
(Last Frame): Shows the last frame
(Edit): Edits the movie Step
a
Movie Playback Panel
5. Useful Shooting Functions 59
Playback Operations
ST:Adjusts the volume during playback
SET: Pauses playback. Press again to resume
playback.
When Playback Ends
The last frame remains displayed when playback
ends.
SET: Displays the movie playback panel. Press
again to play back the movie again from the
first frame.
z You may experience frame dropping and audio
breakup when playing back a movie on a
computer with insufficient system resources.
z The volume at which movies play back can also
be adjusted in the Play menu.
z Please adjust the audio sound level on the TV
when viewing movie files on a TV.
z If you are not editing the movie, operations end
here.
a
aa
aSelect a button from the movie
editing panel using the S
SS
S or T
TT
T arrow
on the omni selector, then press the
SET button.
(Cut Beginning):Deletes frames in the first
half of the movie
(Cut End): Deletes in the second half of
the movie
(Play): Plays back the temporarily
edited movie
(Save): Saves the movie
(Exit): Cancels movie editing and
reverts to the screen in step
z Movies with an original length of 1 second or
more can be edited in 1-frame units.
Movie Editing Panel
60 5. Useful Shooting Functions
b
bb
bSelect the range you wish to edit
using the W
WW
W or X
XX
X arrow.
c
cc
cSelect (Play) using the S
SS
S or T
TT
T
arrow and press the SET button.
The temporarily edited movie will start playing.
z The movie will stop if you press the SET button
while it is playing.
d
dd
dSelect
(Save) using the S
SS
S or T
TT
T
arrow and press the SET button.
z When (Exit) is selected, the edited movie is
not saved and the camera reverts to the screen
in Step .
e
ee
eSelect [Overwrite] or [New File] using
the W
WW
W or X
XX
X arrow and press the SET
button.
[Overwrite]:Saves the edited movie under the
same file name as the original movie.
The original data is deleted.
[New File]: Saves the edited movie under a new
file name. The original data is not
deleted.
z When there is not enough space left on the CF
card, only the overwrite function is available. If
this happens, S appears on the counter of the
movie editing bar.
6. Shooting-Advanced Functions 61
6. Shooting-Advanced Functions
Selecting Menus and Settings
Selecting Settings by Pressing the FUNC. Button (Only in Shooting Mode)
Photo Effect ( ) p. 82
Turn the mode lever to .
Press the FUNC. button.
Press the
S
or
T
arrow to select a function item.
Press the
W
or
X
arrow to select setting contents.
Press the FUNC. button.
Shoot the image.
Select a function item
using S or T
Select setting contents
using
W
or
X
Exposure Compensation (± 0)
p. 78
White Balance ( ) p. 79
ISO Speed ( ) p. 81
Bracket ( ) p. 84
Flash Adjust
(± 0)
p. 89
Flash Output p. 89
Resolution (L) p. 32
Compression ( ) p. 32
Resolution and Movie ( )
p. 32
( ) items in parentheses
show default settings.
Shoot
the image.
Frame Rate ( ) p. 56
62 6. Shooting-Advanced Functions
Press the MENU button.
Press the W or X arrow to switch between menu tabs.
Press the S or T arrow to select a menu item. (Depending on
the function, press the SET button after making a selection.)
Press the W or X arrow to select setting contents. (Depending
on the function, press the SET button after making a selection.)
Press the MENU button.
Shoot the image if in Shooting mode.
Selecting Settings by Pressing the MENU Button
Rec. Menu Play Menu Set up Menu My Camera Menu
Shoot the image.
In Shooting mode, the menu can be closed by pressing the shutter
button halfway. (In Playback mode, the menu closes when the shutter
button is pressed halfway and the camera switches to shooting mode.)
Shooting Playback
6. Shooting-Advanced Functions 63
Rec. Menu
Play Menu
Set up Menu
My Camera Menu
(p. 111)
64 6. Shooting-Advanced Functions
Some menu items may not be available for
selection according to the shooting mode
(p. 162).
You can apply a desired image and sound to
and in the My Camera menu. For
details, see Registering the My Camera
Settings (p. 111) or the Software Starter Guide.
Camera settings can be reset to the default
values (p. 68).
Rec. Menu
Menu Item Setting content
Reference
Page
Flash Sync
Sets the timing at which the flash fires.
1st-curtain*/2nd-curtain
p. 90
Slow Synchro
Sets whether or not the flash will fire
with a slow shutter speed.
On/Off*
p. 36
Flash Adjust
Sets whether or not the flash is
adjusted automatically.
Auto*/Manual
p. 89
Red-eye
Sets whether or not the red-eye
reduction lamp fires when the flash
fires.
On*/Off
p. 35
Flash Pop-up
Sets whether or not the flash pops up
automatically.
On*/Off
When set to [Off] the flash will not fire
automatically.
p. 34
Self-timer
Sets the duration before the self-timer
releases the shutter once the shutter
button is pressed.
10 sec.*/ 2 sec.
p. 49
Wireless Delay
Sets the duration before the self-timer
releases the shutter once the remote
control shutter button is pressed.
0 sec./2 sec.*/10 sec.
p. 136
6. Shooting-Advanced Functions 65
Spot AE Point
Sets the option of [Spot AE Point]
(one of the light metering modes) to
Center (the AE point is fixed to the
center) or AE Point (the AE point
corresponds to the AF point).
Center*/AF Point
p. 76
MF-Point Zoom
Sets whether or not the focusing point
is magnified when using the manual
focus.
On*/Off
p. 95
AF Mode
Sets the frequency of autofocus
activation.
Continuous*/Single
p. 97
Tally Lamp
Sets whether or not the tally lamp
blinks during movie recording.
On*/Off
p. 53
Digital Zoom
Sets whether or not the digital zoom
combines with the optical zoom to
zoom images.
On/Off*
p. 50
Review
Sets the duration images display on
the LCD monitor (or in the viewfinder)
after the shutter button is released.
Off/2 sec.* to 10 sec.
p. 31
Reverse Disp.
Sets whether or not the image is
reversed when the LCD monitor is
tilted 180 degrees toward the lens.
On*/Off
p. 26
Menu Item Setting content
Reference
Page
* Default setting
Play Menu
Intervalometer
Shoots automatically at set intervals.
2* to 100 shots
1* to 60 min.
p. 91
Set shortcut
button
Selects functions to be registered on
the (Shortcut) button.
p. 69
Save Settings
Saves settings selected in the Rec.
menu and the function menu to the
mode dial's mode.
p. 98
Menu Item Setting content
Reference
Page
Protect
Protects images from accidental
erasure.
p. 106
Rotate
Rotates images 90 or 270 degrees
clockwise in the display.
p. 100
Erase all
Erases all images from a CF card
(excluding protected images).
p. 44
Slide Show
Plays images in an automated slide
show.
p. 102
Print Order
Sets the images that will be printed on
a direct print compatible printer or at a
photo lab service, the number of
copies and other parameters.
p. 121
Menu Item Setting content
Reference
Page
66 6. Shooting-Advanced Functions
Set up Menu
Transfer Order
Specifies images before downloading
to a computer.
p. 126
Menu Item Setting content
Reference
Page
Mute
Set [On] to mute the start-up sound,
operation sound, selftimer sound and
shutter sound all at once.
zIf you set [Mute] to [On], no sound
will be heard even when any sound
item in the My Camera menu is set
to , or (On).
zNote that the error warning signal
beeps even when the Mute setting
is [On].
On/Off*
–
Volume
Adjusts the volume of camera
operations.
–
a
Start-up Vol.
Adjusts the Start-up Sound volume
when the camera powers up.
p. 19
b
Operation Vol.
Adjusts the Operation Sound volume
for operation buttons other than the
shutter button.
–
c
Selftimer Vol.
Adjusts the volume of the Selftimer
Sound informing you that the photo
will be taken in 2 seconds.
p. 49
Menu Item Setting content
Reference
Page
d
Shutter Vol.
Adjusts the Shutter Sound volume
when the shutter button is pressed all
the way. There is no shutter sound in
Movie mode.
p. 28
e
Playback Vol.
Adjusts the sound volume when a
movie or sound memo is played.
p. 57, 101
Settings of Above
Items (
a
-
e
)
Off 1 2* 3 4 5
–
LCD Brightness
Sets the brightness level of the LCD
monitor.
(Normal)*/ (Bright)
–
Power Saving
Sets whether or not the camera
automatically powers down or the
LCD monitor (or viewfinder) goes off
after a specified period of time
elapses without camera operation.
Auto Power Down
On*/Off
Display Off
10 sec./20 sec./30sec./1 min.*/2 min./3 min.
p. 107
Date/Time Sets the date, time and date format. p. 21
Format Formats (initializes) a CF card. p. 18
File No. Reset
Sets how file numbers are assigned to
images when new CF cards are
inserted.
On/Off*
p. 110
Menu Item Setting content
Reference
Page
6. Shooting-Advanced Functions 67
* Default setting
Auto Rotate
Sets whether or not images shot with
the camera on end are automatically
rotated in the display.
On/Off*
p. 108
Distance Units
Sets the format of the displayed
distance units of the MF indicator.
m/cm* or ft/in
p. 96
Language
Sets the language used in the menus
and messages on the LCD monitor (or
in the viewfinder).
English*/Deutsch/Français/
Nederlands/Dansk/Suomi/Italiano/
Norsk/Svenska/Español/Chinese/
Japanese
You can change the language during
image playback by holding the SET
button and pressing the JUMP button.
(Except when the camera is
connected to a printer)
p. 23
Video System
Sets the video output signal standard.
NTSC/PAL
p. 118
Menu Item Setting content
Reference
Page
My Camera Menu
You can select the theme, start-up image and sound,
shutter sound, operation sound and selftimer sound
used on this camera. These are called My Camera
settings. You can also customize the and
options for each item with images from the CF card
and newly recorded sounds or by using the supplied
software. See the Software Starter Guide for details.
Menu Item Setting content
Reference
Page
Theme
Selects a common theme for each my
Camera settings item.
p. 111
Start-up Image
Sets the start-up image when you turn
on the camera.
p. 111
Start-up Sound
Sets the start-up sound when you turn
on the camera.
p. 111
Operation Sound
Sets the sound when the omni
selector or any button other than the
shutter button is operated.
p. 111
Selftimer Sound
Sets the sound informing you that the
photo will be taken in 2 seconds.
p. 111
Shutter Sound
Sets the shutter sound when you
depress the shutter button. There is
no shutter sound while a movie is
being shot.
p. 111
68 6. Shooting-Advanced Functions
* Default setting
My Camera
menu settings
content
(Off)/ */ / –
Menu Item Setting content
Reference
Page
Resetting the Settings to Default
You can reset the menu and button operation
settings to default.
1
Turn the mode lever to or to
power up the camera.
2
Press the MENU
button for longer than
5 seconds.
The message "Reset settings
to default?" appears on the
LCD monitor (or viewfinder).
3
Select [OK] using the W
WW
W or X
XX
X arrow
on the omni selector, then press the
SET button.
Resetting starts.
1
2
3
3
6. Shooting-Advanced Functions 69
z The normal screen resumes when resetting is
complete.
z To cancel resetting, select [Cancel] instead of
[OK].
When the camera is in Shooting mode and the
mode dial is set to , only the mode settings
will revert to default.
zThe following settings cannot be reset to
default:
- The [Date/Time], [Language] and [Video
System] options in the [ (Set up)] menu
(p. 66, 67)
- White balance data set with the custom
white balance function (p. 79)
- Newly registered My Camera settings
zSettings cannot be reset when the camera is
connected to a computer or printer.
Registering Settings to the Shortcut Button
Frequently used functions can be registered to
the (Shortcut) button.
The following functions can be registered:
z Resolution (Still Images Only)*
z
White Balance
z Image Quality (Movies Only) z Display Off
z ISO Speed (Still Images Only)
z Frame Rate (Movies Only)
z Photo Effect
z AF Lock (Still Images Only)
z AE Lock (Still Images Only)
* Default setting
70 6. Shooting-Advanced Functions
Registering a Function
1
Select [Set shortcut
button] from the
[ (Rec.)] menu and
press the SET
button.
z See Selecting Menus and
Settings (p. 62).
2
Select the function
you wish to register
using the W
WW
W or X
XX
X
arrow.
2
1, 4
1, 3
z If an "x" mark appears on
the lower right of the icon,
you can still register this
function but the current shooting mode will be
retained and pressing the shortcut button will
not activate the function (the icon of the
registered function will not appear). If this
happens, change the setting of the mode dial.
3
Press the SET button.
4
Press the MENU button.
Mode dial set to
6. Shooting-Advanced Functions 71
Using the Shortcut Button
1
Press the Button.
The registered function is recalled and its icon
appears on the LCD monitor or viewfinder (except
if the display is off).
z Pressing the button cycles between setting
values of the registered functions.
z Functions that are not
available in the current
shooting mode will not
appear even if they are
selected. Change the
shooting mode setting
and press the button
again.
2
Shoot the image.
1
Using the Mode Dial (Creative Zone)
You can freely select camera settings such as
the shutter speed and aperture value to suit
your shooting purposes.
After settings are made, shooting procedures are the
same as for the mode (p. 27).
How to Use the Mode Dial
1
Check that the camera is in Shooting
mode.
z The power/mode indicator lights orange.
Mode Dial
1
2
72 6. Shooting-Advanced Functions
2
Turn the mode dial,
select the function
you wish to use and
shoot the image.
z The camera operates in
the following ways
according to the selected
function:
z The shutter speed and aperture value will show
on the LCD monitor (or viewfinder). The correct
exposure has been set if the shutter speed and
aperture value show in white on the LCD
monitor (or viewfinder).
z The shutter speed and aperture value will show
in red on the LCD monitor (viewfinder) when the
correct exposure cannot be obtained.
P
The camera automatically sets the shutter speed
and aperture value.
Tv
The user selects a shutter speed using the W or
X arrow.
Av
The user selects an aperture value using the W or
X arrow.
M
The user selects the shutter speed using the W or
X arrow and the aperture value using the S or
T arrow.
Shutter
Speed
Aperture
value
z In , or , the combinations of shutter
speeds and aperture values can be changed
within the same exposure setting (p. 73).
See page 162 for settings that can be changed
in this mode.
For information on the relation between the
aperture value and shutter speed, see page 73.
Please note that camera shake becomes a
factor at low shutter speeds. If the camera
shake warning appears in the LCD monitor
(or viewfinder), try the following procedures to
solve the problem.
- Use the (image stabilizer) function (p. 29).
