OWNER’S MANUAL
SLIM SOUND BAR
Please read this manual carefully before operating your set and retain it
for future reference.
NB2338A
www.lg.com
ENGLISH
NB2338A-N0.EVENT.130114..indd 1 2013-05-07 3:01:05
1 Getting Started
Getting Started
2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral
triangle is intended to alert the
user to the presence of uninsulated
dangerous voltage within the
product’s enclosure that may be of
sucient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION concerning the power cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. hen installing the product, ensure
that the plug is easily accessible.
NOTICE : For safety marking information including
product identication and supply ratings, please
refer to the main label on the bottom of the
apparatus.
NB2338A-N0.EVENT.130114..indd 2 2013-05-07 3:01:05
Getting Started
3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
NB2338A-N0.EVENT.130114..indd 3 2013-05-07 3:01:05
Getting Started
4
Getting Started
1
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
y
Reorient or relocate the receiving antenna.
y
Increase the separation between the equipment
and receiver.
y
Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
y
Consult the dealer or an experienced radio/TV
technician for help.
FCC WARNING: This equipment may generate
or use radio frequency energy. changes or
modications to this equipment may cause harmful
interference unless the modications are expressly
approved in the instruction manual. The user could
lose the authority to operate this equipment if an
unauthorized change or modication is made.
NB2338A-N0.EVENT.130114..indd 4 2013-05-07 3:01:05
Table of Contents
5
1
2
3
4
5
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 – Auto power down
6 – DRC (Dynamic Range Control)
6 Introduction
6 – Symbols Used in this Manual
6 Accessories
7 Top panel
7 Rear panel
8 Installing the sound bar
8 – Standing in front of the TV
8 – Mounting the unit on a wall
2 Connecting
10 Connecting the AC adapter
10 Connect to your TV
10 – OPTICAL In connection
3 Operating
11 LG Sound Sync
11 – With wired connection
4 Troubleshooting
12 Troubleshooting
13 Specifications
5 Appendix
14 Trademarks and Licenses
14 Maintenance
14 – Handling the Unit
NB2338A-N0.EVENT.130114..indd 5 2013-05-07 3:01:05
Getting Started
6
Getting Started
1
Unique Features
Auto power down
This unit will be o itself to save electric
consumption in the case main unit is not
connected to external device and is not used for 25
minutes.
So does this unit after six hours since Main unit
has been connected to other device using analog
input.
But the unit can turns on automatically based on
the [AUTO POWER] function you've set.
AUTO POWER On/Off
This function is intentionally designed to turn o
the unit after 1 minute of inactivity. This function
automatically turns on/o the unit when you turn
on/o the external device (TV, DVD Player, Blu-
ray Disc Player, etc.) connected to this unit by the
optical cable.
DRC (Dynamic Range Control)
Makes the sound clear when the volume is turned
down (Dolby Digital only).
Introduction
Symbols Used in this Manual
,
Note
Indicates special notes and operating features.
>
Caution
Indicates cautions for preventing possible damages
from abuse.
Accessories
Please check and identify the supplied accessories.
Power cord (1) Adapter (1)
Wall Mount Bracket
Installation Template
(1)
Wall mount bracket (1)
Optical cable (1) Cable ties for arranging
cables(2)
NB2338A-N0.EVENT.130114..indd 6 2013-05-07 3:01:06
Getting Started
7
Getting Started
1
Top panel
a
1/!
(Standby/On)
Switches the unit ON or OFF. Press
1/!
to turn
on or o the unit.
b
– / + (Volume)
Adjusts speaker volume. Press – / + to adjust the
volume level.
When the unit turns on, volume of the unit will
rise gradually to the volume level set at the
unit turned o.
,
Note
Rear panel
a
DC. IN
b
S/W Download Connector - Only for service.
c
OPT. IN
NB2338A-N0.EVENT.130114..indd 7 2013-05-07 3:01:06
Getting Started
8
Getting Started
1
Installing the sound
bar
Standing in front of the TV
You can hear the sound by connecting the unit to
the other device : TV, Blu-ray disc player, DVD player,
etc.
Place the unit in front of the TV and connect it to
the device.
Mounting the unit on a wall
You can mount the unit on a wall.
Prepare screws and brackets.
Unit
Wall mount bracket
Wall Mount Bracket
Installation Template
1. Match the TV’s BOTTOM EDGE of Wall Mount
Bracket Installation Template with the bottom
of TV and attach to the position.
TV
NB2338A-N0.EVENT.130114..indd 8 2013-05-07 3:01:07
Getting Started
9
Getting Started
1
2. When you mount it on a wall (concrete), use the
wall plugs (Not supplied). You should drill holes.
A guide sheet (Wall Mount Bracket Installation
Template) is supplied to drill. Use the sheet to
check the point to drill.
Screws and Wall Plugs are not supplied for
mounting the unit. We recommend the Hilti
(HUD-1 6 x 30) for the mounting.
,
Note
3. Remove the Wall Mount Bracket Installation
Template.
4. Fix the brackets with screws (not supplied) as
shown in the illustration below.