- Use a tripod.
Program AE
Use the program AE mode to have the camera
automatically set the shutter speed and aperture
value to match the brightness of the scene.
z If a correct exposure cannot be obtained, use the
following methods to solve the problem.
- Use the flash.
- Change the ISO speed setting.
- Change the light metering mode.
6. Shooting-Advanced Functions 73
Differences between the and
Modes.
The following settings can be adjusted in mode,
but not in mode.
Setting the Shutter Speed
When you set the shutter speed in the shutter speed-
priority AE mode, the camera automatically selects
an aperture value to match the brightness. Faster
shutter speeds allow you to catch an instantaneous
image of a moving subject while slower speeds
create a flowing effect and allow you to shoot without
a flash in dark areas.
z Adjust the shutter speed using the W or X arrow
when the image is underexposed (insufficient light)
or overexposed (too much light) and the correct
exposure cannot be obtained.
· Exposure Compensation · White Balance
· ISO Speed · Bracket Mode
· Flash Exposure Compensation
· Flash (Flash on, Slow Synchro, 2nd-curtain)
· Photo Effect · Continuous Shooting
· Light Metering Mode · Manual Focus
· Intervalometer · AF Frame · AE Lock
· FE Lock
z The nature of CCD image sensors is such that
noise in the recorded image increases at slow
shutter speeds. This camera, however, applies
special processing to images shot at shutter
speeds slower than 1.3 seconds to eliminate the
noise, thereby producing high-quality images.
Nevertheless, a certain amount of processing time
may be required before the next image can be shot.
z The aperture value and shutter speed change
according to the zoom state as follows.
z The fastest shutter speed for flash synchronization
is 1/250 second. The camera automatically resets
the shutter speed to 1/250 second if a faster speed
is selected.
Aperture value Shutter Speed (seconds)
Wide Angle End
*1
f/2.8 – f/5.0 to 1/1250
f/5.6 – f/8.0 to 1/2000
Telephoto End
*2
f/3.1 – f/5.6 to 1/1250
f/6.3 – f/8.0 to 1/2000
*1
Maximun wide angle
*2
Maximun telephoto
74 6. Shooting-Advanced Functions
Shutter Speed Display
The numbers in the table below indicate the shutter
speed in seconds. 1/160 indicates 1/160 second.
Also, quote marks indicate the decimal place, so that
0"3 indicates 0.3 second and 2" indicates 2 seconds.
Setting the Aperture
When you set the aperture in the aperture-priority AE
mode, the camera automatically selects a shutter
speed to match the brightness.
Selecting a lower aperture value (opening the
aperture) allows you to fade the background and
create a beautiful portrait. A higher aperture value
(closing it) brings the entire range from foreground to
background into focus. The larger the aperture value,
the greater the range of the image brought into clear
focus.
15" 13" 10" 8" 6" 5" 4" 3"2 2"5 2" 1"6 1"3 1"
0"8 0"6 0"5 0"4 0"3
1/4 1/5 1/6 1/8 1/10 1/13 1/15 1/20 1/25
1/30 1/40 1/50 1/60 1/80 1/100 1/125
1/160 1/200 1/250 1/320 1/400 1/500 1/640
1/800 1/1000 1/1250 1/1600 1/2000
z Adjust the aperture value using the W or X arrow
when the image is underexposed (insufficient light)
or overexposed (too much light) and the correct
exposure cannot be obtained.
z Some aperture values cannot be selected
depending on the zoom position.
z In this mode, the maximum shutter speed with
synchronized flash is 1/250 second. The aperture
value setting may therefore be changed
automatically to match the synchronized flash
speed even if its value was set previously.
Aperture Setting Display
The larger the aperture value, the smaller the lens
aperture.
Manually Setting the Shutter
Speed and Aperture
You can manually set the shutter speed and aperture
to achieve a particular effect. This is convenient for
shooting fireworks and other images where it is
difficult to set the correct exposure automatically.
f/2.8 f/3.1 f/3.2 f/3.5 f/4.0 f/4.5 f/5.0 f/5.6 f/6.3
f/7.1 f/8.0
6. Shooting-Advanced Functions 75
z The brightness of the LCD monitor (or viewfinder)
matches the selected shutter speed and aperture
value. When you select a fast shutter speed or
shoot a subject in a dark place and set the flash to
(Flash On (red-eye reduction) or (flash On)
the image will always be bright.
z When you press the shutter button halfway, the
difference between the standard exposure* and the
selected exposure appears on the LCD monitor (or
viewfinder). If the difference is more than 2 stops,
"-2" or "+2" appears on the LCD monitor (or
viewfinder).
*
The standard exposure is calculated by the AE
function according to the selected metering
method.
Selecting an AF Frame
The AF frame indicates the area of the
composition on which the camera focuses and
can be set manually to the desired area. This is
convenient for focusing accurately on an off-
center subject to obtain the composition you
desire.
However, the AF frame is fixed to center-point
when the digital zoom is used, even if you
previously set the AF frame to the position you
desire.
1
Press the button.
The AF frame appears in green.
Mode Dial
1, 2
2
76 6. Shooting-Advanced Functions
2
Move the AF frame to the desired
area using the S
SS
S, T
TT
T, W
WW
W or X
XX
X arrow,
then press the button.
z You can immediately shoot the image using the
selected AF frame by pressing the shutter
button instead of pressing the button.
z The AF frame will move back to its original
position (Center) if you hold down the
button.
For an explanation of the AF frame colors,
please refer to page 24.
The AF frame is locked to center-point when
using the digital zoom.
When the Spot AE Point is selected as the light
metering mode, you can use the selected AF
frame as the Spot AE Point (p. 76).
Switching between Light Metering Modes
Evaluative metering is the default light
metering mode. This can be switched to
another metering mode.
Mode Dial
Evaluative
Light
Metering
The camera divides images into several
zones for light metering. The camera
evaluates the complex lighting conditions,
such as the position of the subject, the
brightness, the background, the direct light,
and the backlighting, and adjusts the
settings to the correct exposure for the main
subject.
This mode is particularly well-suited for
backlight conditions and general
photography.
Center-
Weighted
Averaging
Averages the exposure from the entire image,
but places more weight on the subject at the
center.
Spot AE Point
Meters the area within the spot AE point
frame.
Center
Locks the spot metering frame to the center
of the LCD monitor.
AF Point Moves the spot AF point to the AF frame.
6. Shooting-Advanced Functions 77
1
Press the button to select a
metering mode.
z Each press of the button changes the
metering mode as follows.
z The icon of the currently selected light metering
mode appears on the LCD monitor (or
viewfinder).
If you have selected (Spot AE point), go to step
2
.
If you have selected (Evaluative Light Metering)
or (Center-Weighted Averaging), shoot the
image.
3
1
2, 3
(Evaluative)
(Spot AE Point)
(Center-Weighted
Averaging)
2
In the [ (Rec.)]
menu, select [Spot
AE Point].
z See Selecting Menus and
Settings (p. 62).
3
Select [Center] or
[AF Point] using the
W
WW
W or X
XX
X arrow, then
press the MENU
button.
z When [Spot AE point] is
set to [Center], the spot
AE point frame appears at the center of the
LCD monitor (or viewfinder), and when [Spot
AE Point] is set to [AF point], it appears inside
the selected AF frame.
e.g. Center
Spot AE Point
78 6. Shooting-Advanced Functions
Adjusting the Exposure
Adjust the exposure compensation setting to
avoid making the subject too dark when it is
backlit or shot against a bright background.
1
Press the FUNC. button.
2
Select * (+/- (Exp.))
using the S
SS
S or T
TT
T
arrow, and set the
exposure using the
W
WW
W or X
XX
X arrow.
* The current setting is
displayed.
Mode Dial
2
1
, 3
, 3, 3
, 3
z The settings can be adjusted in 1/3-stops in the
range of -2EV to +2EV.
z You can shoot the image right after selecting
settings by pressing the shutter button. This
screen will appear again, once the image is
shot.
3
Press the FUNC. button.
z To cancel the exposure compensation, return
the setting to using the W or X arrow.
Exposure settings can be made/canceled even
in mode (p. 53).
6. Shooting-Advanced Functions 79
Adjusting the Tone (White Balance)
When the white balance mode is set to match
the light source, the camera reproduces colors
more accurately.
Combinations of setting contents and light source are
as follows.
Mode Dial
Auto Settings are automatically set by the camera
Daylight For recording outdoors on a bright day
Cloudy
For recording under overcast, shady or
twilight skies
Tungsten
For recording under tungsten and bulb-type 3-
wayelength fluorescent lighting
Fluorescent
For recording under warm-white, color-white
or warm-white (3-wavelength) fluorescent
lighting
Fluorescent H
For recording under daylight fluorescent, or
daylight fluorescent-type 3-wavelength
fluorescent lighting
Flash For flash photography
Custom
For setting a custom value with a white sheet
of paper, etc., to obtain the optimal white
balance for the conditions.
1
Press the FUNC. button.
2
Select * (Auto)
using the S
SS
S or T
TT
T
arrow and select the
desired setting using
the W
WW
W or X
XX
X arrow.
* The current setting is displayed.
z
Please see page 80 regarding the custom setting.
z
You can shoot the image right after selecting
settings by pressing the shutter button. This
screen will appear again, once the image is shot.
3
Press the FUNC. button.
The white balance cannot be adjusted when the
photo effect is set to (Sepia) or (B/W) (p. 82).
2
1
,
,,
,
3
33
3
80 6. Shooting-Advanced Functions
Setting a Custom White Balance
In the following cases, the white balance may not be
correctly adjusted. Use (Custom) to adjust the
white balance.
z Shooting subjects of monotone color (such as sky,
sea or forest)
z Shooting with a peculiar source of light (such as a
mercury-vapor lamp)
1
Press the FUNC. button.
2
Select * (Auto)
using the S
SS
S or T
TT
T
arrow and select
(Custom) using the
W
WW
W or X
XX
X arrow.
* The current setting is displayed.
2
1, 4
3
3
Aim the camera at a
white paper or cloth,
or gray card and
press the SET button.
The white data is recorded.
z Aim the camera so that the
white paper or cloth, or gray card, completely
fills the center of the frame.
z You can shoot the image right after selecting
settings by pressing the shutter button. The
menu displays again after the shot, allowing you
to change the settings easily.
4
Press the FUNC. button.
You are recommended to set the white balance
when shooting in the following conditions.
- The shooting mode is set to and the
exposure compensation and flash
exposure adjustment are set to ±0.
The correct white balance may not be
obtained when the exposure is incorrect
(image is completely black or white).
6. Shooting-Advanced Functions 81
- The zoom is positioned to the telephoto
end setting.
Set the digital zoom to [Off].
- A mode other than is selected.
In mode, white balance data cannot be
read.
- The flash is set to (Flash On) or
(Flash Off).
Use the same flash setting as the one that will
be used for shooting when you set the white
balance. If the white balance setting
conditions and shooting conditions are not
the same, the correct white balance may not
be obtained.
When the flash is set to (Auto with red-
eye reduction) or (Auto), the flash may fire
while the white data is recorded to the custom
white balance. If this happens, make sure the
flash also fires when you shoot the image.
- The ISO speed is set to the same setting
to shoot the image.
The custom white balance will not be canceled
even if you reset camera settings to default
(p. 68).
Changing the ISO Speed
By raising the ISO speed, you can shoot bright
images even poor lighting conditions. This
function is convenient when you want to
prevent camera shake, shoot without the flash
or shoot with a faster shutter speed in dark
conditions.
You can choose from the following speeds: Auto, 50,
100, 200 and 400.
1
Press the FUNC. button.
Mode Dial
2
1
,
,,
,
3
33
3
82 6. Shooting-Advanced Functions
2
Select * (ISO
Speed) using the S
SS
S
or T
TT
T arrow and
select the desired
setting using the W
WW
W
or X
XX
X arrow.
* The current setting is displayed.
z You can shoot the image right after selecting
settings by pressing the shutter button. The
menu displays again after the shot, allowing you
to change the settings easily.
3
Press the FUNC. button.
zHigher ISO speeds increase the image noise.
To take clean images, use as low an ISO
speed as possible.
zThe AUTO setting selects the optimal ISO
speed. It will automatically raise the speed
when the light from the flash is insufficient to
illuminate the subject matter.
Changing the Photo Effect
You can shoot with different saturation and
contrast color effects.
*
, , and modes only
Mode Dial
Photo Effect Off Records with no effect.
Vivid
Emphasizes the contrast and color
saturation to record in bold color.
Neutral
Tones down the contrast and color
saturation to record neutral hues.
Low Sharpening
Records subjects with softened
outlines.
Sepia Records in sepia tones.
B/W Records in black and white.
Custom Effect*
You can freely set the contrast,
sharpness and color saturation.
6. Shooting-Advanced Functions 83
1
Press the FUNC. button.
2
Select * (Effect Off)
using the S
SS
S or T
TT
T
arrow and select the
desired setting using
the W
WW
W or X
XX
X arrow.
* The current setting is displayed.
When is selected
z A screen allowing you to
set the contrast, sharpness
and color saturation
appears when you press
the SET button. Select the item you wish to set
using the S or T arrow, set it using the W or X
arrow and press the SET button.
2
1
,
,,
,
3
33
3
z You can shoot the image right after selecting
settings by pressing the shutter button. The
menu displays again after the shot, allowing you
to change the settings easily.
Contrast
z This function allows you to adjust the degree of
brightness.
z Select from - (Weak), 0 (Neutral) and +
(Strong).
Sharpness
z This function allows you to adjust how sharply
outlines are defined.
z Select from - (Weak), 0 (Neutral) and +
(Strong).
Saturation
z This function allows you to adjust the color
depth.
z Select from - (Weak), 0 (Neutral) and +
(Strong).
3
Press the FUNC. button.
The white balance cannot be set when
(Sepia) or (B/W) mode is selected.
84 6. Shooting-Advanced Functions
Auto Exposure Bracketing (AEB Mode)
In this mode, the camera automatically
changes the exposure within a set range to
take three shots after you press the shutter
button once.
You can adjust AEB settings in 1/3 stops within the
range of -2EV to +2EV of the standard exposure
setting. AEB settings can be combined with exposure
compensation settings (p. 78) to extend the
adjustment range. The images are recorded in the
following order: Standard exposure, underexposure
and overexposure.
1
Press the FUNC. button.
Mode Dial
2, 3
1
,
,,
, 4
4 4
4
3
2
Select * (BKT-Off)
using the S
SS
S or T
TT
T
arrow.
* The current setting is
displayed.
3
Select (AEB),
press the SET button
and adjust the compensation range
using the W
WW
W or X
XX
X arrow.
z Use X to expand the range and W to contract it.
z You can shoot the image right after selecting
settings by pressing the shutter button. The
menu displays again after the shot, allowing you
to change the settings easily.
4
Press the FUNC. button.
z Select (BKT-Off) in Step
3
to cancel the
AEB mode.
The AEB mode cannot be used for flash
photography. If the flash fires, only one image
gets recorded.
6. Shooting-Advanced Functions 85
Focus Bracketing (Focus-BKT Mode)
You can shoot three images while the focus
changes automatically when shooting with the
manual focus.
Three ranges -small, medium or large- can be
selected. Images are shot with the focus position
changing in the following order; current position,
backwards and forward.
1
Press the FUNC. button.
Mode Dial
2, 3
1
,
,,
, 4
4 4
4
2
Select * (BKT-Off)
using the S
SS
S or T
TT
T
arrow, select
(Focus-BKT) using
the W
WW
W or X
XX
X arrow and
press the SET button.
* The current setting is displayed.
3
Select a range using
the W
WW
W or X
XX
X arrow.
z Use X to expand the range and W to contract it.
z You can shoot the image right after selecting
settings by pressing the shutter button. The
menu displays again after the shot, allowing you
to change the settings easily.
4
Press the FUNC. button and shoot
the image with the manual focus
(p. 95).
The Focus-BKT mode is not available when
shooting with the flash on. The camera will
revert to shooting only one image when the
flash is on.
86 6. Shooting-Advanced Functions
Locking the Exposure Setting (AE Lock)
You can set the exposure and focus separately.
This is effective when the contrast is too strong
between the subject and background or when
a subject is backlit.
1
Focus the AF frame or the spot
metering frame on the subject on
which you wish to lock the exposure
setting and press the shutter button
halfway.
z See Selecting and AF Frame (p. 75)
z See Switching Between Light Metering Modes
(p. 76)
Mode Dial
1, 2
2
2
While pressing the
shutter button
halfway, press the
button.
z The exposure setting
locks (AE Lock) and the
icon appears on the
LCD monitor (or viewfinder).
z Pressing the
button again cancels the AE
lock.
3
Recompose the image and shoot.
The camera focuses on the subject in the AF frame.
In mode, AE lock can be set or canceled
even during movie recording (p. 56).
The automatically selected combinations of
shutter speeds and aperture values can be
freely changed without altering the exposure
with the following procedures.
1.Turn the mode dial to , or .
2.Focus on the subject on which you wish to
lock the exposure and press the shutter
button halfway.
AE lock
6. Shooting-Advanced Functions 87
3.Press the button.
The exposure setting will lock and the
icon will appear in the LCD monitor (or
viewfinder).
4.Press the W or X arrow until the desired
shutter speed or aperture value is reached.
5.Recompose the image and shoot. The
setting will cancel after the shot is taken.
Locking the Flash Exposure Setting (FE Lock)
You can obtain the correct exposure regardless
of the location of your subject in the
composition.
1
Press the button and set the flash
to fire (p. 34).
2
Focus the AF frame or the spot
metering frame on the subject on
which you wish to lock the flash
exposure setting and press the
shutter button halfway.
Mode Dial
2
3
1
88 6. Shooting-Advanced Functions
3
While pressing the shutter button
halfway, press the button.
z The flash exposure compensation setting locks
(FE Lock) and the icon appears on the LCD
monitor (or viewfinder).
z The flash will fire a pre-flash and lock the flash
exposure to the required intensity to illuminate
the subject.
z Each time you press the button, the flash
exposure locks at the required intensity for that
composition.
z Using any button or lever other than the omni
selector cancels the FE lock.
4
Recompose the image and shoot.
The FE lock function is not available when
[Flash Adjust] is set to [Manual].
Switching between Built-in
Flash Adjustment Settings
The built-in flash fires with automatic flash
adjustments (except in the
M
mode), but it is possible
to set it so that it fires without any adjustments.
1
Select [Flash Adjust]
from the [ (Rec.)]
menu.
z See Selecting Menus and
Settings (p. 62).
2
Select [Auto] or [Manual] using the W
WW
W
or X
XX
X arrow and press the MENU
button.
Mode Dial
1, 2
6. Shooting-Advanced Functions 89
Setting the Flash Adjustment/Flash Output
Mode Dial
*1
When [Flash Adjust] is set to [Manual], flash output
settings can be made.
*2
[Flash Output] can be set.
Flash Adjust
zWhen [Flash Adjust] is set to [Auto], settings can
be adjusted in 1/3-stop increments in the range
of -2EV to +2EV.
zYou can enjoy flash photography with exposure
adjustments with the combined use of the
camera’s exposure compensation function.
Flash Output
zIn M mode or when [Flash Adjust] is set to
[Manual], the flash output can be controlled in
three steps, starting from FULL, when shooting.
2, 3
1, 4
1
Press the FUNC. button.
2
Select (+/- (Flash)
or Flash Output)
using the S
SS
S or T
TT
T
arrow.
3
Adjust the
compensation using
the W
WW
W or X
XX
X arrow.
z You can shoot the image
right after selecting settings
by pressing the shutter
button. The menu displays again after the shot,
allowing you to change the settings easily.
4
Press the FUNC. button.
e.g. [Flash Adjust]
set to [Auto]
e.g. [Flash Adjust]
set to [Manual]
90 6. Shooting-Advanced Functions
Switching the Timing at which the Flash Fires
Mode Dial
1st-curtain
The flash fires right after the shutter opens,
regardless of the shutter speed. Usually, the 1st-
curtain is used when shooting.
2nd-curtain
The flash fires right before the shutter closes,
regardless of the shutter speed. Compared with the
1st-curtain, the flash fires later and this allows you to
shoot images in which, for example, a car's rear
lamps seem to trail off behind.
Image shot with the
1st-curtain setting
Image shot with the
2nd-curtain setting
1
From the [ (Rec.)]
menu, select [Flash
Sync].
2
Select [1st-curtain]
or [2nd-curtain]
using the W
WW
W or X
XX
X arrow.
z See Selecting Menus and Settings (p. 62).
1
2
6. Shooting-Advanced Functions 91
Shooting Images at Set Intervals (Intervalometer)
You can shoot images at a set interval. This
function can be used for fixed-point
observation of plants and blooming flowers.
The shooting interval time can be set from 1 to
60 minutes and 2 to 100 images can be shot.
Mode Dial
Since the camera may shoot continuously for
an extended period of time, the use of the
Compact Power Adapter CA-PS700 (sold
separately) is recommended (p. 143).
5
2, 3
1, 4
1
1
Select [Intervalometer]
from the [ (Rec.)]
menu and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
2
Select an interval time
using the W
WW
W or X
XX
X arrow.
z If you press the W or X
arrow continuously, the
interval time changes in
units of 5 minutes at a time.
3
Press the T
TT
T arrow and select the
number of shots using the W
WW
W or X
XX
X
arrow.
z If you press the W or X arrow continuously, the
number of shots changes in units of 5 shots at a
time.
z The maximum number of shots* is determined
according to the CF card's remaining capacity.
* The maximum number of shots may decrease
according to the images shot.
92 6. Shooting-Advanced Functions
4
Press the SET button.
z The camera exits the menu screen and Int.
appears at the lower right of the LCD monitor
(or viewfinder).
5
Press the shutter button.
z The first image is shot and the interval shooting
session starts.
z Once the set number of shots is taken the
camera automatically powers down regardless
of the power saving function settings.
z If the below operations are accessed while the
interval shooting is in process, the interval
shooting session will be canceled.
- Turning the mode dial while the camera is
waiting to shoot the next image
- Pressing the shutter button halfway while the
camera is waiting to shoot the next image
- Opening the CF card slot cover or the battery
cover
- Switching to Playback mode
- Turning off the power
zOnce the interval shooting session is started,
all operation buttons become inactive.
zThe lens stays extended until the next image
is shot.
zImages are not displayed on the LCD monitor
(or viewfinder) right after being shot.
zInterval shooting is not available when the
date and time are not set.
zContinuous shooting and self-timer shooting
are not available.
zAEB mode and the Focus-BKT mode settings
cannot be set.
6. Shooting-Advanced Functions 93
Shooting Problem Subjects for the Autofocus
The autofocus may not work well on the
following types of subjects.
z Subjects with extremely low contrast to the
surroundings
z Subjects mixing close and far objects
z Subjects with extremely bright objects at the center
of the composition
z Subjects that are moving quickly
z Subjects with horizontal stripes
To shoot these subjects, first aim the camera at an
object at a similar distance, lock the focus and
recompose the image with the desired subject, or
use manual focus or AF lock.
Shooting with Focus Lock
Mode Dial
2, 3
1
1
Aim the AF frame at an object at a
similar distance to the subject you
wish to shoot.
2
Press the shutter button halfway to
lock the focus.
z The AE setting will also lock when you do this.
The exposure may occasionally be incorrect if
the difference between the two items is too
great. Use AF lock or AE lock when this
happens.
3
Keep it pressed while you
recompose the image and press the
shutter button all the way to shoot
the image.
94 6. Shooting-Advanced Functions
Shooting in AF Lock Mode
1
Aim the AF frame at an object at a
similar distance to the subject you
wish to shoot.
2
Press the shutter button halfway and
while keeping it pressed, press the
MF button.
z appears on the LCD monitor (or viewfinder).
z The focus will stay locked even if you release
the shutter button and MF button.
Mode Dial
2, 3
2
z Pressing the MF button a second time cancels
the manual focus mode.
3
Recompose the image and press the
shutter button all the way to shoot
the image.
AF lock is convenient because you can let go
of the shutter button to recompose the image.
In addition, since the focus stays locked to the
same position even after the shot is taken, you
can immediately shoot the next image with the
same focus position.
When shooting through glass, get as close as
possible to avoid reflection off the glass.
In mode, AF lock can be set or canceled
even during movie recording (p. 56).
6. Shooting-Advanced Functions 95
Shooting in Manual Focus Mode
The focus can be manually set.
1
Press and hold the
MF button, then press
the S
SS
S or T
TT
T arrow.
z The focus will lock and the
icon and the MF
indicator will appear on the
LCD monitor (or viewfinder).
Mode Dial
1
1
2
MF Indicator
z When the [ (Rec.)] menu's [MF-Point Zoom]
is set to [On], if a particular AF frame has been
manually selected (p. 75), the portion of the
image in that frame will appear magnified.
*1
* Except in the , when the digital zoom is
activated or a TV is used as the display.
*1
Can also be set so that the image displayed is
not magnified (p. 65).
z The MF indicator shows approximate figures.
Use them as a shooting guideline only.
z Adjust the focus using the S or T arrow until
the image appears focused.
z Pressing the MF button a second time cancels
the manual focus mode.
2
Press the shutter button all the way
to shoot the image.
Reset the manual focus after the flash pops up.
96 6. Shooting-Advanced Functions
Using the Manual Focus in
Combination with the Auto Focus
The camera automatically searches for a more
suitable focusing point from the current
manually focused location.
1
Focus the camera with the manual
focus.
2
Press the SET button.
z The camera focuses automatically to a more
accurate focusing point near the current
focusing point.
Mode Dial
1
1
2
3
Press the shutter button all the way
to shoot the image.
You can change the MF indicator displayed
distance units (p. 67).
You cannot change the AF frame setting while
focusing manually. Cancel the manual focus
mode, then change the AF frame setting.
6. Shooting-Advanced Functions 97
Switching between Focus Settings
You can switch between focus settings to
shoot.
Mode Dial
Continuous
The camera is continually focusing on
whatever it is aimed even when the
shutter button is not pressed, allowing
you to shoot without missing
opportunities. This is the default setting.
Single
The camera only focuses when the
shutter button is pressed halfway,
conserving battery power.
1
In the [ (Rec.)]
menu, select [AF
Mode].
z See Selecting Menus and
Settings (p. 62).
2
Select [Continuous] or [Single] using
the W
WW
W or X
XX
X arrow and press the
MENU button.
2
1, 2
98 6. Shooting-Advanced Functions
Saving Custom Settings
You can save frequently used shooting modes
and various shooting settings to the
(Custom) mode. When necessary, you can
then shoot images with previously saved
settings by simply turning the mode dial to .
Settings that are usually forgotten when the
shooting mode is changed or when the power
is turned off (such as Continuous Shooting and
Self-timer mode) are also remembered.
Mode Dial
1
Turn the mode dial to , , ,
or .
z When you wish to re-save partially modified
settings (except shooting mode) that were
previously saved in the mode, select .
2
Set the setting contents you wish to
save.
Settings that can be saved to the mode
z Shooting mode ( , , , )
z Items that can be set in , , and
modes (p. 162)
z Shooting menu settings
z Zoom location
z Manual focus location
3, 4
3, 5
1
6. Shooting-Advanced Functions 99
3
Select [Save Settings]
from the [ (Rec.)]
menu and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
4
Select [OK] and press the SET
button.
5
Press the MENU button.
The setting contents do not influence other
shooting modes.
Saved settings can be reset (p. 68).
100 7. Playback-Advanced Functions
7. Playback-Advanced Functions
Rotating Images in the Display
Images can be rotated 90° and 270° clockwise
on the LCD monitor.
1
Select [Rotate] from
the [ (Play)] menu
and press the SET
button.
z See Selecting Menus and
Settings (p. 62).
Original 90° 270°
2
1, 3
2
2
Select an image you
want to rotate using
the W
WW
W or X
XX
X arrow
and press the SET
button.
z The image cycles to the
next orientation (90° 270° original) each
time the SET button is pressed.
3
Press the MENU button.
z The Play menu appears again. Press the
MENU button again to close the menu.
Images can be magnified when rotated (p. 40).
Images taken vertically with the auto rotate
function (p. 108) set to [On] will automatically
be rotated to the vertical position when viewed
on the LCD monitor (or viewfinder).
zMovies cannot be rotated.
zWhen images are downloaded to a computer,
the orientation of images rotated by the
camera will depend upon the software used to
download the images.
7. Playback-Advanced Functions 101
Attaching Sound Memos to Images
In Playback mode (including single image
playback, index playback, magnified playback
and the review immediately after shooting in
Shooting mode) you can attach sound memos
(up to 60 seconds) to an image. The sound
data is saved in WAVE format.
1
Press the button while playing
back images.
z The Sound Memo panel appears.
2
Select using the
W
WW
W or X
XX
X arrow and
press the SET
button.