5. Hang the main unit onto the bracket as shown
below.
y
Do not install this unit upside down. It can
damage the parts of this unit or be the
cause of personal injury.
y
Do not hang onto the installed unit and
avoid any impact to the unit.
y
Secure the unit rmly to the wall so that it
does not fall o. If the unit falls o, it may
result in an injury or damage to the product.
y
When the unit is installed on a wall, please
make sure that a child does not pull any of
connecting cables, as it may cause it to fall.
>
Caution
Detach the unit from the bracket as shown
below.
,
Note
NB2338A-N0.EVENT.130114..indd 9 2013-05-07 3:01:07
2 Connecting
Connecting
10
Connecting
2
Connecting the AC
adapter
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC. IN adapter
input.
3. Plug the AC power cord into an AC outlet.
Only use the AC adapter supplied with this
device. Do not use a power supply from
another device or manufacturer. Using any
other power cable or power supply may cause
damage to the device and void your warranty.
>
Caution
Connect to your TV
You can listen to the sound from the external
device via the unit.
OPTICAL In connection
Connect the OPT. IN jack on the back of the unit
to optical out jack on the external device using an
optical cable.
TV
Optical cable
Blu-ray disc player,
DVD player, etc.
NB2338A-N0.EVENT.130114..indd 10 2013-05-07 3:01:08
3 Operating
Operating
11
Operating
3
LG Sound Sync
You can control some functions of this unit by
your TV's remote control with LG Sound Sync. It
is compatible with the LG TV that is supported LG
Sound Sync. Make sure of the LG Sound Sync logo
on your TV.
Controllable function by LG TV's remote control :
Volume up/down, mute
Refer to the TV's instruction manual for the details
of LG Sound Sync.
Make one of the following connections, depending
on the capabilities of your equipment.
y
When the connections failed, make sure of
the condition of the TV and power of it.
y
Make sure of the condition of this unit and
the connection in the cases below when
using LG Sound Sync.
-
Turned o the unit.
-
Disconnecting the optical digital audio
cable.
,
Note
With wired connection
1. Connect your LG TV to the unit by using an
optical digital cable.
TV
Optical digital cable
2. Set up LG Sound Sync (Optical) on the TV. Refer
to the TV's instruction manual.
3. Turn on the unit.
You can listen to the TV sound if connecting
normally between this unit and your TV.
The amount of time to turn o this unit is
dierent depending on your TV when you set
AUTO POWER function to ON.
,
Note
NB2338A-N0.EVENT.130114..indd 11 2013-05-07 3:01:08
4 Troubleshooting
Troubleshooting
12
Troubleshooting
4
Troubleshooting
PROBLEM CORRECTION
No Power
Plug in the power cord.
Check the condition by operating other electronic devices.
No sound
Check the OPTICAL IN connection.
The AUTO
POWER
function does
not work.
Depending on the connected device by the optical cable, this function may not operate.
When you
sense that
outputted
sound of the
unit is low.
Check the details below and adjust the unit according to them.
y
With the sound bar connected with TV, change the AUDIO DIGITAL OUT setting on TV
Setup Menu from [PCM] to [AUTO] or [BITSTREAM].
y
With the sound bar connected with Player, change the AUDIO DIGITAL OUT setting on
Player Setup Menu from [PCM] to [PRIMARY PASS-THROUGH] or [BITSTREAM].
y
Change Audio DRC setting on Player setup menu to [OFF] state.
NB2338A-N0.EVENT.130114..indd 12 2013-05-07 3:01:08
5 Appendix
Appendix
13
Appendix
5
Specifications
General
Power requirements AC 120 V, 60 Hz
Power consumption DC 18 V
0
12.3 W
Dimensions (W x H x D)
950 mm x 35 mm x 78 mm
(37.4 inches x 1.4 inches x 3 inches)
Net Weight (Approx.) 1.8 kg (4 lbs)
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Inputs
DIGITAL IN (OPTICAL IN) 3 V (p-p), Optical jack x 1
Amplier
Stereo mode 30 W + 30 W (4 Ω at 1 kHz)
y
Designs and specications are subject to change without prior notice.
Power consumption
11 W
NB2338A-N0.EVENT.130114..indd 13 2013-05-07 3:01:08
Appendix
14
Appendix
5
Trademarks and
Licenses
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
1. No decoding mode indication only dolby
digital signals can be decoded.
2. Missing License Notice on product
Manufctured under license from Dolby
Laboratories.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S.
and worldwide patents issued & pending. DTS,
the Symbol, & DTS and the Symbol together are
registered trademarks & DTS 2.0 Channel is a
trademark of DTS, Inc. Product includes software.
© DTS, Inc. All Rights Reserved.
This product is manufactured under licence
from Sontia Logic Limited and contains software
which is protected under international copyright
laws © Sontia Logic Limited. All rights reserved.
Sontia® and the Sontia wave logo are registered
trademarks of Sontia Logic Limited.
Maintenance
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
y
Do not use volatile liquids such as insecticide
spray near the unit.
y
Wiping with strong pressure may damage the
surface.
y
Do not leave rubber or plastic products in
contact with the unit for a long period of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
NB2338A-N0.EVENT.130114..indd 14 2013-05-07 3:01:08
Printed in China
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
NB2338A-N0.EVENT.130114..indd 15 2013-05-07 3:01:08