2
1
2
Sound Memo Panel
z The recording starts and the elapsed time is
displayed. Speak towards the microphone of
the camera.
z To stop recording, press the SET button. To
restart recording, press the SET button again.
z You can add as many sound memos as you like
until their total time reaches 60 seconds.
Playing back the Sound Memos
z Select . Images with sound memos are
displayed with the mark (they do not display
in No Information display mode). To stop
playback, press the SET button. To restart
playback, press the SET button again. You can
adjust the volume using the S or T arrow.
Erasing the Sound Memos
z Check that is displayed and select .
Exiting the Sound Memos Menu
z Press the button.
102 7. Playback-Advanced Functions
The volume can be adjusted in the Set up menu
(p. 66). If you set [Mute] to [On] in the Set up
menu, no sound is reproduced, however, you
can resume the sound and adjust the volume by
pressing the S or T arrow.
zYou cannot attach sound memos to movies.
zYou cannot record or playback sound notes
for images that already have an incompatible
sound file attached. If you attempt to record or
play such images, the "Incompatible WAVE
format" message will display. Incompatible
sound files can be deleted with this camera.
zSound memos for protected images cannot
be erased (p. 106).
Automated Playback (Slide Show)
Slide show image settings are based on DPOF
standards (p. 119).
Starting a Slide Show
All images, or a selection of images, can be
displayed one-by-one in an automated slide show.
1
In the [ (Play)]
menu, select [Slide
Show] and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
All Images
Plays all the images on the CF card in
order
Slide Show 1 - 3
Plays the images selected for each show
in order (p. 103)
1, 3
1, 4
2, 3
7. Playback-Advanced Functions 103
2
Select [Program]
using the S
SS
S or T
TT
T
arrow and select
between [All images]
or one of [Show 1]-
[Show 3] using the W
WW
W or X
XX
X arrow.
3
Select [Start] using the S
SS
S or T
TT
T arrow
and press the SET button.
The show will start and automatically stop when
the show is done.
Pausing and Resuming a Slide Show
z Press the SET button to pause the show. Press
it again to resume.
Fast Forward/Rewinding a Slide Show
z User the W or X arrow to move to the previous
or next image.
Stopping a Slide Show
z Press the MENU button during a slide show to
stop it and display the slide show menu.
4
When the slide show is over, press
the MENU button.
The slide show menu appears again. Press the
MENU button again to close the menu.
Movie images play for the length of time that
they were recorded regardless of the time set
in the slide show settings.
The power saving function is disabled while a
slide show plays on the camera (p. 107).
Selecting Images for Slide Shows
You can mark images for inclusion in slide shows 1-3.
Up to 998 images may be marked per slide show.
Images display in the order of their selection.
1
Display the slide show menu (p. 102).
3
1, 5
2, 3,
4
104 7. Playback-Advanced Functions
2
Select [Program]
using the S
SS
S or T
TT
T
arrow and select
[Show 1], [Show 2]
or [Show 3] using
the W
WW
W or X
XX
X arrow.
z A checkmark (3
33
3) will appear beside a show
already containing images.
3
Choose [Select] using the T
TT
T and W
WW
W
or X
XX
X arrows and press the SET
button.
4
Mark images to include in the show.
Single Image Playback
z Move between images
using the W or X arrow
and mark or remove
marks from images using
the S or T arrow.
z The selection number and
a check mark (3
33
3) appear at the bottom of
selected images.
Index Playback
z Turn the zoom lever
toward to switch to
index playback (3
images).
z Select an image using the
W or X arrow and mark or
remove marks from images using the S or T
arrow.
z The selection number and a check mark (3
33
3)
appear at the bottom of selected images.
z After you press the SET button, you can select
all the images by selecting [Mark all] using the
S or T arrow and pressing the SET button
again. You can deselect all the images by
selecting [Clear all].
z You can select images using the W or X arrow
and change the settings using the S or T
arrow after [Mark all] or [Clear all] has been
selected.
5
Press the MENU button.
z The image selection screen will close.
7. Playback-Advanced Functions 105
Adjusting the Play Time and Repeat Settings
1
Display the slide show menu (p. 102).
2
Select [Set up] using
the W
WW
W or X
XX
X arrow
and press the SET
button.
3
Select [Play Time] or
[Repeat] using the S
SS
S or T
TT
T arrow.
Play Time
Sets the duration that each image in a slide show is
displayed. The options are any one of 3-10 seconds,
15 seconds, 30 seconds and Manual.
Repeat
Sets whether the slide show stops when all the slides
have been displayed or continues to display until
stopped.
2
1, 5
2, 3, 4
4
Select a setting
using the W
WW
W or X
XX
X
arrow.
Play time
z Select a play time.
Repeat
z Select [On] or [Off].
5
Press the MENU button.
The set up menu closes.
The display interval may vary somewhat for
some images.
Slide shows can be easily edited on a
computer with the supplied software
(ZoomBrowser EX or ImageBrowser).
106 7. Playback-Advanced Functions
Protecting Images
You can protect important images from
accidental erasure.
1
In the [ (Play)]
menu, select [Protect]
and press the SET
button.
z See Selecting Menus and
Settings (p. 62).
2
Select an image you
want to protect
using the W
WW
W or X
XX
X
arrow and press the
SET button.
1, 2
1, 3
2
z The icon appears on protected images.
z To remove the protection, press the SET button
again (in protection mode).
z You can make the selection of images easier by
toggling between single image playback and
index playback with the zoom lever.
3
Press the MENU button.
The protect window closes.
Please note that formatting (initializing) a CF
card erases all data, including protected
images (p. 18) and other file types. Please
check the contents of a CF card before
formatting it.
8. Camera Settings 107
8. Camera Settings
Setting the Power Saving Function
This camera is equipped with a power saving
function. Depending on the power saving setting,
the camera may power down or the LCD monitor
(or viewfinder) may go off automatically.
z Auto Power Down
[On]: zShooting mode
Powers down approximately 3 minutes after the
last time a camera control is accessed. The LCD
monitor (or viewfinder) automatically shuts off
approximately 1 minute*
1
after the last time a
camera control is accessed even if [Auto Power
Down] is set to [Off]. Press any button except the
OFF button to turn the LCD monitor (or
viewfinder) back on.
*
1
This time can be changed (p. 108).
zPlayback mode
Powers down approximately 5 minutes after the
last time a control is accessed on the camera.
zPrinter Connection mode
Powers down approximately 5 minutes after the
last time a control is accessed on the camera or
something is printed on the printer.
[Off] : The power saving function does not activate.
z Display Off (Shooting Mode Only)
The LCD monitor (or viewfinder) shuts off after a specified
period of time elapses and no camera control is accessed.
The following time settings can be selected: 10 sec./20
sec./30 sec./1 min.*
2
/2 min./3 min.
*
2
Default setting
When the Auto Power Down Function
Activates
Turn the power on again.
Playback/Printer Connection mode: Turn the
mode lever to the right again to power the camera.
When the Display Off Function Activates
The LCD monitor (or viewfinder) display turns back
on if any button other than the shutter button is
pressed.
Please note that the camera continues to
consume a minimal amount of power even
when the power saving function shuts it down.
The power saving function is disabled while a
slide show plays on the camera or during a
computer connection (p. 102, 115).
You can turn off the power saving function in
the Set up menu (p. 66).
108 8. Camera Settings
1
Select [Power Saving]
in the [ (Set up)]
menu and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
2
Select (Auto Power
Down) using the
S
SS
S
or
T
TT
T
arrow and select
[On] or [Off] using the
W
WW
W
or
X
XX
X
arrow.
3
Select (Display Off) using the
S
SS
S
or
T
TT
T
arrow and select a time using the
W
WW
W
or
X
XX
X
arrow.
4
Press the MENU button.
1
1, 4
2, 3
Setting the Auto Rotate Function
This camera is equipped with an Intelligent
Orientation sensor that detects the orientation
of an image shot with the camera on end and
automatically rotates it to the correct viewing
orientation in the display. You can set this
function on/off.
1
Select [Auto Rotate]
in the [ (Set up)]
menu.
z See Selecting Menus and
Settings (p. 62).
Mode Dial
1, 2
2
8. Camera Settings 109
2
Select [On] using the W
WW
W or X
XX
X arrow
and press the MENU button.
z When this function is On, an icon showing the
orientation of the camera appears at the upper
right corner of the LCD monitor (or viewfinder) if
it is set to Information View.
: Normal
: Camera on right end
: Camera on left end
zThis function may not operate correctly when
the camera is pointed straight up or down.
Check that the correct camera orientation
icon (e.g. ) is displayed and if it is not, then
set the Auto Rotate function to Off.
zEven if the Auto Rotate function is set to On,
the orientation of images downloaded to a
computer will depend upon the software used
to download the images.
When the camera is held on end to shoot, the
Intelligent Orientation sensor judges the upper
end to be "up" and the lower end to be "down".
It then regulates the optimal white balance and
exposure for vertical photography. This
function operates regardless of the On/Off
status of the Auto Rotate function.
When changing the camera’s orientation
between the horizontal and vertical positions,
you may hear noise coming from the
orientation detection mechanism. This is not a
malfunction.
110 8. Camera Settings
Resetting the File Numbers
You can select the way file numbers are
assigned.
1
In the [ (Set up)]
menu, select [File
No. Reset].
z See Selecting Menus and
Settings (p. 62).
On
The file numbers are reset to the start (100-001) each time
a new CF card is inserted. New images recorded on CF
cards with existing files are assigned the next available
number.
Off
The file number of the last image to be shot is memorized
so that images recorded to a new CF card start from the
next number.
1, 2
2
2
Select [On] or [Off] using the W
WW
W or X
XX
X
arrow and press the MENU button.
Setting the [File No. Reset] to [Off] is useful for
avoiding file name duplication when images
are downloaded to a computer.
See Managing Image Files (p. 155).
8. Camera Settings 111
Customizing the Camera (My Camera Settings)
My Camera allows you to customize the start-
up image and start-up, shutter, operation and
self-timer sounds. Each menu item has three
choices.
Changing My Camera Settings
1
Press the MENU
button and press the
X
XX
X arrow twice.
The [ (My Camera)]
menu appears.
1, 3
1, 2
2
Select a menu item using the S
SS
S or T
TT
T
arrow, then select setting content
using the W
WW
W or X
XX
X arrow.
: Off
: General
: Science fiction theme
: Animal theme
z The contents of the and options can be
changed (p. 67).
3
Press the MENU button.
The menu closes and settings are activated.
z In Shooting mode, the menu can be closed by
pressing the shutter button halfway.
If you select [Theme] in Step
2
, you can select
a consistent theme for each of the My Camera
settings.
If [Mute] in the [ (Set up)] menu is set to [On],
no sound is reproduced except for the error
warning signal regardless of the selected My
Camera settings. The Start-up image displays
(p. 67).
112 8. Camera Settings
Registering My Camera Settings
This function registers new contents to the
and options.
Images recorded onto the CF card and newly
recorded sounds can be added to the camera. You
can also use the supplied software to upload your
computer's images and sounds to the camera. The
following menu items can be saved to the camera.
The CF card images and sounds can be registered to
the camera with the following procedures.
· Start-up Image · Start-up Sound
· Operation Sound · Selftimer Sound
· Shutter Sound
1
Turn the mode lever toward
(Playback).
2
Press the MENU
button and press the
X
XX
X arrow twice.
The [ (My Camera)] menu
appears.
3
Select the menu item you wish to register
using the
S
SS
S
or
T
TT
T
arrow and select or
using the
W
WW
W
or
X
XX
X
arrow.
appears.
4
Press the DISPLAY button.
z The start-up image screen or the sound
recording menu appears
5
2
2, 3,
5
4
1
DISPLAY
8. Camera Settings 113
Registering a Start-up
z Select the image you wish
to register using the W or X
arrow and press the SET
button.
Registering Start-up,
Operation, Self-timer and
Shutter Sounds
z Select (Record) using
the W or X arrow and press
the SET button.
z Recording will start and automatically stop
when the time is exceeded.
z Select (Register) and press the SET button.
5
Select [OK] using the W
WW
W or X
XX
X arrow
and press the SET button.
Start-up Sound: 1 sec. Operation Sound: 0.3 sec.
Self-timer Sound: 2 sec. Shutter Sound: 0.3 sec.
File Format of My Camera Settings
My Camera settings should conform to the below file
formats. However, CF card images shot with this
camera can be registered as My Camera settings
regardless of the below formats.
z
zz
z Start-up Image
- Recording image format JPEG (Base line JPEG)
- Sampling rate 4:2:0 or 4:2:2
- Image size 320 x 240 pixels
- File size 20 KB or less
z
zz
z Start-up Sound, Operation Sound, Selftimer
Sound and Shutter Sound
- Recording format WAVE (monaural)
- Quantization bit 8 bit
- Sampling frequency 11.025 kHz and 8.000 kHz
zSounds recorded using the Sound Memo
function (p. 101) and movies cannot be
registered as My Camera settings.
zWhen you register new My Camera settings,
the previously registered settings are erased.
114 8. Camera Settings
- Recording time
Any file format other than those described above
cannot be used with this camera.
An example of this function is to record "Say cheese"
as a self-timer sound so the camera will play back
this sound 2 seconds before the photo is taken. You
could also record cheerful music to bring out the
natural smiles of your subjects, or so they can strike
a pose fitting the music. In these ways, you can
customize your camera by creating and adding new
My Camera settings.
See the supplied Software Starter Guide for more
information on creating and adding My Camera
files.
11.025 kHz 8.000 kHz
Start-up Sound 1.0 sec. or less 1.3 sec. or less
Operation Sound
0.3 sec. or less 0.4 sec. or less
Selftimer Sound 2.0 sec. or less 2.0 sec. or less
Shutter Sound 0.3 sec. or less 0.4 sec. or less
9. Additional Features 115
9. Additional Features
Downloading Images to a Computer
Download images taken with the camera to a
computer in one of the following ways:
Connect the camera to a computer with
the USB cable
You can then download images directly from the
camera to a computer.
Directly from the CF card
Using a card adapter or a card reader, you can
download images directly from the CF card.
After the software is installed, you can use it to easily
download images and print them or send them by e-
mail.
You must install the software and driver bundled on
the supplied Canon Digital Camera Solution Disk
onto your computer if you are using any of the
following operation systems:
z Windows 98 (including Second Edition)/
Windows 2000 / Windows Me
z Mac OS 9.0 - 9.2
It is recommended to power the camera with the
separately sold Compact Power Adapter CA-
PS700 when connected to a computer (p. 143).
All procedures performed with a connection to
a USB 2.0 compliant board are not
guaranteed.
1
Install the driver and the software
applications bundled on the Canon
Digital Camera Solution Disk.
Refer to the Software Starter Guide in the following
circumstances
z You connected the camera to the computer
before installing the driver and software and the
camera is not being recognized by the computer
(see the Troubleshooting section of the Software
Starter Guide)
z You want to find out about the computer system
requirements or about driver and software
installation procedures.
z You want to find out about how to operate the
camera/computer after the connection is made.
116 9. Additional Features
2
Connect the supplied interface cable
to the computer's USB port and the
camera's DIGITAL terminal.
DIGITAL Terminal
a Open the terminal cover with your fingernail.
b Hold the USB connector so the side is up,
then insert it into the DIGITAL terminal
securely.
USB port
Interface cable
bInterface cable
aDIGITAL terminal cover
z To disconnect the cable from the camera: Hold
the cable connector firmly at both sides and pull
it straight out.
z You do not need to turn off the computer or
camera when making a USB connection.
z Please refer to your computer manual for
information regarding the location of the USB
port.
z The camera's LCD monitor (or viewfinder) will
blank out when the connection to the computer
is complete and the power/mode indicator will
light yellow.
9. Additional Features 117
Downloading Images without Installing the Software
(Windows XP and Mac OS X (v10.1 or v10.2) only)
If you are using Windows XP or Mac OS X (v10.1 or
v10.2), you can use the software distributed with
these operating systems to download images (JPEG
format only) without installing the software bundled
on the Canon Digital Camera Solution Disk. This is
useful for downloading images to a computer in which
the software is not installed.
However, please note that there are certain
limitations to downloading images with this method.
For more details, please refer to the supplied For
Windows
®
XP and MC OS X Users leaflet.
1.Connect the supplied interface cable to the
computer's USB port and the camera's DIGITAL
terminal. (Refer to Step
2
of page 116).
2.Follow the onscreen instructions to download the
images.
Mac OS X (v10.1 or v10.2)
When downloading images that have sound
memos with iPhoto, the sound memo file will
not be downloaded. In addition, please note if
[Erase camera contents after transfer] is
selected when you download images, sound
memo files will also be deleted.
Downloading Directly from a CF Card
1
Eject the CF card
from the camera,
and insert it into
a CF card reader
connected to the
computer.
z If you are using a PC
card reader or PC
card slot in your
computer, first insert
the CF card into a PC
card adapter (sold separately) a, and then
insert the PC card adapter into the computer's
PC card reader or PC card slot b.
2
Double-click the icon of the drive
with the CF card.
z Depending on the OS, the CF card screen may
automatically open.
a
b
118 9. Additional Features
3
Copy images from the card into a
folder of your choice on the hard disk.
z
The images are stored in the [xxxCANON] folders
located under the [DCIM] folder (where xxx is a
three-digit number from 100 to 998) (p. 155).
Viewing Images on a TV Set
A video-compatible television connected via the
supplied AV cable AVC-DC300 can be used to
view images as you shoot or play back them.
1
Turn off the camera (p. 19) and the TV.
2
Attach the AV cable to the A/V OUT
terminal on the camera.
3
Plug the other ends of the AV cable
to the video in an daudio in jacks on
the TV.
Black Plug
To the Audio In Jack
Yellow Plug
To the Video In Jack Plug
9. Additional Features 119
4
Turn on the TV and switch it to Video
mode.
5
Power the camera into Shooting
mode or Playback mode (p. 19).
z The image will appear on the TV. Shoot or play
back images as usual.
No image will appear on the LCD monitor (or
viewfinder) when the camera is connected to a
TV monitor.
The video output signal can be switched
(NTSC or PAL) to accommodate different
regional standards. The default setting will vary
between regions.
NTSC:Japan, U.S.A., Canada, Taiwan, etc.
PAL:Europe, Asia (excluding Taiwan),
Oceania, etc.
If an incorrect vide system is set, the output
image will not display properly.
If the TV is a stereo model, you can plug the
audio plug into either the left or right Audio In
jack. Please refer to the TV's manual for details.
A TV set cannot be used in the (Stitch
Assist) mode.
About Printing
There are two ways of printing images shot
with this camera.
z You can easily print images stored in the CF card
by connecting the camera to a direct print
compatible printer
*1
with a cable and operating the
camera buttons.
z You can specify the images on your CF card you
want to print and how many copies you want
(DPOF
*2
Print Settings), and then take the CF card
to a participating photo lab that supports DPOF to
have them printed out later.
*1
This camera complies with the industry standard
PictBridge, therefore, you can connect the camera
to non-Canon PictBridge compliant printers and
print images.
*2
Digital Print Order Format
This manual explains the DPOF print settings. For
information on how to print images, refer to the
Direct Print User Guide supplied with the camera.
Also, refer to your printer's manual.
120 9. Additional Features
Photo Lab
Print settings (DPOF Print Settings) (p. 121)
Image Transmission Settings (DPOF Transfer
Order) (p. 126)
Direct Print Compatible Printing
- For details, see the Direct Print user Guide.
- Also, refer to your printer's manual.
Printers that Can Be Used with this Camera
CP Direct Compatible CP Printers
- See the System Map
Direct Print Compatible Bubble Jet Printers
- For more information, visit your nearest Canon
retailer.
Direct Print
Compatible Printers
zCP Printer zBubble Jet
Printer
zNon-Canon PictBridge
compliant printers
9. Additional Features 121
Print Settings (DPOF Print Settings)
You can select images on a CF card for printing and
specify the number of print copies in advance using
the camera. This is extremely convenient for sending
the images to a photo developing service or for
printing on a direct print function compatible printer.
Refer to the Direct Print User Guide for instructions
on how to select print settings from the printer.
zThe mark may appear on images that
have had print marks set by another DPOF
compliant camera. These settings will be
overwritten by any print marks set by your
camera.
zThe output of some digital printers or photo
lab services may not reflect the specified print
settings.
zPrint settings cannot be set for movies.
Selecting Images for Printing
1
In the [ (Play)]
menu, select [Print
Order] and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
2
Select [Order] using
the W
WW
W or X
XX
X arrow
and press the SET
button.
1, 2
1, 4
2
122 9. Additional Features
3
Select images for printing.
Single Images
z When the print type
(p. 123) is set to
[Standard] or [Both],
select an image using the
W or X arrow. You can
set the number of copies
(up to 99) to be printed
using the S or T arrow.
z When the print type
(p. 123) is set to [Index],
select an image using the
W or X arrow and mark or
remove marks from
images using the S or T
arrow. A check mark
appears on the marked image.
z You can use the same procedures to select
images in index playback (3 images). Turn the
zoom lever toward to switch between single
image playback and index playback.
Number of copies
All the Images on the CF
Card
z Turn the zoom lever
toward to switch to
index playback (3 images).
z You can set one copy of
each image to print by
pressing the SET button,
then selecting [Mark all] using the S or T
arrow, and pressing the SET button again.
z When the print type is set to [Standard] or
[Both], the setting for the number of print copies
can be changed for each image. When [Index]
is selected, the print settings can be deleted.
For the instructions on changing settings,
please reread Step 3 from the beginning.
z You can cancel all the settings by selecting
[Clear all].
z After having marked all images or cleared all
images, you can choose a specific image and
select settings.
4
Press the MENU button.
The selection mode will turn off and the Print
Order menu will reappear.
Number of copies
9. Additional Features 123
Images are printed in order from oldest to
newest by the shooting date.
A maximum of 998 images can be marked per
CF card.
When [Print Type] is set to [Both], the number
of copies can be set. When it is set to [Index],
the number of copies cannot be set (only one
copy will be printed).
Print settings can also be assigned to images
with the supplied software programs
(ZoomBrowser EX or ImageBrowser) on a
computer.
Setting the Print Style
Always select a print style after having selected
the image you wish to print.
The following print settings can be selected.
Print Type
Standard Prints one image per page
Index
Prints the selected images together at
a reduced size in an index format
Both
Prints the images in both the standard
and index formats
Date Adds the date to the print
File No. Adds the file number to the print
124 9. Additional Features
1
In the [ (Play)]
menu, select [Print
Order] and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
2
Select [Set up] using
the W
WW
W or X
XX
X arrow
and press the SET
button.
1, 2
1, 4
2, 3
3
Select [Print Type],
[Date] or [File No.]
using the S
SS
S or T
TT
T
arrow and select
settings using the W
WW
W
or X
XX
X arrow.
Print Type
z Select [Standard], [Index] or [Both].
Date
z Select [On] or [Off].
File No.
z Select [On] or [Off].
4
Press the MENU button.
The set up menu will close and the Print Order
menu will reappear.
zWhen [Print Type] is set to [Index], the [Date]
and [File No.] cannot be set to [On] at the
same time.
zWith CP printers, if [Print Type] is set to
[Both], both [Date] and [File No.] can be set to
[On], however, only the file number is printed
for the index print.
9. Additional Features 125
The date prints as the date and time in the
format specified in the Set Date/Time menu
(p. 21).
Resetting the Print Settings
The print settings can all be removed at once. The
print type is reset to [Standard] and the date and file
number options are set to [Off].
1
In the [ (Play)]
menu, select [Print
Order] and press the
SET button.
z See Selecting Menus and
Settings (p. 62).
1, 2,
3
1
2, 3
2
Select [Reset] using
the W
WW
W or X
XX
X arrow
and press the SET
button.
3
Select [OK] using
the W
WW
W or X
XX
X arrow
and press the SET
button.
126 9. Additional Features
Image Transmission Settings (DPOF Transfer Order)
You can use the camera to specify settings for
images before downloading to a computer.
Refer to the Software Starter Guide for
instructions on how to transfer images to your
computer. You cannot use this function to
transfer several images at once on Mac OS X
computers.
The settings used on the camera comply with
the Digital Print Order Format (DPOF)
standards
.
The mark may appear on images that have
had transfer marks set by another DPOF
compliant camera. These settings will be
overwritten by any transfer marks set by your
camera.
Selecting Images for Transferring
1
In the [ (Play)]
menu, select
[Transfer Order] and
press the SET button.
z See Selecting Menus and
Settings (p. 62).
2
Select [Order] using
the W
WW
W or X
XX
X arrow and
press the SET button.
z To cancel the image
transfer settings, select
[Reset] instead.
1, 2
1, 4
2
9. Additional Features 127
3
Select images for transferring.
Single Images
z Select an images using the
W or X arrow and mark or
remove marks from images
using the S or T arrow. A
check mark (3
33
3) appears on
the marked image.
z You can use the same procedures to select
images in index playback (3 images). Turn the
zoom lever toward to switch between single
image playback and index playback.
All the Images on a CF Card
z Turn the zoom lever
toward to switch to
index playback (3 images).
z Press the SET button and
select [Mark all] using the
S or T arrow, then press the SET button again
to select all the images.
z If you select [Clear all] instead or [Mark all], you
cam remove marks from all the images.
z You can select images using the W or X arrow
and change the settings using the S or T
arrow after [Mark all] or [Clear all] has been
selected.
4
Press the MENU button.
The selection mode will turn off and the Transfer
Order menu will reappear.
Images are transferred in order from oldest to
newest by the shooting date.
A maximum of 998 images can be marked per
CF card.
128 Appendix
Appendix
List of Messages
The following messages may appear on the LCD monitor (or viewfinder).
z For messages which may appear when a printer is connected, refer to the Direct Print User Guide.
Busy... Image is being recorded to, or read from, CF card.
Resetting all the camera and menu settings to default
No memory card You attempted to shoot or play back images without a CF card installed.
Cannot record! You attempted to shoot an image without a CF card installed.
Memory card error! CF card has experienced an anomaly.
Memory card full CF card is too full to accommodate more images or print settings.
Naming error! The file could not be created because there is a file with the same name as the directory that the camera is
attempting to create, or the highest possible file number has already been reached. In the Set up menu,
please set [File No. Reset] to [On]. After you save all the images you wish to retain onto a computer,
format the CF card (p. 18). Please note that formatting will erase all the existing images and other data.
Change the batteries Battery charge is insufficient to operate the camera. Replace with new AA-size alkaline batteries or fully
charged Canon AA-size NiMH batteries (p. 15) (be sure to replace all the batteries at the same time).
Overheated! Shutting down. The internal temperature of the camera became too hot and the camera powered down.
No image No images recorded on CF card.
Image too large You attempted to play back an image larger than 4064 x 3048 pixels.
Incompatible JPEG format You attempted to play back an incompatible JPEG file.
Corrupted data You attempted to play back an image with corrupted data.
RAW You attempted to play back an image recorded in an incompatible RAW format.
Cannot magnify! You attempted to magnify a movie or an image that was photographed with another camera, recorded in a
different format, or edited on a computer.
Appendix 129
Cannot rotate You attempted to rotate a movie or an image that was photographed with another camera, recorded in a
different format, or edited on a computer.
Unidentified Image You attempted to play back an image that was recorded in a special format (proprietary format used by the
camera of another manufacturer, etc.) or a movie clip recorded by another camera.
Incompatible WAVE format Cannot attach sound memos to the image because the image has some sound file recorded in an
inappropriate format.
Protected! You attempted to erase a protected image.
Too many marks Too many images have been marked with print settings, transfer settings or slide show settings. Cannot
process any more.
Unselectable image You attempted to set the print settings for a non-JPEG file.
Cannot complete! Couldn’t save the print, transfer or slide show settings.
Cannot edit Slide show settings file is corrupted.
Cannot register this image! You attempted to register an image recorded with another camera or shot in the RAW format as a start-up
image.
130 Appendix
Troubleshooting
Problem Cause Solution
Camera will not operate Power is not turned on. Turn on the camera.
See Turning the Power On/Off (p. 19)
CF card slot cover or battery cover opened. Confirm that the CF card slot cover and battery cover are
securely closed.
Batteries are loaded in the wrong direction. Reload the batteries in the correct direction.
Insufficient battery voltage. zReplace with unused alkaline or fully recharged batteries (four
AA-size batteries).
zUse the Compact Power Adapter.
Batteries are not the right type. Use only unused AA-size alkaline batteries or Canon AA-size
NiMH batteries. For information about alkaline batteries,
see Proper Battery Handling (p. 15).
Poor contact between camera and battery
terminals.
Wipe the terminals with a clean, dry cloth.
Camera will not record Camera is in Playback or computer/printer
connection mode.
zTurn the mode lever to the left to switch to Shooting mode.
zDuring a computer or printer connection, disconnect the
interface cable before switching the camera to Shooting mode.
Flash is charging (Blinking on LCD monitor/in
viewfinder).
Wait until stops blinking and lights steadily, signaling that the
flash is charged, then press the shutter button.
CF card full. zInsert a new CF card.
zIf required, download the images to a computer and erase
them from the CF card to make space.
CF card not formatted correctly. zFormat CF card.
See Formatting a CF Card (p. 18).
zIf reformatting doesn't work, the CF card logic circuits may be
damaged. Contact the nearest Canon Customer Support Help
Desk.
Appendix 131
Cannot play back You attempted to play back images shot with
another camera or images edited on a computer.
Computer images that cannot be played back will play back if they
are added to the camera using the bundled software program
ZoomBrowser EX or ImageBrowser. See the ZoomBrowser EX/
ImageBrowser Software User Guide (PDF).
File name was changed with a computer or file
location was changed.
Set the file name or location to the file format/structure of the
camera. (See About File and Folder Numbers (p. 155).)
Lens will not retract CF card slot cover or battery cover opened with
camera on.
Close the CF card slot cover or battery cover, then turn off the
camera.
CF card slot cover or battery cover opened while
camera was recording to CF card (warning signal).
Close the CF card slot cover or battery cover, then turn off the
camera.
Switched to Playback mode from Shooting
mode.
The lens does not retract in this case. To make the lens retract,
close the lens cover.
Batteries consumed
quickly
Batteries are not the right type. Use only unused AA-size alkaline batteries or Canon AA-size
NiMH batteries. For information about alkaline batteries,
see Proper Battery Handling (p. 15).
The batteries are cold. Battery performance deteriorates at low temperatures. If
shooting in a cold area, keep the batteries warm (by placing
them in an inner pocket, etc.) until ready to use them.
Battery terminals are dirty. Wipe them well with a dry cloth before use.
The batteries have not been used for over a
year.
If batteries are rechargeable: Performance should return to
normal after several charging cycles.
If rechargeable batteries: The batteries have lost
their effectiveness.
Replace all 4 batteries with new ones.
Problem Cause Solution
132 Appendix
If using rechargeable
batteries: Batteries do
not charge in separately
sold battery charger.
Batteries were placed in the charger in the
wrong direction.
Put batteries back into the charger in the correct direction.
Poor electrical contact. zBe sure to set batteries firmly into the charger.
zBe sure that the power cord is firmly connected to the charger,
and is firmly plugged in to the power outlet.
Battery terminals are dirty. Wipe them well with a dry cloth before charging.
Battery life exceeded. Replace all 4 batteries with new ones.
Image is blurred or out
of focus
Camera moved. zBe careful not to move the camera when pressing the shutter
button.
zUse a tripod at slow shutter speeds when the camera shake
warning appears.
zTurn the Image Stabilizer function on.
Subject out of focal range. Ensure that there is at least 50 cm (1 ft.) between the camera
lens and subject.
Subject is hard to focus on. Use the focus lock or the manual focus to shoot the image.
See Shooting Problem Subjects for the Autofocus (p. 93).
Problem Cause Solution
Appendix 133
Subject in recorded
image is too dark
Insufficient light for shooting. Set the built-in flash to on.
Subject dark in comparison to the background. zSet the exposure compensation to a positive (+) setting.
zUse the AE lock or spot metering function.
See Locking the Exposure Setting (AE Lock) (p. 86)
and Switching between Light Metering Modes (p. 76).
Subject too far for flash to reach. zTo use the built-in flash, shoot within the following ranges:
Auto ISO: 1.0 to 4.2 m (3.3 to 14 ft.) of the subject at the
maximum wide angle and within 1.0 to 3.0 m (3.3 to 9.8 ft.) at
the maximum telephoto setting.
ISO 100 equivalent: 1.0 to 3.8 m (3.3 to 12 ft.) of the subject
at the maximum wide angle and within 1.0 to 2.5 m (3.3 to 8.2
ft.) at the maximum telephoto setting.
zRaise the ISO sensitivity and then shoot.
See Changing the ISO Speed (p. 81).
Subject recorded in
image is too bright
Subject too close causing flash to be too bright. Adjust the flash output with the flash exposure compensation
function (p. 89).
Subject bright in comparison to the background. zSet the exposure compensation to a negative (-) setting.
zUse the AE lock or spot metering function.
See Locking the Exposure Setting (AE Lock)(p. 86)
and Switching between Light Metering Modes (p. 76).
Light shining directly on subject or reflected off
subject into camera.
Change the shooting angle.
Flash set to On. Set the flash to Auto or Off.
A vertical bar of light
(red, purple) appears on
the LCD monitor/in the
viewfinder
Subject too bright This is a normal occurrence in devices containing CCDs and
does not constitute a malfunction. (This red bar of ight will not be
recorded when shooting still photos, but it will be recorded when
shooting movies.)
Problem Cause Solution
134 Appendix
White dots or white
asterisks appear on the
Light from the flash has reflected off dust
particles or insects in the air. This occurs more
frequently in the following conditions:
zWhen shooting at the wide angle end.
zWhen shooting with a high aperture value in
the aperture-priority AE mode.
This is a phenomenon that occurs with digital cameras and does
not constitute a malfunction.
Flash will not fire Flash set to Off. Set the flash to Auto or On.
Image not showing on
TV
Incorrect video system setting. Set the video system to the appropriate setting, NTSC or PAL,
for your TV (p. 67).
Shooting mode set to (Stitch Assist). The output will not appear on a TV monitor in (Stitch
Assist) mode. Shoot in a different mode.
CF card image reading
is slow
Currently used CF card has been formatted in a
different device.
Use a CF card formatted with this camera.
See Formatting a CF Card (p. 18).
Recording images on
the CF card takes too
long
Problem Cause Solution
Appendix 135
Using the Wireless Controller (Sold Separately)
Installing the Battery
Install the date battery (CR2025) into the Wireless
Controller WL-DC100 (sold separately) before use.
1
Place your fingertip
on a
aa
a and press it in
the direction of the
arrow while placing
another fingertip on
b
bb
b and removing the
battery holder.
2
Place the date bat-
tery in the battery
holder with the neg-
ative terminal (-) fac-
ing up. Then replace
the battery holder
into the wireless controller.
Warning
Be particularly careful to keep the date batteries out of the
reach of children. Seek medical assistance immediately if
a child swallows a battery since corrosive battery fluids
could damage the stomach or intestinal wall.
Negative
terminal
(-)
Removing the Battery
To remove the date battery, pull
it in the direction of the arrow.
Shooting/Playback
The wireless controller can be used to shoot or play
back. The wireless controller can be operated from
an approximate distance of up to 5 m (16.4 ft.) from
the front remote sensor.
If you ever dispose of your camera, first
remove the date battery for recycling
according to the recycling system of your
country.
Bij dit produkt zijn batterijen
geleverd. Wanneer deze leeg
zijn, moet u ze niet weggoolen
maar inleveren als KCA
Transmitter
Remote Sensor
136 Appendix
Shooting
Press the button on the camera until the
or icon appears in the LCD monitor (or
viewfinder), then shoot the image.
aCompose the image with the
zoom ring.
bPress the shutter button. The
camera will shoot the image after
the time set in [Wireless Delay] in
the Rec. menu has elapsed (0
seconds, 2 seconds or 10
seconds).
zEach press of this button switches
the information view mode
between No Information and
Information View.
Playback
The movie editing and printing functions are not
available.
The operable range of the wireless controller
will shorten under the following circumstances.
- When strong light strikes the camera.
- When the battery is weak.
zDisplay the next
zIn magnified mode,
these buttons move
the magnified area
around the image.
zIn index playback,
these buttons move
the image selection.
zEach press of this
button cycles the
information view mode.
z
Display images in sets
of nine (index playback)
zDisplay the
previous
zPlay back
movies
zThe display cycles between
magnifications of
approximately 2.5, 5 and 10.
Appendix 137
Using Conversion Lenses (Sold Separately)
Conversion Lens Adapter LA-DC52E and Lens Hood
LH-DC20 are included in the separately sold Lens
Adapter/Hood Kit LAH-DC10.
The camera supports use of the separately sold
Wide Converter WC-DC52A and Tele-converter TC-
DC52B. In order to attach any of these lenses, you
also need to use the separately sold Conversion
Lens Adapter LA-DC52E (included with LAH-DC10).
When shooting in backlit conditions without the flash
and at the wide angle end, the use of the lens hood is
recommended to prevent external light from entering
the lens.
Warning
z When attaching the wide converter or tele-
converter, be sure to screw it on securely. If they
come loose, they may fall from the lens adapter,
posing risk of injury from shattered glass.
z Never look into the sun or into strong light
through the wide converter or tele-converter as
this can result in blindness or impairment of
vision.
zIf you use the built-in flash when shooting with
the wide converter, the outer area of the
recorded image (especially the bottom part of
the image) will come out relatively dark.
zWhen using the wide converter, please set
the camera to the wide angle end.
zWhen using the tele-converter, please set the
focal length to the telephoto end. At other
zoom settings, the image will appear as if its
corners have been cut off.
Wide Converter
WC-DC52A
This 52 mm-threaded magnifying
conversion lens is for taking wide angle
shots. The wide converter changes the
focal length of the camera body's lens
by a factor of 0.7.
Tele-converter
TC-DC52B
This 52 mm-threaded diameter
magnifying conversion lens is for taking
telephoto shots. The lens changes the
focal length of the camera body's lens
by a factor of 1.6.
Filters and lens hoods cannot be attached to
the wide converter and tele-converter lens.
138 Appendix
Attaching a Lens/Lens Hood
1
Be sure that the
camera is turned off.
Press the ring
release button and
hold it down, turn
the ring in the
direction of the
arrow and remove it.
2
Align the z
zz
z marks on the conversion
lens adapter and the z
zz
z mark on the
camera, and turn the adapter in the
direction of the arrows as far as the
S
SS
S mark on the camera.
Ring Release Button
Ring
Conversion Lens
Adapter LA-DC52E
when attached.
3
Set the lens or lens hood on the
adapter, and attach it securely by
turning it in the indicated direction.
Wide Converter WC-
DC52A when attached.
Appendix 139
zYou should not shoot images in (Stitch
Assist) mode when using these attachments.
Although it is possible to select this mode on
the camera, the PhotoStitch software will not
be able to stitch the images together at the
computer.
zTo protect the conversion lens, hold the
camera's lens with one had and screw the
conversion lens onto the camera with the
other hand.
zCompletely remove all dust and dirt from
conversion lenses with a lens blower brush
before use. The camera may focus on any dirt
that remains.
zBe careful when handling the lenses so as not
to get fingerprints on them.
zOnce the lens adapter is screwed on the
camera, it locks into place. When removing
the wide converter or the tele-converter, do so
while firmly pressing on the lens adapter with
your hand to avoid damage to the lenses.
140 Appendix
Using the Power Kits (Sold Separately)
Using Rechargeable Batteries
(Battery and Charger Kit CBK4-200)
Included are the battery charger and four
rechargeable AA-size NiMH (nickel metal hydride)
batteries. Charge batteries as shown below.
zThe charge indicator blinks while charging,
then remains lit when charging is finished.
zThis charger can be used only to charge
Canon AA-size NiMH batteries NB-2AH.
Please do not attempt to charge NB-2AH
batteries in any other type of charger.
zNever mix new batteries together with
batteries that have been used in other devices.
zWhen recharging batteries from the camera,
always recharge all four of them at the same
time.
Charge Indicator
zAll batteries you place in the charger should
be at approximately the same charge state,
and should have been purchased at the same
time. Do not mix batteries with different
purchase dates or different charge states.
zDo not attempt to recharge fully charged
batteries, as doing so may reduce or impair
battery performance. Also, do not charge
batteries for more than 24 consecutive hours.
zDo not recharge batteries in enclosed areas
that tend to retain heat.
zRepeatedly recharging batteries before they
become fully depleted may cause batteries to
lose capacity. Do not recharge the batteries
until the LCD monitor displays the "Change
the batteries" message.
zWipe the battery terminals well with a dry
cloth in the following situations, as the
terminals may be soiled with oil from one's
skin or other dirt:
- if the battery usage time has considerably
diminished
- If the number of recordable images has
considerably diminished
Appendix 141
- When charging the batteries (insert and
remove the batteries two or three times
before charging)
- When charging completes in a matter of a
few minutes (the battery charger indicator
remains lit)
zYou may not be able to fully charge the
batteries due to their specifications right after
purchase or after long periods of non-use. If
this happens, use the batteries until their
charge is depleted before charging them
again. After doing this several times, battery
performance will be restored.
zSince storing fully charged batteries for long
periods of time (about 1 year) can shorten
their lifecycle or affect performance, you are
recommended to use the batteries in the
camera until they are completely discharged
and to store them at normal temperature
(23 °C/73 °F) or less. If you do not use the
batteries for long periods of time, charge them
fully and discharge them fully in the camera at
least once a year before returning them to
storage.
zIf battery usage time is considerably low
despite their terminals being wiped and the
battery charger's indicator remaining lit, it is
possible that the batteries have reached the
end of their lifespan. Switch to different,
unused batteries. If you are purchasing new
batteries, look for Canon's AA-size NiMH
batteries NB4-200 (a NB-2AH four-battery
set).
zLeaving batteries in the camera or charger
may damage it causing battery leakage.
Remove batteries from the camera or charger
and store in a dry cool location when not in
use.
142 Appendix
It takes approximately 250 minutes for the
charger to fully recharge the batteries (as
determined by testing at Canon facilities).
Please do not charge batteries in areas where
the temperature is outside the range of 0 to
35 °C (32 to 95 °F).
Charging time varies according to ambient
temperature and to the batteries' initial charge
state.
The battery charger may emit noise while
charging. This is not a malfunction.
Battery/Charger Kit CBK100 can also be used.
Use Canon AA-size batteries NB-1AH with the
charger included in the CBK100 kit.
Appendix 143
Compact Power Adapter
You should use the separately sold Compact Power
Adapter CA-PS700 when using the camera for long
periods of continuous use or for connecting to a
computer or printer.
1
Attach the power cord to the
compact power adapter and plug it
into a power outlet.
To power outlet
2
Open the terminal cover and connect
the DC plug of the compact power
adapter to the camera's DC IN
terminal.
z Always disconnect and unplug the compact
power adapter after use.
zAlways turn the camera's power off (p. 19)
before connecting or disconnecting the
compact power adapter.
zUsing any other device than Compact Power
Adapter CA-PS700 may lead to camera and
compact power adapter malfunctions.
144 Appendix
Replacing the Date Battery
If the Set Date/Time menu appears when you
turn on the camera power, the date battery
charge is low and the date and time settings
have been lost. Please replace the battery with
a commercially available lithium coin battery
(CR1220) with the following procedures.
Please note that the first date battery may appear
to expire relatively quickly after you purchase the
camera. This is because it is installed in the camera
at the point of manufacture, not when you make the
purchase.
Warning
Be particularly careful to keep the date batteries out
of the reach of children. Seek medical assistance
immediately if a child swallows a battery since
corrosive battery fluids could damage the stomach
or intestinal wall.
1
Turn off the power
and slide the battery
cover in the
direction of the
arrows.
2
Remove the AA-size
batteries, then pull
out the battery
holder by hooking
your fingertip under
the bottom of the
battery holder edge.
3
Remove the old date
battery and place a
new date battery into
the date battery
holder with the
negative terminal (-)
facing upward.
4
Replace the date battery holder,
replace the AA-size batteries and
close the battery cover.
Appendix 145
Camera Care and Maintenance
Use the following procedures to clean the camera
body, lens, viewfinder, LCD monitor and other parts.
Camera body : Wipe the body clean with a soft cloth or
eyeglass lens wiper.
Lens : First use a lens blower brush to remove dust
and dirt, then remove any remaining dirt by
wiping the lens lightly with a soft cloth.
zNever use synthetic cleansers on the
camera body or lens. If dirt remains,
contact the nearest Canon Customer
Support Help Desk as listed on the
separate Canon Customer Support leaflet.
Viewfinder
LCD Monitor
: Use a lens blower brush to remove dust and
dirt. If necessary, gently wipe the viewfinder
and LCD monitor with a soft cloth or an
eyeglass lens wiper to remove stubborn dirt.
zNever rub or press forcefully on the LCD
monitor or viewfinder. These actions may
damage them or lead to other problems.
Never use thinners, benzene, synthetic
cleansers or water to clean the camera. These
substances may distort or damage the
equipment.
146 Appendix
Specifications
All data is based on Canon's testing standard. Subject to change without notice.
PowerShot S1 IS
Camera Effective Pixels Approx. 3.2 million
Image Sensor 1/2.7 -inch CCD (Total number of pixels: Approx 3.3 million)
Lens 5.8 (W) – 58 (T) mm (35mm film equivalent: 38 - 380 mm)
f/2.8 (W) – f/3.1 (T)
Digital Zoom Approx. 3.2x (Up to approx. 32x in combination with the optical zoom)
Viewfinder Color LCD viewfinder
Picture coverage 100 %
LCD Monitor 1.5-inch, low-temperature polycrystalline silicon TFT color LCD (Picture coverage 100%)
AF System TTL autofocus
Focus lock and Manual focus are available
Focusing frame: 1-point AF (any position is available)
Shooting Distance
(from the front of the lens)
Normal AF: 10 cm (3.9 in.) – infinity (W)/ 93 cm (3.0 ft.) – infinity (T)
Manual focus: 10 cm (3.9 in.) – infinity (W)/93 cm (3.0 ft.) – infinity (T)
Shutter Mechanical shutter + electronic shutter
Shutter Speeds 15 – 1/2000 sec.
1.3 sec. or slower shutter speeds are available in Shutter-priority mode or Manual mode.
Slow shutter speeds of 15 to 1.3 sec. or slower operate with noise reduction.
Light Metering System Evaluative, Center-weighted average or Spot (Center or AF-point)
Exposure Control System Program AE, Shutter-priority AE, Aperture-priority AE or Manual exposure control
AE lock is available.
Exposure Compensation ± 2.0 stops in 1/3-stop increments
Auto exposure bracketing (AEB) is available.
Sensitivity Auto, ISO 50/100/200/400 equivalent
Appendix 147
White Balance TTL auto, pre-set (available settings: Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H or
Flash) or custom
Built-in Flash Auto*, on*, off
* Red-eye reduction is available.
Flash Range 1.0 – 4.2 m (3.3 – 14 ft.) (W), 1.0 – 3.8 m (3.3 – 12 ft.) (T)
(When sensitivity is set to ISO 100 equivalent.)
Flash Exposure Compensation ± 2.0 stops in 1/3-stop increments, FE lock, Slow synchro and 1st-curtain/2nd-curtain flash are
available.
Shooting Modes Auto
Creative zone: Program, Shutter-speed priority, Aperture priority, Manual, Custom
Image zone: Portrait, Landscape, Night scene, Fast shutter, Slow shutter. Stitch assist and Movie
Continuous Shooting Approx. 1.7 shots/sec. (Large/Fine mode)
Interval Shooting Shooting interval: approx. 1 – 60 min. (1-min. increments)
Number of shots: 2 – 100 shots (Maximum number of shots varies according to CF card capacity.)
Self-timer Activates shutter after an approx. 10-sec./approx. 2-sec. delay
Wireless Control Shooting and playback are available (wireless controller is sold separately).
When shooting, image is captured instantly/approx. 2-sec./approx. 10-sec. after shutter button is
pressed.
PC-controlled Shooting Available (USB connection only. Exclusive software program is included in the camera kit.)
Recording Media CompactFlash™ (CF) card (Type I and Type II)
File Format Design rule for camera file system and DPOF compliant
148 Appendix
Image Recording Format
Still images:
Movies:
JPEG (Exif 2.2)
*1
AVI (Image data: Motion JPEG; Audio data: WAVE (monaural))
Compression Super fine, Fine, Normal
Number of Recording Pixels
Still images:
Movies:
Large: 2048 x 1536 pixels
Medium 1: 1600 x1200 pixels
Medium 2: 1024 x 768 pixels
Small: 640 x 480 pixels
640 x 480 pixels Fine
640 x 480 pixels
320 x 240 pixels
A maximum file size of 1 GB and a maximum of 1-hour recording are available in one movie
shooting session.
Frame Rate 15 frames/sec. or 30 frames/sec.
Audio Data Sampling frequency: Approx. 22 kHz
Quantization bit: 16 bit
Playback Modes Single (histogram displayable), Index (9 thumbnail images), Magnified (approx. 10x (max.) in LCD
monitor/viewfinder), Sound memos (recording/playback up to 60 sec.) or Slide show
Direct Print Canon Direct Print and Bubble Jet Direct compatible, and PictBridge compliant
Display Languages 12 languages available for menus and messages (English, German, French, Dutch, Danish,
Finnish, Italian, Norwegian, Swedish, Spanish, Chinese and Japanese)
My Camera Settings The start-up image, start-up sound, shutter sound, operation sound and self-timer sound can be
customized using the following methods:
1. Using the images and sounds recorded on a camera.
2. Using downloaded data from your computer using the supplied software.
Interface USB (mini-B, PTP [Picture Transfer Protocol])
Audio/Video output (NTSC or PAL selectable, monaural audio)
Appendix 149
(W): Wide angle end
(T): Telephoto
*1
This digital camera supports Exif 2.2 (also called "Exif Print"). Exif Print is a standard for enhancing the
communication between digital cameras and printers. By connecting to an Exif Print-compliant printer, the
camera's image data at the time of shooting is used and optimized, yielding extremely high quality prints.
Power Source 1. Four AA-size alkaline batteries (included in the camera kit)
2. Four AA-size rechargeable NiMH batteries (NB4-200) (sold separately)
3. Compact Power Adapter (CA-PS700) (sold separately)
Operating Temperature 0 – 40 °C (32 – 104 °F)
Operating Humidity 10 – 90 %
Dimensions 111 x 78.0 x 66.1 mm (4.4 x 3.1 x 2.6 in.) (excluding protrusions)
Weight Approx. 370 g (13.1 oz.) (camera body only)
150 Appendix
Battery Performance
*
The data above reflects standard Canon testing conditions. The actual figures will vary according to the
shooting conditions and settings.
*
Movie data is excluded.
<Test Conditions>
Shooting: Normal temperature (23 °C/73 °F), alternating wide angle and telephoto end shots at 20-second
intervals with flash fired once every four shots and camera power turned off and on every eighth
shot. CF card used. LCD monitor brightness set to factory default.
Playback: Normal temperature (23 °C/73 °F), continuous playback at one image per 3 seconds. CF card
used. LCD monitor brightness set to factory default.
See Proper Battery Handling (p. 15).
Number of Images Shot
Playback Time
LCD Monitor on Viewfinder on
AA Alkaline Batteries
(included with the camera)
Approx. 120 Approx. 125 Approx. 5 hours 30 min.
AA NiMH Battery (NB4-200) Approx. 550 Approx. 570 Approx. 7 hours 30 min.
Appendix 151
CF Cards and Estimated Capacities (Recordable Images)
zThese figures reflect standard shooting conditions established by Canon. Actual totals may vary according to the subject,
shooting conditions and shooting mode.
zL (Large), M1 (Medium 1), M2 (Medium 2) and S (Small) show compression ratios.
z (Superfine), (Fine) and (Normal) indicate the relative compression ratio.
zSome CF cards are not sold in some regions.
* First setting is approximately 30 frames/second; second and third settings are approximately 15 frames/second.
With card included with the camera
FC-32MH FC-64M FC-128M
FC-256MH FC-512MSH
L (Large) 2048 x 1536 pixels
18 38 76 154 308
33 68 137 276 552
67 136 274 548 1096
M1 (Medium 1) 1600 x 1200 pixels
30 61 122 246 491
54 109 219 440 879
108 217 435 868 1736
M2 (Medium 2) 1024 x 768 pixels
53 107 215 431 855
94 189 379 762 1524
174 349 700 1390 2717
S (Small) 640 x 480 pixels
120 241 482 962 1893
196 393 788 1553 3125
337 676 1355 2720 5209
Movie*
640 x 480 pixels (Fine)
15 sec./30 sec. 30 sec./61 sec. 62 sec./124 sec. 125 sec./249 sec. 250 sec./499 sec.
640 x 480 pixels
20 sec./42 sec. 42 sec./85 sec. 85 sec./170 sec. 172 sec./343 sec. 344 sec./686 sec.
320 x 240 pixels
46 sec./91 sec. 92 sec./183 sec. 186 sec./368 sec. 374 sec./735 sec.
743 sec./1463 sec.
152 Appendix
Image File Sizes (Estimated)
Wireless Controller WL-DC100 (Sold Separately)
Resolution
Compression
L 2048 x 1536 pixels 1602 KB 893 KB 445 KB
M1 1600 x 1200 pixels 1002 KB 558 KB 278 KB
M2 1024 x 768 pixels 570 KB 320 KB 170 KB
S 640 x 480 pixels 249 KB 150 KB 84 KB
Image Quality
Frame Rate
Movie
640 x 480 pixels (Fine) 1980 KB/sec. 990 KB/sec.
640 x 480 pixels 1440 KB/sec. 720 KB/sec.
320 x 240 pixels 660 KB/sec. 330 KB/sec.
Power supply : Date battery CR2025
Operating
temperatures
: 0 – 40 °C (32 – 104 °F)
Dimensions : 35 x 6.5 x 56.6 mm (1.4 x 0.3 x 2.2 in.)
Weight : Approx. 10 g (0.4 oz.)
CompactFlash™ Card
Compact Power Adapter CA-PS700 (Sold Separately)
Battery Charger CB-4AH/CB-4AHE
(Included with the separately sold battery charger Kit CBK4-200)
*1 When using 4 NiMH NB-2AH batteries.
*2 When using 2 NiMH NB-2AH batteries, one at each end of the
charger.
Card slot type : Type I
Dimensions : 36.4 x 42.8 x 3.3 mm (1.4 x 1.7 x 0.1 in.)
Weight : Approx. 10 g (0.4 oz.)
Input voltage
: AC 100 – 240 V (50/60 Hz)
30 VA (100 V) – 40 VA (240 V)
Rated output : DC 7.4 V/2.0 A
Operating
Temperatures
: 0 – 40 °C (32 – 104 °F)
Dimensions : 112 x 49 x 45 mm (4.4 x 1.9 x 1.8 in.)
Weight : Approx. 186 g (6.6 oz.)
Input voltage : AC 100 – 240 V AC (50/60 Hz), 10 W
Rated output : 565 mA
*1
, 1275mA
*2
Charging time : Approx. 250 min.
*1
, Approx. 110 min.
*2
Operating
Temperatures
: 0 – 35 °C (32 – 95 °F)
Dimensions : 65.0 x 105.0 x 27.5 mm (2.6 x 4.1 x 1.1 in.)
Weight : Approx. 95 g (3.4 oz.)
Appendix 153
Wide Converter WC-DC52A (Sold Separately)
Tele-converter TC-DC52B (Sold Separately)
Magnification : Approx. 0.7
Focal range : 26.6 mm (35mm film equivalent)
Lens composition : 3 elements in 3 groups
Shooting distance
(from the front of the lens)
: 0 cm – infinity (0 in. – infinity)
Thread diameter
: 52 mm standard filter thread
Conversion Lens Adapter LA-DC52E is required
to attach this lens to the PowerShot S1 IS
Dimensions
: Diameter: 81.0 mm (3.2 in.)
: Length: 46.0 mm (1.8 in.)
Weight : Approx. 145 g (5.12 oz.)
Magnification : Approx. 1.6
Focal range : 608 mm (35mm film equivalent)
Lens composition : 5 elements in 3 groups
Shooting distance
(from the front of the lens)
: 2.15 m – infinity (7.1 ft. – infinity)
Thread diameter
: 52 mm standard filter thread
Conversion Lens Adapter LA-DC52E is required
to attach this lens to the PowerShot S1 IS
Dimensions
: Diameter: 69.6 mm (2.7 in.)
: Length: 66.5 mm (2.6 in.)
Weight : Approx. 145 g (5.12 oz.)
NiMH Battery NB-2AH
(Included with the separately sold NiMH NB4-200 or
the Battery/Charger Kit CBK4-200)
Conversion Lens Adapter LA-DC52E
(Included with the separately sold Lens Adapter/
Hood Set LAH-DC10)
Lens Hood LH-DC20
(Included with the separately sold Lens Adapter/
Hood Set LAH-DC10)
Type : Rechargeable nickel metal hydride battery
Nominal Voltage
: 1.2 V DC
Typical Capacity
: 2300 mAh (Lowest: 2150 mAh)
Cycle Life : Approx. 300 times
Operating Temperature
: 0 – 35 °C (32 – 95 °F)
Dimensions
: Diameter: 14.5 mm (0.6 in.)
: Length: 50 mm (2 in.)
Weight : Approx. 29 g (1.0 oz.)
Thread Diameter : 52 mm standard filter thread
Dimensions
: Diameter: 56.8 mm (2.2 in.)
: Length: 34.5 mm (1.4 in.)
Weight : Approx. 12 g (0.4 oz.)
Thread Diameter : 52 mm standard filter thread
Dimensions
: Diameter: 73.8 mm (2.9 in.)
: Length: 28.2 mm (1.1 in.)
Weight : Approx. 15 g (0.5 oz.)
154 Appendix
Photo Tips and Information
ISO Speed (p. 81)
The ISO speed is the numeric representation of the
camera's sensitivity to light. The higher the ISO speed,
the higher the sensitivity. A high ISO speed allows you
to shoot images in dark indoor or outdoor conditions
without a flash and also helps prevent blurred images
due to camera shake. This is convenient when
shooting images in places where flash photography is
prohibited. The ISO speed setting makes full use of
the available light, resulting in images that convey the
feel of the place they were shot.
ISO 50 equivalent ISO 400 equivalent.
Tip for Using the Self-timer (p. 49)
Normally, the camera shakes a little when you press
the shutter button.
Setting the self-timer to delays the shutter release
for two seconds and allows the camera to stop
shaking, thus preventing a blurred image.
Even better results can be obtained by placing the
camera on a stable surface or by using a tripod to
shoot.
Histogram Function (p. 24)
The histogram is a graph that allows you to judge the
brightness of the shot image. The greater the bias
toward the left in the graph, the darker the image.
The greater the bias toward the right, the brighter the
image. If the image is too dark, adjust the exposure
compensation to a positive value. Similarly, adjust
the exposure compensation to a negative value if the
image is too bright (p. 78).
Dark Image Balanced
Bright Image
Appendix 155
Managing Image Files (p. 110)
About File and Folder Numbers
Images are assigned file numbers from 0001 to
9900, and folders are assigned folder numbers from
100 to 998 (Folder numbers cannot contain 99 in the
last two digits).
Folder File Capacity
Each folder usually contains up to 100 images.
However, since images shot in Continuous mode and
Stitch Assist mode are always saved into the same
folder, a folder may contain more than 100 images.
The number of images may also exceed 100 if a
folder contains images copied from a computer or
images shot with other cameras.
DCIM
DCIM
100 CANON 0001 0002 0099 0100
0101 0102 0199 0200
9801 9802 9899 9900
101 CANON
198 CANON
200 CANON
0001 0002 0099 0100
Folder numbers cannot contain 99 in the last two digits.
Please note, however, that the images in folders
containing 2001 or more images cannot be played
back in this camera.
How to Adjust the Exposure (p. 78)
This camera automatically adjusts the exposure to
shoot images with the optimal brightness. However,
recorded images may sometimes be brighter or
darker than the actual image depending on the
shooting conditions. If this happens, adjust the
exposure compensation manually (p. 78).
Underexposure
The whole recorded image is
dark, which makes white
elements of the image appear
gray. Shooting bright subjects or
in backlit conditions may cause
the image to be underexposed. Adjust the exposure
compensation towards the + end.
Optimal Exposure
156 Appendix
Overexposure
The whole recorded image is
bright, which makes black
elements of the image appear
gray. Shooting dark subjects or
in dark places may cause the
image to be overexposed. Adjust the exposure
compensation towards the - end.
Appendix 157
Index
Numerics
1st-curtain
.............................................................90
2nd-curtain
............................................................90
A
Adjusting the Exposure
.........................................78
AE Lock
.................................................................86
AEB Mode
.............................................................84
AF Frame ( )
..............................................24, 75
AF Lock Mode
.......................................................94
AF Mode
................................................................65
Aperture value
.......................................................71
Auto ( )
..........................................................27
Auto Power Down.......................................... 66
, 107
Auto Rotate Function
...................................67, 108
Automated Playback (Slide Show)
......................102
B
B/W
.......................................................................82
Battery
Charge batteries
...........................................140
Handling
..........................................................15
Status
..............................................................17
C
CF Card
Formatting
.......................................................18
Handling .........................................................17
Color Effect ( )
..................................................82
Compression
.........................................................32
Continuous Shooting ( )
.................................... 52
Contrast color
........................................................82
Creative Zone
....................................................... 71
D
Date/Time
...................................................... 21, 66
Detailed Display
....................................................24
Digital Zoom
................................................... 50, 65
DISPLAY
........................................................ 12, 24
Display Off..................................................... 66
, 107
Distance Units
.......................................................67
DPOF
Print Order
............................................. 65, 121
Transfer Order
....................................... 66, 126
Drive Mode
..........................................................163
E
Erase all
................................................................65
Erasing
Erasing All Images
..........................................44
Erasing Images Individually
............................43
F
Fast Shutter ( )
................................................. 45
158 Appendix
FE Lock ................................................................. 87
File No. Reset
....................................................... 66
File Numbers
...................................................... 110
Flash
........................................................10, 34, 64
Adjustment Settings
....................................... 88
Sync
............................................................... 64
Timing at which the Flash Fires
...................... 90
Focus
............................................................. 28, 93
Focus Lock
........................................................... 93
Focus-BKT Mode
.................................................. 85
Format
......................................................... 66, 113
Formatting
............................................................. 18
Frame rate
..................................................... 32, 56
FUNC.
................................................................... 61
Function
................................................................ 12
H
Histogram Function
...................................... 24, 154
I
Image Stabilizer
............................................. 12, 29
Image Zone
........................................................... 45
Index Playback
..................................................... 41
Indicator
................................................................ 13
Information View
................................................... 24
Intervalometer
................................................ 65, 91
IS (Image Stabilizer)
.......................................12, 29
ISO Speed
............................................................ 81
J
JUMP
..............................................................12, 42
L
Landscape ( )
.................................................. 45
Language
........................................................23, 67
LCD Brightness
.................................................... 66
LCD Monitor
............................................ 12, 24, 26
Lens Cap
.............................................................. 11
Lens Hood
.......................................................... 137
Light Metering Modes ( )
............................65, 76
M
Magnifying Images ( )
....................................... 40
Manual Exposure ( )
......................................... 74
Manual Focus Mode
............................................. 95
Menu
...............................................................12, 62
My Camera Menu
........................................... 67
Play Menu
...................................................... 65
Rec. Menu
...................................................... 64
Selecting Menus and Settings
........................ 62
Set up Menu
................................................... 66
MF
........................................................................ 12
MF-Point Zoom
..................................................... 65
Appendix 159
Microphone ( ) ........................................... 12, 101
Mode Dial
................................................ 13, 45, 71
Mode Lever
...........................................................12
Movie
Editing
.............................................................57
Recording ( )
...............................................53
Viewing
...........................................................57
Mute
......................................................................66
My Camera Settings
................................... 111, 112
N
Neck Strap
............................................................11
Night Scene ( )
...................................................45
O
Omni selector
........................................................12
Operation Sound
................................. 67, 111, 112
Operation Vol.
.......................................................66
Overexposure Warning
.........................................26
P
Playback
..............................................................100
Playback Mode
............................................... 20, 24
Playback Vol.
........................................................66
Portrait ( )
...........................................................45
Power On/Off
........................................................19
Power Saving Function
................................66, 107
Power/Mode Indicator ........................................... 13
Print Order
..........................................................121
Printing
................................................................119
Protect
...................................................................65
R
Red-Eye Reduction ( )
..................10, 34, 36, 64
Remote Sensor
.....................................................10
Resetting the File Numbers
................................ 110
Resetting the Settings to Default
.......................... 68
Resolution
.............................................................32
Reverse Disp.
....................................................... 65
Review
.................................................................. 65
Rotate
...................................................................65
Rotating Images
..................................................100
S
Saturation
..............................................................82
Save Settings ( )
................................................65
Saving Custom Settings
........................................ 98
Self-timer ( )
....................................... 12, 49, 64
Self-timer Sound
................................. 67, 111, 112
Selftimer Vol.
.........................................................66
Sharpness
.............................................................82
Shooting
Movie
.............................................................. 53
160 Appendix
Shooting Mode ............................................... 20, 24
Shortcut ( )
...........................................12, 65, 69
Shutter
Button
............................................................. 12
Pressing
......................................................... 28
Sound
..................................... 28, 67, 111, 112
Speed
............................................................. 71
Volume
........................................................... 66
Slide Show
................................................... 65, 102
Play Time
..................................................... 105
Repeat
.......................................................... 105
Selecting Images
.......................................... 103
Starting
......................................................... 102
Slow Shutter ( )
................................................ 45
Slow Synchro
................................................. 36, 64
Sound Memos
..................................................... 101
Speaker
................................................................ 12
Standard Display
.................................................. 24
Start-up Image
.............................. 19, 67, 111, 112
Start-up Sound
.............................. 19, 67, 111, 112
Start-up Vol.
.......................................................... 66
Stitch Assist ( )
.......................................... 45, 47
T
Tally Lamp
..................................................... 10, 65
Tele-converter .................................................... 137
Telephoto ( )
...............................................12, 27
Terminal Cover
..................................................... 12
Transfer Order
.................................................... 126
Transmission settings
Image Transmission settings
....................... 126
V
Video System
....................................................... 67
Viewfinder
.......................................................12, 26
Viewing
Images on a TV Set
..................................... 118
Volume
................................................................. 66
W
White Balance ( )
............................................ 79
Wide Angle ( )
............................................12, 27
Wide Converter
................................................... 137
Wireless Controller
............................................. 135
Wireless Delay
...................................................... 64
Z
Zoom
................................................ 12, 27, 40, 50
161
Canadian Radio Interference Regulations
THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE CAUSING
EQUIPMENT REGULATIONS.
Réglementation canadienne sur les intérferences radio
CET APPAREIL NUMERIQUE DE LA CLASSE B RESPECTE TOUTES LES EXIGENCES DU REGLEMENT SUR LE
MATERIEL BROUILLEUR DU CANADA.
FCC Notice
(Digital Camera, Model PC1058)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions;
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
The cables with the ferrite core provided with the digital camera must be used with this equipment in order to comply with
Class B limits in Subject B of Part 15 on the FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or
modifications should be made, you could be required to stop operation of the equipment.
Canon U.S.A. Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516) 328-5600
162
Functions Available in Each Shooting Mode
This chart shows the functions available in each shooting mode. You can shoot with the settings saved in the
mode (p. 98).
Ref. Page
Resolution
(Stills)
Large L {* {* {* {* {* {* U*– {* {* {* {*
p. 32
Medium 1 M1 { { { { { { U – { { { {
Medium 2 M2 { { { { { { U – { { { {
Small S { { { { { { U – { { { {
Resolution
(Movies)
640 x 480 pixels (Fine)
–––––––{ ––––
640 x 480 pixels – – – – – – – {*––––
320 x 240 pixels – – – – – – – { ––––
Compression
Superfine { { { { { { U – { { { {
p. 32Fine {* {* {* {* {* {* U*– {* {* {* {*
Normal { { { { { { U – { { { {
Frame Rate
30 Frames/sec. – – – – – – – {*––––
p. 56
15 Frames/sec. – – – – – – – { ––––
Flash
Auto {* {* {{* {* { ––{ –––
p. 34On – {{{{{U – { { { {
Off {{{* {{{* U*– {* {* {* {*
Red-eye Reduction { { { { { { U – { { { { p. 35
Slow Synchro
On – – {{ – { U – { – { –
p. 36
Off {{ ––{ – U*– {* { {* {
163
Flash Adjust
On {{{{{{{ – { {* {*–
p. 88
Off–––––––––{ {{
Flash Sync
1st-curtain {{{{{ – { – {* {* {* {*
p. 90
2nd-curtain – – – – – { – { { { { {
Flash Pop-up
On {{{{{{{ – {* {* {* {*
p. 34
Off––––––––{{{{
Drive Mode
Single Shot {* {* {* {* {* {* {* {* {* {* {* {*–
Standard Con-
tinuous Mode
– {{{{{ ––{{{{p. 52
10-second
Self-timer
{{{{{{{{{{{{
p. 49
2-second
Self-timer
{{{{{{{{{{{{
Intervalometer – – – – – – – – { { { { p. 91
AF Frame
Center Point {{{{{{{{{* {* {* {*
p. 75
Manual – – – – – – – – {{{{
AF Lock – {{{{{{{{{{{p. 86
Manual Focus – {{{{{{ – {{{{p. 95
Digital Zoom
On { { { { { { ––{ { { {
p. 50
Off {* {* {* {* {* {*– – {* {* {* {*
Ref. Page
164
Exposure Compensation – {{{{{UU
(2)
{ { { –p.78
Light
Metering
System
Evaluative Metering {{{{{{{{{* {* {* {*
p. 76
Center-Weighted
Averaging
––––––––{ { { {
Spot Metering ––––––––{{{{
Center ––––––––{* {* {* {*
AF Point ––––––––{ { { {
AE Lock/FE Lock – – – – – – – {
(3)
{{{ –
p. 86, 87
Bracket
AEB ––––––––{ { { –p.84
Focus-BKT ––––––––{
(1)
{
(1)
{
(1)
{
(1)
p. 85
White Balance
(4)
WB –
(5)
{{{{{U {
(6)
{ { { { p. 79
Photo Effect – {{{{{U { { { { {
p. 82
Contrast/Sharpness/
Saturation
––––––––{ { { {
Focus Settings
Continuous {* {* {* {* { { U* { {* {* {* {*
p. 97
Single { { { { { { U – { { { {
ISO Speed –
(7)
–
(7)
–
(7)
–
(7)
–
(7)
–
(7)
–
(7)
–
(7)
{ { { {
(8)
p. 81
Auto Rotate
On {* {* {* {* {* {* U*– {* {* {* {*
p. 108
Off { { { { { { U { { { { {
Ref. Page
165
* Default setting {: Setting selection is possible. U: Setting can only be selected for the first image.
–: Setting selection is not possible.
: Setting remains in effect even when the camera is turned off.
The default for the settings changed by the menu and button operations can be restored all at once except for
[Date/Time], [Language] and [Video System] (p. 68).
(1) Selectable only in manual focus.
(2) Can be set after AE lock is set.
(3) AE lock only is available.
(4) Cannot be adjusted when the photo effect is set to [Sepia] or [B/W].
(5) The white balance is set to [AUTO].
(6) The white balance [Flash] cannot be set.
(7) The ISO speed is automatically set by the camera.
(8) ISO [AUTO] cannot be selected.
